iSimple ISSR12 User Manual
Expand Your Factory Radio
Harness Connection
Port 1
Port 2
Dip Switches
(See Manual)
USB
add
Satellite
Radio
GM
Class II
Owner’s Manual
Gateway
ISSR12
iSimple®
A Division of AAMP of America™
13190 56th Court Clearwater, FL 33760
Ph. 866-788-4237
support@isimplesolutions.com
©2012 AAMP of Florida, Inc.
www.isimplesolutions.com
05-02-12
Rev. 05-05-08
Inst007
Table of Contents
Pages
1. Introduction 2
2. Precautions 2
3. Compatibility Notes 3
4. Dipswitch Settings 3
5. Installation 4
6. Satellite Radio Operation
7. Troubleshooting
8. Warranty Info
5
8
9
GateWay & Optional Add-ons
Harness Connection
Port 1
Port 2
Dip Switches
(See Manual)
USB
Harness Connection
Port 1
Port 2
Dip Switches
(See Manual)
USB
Harness Connection
Port 1
Port 2
Dip Switches
(See Manual)
USB
Factory Radio
Not Included
GateWay Harness
Part #: PGHGM1
GateWay
Part #: PXAMG
*The GateWay will
only support 2 inputs.
OR
Port 2
HD Radio
OR
iPod Input
OR
SXV100 Tuner
(not included)
Bluetooth
OR
AUX Input
1
1. Introduction
Thank you for purchasing the iSimple® GateWay. The GateWay is designed to
provide endless hours of listening pleasure from your factory radio. To ensure that
your satellite tuner performs correctly with your radio, we recommend that you
read this entire manual before attempting installation of the GateWay.
The GateWay allows connectivity for Sirius/XM Satellite Radio (SXV100 sold
seperately) enabling full control of this device from the factory installed radio.
2. Precautions
PREVENTING DAMAGE TO YOUR VEHICLE
To eliminate the risk of an electrical short, we recommend disconnecting the
vehicle’s battery prior to installation. If you do not feel comfortable making these
connections, we suggest you seek professional installation.
PROPER MOUNTING LOCATION
Securely install the interface in a location free from; heat, humidity, moving parts,
sharp metal edges or direct sunlight. We recommend securing the interface to a
suitable location using; double sided tape, Velcro
TM
or zip-ties.
