ITALCOM GROUP ITALCOMPIN User Manual

User Manual

Product name: 4G LTE

Model: PIN

Brand: NYX

Contents

Contents ............................................................................................................................................. 1

1. Appearance and Keypad Operations .............................................................................................. 2

2. Using Memory Card as U Disk ...................................................................................................... 2

3. Wi-Fi .............................................................................................................................................. 3

4. Bluetooth ........................................................................................................................................ 4

5. Gmail.............................................................................................................................................. 5

6. Phone.............................................................................................................................................. 6

7. Messaging ...................................................................................................................................... 8

8. Contacts........................................................................................................................................ 10

9. Clock ............................................................................................................................................ 13

10. Calculator ................................................................................................................................... 14

11. Camera ....................................................................................................................................... 14

12. Gallery........................................................................................................................................ 16

13. Calendar ..................................................................................................................................... 19

14. FM Radio ................................................................................................................................... 20

15. Settings ....................................................................................................................................... 21

16. Notices for the use of phone ...................................................................................................... 23

Keys

Functions

home Short press this button to return home from any application or interface.

Long press it to open Google search.

recent

Short press it to open the recent items.

back

Press it to return to the previous interface，or to close dialog box ,options’

menu ,notification panel or the keypad.

power

Short press this button to lock or unlock the screen. Long press it to open the phone’s menu，then you could choose to Power off,

Restart, Airplane mode, Screenshot and switching scene modes.

Press it to increase the volume.

down

Press it to decrease the volume.

USB debugging connected

USB for file transfer

1. Appearance and Keypad Operations

2. Using Memory Card as U Disk

If you want to send music, pictures or other files to the phone’s memory card from the computer，you

should set memory card as u disk first.

Set memory card as u disk

1) Connect the phone to the computer with USB cable. The notification icon will appear in the status

box.

2) Use USB mobile transmission line will connected to the computer

3) In the notification panel, touch USB is connected，And then touch the USB connected as a media

device

Notice: On the PC operation assistant tool such as mobile phone, Must be open the USB debugging.

3. Wi-Fi

Wi-Fi provides as far as 300feet (100M) range of wireless network access. If you use cell phone to

connect Wi-Fi , you should connect to the wireless access point or 「hot spots」.

Notices：The availability and coverage of Wi-Fi signal depend on the number, infrastructure and other

objects penetrated by the signal.

Open Wi-Fi and to connect to the wireless network

1) Enter settings.

2) Select the Wi-Fi box，to open Wi-Fi. Phone will automatically scan for available wireless networks.

3) Touch Wi-Fi settings. Then a list of Wi-Fi network will show the founded network name and security

settings. (open network or WEP、WPA/WPA2 with password).If you enable the notification in Wi-Fi settings,

The status box will show this icon ( ) when open available wireless network founded.

4) Touch one of the Wi-Fi choices to connect the network. When you choose open network, phone will connect to it automatically. If you choose WEP、WPA/WPA2 with password, you should type the password first, then touch to connect it.

Notices：when the phone is connected to the wireless network, the status box will show this Wi-Fi icon

（）, and the approximate signal strengthen (the number of lit bars).If touch the connected network， will display the name of Wi-Fi network, status ,speed ,signal, strength, security, information and IP address.

If you want to delete the wireless settings, please touch “FORGET” as in the picture below. If you want

to connect to this network, you should re-enter these settings.

Notice：

Unless you choose to forget the network, otherwise, there is no need to re-enter the corresponding password when next time connecting to the previously encrypted wireless network. Wi-Fi will search automatically, that is, phone needn’t to perform additional steps to connect Wi-Fi networks.

Connect to other Wi-Fi networks

In the interface of wireless and network, touch Wi-Fi settings. The founded Wi-Fi networks will show on the Wi-Fi network list.

Touch other Wi-Fi networks, and then you can connect to this network.

Notices: in addition, mobile phone can also surf the Internet by GPRS. Our current SIM card GPRS to open after the default boot. Users can manually choose to open data connection, when for the single card, direct drop down the status bar, touch "data connection" is open, when for the double card, location in "Settings > SIM cards > Mobile data > select SIM1 or SIM2", touched the drop-down "Data connection" of the status bar is open the current selected SIM card data connection, and then touch "Data connection" close this SIM card data connection.

4. Bluetooth

Turn on Bluetooth or set the phone can be detected

1) Enter settings.

2) Select Connected devices, then open Bluetooth, the status box will show this icon ( ).

3) Touch “Pair new device”, all the devices founded will display in the list under the icon.

(Bluetooth device is set open and visible to a nearby equipment work, other equipment as long as open the Bluetooth can search to the Bluetooth and matching, open as long as the other devices can be detected at the same time, you can search for other equipment and matching use)

After a paired device, the system will show the paired and other equipment available

Pairing and connection of Bluetooth headset

1) Enter settings.

2) Select Connected devices, then open Bluetooth, touch “Pair new device” , then your phone will scan

for the Bluetooth devices within range ,and show the founded devices in the list under the icon.

Tips：

Make sure that the devices wanted are under the detected mode.

3) Touch headset in the equipment list to finish the connection.

Notices：generally Bluetooth devices need password to be paired, often use「0000」as the default password.

4) The pairing and connecting status will show under the headset in the Bluetooth devices list. When

the headset connected to your phone, the status box will show this icon（）means connected. Then you can use the headset to make or receive callings.

Cut the connection to the Bluetooth

In the list of Bluetooth equipment, touch or tap and hold the connected hand-free headset.

Press and select “OK”.

5.Gmail

Create an electronic mail account Open the Gmail, You can activate or edit existing e-mail accounts as well as create a new e-mail

account.

Select mail, Google account setting interface appears. Then touch‘ next step’ > create

account>enter name，last name and e-mail account.

Google servers determine whether the name can be used, if so, new interface appears prompting enter password, then judge the password’ security, users who doesn’t meet the requirements need to re-enter the password.

Successfully register a new Gmail account, a messenger created automatically for testing.

2) Loading mail account

a. Open Gmail skip introduction screen>loading interface appears >select load

b. Enter name, password then load

E-mail account initialization, prompting “login successful” All Google accounts will be

synchronized.

3) Creating and sending mails

When creating mails, select mail > creating mails. Enter the address(recipient)、theme and contents. Press MENU you could ‘append’、‘ Add Cc/Bcc’, select send or discarded.

4) Receive mails

There is tone for new mails，Press Menu >‘refresh’， refresh and update the number of the unread mails in a proper way.

5) Delete mails

When loading a mail account，if you want to delete it，you need to restore factory settings . When loading a second one，you could press the menu button to delete it.

Notices：many functions depend on Gmail Account，for example：Electronic Market、Google Talk、 Sync Contact and Calendar.

6.Phone

When the icon of network server appears in the screen, you could dial or receive callings. The signal

bar on the top right corner show the strength of network signal (When the signal with the strongest signal).

Start dialing Open application’s main menu>phone >Dial the keyboard. You could choose SIM1 or SIM2 to do the

dialing.

Dialing At the dialing Keyboard ，enter the phone number，and then click the dialing key , after that, you

should choose one SIM card.

Telephone calls in the call log

Every telephone number called and received in“SIM1、SIM2”will reserved in phone’s menu of call log. Each call to record recently will show“SIM1 or SIM2”,All numbers in the call log can be dialed by clicking the button ”dial” on the right side of the screen. When number list appearing，click it to catch details；press it for long you could dial via “SIM1 or SIM 2”， meanwhile you can edit, delete, save the number or do other operations.

Receive callings

When calling comes, swipe up to answer.

Refuse to answer the phone,

Have a telephone call in, swipe down to reject.

Have a telephone call in, hold the icon in the lower left corner and swipe from the icon to decline with message, the call will be suspended and the caller will receive the corresponding text messages.

Proximity sensor

According to the distance between phone and human body，it will adjust automatically the switch of the backlight.

During the call, close the phone to the ear, the backlight will turn off automatically，which could save batteries and prevent inadvertently touching.

Two-way call/multiparty call (conference call)

Notices：This function needs that SIM card open multiparty call features.

Click“ ”，dial another call（or receive another call，phone default open “call waiting”，after both connected，could view the status of calling.

Telephone recording

During the call，Click“ ”，you could record the dialog of the call.

Call settings

1) Display options: Can set contact sort and name format

2) Sounds and vibration: Can set phone ringtone and vibration

3) Quick responses: Can edit the text messages rejected by the information when content

4) Calling accounts: Can set FDN ,Call forwarding, Call barring and Additional Settings

5) Call blocking: Can add the number of contacts you don't want to receive by phone or text message

6) Voicemail: Can set voicemail number and voicemail notifications

7) Accessibility: Can set TTY mode

8) About: Can view build version and others.
