Product Specifications
i.VoicePRO
TM
901 Overview
Charging Your Headset
Pairing Your Headset with a
Bluetooth Mobile Phone
Pairing Your Headset with Two Mobile Phones (Multipoint)
Using Your Headset
Resetting Your Headset / Removing the Pairing History
Troubleshooting
Safety Information
Care and Maintenance
Contents
Bluetooth Headset
i.VoicePRO
TM
901
User Guide
2
Product Specifications
Bluetooth Specification: v2.1+EDR class 2
Bluetooth Profiles Supported: Headset and Handsfree
Range of Frequency: 2.4GHz Spectrum
Operating Distance: 10 meters
Charging Time: Within 3 hours
Talk Time*: Up to 5 hours
Standby Time*: Up to 100 hours
Dimensions: 63 (L) x 16.5 (W) x 9.8 (H) mm
Weight: 12 grams
* May vary due to users’ operation mode and mobile phone settings
3
Your i.VoicePRO 901 headset requires you to angle the headset to point towards your mouth
for best performance. Please also make sure your hand is not blocking the microphone
while talking.
1
5
2
6
3
4
7
4
i.VoicePROTM 901 Overview
Getting Started
Before using your i.VoicePRO 901 (“headset”) for the first time, please ensure that
1. the headset is fully charged;
2. the fully charged headset must be paired and connected with a Bluetooth mobile
phone.
Charging Your Headset
Use only the supplied charger to charge the headset.
The headset comes with a built-in rechargeable battery. Prior to using the headset for
the first time, you are recommended to fully charge the battery.
5
USB Charging Socket
Status Status Indicator Audio
• Charging • Red light
• Fully charged • Blue light
• Low battery • Flashing red light • a short beep every 1 minute
• Out of battery • The light goes off
♦ 3 hours are required to fully charge the headset.
♦ Charging indication will be delayed for a few seconds if the headset has not been used
for a long time or the battery is drained.
6
Charging Your Headset (cont’d)
Pairing Your Headset with a Bluetooth Mobile Phone
1) Ensure the headset is off.
2) To activate the pairing mode, press and hold the headset’s MFB for 8 seconds without
releasing your finger until its status indicator flashes blue and red light alternately.
3) Activate your mobile phone’s Bluetooth, search Bluetooth devices, select “i.VoicePRO
901” and enter the passcode “0000”. If your mobile phone supports Bluetooth v2.1
“Simple Pairing” function, no passcode is required. When the pairing is completed, the
headset’s status indicator will flash blue light rapidly five times.
If the pairing cannot be completed within three minutes after the pairing mode has been
activated, the headset’s status indicator will flash purple rapidly five times and then turns
off. Repeat steps 1 to 3 to pair both devices again.
Pairing Your Headset with Two Mobile Phones (Multipoint)
i.VoicePRO 901 supports a Multipoint function to allow simultaneous pairing of the
headset with two mobile phones.
1. Follow the pairing procedure as instructed in “Pairing Your Headset with a
Bluetooth Mobile Phone” to pair the headset with the first mobile phone.
2. Repeat the pairing procedure for the second mobile phone.
3. On the first mobile phone’s menu, activate its Bluetooth connection with the
headset.
7
When you turn on your headset for the first time, the headset automatically enters the
pairing mode, i.e. the status indicator flashes blue and red alternately. This allows you
to immediately pair your headset and mobile phone.
Using Your Headset
Function Button Audio Status Indicator
Power ON Press and hold the MFB for 2 a short beep Flashing blue light 3
seconds times
Power OFF Press and hold the MFB for 2 a long beep
seconds
Red light for two seconds
and then the light goes off
1. Noise Filter Button (allways
default on)
2. Status Indicator
3. Volume Key
4. Speaker
5. Multi-function Button (MFB)
6. Microphones
7. USB Charging Socket
Right ear Left ear
