User Manual
Innovative LCD Display Solutions
HAP
HDP
HOP
—
19AV Series
—
19AV Series
—
19AV Series
UMUV.19H-045V1
Apr 05
P.1
HAP-19AV / HDP-19AV / HOP-19AV Series
1. Table of Content
1. Table of Content Page.1
2. Introduction
A) Overview Page.2
B) Features Page.2
C) Dimension Diagrams Page.3-5
D) Technical Specifications Page.6
3. Installation
A) Package Contents Page.7
B) Caution to the user Page.7
C) Cleaning Page.7
D) Precautions Page.8-9
4. Using the System
A) Product Views Page.10-12
B) I/O Outlet Page.13
C) Installation Procedures Page.14
D) Setup Touchscreen (Optional) Page.15
i) For Windows Page.15
ii) For DOS Page.16-18
E) OSD Switch Page.19
F) OSD Control (VGA Version) Page.20-22
G) OSD Control (Video Version) Page.23-27
Disclaimer
This information is subject to change without notice. The producer of this manual accepts no
responsibility for damage or claims, resulting from misuse or misinterpretation.
Apr 05
P.2
HAP-19AV / HDP-19AV / HOP-19AV Series
2. Introduction
A. Overview
This LCD monitor incorporates 19”color active matrix thin-film-transistor (TFT)
liquid crystal display to provide superior display performance. A maximum
resolution of 1280 x 1024 is ideal for displaying complex graphics and high
definition images. Other outstanding designs that enhance this LCD monitor’s
performance are Plug & Play compatibility and OSD (On Screen Display)
controls.
B. Features
● Ultra High Brightness TFT LCD Display up to 700 Cd/m
● Viewable Under Sun Light
● High contrast color TFT LCD display support resolution up to 1280 x
2
.
1024.
● Advanced OSD control for picture quality adjustment.
● Detachable stand for wall-mounting application.
● Optional Composite and S-Video input
● Slim and compact size
● Wide Viewing Angle
Disclaimer
This information is subject to change without notice. The producer of this manual accepts no
responsibility for damage or claims, resulting from misuse or misinterpretation
Apr 05
P.3
HAP-19AV / HDP-19AV / HOP-19AV Series
2. Introduction
C. Dimension Diagrams
HAP-19AV series
Apr 05
P.4
HAP-19AV / HDP-19AV / HOP-19AV Series
2. Introduction
C. Dimension Diagrams
HDP-19AV series
Apr 05
P.5
HAP-19AV / HDP-19AV / HOP-19AV Series
2. Introduction
C. Dimension Diagrams
HOP-19AV series
Apr 05
P.6
HAP-19AV / HDP-19AV / HOP-19AV Series
2. Introduction
Technical Specifications
Panel 19" LCD Panel
Display Type TFT LCD active matrix colour
Resolutions 1280 x 1024
Response Time Tr=15ms, Tf=10ms
Contrast Ratio 500:1 typical
Brightness 700 cd/m2 typical
Monitor
Pixel Pitch 0.294(H) x 0.294(V)
Power Supply
Connectors
Video
Panel Colour 16.7M display colour
Viewing Angle 89 / 89 / 89 / 89 (L / R / U / D)
Storage Temp. -20° to 65°C
Operating Temp. 0° to 50°C
MTBF 50,000 hours
Remote Adapter 110V - 220V AC Input
Adapter Size 108(L) x 64 (W) x 30(D) mm
Cable Length from
mains plug to adapter
Cable Length from
adapter Unit
182cm
180cm
Power Socket 12V (+) female
VGA HDDB 15-pin (female) x 1
Standards Supports NTSC, PAL or SECAM
AP Series : 456(W) x 380(H) x 62(D) mm
Product
Dimension
DP Series : 435(W) x 350(H) x 65(D) mm
OP Series : 464(W) x 360(H) x 56(D) mm
Packing
Dimension
AP / DP / OP Series : 630(L) x 550(W) x 110(H) mm
AP Series : 6.5 / 8.5 Kg
Net / Gross
Weight
DP Series : 6 / 8 Kg
OP Series : 5.5 / 7.5 Kg
The Federal Communications Commission warns the user that any
Apr 05
P.7
HAP-19AV / HDP-19AV / HOP-19AV Series
3. Installation
A. Package Contents
After unpacking the carton, check and see if the following items are included in
good condition. Contact your supplier as soon as possible for replacing the
missing / damaged items.
● 19” TFT LCD monitor
● RCA Cable ( For AV Version Only)
● S-Video Cable ( For AV Version Only)
● VGA Cable (Male to Male)
● DC 12V Adapter
● Power Cord
● Mounting Bracket (AP Series only)
● User Manual
● CD Disc
B. Caution to The User
To assure continued FCC compliance, please use grounded power supply
cord and the provided shielded video interface cable with bonded ferrite cores.
If a BNC cable is going to be used, use only a shielded BNC (5) cable. Also,
unauthorized changes or modifications to the unit if not expressly approved by
the party responsible for compliance could void the user's authority of
operating the equipment.
C. Cleaning
1. Gently wipe screen with a clean camel hair lens brush, or a soft, clean,
lint-free cloth. This removes dust and other particles that can scratch the
screen.
2. Do not apply excessive pressure to the screen surface when wiping it clean
because this may damage the LCD.
3. Do not pour or spray any liquid directly onto the screen or case of the LCD
monitor. Chemical cleaners have been reported to damage the screen or
case of the LCD monitor.
Apr 05
P.8
HAP-19AV / HDP-19AV / HOP-19AV Series
3. Installation
D. Precautions
Read all of these instructions and save them for later use. Follow all warnings
and instructions on the product.
Product
● Do not cover or block the vent holes in the case.
● Do not insert sharp objects or spill liquid into the LCD monitor through
cabinet slots. They may cause accident fire, electric shock or failure.
● Disconnect the power plug from the AC outlet if you will not use it for an
indefinite period of time.
● Do not attempt to service this product yourself, as opening or removing
covers may expose you to dangerous voltage points or other risks.
● Do not touch the screen directly with your fingers. You may damage the
screen, and oil from your skin in difficult to move.
● Do not apply pressure to screen. The LCD is very delicate.
Power
1. Use the type of power indicated on the marking label.
Plugs
1. Do not remove any of the prongs of the monitor’s three-pronged power
plug.
2. Disconnect the power plug from the AC outlet under following
conditions ：
● If the product will not be used for an indefinite period time.
● When the power cord or plug is damaged or frayed.
● If the product does not operate normally when the operating
instructions are followed.
● Adjust only those controls that are covered by the operating
instructions. Improper adjustment of other controls may result in
damage and will often require extensive work by a qualified
technician to restore the product to normal operation.
● If the product has been dropped or the cabinet has been damaged.
● If the product exhibits a distinct change in performance, indicating a
need for service.
Apr 05
P.9
HAP-19AV / HDP-19AV / HOP-19AV Series
3. Installation
D. Precautions (Cont.)
Power and extension cords
1. Do not allow anything to rest on the power cord.
2. Do not locate this product where persons will walk on the cord.
3. Use the proper power cord with correct attachment plug type. If the
power source is 120V AC, use a power cord that has UL and C-UL
approvals. If the power source is a 240V AC supply, use the tandem
(T blade) type attachment plug with ground conductor power cord that
meets the respective European country’s safety regulations, such as
VDE for Germany.
4. Do not overload wall outlets or power cords. Ensure that the total of all
units plugged into the wall outlet does not exceed 10 amperes.
5. Ensure that the total ampere ratings on all units plugged into the
extension cord is not above the cord’s rating.
6. If the power supply cord, which came with your monitor, is to be
connected to the PC instead of the wall outlet, this equipment is to be
used with UL/TÜV approved computers with receptacle rated
100~240V AC, 50/60Hz, 1.0A(minimum).
Environment
1. Place the monitor on a flat and leveled surface.
2. Place the monitor in a well-ventilated place.
3. Keep the monitor away from： Overly hot, cold or humid places, places
directly under sunlight, dusty surroundings, equipment that generate
strong magnetic fields.
Apr 05
P.10
HAP-19AV / HDP-19AV / HOP-19AV Series
4. Using the System
A. Product Views
HAP Series - Front View
AP Series - Rear View
Apr 05
P.11
HAP-19AV / HDP-19AV / HOP-19AV Series
4. Using the System
A. Product Views (Cont.)
HDP Series - Front View
DP Series - Rear View
Apr 05
P.12
HAP-19AV / HDP-19AV / HOP-19AV Series
4. Using the System
A. Product Views (Cont.)
HOP Series - Front View
OP Series - Rear View
Apr 05
P.13
HAP-19AV / HDP-19AV / HOP-19AV Series
4. Using the System
B. I/O Outlet
Front
AP Series
DP Series
OP Series
(1) (3)
(1) DC IN ： Connect to power cable.
(2) PC IN ： Connect to D-Sub 15 pin signal connector.
(3) S-Video IN ： Connect to the S-Video cable connector. (for AV series only)
(4) RCA IN ： Connect to the composite cable connector. (for AV series only)
(2)
(4)
Apr 05
P.14
HAP-19AV / HDP-19AV / HOP-19AV Series
4. Using the System
C. Installation Procedures
This monitor is equipped with an auto-sensing power supply for
voltage ranges 100~240V, 50~60Hz. Please follow the following
instruction to install LCD monitor.
1. Make sure that the system power is turned off.
2. Plug the signal cable to the signal connector at the rear of
PC and the rear of the LCD monitor.
3. Plug adapter output cable to the jack at the rear of LCD
monitor and the power cord to the adapter.
4. Connect the power cord to power source.
5. Turn on the computer and the monitor.
6. Then push the OSD menu button and use the Auto Adjust
function to fine the best mode of your computer.
Apr 05
P.15
HAP-19AV / HDP-19AV / HOP-19AV Series
4. Using the System
D. Setup Touchscreen
Touchscreen used for UltraView products are manufactured by 3M. Here provide
TouchWare
TM
Software includes touch screen drivers for your installing.
Note: To configure the settings of the touchscreen, please refer to the
TouchWare
TM
User Guideline
Note: If you have a Microsoft® IntelliPoint® or Kensington® Mousework® PS/2
mouse, installing TouchWare
TM
software will disable the special mouse
functionally of these devices
For Windows 95, 98, Me, NT4.0, 2000 & XP
1. Open the driver CD provided along with the product or download the driver
from our Website.
2. Make sure you have completed the appropriate hardware connections.
3. Power on your system. Make sure no other application are opened.
4. Double click the “TW564SR4.exe” files.
5. Unzip the file and save it in a default folder
Note: Remember the path of the default folder or create a new folder by your decision.
6. Follow the onscreen instructions to begin the installation.
Note: Choose Express option for automatically installs the required TouchWare
TouchWare
TouchWareTM will also determine multiple monitor configurations at this time.
Note: For details of Custom option, please refer to the website of 3M and download the
user guide of TouchWare
(http:// www.3m.com/3MTouchSystems/downloads/tecdoc.jhtml)
software files, create a TouchWare
TM
software icon on the Windows desktop and control panel.
TM
software.
TM
software program files, and place a
TM
Apr 05
P.16
HAP-19AV / HDP-19AV / HOP-19AV Series
4. Using the System
D. Setup Touchscreen
For Windows 95, 98, Me, NT4.0, 2000 & XP (Cont.)
7. Once installation is complete, restart the system. As the system restarts,
Windows detects and loads the driver.
● For serial controllers, restart the system. As the system restarts, Win-
dows detects and load the driver
Note: This step is not necessary for Windows 2000 or above system, The driver loads
automatically.
● For USB controllers, connect the touch screen cable to the USB port in
your computer. After a few seconds, the system beeps to indicate it has
detected the touch screen and loaded the driver.
For DOS
When you install Touchware from DOS, the Install program only loads the
touchscreen files specific to DOS. The installation includes the following files:
● Touchscreen driver for DOS
● Touchscreen control panel for DOS
● Pen Configuration utility for DOS
● Microcal Diagnostic utility
● ThruGlass control panel for DOS
● DOS help files
If you do not plan to use any of the touchscreen files for windows, you may want
to install just the DOS touchscreen files.
1. Open the driver CD provided along with the product or download the driver
from our Website.
2. Make sure you have completed the appropriate hardware connections. If
not, the Install program cannot properly configure the touchscreen.
3. Close all applications and exit from Windows.
4. Insert the TouchWare Disk into a diskette drive.
5. Access the DOS command line prompt.
6. Change to the drive that has the TouchWare diskette. For example, enter A:
if you inserted the TouchWare diskette in Drive A.
Apr 05
P.17
HAP-19AV / HDP-19AV / HOP-19AV Series
4. Using the System
D. Setup Touchscreen
For DOS (Cont.)
7. Type INSTALL followed by the source disk drive, the destination drive, and
the destination directory.
For example, the following command copies the files from Drive A (source
drive) to Drive C (destination drive) and the \MTS\TOUCH directory :
INSTALL A: C:\MTS\TOUCH
8. Press Enter. The system reports that it is about to copy the DOS touchscreen
files and prompt for confirmation that you want to continue.
9. Press C to start the installation.
● First, the Install program copies all DOS touchscreen files from the
TouchWare diskette to the specified destination drive and directory.
● Next, the Install program automatically searched through the system
and configures the touchscreen to the proper COM port, interrupt, and
communication rate.
● Finally, the Install program prompts if you want it to automatically modify
your AUTOEXEC.BAT file
If you let the Install program modify your AUTOEXEC.BAT file, the system
automatically loads the DOS touchscreen driver whenever you start your
computer.
If you do not let the Install program modify your AUTOEXEC.BAT file, you
must load the DOS touchscreen driver before using a DOS touch application.
For more information, refer to “Loading the DOS Touchscreen Driver” in the
next page
Apr 05
P.18
HAP-19AV / HDP-19AV / HOP-19AV Series
4. Using the System
D. Setup Touchscreen
For DOS (Cont.)
Loading the DOS Touchscreen Driver
After you install the files for the DOS touchscreen driver, you must load the driver
before you can run a DOS touch application or open the DOS Touchscreen
control panel.
You can run the DOS touchscreen driver from a full-screen DOS session within
Windows. However, the Windows touchscreen driver cannot be running. Error
message reads: “Windows x.x is running in 386 Enhanced mode. Device not
found.”
This means either the Windows Touchscreen driver is loaded or the COM port/
IRQ designations are incorrect.
You can manually load the DOS touchscreen driver when needed, or you can let
the system automatically load the driver when you start up your computer.
● To manually load the DOS touchscreen driver:
1. Close all applications and exit from Windows.
2. Access the DOS command line prompt.
3. Use the Change Directory (cd) command to switch to the directory that
has the DOS touch driver files. By default, the Install program loads
TouchWare into the C:\MTS|TOUCH directory.
4. Type DOSTOUCH and then press Enter. The system displays a message
that the driver is now installed. For example:
MicroTouch Mouse Emulator - Version x.x
Copyright © 1990 - 1997 MicroTouch Systems, Inc.
Driver Installed
● To automatically load the DOS touchscreen driver when you start up your
computer, add the following line to your AUTOEXEC.BAT file :
drive-designator :\directory\DOSTOUCH
where drive-designator and directory define the location (disk and path) of
the files for the DOS touchscreen. For example:
C:\MTS\TOUCH\DOSTOUCH
Apr 05
P.19
HAP-19AV / HDP-19AV / HOP-19AV Series
4. Using the System
E. OSD Switch
Menu/Selection Power
Left
Right
Exit
Input Select: This button is used to select CVBS for composite
video input, RGB for VGA input and S-Video for
Super-Video input
OSD Menu: This button is used to enter OSD main Menu
Increase(à): This button is used to adjust the increasing or
next value of selected OSD control option.
Decrease(ß): This button is used to adjust the decreasing or
next value of selected OSD control option.
Power Switch: This button is used to power ON/OFF the LCD
Apr 05
P.20
HAP-19AV / HDP-19AV / HOP-19AV Series
4. Using the System
F. OSD Control For Video Input Version
LCD Membrane Diagram
Menu/Selection Power
Left
Right
Exit
MAIN MENU
BRIGHT/CONTRAST
AUTO ADJUST
PHASE/CLOCK
H/V POSITION
MISC
RESET
Main Menu
Bright / Contrast
● To enter into the Bright, Black level & Contrast sub-menu
Auto Adjust
● To perform automatic optimisations of all functions
● An “ Adjusting” message is displayed during the process
Phase / Clock
● To enter into the phase & clock sub menu
H/V Position
● To enter into the Position sub-menu
MISC
● To enter into the MISC sub-menu
Reset
● Reset to the default factory settings
Apr 05
P.21
HAP-19AV / HDP-19AV / HOP-19AV Series
4. Using the System
F. OSD Control For Video Input Version
Bright / Contrast
1. Brightness
● To perform brightness adjustment of the input RGB signal
● Use the Left & Right button to adjust and button to “Brightness”
2. Contrast
● To adjust the contrast level of the input signal
● Use the Left & Right button to adjust and button to “Contrast”
Phase / Clock
1. Phase
● To adjust input video sampling clock’s phase
● Use the Left & Right button to adjust and button to “Phase”
2. Clock
● To adjust input video sampling clock
● Use the Left & Right button to adjust and button to “Clock”
H/V Position
1. H.Position
● To adjust the horizontal size of the frame
● Use the Left & Right button to adjust and button to “H.position”.
2. V.Position
● To adjust the vertical position of the frame
● Use the Left & Right button to adjust and button to “V.position”.
Apr 05
P.22
HAP-19AV / HDP-19AV / HOP-19AV Series
4. Using the System
F. OSD Control For Video Input Version
MISC
1. Information
● The first header row shows the current resolution setup
● The second header row shows the horizontal frequency of the current
input signal
● The third header row shows the vertical frequency of the current input
signal
2. OSD Timer
● To modify the duration of the OSD time-out
3. Color
a) 5500K
● Select Colour Temp at 5500K
b) 6500K
● Select Colour Temp at 6500K
c) 9500K
● Select Colour Temp at 9500K
d) User
● Change Colour Temp by manual
4. Language
● To select the language of OSD menu 7 Languages :
(1) English
(2) Japanese (日本語)
(3) Chinese (中文)
(4) German
(5) Francais
(6) Espanol
(7) Italiano
Apr 05
P.23
HAP-19AV / HDP-19AV / HOP-19AV Series
4. Using the System
G. OSD Control For Video Input Version
Main Menu
● To enter into the Brightness, Contrast, Sharpness, Saturation, Hue sub-
menu
Geometry
● To enter into Auto Conflg., H. Position, V. Position, Clock, phase sub-menu
Function
● To enter into the OSD Position, OSD Zoom and Color Temp. sub-menu
System
● To enter into the Language, Time, Power OFF and Reset sub-menu.
Apr 05
P.24
(+19)
HAP-19AV / HDP-19AV / HOP-19AV Series
4. Using the System
G. OSD Control For Video Input Version
G. OSD Control For Video Input Version
Brightness
To adjust brightness level of the input signal
Use the q button to select the function, then use t/u button to adjust from 0-100
Contrast
To adjust the contrast level of the input signal
Use the button to select the function, then use t/u button to adjust from 0-100
Sharpness
To adjust the sharpness level of the input signal
Use the button to select the function, then use t/u ’button to adjust from 0-35
Saturation
To adjust the saturation level of the input signal
Use the button to select the function, then use t/u ’button to adjust from 0-100
Hue
To adjust the Hue level of the input signal
Use the button to select the function, then use t/u button to adjust from (–19)-0-
Apr 05
P.25
button to select “ Auto Conflg”
HAP-19AV / HDP-19AV / HOP-19AV Series
4. Using the System
G. OSD Control For Video Input Version
Geometry
Auto Conflg
To perform auto adjustment of the screen output.
Use the button to select the function, then use the t/u
H. Position
To adjust Horizontal Position of the screen output.
Use the button to select the function, then use the t/u button to adjust “H. Position”
V. Position
Clock
Phase
To adjust Vertical Position of the screen output.
Use the button to select the function, then use the t/u button to adjust “ V. Position”
To adjust the width of the image
Use the button to select the function, then use the t/u button to adjust “Clock” .
To perform snow noise adjustment of the image.
Use the button to select the function, then use the t/u button to adjust “ Phase”
Apr 05
P.26
HAP-19AV / HDP-19AV / HOP-19AV Series
4. Using the System
G. OSD Control For Video Input Version G. OSD Control For Video Input Version
Function
OSD Position
To perform OSD position selection of the screen
Use the button to select the function, then use the t/u button to select the digit for
the OSD display region.
OSD Zoom
To perform OSD Zoom function of the OSD image
Use the button to select the function, then use the t/u button to on/off the OSD
Zoom function
Color Temp.
To perform the Color Temperature selection of the image output
Use the button to select the function, then use the t/u ' button to select “ Standard”,
“Cool”, “Warm” and “User”
Apr 05
P.27
HAP-19AV / HDP-19AV / HOP-19AV Series
4. Using the System
G. OSD Control For Video Input Version
System
Language
To perform Language selection of the function display
Use the button to select the function, then use the t/u button to select suitable
display language “ English”, “Chinese (中文)”, “Deutsch”, “Francais”, “Espanol”,
“Italiano” and “Japanese (日本語)”.
Time
To perform time setting of the system.
Use the button to select the function, then input the time setting and restore
Power OFF
To perform preset power off setting
Use the button to select the function, then input time setting and use t/u button
to on/off the function.
Reset
To perform reset all stored parameters to factory preset mode
Use the button to select the function, then use t/u button activate the function.
Loading...
