ITU DT930 Operation Instruction Manual

- 1 -

I.T. Unicode Sdn. Bhd.

(561830-D)

153A, Persiaran Pegaga,

Taman Bayu Perdana,41200 Klang,Selangor,West Malaysia.

Tel:[phone] Fax:[phone]
www.unicode.com.my [e-mail]

Operation Instruction of DT930

Application Installation

- 2 -

Key pad introduction

Display

Scanning
Button

Power On &
Power Off

Key Pad

Function Key
F1 ~ F8

Shift Key
Entry the
Alphabet thru
number key pad

Back Space

Clear Key

- 3 -

RESET DT930 To OS System Menu

To install DT930 Program, LMWin & DT930 Both must be ready.

 Step 1 : Setup LMWIN Software in Computer
 Step 2 : Open the DT930 System Menu Step 3 :
 Step 3 : Set File Mode (for new Device only)
 Step 4 : Transfer Program into DT930 Device

- 4 -

Step 1 : Setup LMWIN Software in Computer

Configuration setting of Computer

Press to start Link Manager.

Press to execute script command. Follow as below.

Click [OK] to confirm.

- 5 -

DT930 Program files.

Make sure the DT930 Program is store in location
C:\DT930\Program\
The file at least content 2 files.

Eg. , the filename can be different but
the extension must be .LOD .

- 6 -

Step 2 : Set DT930 File Mode (for new Device only)

Please

Press [4].UTILITY
Will appear

Will appear

Press [2]. DT700 MODE

Press [CLR]. 3 TIMES, BACK TO TRANSMIT SCREEN.

TRANSMIT

1:SEND FILE
2:RECEIVE FILE
3:FORMAT DRIVE
4:CHG MEM SIZE
5:FILE MODE

FILE MODE

1:NORMAL MODE
2:DT700 MODE

DRV TO FORMAT

A DRIVE

|***.......|020%

- 7 -

Step 1 : Open the DT930 System Menu

The following will descript the DT930 part.

1. Make sure DT930 is in Power Off mode.

2. Hold down the [S] & [.] than press [PW] button. (Press 3 button at
the same time.)
If reset successfully, you will see the following screen.

Press [4].TRANSMIT,
Will appear

SYSTEM MENU

1:EXECUTE AP
2:SET MODE
3:DATE/TIME
4:TRANSMIT
5:VERSION

TRANSMIT
1:MULTI INSTALL
2:AP INSTALL
3:DUPLICATE HT
4:UTILITY
5:PROTOCOL FLNK
6:PORT SIR

7:SPEED 115K

- 8 -

Step 3 : Set Communication Setting

TRANSMIT SCREEN ( Setting for using USB Cradle IO Box)

TRANSMIT
1:MULTI INSTALL
2:AP INSTALL
3:DUPLICATE HT
4:UTILITY
5:PROTOCOL FLNK
6:PORT FIR

7:SPEED 4M

Press button:
[6],[2],[ENT]

- 9 -

Step 4 : Transfer Program into DT930 Device

Press

[4]

UTILITY

Press

[1]

TRANS FILE

RECEIVING SCREEN

Run the program

Press

[CLR] , [CLR]

Press

[1]

EXECUTE AP

Press

[ENT]

Program will executed, the main will vary by program.

TRANSFER FILE
RECEIVE(IR)

TRANSFER FILE
RECEIVE(IR)
KOSSAN.LOD

02%

|**............|
