i-tec C31CR3HUB User Manual

i-tec USB-C Slim Passive HUB 3 Port + Card Reader

i-tec USB-C Slim 3-port HUB with memory
card reader, 3x USB 3.0 port, 1x slot for
SD/SDHC/SDXC, 1x slot for micro
SD/SDHC/SDXC, for notebook tablet
smartphone PC with USB-C connector,
compatible with Thunderbolt 3, Windows
Mac Android

PRODUCT DESCRIPTION

The ADVANCE Series is the highest level of i-tec accessories bringing you the cutting edge technologies of
products with a modern design and exclusive packaging.

Combination of passive 3-port HUB with the card reader. For easy and fast connection of USB peripherals to
your notebook, tablet, PC or smartphone with new USB-C or Thunderbolt 3 interface. An ideal companion for
everybody who does not have enough USB ports and who has to constantly connect and disconnect his/her
favorite USB equipment. The memory card reader will be appreciated especially by users of digital cameras and
HD video cameras using memory cards as a medium for a frequent transmission of data.

The HUB offers three USB 3.0 ports with the Plug & Play function and standard USB charging – it will
automatically detect connected equipment for USB charging. The USB 3.0 interface is important mainly for data
transfers from USB 3.0 memory cards and flash disks which will use its high transfer speed most. Two slots for
memory cards support formats SD, SDHC, SDXC, micro SD, micro SDHC and micro SDXC.

This HUB does not require the installation of drivers. You will just connect it with the USB-C cable to your
computer and immediately you can start using it. This HUB is powered from the USB bus and it has a built-in
overcurrent protection of your computer in case of short connection on the peripheries. The HUB is suitable for
use with Apple MacBook 2015, Chromebook Pixel 2015, Acer Switch Alpha 12, Dell XPS 13, HP EliteBook Folio
G1 and other devices with the USB-C connector. The USB-C connector has many advantages, it is smaller,
symmetrical and allows an easy connection because now you don't need to take care of the connector rotation.

In case of problems with the installation, technical difficulties or incorrect function of the
equipment, check first for the possible solution in the FAQ tab.

PRODUCT FEATURES

Combination of passive 3-port HUB with memory card reader, for easy and fast connection of your
favorite USB peripherals and for data transfer from memory cards
3x USB 3.0 port for connecting the USB equipment and for high-speed data transfer (5 Gbps)
1x slot for SD/SDHC/SDXC memory cards
1x slot for micro SD/micro SDHC/micro SDXC memory cards
Integrated USB-C 3.1 cable for connecting the HUB to the USB port of your notebook, tablet, smartphone
or PC
USB charging detection mechanism for mobile devices
Plug & Play function
Overload and overcurrent protection
LED diode
Powered through USB-C bus, no power adapter is needed
OS Windows 7/8/8.1/10, Mac OS X, Linux, Android 6 or higher, Chrome R51 or higher
Product dimensions: 125 x 29 x 9 mm

i-tec Technologies s.r.o. 1/3 https://www.i-tec.cz

Product weight 38 g
Packaging dimensions: 220 x 153 x 32 mm
Packaging weight: 93 g

SYSTEM REQUIREMENTS

Hardware requirements: notebook, tablet, PC, smartphone with free USB-C or Thunderbolt; 3 port Operation
system: Windows 7/8/8.1/10, Mac OS X, Linux, Android 6 or higher, Chrome R51 or higher

PACKAGE CONTENTS

i-tec USB-C Slim HUB 3 Port + Card Reader with integrated cable (16 cm)
Quick Start

SPECIFICATION

Part Number Product Description & EAN

C31CR3HUB i-tec USB-C Slim Passive HUB 3 Port + Card Reader

EAN: 8595611701665

Hardware

Bus type USB-C, Thunderbolt-3

Ports/Connectors

USB 3.0 TYPE A 3

SD CARD READER 1

System Requirements

Hardware Hardware requirements: notebook, tablet, PC, smartphone with free

USB-C or Thunderbolt; 3 port

Operating system Windows 7/8/8.1/10 (32/64 bit)

Mac OS X
Chrome OS
Linux Ubuntu 14.04/16.04
Android 6, 7, 8Windows 10 - Automatic installation of OS drivers. Other
operating systems - manual driver installation. Firmware updates
automatically.

Other features

Colour Black

Housing Material Plastic

Product Dimensions 125 x 29 x 9 mm

Product Weight 38 g

Package Weight

Packaging Dimensions (LxWxH) 220 x 153 x 32 mm

Support

Warranty period 2 years

Technical support lifetime

Package contents

i-tec USB-C Slim HUB 3 Port + Card Reader with integrated cable (16 cm)
