INTRODUCTION
Thank you for your purchase of the ISP Technologies 300-watt (RMS) Vector
112! This new guitar subwoofer cabinet offers the same world-renowned
VECTOR active guitar subwoofer technology in a smaller, more lightweight
package. Inside is a 12" neo woofer with 300 watts (program) available to
deliver the thunderous low end that you can only find with the Vector subwoofer
system. The concept of the Vector 112 corresponds with the Vector SL guitar
subwoofer in terms of easy hook-up and user-friendly operation. Just plug in
and play. You can literally feel the power of the Vector 112's low-end shake your
bones and yet the highs for your external cabinet are high passed and remain
focused and accurate. Simply connect any combo amplifier and get ready to
hear all the low end you have been missing and the best part, you can add the
Vector 112 to your guitar rig at an amazing low price!
Please read this manual carefully for a through explanation of the Vector 112 and its
functions.
PRECAUTIONS
NOTE: IT IS VERY IMPORTANT THAT YOU READ THIS SECTION TO PROVIDE YEARS OF
TROUBLE FREE USE. THIS UNIT REQUIRES CAREFUL HANDELING.
All warnings on this equipment and in the operation instructions should be adhered to and all
operating instructions should be followed.
Do not use this equipment near water. Care should be taken so that objects do not fall onto and
liquids are not spilled into the unit through any openings.
The power cord should be unplugged from the outlet when the unit is left unused for a long
period of time.
DO NOT ATTEMPT TO SERVICE THIS EQUIPMENT. THIS EQUIPMENT SHOULD BE SERVICED BY
QUALIFIED SERVICE PERSONNELL ONLY. DO NOT MAKE ANY INTERNAL ADJUSTMENTS OR
ADDITIONS TO THIS EQUIPMENT AT ANY TIME. DO NOT TAMPER WITH INTERNAL
ELECTRONIC COMPONENTS AT ANY TIME. FAILURE TO FOLLOW THESE INSTRUCTIONS WILL
VOID THE WARRANTY OF THIS EQUIPMENT, AND MAY CAUSE A SHOCK HAZZARD.
POWER REQUIREMENTS
This unit requires connection to a 120-volt AC outlet. Do not cut or disconnect the ground pin
on the power cord. Do not attempt to connect this unit to any power source other than the
specified 120VAC. The Theta Combo will typically draw approximately three amps of current
when driving a 4-ohm load.
Rear Panel Description
1. INPUT JACK
Connect the speaker output of your guitar amplifier to this input jack. The
VECTOR 112 will internally attenuate the speaker output and apply this
signal to the input of the internal D-CAT amplifier to drive the subwoofer.
2. SUB LEVEL
The SUB LEVEL adjusts the output level of the VECTOR 112’s internal
subwoofer.
3. INPUT JACK
Connect the speaker output of your guitar amplifier to this input jack. The
VECTOR 112 will internally attenuate the speaker output and apply this
signal to the input of the internal D-CAT amplifier to drive the subwoofer.
4. EXTERNAL SPEAKER JACK
Connect your external speaker to this output jack.
5. IMPEDANCE SELECTOR SWITCH
Set this switch to the proper impedance of your external speaker
cabinet(s). This will apply the correct crossover point for the system.
6. POWER INLET CONNECTOR
Connect the IEC AC power cord to this connector.
D-CAT amplifier output power
D-CAT amplifier protection
Frequency Response
Fuse Slo Blo
Dimensions
Weight
Note:
This product covered under multiple
Patents Pending.
300watts RMS
Thermal shutdown, limiter protect
50Hz to 130Hz (-3 dB)
5 amp-120 volt / 3 amp-220 volt
29.9” W x 19.25” H x 14.1” D
60 lbs
FUSE REPLACEMENT
1. Use a small screwdriver as shown to slide the fuse
cover out from the power inlet module. The fuse can
be found inside the fuse cover module after it is
pulled out.
NOTE: A SMALL COMPARTMENT IS ALSO PROVIDED
WITHIN THE FUSE COVER MODULE FOR
STORING A SPARE FUSE.
2. After replacing the fuse with another of identical
specifications, push the fuse cover module fully back
into place, ensuring that the fuse has snapped onto
the fuse holder inside the power inlet module.
VECTOR 112 SPECIFICATIONS
WARRANTY AND SERVICE
The Internal Circuitry is fully guaranteed to be free of defects under normal use and service
for a period of three years from the date of purchase. The Speakers and Cabinet that are
used in this product are fully guaranteed to be free of defects under normal use and service
for a period of three years.
Any damage resulting from the misuse or the failure to follow the precautions and
instructions will void the warranty.
In the event that the unit needs to be repaired, please return the unit to ISP Technologies
directly. Simply repack the unit, send a copy of the original receipt, a note stating the
problem, and send it to:
ISP Technologies, LLC
5479 Perry Drive Unit B
Waterford, MI 48329
Attn: Repair Dept.
All shipping charges must be fully prepaid.
ISP will not be responsible for any damages incurred in shipping of any unit. Any claim will
need to be settled with the shipping company.
The warranty will be voided if the serial number has been tampered with in any way.
The warranty card must also be filled out and returned in order to activate the warranty.
Should you have any questions for the repair department prior to returning the product
please call 1-(248)-673-7790
NOTE: This Product may be covered under one or more of the following patents or patents
pending: 7,035,413; 6,944,305; 6,931,134; 6,831,514; 6,091,013
ISP TECHNOLOGIES, LLC
5479 PERRY DRIVE UNIT B
WATERFORD, MI. 48329
248-673-7790
FAX: 248-673-7696
www.isptechnologies.com
