Series 3 Digital Force Gauges User’s Guide
1
Thank you…
Thank you for purchasing a Mark-10 Series 3 digital force gauge, designed for
tension and compression force testing applications from 0.12 lbF to 500 lbF
(0.5 N to 2,500 N) full scale. The Series 3 is an essential component of a force
testing system, typically also comprising a test stand, grips, and data
collection software.
With proper usage, we are confident that you will get many years of great
service with this product. Mark-10 force gauges are ruggedly built for many
years of service in laboratory and industrial environments.
This User’s Guide provides setup, safety, and operation instructions.
Dimensions and specifications are also provided. For additional information or
answers to your questions, please do not hesitate to contact us. Our technical
support and engineering teams are eager to assist you.
Before use, each person who is to use the Series 3 force gauge should be fully trained i n
appropriate operation and safety procedures.
TABLE OF CONTENTS
OVERVIEW .........................................................2
POWER ...............................................................3
SETUP ................................................................4
HOME SCREEN AND CONTROLS ...................5
OPERATING MODES .........................................7
CHANGING THE UNITS .....................................7
DIGITAL FILTERS ..............................................7
SET POINT INDICATORS ..................................8
COMMUNICATIONS AND OUTPUTS ...............9
CALIBRATION ................................................ 10
OTHER SETTINGS .......................................... 14
SPECIFICATIONS ........................................... 17
www. .com
information@itm.com1.800.561.8187
Series 3 Digital Force Gauges User’s Guide
2
Qty.
Part No.
Description
M3-012 –
M3-20
M3-50 –
M3-100
M3-200 –
M3-500
1
12-1049
12-1049
12-1049
Carrying Case
1
AC1030 /
AC1032
AC1030 /
AC1032
AC1030 /
AC1032
AC adapter body with US, EU, or UK prong
1
08-1026
08-1026
08-1026
Battery (inside the gauge)
1
G1024
G1024
G1031
Extension rod
1
G1026
G1026
G1033
Cone
1
G1025
G1025
G1032
Chisel
1
G1027
G1027
G1034
V-groove
1
G1029
G1029
G1036
Flat 1 G1028
G1038
G1035
Hook
1
N/A
G1039
G1037
Coupling
1 - Certificate of calibration
1
09-1165
USB cable
1 - Resource CD (USB driver, user’s guides,
software, User’s Guide)
1 OVERVIEW
1.1 List of included items
AC1031 /
1.2 Safety / Proper Usag e
AC1031 /
AC1031 /
MESUR Lite software, MESURgauge DEMO
Caution!
Note the force gauge’s capacity before use and ensure that the capacity is not exceeded.
Producing a force greater than 200% of the gauge’s capacity can damage the internal load cell. An
overload can occur whether the gau g e is powered on or off.
Typical materials suitable for testing include many manufactured items, such as springs, electronic
components, fasteners, caps, films, mechanical assemblies, and many others. Items that should not be
used with the gauge include potentially flammable substances or products, items that can shatter in an
unsafe manner, and any other components that can present an exceedingly hazardous situation when
acted upon by a force.
The following safety checks and procedures should be performed before and during operation:
1. Never operate the gauge if there is any visible damage to the AC adapter or the gauge itself.
2. Ensure that the gauge is kept away from water or any other electrically conductive liquids at all
times.
3. The gauge should be serviced by a trained technician only. AC power must be disconnected and
the gauge must be powered off before the housing is opened.
4. Always consider the characteristics of the sample being tested before initiating a test. A risk
assessment should be carried out beforehand to ensure that all safety measures have been
addressed and implemented.
5. Wear eye and face protection when testing, especially when testing brittle samples that have the
potential to shatter under force. Be aware of the dangers posed by potential energy that can
www. .com
information@itm.com1.800.561.8187
Series 3 Digital Force Gauges User’s Guide
3
USB connector
Power input jack
accumulate in the sample during test ing. Extra bodily protection should be worn if a destructive
failure of a test sample is possible.
6. In certain applications, such as the testing of brittle samples that can shatter, or other applications
that could lead to a hazardous situation, it is strongly recommended that a machine guarding
system be employed to protect the operator and others in the vicinity from shards or debris.
7. When the gauge is not in use, ensure that the power is turned off .
2 POWER
The gauge is powered either by an 8.4V NiMH rechargeable battery or by an AC adapter. Since the
batteries are subject to self discharge, it may be necessary to recharge the unit after a prolonged period
of storage. Plug the accompanying charger into the AC outlet and insert the charger plug into the
receptacle on the gauge (refer to the illustration below). The battery will fully charge in approximately 8
hours.
Caution!
Do not use chargers or batteries other than supplied or instrument damage may occur.
If the AC adapter is plugged in, an icon appears in the lower left corner of the display, as follows:
If the AC adapter is not plugged in, battery power drainage is denoted in a five-step process:
1. When battery life is greater than 75%, the following indicator is present:
2. When battery life is between 50% and 75%, the following indicator is present:
3. When battery life is between 25% and 50%, the following indicator is present:
4. When battery life is less than 25%, the following indicator is present:
5. When battery life drops to approximately 2%, the indic a tor from step 4 will be flashing.
Several minutes after (timing depends on usage and whether the backlight is turned on or
off), a message appears, “BATTERY VOLTAGE TOO LOW. POWERING OFF”. An audio
tone will sound and the gauge will power off.
The gauge can be configured to automatically power off following a period of inactivity. Refer to the Other
Settings section for details.
If battery replacement is necessary, it can be accessed by separating the two halves of the gauge. Refer
to the Mechanical Setup section for details.
www. .com
information@itm.com1.800.561.8187
Series 3 Digital Force Gauges User’s Guide
4
3 SETUP
3.1 Mechanical Setup
3.1.1 Loading shaft orientation
In order to accomm odate a variet y of testin g requ irem ents, th e orienta tion of the loading s haf t ma y be set
up in either of the two positions s hown belo w. In order to change the load ing shaf t orientation, l oosen the
two captive screws on the bac k side of t he h ousing, separat e t he t wo hous ing h alves , rota te one half 180
degrees, and reassem ble. Exerc ise care when re assem bling the two ha lves of the housing, ensuring that
internal wires do not interfere.
Load cell shaft up Load cell shaft down
3.1.2 Mounting to a plate
Proper mounting is important if attached to a fixture or test stand. The round steel insert with a hole in the
back of the housing is provided to withstand the load during a test. A mating dowel pin should be used
(see illustration below). Mounting plates on Mark-10 test stands include a dowel pin and clearance holes
for the four threaded holes located near the corners of the housing. An additional two holes are supplied
for metric screws. These holes are designed to accommodate screws in order to hold the gauge in place
(Mark-10 test stands include a set of thumb screws for gauge mounting). The screws must not
for load bearing purposes. Failure to use a dowel pin properly can result in a hazardous situation.
3.1.3 Mounting attachments to the gauge
The force gauge’s threaded loading shaft is designed to accommodate common grips and attachments
with female mounting holes. To mount a grip, gently thread it onto the shaft. Ensure that the grip or fixture
is positioned to ensure axial load with respect to the loading shaft of the force gauge. When using a grip,
ensure that it secures the sample in such a way that it is prevented from slipping out during a test,
preventing a potential safety risk to the operator and others in the vicinity. If using a grip or fixture from a
supplier other than Mark-10, ensure that it is constructed of suitably rugged materials and components.
Do not use jam nuts or tools to tighten grips or attachments onto the shaft. Finger-tighten only.
be used
www. .com
information@itm.com1.800.561.8187
Series 3 Digital Force Gauges User’s Guide
5
No.
Name
Description
1
Tension /
These indicators are used throughout the display and menu.
2
Peaks
The measured compression and tension readings. These readings are reset
by pressing ZERO or by powering the gauge off and on.
3
Primary reading
The current displayed force reading. See Operating Modes section for
details.
4
Load bar
Analog indicator to help identif y when an overlo ad condit ion is imm inent. T he
details.
5
Units
The current unit of measurement. Abbreviations are as follows:
1
2
3
4 5 6
7 8 9
3.2 Installing the USB driver
If communicating via USB, install the USB driver provided on the Resource CD. Installation instructions
may also be found on the CD or may be downloaded from
www.mark-10.com.
Caution!
Install the USB driver before physically connecting the gauge to a PC with the USB cable.
Further instructions for configuring and using the gauge’s outputs are provided in the Communications
and Outputs section.
4 HOME SCREEN AND CONTROLS
4.1 Home Screen
compression
indicator
- indicates a compression (push) direction
- indicates a tension (pull) direction
bar increases either to the right or to the left from the midpoint of the graph.
Increasing to the right indicates compression load, increasing to the left
indicates tension load. If set points are enabled, triangular markers are
displayed for visual convenience. This indicator reflects the actual load, which
may not correspond to the primary reading (depends on operating mode).
The ZERO key does not reset the load bar. See Operating Modes section for
www. .com
information@itm.com1.800.561.8187
Series 3 Digital Force Gauges User’s Guide
6
lbF – Pound-force
capacity / resolution table in the Specifications section for details.
6
Mode
The current measurement mode. Abbreviations are as follows:
See Operating Modes section for details about each of these modes
7
Battery / AC
adapter indicator
Either the AC adapter icon or battery power icon will be shown, depending on
power conditions. Refer to the Power section for details.
8
High / low limit
Correspond to the programmed set points. Indicator definitions are as follows:
– the displayed value is less than the lower force limit
9
Set points
The programmed force limits. Typically used for pass/fail type testing. 1, 2, or
Points menu item.
Primary
Label
Primary Function
Secondary
Label
Secondary Function
Powers the gauge on and off. Press
home screen is displayed.
ENTER
Various uses, as described in the
ZERO
Zeroes the primary reading and
peaks.
(UP)
Navigates up through the menu and
sub-menus .
MENU
Enters the main menu.
ESCAPE
Reverts one step backwards through
the menu hierarchy.
MODE
Toggles between measurement
modes.
(DOWN)
Navigates down through the menu
and sub-menus.
DATA
Transmits the current reading to an
DIRECTION
Reverses the display during
menu items.
kgF – Kilogram-force
gF – Gram-force
N – Newton
Note: not all gauge capacities measure in all the above units. Refer to the
RT – Real Time
PC – Peak Compression
PT – Peak Tension
indicators
4.2 Controls
– the displayed value is greater than the upper force limit
– the displayed value is between the limits
no signals may be present, depending on the configuration shown in the Set
briefly to power on, press and hold
to power off. Active only when the
external device, via the USB port.
following sections.
calibration, and toggles between
tension and compression directions
while configuring set points and other
Note: Measurement units are configured through the menu. Refer to the Changing The Units section for
details.
4.3 Menu navigation basics
Most of the gauge’s various functions and parameters are configured through the main menu. To access
the menu press MENU. Use the UP and DOWN keys to scroll through the items. The current selection is
denoted with clear text over a dark background. Press ENTER to select a menu item, then use UP and
DOWN again to scroll through the sub-menus. Press ENTER again to select the sub-menu item.
For parameters that may be either selected or deselected, pres s ENTER to toggle between se lect ing an d
deselecting. An asterisk (*) to the left of the parameter label is used to indicate when the parameter has
been selected.
www. .com
information@itm.com1.800.561.8187
Series 3 Digital Force Gauges User’s Guide
7
UNITS
For parameters requiring the input of a numerical value, use the UP and DOWN keys to increment or
decrement the value. Press and hold either key to auto-increment at a gradually increasing rate. When
the desired value has been reached, press ENTER to save the change and revert back to the sub-menu
item, or press ESCAPE to revert back to the sub-menu item without saving. Press ESCAPE to revert one
step back in the menu hierarchy until back into normal operating mode.
Refer to the following sections for details about setting up particular functions and parameters.
5 OPERATING MODES
Caution!
In any operating mode, if the capacity of the instrument has been exceeded by more than 110%,
the display will show “OVER” to indicate an overload. A continuous audible tone will be sounded
(if beeps are enabled) until the MENU key has been pressed or the load has been reduced to a
safe level.
Three operating modes are possible with Series 3 gauges. To cycle between the modes, press MODE
while in the home screen.
5.1 Real time (RT)
The primary reading corresponds to the live measured reading.
5.2 Peak Compression (PC)
The primary reading corresponds to the peak compression reading observed. If the actual force
decreases from the peak value, the peak will still be retained in the primary reading area of the display.
Pressing ZERO will reset the value.
5.3 Peak Tension (PT)
Same as Peak Compression, but for tension readings.
6 CHANGING THE UNITS
Series 3 gauges display one of three measurement units. To change the unit, select Units from the
menu. The display appears as follows:
* lbF
kgF
N
The gauge will alwa ys power on with the unit selected.
7 DIGITAL FILTERS
Digital filters are provided to help smooth out the readings in situations where there is mechanical
interference in the work area or test sample. These filters utilize the moving average technique in which
consecutive readings are pushed through a buffer and the displayed reading is the average of the buffer
contents. By varying the length of the buffer, a variable smoothing effect can be achieved. The selection
of 1 will disable the filter since the average of a single value is the value itself.
www. .com
information@itm.com1.800.561.8187
Series 3 Digital Force Gauges User’s Guide
8
DIGITAL FILTERS
SET POINTS
3.50
To access digital filter settings, select Filters from the menu. The display appears as follows:
(1 = Fastest)
Current Reading
8
Displayed Reading
128
Two filters are available:
Current Reading – Applies to the peak capture rate of the instrument.
Displayed Reading – Applies to the primary reading on the display.
Available settings: 1,2,4,8,16,32,64,128,256,512,1024. It is recommended to keep the current reading
filter at its lowest value for best performance, and the displayed reading filter at its highest value for best
visual stability.
8 SET POINT INDICATORS
8.1 General Information
Set points are useful for tolerance checking (pass/fail). Two limits, high and low, are specified and stored
in the non-volatile memory of the instrument and the primary reading is compared to these limits.
8.2 Configuration
To configure set points, select Set Points from the menu. The screen appears as follows:
Upper Disabled
* Upper Enabled
5.00
Lower Disabled
* Lower Enabled
Either one, two, or none of the set points may be enabled. To toggle between the tension and
compression directions, press the DIRECTION key.
If two set points have been enabled, they are displayed in the upper left corner of the display. If only one
set point has been enabled, the word “OFF” appears in place of the value. If no set points have been
enabled, the upper left corner of the display will be blank.
When set points are enabled, the following indicators are shown to the left of the primary reading:
www. .com
information@itm.com1.800.561.8187
Series 3 Digital Force Gauges User’s Guide
9
USB SETTINGS
– the displayed value is greater than the upper
force limit (NO GO HIGH)
– the displayed value is between the limits (GO)
– the displayed value is less than the lower force
limit (NO GO LOW)
Note: Set point indicators reference the displayed reading, not necessarily the current live load.
9 COMMUNICATIONS AND OUTPUTS
Communication with Series 3 force gauges is achieved through the micro USB port located along the left
side of the housing, as shown in the illustration in the Power section. Communication is possible only
when the gauge is in the main operating screen (i.e. not in a menu or configuration area).
The current reading is transmitted from the gauge when the DATA key is pressed. For continuous output,
the gauge also responds to the ASCII command ‘?’ (no quotes), terminated with a Carriage Return
character or with a Carriage Return/Line Feed combination. The gauge’s responses are always
terminated with a Carriage Return/Line Feed. Any detected errors are reported back by means of error
code *10 (illegal command).
Series 3 gauges can send individual data points or continuous data to MESUR
Lite software.
9.1 Communication Settings
To set up communication settings, select USB Settings from the menu. The screen appears as follows:
TM
gauge and MESUR
TM
+ Baud Rate
+ Data Format
Communication settings are permanently set to the following:
Data Bits: 8
Stop Bits: 1
Parity: None
Other settings are configured as follows:
9.1.1 Baud Rate
Select the baud rate as required for the application. It must be set to the same value as the receiving
device.
www. .com
information@itm.com1.800.561.8187
Series 3 Digital Force Gauges User’s Guide
10
Selection
Description
Numeric + Units
Output format includes the value and unit of measure. Compression values have
positive polarity, tension values have negative polarity.
Numeric Only
Output format includes the value only. Polarity same as above.
Invert Polarity
Compression values have nega tive pol arity, tension values have positive polar ity.
May be selected in addition to the Numeric + Units / Numeric Only selection.
Omit Polarity
Both directions are formatted with positive polarity. May be selected in addition to
the Numeric + Units / Numeric Only selection.
CALIBRATION
CALIBRATION
5
DATA FORMAT
9.1.2 Data Format
Select the desired data format. The screen appears as follows:
* Numeric + Units
Numeric Only
Invert Polarity
Omit Polarity
Individual data points ma y be transm itted b y pressing DATA.
10 CALIBRATION
10.1 Initial Physical Setup
The gauge should be mounted vertically to a test stand or fixture rugged enough to withstand a load
equal to the full capacity of the instrument. Certified deadweights or master load cells should be used,
along with appropriate mounting brackets and fixtures. Caution should be taken while handling such
equipment.
10.2 Calibration Procedure
1. Select Calibration from the menu. The display appears as follows:
To invert the
display, press the
DIRECTION button,
then press ENTER.
2. Press DIRECTION to invert the display, if desired. ENTER to continue. The display appears as
follows:
Enter # cal points
(1 to 10)
Compression:
5
Tension:
www. .com
information@itm.com1.800.561.8187
Series 3 Digital Force Gauges User’s Guide
11
CALIBRATION
CALIBRATION
CALIBRATION
CALIBRATION
CALIBRATION
The gauge can be calibrated at up to 10 points in each direction. Enter the number of calibration
points for each direction (compression and tension). At least one point must be selected for each
direction.
Note: To achieve the accuracy specification of ±0.3%, it is recommended to calibrate the gauge
at 5 or more even increments in both tension and compression directions. For example, a gauge
with capacity of 10 lbF should be calibrated at 2, 4, 6, 8, and 10 lb loads in each direction.
3. To escape the Calibration menu at any time, press ESCAPE. The display appears as follows:
NOT COMPLETE
Cancel
Exit w/o saving
Selecting “Cancel” will revert back to the Calibration setup. Selecting “Exit w/o saving” will return
to the menu without saving changes.
4. After the number of calibration points has been entered, press ENTER. The display appears as
follows:
OFFSET
Place force gauge
horizontally, then
press ZERO.
5. Place the force gauge horizontally on a level surface free from vibration, then press ZERO. The
gauge will calculate internal offsets, and the display appears as follows:
OFFSET
Please wait…
OFFSET
Sensor passed
Analog passed
6. The following screen appears after the offsets have been calculated:
OFFSET
Sensor failed
Analog failed
If failed:
www. .com
information@itm.com1.800.561.8187
Series 3 Digital Force Gauges User’s Guide
12
CALIBRATION
CALIBRATION
CALIBRATION
CALIBRATION
CALIBRATION
Press ENTER.
COMPRESSION
Attach necessary
weight fixtures,
then press ENTER.
Attach weight fixtures (brackets, hooks, etc), as required. Do not yet attach any weights or apply
any calibration loads. Press ENTER.
7. The display appears as follows:
COMPRESSION
Optionally exercise
sensor, then press
ENTER.
Optionally exercise the load cell shaft sev eral times (at full scale, if possible), then press ENTER.
8. The display appears as follows:
COMPRESSION
Gain adjust
Apply full scale load
10.00 lbF +/-20%,
then press ENTER.
Apply a weight equal to the full scale of the instrument, then press ENTER.
9. After displaying “Please wait…” the display appears as follows:
COMPRESSION
Ensure no load,
then press ZERO.
Remove the load applied in Step 8, leave the fixtures in place, then press ZERO.
10. The display appears as follows:
COMPRESSION
Apply load
1 OF 5
Enter load:
2.00 lbF
www. .com
information@itm.com1.800.561.8187
Series 3 Digital Force Gauges User’s Guide
13
CALIBRATION
CALIBRATION
CALIBRATION
CALIBRATION
then press ENTER.
Use the UP and DOWN k eys to adjust the load value as required. The load values default to even
increments, as indicated by the previously entered number of data points (even increments are
recommended for best results). For example, if a 50 lbF capacity gauge is calibrated, and 5 data
points were selected, the load values w ill defau lt to 10, 20, 30, 40, and 50 lb. Appl y the calibration
load. Then press ENTER.
Repeat the above step for the number of data points selected.
11. After all the compression calibration points have been completed, the display appears as follows:
COMPRESSION COMPLETE
Reverse direction
for tension.
Attach necessary
weight fixtures,
Press ENTER.
12. The display appears as follows:
To invert the
display, press the
DIRECTION button,
then press ENTER
Reverse the orientation of the load cell shaft by rotating the gauge 180 degrees. Press
DIRECTION to invert the display. Then attach weight fixtures. The following screens will step
through the same procedure as with the compression direction. Proceed in the same manner.
13. At the completion of the tension calibration, the display appears as follows:
COMPLETE
Save & exit
Exit w/o saving
To save the calibration information, select “Save & exit”. To exit without saving the data select
“Exit without saving”.
14. Any errors are reported by the following screens:
Units must be kgF.
Please try again
Press ENTER.
Displayed at the start of calibration if a disallowed unit is selected.
www. .com
information@itm.com1.800.561.8187
Series 3 Digital Force Gauges User’s Guide
14
Selection
Description
Disabled
Disable automatic shutoff.
Enabled
Enable automatic shutoff.
Set Minutes
The length of time of inactivity. Available settings: 5-30, in 5 minute increments.
CALIBRATION
CALIBRATION
CALIBRATION
AUTOMATIC SHUTOFF
Load not stable.
Please try again.
Ensure that the load is not swinging, oscillating, or vibrating in any manner. Then try again.
COMPRESSION
Load too low.
Please try again.
The calibration weight does not match the set value.
TENSION
Load too close
to previous.
Please try again.
The entered calibration point is too close to the previous point.
11 OTHER SETTINGS
11.1 Automatic Shutoff
The gauge may be configured to automatically power off following a period of inactivity while on battery
power. Inactivity is defined as the absence of any key presses or load changes of 100 counts or less. To
access these settings, select Automatic Shutoff from the menu. The display appears as follows:
* Disabled
Enabled
Set Minutes
5
Note: If the AC adapter is plugged in, the gauge will ignore these settings and remain powered on until
the POWER key is pressed.
www. .com
information@itm.com1.800.561.8187
Series 3 Digital Force Gauges User’s Guide
15
Selection
Description
Off
Backlight to be off upon powering on the gauge.
On
Backlight to be on upon powering on the gauge.
Auto
Backlight to be on upon powering gauge, but will shut off after a period of inactivity (as
Minutes parameter. Available settings: 1-10, in 1 minute increments.
BACKLIGHT
TONES
LCD CONTRAST
11.2 Backlight
Several initial settings are available, upon powering on the gauge. To access these settings, select
Backlight from the menu. The display appears as follows:
Off
On
* Auto
Set Minutes
1
defined in the Automatic Shutoff sub-section). The backlight will turn on again when
activity resumes. The length of time of inactivity is programmed in minutes via the Set
Note: If the AC adapter is plugged in, the gauge will ignore these settings and keep the backlight on.
Selecting the On or Off setting in the Backlight menu will manually turn the backlight on or off as if the
Backlight key were pressed.
11.3 LCD Contrast
The contrast of the display may be adjusted. Select LCD Contrast from the menu. The screen appears
as follows:
Set Contrast
10
Press ENTER to modify the contrast. Select a value from 0 to 25, 25 producing the most contrast.
11.4 Tones
Audible tones can be enabled for all key presses and alerts, such as overload, set point value reached,
etc. The Set Point alert can be configured to be either a momentary tone or a continuous tone (until the
load is restored to a value between the set points). To configure the functions for which audible tones will
apply, select Tones from the menu. The screen appears as follows:
Keys
* Alerts
Set Points
* Momentary
Continuous
www. .com
information@itm.com1.800.561.8187
Series 3 Digital Force Gauges User’s Guide
16
RESTORE DEFAULT
Digital Force Gauge
INITIAL MODE
11.5 Initial Mode
This section is used to configure the initial mode upon powering on the gauge. To access this parameter,
select Initial Mode from the menu. The screen appears as follows:
* Real Time
Peak Compression
Peak Tension
The default value is Real Time.
11.6 Restore Default Settings
Default factory settings can be restored by selecting Restore Defaults from the menu. The settings may
be found in the Specifications section. The screen appears as follows:
SETTINGS?
No
Yes
11.7 Information / Welcome Screen
The following screen is displayed at power up and can be accessed at any time by selecting Information
from the menu:
Series 3
Model No: M3-50
Serial No: 1234567
Version: 1.0
(c) Mark-10 Corp.
www. .com
information@itm.com1.800.561.8187
Series 3 Digital Force Gauges User’s Guide
17
Accuracy:
±0.3% of full scale
Sampling rate:
2,000 Hz
Power:
AC or rechargeable battery. Low battery indicator appears when battery level is low, and
Backlight on: up to 7 hours of continuous use
Measurement units:
lbF, gF, kgF, N (depending on model)
Safe overload:
200% of full scale (display shows “OVER” at 110% and above)
M3-012 – M3-100: 0.7 lb [0.33 kg]
Carrying case, chisel, cone, V-groove, hook, flat, extension rod, AC adapter, battery, USB
Environmental
Warranty:
3 years (see individual statement for further details)
Parameter
Setting
Set points
Upper
Disabled (defaults to 80% of full scale, compression, when enabled)
Lower
Disabled (defaults to 40% of full scale, compression, when enabled)
Filters
Current
8
Displayed
128
Backlight
Auto
Minutes
1
USB Output
Disabled
Baud Rate
9,600
Data Format
Numeric + units
Automatic Shutoff
Enabled
Minutes
5
Tones
Keys
Enabled
Alerts
Enabled
Set Points
Momentary
Initial Mode
Real Time
Units
lbF
12 SPECIFICATIONS
12.1 General
gauge powers off automatically when power reaches criti cal stag e.
Battery life:
Weight (gauge only):
Included accessories:
requirements:
12.2 Factory Settings
Backlight off: up to 24 hours of continuous use
M3-200 – M3-500: 0.9 lb [0.41 kg]
cable, resource CD (USB driver, MESUR Lite software, MESURgauge DEMO software,
and user’s guide), NIST-t race a ble certi f icat e of cali brati on
40 - 100°F, max. 93% humidity, non-condensating
www. .com
information@itm.com1.800.561.8187
Series 3 Digital Force Gauges User’s Guide
18
Thread
Flat
M3-012 – M3-100
#10-32 UNF
5/16 [7.94]
M3-200 – M3-500
5/16-18 UNC
5/16 [7.94]
Load Cell Deflection
in [mm]
M3-012
0.12 x 0.0001
-
50 x 0.05
0.5 x 0.0005
0.005 [0.13]
M3-025
0.25 x 0.0002
-
100 x 0.1
1 x 0.001
0.010 [0.25]
M3-05
0.5 x 0.0005
-
250 x 0.2
2.5 x 0.002
0.010 [0.25]
M3-2
2 x 0.002
1 x 0.001
-
10 x 0.01
0.010 [0.25]
M3-5
5 x 0.005
2.5 x 0.002
-
25 x 0.02
0.010 [0.25]
M3-10
10 x 0.01
5 x 0.005
-
50 x 0.05
0.010 [0.25]
M3-20
20 x 0.02
10 x 0.01
-
100 x 0.1
0.010 [0.25]
M3-50
50 x 0.05
25 x 0.02
-
250 x 0.2
0.010 [0.25]
M3-100
100 x 0.1
50 x 0.05
-
500 x 0.5
0.010 [0.25]
M3-200
200 x 0.2
100 x 0.1
-
1000 x 1
0.010 [0.25]
M3-500
500 x 0.5
250 x 0.2
-
2500 x 2
0.010 [0.25]
12.3 Capacity, Resolution & Load Cell Deflection
Model lbF kgF gF N
12.4 Dimensions
IN [MM]
www. .com
information@itm.com1.800.561.8187
Loading...
