Introduction

This document details the features and functions of the Itron Mobile Radio and provides information relating to it s use and maintenance.

The Itron Mobile Radio is equipped with the following features.

• Radio button. For informati on about the radio button, see Button Functions on page 9.

• LED status indicators. For information about the LED indicators, see LED Status

Indicators on page 9.

• USB communication port. For information about the USB communication port, see USB

Communication Port on page 13.

Documentation Conventions

Convention

Example

This guide uses the following documentation conventions:

Hypertext links ap pear in blue text. See Copyright for identification information.

Warning This type of note is used to warn of potential physical harm to the

user or hardware. It is critical that you pay strict attention to Warning notes, read the information carefully, and heed the advice and/or instructions.

Caution This type of note advises users that failure to take or avoid a specified

action could result in a loss of data.

Note Indicates neutral or positive information that stresses or supplements important points of the main text. A note supplies information that may apply only in special cases.

Unpacking Your Itron Mobile Radio

Item

Description

• Itron Mobile Radio with

• AC power adapter

• Communication cable

• Battery kit

• Documentation

Itron Mobile Radio Qui ck Reference Guide

The Itron Mobile Radio comes with the following items.

built-in antenna

AC wall plug with USB type A port. USB cable. Battery, battery compartment cover, screws, gasket

Itron Mobile Radio Compliance Statement

An optional Radio Carrying Kit is available for order separately. The Radio Carrying Kit contains a belt clip and a sho ulder harness.

When you unpack your radio, make sure you have all of the components listed here. If any are missing, contact Itron Support Services immediately.

After you install the battery, charge the radio to 100 percent capacity befor e using it. Complete charging ta kes about six hours.

For more information about the battery, see Battery Basics

To install and charge the battery

1. Plug the connector into the socket in the battery compartment.

You will have to bend the wires at the connector at a 90 d eg r ee angle.

2. Insert the battery into the compartment.

• Make sure the battery lab el is facing th e r idges on the radio case.

• Make sure the wires are alon g the same side as the connector.

• Make sure the removal tab is facing out.

Caution Do not pinch the battery wires when replacing the battery compartment cover.

3. Replace the battery compartment cover making sure the gasket is properly aligned for water

tightness.

4. Fasten the battery com partment cover in place with the provided screws.

Tighten the screws to ens ure water tightness.

5. Plug the USB cable into the Itron Mobile Radio.

6. Plug the USB cable into a PC, an AC wall adap ter, or a 12V AC car adapter.

7. Allow the Itron Mobile Radio to charge for at least six hours.

Daily Operation

• Inspect the radio for broken, loose, or missing parts and fasteners, tak ing corrective action as

required.

• Make sure the radio is operated and stored within the recommended temperature range.

Operating temperature: -4° F to 140° F (-20° C to 60° C) Storage temperature: -40° F to 158° F (-40° C to 70° C)

• Cold temp er ature extremes may result in reduced ava ilable energy f r o m the battery

pack. This energy is recoverable as the battery pack warms to 68° F (20° C).

• Do not subject the radi o to extreme temperatures, such as leaving it in a vehicle in

bright sunlight. Extended exposure to warm temperature extremes can result in permanent reduction in available energy from the battery pack .

• Exit all externa l applications at the end of each work day. This ensures that all applications

communicating with the radio have terminated their Bluetooth links.

• Charge the battery nightly.

Turning the Radio On or Off

To turn the radio on (battery power)

• Press and hold the button for three seconds (until the Power LED turns green) to turn the

radio on.

To turn the radio off (battery power)

• Press and hold the button for three seconds (until the Power LED turns white) to to turn the

radio off.

To turn the radio on (AC adapter)

• The radio is always on when using the AC adapter.

When the radio is using external power (connected to an energy source with the USB cable) pressing the button turns the power LED green until the button is released, but it does not turn the radio off.

LED Status Indicators

Two mu lti-color LED status indicators are loca ted on the top of the radio. These indicators are labeled with a power icon and a communication icon . The color and illumination of the

LED lights provide feedback about the Itron Mobile Radio's status. The LED lights have two patterns for displaying different states.

• Solid. Continuou s without interruption or alteration

• Flash. Alternating periods of colored illumination follo w ed by periods of non-illumination

of the indicator. The color remains consistent during all illumination periods.

The following tables describes the LE D colors and patterns for the most common radio conditions.

Power indicator

Solid

Flash

• Error: Battery

• Turning on

• Initializing

• Charged

• Button pressed

N/A

Charging

Error: General

Battery more than 50%

Battery more than 20%

Battery less than 20%

Comm indicator

Solid

Flash

USB connec ted

Bluetooth® connec ted

Error

Bluetooth low energy connected

Note The application connected to the radio may assign a display pattern to the LEDs that is not described in these tabl e s .

USB Communication Port

When you connect the Itron Mobile Radio to a PC using Windows 7 or Windows

The Itron Mobile Radio has one USB communication port under a protective rubber flap on the side of the radio near th e top.

In addition, the radio is equipped with an int ernal port for wireless Bluetooth communication is in place through Bluetooth, attaching the USB cable only provides power. Communication may occur through Bluetooth whi le c harging with the USB.

Note

8, you may see a prompt to install an updated Texas Instruments driver for the device. Install the necessary driver.

communication s. If

Carrying the Itron Mobile Radio

carrying the radio, make sure the side with the ridges is facing away

The Itron Mobile Radio’s shoulder harness and belt clip provide convenient, hands-free ways to carry the radio while installing, reading, and maintaining meters and endpoints. The shoulder harness and belt clip let you wear the radio comfortably while walking or driving.

As a safety feature, the clips are designed to break away if the radio snags or becomes caught, releasing the wearer and reducing the likelihood of injury.

The radio may also be carried in a pocket, backpack, or bag. The radio is water resistant.

Note If you are from your body, conductive materials, or anything else which may shield the radio signal.

Maintaining Your Itron Mobile Radio

Your Itron Mobile Radio is rugged and water-resistant. However, you should take the following precautions to ensure that it gives you many years of rel iable service.

• Do not subject the radi o to extreme temperatures, such as leaving it in a vehicle in bright

sunlight. For more information, see Battery Best Practices

• Do not leave it in damp or dusty places.

• Do not drop your radio or subject it to severe impacts.

• Do not use products containing DEET near the Itron Mobile Radio. DEET will degrade the

radio's casing.

• When installing or replacing the battery, make sure to follow the provided instructions to

maintain water tightness.

• Use the rubber flap to protect the radio’s USB port in dusty conditions.

To clean the Itron Mobile Radio case

1. Wipe the radio’s case with a damp cloth.

2. Use a soft-bristle brush to remove stubborn deposits.

3. Blow any water out of the c onnector and then leave the radio to drain an d air-dry.

Warning Never use solvents of any kind on the case. Do not expose it to

temperatures above 140° F (60° C).

Storing Your Itron Mobile Radio

Your Itron Mobile Radio can be safely stored for two week s or less with simple preparation. Follow the steps below to prepare your radio for short-term stor age.

To store your Itron Mobile R adio

• Connect the Itron Mobile Radio to external power and allow the battery pack to fully charge.

For information about charging status, see LED Status Indicators on page 9 If you are storing th e Itron Mobile Radio for an extended period of time, you should let it

remain charging or remove its battery.

Note Remove th e Itron Mobile Radio’s battery before stor ing the device for periods longer than two weeks.

Battery Basics

The Itron M o b ile Radio uses a rechargeable lithium-ion (Li-Ion) battery pack as its main power source whenever it is not receiving power through its USB cable.

Caution Do not use any power source other than the Itron-recommended

Charge the r adio's battery to 100 percent capacity before using it. Complete charging takes about six hours. Charge the battery pack through the USB cable, which can draw power from a computer, an AC wall outlet, or a 12V DC car adapter.

battery. Using another power source could damage the radio.

Warning Risk of Explosion! There is a risk of explosion if the battery is

replaced by an incorrect battery type. Dispose of used batteries in accordance with local regulatory guidelines.

Attention Il y a danger d’explosion s’il y a remplacement incorrect de la

batterie. Remplacer uniquement avec une batterie du même type ou d’un type equivalent recommandé par le constructeur. Mettre au rebut les batteries usagées conformément aux instructions du fabricant.

Battery Best Practices

Itron recommends the following practices to ensure long battery life.

• Charge the r adio at the end of each work day.

• Check the charge status at the beginning of each work day.

• Charge the r adio at room temperature (6 8° F/20° C).

• Charging is disabled below 32° F (0° C) and above 104° F (40° C) to protect the lithium-ion

batteries.

• In cold weather, keep the radio inside your outer clothing. A cold battery will not last

all day even with full charge. Metalized fabrics should not be worn over the radio as they may severely reduce reading success.

• In hot weather, keep the radio out of direct sunlight. A hot battery's capacity is

degraded o v er time and eventually the b attery will not l ast all day even with a full charge.

• Shallow or partial discharge and charge cycles are pr eferred, rather than allowing the battery

pack to drain completely before recharging it.

• Charging after a shallow or partial discharge does not degrade battery pack life or

performance.

Safety

Your Itron Mobile Radio is ergonomically designed for safe, comfortable use. However, as with all equipment, you should follow good working practices while using it.

Minimize risk by following these guidelines.

• Maintain good posture while using the radio. Keep your fingers and body relaxed whenever

possible.

• Avoid keeping your muscles tense for long periods. Change tasks often to avoid prolonged

muscle strain. Support the radio while using it.

• Take frequent short breaks. Use these breaks to exerc ise the mu scles in your h ands, arms,

shoulders , neck, and back.

AC Power Adapter

Follow these instructions to help ensure your safety and extend the life of the adapter.

• Use the adapter indoors only.

• Avoid spilling liquid on the adapter.

Do not connect it if it is damp.

• Make sure ventilation around the adapter is not restricted while it is in use.

• Use only the AC adapter sup p lied with your Itron Mobile Radio.

Do not substitute an alternative or unapproved adapter; this may damage the Itron Mobile Radio and void the warranty.

• Inspect the AC adapter b efore use.

Do not use it if there are any signs of damage or deteriora tion.

• Make sure the connector is firmly connected.

• Avoid mechanical st r ain to cables and connectors.

• In the event o f o v erloadin g , t he AC adapter is designed to be fail-safe and may stop

functioning.

• Do not try to use the AC adapter to power any other equipment.

• Avoid use in dusty, damp, or contaminated environments.

Usage in Hazardous Locations

This device is suitable for use in Class 1, Division 2, Groups A, B, C, D locations. It should only be used with computer s yst ems approved for use in hazar dous locations.

Warning—Explosion Hazard Do not replace the battery unless power has been

switched off or the area is known to be non-hazardous.

Avertissement—Risque d’Explosion Couper le courant ou s’assurer que

l’emplacement est designe non dangereux avant de replacer le composants.

Warning—Explosion Hazard Do not disconnect equipment unless power has

been switched off or the area is known to be non-hazardous.

Avertissement—Risque d’Explosion Avant de deconnecter l’equipem ent, c ouper

le courant ou s’assurer qu l’emplacement is designe non dangereux.

Warning—Explosion Hazard Substitution of components may impair suitability

for Class 1, Division 2 locations.

Avertissement—Risque d’Explosion La substitution de composants peut rendre

ce materiel inacceptable pour les empl acements de class e 1, division 2.

Troubleshooting

Problem

Possible Solutions

• If charging from a PC through the USB cable, try a different

issue, replace the battery.

If you have a problem with your Itron Mobile Radio, review the appropriate troubleshooting steps listed belo w. If the problem remains un r esolved, contact an Itron customer service representative (e-mail: support@it ron.com; phone: 1.877.487.6602).

Battery does not charge

USB port on the PC. The port may be bad or incapable of providing sufficient current for charging.

• Try a different AC outlet.

• Make sure the USB port is clean and free of dirt or other

contaminants.

•

If the previous troub leshooting suggestions do not solve the

Problem

Possible Solutions

Battery power drains

• Make sure the battery indicates a full charge following an

issue, replace the battery.

• Install Texas Instruments drivers.

• See your application’s user guide for setup information.

quickly

overnight charge (see LED Status Indicators on page 9).

• If the previous troub leshooting suggestions do not solve the

USB connection problems

• Inspect the USB port for damage, dirt, or other contaminants.

Bluetooth connection problems

Radio will not turn off Radio will not turn on

Disconnect the radio f r om external power sources and press the button firmly for six seconds. This will force th e radio t o reset its firmware.

Optimizing Bluetooth® Performance

Bluetooth communication works best when the communicating devices have an unobstructed view from one devi ce to the other. When possible, remove or reduce obstacles between the Itron Mobile Radio and the mobile devi ce during Bluetooth c om mun ication.

Tips for Radio Readings

The Itron Mobile Radio is used to receive the radio signals from ERT-equipped meters. To maximize the radio capabilities, consider t he following factors when collecting data.

• Absorption. Conductive material such as steel, metallic pipe and siding, and tree leaves and

branches absorb more of a radio signal than concrete, bricks, sheetrock, plastic, and wood. Due to absorption, you may have shorter readability distances in industrial or business areas than in residential areas.

• Shielding. When con d uctive materials are clos e together, as in metal partitions or narrow-

mesh fencing , they act as a shield and absorb the entire radio signal. Move a short distance away from conductive material so the ERT signal is not shielded. Keep moving to assist in receiving signals that may be shielded. Metalized fabrics should not be worn over the radio as they may severely reduce reading success.

• Reflection. Radio signals can be r ef lected by some of the same types of conductive material

that absorb th em. Move a short distance away from the reflective material to find the direct ERT signal or a strong reflected signal. Keep moving to assist in receiving signals that may be reflected.

Itron Mobile Radio Capabilities and Limitations

Equipment Description Itron Mobile Radio Model: IMR FCC ID: EO9IMR IC: 864A-IMR

Itron Mobile Radio Transmitter Information

Transmit frequency MAS, FCC: 952 MHz–960 MHz Transmit frequency MAS, ISED: 952 MHz–953 MHz Transmit frequency ISM: 908 MHz–923.8 MHz Antenna type: Directional antenna with maximum gain perpendicular to the front face of the IMR unit. Receiver Information Frequency ISM: 908–923.8 MHz

Bluetooth Manufacturer: Panasonic Model: PAN1326B FCC ID: T7V1316 IC: 216Q-1316 Transmitter class: Class 1 Transmit/receive frequency: 2402 MHz–2480 MHz Maximum transmitter power: 10.5 dBm Antenna type: integral, chip
