iSimple ISUSB User Manual
Expand Your Factory Radio
add
iPod
GM
®
Owner’s Manual
iSimple Connect
iSimple®
A Division of AAMP of America™
13190 56th Court Clearwater, FL 33760
Ph. 866-788-4237
support@isimplesolutions.com
©2012 AAMP of Florida, Inc.
www.isimplesolutions.com
07-13-12
Table of Contents
Pages
1. Introduction 2
2. Precautions 2
3. Compatibility 3
4. Dipswitch Settings 3
5. Installation 4-5
Non-Navigation Radios
6. iPod Operation 5-6
7. USB Operation
6-7
8. Selecting AUX Input 8
9. Selecting Factory Satellite 8
(if equipped)
Navigation Radios
10. iPod Operation 8-9
11. USB Operation 9-11
12. Selecting Aux Input
12
13. Selecting Factory Satellite 12
(if equipped)
14. Bluetooth Operation 12-14
15. Updating the Interface 15
16. Troubleshooting
17. Warranty Info
16
17
CONNECT
iSimple Connect Harness
Part #: PGHGM1
iSimple Connect
®
& Optional Add-ons
Factory Radio
Not Included
HD Radio
OR
OR
AUX Input
Satellite Radio
USB Stick
OR
iPod/iPhone
OR
Android Device
1
1. Introduction
Thank you for purchasing the iSimple CONNECT®. The CONNECT® is designed
to provide endless hours of listening pleasure from your factory radio. To ensure
that your iPod performs correctly with your radio, we recommend that you read
this entire manual before attempting installation of the Connect.
®
The CONNECT
(cable and tuner sold seperately) and HD Radio (tuner sold separately), enabling
full control of these devices from the factory installed radio. It also retains original
system features such as satellite radio and rear seat entertainment (if equipped).
2. Precautions
UPDATING iPod FIRMWARE
Updating the rmware prior to installation or future rmware updates for your iPod
may affect the features and functions described in this manual.
PREVENTING DAMAGE TO YOUR VEHICLE OR IPOD.
Some installations require you to make wiring connections. To eliminate the risk
of an electrical short, we recommend disconnecting the vehicle’s battery prior to
installation. If you do not feel comfortable making these connections, we suggest
you seek professional installation. We recommend that the iPod be disconnected
from the interface when the vehicle is not in use.
PROPER MOUNTING LOCATION
Securely install the interface in a location free from; heat, humidity, moving parts,
sharp metal edges or direct sunlight. We recommend securing the interface to a
suitable location using; double sided tape, VelcroTM or zip-ties.
allows connectivity for iPod, Bluetooth, Sirius Satellite Radio
2
3. Compatibility
Your vehicle MUST either be equipped with, or have the ability to support
Satellite Radio. Please visit www.isimplesolutions.com for the most up to date
application information and to verify your vehicle’s compatibility.
4. Dipswitc h Settings
ALL VEHICLES
3
5. Installation
1. When making electrical connections it is always recommended that the vehicle’s
battery be disconnected from the electrical system before performing the
installation.
Please Note: If the radio is equipped with a built in CD Changer, please
remove ALL discs before proceeding to prevent damage to the radio’s
CD mechanism.
2. Carefully remove the trim panels covering the 7mm bolts that secure the radio into
the dash cavity. Remove these bolts, and carefully pull the radio from the dash of
the vehicle. This will provide access to the factory radio harness where you will
plug in the CONNECT
3. Disconnect the factory 16-Pin harness and 14-Pin harness from the back of the
radio.
®
harness.
4. Connect the included USB cable into the USB port on the CONNECT
®
. Carefully
run the USB cable behind the dash to the location where it can be easily accessed.
This location will vary based on the vehicle, and the customer’s prefrence. When
running this cable through the dash be sure to secure it away from moving parts or
sharp metal edges that may damage the cable.
5. Connect the 8-Pin auxiliary input cable to the second port (closest to the
dipswitches) on the Connect if an additional auxiliary input is desired.
6. If connecting the HD Radio Tuner (HDRT sold separartely) or Satellite Radio
tuner (sold separartely), these devices MUST be connected before plugging in
the 24 pin connector. Please refer to the manual included with each part for proper
installation.
7. Plug in the male connectors on the PGHGM1 harness into the 16-pin port and
14-pin port on the back of the radio. Next, connect the factory 16-pin and 14-pin
harness into the female connectors on the PGHGM1 harness. Be sure to make a
rm connection but do not force it. Plug the Black micro-t 24-pin connector on the
PGHGM1 harness into the CONNECT
8. To complete the installation secure the CONNECT
®
box.
®
and any other modules into
the cavity in the dash behind
the radio. Be sure that the cables and interface modules are not near moving
parts or sharp metal edges as they may damage the cables. To prevent rattling
noises inside the dash, use zip ties, tape, or other fasteners to mount the
interfaces securely.
9. With all connections made, reconnect the vehicle’s battery , insert the key into the
ignition, and turn the vehicle on. Check for proper operation of the CONNECT
®
before reinstalling the factory dash panels.
4
