Isotech 4934, 4936 Operating Manual

User Maintenance Manual

HYPERION ADVANCED 4936

DRAGO ADVANCED 4934

Telephone: [phone] Fax: [phone] Email: [e-mail] Website: www.isotech.co.uk

Isothermal Technology Limited, Pine Grove, Southport, Merseyside, PR9 9AG, England

Hyperion – Drago (Advanced) 04-11/16

Guarantee

ⓒIsothermal Technology Limited

This instrument has been manufactured to exacting standards and is guaranteed for twelve
months against electrical break-down or mechanical failure caused through defective material or
workmanship, provided the failure is not the result of misuse.

In the event of failure covered by this guarantee, the instrument must be returned, carriage paid,
to the supplier for examination and will be replaced or repaired at our option.

FRAGILE CERAMIC AND/OR GLASS PARTS ARE NOT COVERED BY THIS GUARANTEE
INTERFERENCE WITH OR FAILURE TO PROPERLY MAINTAIN THIS INSTRUMENT MAY
INVALIDATE THIS GUARANTEE

The company is always willing to give technical advice and assistance where appropriate. Equally,
because of the programme of continual development and improvement we reserve the right to
amend or alter characteristics and design without prior notice. This publication is for information
only.

This handbook contains information that has been reproduced with the kind permission of
Eurotherm. Such data is subject to the following notice.

ⓒ2014 Eurotherm Limited

Eurotherm, the Eurotherm logo, Chessell, nanodac, and Itools, are trademarks of Invensys plc, its
subsidiaries and affiliates.

All rights are strictly reserved. No part of this document may be reproduced, modified or
transmitted in any form by any means, neither may it be stored in a retrieval system other than
for the purpose to act as an aid in operating the equipment to which the document relates, without
the prior written permission of Invensys Eurotherm Limited.

Eurotherm Limited pursues a policy of continuous development and product improvement. The
specifications in this document may therefore be changed without notice. The information in this
document is given in good faith, but is intended for guidance only.

Isothermal Technology Limited

Pine Grove, Southport, Merseyside, PR9 9AG, England

Telephone: [phone] / Fax: [phone]

Email: [e-mail] / Website: www.isotech.co.uk

2

Contents

1 UNPACKING AND INITIAL INSPECTION ........................................................................................ 6

2 BEFORE YOU USE THE EQUIPMENT ................................................................................................. 7

3 SUMMARY OF SYMBOLS ................................................................................................................... 8

4 ELECTRICITY SUPPLY ....................................................................................................................... 9

5 THE UNIT MUST BE EARTHED ................................................................................................ 10

6 EMC INFORMATION ................................................................................................................. 11

7 CAUTIONARY NOTE ................................................................................................................. 12

8 SAFETY WARNINGS ................................................................................................................ 13

8.1 ENVIRONMENTAL CONDITIONS ........................................................................................................................ 13

8.2 DO NOT MODIFY OR DISASSEMBLE ................................................................................................................. 13

8.3 BEWARE OF ELECTRICAL CONSIDERATIONS...................................................................................................... 13

8.4 BE CAREFUL WHERE IT IS USED ..................................................................................................................... 13

8.5 BE CAREFUL WITH EXTREMES OF TEMPERATURE .............................................................................................. 13

8.6 BE CAREFUL WITH INSERTS ........................................................................................................................... 13

8.7 BE CAREFUL WITH FLUIDS ............................................................................................................................. 14

9 CONSIDER THE ENVIRONMENT ..................................................................................................... 15

10 INTRODUCTION ............................................................................................................................. 16

10.1 COMPARISON CALIBRATION .......................................................................................................................... 16

10.2 BASIC OPERATION ....................................................................................................................................... 16

10.3 SITE OR SELF-CONTAINED CALIBRATORS ....................................................................................................... 16

10.4 EXTERNAL STANDARDS + BASIC ................................................................................................................... 17

10.5 ADVANCED CALIBRATORS .......................................................................................................................... 17

11 MODE OF OPERATION ................................................................................................................... 18

11.1 METAL BLOCK BATH .................................................................................................................................... 18

11.2 STIRRED LIQUID BATH ................................................................................................................................. 18

11.3 STIRRED ICE BATH - HYPERION MODEL ONLY ................................................................................................ 19

11.4 BLACK BODY SOURCE .................................................................................................................................. 19

11.5 SURFACE SENSOR CALIBRATION .................................................................................................................... 19

11.6 ITS-90 FIXED POINT CALIBRATION .............................................................................................................. 19

12 HOW TO MEASURE THE TRUE TEMPERATURE INSIDE THE ACCESSORIES SUPPLIED WITH

THE ISOCAL-6 ...................................................................................................................................... 20

12.1 THE CONTROLLER ....................................................................................................................................... 20

12.2 THE REFERENCE THERMOMETER ................................................................................................................... 20

12.3 THE INDUSTRIAL THERMOMETER .................................................................................................................. 20

13 OPERATION OF THE ADVANCED DRY BLOCK TEMPERATURE CALIBRATOR .......................... 21

13.1 A TOUR OF THE EQUIPMENT ........................................................................................................................ 21

13.2 THE USER INTERFACE START UP SCREEN AND CONTROLS .......................................................................... 22

13.3 THE ISOTECH HOMEPAGE .......................................................................................................................... 22

13.4 THE THERMOSTAT TESTING PAGE .......................................................................................................... 23

13.5 THE PROGRAM PAGE (NO ACTIVE PROGRAM) ............................................................................................. 23

13.6 THE PROGRAM PAGE (ACTIVE PROGRAM RUNNING)..................................................................................... 23

13.7 THE USER ACCESS PAGE........................................................................................................................... 24

3

14 GETTING STARTED ........................................................................................................................ 25

14.1 CHANGING THE SET POINT .......................................................................................................................... 25

15 USING THE ADVANCED FEATURES OF THIS EQUIPMENT ........................................................ 26

15.1 TO SET FROM THE FRONT PANEL ................................................................................................................. 26

15.1.1 Operator Access

15.1.2 Supervisor Access (in addition to the above functions)

15.1.3 Engineer Access

15.2 HOW TO LOG IN AS THE SUPERVISOR ...................................................................................................... 27

15.3 HOW TO LOG IN AS THE ENGINEER ........................................................................................................... 27

15.4 HOW TO CHANGE INPUT SENSOR ON CHANNELS 1, 2 AND 3 .......................................................................... 28

15.5 HOW TO GLOBALLY CHANGE FROM °C TO °F OR KELVIN

15.6 HOW TO GLOBALLY CHANGE FROM °C TO °F OR KELVIN

15.7 THERMOSTAT TESTING USING THE ADVANCED UNIT ..................................................................................... 29

15.8 ENABLING THE AUTOTUNE FEATURE .......................................................................................................... 30

15.9 USING THE SETPOINT TRIM FEATURE FOR OFFSET ELIMINATION ................................................................. 30

15.10 HOW TO CHANGE THE DATE AND TIME OR THE LANGUAGE OF THE ADVANCED EQUIPMENT ............................ 31

15.11 THERMOMETER INPUT CHANNELS ................................................................................................................ 31

15.12 PROCESS TO APPLY A USER CALIBRATION TO THE CONTROLLER USING A PRT CONNECTED TO CHANNEL 1 ......... 32

15.13 THE NETWORK INTERFACE .................................................................................................................. 33

15.14 TO ACCESS THE NETWORK INTERFACE .................................................................................................. 33

15.15 THE WEB BROWSER .............................................................................................................................. 33

15.16 DATA LOGGING ......................................................................................................................................... 34

15.17 FTP SERVER ARCHIVING ............................................................................................................................ 35

15.18 PROGRAMMER FUNCTION ........................................................................................................................... 35

15.19 PROGRAM DETAILS .................................................................................................................................... 36

15.19.1 Operation

15.19.2 Status

............................................................................................................................................. 36

15.19.3 Program

15.19.4 Holdback Style

15.19.5 Program

15.19.6 Ch1 Holdback

15.19.7 Ch1 Holdback value

15.19.8 Ch2 Holdback

15.19.9 Ch2 Holdback value

15.19.10 Ramp Style

15.19.11 Time

............................................................................................................................................. 37

15.19.12 Ch1 Ramp Units

15.19.13 Ch2 Ramp Units

15.20 HOW TO CREATE A SIMPLE PROGRAM USING THE CONTROLLER INTERFACE ................................................... 38

15.21 TO ENABLE/RUN THIS PROGRAM ............................................................................................................. 39

15.22 TO EDIT AN EXISTING PROGRAM .............................................................................................................. 39

15.23 USING THE HOLDBACK FEATURE .............................................................................................................. 39

.............................................................................................................................. 26

............................................................... 26

............................................................................................................................... 26

(FIRMWARE VERSION A5.40 BEFORE NOVEMBER 2016)
(FIRMWARE VERSION A5.43 AFTER NOVEMBER 2016)

....................................................................................................................................... 36

......................................................................................................................................... 36

............................................................................................................................... 36

......................................................................................................................................... 36

................................................................................................................................. 37

....................................................................................................................... 37

................................................................................................................................. 37

....................................................................................................................... 37

................................................................................................................................... 37

........................................................................................................................... 37

........................................................................................................................... 37

. 29

... 29

16 CONNECTING TEMPERATURE SENSORS ..................................................................................... 41

16.1 PLATINUM RESISTANCE THERMOMETERS, PRTS ............................................................................................. 41

16.2 INPUT CONNECTIONS ................................................................................................................................... 41

16.3 CONNECTING THERMOCOUPLES .................................................................................................................... 41

16.4 CONNECTING 4 – 20MA CURRENT TRANSMITTERS ......................................................................................... 42

16.4.1 Using the Current Loop Interface (935-06-161)

16.4.2 Altering Channel 1 setting to read in mA

16.4.3 Altering Channel 1 setting to read in °C

17 SPECIFICATION ............................................................................................................................. 44

18 CONNECTING TO A PC ................................................................................................................... 45

........................................................................................ 43

........................................................................... 42

...................................................................................... 42

4

18.1 ISOTECH CONFIG UTILITY ............................................................................................................................ 45

18.2 ISOTECH I-CAL EASY ..................................................................................................................................46

18.3 PROGRAM EDITOR .......................................................................................................................................46

18.4 REVIEW ...................................................................................................................................................... 47

19 ACCESSORIES ................................................................................................................................. 48

5

1 Unpacking And Initial Inspection

Our Packing Department uses custom designed packaging to send out your unit, but as accidents
can still happen in transit, you are advised, after unpacking the unit, to inspect it for any sign of
shipping damage and confirm that your delivery is in accordance with the packing check list. If
you find any damage or that part of the delivery is missing notify us or our agent and the carrier
immediately. If the unit is damaged you should keep the packing for possible insurance
assessment.

6

2 Before You Use The Equipment

Please read the handbook and familiarise yourself with all warnings, hazards and safety
information. Regularly inspect the equipment, accessories and electrical leads. Do not use if there
is any sign of damage. Keep the equipment clean, only use a damp cloth. Do not use solvents or
allows liquids to enter the case.

7

3 Summary of Symbols

ISO3864 – Caution, read the entire manual before use

IEC 417 – Caution, hot surface (risk of burn)

O

Off l On

Waste Electrical and Electronic Equipment (WEEE directive) symbol
Complies with European regulations (CE mark)

USB symbol

Ethernet RJ45 symbol

Risk of Electrical Shock

8

4 Electricity Supply

Before connecting to the electricity supply please familiarise yourself with the parts of the manual
relevant to your model.

Your unit's supply voltage requirement is specified on a label on the instrument along with the
serial number. Only connect to a power supply matching the requirement stated on the equipment.

9

5 The Unit Must Be Earthed

Colour

Function

Green/Yellow

Earth (Ground)

Brown

Live (line)

Blue

Neutral

This equipment is a Class 1 Appliance and must be earthed (grounded). Use the supplied power
cord and plug it directly into an AC outlet with a protective earth.

If using an alternative cord ensure it is of adequate rating.

If fitting a plug to the cable we have supplied the cable is colour coded as follows:

Do not use the equipment if it is not correctly earthed. If in doubt consult Isothermal Technology
Ltd or a qualified electrician.

10

6 EMC Information

This product meets the requirements of the European Directive on Electromagnetic Compatibility
(EMC) 89/336/EEC as amended by EC Directive 92/31/EEC and the European Low Voltage
Directive 73/25/EEC, amended by 93/68/EEC. To ensure emission compliance please ensure that
connecting leads are fully screened.

The product meets the susceptibility requirements of EN 50082-1, criterion B.

11

7 Cautionary Note

Operators of this equipment should be adequately trained in the handling of hot and cold items.
It is important the user has been trained about the selection and use of liquids over a wide
temperature range. It is expected that personnel using this equipment will be competent with the
management of apparatus which may be powered or under extremes of temperature and are able
to appreciate the hazards which may be associated with and the precautions to be taken with,
such equipment.

12

8 Safety Warnings

8.1 Environmental Conditions

 Operating temperature: 5-40°C (41-122°F)
 Relative Humidity: 5-80% - Non-condensing

8.2 Do Not Modify Or Disassemble

 Do not use the apparatus for jobs other than those for which it was designed, i.e. the

calibration of thermometers

 There are no user serviceable parts inside. Do not dismantle or modify the apparatus. For

repair information contact Isothermal Technology Ltd

 For equipment with fans, the fan should kept free from dust build up; a soft brush or

vacuum cleaner may be used on the external grill

8.3 Beware Of Electrical Considerations

 The equipment is for installation category II (transient voltages) and pollution degree

II in accordance with IEC 664 at altitudes to 2000 metres

 Sensor Input Connection must never exceed 30V with reference to ground
 Thermostat test inputs should be voltage free: isolate from any voltage source during test

8.4 Be Careful Where It Is Used

 The equipment is not for use in hazardous areas or in an environment close to flammable

materials or gases

 The equipment must be used on a flat level surface, with adequate space around it for air

flow and avoid blocking ventilation slots

 Ensure free space above the unit to avoid risk of burn or fire
 The equipment should only be used indoors
 Site in a way that allows access to the power switch, and to allow the cable to be

disconnected

 Avoid excessive heat, humidity, dust and vibration ensuring it will not be subjected to

dripping or splashing liquids

8.5 Be Careful With Extremes Of Temperature

 In normal use the calibration volume, inserts and probes will become very hot and present

a burn hazard

 Do not remove inserts, probes or handle the equipment when it is hot or cold.
 Allow the equipment and accessories to reach a temperature between ambient and 70°C

before switching off or storing the equipment in its case

 Do not use the equipment outside its recommended temperature range
 Operating the equipment at extremes of temperature for extended periods may call for

early replacement of the heating assembly

 Wear appropriate protective clothing

8.6 Be Careful With Inserts

 Only use inserts supplied with, or ordered specifically for, this model
 Do not handle inserts while they are very hot or cold
 Inserts for low temperature models may melt and cause a fire if used in high temperature

models

 Only use Isotech inserts which are specially treated to avoid them from becoming stuck in

the calibration volume

 Do not use powders, liquids or compounds in the insert; this may lead to the insert or

probes becoming stuck

13

8.7 Be Careful With Fluids

 Isocal-6 models can be used as liquid baths; the Hyperion and Drago models can have the

liquid directly in the block or the liquid container. For all other models do not add liquid
directly to the block; you must place the liquid in the appropriate Isotech liquid container
kit.

 To avoid risk of toxic fumes or ignition only use the appropriate fluid and be careful not to

exceed the stated temperature range

 Do not handle hot fluids
 Wear appropriate eye protection and be careful to avoid spills, overspills or splashing
 Do not overfill - liquids will expand on heating, allow room for expansion
 Be careful to select an appropriate liquid – viscous liquids will offer poor thermal

performance.

 Never mix fluids and keep containers clean and dry before introducing a new fluid
 Do not use oils below the dew point. Water introduced into oil can present a hazard at

higher temperatures due to steam generation

 Ensure adequate ventilation of any liquid fumes

14

9 Consider The Environment

The equipment should be recycled or disposed of in a proper way; following the Waste
Electrical and Electronic Equipment (WEEE) directive

15

10 Introduction

The Isocal-6 range of products allows unprecedented flexibility for the calibration of temperature
sensors. The Isocal-6 range may be used with the following options:

1. As a Metal Block Bath

2. As a Stirred Liquid Bath (not Drago)

3. A Blackbody Source

4. A Surface Sensor Calibrator

5. An ITS-90 Fixed Point Apparatus

10.1 Comparison Calibration

By definition, one compares industrial thermometers to a calibrated standard. There are three
methods commonly used.

10.2 Basic Operation

Using the controller as the “calibrated standard”. This method means that the

complete bath is calibrated by comparing the controller reading to a calibrated
standard placed in the bath.

This is a common method but is unsafe since the control sensor is

a) inaccessible
b) in the wrong place to give correct temperature of the insert

For these reasons it fails to satisfy ISO9000 and gives large uncertainties.

10.3 Site or Self-Contained Calibrators

In these an indicator and external calibrated sensor are used to measure
the temperature of the insert. This arrangement gives good results and
traceability. To recalibrate however it does mean sending the whole
calibrator back to the calibration laboratory. The calibrator is self­contained, self-sufficient and meets ISO9000 requirements.

16

10.4 External Standards + Basic

Here a separate indicator and calibrated sensor
are used to measure the inserts temperature.
With a suitable indicator such as the Isotech
milliK this gives the most accurate and reliable
results, depending on the indicator.

It means that the calibrator does not need
calibrating; only the indicator and its calibrated
sensor need re-calibration. One indicator may
be used with a range of blocks. This method
also meets ISO9000 requirements.

10.5 ADVANCED Calibrators

The ADVANCED model includes an indicator with channels for both
the test thermometers and an external calibrated sensor used to
measure the temperature of the insert. This allows best practice
calibration with established traceability and uncertainty. To
recalibrate however it does mean sending the whole calibrator back
to the calibration laboratory. The calibrator is self-contained for
reference and test probes, self-sufficient and meets ISO9000
requirements.

17

11 Mode Of Operation

11.1 Metal Block Bath

The metal block bath function of the Isocal-6 is well suited for fast, convenient,
mess free calibration of temperature sensors.

The Isocal-6 metal insert is placed into the calibration well. The stir speed control
should be set to the OFF position (turn fully anti-clockwise).

The thermometers under test are placed into suitable holes in metal. For the
ADVANCED and Site models a calibrated reference probe should be placed into
the insert and the actual temperature can be read from the unit’s display. For the
Basic models an external temperature indicator should be used.

For traceable calibration the actual value of the insert temperature should be
recorded along with the values from the sensors under test.

11.2 Stirred Liquid Bath

The stirred liquid bath function of the Isocal-6 is well suited for odd shaped sensors
which will not easily be accommodated in a metal insert.

Liquid baths have the added benefit of potential for greater accuracy due to better
temperature uniformity and the avoidance of air gaps.

The liquid can be placed directly into the block. Take care not to spill any liquid
and remove the mains power connector during filling. Placing the liquid directly
into the block will provide the fastest response time and best agreement between
the temperature of the oil and that indicated on the temperature controller. Take
care not to overfill and allow room for the liquid to expand as it is heated. The
maximum depth should be approximately 150mm.

Liquid containers can be used and will be particularly useful when more than one
liquid type is to be used. Using one container for each liquid permits rapid mess free change of
fluid.

The Isocal-6 Liquid Container is placed into the calibration well and the container is filled with a
suitable liquid, for the temperature range that the bath is to be used over. The container should
be filled to 40mm from the top of the tank. Care must be taken to adjust the level as the liquid
contracts or expands with temperature changes. The stirrer speed control is set ON and to the
mid position. If necessary the speed to can be adjusted to give the optimum value for a particular
application, this position should be found experimentally and then noted for future use.

The thermometers under test are placed into the liquid. Two accessories are available to support
the thermometers.

a) The Thermometer Support - this sits into either the calibration volume or the liquid

container. The thermometers rest against the suspended lower plate.

b) An optional cap is available which grips the thermometers; suspending them into the

liquid. The cap has two diameters and can be fitted to the block or to the liquid container.

18

It is important that one of the accessories is used to prevent the probes from reaching the bottom
of the tank which would stop the stirring action. For the ADVANCED and Site models a calibrated
reference probe should be placed into the liquid and the actual temperature can be read from the
unit’s display. For the Basic models an external temperature indicator should be used. For
traceable calibration the actual value of the liquid temperature should be recorded along with the
values from the sensors under test.

11.3 Stirred Ice Bath - Hyperion Model Only

The Stirred Ice Bath function is as the Stirred Liquid Bath. The liquid container is filled with water,
the stirrer speed control set to mid-position and the controller set to 0.0°C. Once the controller
has stabilized at 0.0°C allow 10-15 minutes before starting calibration.

11.4 Black Body Source

The black body function of the Isocal-6 is well suited for fast, convenient,
mess free calibration of infra-red temperature sensors.

The Isocal-6 black body target is placed into the calibration well. The stir
speed control should be set to the OFF position.

The units under test should be aligned with the target.

For the S models a calibrated reference probe should be placed into the
hole in the block and the actual temperature can be read from the
temperature indicator to which the infrared thermometer(s) are
compared. For the B models and external temperature indicator should be
used.

11.5 Surface Sensor Calibration

The surface sensor function of the Isocal-6 is well suited for fast, convenient,
mess free calibration of most surface temperature sensors.

The Isocal-6 surface sensor insert is placed into the calibration well. The stir
speed control should be set to the OFF position.

A calibrated probe s placed in the pocket of the surface sensor insert and
connected to the temperature indicator of the S models. For the B models an
external indicator should be used. Surface sensors are placed on top of the
insert and when stable compared to the calibrated probe.

11.6 ITS-90 Fixed Point Calibration

The ITS-90 fixed point function of the Isocal-6 is well suited for fast, convenient, mess free
calibration of thermometers to uncertainties as low at 0.001°C.

The special cell is placed into the Isocal-6 calibration well. The stir speed control should be set to
the OFF position. For detailed operating information, refer to the separate manual provided with
the cell

19

12 How To Measure The True Temperature Inside The Accessories

Supplied With The Isocal-6

The controller of the Isocal-6 controls and reads the temperature of the block surrounding the
35mm∅ by 160mm deep calibration well.

There are various accessories including the surface calibration insert, the oil container, blackbody
etc. These adapt the Isocal-6 to perform varied calibration functions.

None of these accessories actually get to the block temperature (and hence the controller’s
temperature) because each accessory has a different immersion characteristic. For this reason the
Isocal-6, like all comparison baths, requires a reference thermometer to indicate the true
temperature inside the accessory.

Remember the following:-

12.1 The Controller

The controller is used to set a constant temperature and create an isothermal environment for the
comparison calibration of temperature sensors.

12.2 The Reference Thermometer

The reference thermometer is placed in the accessory or insert and measures the true temperature
inside the insert or accessory.

12.3 The Industrial Thermometer

The industrial thermometer is placed in the accessory or insert and is compared to the true
temperature as indicated by the reference thermometer. An insert will typically have a 1%
immersion error. For more details see - Depths of Immersion. Tavener J. P – available at
http://www.isotech.co.uk

20

13 Operation Of The ADVANCED Dry Block Temperature Calibrator

13.1 A Tour Of The Equipment

Figure 1: Main Input and Output for the
ADVANCED equipment

1. Main supply voltage connection socket
This socket allow the Mains Voltage to be
applied to power up the equipment. Use only
the supplied lead or a suitably specified IEC
alternative. Confirm the supply voltage using
the ratings label on the rear of the
equipment.

2. Power On/Off switch
Once the Power lead is connected, this switch
will power up and down the equipment

3. Fuse carrier and window showing fuse

rating
With the mains cable disconnected, the fuse

carrier can be removed for the inspection or
replacement of the fuse. The fuse rating is
displayed through the window.

4. Channels 1 and 2 PRT input sockets
These allow for the connection of external
Platinum resistance thermometers. Warning
– Do not connect any other form of input to
these sockets.

5. Channels 1,2 and 3 Thermocouple input sockets
These allow for the connection of a range of Thermocouples to be connected. Warning – Do
not connect any other form of input to these sockets.

6. USB socket
This allows for the connection of a USB memory stick or the connection of a USB keyboard.

Please see relevant note at the end of this section.

7. Full colour graphical user interface display
¼ VGA crystal clear, IP66 wash-down display

8. Magnetic stirrer speed adjuster
Manual adjustment of the Magnetic stirring speed.

9. Thermostatic testing input sockets channels 1 and 2
Allows for two thermostats to be connected simultaneously to verify opening or closing
temperatures.

21

10.Ethernet (RJ45) socket
This allows for the connection of the equipment to either a PC for direct connection or to a
network to allow network access.

11.Dry block/Liquid bath volume
This is actual heat source of the ADVANCED unit. This may be either a Liquid bath or Dry
Block

Note: Precautions against electrostatic discharge should be taken when the
instrument terminals are being accessed. The USB and Ethernet connections are
particularly vulnerable.

When using a USB extension cable, a high quality screened cable must be used. The
total length of USB cable between the device and the USB port must not exceed 3
metres (10 ft.)

13.2 The USER INTERFACE Start Up

Screen And Controls

Figure 2

1. ISOTECH splashscreen

2. PAGE button

3. SCROLL button

4. DOWN button

5. UP button

13.3 The ISOTECH Homepage

Figure 3

1. Channel 1 display value

2. Channel 2 display value

3. RECORD icon

4. Product identifier

5. Block temperature (Process Variable)

6. Set temperature (Working Set Point)

7. Channel 3 display value

8. Setpoint adjust

22

13.4 The THERMOSTAT TESTING Page

Figure 4

1. THERMOSTAT 1 freeze temperature

2. THERMOSTAT 1 freeze temperature

3. SENSE value 1 (Normally Open/Closed)

4. SENSE value 2 (Normally Open/Closed)

5. REFERENCE channel temperature display

13.5 The PROGRAM Page (No Active Program)

Figure 5

1. Current program NAME/STATUS

2. MODE display

3. Program Edit beacon

4. Block temperature (Process Variable)

5. Program Setpoint

6. Program STATUS

13.6 The PROGRAM Page (Active Program Running)

Figure 6

1. Program status (running)

2. Segment type

3. Program progress

4. Segment time remaining

5. Program time remaining

6. Segment progress

23

13.7 The USER ACCESS Page

Figure 7

1. Channel 1 input type – read only

2. Channel 2 input type – read only

3. Channel 3 input type – read only

4. Channel 1 minus Channel 2 – read only

5. Channel 1 minus Channel 3 – read only

6. IP Type (fixed or dynamic (DHCP)) –

read only

7. Setpoint Trim enable/disable – writeable

8. Autotune - writeable

24

14 Getting Started

To operate this equipment, place on a suitable surface and visually inspect for any damage, since
either last use, or from transit. Assuming all is well, place the supplied insert or liquid container
in the well at the rear of the equipment.

Using the supplied mains lead, insert into the Main supply voltage connection socket (figure
1, item 1). Ensure the voltage supply and rating of the equipment comply and plug the lead into
the supply.

Press the Power On/Off switch (figure 1, item 2) to power up the equipment. The display will
now illuminate and display the ISOTECH splashscreen (figure 2). The white progress bar at the
bottom of the screen will scroll across the screen showing progress. Normally in the region of 45
seconds.

When the screen has booted up, the home page will be as
figure 3. The equipment will now heat or cool to the last set
point indicated as figure 3, item 7.

To assist in getting started there are some tutorial videos
online at http://www.isotech.co.uk/advanced

14.1 Changing The Set Point

To change the setpoint of the equipment on the ADVANCED
unit:

1. From the ISOTECH homepage, press the SCROLL button once, this will highlight the

SETPOINT ADJUST box.

2. Press the SCROLL button once more and this will allow adjustment of the setpoint via the

UP/DOWN buttons.

3. Scroll to the desired set point as described above.

4. When the temperature is set, press the SCROLL button again to enter and save the setting.

5. The equipment will now raise or lower the block temperature as required.

25

15 Using The ADVANCED Features Of This Equipment

The User interface allows for the alteration of certain aspects of the control and indication system.
Examples would be the ability to change the sensor type on any of the Input channels or to change
the resolution of the Channel temperature. This configuration can be set from a PC using the
Isotech Config Utility – see “Connecting to a PC" or from the front panel.

15.1 To Set From The Front Panel

To do this, the user will need to log in to different levels of access using the controller menu
system.

There are three levels of access:

1. Operator Access

2. Supervisor Access

3. Engineer Access

Typical levels of adjustment are outlined below for each level.

15.1.1 Operator Access

 Scroll the home pages to allow readable access to controller function
 Change the set point of the bath
 Change the Sense status of the Freeze display
 Enable the Autotune
 Enable the set point trim function

15.1.2 Supervisor Access (in addition to the above functions)

 Program selection for the program function
 Thermometer calibration data entry for Channels 1, 2 and 3

15.1.3 Engineer Access

 Change sensor type for channels 1, 2 and 3
 Change resolution for channels 1, 2 and 3
 Change language selection
 Change °C to °F or K

26

15.2 How To Log In As The SUPERVISOR

Figure 8

Figure 9

Figure 10

Figure 11

1. Press the Page button to display the Home menu (figure 8)

2. Scroll to LOG IN

3. Press the SCROLL button

4. Press up to scroll to SUPERVISOR in dialogue box

5. Press the SCROLL button to prompt for a passcode

6. Select code 15 from the soft keyboard

7. Press PAGE button to prompt to accept the changes

8. Select Yes and enter with SCROLL button to display the SUPERVISOR screen (figure 9)

9. When logged in as the SUPERVISOR the equipment will control in the normal way

15.3 How To Log In As The ENGINEER

1. Press the Page button to display the Home menu (figure 10)

2. Scroll to LOG IN

3. Press the SCROLL button

4. Press up to scroll to ENGINEER in dialogue box

5. Press the SCROLL button to prompt for a passcode

6. Select code 17 from the soft keyboard

7. Press PAGE button to prompt to accept the changes

8. Select Yes and enter with SCROLL button to display the ENGINEER screen (figure 11)

9. When logged in as the ENGINEER, the equipment will not control the temperature of the

heat source

27

15.4 How To Change Input Sensor On Channels 1, 2 And 3

Input sensors can be user defined using the menu system to change to PT100, a range of
thermocouple types, Ohms or Voltage. To change sensor type follow the procedure below:

1. Log in as the ENGINEER

2. Scroll to CHANNEL

3. Select the desired channel for alteration

4. Press the SCROLL button to enter

5. Scroll to MAIN

6. The MAIN Sub Menu will now be displayed

To configure for a PT100:

1. Scroll to TYPE and press SCROLL to enter

2. Press UP to scroll to RTD, press the SCROLL button to enter

3. Scroll to RESOLUTION and press SCROLL to enter

4. Press up to select the Resolution required, press SCROLL to enter

5. Scroll to LIN TYPE and press SCROLL to enter

6. Select PT100 from the list and press SCROLL to enter

7. Ensure RANGE HIGH is set to 800

8. Press the PAGE button until the ENGINEER screen is displayed, scroll to LOG OUT and

enter with the SCROLL button

To configure for a Thermocouple:

1. Scroll to TYPE and press SCROLL to enter

2. Press UP to scroll to THERMOCOUPLE, press the SCROLL button to enter

3. Scroll to RESOLUTION and press SCROLL to enter

4. Press up to select the Resolution required, press SCROLL to enter

5. Scroll to LIN TYPE and press SCROLL to enter

6. Select required thermocouple type from the list and press SCROLL to enter

7. Ensure RANGE HIGH is set to 1200

8. Press the PAGE button until the ENGINEER screen is displayed, scroll to LOG OUT and

enter with the SCROLL button

Important Note: The COLD JUNCTION on Channels 1, 2 and 3 should ALWAYS be set
to CJTypeRemCh3. This value should not ever be changed. Doing so will disable the
cold junction compensation for Channels 1, 2 and 3.

Channel 3 input type should ALWAYS be set to TC+RTD, the thermocouple type can
selected from lower done in the menu.

28

15.5 How to globally change from °C to °F or Kelvin

A5.40 before November 2016)

1. Log in as the ENGINEER above

2. Select the Channel required for adjustment

3. Select Main from the channel options

4. Scroll down to RANGE UNITS

5. Enter using SCROLL button and select required units

6. Enter value using SCROLL button

7. Press the PAGE button until the ENGINEER screen is displayed, scroll to LOG OUT and

enter with the SCROLL button

Note: Channel 4 is reserved for the control sensor and as such is disabled from user
access.

15.6 How to globally change from °C to °F or Kelvin

A5.43 after November 2016)

1. Log in as the ENGINEER

2. Scroll to INSTRUMENT

3. Scroll to DISPLAY

4. Scroll to UNITS

5. Select by pressing the SCROLL button

6. Use up/down to select from °C, °F or Kelvin

7. Press the PAGE button to exit and save the selection

Note: Channel 4 is reserved for the control sensor and as such is disabled from user
access.

(firmware version

(firmware version

15.7 Thermostat testing using the ADVANCED unit

The ADVANCED equipment has the facility to test thermostats or thermal switches using the page
featured in figure 4. Up to two thermostats can be tested at the same time.

The system uses Channel 1 as a reference channel to record the temperature of the thermostat
opening or closing. To use this feature, there must be a thermometer connected to Channel 1.

The sense of the thermostat can be changed by the user and each thermostat is referred to as
“FREEZE 1” and “FREEZE 2”. The options are Normally open (N/O) or Normally closed (N/C).

The thermostat is connected via the 2mm input sockets on the controller plate (item 9, figure 1).

You are not required to log in to access this feature.

How to change the SENSE value on the FREEZE display:

1. Scroll to the FREEZE display page

2. Highlight SENSE 1 by pressing the SCROLL button

3. Press the SCROLL button again to access the value and adjust using the up/down buttons

4. Enter the value by pressing the SCROLL button again

5. To adjust SENSE 2, scroll the it at point 2 and adjust as above

Note: if there is no sensor connected to Channel 1 the FREEZE display will return an
“ERROR” message.

29

15.8 Enabling The AUTOTUNE Feature

Note: This feature is available on all ADVANCED equipment except PEGASUS.

The ADVANCED equipment has the ability to AUTOTUNE the control parameters to hone the
temperature stability at a specific block temperature. When enabled it will allow the controller to
cycle the temperature of the block and calculate the best values for this temperature. After two
cycles it will install the calculated values and use these for the control loop.

You are not required to log in to access this feature.

To enable the AUTOTUNE feature:

1. Scroll to the USER ACCESS page

2. Press the Scroll button and then select the AUTOTUNE feature using the down button

3. Press the Scroll button again to highlight the feature

4. Use the up/down button to select ON

5. Press the Scroll button again to enter the value.

6. The controller will now begin the tuning process

During the tuning process, AT can now be seen to the left of the clock on the ISOTECH homepage
(figure 3).

To disable the tuning feature during a tune, repeat the process above and select OFF. This will
now disable the tune and install the previous values.

15.9 Using the SETPOINT TRIM feature for Offset Elimination

This ADVANCED equipment has the facility to adjust the heat source temperature to a value
determined by Channel1 temperature sensor (only Channel 1 will function with this feature).
This allows the user to more accurately bring the block temperature closer to the reference
temperature without making any manual adjustments. This value will automatically adjust every
30 minutes and will not adjust to any value outside of ±5°C of the control sensor value. This will
prevent overheating in the event of a sensor failure of the sensor being accidently removed from
the heat source. In this event the equipment will disable the feature and control in normal mode.

You are not required to log in to access this feature.

To enable the SETPOINT TRIM feature:

1. Ensure a reference sensor is connected to channel 1 and fully immersed into the heat

source

2. Scroll to the USER ACCESS page and scroll down to the SETPOINT TRIM box

3. Press the Scroll button to highlight the feature

4. Press the up/down button to change the value to INPUT 2

5. Enter this with the Scroll button

6. Exit by pressing the PAGE button and scroll to the homepage

The display may change by the difference between the reference temperature and the control
sensor value. This is normal and should not be adjusted.

To exit SETPOINT TRIM mode repeat the process above and enter INPUT 1 and the controller will
now function in normal mode.

30

15.10 How to change the Date and Time or the Language of the

ADVANCED equipment

The Date and time of the ADVANCED equipment can be changed to suit local time. This can also
incorporate the any daylight saving time in the time zone of your country or region. The display
language of some of the display screens can also be change to suit the local language.

The options for this are:

 English
 French
 German
 Italian
 Spanish

Note: Only the Supervisor and Engineer menus will read in the alternative language. The Isotech
Home screen will still read in English when this feature is used.

To change the DATE and TIME or LANGUAGE:

 To access these features you will need to log in as the Engineer.
 When logged in, scroll to the INSTRUMENT tab on the Engineer homepage
 Press the SCROLL button to enter
 Scroll to CLOCK and enter by pressing SCROLL button
 Alternatively scroll to LOCALE and enter by pressing SCROLL button
 Adjust as necessary and exit engineer mode

15.11 Thermometer Input Channels

The ADVANCED equipment has three temperature sensor input channels that can be used for
either a Platinum Resistance Thermometer or a Thermocouple. Channels 1 and 2 can accept
either of these sensors or Channel 3 can accept a Thermocouple.

The thermocouple input connectors used on all three channels have internal cold junction
compensation. This means that the thermocouple can plug directly into the Copper connector
and the controller will automatically compensate for the cold junction of the thermocouple. Ensure
the thermocouple has no additional cold junction as this will introduce errors.

Each of these channels can accept up to eight correction points to improve the linearity of the
thermometer accuracy to the Controller display. These are user defined and are unique to only
one thermometer.

When using the calibration feature, the points must be used in ascending order, that is to say, the
lowest point (Point 1) must be used at the lowest temperature. Each point for the calibration is
based on two values: the temperature at which the value is applied (the point) and the value to
adjust the temperature by (the offset). The factory default setting for each unused channel is
Point -200 and Offset 0.00. This means that if the calibration is enabled then the controller will
ignore these values until they are populated with real values.

The feature functions in the same way irrespective of sensor type.

31

The calibration (CAL STATUS) has several settings listed below:

POINTS 1-8: The specific values that are entered to calibrate the thermometer to the controller

ON: Enables the calibration and allows the adjustment of the populated points to function

OFF: Disables the calibration and the channel runs unadjusted

RESET: Erases all existing data for all points (Care must be taken with this as this is not reversible)

15.12 Process to apply a User Calibration to the controller using a PRT

connected to Channel 1

1. Connect the thermometer to Channel 1 and ensure the channel is correctly configured

using the processes above

2. Ensure the thermometer is correctly inserted to heat source of the ADVANCED equipment

3. Ensure the Calibrated Reference thermometer is placed in the same heat source

4. Allow the system the thermally stabilise

5. Press the PAGE button to enter the SUPERVISOR menu

6. Scroll to the CHANNELS tab and enter with the SCROLL button

7. Select 1 from the list and enter with the SCROLL button

8. Scroll to the ISOTECH tab and enter with the SCROLL button

9. Scroll to CAL STATUS and enter with the SCROLL button

10. Scroll to POINT 1 and enter

The controller is now ready to accept a value. Ensure the equipment is thermally stable, you will
now need to use the temperature value displayed by the Calibrated reference thermometer.

11. Record the value on the Calibrated thermometer and scroll to DISPLAY VALUE tab and

press enter

12. This will bring up a soft keyboard, use this keyboard to enter the exact temperature

displayed by the calibrated standard

13. Press the PAGE button to enter the value, the controller will ask you to confirm the settings.

Select YES and enter the value

14. The controller will now accept the value and move to POINT 2 on the display

15. Exit back to the homepage and check the value on the CHANNEL 1 display window

16. When confirmed, move to the next temperature and repeat the process for point 2 and so

on

This process is the same for all three channels.

32

15.13 The NETWORK INTERFACE

Access to the NETWORK interface is available when logged in as the ENGINEER. This will allow
adjustment to various network parameters, should they need to be adjusted.

This menu allows writeable access to:

 IP type (FIXED or DYNAMIC (DHCP))
 IP address
 Subnet Mask
 Gateway

and Read only access to:

 MAC address
 Client identifier

15.14 To access the NETWORK INTERFACE

1. Log in as the ENGINEER

2. From the ENGINEER page scroll to NETWORK tab and enter with the SCROLL button

3. Scroll to INTERFACE and enter with the scroll button

4. Scroll to and adjust desired parameter using the pop out soft keyboard

Note: Do not use network cable in excess of 10 metres length.

Use this section in conjunction with CONNECTING TO A PC. This provides details of the
available software and download details.

15.15 The WEB BROWSER

The ADVANCED equipment has a built in WEB BROWSER that enables access to the equipment
either via a local network or over the Internet.

The browser homepage

To open the browser simply open the supported browser (below) and in the address bar type the
IP address (see NETWORK INTERFACE) in the format http://XXX.XXX.XXX.XXX

33

Supported Browsers:

• Google Chrome V22.0 or greater

• Google Mobile Chrome (Android Mobile technology running ‘Ice cream sandwich’ or

greater

• Internet Explorer V9.0 or greater

• Mobile Safari (Apple Mobile technology running IOS 5.0 or greater)

All files are uploaded from the ADVANCED device to the browser, where all JS and JQuery
files are executed locally.

Browsers should be configured to allow cookies, and support for file caching should
also be enabled. If cookies are not enabled this will have the following detrimental
effects:

• Any web page configuration changes ‘saved’ by the user in the client browser will not be

retained when navigating between web pages

• For the most efficient browsing make sure that caching is enabled in the browser being

used.

• Web server supports standard ASCII character set. Any non-displayable characters will,

therefore, be replaced by an asterisk ‘*’.

The clickable links will allow you to:

 View any active channels via the TRENDING link (including the control sensor)
 View any messages or alarm details via the SUMMARY link
 View individual channels via the settings button in the TRENDING link

Note: The browser is not available when the equipment is in ENGINEERING mode
(logged in as the engineer).

15.16 Data Logging

The ADVANCED equipment will always record data for all four channels UNLESS the equipment is
in ENGINEERING mode. This is indicated by the green R in the bottom left had side of the

ISOTECH homepage (figure 3).

The data can either be extracted via the USB socket on the front panel or to a PC by means of
the FTP protocol (Remote Archiving) using REVIEW software.

To back up the data via USB stick on the control panel use the following procedure:

1. Log in as the SUPERVISOR

2. Plug a suitable USB memory stick (8GB maximum) to the socket on the control panel

(figure 1, item 6)

3. Ensure the controller has accepted the memory stick by the icon in the lower left of the

ISOTECH homepage (figure 3)

4. Press the page button to scroll to the SUPERVISOR menu

5. Scroll to DEMAND ARCHIVING

6. Scroll to ARCHIVE TO and enter, select USB from the options and enter

7. Scroll to ARCHIVE and select from:
a. Bring to date

34

b. All
c. Last month
d. Last week
e. Last day
f. Last hour
g. None

8. When the selection is entered by pressing the SCROLL button, the transfer will begin (this

may take several minutes depending on the selection made)

9. When the transfer is complete, remove the USB stick and exit SUPERVISOR mode

The data will be stored in a folder called HISTORY.

15.17 FTP Server Archiving

This allows the archiving of recorder files to a remote computer via the RJ45 type connector at
the rear of the recorder, either directly or via a network.

In order to carry out a successful transfer:

1. Details of the remote host must be entered in the Network Archive area of configuration

2. The remote computer must be set up as an FTP server. Help from the user’s IT department

may be necessary in order to achieve this.

3. The remote computer must also be set up to respond to ‘pings’. This is because the

instrument pings the host whilst establishing connection, if it does not receive a response
the archive attempt fails.

4. When accessing files using Microsoft® Internet Explorer, the address (URL) field can be

in one of two for-mats:

5. ftp://<instrument IP address>. This allows a user to log in as the anonymous user (if the

recorder has any account with the user name set to ‘anonymous’ with a blank password.

6. ftp://<user name>:<password>@<instrument IP address> to log in as a specific user.

For IE5 users, Microsoft® Internet Explorer displays, by default, history files only. To quit the

history folder, either uncheck the Tools/Internet Options/Advanced/Browsing/’Enable folder view
for FTP sites’ option, or check the Tools/Internet Options/Advanced/Browsing/’Use Web based
FTP’ option.

15.18 Programmer Function

The ADVANCED equipment has an on-board PROGRAMMER function built in. The PROGRAMMER
runs in SEGMENTS and can store up to 100 programs, each containing 25 segments.

This feature is particularly useful for an automated calibration run, the test data can then be
extracted and converted to a spreadsheet using the REVIEW software available.

The programs can either be created using the available software, or using the control interface
on the ADVANCED equipment.

The software can be downloaded at www.isotech.co.uk/downloads. Once created, a program can
be sent directly to the instrument via the network connection or saved to a USB memory stick and
imported from there via the USB socket on the controller panel (Fig1, item6).

35

Instructions and details of installation are supplied with the download.

Note: Channel 2 is disabled on this instrument. Details in the following text appear
for information only.

To create, install and run a PROGRAM via the controller interface please follow the
instructions below:

See below for a more detailed description of each of the PROGRAM functions.

15.19 Program Details

15.19.1 Operation

This allows the user to select one of the following:

Load. Opens the program store and allows the user to select a program to be loaded.

Store. Allows the current program to be saved to the internal program drive. This is useful if

you wish to snapshot the current program and store this under a different program name.

Delete. Allows the selected program to be deleted.

Delete All. Deletes all programs.

Copy. Copies the selected program for ‘pasting’ either from the internal drive to the USB device,

or vice-versa. This is useful if you wish to transfer a program to other ADVANCED instruments.

Copy All. As above, for ‘Copy’, but copies all the programs in the selected directory.

Note: If a ‘Store’, ‘Copy’ or ‘Copy All’ operation would result in there being a total of
more than 100 program files in the internal drive, the operation fails and an error
message is displayed.

15.19.2 Status

Success: Previous operation was successful.
Failed: Previous operation failed.
Loading: The program is loading.
Copying: The program copy process is underway.
Deleting: The relevant program is being deleted.

15.19.3 Program

The name of the program currently loaded.

15.19.4 Holdback Style

Appears only if ‘Holdback’ is enabled. See ‘Holdback’, below.

15.19.5 Program

Holdback applies to all appropriate segments.

Per Segment: Holdback enabled on a segment by segment basis as described in ‘Segment

configuration below.

36

15.19.6 Ch1 Holdback

Appears only if ‘Holdback Style’ (above) is set to ‘Program’.
Off: Holdback is disabled
Low: Holdback is entered when PV < (PSP - Holdback Value)
High: Holdback is entered when PV > (PSP + Holdback Value)
Band: Holdback is entered when PV < (PSP - Holdback Value) or PV > (PSP + Holdback
Value)

15.19.7 Ch1 Holdback value

The value to be used in triggering holdback.

15.19.8 Ch2 Holdback

As for Ch1 Holdback, above but for channel 2.

15.19.9 Ch2 Holdback value

As for ‘Ch1 Holdback value’, above, but for channel 2.

15.19.10 Ramp Style

Ramp style applies to all ramp segments in the program. Ramp Style can be edited only when
the program is in Reset mode. Setpoints, rates, times etc. are set in the individual segment
configurations
Rate. A Ramp Rate segment is specified by a target set-point and the rate at which to
ascend/descend to that set-point.

15.19.11 Time

A Ramp Time segment is specified by a target set-point and a time in which to achieve that set­point.

15.19.12 Ch1 Ramp Units

Select ‘Per Second’, ‘Per Minute’ or ‘Per Hour’ for ramp timing units. Ramp Units can be edited

only when the program is in Reset mode.

15.19.13 Ch2 Ramp Units

As for ‘Ch1 Ramp Units’ above.

37

15.20 How to create a simple PROGRAM using the controller interface

Below shows a basic PROGRAM that demonstrates the ADVANCED instrument ability to create a
program.

Figure 12

This PROGRAM has 7 segments and these segments are saved as TEST_1 in the memory of the
ADVANCED equipment.

It shows the ADVANCED instrument starting with a setpoint of 0.00°C

 It is then set to RAMP to 150°C over a period of 120 minutes
 It is then set to DWELL at this temperature for a period of 120 minutes
 It is then set to RAMP to 300°C over a period of 120 minutes
 It is then set to DWELL at this temperature for a period of 120 minutes
 It is then set to RAMP to 450°C over a period of 120 minutes
 It is then set to DWELL at this temperature for a period of 120 minutes
 It is then set to END and RESET to 0.00°C

38

15.21 To enable/RUN this PROGRAM

1. Log in as the SUPERVISOR and exit menu

2. Scroll to the PROGRAM page (figure 5)

3. Press the SCROLL button to highlight the RESET box

4. Press the UP button to highlight the PAGE icon in the top right hand side of the screen

5. Enter this with the SCROLL button

6. This will access the PROGRAM EDIT menu page

7. Scroll to OPERATION and select LOAD, enter with the SCROLL button

8. Scroll to TEST_1 and enter with the SCROLL button

9. The STATUS will display SUCCESS and the CURRENT PROGRAM will display TEST_1

10. TEST_1 is now the default program

11. To RUN the program TEST_1 exit the PROGRAM EDIT page using the PAGE button until

you see the PROGRAM homepage

12. Press SCROLL once to highlight the RESET box

13. Scroll to TEST_1 and press the SCROLL button to initiate the program

The page will now change to show the current program running, as Fig6 above.

15.22 To edit an existing PROGRAM

1. Follow the above procedure to point 10

2. Scroll down to SEGMENT NUMBER and select the SEGMENT you wish to edit using the

SCROLL and UP/DOWN buttons

3. Edit the required parameter (RAMP, DWELL, TIME DURATION etc) using the scroll and

UP/DOWN buttons and enter the value

4. When the editing is complete, it can either be left as the existing PROGRAM or saved under

an alternative file name in the internal memory

5. To leave the alterations under the existing filename simply exit out of the menu and RUN

the program as normal

6. To save as an alternative filename in the memory, SCROLL back up to OPERATION and

enter using the SCROLL button

7. Scroll to STORE and enter

8. The soft keyboard will open allowing you to save the file as a filename of your choice

9. When the name is selected, press the PAGE button to save the changes

10. Both the original file and the modified file will now exist in the memory

15.23 Using the HOLDBACK feature

The PROGRAMMER has a HOLDBACK feature available.

Holdback pauses the program (freezes the Programmer setpoint (PSP) and the time remaining
parameters) if the difference between the Process value (PV) and the PSP exceeds a user-specified
amount (Holdback value). The program remains paused until the PV returns to within the specified
deviation.

In ramp or step segments, holdback indicates that the PV is lagging the SP by more than the
specified amount and that the program is waiting for the process to catch up. In a dwell segment,
holdback is used to guarantee that a work piece stays at set-point within a specified tolerance for
the specified dwell duration.

39

This is particularly useful when running a calibration program as it will allow the heat source to
eliminate any “lag” between the controller and the heat source itself.

Holdback can be configured to hold either the segment or the complete program.

The USER defined value is used to define the actual value applied to it.

This can either be:

LOW, where the heat source temperature is below the Setpoint. The programmer will hold the
value until the heat source has “caught-up” in temperature.

HIGH, where the heat source temperature is above the Setpoint. The programmer will hold the
value until the heat source has “caught-up” in temperature.

BAND, where the heat source is outside a band of temperature around the setpoint

To enable this feature

1. Go to EDIT AN EXISTING PROGRAM and enter the menu

2. Scroll to HOLDBACK STYLE and enter using the SCROLL button

3. Select desired parameter and enter using the SCROLL button

4. Scroll to CH1 HOLDBACK and enter the desired parameter and enter with the SCROLL

button

5. Scroll to CH1 HOLDBACK VAL and select the desired temperature, enter using the SCROLL

button

40

16 Connecting Temperature Sensors

16.1 Platinum Resistance Thermometers, PRTs

Set the input type to suit from either the front panel of the Isotech Config Software utility.

PRTs can be connected to Inputs P1 and P2. When connecting a PRT ensure the corresponding
thermocouple input is not used, that is if connecting a PRT to Input P1 then Input T1 must not be
used, is if connecting a PRT to Input P2 then Input T2 must not be used.

16.2 Input Connections

The five pin cable plug to suit PRTs is part number 935-16-107. These are readily available,
suppliers include RS Components (Part Number 129-8573) and Farnell (Part Number 112-2585).

With three wire PRT connections ensure identical lead resistance in all three legs of the connection
by using the same length and gauge of cables.

16.3 Connecting Thermocouples

Set the input type to suit from either the front panel of the Isotech Config Software utility.

Thermocouples can be connected to Inputs T1, T2 and T3. When connecting a thermocouple
ensure the corresponding PRT input is not used, that is if connecting a thermocouple to Input T1
then Input P1 must not be used, is if connecting a thermocouple to Input T2 then Input P2 must
not be used.

Input connectors are the industry standard “miniature thermocouple plugs”.

41

16.4 Connecting 4 – 20mA Current Transmitters

16.4.1 Using the Current Loop Interface (935-06-161)

This accessory makes it simple to connect and power 4-20mA Transmitters. It includes a 24V DC
Power Supply and a 2.49Ω shunt resistor, connected between 0VC and the central connector.

Set the input type to suit from either the front panel of the Isotech Config Software utility.

Connect the current loop interface either Inputs T1 or T2 when connecting ensure the
corresponding PRT input is not used, that is if connecting to Input T1 then Input P1 must not be
used, is if connecting to Input T2 then Input P2 must not be used.

Connect with the supplied low thermal EMF connecting lead.

16.4.2 Altering Channel 1 setting to read in mA

 Log in as the engineer and access channel 1 settings as detailed in the manual.
 Scroll to MAIN and change the sensor type to mA.
 Scroll to RESOLUTION and alter the resolution to your requirement.
 Log out.

42

16.4.3 Altering Channel 1 setting to read in °C

The channel can also be configured to read in true temperature as well. Please see below for
example settings

A Pt100 is used to measure a temperature range of 0 to 100°C. This thermometer output is
transmitted to the channel by a 4 to 20mA transmitter, for display as a value of temperature.

In Channel 1, set the following for the relevant channel:

 Type = mA
 Units = °C
 Input Low = 4.00
 Input High = 20.00
 Shunt = 2.49 ohms (this is a fixed value for the Current Loop Adapter)
 Lin Type = Pt100
 Range Low = 0
 Range High = 100
 Range Units = °C
 Scale Low = 0
 Scale High = 100

Other items may be left at their defaults.

43

17 Specification

Model

Parameter

Hyperion 4936

Drago 4934

Temperature Range

-25°C to 140°C1

30°C to 250°C2

Stability – Dry Block / Liquid Bath

±0.005°C

±0.005°C

Display Resolution

0.001°C over whole range

0.001°C over whole range

Input Channel Accuracy:
Thermocouple

E, J, K, N: ±0.2°C at 660°C, R: ±0.6°C, S: ±0.7°C at

660°C, T: ±0.2°C at 150°C

CJC Accuracy

±0.35°C

Input Channel Accuracy: RTD

±0.05°C±0.005% RDG

Stability

Blackbody ±0.3°C, Surface Sensor ±0.5°C, ITS-90 Cells

±0.0005°C

Display Accuracy

3

0.15°C

Uniformity - Radial, Liquid Bath Mode

<0.009°C

<0.007°C

Uniformity - Axial, Liquid Bath Mode
(40mm)

<0.011°C

<0.013°C

Uniformity - Radial, Dry Block Mode
(Between Wells)

<0.008°C

Uniformity - Axial, Dry Block Mode
(40mm)

<0.040°C

Heating Time

-20°C to 140°C: 40 Mins

30°C to 250°C: 40 Mins

Cooling Time

140°C to 20°C: 90 Mins

20°C to -25°C: 80 Mins

250°C to 30°C: 90 Mins

Insert Size

65 x 160mm

Insert Types

Standard 8 x 8mm + 2 x 4.5mm, Undrilled or Custom

Drilled

Power

115 or 230Vac 50/60Hz

200 Watts

115 or 230Vac 50/60Hz

1000 Watts

Dimensions

384H (including handle) x 212W x 312Dmm

Weight

12kg

8kg

(1) In ambient of 20°C: Minimum Temperature is 45°C Below Ambient, Absolute Minimum -35°C
(2) In ambient of 20°C
(3) Dry Block Mode only: Comparing 4.5mm Well to Controller Display Value

44

18 Connecting to a PC

There are several software applications that can be used with the ADVANCED models

18.1 Isotech Config Utility

This application makes it easy to adjust and set the various options such as sensor input types,
units, resolution etc.

45

18.2 Isotech I-Cal EASY

This application allows logging of data from the ADVANCED model. Additionally if a license is
purchased it allows for fully automatic calibration including certificate printing and the calculation
of coefficients.

Refer to the Isotech I-Cal EASY handbook and help system for more details

18.3 Program Editor

This allows set point programs to be created on a PC and uploaded to the ADVANCED model

Installation instructions are included with the download

46

18.4 Review

This is a proprietary software package which allows the user to extract ‘archive’ data from one or

more ADVANCED Dry Blocks and to present this data on a host computer, as if on a chart, or as
a spreadsheet.

As described in the Review help system, ‘Review’ allows the user to set up a regular transfer of
data (using ftp) from connected instruments into a database on the pc, and then from this
database to the chart or spreadsheet. The chart/spreadsheet can be configured to include one
or more ‘channels’ from one or all connected instruments.

It is also possible to archive instrument history files to a memory stick and to use this to transfer
the data to the pc.

The user name and password are both ‘history and they are not editable.

These applications can be downloaded from the Isotech website

http://www.isotech.co.uk/downloads

Connection to the unit is via the Ethernet interface, configure the IP address to suit your network
and then select that IP address in the software. Consult your network manager for assistance if
required.

47

19 Accessories

Dry Block Use

Standard Dry Block Insert

8 x 8mm; 2 x 4.5mm and 157mm deep

936-06-01a
Blank Dry Block Insert

936-06-01b

Liquid Bath Use

Stirred Liquid Container Kit

936-06-02

Support Kit Assembly for up to 8 thermometers

936-06-08

Magnetic Followers (Pack of 5)

932-12-74

Blackbody Use

Black Body Target Kit

936-06-03

Surface Sensor Use

Surface Sensor Calibrator Kit

936-06-04

ITS-90 Fixed Points

Slim Gallium Cell

17401M

Slim Water Triple Point Cell

B8 Probes

Standard Probe

935-14-61/DB

Current Loop Interface

935-06-161

Carrying Case

935-14-112

48
