EVO3 Solus Instruction Manual
November 2011
November 2011
Contents
The company A.1
The principles A.1
The execution A.1
Overview B.2
Features B.2
Safety B.3
Placement C.3
Equipment coupling C.3
System integration C.3
Fault finding D.4
Dimensions & sockets E.5
Cabling F.6
Third party products F.6
Upgrades F.6
G.7
A. Introduction
B. The product
C. Installation
D. Troubleshooting
E. Specifications
F. Considerations
G. Warranty
General section
November 2011
A. Introduction
IsoTek was formed in July 2001 with the vision to create high quality
mains power distribution units that moved beyond current
conventions. Through careful market analysis and extensive research
we were able to launch products that moved power distribution
forward to be recognised as an integral part of any audio or home
theatre system. Our products continue to lead the way in power
management systems, our latest GII range galvanises our commitment
to pursue excellence at every level.
We believe all products benefit from their own clean power supply,
therefore we advocated the concept of using (smaller) individual filters
on each component, with these being specifically designed for their
purpose, this dramatically reduces and stops component cross
contamination and dispels the belief that one size fits all. Every single
component used in our designs is extensively tested for quality,
reliability and purpose. Our circuit designs are extensively ‘field’ tested
before coming to market so we can guarantee the widest compatibility
with third party products.
Within the market of premium audio it is vital to offer exceptional
performance and value for money. Products must be made to the
highest of standards, be reliable and attractive. A manufacturer must
offer exceptional service, dealer training, support and undertake the
very best in promotion design and literature. If all these elements are in
place customers should experience excellence at every stage. Our
continual quest is to meet these challenges.
All of our products are professionally designed, manufactured and
hand built in the UK, with deep consideration given to both style,
functionality, performance and value for money.
The company
The principles
The execution
The company
Multi award winning mai ns power conditione rs
November 2011
B. The product
Thank you for purchasing our latest EVO3 Solus model. Solus is an
award winning 6-way power conditioner.
IsoTek has enhanced a number of key circuits to ensure the EVO3
Solus tackles both differential and common mode noise with even
greater effectiveness than the GII model it replaces. The sophisticated
delta filter network has been significantly improved, while newly
devised individual differential filtering is applied to each of the unit’s six
outputs, preventing cross-contamination between connected audio
components.
IsoTek’s proprietary K.E.R.P. and Polaris-X technologies are also
integrated into the design. K.E.R.P. (Kirchoff’s Equal Resistance Path)
equalises resistance across all outlets, thereby increasing the
effectiveness of the internal filter networks. Polaris-X ensures that the
electrons take the easiest route, thus reducing crosstalk and improving
component-from-component isolation. In addition to improved filtering,
the EVO3 Solus delivers greater protection against spikes and surges
in the mains supply, with 22,500A of instantaneous, repeatable
protection on tap. Equipment is connected at the rear of the unit via six
high quality outlets.
Ensure that good airflow can circulate through the unit. If you have to
locate the unit on the floor we strongly recommend you do not place
the unit near heat sources, such as radiators or air ducts.
Do not place the Solus on a soft surface, for example a rug or carpet,
which could block the ventilation intakes on the underside of the unit.
Do not let any liquids spill onto or objects fall into the chassis. Should
either of these events happen, immediately switch off the unit at the
wall socket, wait for at least one minute, unplug all other cables and
return it to your authorised IsoTek dealer for a full service.
Overview
Features
Front elevation of the unit
20Kg
!
Safety
November 2011
C. Installation
In the interest of safety the unit should be placed upon its own
dedicated shelf on an audio grade equipment rack. The unit may be
placed on top of or under other pieces of equipment, do not exceed a
maximum weight loading of 20kg. Do not place the Solus in areas
where the temperature is likely to exceed 25 degrees. For example,
close proximity to ‘tube’ amplifiers.
Once the Solus is placed connect the unit to a mains wall socket, we
recommend that a good quality cable is used and that the wall socket
is also unswitched. Turn off all equipment you wish to have a clean
mains supply, unplug the cables relating to these from the wall socket
or redundant distribution block you may have been using and plug
these into the rear sockets of the Solus.
We strongly recommend that a good quality mains cable is used and
this cable is consistent throughout your system. Look for a cable with
good conductors, for example oxygen free copper, this cable should
also have a high degree of shielding from RFI.
Placement
Equipment
coupling
System integration
Front & rear of the unit
IEC Inlet
6 high quality UK three pin outputs
Product name badge
LED indicator light
Official EVO3 badge
November 2011
D. Troubleshooting
The front panel LED is not lit and the unit gives no power.
Check that the mains inlet fuse is intact, this will be located in the
drawer of the IEC socket at the rear of the unit on the left hand
side. If there is not a fuse located or you have used up your supply
please contact us by email support@isoteksystems.com so that we
can forward you a free replacement.
Check that the mains cable is securely plugged into the unit and
the wall socket.
Check the fuse within the plug is intact.
On rare occasions the fuse at the main distribution fuse box may
also need to be checked.
Fault finding
Fuse location
Fuse holder of IEC inlet
Fuse in UK three pin plug
November 2011
E. Specifications
The following information relates only to the IsoTek EVO3 Solus.
Number of outlets: 6
Type of outlets: UK, EU, US, CH, AU, ZA
Standard mains inlet: IEC C14 fused
Mains voltage: 100 - 240VAC/50-60Hz
Maximum current: 10Amps HRC
Total wattage: 2300VA / 1100VA
External mains fuse 10Amps
Dimensions: 445mm x 95mm x 305mm (WxHxD)
Weight: 7.5Kg
Please note, the information given in this document is correct at the
time of print. Small production changes in the course of improvement
through our ongoing research and development policy may arise. If
clarification of any point is required please refer to your local
authorised IsoTek dealer or visit www.isoteksystems.com where you
can download the very latest information.
Dimensions
& sockets
Front & rear elevation
November 2011
F. Considerations
We strongly recommend that a good quality mains cable is used and
this cable is consistent throughout your system. Look for a cable with
good conductors, for example OFC (oxygen free copper). This cable
should also have a high degree of shielding from RFI. Outside of the
UK it is not uncommon for cables of 6Amps current capability to be
connected to a 20Amp outlet. In practice this seems to be a safe
arrangement. However we strongly recommend a cable of the full
20Amps carrying capability be used, with a minimum 1.5mm squared.
IsoTek produce their own cable in standard 1.5M lengths. All cables
feature high quality connectors, OFC conductors and fully earth
shielded. This removes any chance of RFI entering the cable. A
number of versions are available: Premire, Premium and Elite as well as
higher current Optimum and Extreme. IsoTek 24ct high grade
connectors are used in the Elite, Optimum designs these can also be
purchased individually.
Our GII & EVO3 range of products work well with all third party
equipment including varying cable technologies. If ‘off-the-shelf’ mains
cables are used we recommend the use of Ferrite rings to reduce RFI.
We also recommend the use of contact conditioners, for example Blue
Horizon’s Clean-IT (www.bluehorizonideas.com). Isolation devices, feet
and cones may also be used. We recommend Clearlight Audio RDC
products which we use on our higher end products, for example, Titan.
It is possible to increase the performance of the Solus through ideal
location and product placement, the use of isolation devices and
contact conditioners for example. The Solus can also be used to run
front-end only equipment with one of our dedicated power amplifier
products. For example, the introduction of a Titan for that specific
purpose. Full details can be found from your local authorised IsoTek
dealer or on our web site www.isoteksystems.com
Cabling
Third party
products
Upgrades
Product examples
IsoTek GII Titan
IsoTek Elite & Optimum Cables
November 2011
G. Warranty
Please complete & send
As part of our on-going commitment to the highest standards of customer service, IsoTek offers
you the opportunity to extend the standard 2 year product warranty to 3 years, free of charge.
Simply visit:
www.isoteksystems.com/register
And follow the on screen instructions. This service will automatically update your details and
give confirmation of your registration via email within 24 hours.
IsoTek will not share your personal details with any third parties without your permission.
If you do not have internet access then please forward a copy of your invoice, together with the
product serial number and your address to our UK office:
IsoTek Systems,
4 Mozzetta,
Kings Head Yard,
Winchester,
SO23 9HN
England.
