THE BASICS

Home Button

Jump to the Home Menu

Tune/Track Down Button

Media control Previous, Back, Seek

Press & hold function in select sources

Multifunction Knob

Press & Hold to Power On/Off

Turn to adjust Volume Up/Down

Press once to Mute

4

StingerElectronics.com StingerElectronics.com

Tune/Track Up Button

Media control Next, Forward, Seek
Press & hold function in select sources

Voice Button

Launches voice control

5

GETTING STARTED

Device Status

MENU / BACK

Customizable

Source Tabs

Information Bar

Home Menu

SELECTING A SOURCE

To select a SOURCE that is not

Source InfoTime

Dimming/Mute

Reset

located on the Source Tabs, touch
MENU on the Information Bar, or
press the HOME button to access the
HOME MENU.

The HOME MENU displays all Sources,
along with Settings, Audio, Display
and Camera options.

SOURCES that are not currently
available are grayed out.

POWER UP!

With vehicle ignition in the ON or
ACC position, Press and Hold the
Mulifunction Knob.

The source will automatically default
to the last source used prior to
powering down.

You can adjust the audio volume at
start-up in MENU > AUDIO > VOLUME

> Start Volume Mode

The Information Bar is located at the
top of the screen. Depending on the
SOURCE, it will provide information
or content sensitive controls. Also
contains the MENU/BACK button,
time display, paired phone signal
and battery info, mute and dimming
functions.

6

StingerElectronics.com StingerElectronics.com

The Source Tabs are located across
the bottom of the screen and give you
direct access to common sources. Five
of the Tabs are customizable in MENU >

SETTINGS > Tabs

NOTE!

The BT MUSIC and PHONE Tabs will
be highlighted Blue if a phone is
paired and connected,

If the display becomes unresponsive,
you can reset the unit by pressing
the Reset Button with a paper clip
or similiar. Vehicle ignition should be
ON when resetting.

QUICK TIP

There are multiple ways to scroll...

Up/Down Arrows, MultiFunction Knob

and Swiping Up/Down

SETTING THE TIME

1) Touch and release the Time
Display on the Information Bar to
access the clock settings.

2) Set the time and format.

3) Touch the BACK/RETURN Arrow to

.....save and exit.









1

3

2

7

AM/FM RADIO BT PHONE

4

3

65 7

8
9

2

1

Touch the AM/FM Tab or MENU

1 1

> Radio to select the Radio

source. Pressing the AM/FM Tab
repeatedly will cycle through FM1­FM2-FM3-AM1-AM2

Preset Stations - A total of 18 FM

2 2

and 12 AM stations can be stored
in memory. To assign a preset, go
to desired station, press and hold a
preset location until preset button
highlights and station frequency
appears.

Tune/Seek Down - Press and

3

release to Tune Down. Press and
hold to Seek the next available
radio station.

Preset Bank Number - Displays

4

current set of presets (FM1-FM2­FM3-AM1-AM2).

Station Display - Displays current

5

frequency.

ST Indicator - Indicates when

6

current radio station is in Stereo.

DX/LOC - changes the radio

7

tuner sensitivity. Touch to toggle
between Distant (DX) and Local
(LOC).

Auto Preset - Touch to

8

automatically set the 6 presets
with current location radio
stations.

Tune/Seek Up - Press and release

9

to Tune Up. Press and hold to
Seek the next available radio
station.

6

5

Touch the Phone Tab or press the
HOME BUTTON > Phone to select

the Phone source. Pressing the
Phone Tab repeatedly will cycle
through the Phone options.

Number Pad - Touch to launch
the number pad for dialing phone
numbers.

Switch - Switches phone calls

3

between the car speakers and the
phone handset.

Clear - Clear/delete last number

4

entered.

Call Button - Dials the number

5

entered on the phone or on the
number pad. Answers incoming
call.

7 8 9

1234

End - Press to end call.

6

Phone Name - Displays the name

7

of the currently paired phone.

Favorite - Customizable list of

8

favorite contacts.

Contacts - List of contacts from

9

paired phone. Not supported by
all phones.

Settings - List of devices and

10

settings. Add or Delete devices.

Call Log - Recent Dialed,

11

Received and Missed calls.

10

11

8

StingerElectronics.com StingerElectronics.com

9

BT PHONE

BT PHONE

Pairing a Device

1) Select Settings from the Phone

...main menu to go to Device/Setup.

2) Select Add on the Device page.
Place your device in Discoverable

Mode.

3) Select your device from the list.
Select Connect to initiate pairing

4) Select Pair when prompted

NOTE!

If your device does not appear

in the device list, conrm it is

discoverable and select Retry

Setup Tab

Once your device is paired and
connected, you can select the
Setup Tab in the Settings.

Auto Connect (On/Off): Set to
ON if you want your phone to
automatically connect when the
system is turned on.

Setup Tab

Contacts

While your phone is paired, you
may access your contacts by
selecting Contacts. It may take
several minutes to load all your
contacts.
When you select a contact from
the list, all associated numbers will
be displayed on the left side of
the screen. Touch the number you
want to dial.

To Search your contact list, select
the magnifying glass icon on the
Information Bar.

To Add a contact number to your
Favorite list, just touch the star next
to the contact phone number and
it will be added to your Favorite list.

Call Log

The Call Log lists recently Dialed,
Received and Missed calls. Touch
the contact or phone number to
call back.

Search Contacts

Pin Code: Change the pin code for
Bluetooth connection. The default
pin code is "1234"

Microphone Gain (0-6): Adjusts the
volume of your voice when using
using hands free phone.

10

StingerElectronics.com StingerElectronics.com

NOTE!

The BT MUSIC and PHONE Tabs will
be highlighted Blue if a phone is
paired and connected,

11

BT MUSIC

4

3

®

SiriusXM

Only SiriusXM® brings you more of what you love to listen to, all in one place. Get
over 140 channels, including commercial-free music plus the best sports, news,
talk, comedy and entertainment. Welcome to the world of satellite radio.
A SiriusXM Vehicle Tuner and Subscription are required.
For more information, visit www.siriusxm.com

Activating your SiriusXM Subscription

5

12

After installing your SiriusXM Connect Vehicle Tuner and antenna, power on your
radio and select SiriusXM mode. You should be able to hear the SiriusXM preview
channel on Channel 1. If you cannot hear the preview channel, please check the
installation instructions to make sure your SiriusXM Connect tuner is properly installed.

After you can hear the preview channel, tune to Channel 0 to nd the Radio ID of

your tuner. In addition, the Radio ID is located on the bottom of the SiriusXM Connect
Vehicle Tuner and its packaging. You will need this number to activate
your subscription. Write the number down for reference.

Satelite Radio

(OPTIONAL)

Touch the BT Music Tab or press the

1

HOME BUTTON > BT Music to select

Bluetooth audio streaming.

Play/Pause - Touch to play or

2

pause the audio.

Previous Track/Program - Touch

3

once to restart current track, touch
again for Previous track.

Song/Program Information -

4

Displays information for the current
track.

Next Track/Program - Touch

5

to advance to the Next track/
Program.

12

StingerElectronics.com StingerElectronics.com

Note: the SiriusXM Radio ID does not include the letters I, O, S or F.
In the USA, you can activate online or by calling SiriusXM Listener care:

•Visit www.siriusxm.com/activatenow

•Call SiriusXM Listener Care at 1- 866- 635- 2349

For Canadian Subscriptions, please contact:

• Visit www.siriusxm.ca/activatexm

• Call XM customer Care at 1- 877- 438- 9677

As part of the activation process, the SiriusXM satellites will send an activation
message to your tuner. When your radio detects that the tuner has received the
activation message, your radio will display: Subscription Updated. Once subscribed,
you can tune to channels in your subscription plan. Note, the activation process
usually takes 10 to 15 minutes, but may take up to an hour. Your radio will need to be
powered on and receiving the SiriusXM signal to receive the activation message.

13

SiriusXM Satelite Radio SiriusXM Satelite Radio

3 4 7 8 95 6

Touch the SXM Tab or press the

1

HOME BUTTON > SiriusXM to select

the optional SiriusXM Satellite
Radio source. Pressing the SXM
Tab repeatedly will cycle through
the SiriusXM preset banks (SXM1­SXM2-SXM3).

SXM Info - Displays preset bank

2

number, channel number and
category.

Channel Down- Touch to go to

3

previous channel.

Channel Up- Touch to advance

4

to next channel.

CH - Touch to display a list of

5

available Channels with channel
information.

10 11

12

12

CAT - Touch to display a list of

6

channel Categories.

Preset/Channel View - Toggles

7

the display between Presets and
Channel/Song View.

Rewind/Track Down - Move

8

backwards through stored audio

Pause/Play - Pause live

9

broadcast / Play stored audio

Fast Forward/Track Up- Move

10

forward through stored audio

LIVE- Select to return to live

11

broadcast when listening to
stored audio.

Channel/Song Info- Displays

12

song info and channel name.

Info Button

Channels [CH]

Displays a list of availble SiriusXM
channels. Touching Info will provide
additional information on what is
currently playing on each channel
(Artist, Song, Content Info).

Signal Strength

Categories [CAT]

Displays a list of channel categories.
When a category is selected, a list
of matching channels will display.
Selecting All Channels will display all
channels in numerical order.

Preset Channels

A total of 18 SiriusXM channels can
be stored in memory. To cycle
through the preset banks, press the
SXM Tab repeatedly.

To assign a preset, go to desired
channel, touch and hold a preset
location until preset button highlights
and channel name appears.

To reset the presets back to original
settings: Go t o MENU > Settings > Load
Defaults * The reset process takes
3-4 minutes and will reset ALL saved
settings to Factory Default

14

StingerElectronics.com StingerElectronics.com

15

SiriusXM Satelite Radio

SiriusXM Satelite Radio

Direct Tuning

If you know the channel number you
want, you can touch the Numeric
Keypad Icon on the Information
Bar and enter the channel number
directly. (See Page 17 for Parental
Control function).

SiriusXM Replay™

Replay allows you to pause, rewind
and replay up to 1 hour of live
SiriusXM Satellite Radio.

Pressing Pause or Rewind while
listening to a live broadcast will
enable Replay mode.

Replay Controls

Touch for Previous Song
Touch & Hold for Rewind

Play
Pause
Touch for Next Song

Touch & Hold for Fast Forward

When you reach the end of the
stored audio buffer, you will return
to the live broadcast. Or, touch
the LIVE button in the Replay view
to return to the live broadcast of
the current channel.

Numeric Keypad Icon

Replay Controls

LIVE Button

Replay Time Bar

Parental Control

The SiriusXM Parental Control feature
allows you to prevent access to
inappropriate mature content for a
younger listener. When enabled, the
Parental Control feature requires you
to enter a passscode to access the
channels that are rated as Mature
Channels.

By default, all channels are Unlocked
and the Lock Code is 1234

Lock Mature Channels:

1. Touch the Numeric Keypad Icon
on the Information Bar.

2. Touch the Parental Control button.

3. Select Lock Mature Channels

4. Enter 4 digit lock code.

Unlock Mature Channels:

1. Touch the Numeric Keypad Icon
on the Information Bar.

2. Touch the Parental Control button.

3. Select Unlock Mature Channels

4. Enter 4 digit lock code.
Set/Change Lock Code:

Select Set Lock Code, enter old
code and then enter new code.

Reset Lock Code:
To reset the Lock Code to default
code (1234)
Go to MENU > Settings > Load Defaults
* The reset process takes 3-4 minutes

and will reset ALL saved settings to
factory default.

Numeric Keypad Icon

Parental Control

16

StingerElectronics.com StingerElectronics.com

17

iPod

®

USB Media

1 2 3 4 75 6

Touch MENU>iPod or press the HOME
BUTTON > iPod to select iPod as your

source.

Previous Track - Touch once to

1

restart current track, touch again
for Previous track.

Play/Pause - Touch to play or

2

pause the audio.

Next Track - Touch to advance to

3

the Next track.

Song Detail

iPod Root Menu

View

With a USB plugged in - touch the

USB Tab or press the HOME BUTTON
> USB to select USB.

From the USB Root Menu you can
browse Audio, Video and Image

les. See page 29 for a list of
supported le types.

Touch to select a le to view/play.

Note: You can use the right knob
to scroll and then press the knob to
select.

Media Controls

Previous Track/File
Play
Pause
Next Track/File
Repeat

Shufe

Search

USB Root Menu

Video / Image Files

Repeat - Replays the current track.

4

Shufe - Plays tracks in random

5

order.

Search - Search for artist, album or

6

song.

Root Menu/Song Details - Toggles

7

between Song Details and the iPod
root menu.

18

StingerElectronics.com StingerElectronics.com

Browse and Select by

Artists, Albums, Playlists, Songs...

Toggle Menu
Full Screen
Settings

WARNING!

Driver is prohibited by law from viewing
video on any in-dash monitor while the
vehicle is in motion.

Music Files

19

Apple CarPlay

®

Android Auto

TM

Set up Apple CarPlay

You can use Apple CarPlay to get
directions, make calls, send and
receive messages, and more.

You need an iPhone 5 or later to use
Apple CarPlay. Also, make sure that
you're in an area that supports Apple
CarPlay and that Siri is on. To turn on
Siri on your phone, go to Settings > Siri
& Search.

With the your vehicle running, plug
your iPhone into the Apple CarPlay
USB port. Apple CarPlay will launch
automatically.

If your iPhone is already plugged
into the USB, touch MENU > Apple

CarPlay or press the HOME BUTTON
> Apple CarPlay to launch Apple

CarPlay.
NOTE: If Apple CarPlay will not

launch, see Page 25 for Apple
Carplay Settings.

The display will show available apps.
Only apps that are supported by
Apple CarPlay will appear.

Home Button / Siri

Ask Siri for what you need.

Press the Voice Control button or
touch the Home button in Apple CarPlay
until Siri appears on the display, then say
what you need.

Set up Andriod Auto

Make sure your phone is running
Android 5.0 (Lollipop) or later.
Download the Android Auto app
from Google Play on your device.
Once the app is installed, open the
app and follow the setup steps.

Connect your phone

Before you connect your phone for

the rst time, turn on your car. Make

sure it's in park (P) and that you have
time to set up Android Auto.

1. Unlock your phone's screen.

2. Connect your phone using a USB
cable.

3. Your phone might ask you to
download or update certain apps,
like Google Maps.

4. Review the Safety Information and
Android Auto permissions to access
your apps.

5. Turn on notications for Android

Auto. For the best experience, we
recommend accepting all requests.

Your phone’s Bluetooth will be turned
on automatically when Android Auto
is connected to the car via USB.

Voice Command Microphone

1 2 3 4 5

1 Maps & Navigation
2 Calls & Contacts
3 Home Screen
4 Music & Audio
5 Exit Android Auto

To add, remove, or customize the
order that the apps are in on your
iOS device:

1. Go to Settings > General, and tap
Apple CarPlay.

2. Select UN1880

3. Use the add or delete icons to add
or remove apps. Tap and drag an

20

StingerElectronics.com StingerElectronics.com

To exit Android Auto, touch the Exit
icon.

For details about Apple CarPlay, visit the following site:
http://www.apple.com/ios/carplay

21

MAIN SETTINGS

MAIN SETTINGS

Touch MENU > Settings or press the
HOME BUTTON > Settings to access
the Settings. Use Arrows to change
values and the Back Button to save
changes.

Settings > Main

Time (Touch to change time)
Beep [OFF-LOW-MID-HIGH]
OSD [English-French-Spanish]
FM TUNING STEPS
[200kHz (NA) - 100kHz (EU)]
Load Defaults [OK] - This will remove
all previously saved settings.

Settings > Cameras

The default Camera Names are Rear,
Left, Right and Front. You can change
the names using the arrow icon on the
left [OUTSIDE-AUX-INSIDE-BED-TRAILER]

Trigger [ON-OFF]
Reverse Camera Audio [OFF-MUTE-ON]

Settings > Style

Illumination[AUTO-ON-OFF]
Illumination Color

[AQUA-BLUE-RED-GOLD-GREEN-WHITE]
Highlight Color

[AQUA-BLUE-RED-GOLD-GREEN-WHITE]
LED Brightness [0-20]

Back Button to Exit and Save Changes

Change Name

Settings > Tabs

Tabs 2-3-4-5-6 are customizable. Use
the arrows to scroll through available
options. After setting Tabs, touch the
BACK/RETURN arrow to save. Tabs

1 and 7 are xed and can not be

changed.

Trigger On/Off

HDMI INPUT

Touch MENU > HDMI or press the HOME
BUTTON > HDMI to switch to the HDMI
input.

The HDMI input can be used for an
external DVD player, streaming sticks,
media players, smartphone mirroring.

You can only view HDMI content with
the vehicle in Park and the parking
brake ON.

Settings > Background

Allows you to change the background
image. You can upload up to 3 of your
own images. To upload an image(s),
copy images onto a USB thumb drive
and connect drive to one of the USB
ports. Touch the + symbol and select
image. Background images should be
1024*600 resolution and .BMP format.
Size is not limited.

22

StingerElectronics.com StingerElectronics.com

When viewing HDMI content, the
Information Bar will auto-hide. To
access the Information Bar, touch
anywhere on the screen.

WARNING!

Driver is prohibited by law from viewing
video on any in-dash monitor while the
vehicle is in motion.

23

AV IN

DISPLAY SETTINGS

Touch MENU > AV IN or press the
HOME BUTTON > AV IN to switch to
the AV input.

You can only view the AV input with
the vehicle in Park and the parking
brake ON.

When viewing the AV IN, the
Information Bar will auto-hide. To
access the Information Bar, touch
anywhere on the screen.

WARNING!

Driver is prohibited by law from viewing
video on any in-dash monitor while the
vehicle is in motion.

NAVIGATION

To access the optional Navigation,
touch MENU > NAVIGATION or press
the NAVIGATION BUTTON on the right
side of the display.

The User Manual for iGo Navigation can
be found on StingerElectronics.com

Touch MENU > Display or press the
HOME BUTTON > Display to access
the display settings.

Display

Set Day

This is the brightness of the display in daylight.

Set Night [1-20]

This is the brightness of the display at night.

Auto [ON-OFF-MANUAL]

If set to Auto, the display will automatically
change to the Night setting when the vehicle's

lights are ON.

Display > Rear Zone

Rear Zone

This selects the Source to send to the AV OUT.
For example, a rear seat entertainment system.

Display > Apple CarPlay

Steering Wheel

This adjusts the Apple CarPlay side menu.

iPhone [Apple CarPlay-iPod Only-OFF]

Determines how iPhone will be used when
plugged into USB port.

Mic Gain [LOW-MID-HIGH]

Adjusts the microphone sensitivity for Apple
CarPlay.

[1-20]

[OFF-USB-AV]

[LEFT-RIGHT]

24

Display > Andriod Auto

Android Auto
Auto Launch [ON-OFF]

[ON-OFF]

StingerElectronics.com StingerElectronics.com

25

AUDIO SETTINGS

AUDIO SETTINGS

Touch MENU > Audio or press the
HOME BUTTON > Audio to access the
AUDIO settings.

Audio > EQ

EQ

Touch to access 15 Band Equalizer and EQ presets.

Loudness [ON-OFF]
Front Speaker HPF

[BYPASS-25HZ-40HZ-63HZ-100HZ-160HZ-250HZ]

User selectable High Pass Filter for Front Speakers.

Rear Speaker HPF

[BYPASS-25HZ-40HZ-63HZ-100HZ-160HZ-250HZ]

User selectable High Pass Filter for Rear Speakers.

Front Speaker Slope

User selectable Slope for Front Speaker HPF

Rear Speaker Slope

User selectable Slope for Rear Speaker HPF

[6dB-12dB-18dB]

[6dB-12dB-18dB]

15 Band Equalizer and EQ presets

The EQ has four global factory presets: Bass
Boost - Rhythym - Vocal - Flat. There are 3

User dened presets. User 1 & 2 presets are

"source dependent" so each source can
be tuned differently. For example, if you
are listening to BT Music and access the EQ
and save a User preset, that particular User
preset will only be available when listening
to BT Music. The Master Preset is a global
setting that will EQ all audio sources.

NOTE

Use Left/Right Arrows to change
settings. Use BACK arrow to Save and
Exit. Default button resets settings to
default values.

Reset to Default

Equalizer and EQ presets

Audio > Speaker

Fader [-9 - 0 - 9]

Using the blue Up and Down arrows, you can fade.

Balance [-9 - 0 - 9]

Using the blue Left and Right arrows, you can
adjust the speaker balance left and right.

Time Alignment [OFF-ON]

When set to ON, select the gear icon to adjust
Time Alignment settings.

Audio > Speaker > Time Alignment

Time Alignment compensates for the
uneven distances between the speakers
and a listener’s ears. Time Alignment delays
signals from the closest speaker(s), so that
all the sound arrives at the listening position
at the same time, giving the listener a more
accurate, life-like stereo image.

To set the Time Alignment, select a Listen­ing Position, and then measure from each
speaker to the Listening Position. Input
speaker distance values in inches into the
appropriate positions.

Each Listening Position can have a unique
set of values.

Listening Positions
[Front-L - Front-R - Front - All]

Saving an EQ User/Master Preset

When you make an adjustment to the
equalizer you will be prompted to select
a preset location. Select a User or Master
position located on the top Information Bar.
When you are done adjusting the EQ, touch
the Back/Return Arrow to save your settings.
Note: You can also modify and save the
factory presets as User presets.

26

StingerElectronics.com StingerElectronics.com

27

AUDIO SETTINGS

REAR ZONE

Audio > Sub-Out

Sub-Out [ON-OFF]

Turns the subwoofer output ON/OFF.

Level [-14 - 7]

Adjusts the SUB OUT level.

Crossover

[BYPASS-25Hz-40Hz-63Hz-100Hz-160Hz-250Hz]

Adjusts crossover frequency of sub output. Fixed
12dB octave slope.

Audio > Volume

Start Volume Mode

Volume at start-up. LAST will be same level as
when unit was shut off. SET will be a preset level
adjusted below.

Set Start Volume [0-40]

Adjusts SET volume level to specic level.

The Volume Mode is adjustable for
Bluetooth(BT), Navigation(Nav) and Siri
using the same procedure.

Note: Use the arrow buttons at bottom of
screen to move between pages.

[LAST-SET]

Touch MENU > Rear or press the
HOME BUTTON > Rear to access the
REAR ZONE menu.

Shortcut to Display > Rear Zone

Rear Zone [USB-AV IN]

This selects the Source to send to the AV OUT.
For example, a rear seat entertainment system.

CAMERA MENU

Touch MENU > Cameras or press the
HOME BUTTON > Cameras to access
the Cameras menu.

If there are optional cameras
installed, you may view them at
anytime using the Cameras menu.

To Exit a camera view, touch
anywhere on the screen.

Audio > Other

Toslink Variable Output
Set MIC Location [EXTERNAL-INTERNAL]

Switch between microphones .

Source Gain [USB AUDIO-USB VIDEO-IPOD-

BT MUSIC-AUX-HDMI-SXM-AM/FM-CAMERA­ANDRIOD AUTO-APPLE CARPLAY]

Selects Source to adjust Gain(volume level).

Gain [-12 - 6]

Adjusts Gain of selected Source.

28

[OFF-ON]

StingerElectronics.com StingerElectronics.com

DISPLAY OFF

Touch MENU > DISPLAY OFF or press
the HOME BUTTON > DISPLAY OFF to
turn off LCD and display large clock.

Tap the screen anywhere to return to
regular display.

29

TROUBLE SHOOTING

TROUBLE SHOOTING

Black Screen with Audio

Touch the screen anywhere as it may have
been turned off, see page 29.
Ensure the cables on the back of the screen
are fully locked into place and also properly
connected at the back of the radio module.

Bluetooth

Device will not Pair

Ensure Bluetooth is turned ON in your
device settings. Delete all unused devices.
Delete any "Stinger" device. Restart/
Reboot device and try pairing again.
(Page: 10)

Music Volume is low

- Turn up volume on device

- Turn up volume on head unit.

- Turn up BT Volume Gain (Page: 28)

Phone Volume is low

- Turn up volume on device

- Turn up volume on head unit.

- Turn up BT Volume Gain (Page: 28)

- Turn up Mic Gain (Page: 10)

Video/Cameras

Rear Camera not displaying in reverse

- Make sure rear camera trigger is ON
(Page: 22)

- If display is showing NO SIGNAL in reverse,

..ensure camera RCA is plugged into
..correct RCA input (CAMERA IN).

- Conrm camera has power and ground.

- Conrm camera trigger is receiving

..positve12V.

Note: NTSC and PAL video formats only.

SiriusXM Satellite RadioGeneral

Check Antenna

The radio has detected a fault with the
SiriusXM antenna. The antenna cable may be
either disconnected or damaged.

- Verify that the antenna cable is connected

..to the SiriusXM Connect Vehicle Tuner.

- Inspect the antenna cable for damage and
kinks.

Replace the antenna if the cable is damaged.

SiriusXM products are available at your local
car audio retailer or online at www.shop.
siriusxm.com.

Check Tuner

The radio is having difculty communicating

with the SiriusXM Connect Vehicle Tuner. The
tuner may be disconnected or damaged.

- Verify that the SiriusXM Connect Vehicle

..Tuner cable is securely connected to the
..radio.

No Signal

The SiriusXM Connect Vehicle Tuner is having

difculty receiving the SiriusXM satellite signal.

- Verify that your vehicle is outdoors with a

..clear view of the sky.

- Verify that the SiriusXM magnetic mount

..antenna is mounted on a metal surface on
..the outside of the vehicle.

- Move the SiriusXM antenna away from any
obstructions. Inspect the antenna cable for
damage and kinks.

- Consult the SiriusXM Connect Vehicle tuner
installation manual for more information on
antenna installation.

Replace the antenna if the cable is damaged.

SiriusXM products are available at your local
car audio retailer or online at www.shop.
siriusxm.com.

Channel Locked

The channel that you have requested is
Locked by the radio Parental Control feature.
See the Parental Control section on Page 17
for more information on the Parental Control
feature and how to access locked channels.

Subscription Updated

The radio has detected a change in your
SiriusXM subscription status.

- Press anywhere on the screen to clear the

..message.

In the U.S.A., visit www.siriusxm.com or call
1- 866-635-2349 if you have questions about
your subscription. In Canada, visit www.
siriusxm.ca or call 1- 877-438-9677 if you have
questions about your subscription.

Channel Unavailable

The channel that you have requested is not
a valid SiriusXM channel or the channel that
you were listening to is no longer available.

You may also see this message briey when
rst connecting a new SiriusXM Connect

Vehicle tuner.

Visit www.siriusxm.com for more information
about the SiriusXM channel lineup.

title, exists.

Memory End

This message will display when the beginning
of stored audio has been reached. You
cannot rewind any further.

Memory Full

The stored audio memory has become full
while audio was paused. Resume playback.

Channel Unsubscribed

The channel that you have requested is
not included in your SiriusXM subscription
package or the channel that you were
listening to is no longer included in your
SiriusXM subscription package.

In the U.S.A., visit www.siriusxm.com or call
1- 866-635-2349 if you have questions about
your subscription package or would like to
subscribe to this channel. In Canada, visit
www.siriusxm.ca or call 1- 877-438-9677.

Apple CarPlaySiriusXM Satellite Radio (cont)

Apple CarPlay will not start/launch

- Ensure you are using a Apple certied

..cable

- Make sure you are plugged into USB

..#1(top)

- Make sure Apple CarPlay is turned ON

..(Page 25)

Android Auto

Android Auto

- Ensure you are using a USB certied cable

- Make sure Android Auto app is

..downloaded and installed on your device.

- Make sure you are plugged into USB

..#1(top)

- Make sure Android Auto is turned ON

..(Page 26)

30

StingerElectronics.com StingerElectronics.com

31

SPECIFICATIONS SPECIFICATIONS

GENERAL

Operating Voltage: 9.0VDC to 18VDC
Grounding system; Negative Ground
Max current consumption: 10A fused

DIMENSIONS

Radio Module:
178 mm x100 mm x 116 mm (W x H x D)
Display:

247.2 mm x 180.6 mm x 48.5 mm (W x H x D)

DISPLAY

10-inch Diagonal
16:9 aspect ratio
1024 x 600
Pixels: 1,843,200
Active area 222.72 (W) x 125.28 (H) mm
Operating Temperature (C) -20° to 70°

AUDIO

Max power output: 50W x 4ch/4Ω

Load impedance: 4Ω nominal 2Ω allowable

Continuous power output:

25W x 4ch/4Ω 20Hz to 20KHz,

1%THD at 14.4V
Audio output level (max): 4.0V preout
EQ: (15-band)
25Hz/40Hz/63Hz/100Hz/160Hz/250Hz/400Hz/
630Hz/1KHz/1.6KHz/2.5KHz/4KHz/6.3KHz/
10KHz/16KHz
Gain: ±12dB (2dB/step)
HPF: 25Hz/40Hz/63Hz/100Hz/160Hz/250Hz
Slope: 6dB, 12dB, 18dB

AUDIO (CONT)

Subwoofer Preout
LPF: 25Hz-40Hz-63Hz-100Hz-160Hz-250Hz
Gain: -14dB to 7dB (1dB/step)
Phase: 0 or 180
Speaker level: ±9dB (1dB/step)
Time Alignment: 0 to 100 step (1inch/step)

USB

USB 2.0
Max current supply 1.5A
USB Class:
MSC (Mass Storage Class),
MTP (Media Transfer Protocol)
File system: FAT32, NTFS

BLUETOOTH

V4.2
4dBm Class2

2.4GHz to 2.48GHz

FM TUNER

87.9MHz to 107.9MHz
Usable sensitive
30dB (mono S/N: 30dB)
SNR: 65dB

AM TUNER

530KHz to 1710KHz
Usable sensitive

30dB（mono S/N:20dB（

SNR 58dB

CAMERA(S) VIDEO INPUTS

NTSC OR PAL video formats

HDMI INPUT

480P / VGA

TOSLINK

Output: Variable

BACKGROUND IMAGE (USER)

File Format: BMP
Resolution: 1024 x 600

File size is not limited

AUDIO/VIDEO FORMATS

AUDIO

MPEG-1 Audio Layer-3 (.mp3)

FLAC (.ac)

MPEG-2 Advanced Audio (.aac)
MPEG-4 Audio (.m4a)
Windows Audio (.wav)
OGG Audio (.ogg)

VIDEO

QuickTime (.mov)
MPEG-4 Video (.mp4)
Microsoft AVI (.avi)
MPG Video (.mpg)
MPEG Video 1/2 (.mpeg)
VOB DVD (.vob)

Flash Video (.v)

MKV Media (.mkv)


JPEG (.jpg)
CompuServe GIF (.gif)
PNG (.png)
JPEG (.jpeg)
Bitmap (.bmp)

32

StingerElectronics.com StingerElectronics.com

33

DIMENSIONS

CONNECTIONS

9.73

DIMENSIONS ARE IN INCHES

0.80

1.44 0.47

7.11

Power / Speaker

GPS Antenna

15 Amp Fuse

AV In/Out - Rear Camera Microphone

1

The top USB1 must be used for Apple CarPlay and Android Auto.

USB1 CP/AA

REMOVING THE DISPLAY

To remove the display from the
plastic mounting bracket, push up
from compression spring side(1)
and swing out to unhook top(2).

USB2

Multi Camera

1

SWI

Display Cable

HDMI Input

SiriusXM Tuner

2

TOSLINK

LVDS Cable

Radio Antenna

34

1

StingerElectronics.com StingerElectronics.com

35

FEATURES

10” 1024 x 600 HD Digital Touchscreen with 16.7M colors

Apple CarPlay

Google Android Auto

SiriusXM-Ready™ with Replay

®

™

(SiriusXM Connect Vehicle Tuner and Subscription required)

AM/FM Radio - PTY / RT information

High power 4 x 50W built-in amplifier

4V 6ch RCA audio outputs with subwoofer control

Toslink Variable Audio Output

15 Band Adjustable EQ with 3 user presets

1 HDMI rear input

2 USB rear inputs 1.5amp output

Handsfree Bluetooth 4.2 A2DP with aptX

®

™

Optional built-in iGO navigation

4 Camera Video inputs with wired triggers

Rear camera input with Mic Audio input

Hardwired remote control ready

Customizable display backgrounds

1DIN chassis mounting design

UG-UN1810 REV.071619
