S-917 USER MENU
Power supply Assembly
POWER BRKT
Fan Filter Assembly
Main list
12cm Fan
Side Plate Left
PSII type power
or Mini Redundant PSU
ITX board
internal 2.5" HDD
5.25" ODD x7
Front Controls & indicators
H.D.D LED
System power LED
Power switch
Reset Switch
USB port
Front control & Indicators
USB Port
M3 Screws flat head H=4mm
PSII power
6#32 Screws hex head H=6mm
2.5" Drive Bay Assembly
6#32 Screws hex head H=6mm
6#32 Screws hex head H=6mm
2.5" HDD
Mini Redundant PSU
5.25" Drive Bay Assembly
Filter 163X18X5
Panel
M3 Screws flat head H=4mm
525 Cover
Pedestal Foot-stand Assembly
Plastic Stand
6#32 Screws hex head H=6mm
Fan Assembly
12cm Fan
T5 Screws flat head H=10.5mm
M3 Screws round head H=4mm
Accessory List
Part Description
M3 Screw Round head H=4mm
6#32 Screw Hex head H=6mm
M3 Screw flat head H=4mm
Part No.
5.25" ODD x7
Q'ty
32
6
4
