1U Rack mount 17” TFT SAMSUNG LCD Monitor Keyboard Drawer
Model: RP1617d
Features:
l Unique mechanical design to
maximize rack mountable space
l Adjustable mounting brackets from
15.4” to 29.2”
l Lock out rails to prevent movement
of the keyboard
l Built-in on screen display controlled
by integral membrane switches
Specification
Monitor
Panel: SamSung 17" LCD panel
Display type: TFT / LCD active matrix color
Resolutions: 1028 x 1024
Response time: Tr=5ms/ Tf=20ms
Contrast ratio: 350 : 1 typical
Brightness: 250 cd/m2 typical
Pixel pitch: 0.264mm (H) x 0.264mm (W)
Panel color: 16.7 million display colors
Viewing angle: 150o (Horiz.)/ 125 o (Vert.)
Storage temp. -20o C to 60 o C
Operating temp. 0 o C to 50 o C
MTBF 20,000 hours
Power supply
Remote adapter: 110V - 220V AC Input , 12V 5A Output
Adapter Size: 4.3”(L) x 2.4” (W) x 1.2”(H)
(108x61x30mm)
Cable length from mains plug to adapter: 6ft (182cm)
Cable length from adapter to unit: 6ft (180cm )
Safety approval: UL, CE
Mains plug options available
Product dimension--- 17.3”(W) x 1.75”(H) x 26.4”(D)
(44 x 4.45 x 67 cm)
Packing dimension--- 32.5”(L) x 24”(W) x 7”(H)
(83 x 61 x 18cm)
Optional
l Optional Video Input-S-Video and Composite Video Input --
Supported PAL & NTSC
l Optional –48V DC Input Supply
Weight
Model No Net / Gross weight
RP1617d 38 lbs / 47 lbs (17.3 kg / 21.4kg)
www.i-techcompany.com, Toll Free: 1-888-itech-18 (1-888-483-2418), Fax: 1-510-372-2736.
l SAMSUNG Industrial LCD Panel
l Full Size 3 buttons Trackball
Keyboard
l Optional Video Input-S-Video and
Composite Video Input --Supported
PAL & NTSC
l Optional –48V DC Input Supply
l Front-access lock of security
l Standard D-sub 15-pin VGA input
connector
l Supplied with 12V 5A remote power
adapter
l All mounting hardware included
