ISHIDA UNI-7 series User Manual

User’s Manual
IMPORTANT
Read this manual thoroughly, and do not perform installation, operation, maintenance, or inspection unless you fully understand all of the contents.
Keep this manual in a safe place where you can refer to it easily while installing, operating, and carrying out maintenance or inspections.
RS-61004-11 1.01
© ISHIDA Co., Ltd. 2008 All rights are reserved.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means mechanical, electronic, photocopying, recording, or otherwise without prior written permission of ISHIDA.
NOTICES
NOTICES
IMPORTANT NOTICE
Those who handle the machine must be aware of the hazards involved. These dangers may not be obvious, so it is imperative to follow the instructions detailed in this manual when installing, operating, inspecting, or servicing the machine. Therefore, we recommend that you thoroughly read and understand this manual before installing, operating, inspecting, or servicing the machine. ISHIDA is not liable for any damage, loss or injury that results from incorrect operation, insufficient caution, unauthorized modifications to the machine, or failure to follow the instructions contained in this manual.
LIMITATIONS OF LIABILITY
ISHIDA assumes no responsibility for special, indirect, or consequential damages, loss of profits or commercial loss in any way connected with the machine, whether such claim is based on contract, warranty, negligence, or strict liability. ISHIDA assumes no responsibility for the user's programming of this machine, or any consequence thereof. In no event shall ISHIDA be responsible for warranty, repair, or other claims regarding the machine unless ISHIDA’s analysis confirms that the machines were properly handled, stored, installed, and maintained and not subject to contamination, abuse, misuse, or inappropriate modification or repair.
CHANGE IN SPECIFICATIONS
Machine specifications and accessories may be changed at any time due to improvements or other reasons. Consult with your ISHIDA representative at any time to confirm the actual specifications of the purchased machine.
ERRORS AND OMISSIONS
The information in this manual has been carefully checked and is believed to be accurate; however, no responsibility is assumed for clerical, typographical or proofreading errors, or omissions.
UNI-7 User’s Manual i
PRECAUTIONS FOR SAFE USE
PRECAUTIONS FOR SAFE USE
It is strongly advised that the following safety measures must be observed to ensure the safe operation of the machine.
Prepare a dedicated power source and always use a
power supply with rated voltage. Never connect the machine power input with an AC power supply exceeding the rated voltage. To avoid any potential electrical shock, ensure that the protective ground wire is connected to the main grounding provision.
A power supply that generates voltage variation may cause a malfunction, or using the machine outside of the rated voltage may result in machine failure or danger such as electric shock.
Do not install the machine near a TV set or radio. Doing so may cause static to the TV set and/or radio as
this machine emits week electric wave.
Do not allow water or any liquids to come into
contact with the machine.
Doing so may result in fire or cause the machine to break down.
Do not drop or apply a strong shock to the machine. Doing so may cause the machine to break down.
Do not disassemble, modify, or attempt to repair the
machine.
Doing so may damage the original safety functions.
Do not hold the connector cover when carrying the machine.
Dropping the machine may result in injury or cause the machine to break down.
ii UNI-7 User’s Manual
PRECAUTIONS FOR SAFE USE
Do not hold the operation panel or weigh platter
when carrying the machine.
Doing so may cause the operation panel or the platter to break down.
Do not hold the customer display for the pole type
when carrying the machine.
Dropping the machine may result in injury or cause the machine to break down.
Handle with care when removing or inserting the
cassette.
Careless cassette handling may result in injury or cause the cassette to break down.
Do not drop the cassette. Dropping the cassette may result in injury or cause the
cassette to break down.
Do not press the touch panel with an edged thing.
Doing so may scratch the panel and cause the machine to break down.
Risk of explosion if battery is replaced by an
incorrect type. Make sure to dispose of used batteries according to the instructions.
UNI-7 User’s Manual iii
PRECAUTIONS FOR MACHINE INSTALLATION
PRECAUTIONS FOR MACHINE INSTALLATION
Do not install the machine in the following types of places:
Places subject to high
temperatures or high humidity
Places exposed to direct
sunlight
Places where water or other
liquids are easily spilled on the machine
Places subject to excessive
vibration or unstable foundations
Places exposed to direct cold
air from air conditioners or refrigerators
Places where the floor or
foundation is unstable
Places subject to a lot of
dust or dirt
Places with large voltage
fluctuations
iv UNI-7 User’s Manual
PRECAUTION SYMBOLS
PRECAUTION SYMBOLS
This machine is manufactured for use according to proper procedures by a qualified person and only for the purposes described in this manual. The following conventions are used to indicate and classify precautions depending on the level of danger, or seriousness of potential injury. Always heed the information provided in this manual. Failure to heed precautions can result in personal injury or property damage.
The following precaution symbols are used in this manual.
Indicates a potentially hazardous situation which, if not avoided, may result in serious injury or death. Additionally, there may be significant property damage.
Indicates a potentially hazardous situation where, if not avoided, may result in minor or moderate injury or in property damage.
Indicates reference information for operation.
Indicates the referred page for operation.
UNI-7 User’s Manual v
TABLE OF CONTENTS
TABLE OF CONTENTS
CHAPTER 1 BEFORE USE....................................................................................................1-1
1.1 SPECIFICATIONS...................................................................................................1-1
1.2 MODEL VARIATIONS..............................................................................................1-2
1.3 PART NAMES AND FUNCTIONS............................................................................1-3
1.3.1 FRONT VIEW (BENCH TYPE).................................................................... 1-3
1.3.2 REAR VIEW (BENCH TYPE)......................................................................1-3
1.4 OPERATION PANEL................................................................................................1-4
1.5 ADJUSTMENTS ......................................................................................................1-5
1.5.1 LEVEL ADJUSTMENT (BENCH TYPE)......................................................1-5
1.5.2 OPERATION PANEL ANGLE ADJUSTMENT (BENCH TYPE)...................1-5
1.6 LABEL / RECEIPT ROLL LOADING........................................................................ 1-6
1.7 REMOVING & REPLACING OF WEIGH PLATTER ................................................1-9
1.7.1 REMOVING THE WEIGH PLATTER........................................................... 1-9
1.7.2 REPLACING THE WEIGH PLATTER..........................................................1-9
1.8 CLEANING OF THE MACHINE.............................................................................1-10
1.8.1 CLEANING OF THE THEREMAL HEAD...................................................1-10
1.8.2 CLEANING OF THE LABEL SENSOR...................................................... 1-11
1.8.3 CLEANING OF THE PRINT ROLLER AND PRISM ..................................1-12
1.8.4 PRECAUTIONS WHEN USING CLEANING FLUIDS...............................1-13
1.9 STARTING PROCEDURES...................................................................................1-14
1.9.1 TURNING ON THE POWER.....................................................................1-14
1.9.2 PERFORMING ZERO ADJUSTMENT ......................................................1-15
1.9.3 GETTING BACK TO THE INITIAL SCREEN.............................................1-16
CHAPTER 2 LABEL/RECEIPT ISSUE ...................................................................................2-1
2.1 LABEL ISSUE WITHOUT OPERATOR....................................................................2-1
2.1.1 WEIGHING UNIT PRICE PRODUCTS........................................................2-1
2.1.2 WEIGHING FIXED PRICE PRODUCTS .....................................................2-4
2.1.3 PROCESSING FIXED PRICE PRODUCTS................................................2-7
2.1.4 PROCESSING FIXED WEIGHT/FIXED UNIT PRICE PRODUCTS............ 2-9
2.2 LABEL ISSUE WITH OPERATORS....................................................................... 2-11
2.2.1 WEIGHING UNIT PRICE PRODUCTS...................................................... 2-11
2.2.2 WEIGHING FIXED PRICE PRODUCTS ...................................................2-14
2.2.3 PROCESSING FIXED PRICE PRODUCTS..............................................2-17
2.2.4 PROCESSING FIXED WEIGHT/FIXED UNIT PRICE PRODUCTS.......... 2-19
2.3 RECEIPT ISSUE.................................................................................................... 2-21
CHAPTER 3 TRACEABILITY PRODUCTS............................................................................3-1
3.1 REFERING TO PREVIOUS TRACEABILITY DATA.................................................3-1
3.2 CHANGING TRACEABILITY DATA .........................................................................3-4
vi UNI-7 User’s Manual
TABLE OF CONTENTS
CHAPTER 4 TEMPORARY CHANGE OPERATIONS ........................................................... 4-1
4.1 UNIT PRICE CHANGE ............................................................................................4-1
4.2 FIXED PRICE CHANGE..........................................................................................4-3
4.3 AMOUNT DISCOUNT FOR UNIT PRICE................................................................4-5
4.4 PERCENT DISCOUNT FOR UNIT PRICE ..............................................................4-7
4.5 AMOUNT DISCOUNT FOR TOTAL PRICE.............................................................4-9
4.6 PERCENT DISCOUNT FOR TOTAL PRICE.......................................................... 4-11
4.7 PRODUCT QUANTITY CHANGE.......................................................................... 4-13
4.8 PRINT QUANTITY SETTING.................................................................................4-15
CHAPTER 5 SELF-SERVICE OPERATIONS......................................................................... 5-1
5.1 WEIGHING PRODUCTS ......................................................................................... 5-1
5.2 FIXED PRICE PRODUCTS ..................................................................................... 5-3
CHAPTER 6 ACCUMULATOR MODE ...................................................................................6-1
6.1 MANUAL INPUT ACCUMULATION ......................................................................... 6-1
6.2 WEIGHING ACCUMULATION.................................................................................6-3
6.3 MANUAL INPUT VOID.............................................................................................6-6
6.4 WEIGHING VOID.....................................................................................................6-9
CHAPTER 7 TOTAL ADJUST MODE ....................................................................................7-1
7.1 MANUAL INPUT SUBTRACTION............................................................................ 7-1
7.2 WEIGHING SUBTRACTION....................................................................................7-3
7.3 MANUAL INPUT ADDITION.....................................................................................7-6
7.4 WEIGHING ADDITION ............................................................................................7-9
CHAPTER 8 TOTAL MODE.................................................................................................... 8-1
8.1 DAILY TOTAL...........................................................................................................8-1
8.2 WEEKLY TOTAL ......................................................................................................8-4
8.3 CUMULATIVE TOTAL..............................................................................................8-6
8.4 TRACEABILITY TOTAL ........................................................................................... 8-8
8.5 PRESET REPORT PRINTING.................................................................................8-9
8.6 TOTAL CLEAR....................................................................................................... 8-10
CHAPTER 9 PROGRAM MODE.............................................................................................9-1
9.1 PROGRAM MODE ENTRY......................................................................................9-1
9.2 PLU FILE REGISTRATION...................................................................................... 9-4
9.3 CAMPAIGN LIST REGISTRATION........................................................................9-14
9.4 OPERATOR REGISTRATION................................................................................9-19
9.5 PRESET KEY REGISTRATION............................................................................. 9-22
9.5.1 SETTING PRESET FUNCTIONS..............................................................9-22
9.5.2 ASSIGNING IMAGES ON THE PRESET KEYS .......................................9-25
9.5.3 COLORING PRESET KEYS.....................................................................9-27
9.5.4 CHANGING PRESET KEY SIZES ............................................................9-30
9.5.5 EDITING PRESET KEY NAMES...............................................................9-33
UNI-7 User’s Manual vii
TABLE OF CONTENTS
9.5.6 CONFIRMING PRESET KEY DATA..........................................................9-36
9.5.7 DELETING PRESET KEYS....................................................................... 9-37
9.5.8 MEMBRANE KEYS...................................................................................9-39
9.6 ADVERTISEMENT MESSAGE REGISTRATION..................................................9-42
9.7 STORE NAME REGISTRATION............................................................................9-46
9.7.1 CHANGING EXISTING STORE DATA......................................................9-46
9.7.2 CREATING NEW STORE DATA ............................................................... 9-49
9.8 DEPARTMENT NAME REGISTRATION................................................................9-53
9.8.1 CREATING NEW DEPARTMENT NAMES................................................ 9-53
9.8.2 CHANGING EXISITING DEPARTMENT NAMES .....................................9-57
9.9 GROUP NAME REGISTRATION...........................................................................9-59
9.9.1 CREATING NEW GROUP NAMES........................................................... 9-59
9.9.2 CHANGING EXISITING GROUP NAMES.................................................9-62
9.10 COOKING INSTRUCTION REGISTRATION......................................................... 9-64
9.10.1 CREATING NEW INSTRUCTIONS...........................................................9-64
9.10.2 CHANGING EXISITING INSTRUCTIONS................................................. 9-67
9.11 NUTRITION FILE REIGISTRATION......................................................................9-69
9.11.1 CREATING NEW NUTRITION DATA........................................................9-69
9.11.2 CHANGING EXISTING NUTRITION DATA............................................... 9-72
9.12 EXTRA MESSAGE REGISTRATION.....................................................................9-75
9.12.1 CREATING NEW MESSAGES.................................................................. 9-75
9.12.2 CHANGING EXISITING MESSAGES .......................................................9-78
9.13 COUPON MESSAGE REGISTRATION.................................................................9-80
9.13.1 CREATING NEW MESSAGES.................................................................. 9-80
9.13.2 CHANGING EXISITING MESSAGES .......................................................9-83
9.14 POP MESSAGE REGISTRATION......................................................................... 9-85
9.15 TAX REGISTRATION.............................................................................................9-87
9.16 SCHEME TABLE REGISTRATION........................................................................9-88
9.16.1 CREATING NEW TABLES........................................................................9-88
9.16.2 CHANGING EXISITING MESSAGES .......................................................9-92
9.17 GEN TABLE REGISTRATION................................................................................9-96
9.18 LOOKUP TABLE REGISTRATION ........................................................................9-99
9.18.1 CREATING NEW TABLES........................................................................9-99
9.18.2 CHANGING EXISITING TABLES............................................................9-106
9.19 MINCE TRACEABILITY REGISTRATION ........................................................... 9-110
9.20 FIXED PRICE MARK REGISTRATION ................................................................9-111
9.20.1 CREATING NEW PRICE MARKS............................................................9-111
9.20.2 CHANGING EXISITING PRICE MARKS................................................. 9-113
9.21 FREE MESSAGE REGISTRATION..................................................................... 9-115
9.21.1 CREATING NEW MESSAGES................................................................ 9-115
9.21.2 CHANGING EXISITING MESSAGES ..................................................... 9-118
9.22 CHECK LABEL REGISTRATION......................................................................... 9-120
viii UNI-7 User’s Manual
TABLE OF CONTENTS
CHPATER 10 SETUP MODE.................................................................................................. 10-1
10.1 SETUP MODE ENTRY..........................................................................................10-1
10.2 MACHINE NUMBER SETTING .............................................................................10-3
10.3 SALES MODE SETTING.......................................................................................10-4
10.4 PASSWORD SETTING.......................................................................................... 10-5
10.5 KEY LOCK SETTING ..........................................................................................10-10
10.6 DATA STORAGE SETTING................................................................................. 10-14
10.7 PRESET REPORT SETTING ..............................................................................10-15
10.8 AUTO PROGRAM SETTING...............................................................................10-19
10.9 DEFAULT DATA SETTING................................................................................... 10-21
10.10 PLU UPDATE SETTING...................................................................................... 10-29
10.1 1 RECEIPT SETTING.............................................................................................10-35
CHAPTER 11 ADJUSTMENT MODE .....................................................................................11-1
11.1 ADJUSTMENT MODE ENTRY.............................................................................. 11-1
11.2 DATE / TIME ADJUSTMENT................................................................................. 11-2
11.3 TOUCH PANEL ADJUSTMENT............................................................................. 11-4
11.4 DISPLAY CHECK .................................................................................................. 11-6
APPENDIX TEXT EDITING...................................................................................................A-1
A.1 OPERATION PANEL AND KEY FUNCTIONS.........................................................A-1
A.2 NORMAL CHARACTER EDITING...........................................................................A-3
A.3 SPECIAL CHARACTER EDITING...........................................................................A-6
A.4 LINE DELETION......................................................................................................A-8
A.5 CHARACTER DELETION........................................................................................A-9
A.6 CHARACTER BACKSPACING..............................................................................A-11
UNI-7 User’s Manual ix
Chapter 1 BEFORE USE
1
BEFORE USE
1.1 SPECIFICATIONS
Items Descriptions
Use conditions
Temperature: 5 to 35°C
Humidity: 30 to 85%, Non condensing. Power supply: AC100 – 240V, 50 / 60Hz Power consumption 1.0A/0.5A Weight Bench type: Approx.11.5 kg
Pole type: Approx.12.5 kg Weighing capacity 15 kg: 0 to 6/0.002 kg, 6 to 15/0.005 kg Weighting accuracy 1/3000 Operator/Customer display 7.0 inch color liquid crystal with back light, 480 X 234dots Printing method Direct thermal method Thermal head 2 inches (448dots) and 8 dots/mm Printing speed 100mm/second, 120mm/second
Note: The printing speed may vary according to label conditions.
Printing effective size 56mm Label size Label width: 30mm to 60mm
Label length: 20mm to 150mm Number of label cassettes 7 cassettes Input/Output LAN 1 channel
USB 1 channel
CF 1 channel
Drawer 2 channels Program store medium Flash ROM (32M bytes)
UNI-7 User’s Manual 1-1
Chapter 1 BEFORE USE
1.2 MODEL VARIATIONS
Bakery Type
Bench Type
Pole Type
Elevated Type
Self-service Type
Hanging Type
1-2 UNI-7 User’s Manual
Chapter 1 BEFORE USE
1.3 PART NAMES AND FUNCTIONS
1.3.1 FRONT VIEW (BENCH TYPE)
1.3.2 REAR VIEW (BENCH TYPE)
UNI-7 User’s Manual 1-3
Chapter 1 BEFORE USE
1.4 OPERATION PANEL
Keys for Usual Use
Used to delete an entered numerical value.
Used to display Menu Select screen.
Used to call a registered product data.
Used to turn the previous page.
Used to feed labels.
Used to turn the next page.
Used to issue a label.
Used to jump to the top page.
Used to enter tare weight.
Used to jump to the end page.
Used to reset a weigh to zero.
Used to escape from the current mode.
1-4 UNI-7 User’s Manual
Chapter 1 BEFORE USE
1.5 ADJUSTMENTS
  
1.5.1 LEVEL ADJUSTMENT (BENCH TYPE)
Install the machine horizontally to use.
Be sure to turn off the power switch before placing the machine on a stable platform, and adjust the machine inclination by turning the four level adjustment feet so that the bubble is located at the center of the level gauge. Accurate measurements cannot be performed if it is not installed horizontally.
1.5.2 OPERATION PANEL ANGLE ADJUSTMENT (BENCH TYPE)
To obtain a better view, adjust the angle of the operation panel within the range between 0 and 70 degrees.
UNI-7 User’s Manual 1-5
Chapter 1 BEFORE USE
1-6 UNI-7 User’s Manual
1.6 LABEL / RECEIPT ROLL LOADING
1.
Pull out the cassette from the main body.
Before pulling out the cassette unit, ensure that nothing is placed on the weigh platter.
2.
Set a new roll around the roll holder and raise the roll stopper to fix the roll position.
3.
Thread the paper as shown in the figures below..
Chapter 1 BEFORE USE
4
For labels, fix the paper end with the backing paper stopper, and gently turn the winding bobbin counterclockwise until the label becomes tight.
5.
Slide the label/receipt guide to help smooth paper feeding according to the paper width.
UNI-7 User’s Manual 1-7
Chapter 1 BEFORE USE
1-8 UNI-7 User’s Manual
6.
Push the cassette straight into the main body to return to its original position.
yBefore inserting the cassette unit into the main body, ensure that nothing sticks to the
magnet on the bottom of the cassette unit.
yPush the cassette slowly into the main body so as not to get your fingers caught.
7.
For labels, press the [FEED] key on the key sheet to issue a label. At this time, confirm that the label is completely peeled off.
Confirm that the backing paper is wound up smoothly. If the backing paper is wound up diagonally, check that the label is set correctly.
Chapter 1 BEFORE USE

1.7 REMOVING & REPLACING OF WEIGH PLATTER
1.7.1 REMOVING THE WEIGH PLATTER
When removing the weigh platter from the main body, lift the front side to pull out the two pins from the two rubber platter holders and remove the platter by pulling it to disengage the two hooks at the rear side of the platter.
1.7.2 REPLACING THE WEIGH PLATTER
When replacing the weigh platter onto the main body, engage the two hooks at the rear side of the platter and lower the platter so that the two pins on the bottom of the platter are inserted into holes of the rubber platter holders.
UNI-7 User’s Manual 1-9
Chapter 1 BEFORE USE
1-10 UNI-7 User’s Manual
1.8 CLEANING OF THE MACHINE
1.8.1 CLEANING OF THE THEREMAL HEAD
1.
Pull out the cassette from the main body.
Before pulling out the cassette unit, ensure that nothing is placed on the weigh platter.
2.
Use a cotton-tipped swab to clean off the thermal head.
Chapter 1 BEFORE USE
1.8.2 CLEANING OF THE LABEL SENSOR
1.
Pull out the cassette from the main body.
Before pulling out the cassette unit, ensure that nothing is placed on the weigh platter.
2.
Use a dry cloth to clean off the emitter and receiver of the label sensor.
UNI-7 User’s Manual 1-11
Chapter 1 BEFORE USE
1-12 UNI-7 User’s Manual
1.8.3 CLEANING OF THE PRINT ROLLER AND PRISM
1.
Pull out the cassette from the main body.
Before pulling out the cassette unit, ensure that nothing is placed on the weigh platter.
2.
Use a dry cloth to clean off the print roller and prism.
Chapter 1 BEFORE USE
1.8.4 PRECAUTIONS WHEN USING CLEANING FLUIDS
Use a soft cloth and a neutral detergent to clean the machine. Do not use thinner, benzene, etc. Doing so may damage the original safety functions. For some parts, use cleaning fluid (isopropyl alcohol).
Do not use cleaning fluid near fire as the fluid is flammable.
Do not use cleaning fluid in a poorly ventilated area. Always provide adequate
ventilation when cleaning.
Take the following actions in the event of an accident:
If the fluid gets in your eye  Immediately wash your eye(s) with water for at least 15 minutes, and consult your
doctor.
If you wear contact lenses, remove and wash them.
If the fluid comes into contact with your skin  Immediately rinse the area of contact with water, and then wash with soap.
If you notice any skin abnormalities at the area of contact, or if any pain persists,
consult your doctor.
If the fumes of the fluid are inhaled  Immediately move the victim to an area where fresh air is available, and have the
victim lie down and keep warm.
If breathing becomes difficult or stops, provide artificial respiration and seek medical
attention immediately.
If the fluid is swallowed  Do not try to induce vomiting.
Do not give the victim anything to drink, and do not rinse the mouth. If vomiting occurs naturally, have the victim lean forward to reduce risk of aspiration. Keep the victim warm and seek medical attention.
UNI-7 User’s Manual 1-13
Chapter 1 BEFORE USE
1.9 STARTING PROCEDURES
1.9.1 TURNING ON THE POWER
1.
Push down the "I” side of the Power Switch to turn on the power.
2.
The Time Check screen appears. Then, check that displayed date and time agree with current date and time, and press the [ENTER] button on the screen to proceed to the next step.
Note: Refer to “Time/Date Set” menu in Adjust Mode when changing the date or time.
3.
After a while, the initial screen appears.
21-JUN-2007
11:13:38
1-14 UNI-7 User’s Manual
Chapter 1 BEFORE USE
1.9.2 PERFORMING ZERO ADJUSTMENT
1.
If the weight value is not zero on the initial screen,
Press the [ZERO] key on the key sheet to perform zero weight adjustment.
2.
The “ZERO” indicator lights up and the weight value becomes zero.
UNI-7 User’s Manual 1-15
Chapter 1 BEFORE USE
1.9.3 GETTING BACK TO THE INITIAL SCREEN
1.
To get back to the initial screen from a Menu Select screen, press either the “SALES” field or the icon at the bottom right on the screen.
2.
The initial screen appears.
   
1-16 UNI-7 User’s Manual
Chapter 2 LABEL/RECEIPT ISSUE
2
LABEL/RECEIPT ISSUE
2.1 LABEL ISSUE WITHOUT OPERATOR
 
2.1.1 WEIGHING UNIT PRICE PRODUCTS
1.
Ensure that the initial screen is displayed.
 
2.
Enter a desired PLU number using the numeric keys and press the [PLU] key on the key sheet, or simply press a preset key on the screen where the product is allocated.
EXAMPLE PLU No.6 “Roast Beef”
Î
or
3.
When the product is preset as a traceable item, the traceability screen appears. See section 2.3 for more details about traceability products.
4.
The selected PLU screen appears.
Without Preset Tare Weight
Uni-7 User’s Manual 2-1
Chapter 2 LABEL/RECEIPT ISSUE
With Preset Tare Weight
Manual Tare Entry
To newly enter a tare weight or overwrite an existing tare weight, enter the tare weight using the numeric keys and press the “TARE” field on the screen.
EXAMPLE Tare weight “50g”
 
5.
See section 2.4 for Temporary Change Operations.
6.
Put a product on the weigh platter.
The weight is measured and the total price is calculated.
2-2 Uni-7 User’s Manual
Chapter 2 LABEL/RECEIPT ISSUE
7.
When “MANUAL” is set in the Print Mode,
Press the [PRINT] key on the key sheet.
The label is issued.
Non-traceable products Traceable products
When “AUTO” is set in the Print Mode,
The label is automatically issued as soon as the weighing is stabilized.
Non-traceable products Traceable products
Uni-7 User’s Manual 2-3
Loading...
+ 255 hidden pages
