Bluetooth Noise-Isolating Earbuds
User Manual
IT-01
2
Get started
Congratulations! Thank you for choosing ISOtunes PRO Bluetooth stereo headphone.
Before using ISOtunes PRO, users should read this manual to familiarize themselves with
the Bluetooth functions of your mobile phone or other devices.
Safety Rules
1, Please follow the rules depicted in this manual carefully to ensure your safety. Before
using this ISOtunes PRO, we would strongly encourage you to read through this user
manual.
2, Be more care of any edges, uneven surfaces, metal parts, accessories and packaging
to avoid any possibility of injury.
3, Do not dismantle, repair and modify product to avoid fire breaking, electric shocking
and product damaging completely, which are not covered under warranty.
4, Do not use any diluents or volatile liquid to clean the ISOtunes PRO.
5, Do not use the ISOtunes PRO in a hazardous location.
Features
1, Bluetooth 4.0+EDR
2, aptX® audio technology
3, IPX4 water-proof
3, Support connecting with 2 phones devices
4, iOS show the headphone battery power status
3
How to use
1, L&R orientation
2, Great sound performance is in selecting the right size eartip
3 ,General Function
Operation LED Status
Power on Blue LED flashes 2 times
Power off Red LED flashes 2 times
Pairing Red LED & Blue LED flashes alternately
Standby Blue LED flashes 3 times in 5 seconds
Incoming call Blue LED flashes continuous
Low battery Red LED flashes 2 times every 2 seconds
Charging Red LED keep lighting during charging
Blue LED keep lighting charging finished
4, Basic Buttons Operation
Power on: Press multifunction button for 2 seconds. Blue LED flashes 2 times.
Headphone turn on.
Power off: Press multifunction button for 3 seconds. Red LED turn off after flashes 2
times. Headphone turn off.
Volume adjust: Each press on 'Volume up' or ' Volume down' buttons, one level voice
volume changes. When volume reaches to Max or Minimum, "Tick" reminding voice
occurs.
Play/Pause: Short press multifunction button, music pause. Press it again, music
continues.
Previous: in standby status, Long press 2 seconds 'volume down' button, music turns to
previous one.
Next:: in standby status ,Long press 2 seconds '
Volume up’, music turns to next one.
Answer Call: Short press multifunction button to answer the phone call.
End call: Short press multifunction button, phone call ended.
Reject call: Press 'Volume up' button for 2 seconds to reject a call.
Transfer call: During the phone call conversation, press' Volume up 'button for 2
seconds, call switches to mobile phone. Press 'Volume up' button for 2 seconds again, call
switches to headphone.
Last number redial: in standby status, continuously press headphone multifunction
button twice to redial the last number.
Call Mute function: Press 'Volume down' button for 2 seconds, call mute. Press
'Volume down' button for 2 seconds again, call mute cancel.
4
Battery Capacity status: When headphone connects to iOS devices, iOS devices show
the headphone battery power status on the upper right corner.
Charging: New headphone has enough power for pairing and dialing out for several
times. When in low battery, please charging via USB cable for 2 hours. Red LED keep
lighting during charging, blue LED keep lighting charging finished.
Reset Mode: Connect the headphone to computer via Micro USB cable. When red LED
light flashes, headphone reset finished.
5, Pairing
Pairing with one phone or other device
Make sure the headphone is power off.
Press and hold the multifunctional button for 5 seconds to enter into the pairing mode.
Red LED & Blue LED flashes alternately, Activate your phone or device Bluetooth function
and search for headphone. From the list of found devices on your mobile phone , select
the headphone “ISOtunes PRO” to connect it. Follow the instruction to enter “0000” as PIN
if the mobile phone
reminder
to need. Headphone or device can be used to play your
phone music or dial phone call etc.
6, Sound quality with aptx® code
Featuring the apt-X codec, the headsets can connect wirelessly to any aptX® enabled
devices, vastly improves the quality of Bluetooth streaming, delivering CD-quality sound.
Kit Contents
1, 1 X Stereo Bluetooth headphone ISOtunes PRO
2, 1 X Charging Micro USB Cable
3, 1 X User Manual
Warning
1, You must choose a qualified charger from a regular manufacturer to charge the
headphone.
2, You must charge the headphone if it has not been used for more than 12 months.
Do not dispose of the battery in fire, as it may cause explosion.
5
Specification
Bluetooth version: 4.0+EDR
Talk time: 8h
Stand-by time: 240h
Music play time: 8h
Wireless range: 10m
Bluetooth profiles: A2DP/ AVRCP/ HSP /HFP
Impedance: 16Ω
Sound pressure level: 91±3dB
Frequency Response: 20Hz---20 KHz
6
FCC Information and Copyright
This equipment has been tested and found to comply with the limits for a Class B digital
device,pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates,uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment .The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restriction.
