ITALCOM GROUP ITALCOMFLYMINI Users manual

GSM/GPRS Mobile Phone
User’s Guide
0
Table of Contents
1.1
OVERVIEW ............................................................. 4
1.2
SAFETY GUIDE ....................................................... 5
1.3
SAFETY WARNINGS AND NOTICES ........................ 6
1.3.1 General attention ................................................ 6
1.3.2 Notices when using your phone .......................... 7
1.3.3 Notices when using the battery ........................... 9
1.3.4 Charging your phone ........................................ 12
1.3.5 Cleaning and maintenance ............................... 15
2.1
COMPONENT NAME AND EXPLANAT IO N.................. 16
2.1.1 Technical parameters ................................. 16
2.1.2 Icons ............................................................. 16
2.2 KEY EXPLANATIONS ............................................. 19
USING THE TOUCHSCREEN ................................. 20
2.3
2.4
CONNECTING TO THE NET W ORK......................... 20
2.4.1 Inserting and removing the SIM card ................ 20
2.4.2 Turning your phone on and off .......................... 21
2.4.3 Unlocking the SIM card .................................... 22
2.4.4 Unlocking your phone ....................................... 23
2.4.5 Connecting to the network ................................ 23
1
2.4.6 Making a call .................................................... 24
2.4.7 Making a domestic call ..................................... 24
2.4.8 Making an international call ............................ 25
2.4.9 Making a call from the list ................................ 25
2.4.10 Making an emergency call .............................. 26
2.4.11 Call menu ........................................................ 26
3.1
FILE MANAGEMENT ............................................ 28
3.2
SENDING AN EMAIL ............................................. 29
3.3
DIALING ............................................................... 30
3.4
3G VIDEO CAL L ................................................... 31
3.5
CALCULATOR ...................................................... 32
3.6
BROWSER............................................................ 33
3.7
VOICE RECORDER .............................................. 34
3.8
CALENDAR .......................................................... 36
3.9
SETTINGS ............................................................ 37
3.10
CLOCK ............................................................... 39
3.11
RADIO ................................................................ 41
3.12
GOOGLE SEARCH.............................................. 43
3.13
CONTACTS ........................................................ 43
3.14
GALLERY ........................................................... 45
3.15
CAMERA ............................................................ 46
3.16
MESSAGING ...................................................... 47
2
3.17 NOTIFICATION MENU ........................................ 49
3.18
DOWNLOAD CONTENT ...................................... 50
3.19
MUSIC ................................................................ 50
3.20
CALL RECORDS ................................................ 52
3.21
WIDGET ............................................................. 53
3.22
SELECTING WALLPAPER SOURCE ................... 54
3
1 The Basics
1.1 Overview
Thank you for choosing the GSM/GPRS mobile
phone. After reading this guide you will be able to fully
master the use of your phone and appreciate all its
functions and ease of use.
Not only does the smartphone provide you with
basic call functions such as call Register, but also with
many practical functions and services, to improve the
time you spend working and playing.
The color screen mobile phone complies with the
GSM/GPRS technology and has been approved by
certification authorities both domestically and abroad.
The availability of some services and features
described in this manual depends on the network and
your subscription. Therefore, some menu items may
not be available in your phone. The shortcuts to
menus and features may also vary from phone to
phone.
Our company reserves the right to revise this
manual content without prior notice.
4
1.2 Safety guide
If your mobile phone is lost or stolen, please
contact the telecommunications authorities or a
sales agent immediately to have a hold on the
phone and the SIM card. This will prevent
economic loss caused by unauthorized calls
made from your mobile phone.
When you contact the telecommunications
authorities or a sales agent, they will need to
know the IMEI number of our mobile phone
(remove battery to expose number located on the
label on back of phone). Please copy this number
and keep in a safe place for future use.
In order to avoid the misuse of your mobile
phone please take the following preventative
measures:
Set the PIN number of your mobile phone’s SIM
card and change this number immediately if it
becomes known to a third party.
Please keep the phone out of sight when leaving
it in a vehicle. It is best to carry the phone with
you, or lock it in the trunk.
Set call barring.
5
1.3 Safety warnings and notices
Before using your mobile phone, read and
understand the following notices carefully to ensure
you will use it safely and properly.
1.3.1 General attention
Only the battery and battery charger specified by
our company should be used in your phone.
Other products might result in battery leakage,
overheating, fire or explosion.
To avoid your phone malfunctioning, or catching
fire, please do not violently impact, jolt or throw
your phone.
Please do not place the battery, mobile phone, or
charger in a microwave oven or high-pressure
equipment. Otherwise it could lead to unexpected
accidents such as damage to the circuitry or fire
hazard.
Please do not use your phone near flammable or
explosive gases, otherwise it could cause
malfunction of your phone or fire hazard.
Please do not subject your phone to high
temperatures, high humidity or dusty places;
otherwise this may lead to the malfunction of your
6
phone.
Keep your phone out of the reach of small
children. Your phone is not a toy. Children could
hurt themselves.
To avoid your phone falling and malfunctioning or
being damaged, please do not place it on uneven
or unstable surfaces.
1.3.2 Notices when using your phone
Turn off your mobile phone where the phone is
not allowed, such as, on the airplane or in
hospitals. Using the mobile phone in those places
may impact the normal operation of electronic
devices and medical instruments. Follow relevant
regulations when using your mobile phone in
those places. Your mobile phone has the auto
turn-on feature. Check your alarm clock settings
to confirm that your mobile phone will not be
turned on automatically during flight.
Please do not use your mobile phone near the
weak signal or high precision electronic devices.
RF interference might cause malfunctioning of
such electronic devices and other problems.
Special tips must be paid near the following
equipment: hearing aids, pace makers and other
7
medical electronic devices, fire detectors,
automatic doors and other automatic control
installations. To find out the effect of mobile
phones on a pacemaker or other pieces of
electronic medical equipment please contact the
manufacturers or local sales agents of the
equipment.
Please do not subject the LCD to impact or use
the screen to strike things, as this will damage the
LCD board and cause leakage of the liquid crystal.
There is a risk of blindness if the liquid crystal
substance gets into the eyes. If this occurs rinse
eyes immediately with clear water (under no
circumstances rub your eyes) and go immediately
to a hospital for treatment.
Do not disassemble or modify your mobile phone,
as it will lead to damage to the phone such as
battery leakage or circuitry failure.
Under very rare circumstances using the mobile
phone in certain model cars may negatively affect
the internal electronic equipment. In order to
assure your safety under such circumstances
please do not use the mobile phone.
Please do not use needles, pen tips, or other
8
sharp objects on the keypad as this may damage
the mobile phone or cause it to malfunction.
In the event of antenna malfunction, do not use
your phone, as it could be harmful to human body.
Avoid letting the phone come into close contact
with magnetic objects such as magnetic cards as
the radiation waves of the mobile phone may
erase the information stored on floppy disks, pay
cards and credit cards.
Please keep small metal objects, such as
thumbtacks far away from the receiver. When the
receiver is in use it becomes magnetic and may
attract these small metal objects and thus these
may cause injury or damage the mobile phone.
Avoid having the mobile phone come into contact
with water or other liquids. If liquids enter the
phone, this could cause a short circuit, battery
leakage or other malfunction.
1.3.3 Notices when using the battery
The battery has a limited service life. The
remaining life gets shorter as the times of
charging increase. If the battery becomes feeble
even after the charging, this indicates the service
life is over and you have to use a new battery.
9
Do not dispose of old batteries with everyday
domestic garbage. Please dispose of old batteries
at the directed places with specific rules for their
disposal.
Please do not throw batteries into a fire, as this
will cause the batter to catch fire and explode.
When installing the battery, do not use force or
pressure, as this will cause the battery to leak,
overheat, crack and catch fire.
Please do not use wires, needles or other metal
objects to short-circuit the battery. Also, do not put
the battery near necklaces or other metal objects,
as this will cause the battery to leak, overheat,
crack and catch fire.
Please do not solder the contact points of the
battery, as this will cause the battery to leak,
overheat, crack and catch fire.
If the liquid in the batteries goes into the eyes,
there is a risk of blindness. If this occurs do not
rub the eyes, but immediately rinse eyes with
clear water and go to the hospital for treatment.
Please do not disassemble or modify the battery,
as this will cause the battery to leak, overheat,
crack and catch fire.
10
Please do not use or place the batteries near high
temperature places such as near a fire or heating
vessel, as this will cause the battery to leak,
overheat, crack and catch fire.
If the battery overheats, changes color, or
becomes distorted during use, charging, or
storage, please stop using and replace it with a
new battery.
If the liquid from the battery comes in contact with
skin or clothing this could cause burning of the
skin. Immediately use clear water to rinse and
seek medical tips if necessary.
If the battery leaks or gives off a strange odor,
please remove the battery from the vicinity of the
open fire to avoid a fire or explosion.
Please do no let the battery become wet as this
will cause the battery to overheat, smoke and
corrode.
Please do not use or place batteries in places of
high temperature such as in direct sunlight, as
this will cause the battery to leak and overheat,
lower performance, and shorten the battery’s life.
Please do not continuously charge for more than
24 hours.
11
1.3.4 Charging your phone
Connect the connector of charger to the mobile
phone. The battery level indicator flashes on the
screen. Even if the phone has been turned off, the
charging image still appears, indicating that the
battery is being charged. If the phone is overused
when the current is insufficient, it may take longer
time for the charging indicator to appear on the
screen after the charging begins.
When the battery level indicator does not flash
and indicates the battery is full, this indicates the
charging has been completed. If the phone is off
during charging, the charging being completed
image also appears on the screen. The charging
process often takes 3 to 4 hours. During the
charging, the battery, phone and charger gets
warm, this is a normal phenomenon.
Upon the completion of charging, disconnect the
charger from AC power socket, and from the
mobile phone.
Notes:
During charging, the phone must be placed in
well-ventilated environment of ＋5 ℃ ~ ＋40 . ℃
Always use the charger supplied by your phone
12
manufacturer. Using an unauthorized charger
might cause danger and invalidate the
authorization and warranty clauses for your
phone.
The standby time and call duration provided by
the manufacturer are based on ideal operating
environment. In practice, the battery's operating
time varies depending on network conditions,
operating environment and usage methods.
Make sure the battery has been installed before
charging. It is best not to remove the battery while
charging.
Upon completion of charging, disconnect the
charger from your phone and the power supply.
If you have not disconnected the charger from your phone and the power supply, the charger will continue to charge the battery after about 5 to 8 hours when the batter level decreases substantially. We advise you not to do like this, as it lowers your phone performance and shortens your phone life.
Notices when using your charger
Please use AC 220 volts. The use of any other
voltage will cause battery leakage, fire and cause
13
damage to the mobile phone and charger.
It is forbidden to short circuit the charger, as this
will cause electrical shock, smoking and damage
to the charger.
Please do no use the charger if the power cord is
damaged, as this will cause fire or electrical
shock.
Please immediately clean any dust gathered on
the electrical outlet.
Please do no place vessels with water near the
charger in order to avoid water splashing onto the
charger and causing an electrical shortage,
leakage or other malfunction.
If the charger comes in contact with water or other
liquid the power must immediately be switched off
to avoid an electrical short or shock, fire or
malfunction of the charger.
Please do not disassemble or modify the charger,
as it will lead to bodily harm, electrical shock, fire
or damage to the charger.
Please do not use the charger in the bathroom or
other excessively moist areas, as this will cause
electrical chock, fire or damage to the charger.
Please do not touch the charger with wet hands,
14
as this will cause electrical shock.
Do not modify or place heavy objects on the
power cord, as this will cause electrical shock or
fire.
Before cleaning or carrying out maintenance
please unplug the charger from the electrical
outlet.
When unplugging charger, do not pull on the cord,
but rather hold on to the body of the charger, as
pulling on the cord will damage the cord and lead
to electrical shock or fire.
1.3.5 Cleaning and maintenance
The mobile phone, battery, and charger are not
water resistant. Please do not use them in the
bathroom or other excessively moist areas and
likewise avoid allowing them to get wet in the rain.
Use a soft, dry cloth to clean the mobile phone,
battery and charger.
Please do not use alcohol, thinner, benzene or
other solvents to wipe the mobile phone.
A dirty outlet will cause poor electrical contact,
lose of power and even inability to recharge.
Please clean regularly.
15
2 Getting Started
2.1 Component name and explanation
2.1.1 Technical parameters
Handset
Model FIY MINI
Dimension 118.4x63x9.7 mm
Weight 80g
Lithium-ion battery
Model NYX1300A56X53
Nominal voltage 3.7v
Maximum charge voltage 4.2v
Capacity 1300MA
Standby duration 120H
Talk duration 5H
Travel charger
Model 50-60Hz 0.15A
Input AC90-264V
2.1.2 Icons
In the standby mode, the following icons may
appear in standby screen:
16
Icon Description
Indicate the intensity of network signals.
Show missed calls.
Location by satellite.
Receive a new message.
An application is being downloaded.
The downloading is over.
The alarm clock has been set and activated.
A call is in progress.
The phone is playing a song.
17
Show battery level.
Enable USB.
The access is blocked.
Get connected to the wireless network
Turn on the Bluetooth.
No SIM card is installed in the phone.
GPRS data connection is on.
18
2.2 Key explanations
Key Explanations
Power key ● Hold down this key to turn your
phone off and on.
● Generally, press this key to lock
the mobile phone.
Side volume
keys
● During the conversation, press
the two keys to adjust the volume.
● While playing an audio file,
press the two keys to adjust the
volume.
Return key
Home key
Menu key
●Return to the previous menu.
●At any status, press the key to
return to the standby screen.
●Show options of current menu.
Note: In this guide, the phrase “press the key”
refers to pressing and thereafter releasing a key.
“Hold down a key” refers to pressing a key and
keeping it depressed for 2 seconds or longer.
The descriptions and functions of keys
depend on the model of your phone.
19
2.3 Using the touchscreen
Your phone provides many touch keys in the Main
screen. To use these keys correctly, calibrate the
touch screen in advance (see “Calibrator”).
Meanwhile please follow the instructions:
■Do not touch the screen with wet hands.
■Do not touch the screen with great forces.
■Do not touch the screen with metallic or
conductive objects.
2.4 Connecting to the network
2.4.1 Inserting and removing the SIM card
Turn off the phone; remove the battery and
unplug other external power supplies. Insert the SIM card into the SIM holder as shown in the phone.
When you need to remove the SIM card, turn
off the phone, remove the battery and then
remove the SIM card from the holder.
Warning: Do turn off your phone before removing the SIM card. Never insert or remove the SIM card when an external power supply is connected,
as this may cause damage to the SIM card.
20
Loading...
+ 49 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
