1. Introduction
1.1 Acknowledgement
iVIEW's new 6'' Supra mini 600 is the next-generation tablet with 2G / 3G Phone
and supports frequencies to cover most countries in the world. It features with
6'' IPS high resolution screen (960*540) and strong processors of Dual Core A7
CPU providing access to the web for news, weather, or local business info;
downloading thousands of Apps from the King Kong Market to tap your need,
such as games, favorite movie clips, music, and videos. With built-in bluetooth
you can connect to Bluetooth speaker system and earphone to listen to music,
or connect to a bluetooth keyboard for easy typing, and send files to another
tablet or mobile phone with bluetooth function. The GPS feature is another plus
that helps with the road navigation. With memory of 8GB, you may store plenty
of pictures, movies, and documents. Expansion storage is up to 32GB via Micro
Card Reader slot. iVIEW-600 Supra mini is your all-in-one tablet that you can't
live without.
1.2 Announcements
Preventive Maintainance
● Please always keep the MID dry. To avoid the device short trouble,
corrosion fault and electric short. Please prevent the device, battery and
charger from water and moisture, and don’t operate the device or
charger by wet hand.
● To avoid failure of device, battery and charger, please prevent the device,
battery, charger from violent shock or shake.
● To avoid failure of device, battery and charger, please prevent the device,
battery, charger of all over heating or too cold circumstance.
● Never shock, throw, prod the MID, or drop, extrude, bend the MID.
3
● Never disassemble the device and accessories arbitrarily, otherwise the
device and accessories are not in our company warranty scope.
1.3 Safety Instruction
Before the operation of the MID, please read this chapter and teach your
kids about these information. For further details, please refer to the safety
instructions and announcement.
● Never use the MID when driving car, in order to ensure safe driving.
● In the medical area, please abide by related rules and regulations. Please
shut down the MID when it is near to the medical area.
● To avoid the wireless signal to interrupt the plane- controlled signal, please
shut down the MID or using airplane mode when you are boarding a flight.
● To avoid electronic equipment failure, please shut down the MID in the
vicinage of high-accuracy electronic equipments.
● Please don’t disassemble the MID and accessories. Only authorized
agent has access to service the MID.
● Please keep the MID far away from magnetic equipments, the radiation
of MID may erase the data stored in the magnetic equipments.
● Never use the MID in the vicinage of high temperature, inflammable gas
(gas station)
● Protect the MID and accessories from kids reach scope, and avoid the
kids to use the MID without parents’ supervision.
● Please comply with related rules and regulations, and respect others’
privacy and legal rights while using the MID.
● Please strictly adhere to related instructions in the manual when using
USB cable to ensure the safety of the MID or PC.
● Never use the MID in bathroom or other humid environment, and please
protect the MID from liquid wash or wet.
4
1.4 Appearance and button:
Touch Panel
Fornt Camera
Earphone Jack
Flash Light
Back Camera
USB
Volume-
Volume+
Power
* Touch panel
6” Capacitive touch panel: During the operation, you can click and drag items
on the touch panel.
5
* POWER
To power on: Press and hold the power button, the system will enter the
main interface.
To power off: In the main menu interface, press the power button for about
5 seconds to power off, the system will appear "power off" option, click ”ok”
and you can safely power off.
Lock screen: Press power button to lock screen or unlock screen.
【Remark】: When the power ran out, the system will power off automatically.
* Volume + / Volume-
The buttons Volume + / Volume- located on the side of the tablet which
allow to adjust volume.
* Front Camera, Back Camera
Front 0.3MP, Back 5.0MP with Flash Light
* SIM Card
Portable exchangeable memory chip for phone function.
* Card Reader
Card Reader Slot: External micro SD card.
* Earphone Jack
3.5 mm standard earphone jack.
* Micro USB
Micro USB Jack: You can use it to connect the computer for data
transmission, charging, or use the USB charger to charge.
6
* Reset
When the tablet fails to respond when buttons are pressed, using a thin
small object (such as a paperclip) to press RESET button, the tablet will
force to reset.
【Remark】: Unless it’s unable to power off by normal procedure, otherwise
don’t use the reset option.
1.5 Abbreviation/Terminology
Abbreviation/Terminology Full Name Description
MID Mobile Internet Device Mobile Internet Terminal
WIFI Wireless Fidelity
TF
TransFlash
Base on IEEE 802.11b standard
wireless LAN
Alternative name Micro SD, super
miniature memory card
2. MID Introduction
2.1 MID Accessories Introduction
Package:
Below items are included in your tablet package:
● MID complete device
7
● Power adaptor
● USB cable
● OTG cable
● Earphone
● SIM card adapter *2
● User manual
2.2 MID Operation and Preparation
Battery Charging
If this navigator is first used, please use AC adaptor to fully charge it.
1. Apply the power adptor to charge for MID.
2. Don’t pull out the adaptor while charging.
2.3 MID Status and Reminder
Reminder Icons
When some remind message appears in your reminder window, please click
column and slip the screen to open the reminder list. Choose the menu
you need, and confirm the information. Then you can close the reminder
window through clicking the column to slide up. Please refer to below status
icons:
8
New email Airplane Mode on
USB connected
Return button
Current electric
volume
Home button, display recently-used application by holding it
Reminder board
Reminder icons will work whiles receiving emails. When WIFI is open, you
can open the reminder board to view the detailed information.
Open the reminder board
When the reminder column shows new reminder icon, please hold the
column and slip down your finger, then the reminder board is opened.
USB adjustment
connected
Downloading
WIFI connected,
internet is available
3. Quick Start Guide
3.1 Keys Function
Keys Function Description:
9
Power button
Volume
+ (up)
Volume
- (down) Decrease the volume.
HOME button (home)
Back button
Menu button
Short press to sleep/wake up, long press to startup
and Shut down.
Increase the volume.
Press the Home button will get you back to the Home
Interface.
Press and hold the Home button to display
recently-used applications..
Click it in any interface will return toprevious menu.
This button will display in menu interface.
3.2 Startup and Shut down
Startup
Long press POWER key for three seconds, you can enter into startup
picture. The system enters into screen lock status, please unlock it.
Shut down
1. Long press POWER, it will popoup Shut down window.
2. Shut down window contains options: Power off, Reboot, Airplane
mode, profiles.
3. Then click Power off.
3.3 Open and Close of the Screen
Screen will be closed on its own when no operation is taking place.
1. Screen will be closed on its own if no operation is taking place for
some to save battery power.
2. When screen is open, press POWER key, the screen will be closed
immediately.
10
Open the screen when it is closed.
If the screen is closed, short press POWER to open the screen. The screen
will be locked open it, it will show the picture as below picture, left slide to
unlock and enter into camera, right slide the unlock icon to unlock the screen.
Picture 3.1
3.4 Usage of Touch Screen
MID operating methods
There are below methods to view the main screen, menu and application
procedure in your MID.
Click
When you want to use the screen keyboard typing or choose application in
the main interface, you only need to touch it by your finger.
Press on
If you want to open some item( textbox or the link in the webpage), or
shortcut and main procedure move, you can press on this item.
11
Quickly Slide or Slide
Quickly slide or slide indicates make quick vertical or horizoncial movement
by finger.
Pull
Before you pull, you need to hold the item with strenghth until you pull it into
the position you want.
Rotate
For most pictures, you only need to rotate the MID sidewise to change the
screen direction from horizoncial to vertical. For instance, when you are
typing wods, and watching movies.
3.5 Home Page
In the main interface as below picture 3.2, long press the blank and it will
pop up windows to set wallpaper, folder, widgets, and shortcut.
Battery volume
Time
Picture 3.2
12
The extended home page
The home page can be extended beyond the wideness of screen to provide
more space, which you can put new-added shortcuts and widgets. Click the
blank space in home page then slide right or left to extend to the right or left
of the screen. In the home page, there are two extended pictures, as
Picture 3-2.1.
Picture 3-2.1
The shortcut icons management in desktop application.
The system below Android 2.3 have the function of creating folder in desktop,
then put the icons into the floders. Android 4.2.2 system makes the function
of creating new folder become much easier. Operations are as below:
1. Drag the icons need to be put together on one icon (can also overlay
several icons) as Picture 3-2.2.
2. Then click the overlayed icons, the applications can be folded, as
Picture 3-2.3.
13
Picture 3-2.2
Picture 3-2.3
14
Remove the icons in desktop
1. Press and hold the icons need to be remove, then on the right
above of the screen, icon will appear.
2. Drag the icon to the above of the removed icon till the icon
becomes red, then move your finger to delate the icon.
Change the wallpaper of desktop
1. In home page, long press any blank space in main screen, it will
pop up a window to change the wallpaper.
2. Click the gallery or wallpaper gallery to select the wallpaper.
Note:
Before voice searching, please make sure your internet is well
connected.
3.6 Visit Application
Click in Picture 3.2, enter into main interface as Picture 3.3, choose the
application you want to visit.
15
Picture 3.3
3.7 USB Connection
MID storage configuration
Before transmitting documents, you have to conduct storage configuration
for your MID:
1. Connect the MID and computer by USB cable, the reminder column
will show the remind information.
2. Open the reminder board; please view the MID status and reminder
to learn how to open the board.
3. In the reminder board, click the “USB Connected”, it will as below
Picture 3.4, then click “Turn on USB storage”.
4. Now the USB is connected successfully.
16
Loading...
