USER MANUAL

MOBILE PHONE

MODEL：P32

HEREBY, ITEL MOBILE LIMITED

DECLARES THAT THIS MOBILE PHONE IS IN

COMPLIANCE WITH THE ESSENTIAL

REQUIREMENTS AND OTHER RELEVANT

PROVISIONS OF DIRECTIVE 2014/53/EU.

1 TAKING CARE OF YOUR DEVICE

2 KNOW YOUR PHONE

3 SIM/SD CARD INSTALLATION

4 MAKE CALLS

5 MESSAGES

6 CAMERA

7 GALLERY

8 WI-FI

9 MUSIC

10 FINGERPRINT

11 WARRANTY CONDITIONS

12 SAR

13 E-WASTE、RECYCLE YOUR PHONE

14 DISCLAIMERS

15 COPYRIGHTS

16 CAUTION

17 DECLARATION OF CONFORMITY

2

6

7

8

9

10

11

12

13

15

17

18

20

23

24

25

27

1

2

1 TAKING CARE OF YOUR DEVICE

Your device is a product of superior design and
artisanship and should be handled with care: The
following suggestions will help you protect your
phone :

Keep the device dry. Precipitation, humidity,
and all types of liquid or moisture can contain
minerals that will rust electronic circuits.If your
device gets wet and your device battery is
removable, please remove the battery and
refrain from turning on the device, wipe it with
dry cloth and take it to the service center. If
your device gets wet and your device battery
is un-removable, please don’t reboot your
device and take it to the service center.

Do not use or store the device in dusty or dirty
areas. Its moving parts and electronic
components may be damaged.

Do not store the device in higher than 45°C or
lower than 0°C temperature. Otherwise it can
shorten the life of electronic devices and
damage batteries.

Fully understand user manual before use

3

Battery& Chargers Safety:

Only use original battery, charger and
accessories applicable to the specic mobile
model. Using other types of battery, charger
and accessories may violate the certication or
warranty terms of the equipment and may
result in danger.

Do not drop, knock, or shake the device.
Rough handling can break internal circuit
boards and ne mechanics.

Do not use harsh chemicals, cleaning solvents,
or strong detergents to clean the device. Use a
soft, clean and dry cloth to clean the surface of
the device.

Do not attempt to open the device other than as
instructed in this guide. Repairing of phone by
yourself and others than our authorized service
agent/center is against the warranty rules.

If your device support hot plug SD card or SIM
card, you can plug the SD card during the
device running, otherwise you need to plug
the SD card or SIM card after power o the
device or remove the battery.

4

Do not place the battery or devices in re or
heating devices, such as microwave ovens,
stoves, or radiators and improper disposal of
batteries may lead to explosion.stoves, or
radiators and improper disposal of batteries
may lead to explosion.

Return waste and used batteries to the
supplier or specied recovery site.

Stop charging when battery is higher than 55
℃,and restore charging when below 50℃. Stop
charging when battery is below 0℃，and restore
charging when higher than 5℃.

If the time span of the battery after charging
becomes much shorter than usual, the battery
life is at an end. Replace the battery with a new
battery of the same make and specication.

*Notes:

If you want to know more:
www.itel-mobile.com
www.facebook.com/itelmobile
Twitter.com/itel_mobile

If your device battery is removable, you can
keep pressing the power button for 10 seconds
to restart the phone. If your device battery is
un-removable，you can reset the battery to
restart the phone.

5

2 KNOW YOUR PHONE

6

1. Earphone Plug

3. Sensor

5. Front Flash

7. USB Port

9. Power Button

11/12. Rear Camera

14. Speaker

2. Receiver

4. Front Camera

6. Microphone

8. Volume Button

10. Flash

13. Fingerprint

3 SIM/SD CARD INSTALLATION

1. Power o mobile.

2. Refer to the following picture for SIM / SD card
installation.

7

4 MAKE CALLS

On dial interface and enter a complete phone
number to make a call.

Call Recorder Storage Path：
No SD Card: internal shared storage / recorder /
Call Recorder
SD Card inserted and SD Card is default write disk:
SD card / recorder / Call Recorder

8

100%

100%

5 MESSAGES

You can use Messages to exchange text and
multimedia messages with your friends.

9

100%

6 CAMERA

You can select the camera APP to take photos. You
can switch the rear camera and front camera to
take photo on camera APP, you can select Beauty
or PANO or Lowlight mode to take photo in
dierent environment. You can generate photos
into dierent eect by using a Filter or Vignette or
Watermark.

10

7 GALLERY

You can use gallery to view pictures that you have
taken with Camera, downloaded, or copied onto
your SD card, you can also share your pictures and
videos with friends.

11

12

8 WI-FI

To browse the web, you need switch on Data
connection.If there is Wi-Fi around, you can switch
on Wi-Fi to use it browse the web. Some may need
password.

9 MUSIC

When you copy music to your SD card, the Music
player searches the card for music les and builds
a catalog of your music, based on information
about each le that is stored in the le itself.

13

14

10 FINGERPRINT

Use a ngerprint to unlock the screen or to
encrypt your important data and privacy
information.

Add ngerprint or delete Fingerprints

You can enter Settings application, click
Security and select ngerprint to add
ngerprints.
You can also click on the Fingerprint
application icon directly to add ngerprints.

Note：

1.You need to choose your backup screen lock
method before adding Fingerprint.

2.You can click the ngerprint in Fingerprint
list and then choose to delete it.

You can use ngerprint to answer a call or to
take a photo or to start call recorder.

11 WARRANTY CONDITIONS

The warranty period starts at the time of product's
original purchase by the rst end-user. The
product may consist of several dierent parts and
dierent parts may be covered by a dierent
warranty.

This Limited Warranty does not cover user
manuals or any third party software, settings,
content, data or links included or downloaded
in the product, whether included during
installment, assembly, shipping or any other
time in the delivery chain or otherwise and in
any way acquired by you. Itel does not warrant
that any Itel software will meet your
requirements, will work in combination with
any hardware or software provided by a third
party, that the operation of any software will be
uninterrupted or error free or that any defects in
the software are correctable or will be
corrected.

What is not covered?

1.

15

This Limited Warranty does not cover2.

16

(a) Normal wear and tear (including, without
limitation, wear and tear of camera lenses,
batteries, or displays)

(b) Defects caused by rough handing (including,
without limitation, defects caused by sharp
objects, by bending, compressing or
dropping,etc.)

(c) Defects or damage caused by misuse of the
Product, including use that is contrary to the
instructions provided by itel (e.g. as set out
in the Product's user guide).

(d) Transport costs.

(e) Other acts beyond the reasonable control of
itel.

The Limited Warranty does not cover defects or
alleged defects caused by the fact that the
product was used with, or connected to, any
product, accessory, software and/or service not
manufactured, or supplied, by itel or was used
otherwise than for its intended use. Defects can
be caused by viruses from your or a third party's
unauthorized access to services, other
accounts,computer systems or networks. This
unauthorized access can take place through
hacking, password mining or through a variety
of other means.

3.

This Limited Warranty does not cover defects
caused by the fact that the battery has been
short-circuited or by the fact that the seals of
the battery enclosure or the cells are broken or
show evidence of tampering or by the fact that
the battery has been used in equipment other
than those for which it has been specied.

4.

This Limited Warranty is not enforceable if the
Product is opened, modied or repaired by
anyone other than an authorized service centre,
if it is repaired using unauthorized spare parts
or if the Product's serial number, the mobile
accessory date code or the IMEI number has
been removed, erased, defaced, altered or are
illegible in any way and this shall be determined
in the sole discretion of itel.

5.

17

This Limited Warranty is not enforceable if the
Product has been exposed to moisture, to
dampness or to extreme thermal or environ­mental conditions or to rapid changes in such
conditions, to corrosion, to oxidation, to spillage
of food or liquid or to inuence from chemical
products.

6.

12 SAR

Head

Body

0.351W/Kg

0.863W/Kg

Specic Absorption Rate (SAR) Certication
THIS DEVICE MEETS INTERNATIONAL GUIDELINES
FOR EXPOSURE TO RADIO WAVES

Your mobile device is a radio transmitter and
receiver. It is designed not to exceed the limits for
exposure to radio waves (radio frequency
electromagnetic elds) recommended by
international guidelines. The guidelines were
developed by an independent scientic
organization (ICNIRP) and include a substantial
safety margin designed to assure the safety of all
persons, regardless of age and health.
The radio wave exposure guidelines use a unit of
measurement known as the Specic Absorption
Rate, or SAR. The SAR limit for mobile devices is 2.0
W/kg. Tests for SAR are conducted using standard
operating positions with the device transmitting
at its highest certied power level in all tested
frequency bands. The highest SAR values under
the ICNIRP guidelines for this device model are:
Maximum SAR for this model and conditions
under which it was recorded

18

During use, the actual SAR values for this device
are usually well below the values stated above.
This is because, for purposes of system eciency
and to minimize interference on the network, the
operating power of your mobile device is
automatically decreased when full power is not
needed for the call. The lower the power output of
the device, the lower its SAR value.
A body-worn SAR test has been performed on this
device at a separation distance of 5 mm. To meet
RF exposure guidelines during body-worn
operation, the device must be positioned at least
5 mm away from the body.
Organizations such as the World Health
Organization and the US Food and Drug
Administration have suggested that if people are
concerned and want to reduce their exposure,
they could use a hands-free accessory to keep the
wireless device away from the head and body
during use, or reduce the amount of time spent
using the device.

19

20

13 E-WASTE、RECYCLE
YOUR PHONE

The WEEE logo (shown at the left)
appears on the product (battery,
handset, and charger) to indicate
that this product must not be
disposed o or dumped with your
other household wastes. You are

liable to dispose of all your electronic or electrical
waste equipment by relocating over to the
specied collection point for recycling of such
hazardous waste.
Collection and proper recovery of your electronic
waste equipment’s at the time of disposal will
allow us to help preserve the environment.
Recycling of the electronic waste equipment will
ensure safety of human health and environment.

INFORMATION UNDER E-WASTE (MANAGEMENT
AND HANDLING) RULES, 2011
For disposal of e-waste, please call our helpline no.
or visit our website.
E-waste Helpline No.:18004190525
Website: www.itel-mobile.com

1. Instructions for disposal of products
a) At the end of their life, should drop used
electronic products, batteries, and packaging
materials in the nearest disposed products cans or
collection center.
b) Should divide the packaging materials
according to corresponding waste disposal
options and sort for recycling.
c) Battery should be removed from the product for
recycling.

2. Prohibition for disposal of equipment
a) Never dump E-wastes in garbage bins or
municipal solid waste stream.
b) Do not dispose of your product as per unsorted
municipal waste.
c) Do not throw used batteries into household
waste.
d) Do not dispose the damaged or leaking Lithium
Ion (Li-Ion) battery with normal household waste.

3. Information on the consequences of improper
handling, accidental breakage damage and
improper recycling of the end of life product.

21

22

a) If batteries are not properly disposed of, it can
cause harm to human health or the environment.
b) Placing of batteries or devices on or in heating
devices, such as microwave ovens, stoves, or
radiators and improper disposal of batteries may
lead to explosion.
c) If the battery terminals are in contact with
metal objects, it may cause a re.

23

14 DISCLAIMERS

Other product logos and company names
mentioned herein may be trademarks or trade
names of their respective owners.

The content of this manual may vary from the
actual content displayed in the mobile phone. In
such a case, the later shall update.

We keep the right to make modications to any of
the content in this user guide without public
announcement or prior notication.

For devices with external power supplies, plug
socket should be placed in short distance and
easily accessible.

We suggest that the customer select the
tempered glass which thickness less or equal than

0.3mm ，otherwise it will caused to touch screen
sensitivity decreased ,even to malfunction. Please
tear o the tempered glass if you meet this
problem

15 COPYRIGHTS

All rights reserved. Reproduction, transfer,
distribution or storage of part or all of the
contents in this document in any form without the
prior written permission of is strictly prohibited.

To prevent possible hearing damage, do not
listen at high volume levels of long periods.

To use the device only with the earphones
included, never change the earphones included
for another one.

Ensure your player at low volume levels or
power o before you leaving.

24

1.Use careful with the earphone maybe excessive
sound pressure from earphones and headphones
can cause hearing loss.

2.Risk of explosion if battery is replaced by an
incorrect type, dispose of used batteries
according to the instructions.

3.The product shall only be connected to a USB
interface of version USB2.0

4.Adapter shall be installed near the equipment
and shall be easily accessible.

5.EUT Temperature:-10℃～+45℃.

6. Adapter: IMU05
Input: 100-240V~50/60Hz 200mA
Output: 5.0V 1.0A

7.The device complies with RF specications
when the device used at 5mm from your body.

8.To prevent possible hearing damage, do not
listen at high volume levels for long periods.

9.Earphone and USB cable are shielded.

25

16 CAUTION

Operating Frequency Band (RF)：
E-GSM900: 880-915MHz (TX), 925-960MHz (RX)
DCS1800: 1710-1785MHz (TX), 1805-1880MHz (RX)
WCDMA BAND I: 1920-1980MHz (TX),
2110-2170MHz (RX)
Bluetooth: 2400-2483.5MHz (TX/RX)
WIFI: 2412-2472M (TX/RX)
GPS:1.57542GHz
FM: 87.5MHz - 108MHz

Modulation mode：
GMSK (GSM)
BPSK,QPSK(WCDMA)
GFSK, π/4- DQPSK, 8DPSK (BT)
GFSK(BLE)
DSSS (DBPSK,DQPSK,CCK) for IEEE 802.11b
OFDM(BPSK,QPSK,16QAM,64QAM)for
IEEE802.11g/n HT-20/ HT-40
BPSK(GPS)

Max. Of Transmit power:
GSM900：33dBm±2dB
GSM1800：30dBm±2dB
WCDMA BAND I:24dBm+1.7dB/-3.7dB
Bluetooth：0-10 dBm
Wi: 14dBm +/-3dB

26

We：ITEL MOBILE LIMITED.

OF RMS 05-15, 13A/F SOUTH TOWER WORLD
FINANCE CTR HARBOUR CITY 17 CANTON RD TST
KLN HONG KONG.

Declare under our sole responsibility that the
product

Product Description: Mobile phone
Brand Name: itel
Model No.: P32
Product Identication Element: P32

to which this declaration relates, is conformity with
the following standards and/or other normative
documents.

3.1a Health: EN 50360:2017
EN 50566:2017
EN 62479:2010
EN62209-1:2016
EN62209-2:2010

27

17 DECLARATION
OF CONFORMITY

3.1a Safety:
EN60950-1:2006+A11:2009+A1:2010+A12:2011+
A2:2013

3.1b EMC: Draft ETSI EN 301 489-1 V2.2.0 (2017-03)
Draft ETSI EN 301 489-17 V3.2.0 (2017-03)
Draft ETSI EN 301 489-19 V2.1.0 (2017-03)
Draft ETSI EN 301 489-52 V1.1.0 (2016-11)
EN 55032:2015
EN 55035: 2017
EN61000-3-2:2014
EN61000-3-3:2013

3.2 Radio: ETSI EN 301 511 V12.5.1 (2017-03)
ETSI EN 301 908-1 V11.1.1 (2016-07)
ETSI EN 301 908-2 V11.1.1 (2016-07)
ETSI EN 300 328 V2.1.1 (2016-11)
ETSI EN 303 413 V1.1.1 (2017-06)
Final Draft ETSI EN 303 345 V1.1.7(2017-03)

We hereby declare that [all essential radio test
suites have been carried out and that] the above
named product is conformity to all the essential
requirements of directive 2014/53/EU.

28

The conformity assessment procedure referred to
in Article 17 and detailed in Annex III of Directive
2014/53/EU has been followed with the
involvement of the following Notied Body:
SIEMIC, INC., 775 Montague Expressways, Milpitas,
CA 95035, USA
And issued the EU-type examination certicate:
The accessories of this equipment which will be
sold and used with the equipment together are
listed at:
Adapter: IMU05
Input: AC100-240V 50/60Hz 200mA
Output: DC 5.0V 1.0A
Li-ion battery : BL-38AI
Voltage: 3.85V
Capacity: 4000mAh/3850mAh(typ/min)
Limited Charge Voltage: 4.4V
The software version of this equipment: V001
Place and date of issue (of this DoC):
Shenzhen/2018-03-28
Lebin,Xie/Manager
(Name / Title)
(Name and signature of person responsible)

29
