i-tec USB-C 3.1 Dual 4K DP Video Adapter
i-tec USB-C to Dual Display Port Video
Adapter, 2x Display Port 4K Ultra HD,
compatible with Thunderbolt 3 for , Mac
OS only for one Display
PRODUCT DESCRIPTION
Expand your desktop to two external Display Port monitors or connect projectors or television to your notebook,
tablet or PC via new USB-C or Thunderbolt 3 connector. The adapter supports 2x 4K Ultra HD video with
resolution up to 3840 x 2160 px and stereo sound. The adapter is suitable for use with Chromebook Pixel 2015,
Acer Switch Alpha 12, Dell XPS 13, HP EliteBook Folio G1 and other devices with the USB-C connector. The USBC connector has many advantages, it is smaller, symmetrical and allows the easy connection because now you
need not take care of the rotation of the connector. When connected to the Apple notebook, only one monitor is
supported. No USB-C video adapter is able to support two monitors in Mac OS environment; only Thunderbolt 3
adapter is capable of dual monitor output in Mac OS systems.
The adapter is an excellent choice for designers, graphic designers, gamers, and other users working with more
than one screen simultaneously. Using the “Extend” and “Mirror” modes you can work for example with
applications on two monitors (e.g., wide spreadsheets), or you can work on the first screen and search for
information on the Internet on the second screen, you can compare several documents simultaneously without
constant switching among the open windows, you can display panoramic images on two screens without the
need to have another computer etc. Using is very simple, just plug the adapter into the USB-C or Thunderbolt 3
port on your computer, connect it with a display device via Display Port cable and you can immediately start
using. Driver installation is automatic from the system.
Please make sure to check a compatibility of your device, whether it meets all the requirements for an operation
of the specific i-tec product, especially video output (Display Port Alt mode), and/or Power Delivery. If your
device would not be fully compatible, your new i-tec product may not operate correctly. You may find the
specifications your device (i.e. USB port), in a user manual supplied with your notebook/tablet/smartphone, or –
alternatively – via customer service provided by a manufacturer of your device. If still uncertain, however,
contact our service at support@itecproduct.com.
PRODUCT FEATURES
Expand your desktop to two external Display Port monitors or connect projector or television via new
USB-C or Thunderbolt 3 connector, the adapter allows you to transfer video with 4K Ultra HD resolution
and stereo sound
When connected to the Apple notebook, only one monitor is supported. No USB-C video adapter is able
to support two monitors in Mac OS environment; only Thunderbolt 3 adapter is capable of dual monitor
output in Mac OS systems.
1x USB-C 3.1 connector, transfer rate up to 10 Gbps, for connecting to a notebook, tablet or PC
Graphic interface: 2x Display Port (spec. 1.2), max. 3840x2160 / 30Hz, for connecting an external
monitor, projector or television
Mode: Extend, Mirror and Primary Display
Supported colors 16/32 bit
Powered through USB bus, no power adapter is needed
i-tec Technologies s.r.o. 1/3 https://www.i-tec.cz
OS: Requires USB-C interface with "DisplayPort Alternate Mode" support (not all devices/systems with
USB-C interface supports the standard) or Thunderbolt 3 port – Windows 10 32/64bit, Mac OS X, Chrome
OS (Google) with Intel Broadwell Processor and R51 and higher
Product dimensions: 70 x 60 x 15 mm
Product weight: 60 g
Packaging dimensions: 180 x 130 x 25 mm
Packaging weight: 153 g
SYSTEM REQUIREMENTS
Hardware requirements: notebook, tablet, PC with OS Windows, Mac or Google with a free port USB-C with
"DisplayPort Alternate Mode" support or with Thunderbolt 3 port
Operating system: Windows 10, Mac OS X, Google (Chrome OS) with latest updates
PACKAGE CONTENTS
i-tec USB-C 3.1 Dual 4K DP Video Adapter with cable (30 cm)
Quick Start
SPECIFICATION
Part Number Product Description & EAN
C31DUAL4KDP i-tec USB-C 3.1 Dual 4K DP Video Adapter
EAN: 8595611702037
Hardware
Bus type USB-C, Thunderbolt-3
Ports/Connectors
DISPLAY PORT 2
System Requirements
Hardware Hardware requirements: notebook, tablet, PC with OS Windows, Mac or
Google with a free port USB-C with “DisplayPort Alternate Mode”
support or with Thunderbolt 3 port
Operating system Windows 7/8/8.1/10 (32/64 bit)
Mac OS X
Chrome OS Windows 10 - Automatic installation of OS drivers. Other
operating systems - manual driver installation. Firmware updates
automatically.
Other features
Colour Black
Housing Material Plastic
Product Dimensions 70 x 60 x 15 mm
Product Weight 60 g
Package Weight 153 g
Packaging Dimensions (LxWxH) 180 x 130 x 25 mm
Support
Warranty period 2 years
Technical support lifetime
i-tec Technologies s.r.o. 2/3 https://www.i-tec.cz
Package contents
i-tec USB-C 3.1 Dual 4K DP Video Adapter with cable (30 cm)
Quick Start
For further information regarding setup or for answers to FAQ’s, please visit our website i-tec.cz. Specifications
are subject to change without notice.
Updated 19.7.2018
