iSimple PGHVW1 User Manual

Expand Your Factory Radio
iSimple® A Division of AAMP of America™ 13190 56th Court Clearwater, FL 33760 Ph. 866-788-4237 support@isimplesolutions.com
©2009 AAMP of Florida, Inc.
www.isimplesolutions.com
add
add
iPod
iPod
VOLKSWAGEN
Owner’s Manual
Media Gateway
PXAMG
®
®
PGHVW1
Rev. 10-27-09
INST010
Table of Contents
Pages
1. Introduction 1
2. Precautions 1
3. Compatibility Notes 1
4. Dipswitch Settings 2
5. Installation 2
6. iPod Operation 4
PanasonicRadioOperation Delphi Radio Operation
7. HD Radio Operation 9
(if equipped)
Panasonic Radio Operation Delphi Radio Operation
8. Sirius Satellite Radio Operation 11
9.Selecting AUX Input 12
10. Selecting Factory Satellite 12
(if eqipped)
11. Troubleshooting 13
12. Warranty Information 14
Harness Connection
a
Port 1
a
Port 2
a
Dip Switches
(See Manual)
a
USB
a
Media Gateway & Optional Add-ons
Harness Connection
a
Port 1
a
Port 2
a
Dip Switches
(See Manual)
a
USB
a
*The Media Gateway will only support 2 inputs.
Factory Radio
Not Included
iPod
Not Included
Media Gateway Harness
Part #: PGHVW1
Media Gateway
Part #: PXAMG
11Ft. iPod Cable
3Ft. HD Radio Cable
HD RadioTM Tuner
(sold separately)
Antenna Adapter
* Required for most vehicles. (sold seperately)
Part #: HDRT
1. Introduction
Thank you for purchasing the iSimple® Media Gateway. The Media Gateway is designed to provide endless hours of listening pleasure from your factory radio. To ensure that your iPod performs correctly with your radio, we recommend that you read this entire manual before attempting installation of the Media Gateway. The Media Gateway allows connectivity for iPod, Sirius Satellite Radio tuner (SCC1 sold seperately) and HD Radio tuner (HDRT sold separately), enabling full control of these devices from the factory installed radio. It also retains original system features such as Satellite Radio (if equipped).
2. Precautions
UPDATING iPod FIRMWARE
For proper operation of the Media Gateway , your iPod must be updated
with the most recent version of rmware from Apple. This is done on your
computer. To update the software on the iPod go to: http://www.apple. com/ipod/download/. Follow the directions on the website to complete the download. There is no charge for this update.
PREVENTING DAMAGE TO YOUR VEHICLE OR iPod.
Some installations require you to make wiring connections. To eliminate the risk of an electrical short, we recommend disconnecting the vehicle’s battery prior to installation. If you do not feel comfortable making these connections, we suggest you seek professional installation. We recommend that the iPod be disconnected from the interface when the vehicle is not in use.
PROPER MOUNTING LOCA TION
Securely install the interface in a location free from; heat, humidity , moving parts, sharp metal edges or direct sunlight. We recommend securing the interface to a suitable location using; double sided tape, VelcroTM or zip-ties.
3. Compatibility Notes
Your vehicle MUST either be equipped with, or have the ability to support
Satellite Radio. Please visit www.isimplesolutions.com for the most up to date application information and to verify your vehicle’s compatibility.
1
4. Dipswitch Settings
After removing the radio from the vehicle, identify the manufacturer of the radio. T wo companies make the radios featured in these VW vehicles. If the model number sticker is on the side of the radio it is a Delphi brand radio. If the model number sticker is on the top of the radio it is a Panasonic brand radio.
For Delphi radios all dip switches must be in the OFF position (up) for the Media Gateway to function.
For Panasonic radios only dipswitch #2 needs to be turned ON (down), the rest must be OFF (up) for the Media Gateway to function.
5. Installation
Before installing the Media Gateway, be sure you have correctly set the dipswitches according to section four.
NOTE: DO NOT disconnect the wiring from the “passenger airbag light” on the dash bezel. Disconnecting this harness will cause an airbag light to illuminate in the gauge cluster which needs to be reset by a Volkswagen dealership.
1. When making electrical connections it is always recommended that the vehicle’s battery be disconnected from the electrical system before performing the installation.
2. Carefully remove the radio from the dash of the vehicle. We recommend the use of iSimple® Part # GET (when applicable) to remove
the radio from the dash. These tools are specically designed to be used
to remove Volkswagen radios. This will provide access to the factory radio connectors where you will connect the Media Gateway harness.
3. Disconnect the factory harness from the back of the radio. Disconnect the antenna connector from the radio.
2
4. Connect the 8-Pin iPod docking cable into the rst port on the Media
Gateway furthest away from dipswitches. Carefully run the 11 foot iPod cable behind the dash to the location where the iPod will be mounted or stored (for example; the glove box or center console). This location may vary based on the vehicle, and customer’s preference. When running this cable through the dash, be sure to secure it away from moving parts or sharp metal edges that may damage the cable.
5. If connecting the HD Radio tuner (HDRT sold separately) Plug the 3 foot HD Radio cable (8-Pin mini-din to 8-Pin mini-din) into the second port (closest to the dipswitches) on the Media Gateway. Connect the other end of this cable into the HD Radio tuner. Connect the factory WHITE antenna cable into the antenna connection on the HD Radio tuner (HDRT). For
best performance of the HDRT use an amplied antenna adaptor to
make this connection. We recommend the use of a Best Kits BAADIN22 or equivalent. If the Tan connector is connected into the HDRT it will not receive any AM reception.
6. If connecting the Satellite Radio tuner (SCC1 sold separartely), make the folllowing connections before connecting the PXAMG to the vehicle. Plug the black end of the 3 foot PXAMGSR (8-Pin mini-din to 8-Pin mini­din; sold seperately) into the second port (closest to the dipswitches) on the Media Gateway. If you are installing the Satellite Radio Tuner with the HDRT, connect the PXAMGSR cable to the port farthest from the dipswitches. Connect the gray end of this cable into the Satellite Radio tuner.
7. Plug the male connector on the PGHVW1 harness into the port on the back of the radio. Next, connect the factory harness into the female
connector on the PGHVW1 harness. Be sure to make a rm connection but do not force it. Plug the black micro-t 24-pin connector on the
PGHVW1 harness into the PXAMG Media Gateway box.
8. To complete the installation secure the Media Gateway (PXAMG) and HD Radio tuner (HDRT) or Satellite radio tuner (SCC1) into the cavity behind the dash. Be sure that the cables and interface modules are not near moving parts or sharp metal edges as they may damage the cables. To prevent rattling noises inside the dash, use zip ties, or electrical tape, or other fasteners to mount the interfaces to the factory wiring or installed audio components (for example under the factory Satellite tuner (if present).
3
9. With all connections made, reconnect the vehicle’s battery, insert the key into the ignition, and turn the vehicle on. Check for proper operation of the Media Gateway and HD Radio tuner or Satellite Radio tuner before reinstalling the factory dash panels.
10. When rst powering up the vehicle with the radio reconnected,
“CODE” may appear on the screen. This is a safety feature of the VW radio. If you see this message, DO NOT enter a code, simply let the radio sit on this screen for about 10 seconds, then turn the vehicle off. Disconnect the gateway harness from the vehicle. Reconnect the gateway harness to the vehicle. Normal operation should resume.
11. NOTE: The rst time that you access the Gateway, your radio may
display “DEV INIT” while the device is initializing. If this is displayed, please wait one minute the cycle the ignition off and on. Access “SAT” mode again to begin normal gateway operation.
6. iPod Operation
Entering Mode Select Menu
Press the “SAT” button. Press the “CAT FLDR” ▲ or ▼ button to cycle
through the Media Gateway sources until IPOD is displayed. Wait 6 seconds and the radio will select the displayed option.
PLEASE NOTE: If you are listening to Satellite Radio and wish to switch the Media Gateway source, you must press the TUNE KNOB twice before pressing the “CAT FLDR” ▲ or ▼ button. If the radio still does not go into the mode select menu, press and hold the TUNE KNOB until the radio menu is displayed. Turn the TUNE KNOB until the radio displays”SELECT SCAN SAT”. Press the preset button underneath “Channels”. Press and hold the TUNE KNOB to exit the radio menu. You should now be able to access the mode select menu.
4
Panasonic Radio Controls
Next Track
Turn the Tune knob Clockwise to skip to the next track.
Previous Track
Turn the Tune knob Counter-clockwise to go back to the previous track.
Enter Browse menu / make a selection
Press the TUNE KNOB to enter the browse menu or make a selection while in the browse menu.
Menu back
Press “Seek ▼” to move back one folder in the menu.
Steering Wheel controls
The Multifunction display in the gauge cluster must be in “Audio mode” for the steering wheel controls to operate the Media Gateway .
Press the “▲” button on the SWC to advance to the next track. Press the “▼” button on the SWC to go back to the previous track.
Press the “OK” button on the SWC to enter the browse menu or to make a selection while in the browse menu.
Press the “▲” or “▼” buttons while in the browse menu to scroll through
the menus.
PLEASE NOTE: In the 2009 VW CC the “OK” button does not function. In this vehicle you will only be able to change the tracks with the < or > buttons on the left side of the steering wheel.
5
Browse by Artist
Press the TUNE KNOB to enter the browse menu. ”PL:LIST” will appear on your display .
Press the “CAT FLDR” ▲ button until
“AR:ARTIST” is displayed. Press the TUNE KNOB to select browse by Artist. The list of Artists on your Pod will be displayed one at a time in alphabetical order. “AR” will be displayed in front of the artist’s name to indicate that you are searching for an artist.
Press the “CAT FLDR” ▲ button to cycle through the artists.
When the desired artist is displayed on the radio, Press the TUNE KNOB to select the artist and display the albums by that artist. The Albums from the selected Artist will be displayed one at a time in alphabetical order. “AL” will be displayed in front of the name of the album to indicate you are searching for an album.
Press the “CAT FLDR” ▲ button to cycle through the albums.
Once the desired album is displayed, Press the TUNE KNOB to select the desired Album.
The rst song in the album will be displayed. “TR” will be displayed in front
of the song title to indicate that a “track” or song title is being displayed.
Press the “CAT FLDR” ▲ button to cycle through the songs in the selected
album. Songs are listed in the order in which they appear in the album, not alphabetically . Once the radio displays the name of the desired song Press the TUNE KNOB to select and play the desired song. The display will automatically update to display and scroll the title of the chosen song.
6
Delphi Radio Controls
Next Track
Turn the Tune knob Clockwise to skip to the next track.
Previous Track
Turn the Tune knob Counter-clockwise to go back to the previous track.
Enter Browse menu / make a selection
Press PRESET 2 to enter the browse menu or to make a selection while in the browse menu.
Menu back
Press Preset # 1 to move up one folder in the menu.
Exit Browse Menu
Press Preset # 3 to exit the browse menu
Rewind
Press Preset # 5 to rewind, press Preset # 5 again to play .
Fast Forward
Press Preset # 6 to fast forward, press Preset # 6 again to play .
Random modes
Press Preset # 4 to toggle between the random modes (Song, Album, Off.)
7
Browse by Artist
Press PRESET 2 to enter the browse menu. ”PL:LIST” will appear on your display .
Press the “CAT FLDR” ▲ button until
“AR:ARTIST” is displayed. Press PRESET 2 to select browse by Artist. The list of Artists on your Pod will be displayed one at a time in alphabetical order. “AR” will be displayed in front of the artist’s name to indicate that you are searching for an artist.
Press the “CAT FLDR” ▲ button to cycle through the artists.
When the desired artist is displayed on the radio, Press PRESET 2 to select the artist and display the albums by that artist. The Albums from the selected Artist will be displayed one at a time in alphabetical order. “AL” will be displayed in front of the name of the album to indicate you are searching for an album.
Press the “CAT FLDR” ▲ button to cycle through the albums.
Once the desired album is displayed, Press PRESET 2 to select the desired Album.
The rst song in the album will be displayed. “TR” will be displayed in front
of the song title to indicate that a “track” or song title is being displayed.
Press the “CAT FLDR” ▲ button to cycle through the songs in the selected
album. Songs are listed in the order in which they appear in the album, not alphabetically . Once the radio displays the name of the desired song Press PRESET 2 to select and play the desired song. The display will automatically update to display and scroll the title of the chosen song.
8
7. HD Radio Operation
(if equipped)
Entering Mode Select Menu
Press the “SAT” button. Press the “CAT FLDR” ▲ or ▼ button to cycle
through the Media Gateway sources until HD-FM or HD-AM is displayed. Wait 6 seconds and the radio will select the displayed option.
PLEASE NOTE: If you are listening to Satellite Radio and wish to switch the Media Gateway source, you must press the TUNE KNOB twice before pressing the “CAT FLDR” ▲ or ▼ button. If the radio still does not go into the mode select menu, press and hold the TUNE KNOB until the radio menu is displayed. Turn the TUNE KNOB until the radio displays”SELECT SCAN SAT”. Press the preset button underneath “Channels”. Press and hold the TUNE KNOB to exit the radio menu. You should now be able to access the mode select menu.
PANASONIC Radio Controls
Seek Up
Press the ”SEEK▲” button to seek up to next available station.
Seek Down
Press the ”SEEK ▼” button to seek down to the next available station.
Manually T une
Turn the Tune knob to manually tune. Clockwise will tune up, Counter­clockwise will tune down.
Storing stations into preset memory
Tune to the station you wish to store then press the TUNE KNOB. Use the “CAT FLDR” button to cycle through the preset locations (1-18FM, or 1-6 AM). Once the location you would like to select is displayed press the TUNE KNOB to store the station. The radio will display “PR SAVED”
Recall a station from preset memory
Press the TUNE KNOB to access the preset memory menu. Use the “CAT FLDR” button to cycle through the preset locations. When
the desired preset is displayed press the SEEK ▼ button to recall it.
Steering Wheel Controls
The Multifunction display in the gauge cluster must be in “Audio mode” for the steering wheel controls to operate the Media Gateway .
Press the “▲” arrow on the steering wheel controls to seek up. Press the “▼” arrow on the steering wheel controls to seek down.
Storing stations into preset memory
Press “OK” access the preset memory menu.
Use the “▲” and “▼” buttons to cycle through the preset locations (1-18FM, or 1-6 AM)
Press “OK” to store the current station into the location displayed on the radio, for example PRE1.
Recall a station from preset memory
Press “OK” to access the preset memory menu.
Use the “▲” and “▼” buttons to cycle through the preset locations. When
the desired preset is displayed, wait 3 seconds, the radio will auto select the station.
PLEASE NOTE: In the 2009 VW CC the “OK” button does not function. In this vehicle you will only be able to seek through the stations with the < or > buttons on the left side of the steering wheel.
Delphi Radio Controls
Seek Up
Press the ”SEEK▲” button to seek up to next available station.
Seek Down
Press the ”▼SEEK” button to seek down to the next available station.
Manually T une
Turn the Tune knob to manually tune. Clockwise will tune up, Counter­clockwise will tune down.
Storing stations into Preset memory
Tune to a station you wish to save into Preset memory. Press and hold the Preset button (1-6) where you want to store the preset. Holding the preset button for two seconds will store the station into memory.
PLEASE NOTE: If using the HDRT in conjunction with the SCC1, the HD Radio preset text will overwrite the SCC1 preset text, however the presets will still operate normally .
Recall a station from Preset memory
Press the preset button (1-6) to recall the station stored in that location.
10
8.Sirius Satellite Radio Operation
(if equipped)
Entering Mode Select Menu
Press the “SAT” button. Press the “CAT FLDR” ▲ or ▼ button to cycle
through the Media Gateway sources until SIRIUS is displayed. Wait 6 seconds and the radio will select the displayed option.
PLEASE NOTE: If you are listening to Satellite Radio and wish to switch the Media Gateway source, you must press the TUNE KNOB twice before pressing the “CAT FLDR” ▲ or ▼ button. If the radio still does not go into the mode select menu, press and hold the TUNE KNOB until the radio menu is displayed. Turn the TUNE KNOB until the radio displays”SELECT SCAN SAT”. Press the preset button underneath “Channels”. Press and hold the TUNE KNOB to exit the radio menu. You should now be able to access the mode select menu.
Channel Up
Turn the rotary TUNE KNOB clockwise to move up through the channels
Channel Down
Turn the rotary TUNE KNOB counter-clockwise to move down through the channels
Category Up
Press the “CAT FLDR ▲” button to move up through the categories.
Category Down
Press the “CAT FLDR ▼” button to move down through the categories.
Store Presets
Press and hold the preset button on which you want to store the channel.
PLEASE NOTE: If using the HDRT in conjunction with the SCC1, the HD Radio preset text will overwrite the SCC1 preset text, however the presets will still operate normally
Recall Presets
Press the preset button that corresponds with the channel you want to recall.
Steering Wheel Controls
Press the “▲” button to cycle up through the presets. Press the “▼” button to cycle down through the presets.
11
9. Selecting AUX
Entering Mode Select Menu
Press the “SAT” button. Press the “CAT FLDR” ▲ or ▼ button to cycle
through the Media Gateway sources until AUX is displayed. Wait 6 seconds and the radio will select the displayed option.
PLEASE NOTE: If you are listening to Satellite Radio and wish to switch the Media Gateway source, you must press the TUNE KNOB twice before pressing the “CAT FLDR” ▲ or ▼ button. If the radio still does not go into the mode select menu, press and hold the TUNE KNOB until the radio menu is displayed. Turn the TUNE KNOB until the radio displays”SELECT SCAN SAT”. Press the preset button underneath “Channels”. Press and hold the TUNE KNOB to exit the radio menu. You should now be able to access the mode select menu.
10. Selecting Factory Satellite Radio (if equipped)
Entering Mode Select Menu
Press the “SAT” button. Press the “CAT FLDR” ▲ or ▼ button to cycle
through the Media Gateway sources until SAT is displayed. Wait 6 seconds and the radio will select the displayed option.
PLEASE NOTE: If you are listening to Satellite Radio and wish to switch the Media Gateway source, you must press the TUNE KNOB twice before pressing the “CAT FLDR” ▲ or ▼ button. If the radio still does not go into the mode select menu, press and hold the TUNE KNOB until the radio menu is displayed. Turn the TUNE KNOB until the radio displays”SELECT SCAN SAT”. Press the preset button underneath “Channels”. Press and hold the TUNE KNOB to exit the radio menu. You should now be able to access the mode select menu.
For instructions on the operation of the factory installed Satellite Radio tuner, please reference the owner’s manual supplied with the vehicle.
12
10. Troubleshooting
Symptom Cause Remedy
Radio shows iPod not connected
iPod cable is not connected to iPod or Gateway.
Verify the docking cable is connected to the Media Gateway, and the iPod
I can not correctly control the iPod through the radio.
I have updated my
iPod’s rmware
and still have control issues
I don’t see iPod artist or song information on the screen
I can’t use my iPod’s click wheel to select music
The Media Gateway does not recognize the HD Radio tuner (HDRT)
Radio shows “DEV INIT”
When I listen to the factory AM or FM radio there is only static, no audio.
No AM or FM reception using the HD Radio source
HD Radio station
quality uctuates
or is lost randomly
The iPod rmware
may be out of date.
Sometimes the
iPods needs to be reset
The radio is
displaying a different
text eld
The iPod is in
external control mode. This allows text to be displayed on the radio screen
The HD tuner was not properly connected when the PXAMG was
rst connected and
initialized.
Gateway device is
initializing
Factory antenna cable is connected to the HD Radio tuner.
Factory antenna cable is not connected to the HD Radio tuner (HDRT)
The HD Tuner is temporarily losing reception of the Digital HD Radio broadcast signal
Update iPod rmware for free at http://www.apple.com/ipod/download
Press and hold the click wheel (center button) and the menu button for 10 seconds. This will reboot the iPod. YOU WILL NOT LOSE MUSIC on the iPod by doing this reset
Press the Text / Scan button to see text
Press the Aux / Sat button and select AUX 2 source to control the iPod manually using the click wheel
HDRT must be connected before the PXAMG is powered on. Disconnect the PXAMG from the vehicles harness for 5 minutes. Verify the 8 pin DIN HDRT cable is securely connected at both ends before reconnecting the vehicle harness.
This only occurs the rst time the PXAMG is
powered on. Wait one minute, cycle ignition off and on then enter SAT Mode.
Use Gateway to access HD Radio source. This will provide all AM and FM reception for your vehicle.
Remove from factory radio, connect into HDRT module. Note* We recommend a Best Kits BAADin22
This is expected performance. The Digital HD Radio playback will resume in areas of higher broadcast signal strength.
I receive FM but no AM stations
13
Poor antenna connection
Verify that the WHITE antenna connector is connected to the HDRT, using a BAADin22 or equivalent adapter.
11. Warranty Information
One Year Limited Warranty
The quality controls used in the manufacture of this product will ensure your satisfaction. This warranty applies only to the original purchaser of this product from an authorized
iSimple
uct that, upon inspection by normal use due to defects in material or workmanship. This warranty does not apply to installation expenses. Attempting to service or modify this unit, operating this unit under conditions other than the recommended voltage will render this WARRANTY VOID.
Unless otherwise prescribed by law, property damage and or any incidental or consequential damages of any kind (includ­ing water damage) resulting from malfunctions, defects, misuse, improper installation or
alteration of this product. All parts of this of 1 year as follows:
®
dealer . This warranty covers any supplied or manufactured parts of this prod-
iSimple
®
authorized personnel, is found to have failed in
iSimple
®
shall not be liable for any personal injury,
iSimple
®
product are guaranteed for a period
Within the rst 12 months from date of purchase, subject to the conditions above,
iSimple
or workmanship providing it is returned to an Authorized OF PURCHASE from an authorized
®
will repair or replace the product at their discretion, if it is defective in material
iSimple
iSimple
®
dealer.
®
dealer , with PROOF
Warning:
This equipment may be reset by unintentional electrostatic discharge during operation. Exposure to direct sunlight or extreme heat may cause damage or malfunction.
FCC Class B Radio Frequency
Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment gener­ates, uses, and can radiate radio frequency energy and, if not installed and used in ac­cordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television recption, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
1. Reorientate or relocate the receiving antenna.
2. Increase the separation between the equipment and reciever.
3. Connect the equipment into an outlet on a circuit differant from that of which the reciever is connected.
4. Consult the dealer or an experienced radio / television technical for help.
Notice : The changes or modications not expressly approved by the party responsible for
compliance could void the user authority to operate the equipment.
For Best Performance Have It
Professionally Installed.
14
Notes
____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________
15
Notes
____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________
16
www.isimplesolutions.com
For Best Performance Have It
Professionally Installed.
17
Loading...
