IRIS 3030, 3020, 3010 User Manual

Download

IRIS Series 3000

Owner’s Guide

Version 1.1

Silicon Graphics, Inc.

2011 Stierlin Road

Mountain View, CA 94043

Technical Publications:

Marcia Allen Robin Florentine Susan Luttner Celia Szente Diane M. Wilford

Illustrations:

Anna Szabados

Special thanks to Herb Kuta, Donl Mathis, and Rick McLeod.

This document contains proprietary information of Silicon Graphics, Inc., and is protected by Federal copyright law. The information may not be disclosed to third parties or copied or duplicated in any form, in whole or in part, without prior written consent of Silicon Graphics, Inc.

The information in this document is subject to change without notice.

IRIS Series 3000 Owner’s Guide Document numbers: 007-5220-010, 007·5220-011

Un i x is a trademark of AT&T Bell laboratories. Ethernet and XNS are trademarks of Xerox Corporation. Geometry Engine is a trademark of Silicon Graphics, Inc. VAX is a trademark of Digital Equipment Corporation.

User Information

Please read the following information on product safety and interference potential.

Computer and CRT:

WARNING - For continued protection against risk of fire, replace fuses only with the same type and rating of fuse.

No operator-serviceable parts inside unit.

Class A Computing Device

WARNING: This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instruction manual, may cause interference to radio communications. It has been tested and found to comply with the limits for a Class A computing device pursuant to Subpart J of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment. Operation of this equipment in a residential area is likely to cause interference in which case the user at his own expense will be required to take whatever measures may be required to correct the interference (FCC, Part

15.818 a).

Instructions to User

This equipment generates and uses radio frequency energy and if not installed and used properly, ie., in strict accordance with the operating instructions, reference manuals, and the service manual, may cause interference to radio or television reception. It has been tested and found to comply with the limits for a Class A computing device pursuant to Subpart J of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial installation.

If this equipment does cause interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1. Reorient the receiving antenna.

2. Relocate the equipment with respect to the receiver.

3. Move the equipment away from the receiver.

4. Plug the equipment into a different outlet so that equipment and receiver are on different branch circuits.

If necessary, consult a Silicon Graphics field engineer for additional suggestions.

Silicon Graphics is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. It is the responsibility of the user to correct such interference.

List of Figures

Figure Page

IRIS Series 3000 System 2-3 IRIS 3030 Cabinet Front Panel (IRIS 3020 Similar) 2-4 IRIS 3010 Cabinet Front Panel 2-5 IRIS Cabinet Connections - Nineteen-inch 60 Hz Monitor 2-7 IRIS Cabinet Connections - Fifteen-inch 60 Hz Monitor 2-9 IRIS Cabinet Connections - 33 Hz Monitor 2-10 Monitor Control Panel for Nineteen-inch 60 Hz Monitor 2-12 Monitor Control Panel for Fifteen-inch 60 Hz Monitor 2-13 Monitor Control Panel for 33 Hz Monitor 2-14

IRIS Configuration Switches 3-2 Sample IRIS Boot Information 3-6

Sample /etc/passwd File 4-4 Sample /etc/group File 4-6

Standard I/O Panel and Auxiliary I/O Panel 7-2 Sample /etc/ttytype File 7-3 Sample /etc/inittab File 7-4 Sample /etc/gettydefs File 7-5

Monitor Back Panel for Nineteen-inch 60 Hz Monitor A-6 Monitor Back Panel for Fifteen-inch 60 Hz Monitor A-7 Monitor Back Panel for 33 Hz Interlaced Monitor A-8 IRIS Cabinet Back Panel A-11

List of Tables

Table Page

IRIS Configuration Switches 3-9 PROM Monitor Commands 3-11 Boot Devices 3-11

Special Device Files in /dev 4-11, 4-12 Approximate Tape Capacities for Backups 4-21 Sample Tape Drive Commands 4-22 Files Critical to Un i x Operation 4-27

Disk Partition Sizes 6-2 Disk Storage Requirements 6-3 Two Ways to Configure a Second Disk 6-9

Serial Device Names 7-2 Cartridge Tape Drive Specifications 7-18 Pin Definitions for Modem Cable 7-20 Pin Definitions for a Null Modem Cable 7-20 Simplified Null Modem Pin Definitions for Printers 7-21 Three-wire Null Modem for Terminals 7-22 Summary of Cable Types 7-22

Primary and Secondary Video Options 8-1

IRIS Component Specifications A-2 IRIS Environmental Specifications A-12

Device Abbreviations B-1

CONTENTS

1. Road Map .............................................. 1-1

1.1 Installation Overview ............................... 1-1

1.2 IRIS Series 2000 Turbo Products ....................... 1-2

1.3 Product Support .................................... 1-2

1.4 Conventions ....................................... 1-2

2. Hardware Installation .................................... 2-1

2.1 Hardware Components .............................. 2-1

2.2 Keyboard and Mouse Connection ..................... 2-6

2.3 Monitor to Cabinet Video Connections ................. 2-6

2.3.1 Nineteen-inch 60 Hz Non-interlaced

Monitor ..................................... 2-6

2.3.2 Fifteen-inch 60 Hz Non-interlaced

Monitor ..................................... 2-8

2.3.3 33 Hz Interlaced Monitor ....................... 2-8

2.4 Monitor Adjustment ................................ 2-11

2.5 Monitor AC Power Cable Connection .................. 2-15

2.6 Cabinet AC Power Connection ........................ 2-15

2.7 IRIS to Ethernet Connection .......................... 2-15

3. Booting the IRIS ......................................... 3-1

3.1 Workstation Booting Instructions ...................... 3-1

3.2 Terminal Booting Instructions ........................ 3-4

3.3 The Startup Environment ............................ 3-5

3.4 Boot Options ...................................... 3-8

3.4.1 PROM Monitor Boot ........................... 3-9

3.4.2 Automatic Boot ............................... 3-12

4. Workstation System Administration ......................... 4-1

4.1 Basic Operation and Shutdown ....................... 4-1

4.2 Un i x Configuration ................................. 4-2

4.2.1 Naming an IRIS Workstation .................... 4-3

4.2.2 Adding a New Account ........................ 4-3

4.2.3 Entering Multi-user Mode

Automatically ................................ 4-8

4.2.4 Un i x Configuration Files ....................... 4-8

4.2.5 Device Files .................................. 4-11

4.3 Network Communication ............................ 4-13

4.3.1 XNS Network Commands ...................... 4-13

4.3.2 TCP/IP Network Commands .................... 4-14

4.3.3 Using Multiple Kernels ........................ 4-19

4.4 Backups .......................................... 4-19

4.4.1 Making a Bootable Backup Tape ................. 4-20

4.4.2 Making Periodic Backups ....................... 4-21

- i -

4.4.3 Storing Key Un i x Files on a Second

Disk ........................................ 4-25

4.5 Crash Recovery .................................... 4-26

4.5.1 Recovery Strategies ............................ 4-27

4.5.2 Recovery with init ............................. 4-28

4.5.3 Recovery by Booting from Tape .................. 4-29

4.5.4 Recovery by Booting from the Second

Disk ........................................ 4-33

5. IRIS 3010 System Administration ........................... 5-1

5.1 Host Software Installation ........................... 5-1

5.2 Operation ......................................... 5-3

5.2.1 Connecting to the Host ......................... 5-3

5.2.2 Issuing Commands to the Terminal

Emulator .................................... 5-4

5.2.3 Running a Demonstration Program ............... 5-6

5.2.3 Shutting Down the IRIS Terminal ................ 5-7

5.2.4 Boot Failure Recovery .......................... 5-7

5.3 Software Configuration .............................. 5-8

5.3.1 Configuration Tools ........................... 5-8

5.3.2 Configuring the Startup Environment ............ 5-10

5.3.3 XNS Configuration ............................ 5-14

5.3.4 TCP/IP Configuration ......................... 5-14

5.3.5 Miscellaneous Un i x Configuration ............... 5-15

6. Disk Configuration ....................................... 6-1

6.1 Disk Specifications ................................. 6-2

6.2 IRIS Workstation Disk Configuration .................. 6-3

6.2.1 Changing the Swap Partition Size on an IRIS

3020 ........................................ 6-4

6.2.3 Changing the Swap Partition Size on an IRIS

3030 ........................................ 6-6

6.2.4 Configuring a Second Disk on an IRIS

Workstation .................................. 6-9

6.3 IRIS Terminal Disk Configuration ..................... 6-13

6.3.1 Changing the Swap Partition Size on an IRIS

Terminal ..................................... 6-13

6.3.2 Creating and Using a Backup Floppy

Set .......................................... 6-17

7. Optional Peripherals ..................................... 7-1

7.1 ASCII Terminal .................................... 7-1

7.1.1 Connecting an ASCII Terminal to the

IRIS ......................................... 7-1

7.1.2 Configuring Software for an ASCII Terminal

Connection .................................. 7-3

7.2 Dial and Button Box ................................ 7-5

- ii -

7.2.1 Connecting the Dial and Button Box to the

IRIS ......................................... 7-5

7.2.2 Configuring Software for the Dial and Button

Box Connection ............................... 7-6

7.3 Modem (IRIS Workstation Only) ...................... 7-7

7.3.1 Connecting a Modem to the

Workstation .................................. 7-7

7.3.2 Configuring Software for a Modem

Connection .................................. 7-7

7.4 Serial Printer ...................................... 7-10

7.4.1 Connecting a Printer to the IRIS ................. 7-10

7.4.2 Configuring the Software for a Printer

Connection .................................. 7-10

7.5 Color Graphics Printer .............................. 7-13

7.5.1 Connecting the Color Graphics Printer to the

IRIS ......................................... 7-13

7.5.2 Using the Color Graphics Printer ................ 7-13

7.6 Digitizer Tablet .................................... 7-14

7.6.1 Connecting the Digitizer Tablet to the

IRIS ......................................... 7-15

7.6.2 Configuring Software for a Digitizer

Tablet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-16

7.6.3 Using a Digitizer Tablet ........................ 7-17

7.7 Tape Drives (IRIS Workstation Only) ................... 7-17

7.7.1 Half-inch Tape Drive .......................... 7-17

7.7.2 Quarter-inch Cartridge Tape Drive ............... 7-18

7.8 Floppy Disk Drive .................................. 7-18

7.9 Stereo Optic Viewer ................................. 7-19

7.9.1 Connecting the Stereo Optic Viewer to the

IRIS ......................................... 7-19

7.10 Serial Port Cabling .................................. 7-19

8. Video Options ........................................... 8-1

8.1 Supported Options ................................. 8-2

8.1.1 60 Hz Non-interlaced Monitor ................... 8-2

8.1.2 33 Hz Interlaced Monitor ....................... 8-2

8.1.3 RS-170A ..................................... 8-2

8.1.4 European Video Standard ...................... 8-2

8.1.5 Genlockable RS-170A or European Video

Standard .................................... 8-3

8.2 Booting with the Secondary Video Driver ............... 8-4

8.3 Using the Graphics Library with the Video Options ....... 8-4

9. Demonstration Programs and Gifts ......................... 9-1

9.1 Demonstration Programs ............................ 9-1

9.1.1 Running Demonstration Programs ............... 9-1

- iii -

9.1.2 Using the Mouse with the Window

Manager ................................... 9-2

9.1.3 Window Manager Demonstration

Programs .................................. 9-2

9.2 Gifts ............................................ 9-9

Appendix A: IRIS Specifications ..................................... A-1

A.1 Cables .......................................... A-2

A.2 Monitor ......................................... A-2

A.2.1 60 Hz Non-interlaced Monitors ................ A-2

A.2.2 33 Hz Interlaced Monitor ..................... A-2

A.2.3 Monitor Control Panel ....................... A-2

A.2.4 Monitor Back Panel .......................... A-2

A.3 IRIS Electronics Cabinet ........................... A-9

A.3.1 Power Switch ............................... A-9

A.3.2 Optional Tape Drives ........................ A-9

A.3.3 Standard I/O Panel .......................... A-9

A.3.4 Cabinet Power Panel ......................... A-10

A.4 Site Selection .................................... A-12

Appendix B: System Messages ....................................... B-1

B.1 Hardware Error Messages .......................... B-2

B.1.1 General Hardware Error Messages ............. B-2

B.1.2 Disk Controller Messages ..................... B-2

B.1.3 Tape Drive Messages ......................... B-3

B.1.4 Floppy Controller Messages ................... B-4

B.2 System Software Messages ......................... B-4

- iv -

1. Road Map

This document explains how to install and test IRIS series 3000 products, and how to perform system administration. Read this document carefully before installing your IRIS.

1.1 Installation Overview

The table below summarizes the procedures for installing IRIS series 3000 products.

To complete this procedure: See Chapter/Section:

Install hardware

Install optional peripherals, including ASCII terminals

Install non-standard video monitors

Boot the IRIS workstation

Boot the IRIS terminal

Configure software (IRIS workstation)

Configure software (IRIS terminal)

Configure disk

Chapter 2

Chapter 7

Chapter 8

Section 3.1

Section 3.2

Chapter 4

Chapter 5

Chapter 6

Version 1.1 SERIES 3000

For basic information about Un i x commands, the Un i x text editor, and navigating the file system, see the pamphlet entitled Getting Started with Your IRIS Workstation.

1.2 IRIS Series 2000 Turbo Products

This manual is applicable to the IRIS 2300T (3010 equivalent), 2400T (3020 equivalent), and 2500T. Early IRIS series 2000 models with the Turbo upgrade may not have the same standard peripherals described here. The 60 Hz monitor may be different from the one described in this guide. The mouse may be mechanical rather than optical. The early IRIS 2400 Turbo system required a separate junction box. For a description of these features, see the IRIS Workstation Guide Series 2000, Version 1.0.

1.3 Product Support

Silicon Graphics provides a comprehensive product support and maintenance program for IRIS series 3000 products. For further information, contact Customer Service through the Geometry Hotline

Silicon Graphics Geometry Hotline

(800) 252-0222 U.S. except California (toll-free)

(800) 345-0222 California (toll-free)

(800) 443-0222 Canada

1.4 Conventions

This document uses the standard Un i x convention for referring to entries in the Un i x documentation. The entry name is followed by a section number in parentheses. For example, cc(1) refers to the cc manual entry in Section 1 of the Un i x Programmer’s Manual, Volume I.

In command syntax descriptions and examples, square brackets surrounding an argument indicate that the argument is optional. Words in italics represent variable parameters, which should be replaced with the string or value appropriate for the application.

In text descriptions, filenames and Un i x commands are written in italics. IRIS Graphics Library and PROM monitor commands are written in typewriter font.

1-2 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.1

Road Map

2. Hardware Installation

This chapter describes how to install and connect the standard components of the IRIS 3000 series systems (see Figure 2-1).

WARNING

Do not connect the IRIS to an external power source until each cable has been connected and checked.

2.1 Hardware Components

The typical configuration for IRIS series 3000 systems includes these components:

• Electronicscabinetwithonediskdrive

•Nineteen-inch tilt-and-swivel 60 Hznon-interlaced monitor (standard) or

fifteen-inch tilt-and-swivel 60 Hz non-interlaced monitor

• Keyboardwithright-handandleft-handconnectorsforthemouse

•Opticalmousewithgridpad

•Ethernettransceiver

For a more detailed description of the components, see Appendix A.

The IRIS 3000 series products can also be ordered with these hardware options:

• Dialandbuttonbox

• 33Hzinterlacedmonitor

•Digitizertablet

• Tektronix4692colorprinter

•Half-inchtapedrive

• Quarter-inchcartridgetapedrive

•Stereoopticviewercable

• Floppydiskdrive(standardontheIRIS3010)

•Additionalharddiskdrive

Version 1.0 SERIES 3000

2-2 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Hardware Installation

This manual is applicable to the IRIS 2300T, 2400T, and 2500T. Early IRIS series 2000 models with the Turbo upgrade may not have the same standard peripherals described here. The 60 Hz monitor may be different from the one described in this guide. The mouse may be mechanical rather than optical. The early IRIS 2400 Turbo system required a separate junction box. For a description of these features, see the IRIS Workstation Guide Series 2000, Version

1.0.

To install optional peripherals, see Chapter 7.

The major components have the following functions and features:

•Theelectronics cabinet for the standard configuration of the IRIS series 3000 is a floor-standing unit with a 20-slot backplane, a disk drive, and a power supply (see Figure 2-1). The cabinet uses forced-air cooling and is mounted on casters. A quarter-inch cartridge tape drive (internal) or a half-inch streaming tape drive (external) is optional on the IRIS workstation (see Figure 2-2). A floppy disk drive is standard on the IRIS terminal (see Figure 2-3). See Chapter 6 for disk specifications and Chapter 7 for tape specifications.

•Threetypesofmonitor are available from Silicon Graphics for the IRIS series

3000. The fifteen-inch and nineteen-inch tilt-and-swivel monitors are 60 Hz high-resolution RGB color monitors. Silicon Graphics also offers a 33.43 Hz nineteen-inch interlaced monitor. (This monitor will be referred to as 33 Hz rather than 33.43 Hz.)

The IRIS series 3000 can also be ordered with drivers for other types of

monitors (see Chapter 8, Video Options).

•Thekeyboard is an 83-key, up-down encoded keyboard, with right-hand and left-hand connectors for the optical mouse.

•Themouse is a three-button optical mouse with a grid pad.

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 2-3 Hardware Installation

Figure 2-1: IRIS Series 3000 System

2-4 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Hardware Installation

Figure 2-2: IRIS 3030 Cabinet Front Panel (IRIS 3020 Similar)

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 2-5 Hardware Installation

Figure 2-3: IRIS 3010 Cabinet Front Panel

2-6 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Hardware Installation

2.2 Keyboard and Mouse Connection

Connect the mouse to the keyboard by inserting the mouse cable in either the right-hand or left-hand nine-pin D connector in the keyboard. Secure the mouse connector to the keyboard with the two retaining screws on the connector. Connect the keyboard to the IRIS by inserting the keyboard cable into

Port 1

of the standard I/O panel on the IRIS.

2.3 Monitor to Cabinet Video Connections

The procedure for connecting the monitor to the IRIS is different for each type of monitor.

2.3.1 Nineteen-inch 60 Hz Non-interlaced Monitor

Use the color-coded coaxial video cables to connect the monitor to the cabinet (see Figure 2-4).

1. If you are using only one monitor, plug the terminators into the unused video connectors. The terminators are attached to the monitor by chains.

To connect several monitors in a series (daisy chain), remove the

terminators from all but the last monitor. Plug the terminators on the last monitor into the unused video input sockets.

Attach the outgoing video cables to the unused BNC connectors on

the back of the monitor.

2. Connect each color-coded cable end to the corresponding input socket on the monitor back panel.

Push each cable into its connector and rotate to lock into place.

3. Connect the other end of each color-coded cable to the corresponding output socket on the standard I/O panel.

Push each cable into the connector and rotate to lock into place.

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 2-7 Hardware Installation

Figure 2-4: IRIS Cabinet Connections

Nineteen-inch 60 Hz Non-interlaced Monitor

2-8 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Hardware Installation

2.3.2 Fifteen-inch 60 Hz Non-interlaced Monitor

Use the color-coded coaxial video cables to connect the monitor to the cabinet (see Figure 2-5).

1. If you are using only one monitor, set all of the input impedance switches on the back of the monitor to the

75 Ω

position. The input impedance switches are push-button switches located between the input sockets. IN is the

75 Ω

position.

OUT

is the

High

position.

To connect several monitors in a series (daisy chain), set the input

impedance switches to the

High

position for all but the last monitor,

which should be set to the

75 Ω

position.

Attach the outgoing video cables to the unused BNC connectors on

the back of the monitor.

2. Connect each color-coded cable end to the corresponding input socket on the monitor back panel.

Push each cable into its connector and rotate to lock into place.

3. Connect the other end of each color-coded cable to the corresponding output socket on the standard I/O panel.

Push each cable into the connector and rotate to lock into place.

2.3.3 33 Hz Interlaced Monitor

Use the color-coded coaxial video cables to connect the monitor to the cabinet (see Figure 2-6).

1. If you are using only one monitor, set all of the input impedance switches on the back of the monitor to the

75 Ω

position.

To connect several monitors in a series (daisy chain), set the input

impedance switches to the

High

position for all but the last monitor,

which should be set to the

75 Ω

position.

Attach the outgoing video cables to the unused BNC connectors on

the back of the monitor.

2. Connect each color-coded cable end to either one of the corresponding input sockets on the monitor back panel.

Push each cable into its connector and rotate to lock into place.

3. Connect the other end of each color-coded cable to the corresponding output socket on the standard I/O panel.

Push the cable into the connector and rotate to lock into place.

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 2-9 Hardware Installation

Figure 2-5: IRIS Cabinet Connections

Fifteen-inch 60 Hz Non-interlaced Monitor

2-10 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Hardware Installation

Figure 2-6: IRIS Cabinet Connections

33 Hz Interlaced Monitor

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 2-11 Hardware Installation

2.4 Monitor Adjustment

The monitor control panel on the right side of the monitor allows the characteristics of the monitor to be adjusted.

The nineteen-inch monitors (60 Hz and 33 Hz) have two knobs labeled

Brightness

and

Contrast

, and a button labeled

Degauss

(see Figures 2-7 and

2-9).

The fifteen-inch monitor has two recessed dials labeled

Brightness

and

Contrast

, and a button labeled

Degauss

(see Figure 2-8).

NOTE: Color rendering and stability may drift for the first 45 minutes after powerup.

1. After the monitor has warmed up, turn the

Brightness

and Contrast

controls to the maximum (clockwise) setting.

2. Turn the

Brightness

control down until the gray raster just disappears in relation to the black area at the edge of the screen. Lighter brightness settings impair image sharpness and color fidelity.

3. After the

Brightness

control has been set, adjustment of the

Contrast

control is a matter of personal taste.

4. If the color purity or convergence appear to be out of adjustment, hold down the

Degauss

button on the monitor control panel for about five seconds and then release it. The image should improve noticeably.

Once the nineteen-inch 60 Hz monitor has been adjusted, the

Brightness

and

Contrast

knobs can be pushed in: so that they are

flush with the surface of the monitor.

2-12 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Hardware Installation

Figure 2-7: Monitor Control Panel for

Nineteen-inch 60 Hz Non-interlaced Monitor

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 2-13 Hardware Installation

Figure 2-8: Monitor Control Panel for

Fifteen-inch 60 Hz Non-interlaced Monitor

2-14 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Hardware Installation

Figure 2-9: Monitor Control Panel for

33 Hz Interlaced Monitor

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 2-15 Hardware Installation

2.5 Monitor AC Power Cable Connection

Plug the monitor into a 120/240 VAC outlet.

1. Connect the female end of the AC power cable to the

Input

power

socket on the monitor back panel.

2. Connect the male end of the monitor power cable to a wall outlet.

2.6 Cabinet AC Power Connection

The cabinet power socket is located on the cabinet power panel (see Figure A-4).

CAUTION

Do not connect the IRIS to a switched power outlet.

1. Connect the female end of the AC power cable to the power socket labeled

Power

on the cabinet power panel.

2. Connect the male end of the cabinet power cable to an appropriate outlet. See Appendix A, IRIS Specifications, for the IRIS power requirements.

2.7 IRIS to Ethernet Connection

The IRIS can communicate with other hosts and terminals (that have the necessary communication software) through an Ethernet local area network. The IRIS can be connected to an Ethernet local area network while the network is operating.

To connect the IRIS to an Ethernet local area network, you need:

•AnEthernet transceiver to attach to the Ethernet.

• One 75-foot, 15-conductor drop cable to connect the IRIS cabinet to the

Ethernet transceiver.

The Ethernet port is located on the standard I/O panel, on the back of the cabinet.

To connect the Ethernet cable to the cabinet, follow these steps:

1. Connect the male end of the drop cable to the Ethernet port, labeled

Ethernet

on the standard I/O panel. Use the slide lock to secure

the cable in the connector.

2. Select an appropriate tap point on the Ethernet coaxial cable.

2-16 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Hardware Installation

NOTE: Approved Ethernet coaxial cable is

marked with rings at 2.5-meter intervals (minimum distance). Transceivers should be placed at these rings to minimize transceiver reflection, which can induce transmission errors.

Tap into the Ethernet cable (instructions are included with each

transceiver) .

3. Connect the transceiver to the Ethernet cable.

4. Connect the female end of the drop cable to the transceiver.

3. Booting the IRIS

This chapter contains step-by-step procedures for booting and checking out a new IRIS system. This chapter also describes the bootstrap options and the startup environment for the IRIS. Before following the procedures in this chapter, you must have installed your system as described in Chapter 2. After completing the procedures in this chapter, see Chapter 4 for workstation system administration procedures, or Chapter 5 for terminal system administration procedures.

This chapter contains the following sections:

Section Topic

3.1

3.2

3.3

3.4

Workstation Booting Instructions Terminal Booting Instructions The Startup Environment Boot Options

3.1 Workstation Booting Instructions

To boot the default software shipped on the disk and run the flight simulator demonstration program, follow these steps:

1. Set the

Power

switch on the display monitor to On.

2. Set configuration switches 1 through 9 on the cabinet back panel to

Closed

(see Figure 3-1).

3. Set the

Power

switch on the cabinet front panel to On. If the power

for the workstation is already on, press the

Reset

button. The

workstation displays the PROM monitor prompt:

iris>

Wait 20 seconds tor the disk to spin up to speed. (The boot will fail if

you don’t wait that long.)

Version 1.0 SERIES 3000

3-2 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Booting the IRIS

Figure 3-1: IRIS Configuration Switches

4. Enter the letter b and press

Return

The workstation displays system information similar to that shown

in Figure 3-2.

5. At this point, the IRIS is running in Un i x single-user mode, which is used only for system maintenance. For normal operation of the IRIS workstation, start multi-user mode by entering the multi command.

6. When the workstation prompts for the correct date, enter the date in the requested format, as illustrated in the example below. The characters mmddhhmmyy.ss represent digits for month-day-hourminute-year-seconds. The year and the seconds are optional.

Is the date Wed July 21 08:10:33 PST 1989 correct? (y or n) n Enter the correct date (mmddhhmm[yy][.ss]):0721083089.33

7. The workstation prompts for a file system check:

Do you want to check filesystem consistency? (y or n)

If you answer yes, the file systems are checked with the fsck

program. Only answer no if the system has been shut down with the reboot command, as described in Section 4.1. Even then, you are advised to run fsck occasionally. (See the Un i x Programmer’s Manual for more about fsck.) The system now performs initializations required for multi-user mode. Once multi-user mode has been started, a login prompt appears:

IRIS login:

8. To test a newly installed system, log in to the guest account:

IRIS login: guest

9. To use the Flight simulator, type:

~demos/flight

10. To leave the flight program, press the

ESC

key.

11. To log out, type:

logout

Version 1.1 SERIES 3000

IRIS OWNER’S GUIDE 3-3 Booting the IRIS

Important

Now that your IRIS workstation is up and running, make sure you have a bootable backup tape containing the stand-alone software, the root file system, and the user file system. You should receive a bootable backup tape with your workstation. This tape can be used to boot the workstation and rebuild the disk in case the file system is damaged.

For more information about system administration, such as adding new accounts, changing the time zone, and enabling network communication, see Chapter 4.

Section 3.4 contains more detailed information about the boot procedure, including procedures for booting from various devices. Section 3-4 also describes the PROM monitor, a command interpreter that controls the boot environment. Table 3-2 shows the commands understood by the PROM monitor. Table 3-3 shows the boot devices.

3.2 Terminal Booting Instructions

To boot the default software shipped on the disk and run the flight simulator demonstration program, follow these steps:

1. Set the

Power

switch on the display monitor to On.

2. Set configuration switches 1 through 9 on the cabinet back panel to

Closed

(see Figure 3-1).

3. Set the

Power

switch on the cabinet front panel to On. If the power

is already on, press the

Reset

button. The IRIS terminal displays

the PROM monitor prompt:

iris>

Wait 20 seconds for the disk to spin up to speed. (The boot will fail

if you don’t wait that long.)

4. Enter the letter b and press

Return

3-4 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.1

Booting the IRIS

5. When the terminal prompts for the correct date, enter the date in the requested format, as illustrated in the example below. The characters mmddhhmmyy.ss represent digits for month-day-hourminute-year-seconds. The year and the seconds are optional.

Is the date Wed July 21 08:10:33 PST 1989 correct? (y or n) n Enter the correct date (mmddhhmm[yy][.ss]):0721083089.33

6. After the startup sequence is complete, the IRIS 3010 automatically runs the terminal emulator program, wsiris. Enter the sequence ~! to the first prompt to enter the shell:

XNS or IEEE-488 option:

Connect to what host? ~!

TCP/IP option:

Enter IRIS IP address : ~!

If your IRIS has the IBM option, enter ~! to return from the t3279

menu to the shell.

The shell prompt appears:

7. To use the flight simulator, type:

~demos/flight

8. To leave the flight program, press the

ESC

key.

To return to the terminal emulator program, enter the exit command.

See Chapter 5 for more information on using the terminal emulator, connecting to a host, and configuring the user environment.

3.3 The Startup Environment

During the startup process, the IRIS displays a set of system information, including memory size, hardware configuration, and file system identification (see Figure 3-2).

Version 1.1 SERIES 3000

IRIS OWNER’S GUIDE 3-5 Booting the IRIS

Kernel Number:

SYSTEM 5 UNIX #6: [ Fri May 4 11:15:09 PST 1985]

Actual Memory:

real = 4194304

Kernel Size:

kmem = 491520

Available User Memory:

user = 3702784 bufs = 819200 (max=8k)

Hardware Configuration:

dsd0 at mbio 0x7f00 ipl1 qic0 slave 0 md0 (Priam V170 Name: IP-2) slave 1 md1 (Priam V170 Name: IP-2) slave 2 mf0 not installed st0 not installed nx0 (FW2.6 HW 2.0) (0800.1400.0120) at mbio 0x7ffc ipl2 fpa installed

Root File System Device Name:

root on md0a

Swap Space Device Name and Size:

swap on md0b [8865K]

Figure 3-2: Sample IRIS Boot Information

3-6 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.1

Booting the IRIS

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 3-7 Booting the IRIS

The IRIS terminal boots into the terminal emulator program. For more information on IRIS terminal operation, see Chapter 5.

The IRIS workstation boots into single-user mode, which should be used only for system maintenance. For normal operation, the workstation must be put into multi-user mode. The multi command initiates the process of putting the workstation into multi-user mode. The details of the procedure are controlled by the file /etc/rc, which contains commands tor starting daemons and mounting file systems. For more information, see brc(1).

1. To enter multi-user mode, enter the multi command:

multi

2. If the /etc/model file becomes corrupted, the system prompts for the model number, writing the response to /etc/model.

3. The workstation asks to run the Un i x lesystemcheckprogramfsck.

Do you want to check filesystem consistency? (y or n)

If you answer yes, the file systems are checked with the fsck

program. Only answer no if the system has been shut down with the reboot command, as described in Section 4.1. Even then, you are advised to run fsck occasionally.

If fsck is run and finds no problems, it displays one line for each

test. If fsck finds any problems, it prompts for permission to repair the file system. See the Un i x Programmer’s Manual for more information on fsck.

4. Enter the correct date using the specified format:

Enter the correct date (mmddhhmm[.ss][yy]):07210830.3389 Is the date Wed July 21 08:30:33 PST 1989? (y or n) y

In the example above, the characters mmddhhmm.ssyy represent

month-day-hour-minute-seconds-year. The seconds and the year are optional. The entry above sets the date to 33 seconds past 8:30 a.m. on July 21, 1989.

The system now performs initializations required tor multi-user

mode. Once multi-user mode has been started, a login prompt appears:

IRIS login:

3-8 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Booting the IRIS

5. Section 4.2 explains how to configure the workstation to boot into multi-user mode automatically.

3.4 Boot Options

The IRIS boot environment is determined by the setting of configuration switches 1 through 4 on the cabinet back panel. The two basic boot options are automatic boot or PROM monitor boot:

Automatic boot At powerup, the IRIS tries to boot from a file called

defaultboot on the device specified by the configuration switches (see Table 3-1 and Section

3.4.2).

PROM monitor boot At powerup, the IRIS enters the PROM monitor and

waits for further boot instructions (see Section 3.4.1).

To boot from a secondary video driver, see Chapter 8.

Since the IRIS can be booted from different devices (hard disks, tape drives, etc.), the PROM monitor provides the ls command, a version of the Un i x ls(1) command, for displaying the names of the files on the attached devices. You can specify a device name and a pathname in the ls. command (see Table 3-2).

For example, ls / searches the root file system (/) on the default device and lists its contents. If you type ls without an argument, the IRIS displays a list of files on the default device.

The IRIS is shipped with the configuration switches set for booting from the PROM monitor. To select automatic booting, change the settings of the configuration switches on the standard I/O panel. Table 3-1 lists the defined configuration switch settings.

If you attempt to boot a nonexistent device or file from the PROM monitor, the system prints an error message and returns you to the PROM monitor. If an automatic boot fails, the system waits a few seconds and tries again. Automatically booting an IRIS 3030 always fails on the first attempt after power-up, but the automatic retry should succeed.

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 3-9 Booting the IRIS

Configuration Switches

Switch Switch Name Position1 Meaning

1 - 4 Boot environment CCCC

OCCC

COCC OOCC OCOC

Hard disk boot Cartridge tape boot Floppy disk boot Network boot PROM monitor

5 Autoboot C

PROM Monitor boot Automatic boot

6 Quiet mode C

Display system information Don’t display system information

7 Monitor select C

Display on primary monitor Display on secondary monitor

8-9 Reserved C

Table 3-1: IRIS Configuration Switches

As Table 3-1 shows, switches 1 through 4 select the device from which the IRIS is to be booted. Switch 5 specifies whether the IRIS should perform an automatic boot or a PROM monitor boot. Switch 6 determines whether or not system information is displayed on the screen after the IRIS is reset. Switch 7 selects the display monitor type. (For an explanation of selecting a display type, see Chapter 8, Video Options.)

3.4.1 PROM Monitor Boot

The PROM monitor is a command interpreter designed primarily to control the IRIS boot environment. The IRIS enters the PROM monitor when the power is turned on or the system is reset in either of two cases:

•Configuration switches 1 through 4 are set for PROM monitor boot

(“OCOC”).

•Switch5issetto“C”,regardlessofthesettingofswitches1through4.

C means

Closed

and O means

Open

3-10 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Booting the IRIS

Table 3-2 summarizes the PROM monitor commands. Table 3-3 lists the device names recognized by the PROM monitor.

To boot through the PROM monitor, follow these steps:

1. Set the

Power

switch on the display monitor to On.

2. Set configuration switches 1 through 4 to the appropriate boot device setting (see Table 3-1). The default boot device is the hard disk, which has the setting “CCCC”.

3. Set switch 5 to

Closed

4. Set the

Power

switch on the cabinet front panel to On.

If the clock battery has run down, the system displays this ominous

message:

Power has been lost to the machine.

This message refers only to the clock, however.

The IRIS displays the PROM monitor prompt:

iris>

If the prompt does not appear, press the

Reset

button.

Wait 20 seconds for the disk to spin up to speed. (The boot will fail

if you don’t wait that long.)

5. To boot from the device specified by configuration switches 1 through 4, enter the letter b and press

RETURN

The IRIS reads the file defaultboot from the default device.

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 3-11 Booting the IRIS

Command Description

[b] file

[b] dev:

[b] dev: file

ls [dev:] [pathname]

xns[.hostname]:[file]

exit

Boot defaultboot from the default boot device.

Boot file on the default boot device. The default boot device is determined by the configuration switches (see Table 3-1).

Boot file defaultboot from specified device.

Boot file on device dev.

Display a list of PROM monitor commands.

List the contents of directory pathname on device dev. With no arguments, ls provides a list of files on the default device (see Table 3-3).

Boot file over the network using XNS.

Restart the PROM monitor.

Table 3-2: PROM Monitor Commands

Device Description

hd0 md0 si0 hd1 md1 si1 ct0 mq0 sq0 fd0 mf0 sf0

Disk drive 0 (generic) Disk drive 0 (IRIS 3010/3020) Disk drive 0 (IRIS 3030) Disk drive 1 (generic) Disk drive 1 (IRIS 3010/3020) Disk drive 1 (IRIS 3030) Cartridge tape drive 0 (generic) Cartridge tape drive (IRIS 3020/3030) Cartridge tape drive (IRIS 3030) Floppy disk 0 (generic) Floppy disk 0 (IRIS 3020/3030) Floppy disk 0 (IRIS 3030)

Table 3-3: Boot Devices

You can boot the IRIS from any attached device through the PROM monitor, regardless of the settings of switches 1 through 4. See Table 3-2 for a listing of the PROM monitor commands.

The examples below show how to boot from various devices using the PROM monitor. Table 3-3 lists the available device names. In all of the examples, if you enter a device name but no filename, the IRIS looks for a file with the name defaultboot on the specified device. If you enter only a device or filename, or both, with no specific PROM monitor command, the IRIS tries to boot from the specified device and file.

3-12 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Booting the IRIS

Booting from the Tape Drive

To boot from the tape drive, specify the tape drive device name and filename. For example, to boot the file mdfex on the tape drive, enter this command:

ct0:mdfex

To be able to boot from a tape, it must be in cpio format. See Section 4.4 for information on making a bootable backup tape.

Booting from the Disk

To boot from the disk drive, specify the disk device name and filename. For example, to boot the file vmunix1 on the a partition of drive number one, hd1, enter this command:

hd1:vmunix1

Booting over the Ethernet

To boot the IRIS over an XNS Ethernet, use this command syntax:

xns[.hostname]:filename

If the hostname is omitted, the first host to recognize filename responds.

For example, to boot the IRIS from the file /usr/local/boot/goboot on the host cruncher, enter this command:

xns.cruncher:/usr/local/boot/goboot

3.4.2 Automatic Boot

When configuration switch 5 is set for automatic boot, the IRIS attempts to boot the file defaultboot on the device specified by configuration switches 1 through 4 (see Table 3-1).

To configure the IRIS to boot automatically:

1. Set the

Power

switch on the display monitor to On.

2. Set configuration switch 5 to

Open

3. Set configuration switches 1 through 4 to the appropriate settings for the boot device (see Table 3-1).

4. Set the

Power

switch on the cabinet front panel to On.

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 3-13 Booting the IRIS

NOTE: It the power for the IRIS is already on, press the

Reset

button. Do not press the

Reset

button while the IRIS is running Un i x without first using the /etc/reboot command.

4. Workstation System Administration

The system administrator is responsible for configuring the IRIS workstation to meet local requirements and for maintaining the installed system. This chapter covers the following procedures:

Section Topic

4.1 Basic Operation and Shutdown

4.2 Un i x Configuration

4.3 Network Communication

Naming the workstation Adding user accounts Booting into multi-user mode automatically Un i x configuration files Special device files in /dev XNS network commands Using multiple kernels

4.4 Backups Making a bootable tape Making periodic backups Storing key Un i x files on a second disk

4.5 Crash Recovery Recovering from a crash by:

•usinginit

•bootingfromtape

•bootingfromtheseconddisk

4.1 Basic Operation and Shutdown

If you have not yet installed and booted the workstation, see Chapters 2 and 3. For a description of the startup environment, see Section 3.3.

The IRIS workstation boots into single-user mode, which should be used only for system maintenance. For normal operation, the workstation must be put in multi-user mode, as described in Section 3.3. Section 4.2 explains how to configure the workstation to boot into multi-user mode automatically.

Version 1.0 SERIES 3000

4-2 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Workstation Administration

CAUTION

Do not press the

Reset

button while the IRIS workstation is running Un i x . For information on rebooting the system, see Chapter 3. If the IRIS workstation is not running Un i x and is under control of the PROM monitor, then the

Reset

button

or the

Power

switch may be used.

Before turning off power to the workstation, you should perform a soft reboot of the system to ensure that all in-memory disk-blocks have been written to the disk and that all directory information on the disk is current.

To shut down the workstation, follow these steps:

1. Make sure there are no other users on the system:

who

2. Become the super-user.

3. Reboot the system:

reboot

4. Set the

Power

switches on the cabinet and monitor to

Off

4.2 Un i x Conguration

One of the strengths of the Un i x operating system is its flexibility. The system administrator configures the workstation to the needs of the local user community, and the users can fine-tune their own environments.

The following subsections contain instructions for performing common system administration tasks on an IRIS workstation. To perform these tasks, become the super-user by logging in as root:

IRIS login: root

Once you are logged in as root, you can return to a login shell by entering the

exit command.

For more information on Un i x configuration, see the Un i x Programmer’s Manual and the list of configuration files in Section 4.2.4.

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 4-3 Workstation Administration

4.2.1 Naming an IRIS Workstation

The default name of a new IRIS workstation is IRIS. If you have more than one workstation on a network, you must assign each workstation a unique name. The name can be up to eight characters long and must contain no blanks.

To change the name of a workstation, edit the file /etc/sys_id and reboot the system. To display the system name at login, change the name in the file /etc/gettydefs. To display a message at login, edit the file /etc/motd (message of the day). To determine the current name of the system, use the hostname(1) command.

4.2.2 Adding a New Account

The IRIS workstation is shipped with six user accounts: root, rootcsh, rootsh, guest, demos, and mexdemos. The root and rootcsh accounts are super-user

accounts with a C shell environment. The rootsh account is a super-user account with a Bourne shell environment. The guest account is a sample user account with a C shell environment. The demos and mexdemos accounts are for running demonstrations (see Chapter 9).

The accounts shipped on a new IRIS workstation have no passwords. To establish passwords tor these accounts, follow the procedure below. See the passwd manual page for more information.

Typically, each user on an IRIS workstation is given his or her own account. The procedure for creating a new account on the IRIS workstation consists of adding the new user to the file /etc/passwd, creating a home directory tor the user, and setting up startup files to define the user’s environment. The details of this procedure are presented below. You should become the super-user to create a new account (see above).

1. Add a line for the new account to the file /etc/passwd. Figure 4-1 contains a sample /etc/passwd file.

The file /etc/passwd contains a line for each account on a Un i x system.

Each line has seven fields separated by colons (:).

Field Contents

1 2 3 4 5 6 7

Account name Encrypted user password User number Group number User’s real name Home directory (default /) Login shell (default /bin/sh)

4-4 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Workstation Administration

root::0:0:Superuser:/:/bin/csh rootcsh::0:0:Superuser:/:/bin/csh rootsh::0:0:Superuser:/:/bin/sh daemon:*:1:1::/: bin:*:2:2:Binary Files:/: uucp:*:3:5:UUCP Login Account:/usr/spool/uucppublic:/usr/lib/uucp/uucico adm:*:5:3:Administration:/usr/adm: iris::7:0::/:/bin/tesh uucpadm:*:8:8:UUCP Administration:/usr/lib/uucp: lp:*:9:9:Line Printer:/: mexdemos::996:997::/usr/people/mexdemos:/bin/csh demos::997:997::/usr/people/demos:/bin/csh guest::998:998::/usr/people/guest:/bin/csh games:*:999:999:Games:/usr/games:/bin/sh steve::11:20:Steve Brown:/usr/people/steve:/bin/csh

Figure 4-1: Sample /etc/passwd File

Be sure that the new entry contains a unique account name, a

unique user number, and a group number. The user number is used to assign ownership of files to that user.

The group number is the group identification given to the user at

The group number corresponds to the groups in the file /etc/group

(see group(4)). The /etc/group file shipped on the workstation has group number 20 set to user; this is a default group number to use for new users.

Leave the password field empty. The system encrypts the password

and adds it to the file when the user establishes a password (see step 4). In Figure 4-1, the asterisks (*) in the password fields for some accounts prevent those names from being used as login accounts.

Ordinarily, the home directory in field 6 is the user’s own directory

(see step 2). The login shell in field 7 can be either the C shell (/bin/csh) or the Bourne shell (/bin/sh). The default is the Bourne shell.

For example, to add a new account for a user named jose to the

sample file in Figure 4-1, you might enter this line:

jose::10:20:Jose Aranda:/usr/people/jose:/bin/csh

See passwd(4) for more information.

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 4-5 Workstation Administration

2. Make a home directory tor the new user, with the same name specified in field 6 of the /etc/passwd entry, and set the protections and ownership of the new directory. Typically, all users’ home directories are made subdirectories of the directory /usr/people.

The mkdir(1) command creates the new directory.

mkdir /usr/people/jose

The chgrp(1) command changes the group to which the directory

belongs. The example below puts the directory /usr/people/jose in the group user.

chgrp user /usr/people/jose

The chmod(1) command sets the protection parameters on a file or

directory. The example below sets protection codes to allow only the owner to create files in the directory. All users may read the file and search the directory. Protection parameters can be set only by the super-user or by the owner of the file or directory.

chmod 755 /usr/people/jose

The chown(1) command changes the ownership of the directory. The

ownership of a directory can be set only by the superuser. The example above establishes jose as the owner of the directory /usr/people/jose.

chown jose /usr/people/jose

3. Jose is a member of group user by virtue of his /etc/passwd entry. He can be in other groups as well, defined by /etc/group, To include the new user in groups other than user, edit the file /etc/group, Entries to this file are optional. See group(4) for more information.

4-6 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Workstation Administration

sys:*:0: system:*:0: daemon:*:1: bin:*:2: adm:*:3: sgi_use:*:4: uucp:*:5:uucp sgi_use:*:6: sgi_use:*:7: uucpadm:*:8:uucp lp:*:9: user:*:20: vlsi:*:21:steve

Figure 4-2: Sample /etc/group File

Figure 4-2 contains an example /etc/group file. The file contains a

line for each group on the system. Each line consists of four fields separated by colons (:).

Field Contents

1 2 3 4

Group Name Encrypted Group Password Group Number Group Members

To add a user to a group, append the user’s name to the list of group

members. Separate group members with commas. For example, to add jose to the group vlsi, append the name jose to the line for the group vlsi:

vlsi:*:21:steve,jose

4. The new user should log in and use the passwd command to establish a password for the account. Issue the exit command to return to a login shell if you are now the super-user.

passwd New password: password

Re-enter new password: password

The password is encrypted and added to the file /etc/passwd.

If the user forgets his or her password, the encrypted password can

be removed from the user’s entry in /etc/passwd.

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 4-7 Workstation Administration

The passwd command can also be used to change passwords. The

passwd program queries the user for the old password before

establishing a new one.

5. Add startup files like .cshrc, .login, and .profile to the new user ’s home directory. These files control the details of the user’s environment. You can copy the startup files from /usr/people/guest, modifying them if necessary.

The choice of the C shell or the Bourne shell determines which files

are necessary. If you choose the C shell, the user’s home directory should contain the files .login and .cshrc. The C shell reads the .cshrc file in the user ’s home directory each time a shell is started. If the shell is a login shell, the C shell then reads the .login file in the user’s home directory.

If you choose the Bourne shell, the user ’s home directory should

contain the file .profile. The Bourne shell reads the .profile file in the user’s home directory when a login shell is started. For more information on the C shell and the Bourne shell, see csh(1) and sh(1).

Each user’s shell startup file should use the tset command to read

/etc/ttytype and set the terminal type, so that screen editors and other programs know how to communicate with the terminal. The usual way to use tset with the C shell is to add these lines to your .login file:

set noglob set tmp = (`tset -s -Q`) setenv TERM = tmp[1] setenv TERMCAP = tmp[2] unset tmp noglob

Add this line to your .profile file to use tset with the Bourne shell:

eval `tset -s -Q`

For more information, see tset(1) and ttytype(4).

4-8 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Workstation Administration

4.2.3 Entering Multi-user Mode Automatically

By default, the IRIS workstation boots into single-user mode, which should be used only for system maintenance. When the system is running in single-user mode, only the root file system is mounted, none of the system daemons are started, and the terminal lines do not allow users to log in. To enter multi-user mode, the super-user issues the multi command.

The super-user can also edit the file /etc/inittab so that the system automatically enters multi-user mode each time it is booted. The first line of /etc/inittab tells init which mode to enter after booting Un i x :

is:s:initdefault:

Replace the s (for single) in the second field with 2 or 3:

XNS protocol:

is:2:initdefault:

TCP/IP protocol:

is:3:initdefault:

The system will now enter multi-user mode each time it is rebooted. For more information on the init process, see init(1M) and inittab(4).

4.2.4 Un i x Conguration Files

The directories /etc and /usr/lib contain the major system configuration files. They can be edited by the system administrator as needed to serve the needs of the local user community.

/etc/bcheckrc This file contains commands to perform a file

system check, and to set the date using /etc/rc.getdate if possible, or to prompt for the date if not.

/etc/checklist This file lists the file systems processed by default

by fsck.

/etc/cshrc This file is read at login by accounts that specify the

C shell as the login shell. It contains commands that define the user’s environment. See csh(1) and

cshrc(4).

/etc/gettydefs This file contains entries for line speeds and

terminal settings used by getty(1M) for initializing devices. See gettydefs(4).

/etc/group This file contains the list of groups that are used to

control access to files. See Section 4.2 and group(4).

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 4-9 Workstation Administration

/etc/inittab This file contains the table that init uses to dispatch

processes for initializing devices, starting daemons, and starting the shell. See inittab(4), and init(1M).

/etc/model This file contains the model number of the IRIS.

/etc/motd This file contains the message of the day, which is

displayed each time a user logs in to an IRIS workstation.

/etc/passwd This file contains information about the users with

accounts on the workstation. It includes each user’s name, user number, group number, home directory, and login shell. See Section 4.2.2 and passwd(1).

/etc/profile This file is read at login by accounts that specify the

Bourne shell as the login shell. It contains commands that define the user’s environment. See

sh(1) or profile(4).

/etc/rc This command file is executed by init(1M) at the

start of multi-user mode. Typically, it is used to start daemons and mount file systems. See

brc(1M).

/etc/rc.fs This shell script mounts file systems on appropriate

devices, according to the model number of the workstation. It is called by the program /etc/rc when multi-user mode is entered.

/etc/sys_id This file contains the name of the system, which is

always IRIS on a new workstation. See Section 4.2,

hostname(1), and sys_id(4).

/etc/rc.getdate If a file with this name exists and is executable, the

standard output of its execution is used as the argument to date(1). Otherwise, the user is prompted for the date.

/etc/termcap This file contains definitions of different terminal

types. See termcap(4).

/etc/ttytype This file contains a mapping of the terminal types

attached to each tty port on the IRIS workstation. This file is read by tset(1) and by login to initialize the terminal (TERM) environment variable at login. See tset(1) and ttytype(4).

/etc/TZ This file contains an entry for the time zone.

Several different utilities use this file. /etc/TZ contains three fields:

4-10 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Workstation Administration

1. Standard heading for time zone

2. Offset from Greenwich Mean Time (in hours)

3. Optional daylight savings time zone

The IRIS workstation is shipped with the time zone

set for Pacific Standard Time:

PST8PDT

These are examples for other time zones:

EST5EDT CST6CDT MST7MDT

For more information, see TZ(4).

/usr/lib/crontab This file contains entries for commands to be run at

fixed intervals by the cron daemon (the clock daemon). See cron(1M).

/usr/lib/acct/holidays This file contains a list of holidays. It is used by the

calendar(1) program.

/usr/lib/Mail.rc This file contains set commands used for initializing

the mail system.

The next four files configure the Un i x -to-Un i x communication system UUCP. Further information on UUCP can be found in the Un i x Programmer’s Manual,

Volume II.

/usr/lib/uucp/L-devices This file sets the line speeds for the ports used by

uucp(1C). The file contains a series of one-line

entries that follow the format of this example:

DIR tty06 0 4800

This entry specifies that the device /dev/tty06 is a

directly connected computer that can be used at 4800 baud.

/usr/lib/uucp/L-dialcodes This file contains the dial-code abbreviations used in

the /usr/lib/uucp/L.sys file. The entries are in the form:

abb dial-sequence

abb is the abbreviation of a location, and dial-sequence

is the dial sequence associated with the location. For example:

sf 415

This entry sends the sequence 415 to the dial unit.

/usr/lib/uucp/L.sys This file contains information about sites that

uucp(1) can communicate with.

/usr/lib/uucp/USERFILE This file contains information that limits user

accessibility. It specifies which files a user on the local machine can access, which files can be accessed from a remote computer, which login name is used by a particular remote computer, and whether a remote computer should be called back to confirm its identity.

4.2.5 Device Files

File Description

drum

EXOS/*

floppy

rfloppy

ib[0-9]

kmem

md0[a-h]

rmd0[a-h]

md1[a-h]

rmd1[a-h]

mem

mf0a

rmf0a

Paging device (used for virtual memory)

Directory of TCP/IP devices

Optional floppy disk drive (generic blocked device)

Optional floppy disk drive (generic raw device)

IEEE-488 devices

Kernel memory; see mem(7)

Disk zero partitions (IRIS 3010/3020 block devices)

md0a contains the root (/) file system; md0c contains the user (/usr) file system (IRIS 3020)

or a copy of the root file system (IRIS 3010). See efs(4).

Disk zero partitions (IRIS 3010/3020 raw devices)

Optional disk partitions (IRIS 3010/3020 block devices)

Optional disk partitions (IRIS 3010/3020 raw devices)

Memory; see mem(7)

Optional floppy disk drive (IRIS 3010/3020 blocked device)

Optional floppy disk drive (IRIS 3010/3020 raw device)

Table 4-1: Special Device Files in /dev

Version 1.1 SERIES 3000

IRIS OWNER’S GUIDE 4-11 Workstation Administration

File Description

null

pxd

rmt1

rmt2

rmt3

rmt4

sf0a

rsf0a

si0[a-h]

rsi0[a-h]

si1[a-h]

rsi1[a-h]

sq0

nrsq0

syscon

systty

tek

tty

ttyd1

ttyd2

ttyd3

ttyn*

ttyw[0-9]

ttyT?

Null device (zero length on input, data sink on output) See null(7).

IBM driver

Cartridge magnetic tape (generic raw blocked device)

Cartridge magnetic tape (generic raw blocked device and no rewind on open or close)

Half-inch magnetic tape (raw blocked device)

Half-inch magnetic tape (raw blocked device with no rewind on open and close)

Optional floppy disk drive (IRIS 3030 blocked device)

Optional floppy disk drive (IRIS 3030 raw device)

Disk zero partitions (IRIS 3030 block devices)

si0a contains the root (/) file system; si0c contains the user (/usr) file system. See efs(4).

Disk zero partitions (IRIS 3030 raw devices)

Optional disk partitions (IRIS 3030 block devices)

Optional disk partitions (IRIS 3030 raw devices)

Cartridge magnetic tape (IRIS 3030 raw blocked device)

Cartridge magnetic tape (IRIS 3030 raw blocked device and no rewind on open or close)

System console (linked to /dev/console)

Color graphics printer device

A synonym for the terminal device associated with a process See termio(7) and tty(7).

Serial

Port 2

on standard I/O panel

Serial

Port 3

on standard I/O panel

Serial

Port 4

on standard I/O panel

XNS Ethernet network terminal devices

Window ttys; ttyw0 is the console.

Pseudo tty devices

Table 4-1: Special Device Files in /dev (continued)

4-12 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.1

Workstation Administration

4.3 Network Communication

An IRIS workstation can communicate with other devices over an Ethernet local area network using the XNS and TCP/IP protocols. Only one communication protocol can be used at one time.

The following sections present a brief overview of the commands used for communicating over the Ethernet. For more information about the network software for the IRIS workstation, see the manual pages for these commands in the Un i x Programmer’s Manual, Volume IA. To make the workstation emulate a terminal, see Chapter 5.

The following two sections use these terms:

• Anetwork is a collection of computers and terminals connected together.

• Ahost is a computer on a network.

• Alocal host is the host you are using.

• Aremote host is another computer on the same network.

4.3.1 XNS Network Commands

To communicate over an XNS Ethernet local area network, the IRIS workstation uses three commands:

xcp Copies a file from one computer to another.

xx Runs a command on a remote host.

xlogin Initiates a login on a remote host.

xcp copies a file from one host to another. The command line specifies both the

source host and file first, followed by the destination host and file:

xcp [sourcehost:]pathname [destinationhost:]pathname

If no host name is specified, the local host is assumed. In these examples, the user must have an account with the same user name on both hosts.

xcp sqiral.c olympus:/oh4/doc/install/sqiral.c

This example copies the file sqiral.c in the current directory of the local machine to the file sqiral.c in the directory /oh4/doc/install on a host named olympus.

xcp sting:/usr/include/stdio.h test

This example copies the file /usr/include/stdio.h from a remote machine sting to the file test on the local machine.

xcp puppy:temp_vi sting:temp_vi

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 4-13 Workstation Administration

4-14 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Workstation Administration

This example copies the file temp_vi from the remote machine named puppy to a file with the same name on a remote machine named sting in the user’s home directory on each machine.

xcp -r -v sting:/usr/include/* localinclude

This command is an example of recursive copying. It copies all files and directories from /usr/include on the remote machine sting to the directory localinclude on the local host. The -v option prints the names of the files it creates.

xx runs commands on a remote host. Like xcp, this command assumes that the user has accounts under the same user name on both the remote and local host.

The xx command takes the command to be executed as an argument. For example, to find the load average on another machine, enter this command:

xx hostname uptime

xlogin initiates a login on a remote host across the network. The command

takes the remote host name as an argument. For example, to log in remotely to a host with the name olympus, enter this command:

xlogin olympus login: ...

For more information about the network software for the IRIS workstation, see the manual pages for these commands in the Un i x Programmer’s Manual, Volume IA.

4.3.2 TCP/IP Network Commands

This section describes the commands for communicating over an Ethernet local area network using TCP/IP. You must be running the TCP/IP kernel to use TCP/IP communications (See Section 4.3.3 below).

Each computer to be accessed with the network communication tools must have a unique name. The file /etc/hosts contains these names. (See the documentation that accompanies the network software for more information.)

To communicate over an TCP/IP Ethernet local area network, the IRIS workstation uses five commands:

rcp Copies a file from one computer running Un i x to another

computer running Un i x .

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 4-15 Workstation Administration

rsh Starts a shell on a remote host running Un i x .

rlogin Initiates a login on a remote host running Un i x .

ftp Transfers files to and from a remote host using FTP

protocol.

telnet Communicates with a host using TELNET protocol.

rcp copies a file from one host to another. The command line specifies the source

host and file, followed by the destination host and file:

rcp [sourcehost:]pathname [destinationhost:]pathname

If no host name is specified, the local host is assumed. In these examples, the user must have an account with the same user name on both hosts.

rcp sqiral.c olympus:/oh4/doc/install/sqiral.c

This example copies the file sqiral.c in the current directory of the local machine to the file sqiral.c in the directory /oh4/doc/install on a host named olympus.

rcp sting:/usr/include/stdio.h test

This example copies the file /usr/include/stdio.h from a remote machine sting to the file test on the local machine.

rcp puppy:temp_vi sting:temp_vi

This example copies the file temp_vi from the remote machine named puppy to a file with the same name on a remote machine named sting in the user’s home directory on each machine.

rcp -r sting:/usr/include/* localinclude

This command is an example of recursive copying. It copies all files and directories from /usr/include on the remote machine sting to the directory localinclude on the local host.

rsh connects your terminal to a remote host and executes the commands you specify. Like rcp, this network utility assumes that the user has accounts under the same user name on both the remote and local host.

If a command is specified, the rsh program takes the command as an argument. For example, to find the load average on another machine, enter this command:

rsh hostname uptime

4-16 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Workstation Administration

rlogin initiates a login on a remote host across the network. The command takes the remote host name as an argument. For example, to log in remotely to a host named olympus, enter this command:

rlogin olympus login: ...

If you do not specify a command to be executed, rlogin starts a login process on the remote host.

Like rlogin, telnet also initiates a login on a remote host across the network. The program takes the name of the host as an argument. For example, to log in remotely to a host named puppy, enter this command:

telnet puppy

The screen shows:

Trying..., connected to puppy. Escape character is ^].

To disconnect from the host, first log out from the host. Then, exit the telnet program. To do this, type

CTRL-]

. Typing

CTRL-]

gets the attention of the

telnet program. To the telnet> prompt, type:

quit

For more information on telnet, see telnet(1C).

Using the File Transfer Program

ftp is a program for transferring files using the ARPANET File Transfer Protocol. Below is a brief description of some of the ftp commands. For more information, see ftp(1C).

1. To start the ftp program, type:

ftp hostname

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 4-17 Workstation Administration

hostname is the host to which you wish to transfer files. For example,

suppose your hostname is olympus. Then, you type:

ftp olympus

Assuming your hostname is olympus, the screen shows:

Connected to olympus. 220 olympus FTP server (Version 4.81 Mon Sep 26 08:36:28 PDT 1983) ready.

The host then requests your name and password. The following

example assumes the user’s name is Peter.

Name (olympus:peter):peter Password (olympus:peter): 331 Password required for peter. 230 User peter logged in.

After you’ve logged in, the ftp prompts appears:

ftp>

2. Now you’re ready to send and receive files using the commands below. Each bulleted item shows both the command syntax and an example for that command.

• To send a file to the remote host, type a command using the

following syntax:

send localfile remotefile

For example, this command sends the file myfile to a file of the

same name on the host machine:

send myfile

The screen indicates that the file has been sent to the remote

machine.

•To get a file on the remote machine and bring it to the local

machine, type:

get localfile remotefile

For example, this command gets the file yourfile from the remote

host and stores it on the local machine in the current directory as myfile:

get yourfile myfile

The screen indicates that the file has been received by the local

machine. You can see if the file has been received by typing:

!ls

•Totransfer multiplefilesfromthelocalmachinetoadirectory

on the remote machine, type:

cd remotedirectory mput localfile1 localfile2 ...

For example, to transfer the files thisfile and thatfile to the

directory /usr/john/filexfer, type:

cd /usr/john/filexfer mput thisfile thatfile

The screen indicates that the files have been sent.

• Totransfer multiple files fromthe remote machine to the local

machine into the current directory, type:

mget localfile1 localfile2 ...

For example, to transfer the files localinclude and graph.c, type:

mget localinclude graph.c

The screen indicates that the files have been received.

•YoucantransfereitherbinaryorASCIIfileswithftp. By default,

ftp transfers ASCII files. To transfer binary files, type:

binary

To transfer ASCII files, type:

ascii

4-18 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Workstation Administration

3. To exit ftp, type:

quit

4.3.3 Using Multiple Kernels

The Un i x operating system is read into memory from a disk file at boot time. The file can have any name, but there are two names that are recognized in special ways: /defaultboot and /vmunix. The PROM monitor recognizes the name defaultboot in the root directory of the disk, and boots that file when no name is explicitly given. Certain Un i x commands recognize the name vmunix and expect it to contain a copy of the kernel currently running in memory.

New kernels are shipped in a directory called /kernels, with names such as

3000.std (the standard kernel), 3000.tcp (the TCP/IP optional kernel), and so on. A copy of one of the kernels is installed as /defaultboot and linked to /vmunix. (A link is a method of giving the same file two different names - see cp(1)).

When a software option includes a new kernel (for example the TCP/IP option), the kernel will automatically be installed as /defaultboot and /vmunix. In most cases, this is the proper thing to do. The PROM monitor will boot that kernel by default, and the various kernel-dependent Un i x commands will find the image of the kernel in the /vmunix file. However, some sites switch between more than one kernel, to have access to more than one communications option. In such an environment, it will be necessary to copy the kernel being used to /vmunix, and link it to /defaultboot (This is done as the last step before taking the system down with the old kernel to reboot it with the new choice.) The kernel(1M) program takes care of these details. The argument is the short name of the kernel you want to install, e.g. std, tcp, ibm, and so on. It can only be run by the superuser.

4.4 Backups

•When you install your IRIS workstation, make sure you have a bootable backup tape containing the stand-alone software, the root file system, and the

user file system. You should receive a bootable backup tape with your workstation. Make a new bootable backup tape after you install new software or change the size of the swap partition on your disk (see Section

4.4.1).

•Aftertheworkstationisinuse,makeperiodic backup tapes of either the entire disk or the user data stored on the disk (see Section 4.4.2).

•Ifyourworkstationhasaseconddisk,storeacopyofthekey Un i x files on the second disk (see Section 4.4.3).

The IRIS workstation supports two tape drives: a cartridge tape drive and a half-inch tape drive. The cartridge tape drive can be used both for making

Version 1.1 SERIES 3000

IRIS OWNER’S GUIDE 4-19 Workstation Administration

bootable backup tapes and periodic backup tapes, and for installing software updates. The IRIS workstation can be booted from the cartridge tape drive in case the root file system on the disk is damaged (see Section 4.5.3).

The half-inch tape drive can be used for making periodic backup tapes and for transferring files, but it is not a bootable device.

The tape drives can be used with either tar(1) or cpio(1), the standard Un i x archiving tools. Use the mkboot(1M) command to make a bootable backup cartridge tape.

4.4.1 Making a Bootable Backup Tape

The bootable backup tape can be used to boot the workstation and rebuild the disk in case the file system on the disk is damaged beyond use. Make a bootable backup tape as soon as you install a new workstation. Make a new bootable backup tape whenever you install a new software distribution or change the size of the swap partition on your disk.

To make a bootable backup tape, follow these steps:

1. Become the super-user and reboot the system into single-user mode:

su reboot b fsck

Correct any errors reported by fsck.

2. Change your working directory to the root file system:

cd /

3. Mount the /usr file system:

IRIS 3020:

mount /dev/md0c /usr

IRIS 3030:

mount /dev/si0f /usr

If /usr is too large, back it up onto a separate tape, using the procedure

described in Section 4.4.2.

4. Put a tape in the tape drive.

4-20 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.1

Workstation Administration

5. Run the mkboot program. (If you have already backed up /usr onto a separate tape, omit the /usr argument.)

mkboot /usr

See Section 4.5.3 for the procedures for rebuilding a damaged file system from the bootable backup tape.

4.4.2 Making Periodic Backups

This section describes the procedure for making routine backups of the IRIS workstation disk(s). The disk(s) can be backed up to a tape on a local tape drive or across a network to a tape on another workstation.

Each file system is backed up onto a separate tape. Table 4-2 below gives the capacity of various tapes. The df command tells you how much of the file systems are used. Use this information to determine the size of tape required to back up a file system.

CAUTION

Do not use multiple tapes to copy a file system that is too large to fit onto one tape. Inserting a second tape, even when you are prompted to do so, could cause a system crash. If more than one tape is required, back up subdirectories of the file system onto separate tapes.

Tape Width Tape Length Approx. Capacity

Quarter-inch Quarter-inch Half-inch (PE format)

450 ft. 600 ft. 2400 ft.

40 Mb 60 Mb

44.6 Mb

Table 4-2: Approximate Tape Capacities for Backups

Table 4-3 lists samples of the Un i x commands for making periodic backup tapes. See find(1) for more information on the arguments to find.

Version 1.1 SERIES 3000

IRIS OWNER’S GUIDE 4-21 Workstation Administration

Cartridge Tape Half-inch Tape

Complete Backup

tar c . cpio -oha1 .

tar c3 . cpio -oBa3 .

Incremental Backup

find . -mtime -7 -print | tar c find . -mtime -7 -print | cpio -oha1

find . -mtime -7 -print | cpio -oBa3

Read Tape

tar x cpio -ihumd1

tar x3 cpio -iBumd3

List Tape Contents

tar xv cpio -ihtv1

tar tv3 cpio -iBtv3

Table 4-3: Sample Tape Drive Commands

In general, you should make periodic backup tapes of everything on the disk. You may want to back up dynamic parts of the file system—such as the user files—more frequently than the more stable parts of the file system. To simplify this process, you can set up the file system so that the files that change most frequently are stored in one directory, which can be backed up independently. If you follow the recommendations in Section 4.2.2 for establishing new accounts, then most user files will be stored in the directory /usr/people.

Each tar or cpio command generates a single output file, which is written to tape. To put several of these output files on one tape, use the tape devices without rewind. When these devices are used, output files can be written one after another onto the tape; the tape does not rewind to the beginning after each write, but rather remains where it was after the last write.

NOTE: If you interrupt the non-rewind cartridge tape device on an IRIS 3020 or 2400T, you must reboot the system to use the tape drive again. To avoid this problem, remove the cartridge from the drive to stop the device.

To use the no-rewind tape devices, replace the tar and cpio commands in steps 4 and 8 below with these lines:

tar c2 . # non-rewind cartridge tape device tar c4 . # non-rewind half-inch tape device cpio -oh2 # non-rewind cartridge tape device cpio -oh4 # non-rewind half-inch tape device

4-22 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.1

Workstation Administration

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 4-23 Workstation Administration

Backing Up a System with a Local Tape Drive

To back up the disk on a workstation with a local tape drive, follow these steps:

1. Become the super-user:

If you are only backing up the /usr file system, go to step 6.

2. Reboot the system into single-user mode:

reboot b

Correct any errors reported by fsck.

3. Install a tape in the tape drive.

4. Back up the root file system using one of these commands:

Using tar:

tar c . # rewind cartridge tape device tar c3 . # rewind half-inch tape device

Using cpio:

cpio -oh1 . # rewind cartridge tape device cpio -oh3 . # rewind half-inch tape device

5. Mount the /usr file system:

mount /dev/md0c /usr

6. Change directories to /usr:

cd /usr

7. Install another tape in the tape drive.

8 Back up the /usr file system using one of these commands:

Using tar:

tar c . # rewind cartridge tape device tar c3 . # rewind half-inch tape device

4-24 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Workstation Administration

Using cpio:

cpio -oh1 . # rewind cartridge tape device cpio -oh3 . # rewind half-inch tape device

9. If you have any additional file systems, mount them and back them up following the same procedure.

Backing Up a System without a Local Tape Drive

An IRIS workstation with no tape drive is backed up across an XNS Ethernet onto a tape loaded on another workstation. Both systems must have network communication capabilities. The system with a tape drive must have a host name, which is referred to in this description as hostA, and must be in multiuser mode.

To back up a disk onto a tape installed in a remote workstation, follow the procedure for backing up a system with a local tape drive, but use the command lines below for steps 4 and 8. Replace rmt1 with rmt2, rmt3, or rmt4 depending on your backup device (see Table 4-1).

4. Back up the root file system:

Using tar:

tar caBf - . | xx hostA dd ibs=10k obs=200k of=/dev/rmt1

Using cpio:

cpio -oha . | xx hostA dd ibs=10k obs=250k of=/dev/rmt1

8. Back up the usr file system:

Using tar:

tar caBf - . | xx hostA dd ibs=10k obs=200k of=/dev/rmt1

Using cpio:

cpio -oha . | xx hostA dd ibs=10k obs=250k of=/dev/rmt1

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 4-25 Workstation Administration

4.4.3 Storing Key Un i x Files on a Second Disk

If you have two disks on your workstation, store a copy of the key Un i x files on the second disk. You could boot from the second disk if the root file system on the first disk became corrupted (see Section 4.5.4).

See Chapter 6 for a discussion of disk configuration. Note that it is not possible to boot from a second disk that has been configured as a single file system.

The procedure below assumes that the file system on the a partition of the second disk is named /n. To store a copy of key Un i x files on the second disk, follow these steps:

1. Change to the root directory:

cd /

2. Create a file that contains the key Un i x files. (The backslash in this command is typed only when immediately followed by a

RETURN

is the case here):

find .cshrc .login .profile vmunix* bin etc dev \

-print -type f | sort > /keyfiles

The key Un i x files consist of:

• fivefilesfromtherootdirectory,

•allofthefilesinthe/dev directory, and

•someofthefilesfromthe/bin and /etc directories.

3. Edit /keyfiles to remove any files prefixed with bin and dev that are not listed below.

bin/cat bin/chgrp bin/chmod bin/chown bin/cp bin/cpio bin/csh bin/dd bin/echo bin/ln bin/ls bin/mkdir bin/more bin/mv bin/ps bin/pwd bin/rm bin/rmdir bin/sh bin/sleep bin/stty bin/su bin/sync bin/tar bin/tset bin/vi

etc/checklist etc/clri etc/cshrc etc/fsck etc/fsdb etc/group etc/init etc/inittab etc/link etc/mkfs etc/mknod etc/mnttab etc/mount etc/passwd etc/profile etc/reboot etc/sys_id etc/tar etc/telinit etc/termcap etc/ttytype etc/umount etc/unlink

4-26 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Workstation Administration

4. Copy the files listed in /keyfiles into a file system on the second disk. This procedure assumes the file system is named /n.

cpio -pdaumv /n < /keyfiles

5. Move /keyfiles to the second disk.

mv /keyfiles /n

You now have a copy of the key Un i x files on the second disk. To find out how to recover from a crash by booting from this copy, see Section 4.5.4.

4.5 Crash Recovery

Depending on the cause, a system crash can leave an IRIS workstation in a state that requires some software repair. This section describes the steps you should take immediately after a workstation crash and the procedures for repairing the disk if the software is damaged.

See Appendix B for a list of system error messages and their probable causes. Also, see the crash(8) manual entry.

If the IRIS workstation stops running for some reason, follow this recovery sequence:

1. Try to reboot the workstation by entering the reboot command:

reboot

2. If the system does not respond, wait one minute, and press the

Reset

button.

The system should attempt to follow the normal boot sequence (see

the description of init, below).

3. Boot the system in single-user mode.

4. Run the file system check program, fsck. This program may identify problems with the file system (see Section 3.3 and fsck in the Un i x Programmer’s Manual, Volume II).

5. If fsck runs without any problems, enter multi user mode:

multi

If rebooting and running fsck does not solve the problem, see the procedures below for identifying the problem and recovering the system.

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 4-27 Workstation Administration

4.5.1 Recovery Strategies

Accidental changes to the files critical to Un i x operation can prevent the Un i x operating system from booting. Table 4-4 lists some of the files that are most likely to cause serious problems.

Critical Files

File Purpose

/ /vmunix /vmunix1

Root directory Kernel Kernel that runs on the second disk

/defaultboot /dev /dev/console /dev/syscon /dev/systty /dev/md0a /dev/rmd0a /dev/drum

Kernel used by default in booting Device directory Console tty device System console device System tty device Root file system device Raw root file system device Paging device for virtual memory

/etc /etc/init /etc/inittab /etc/passwd

Miscellaneous file directory Program that starts other user processes Table for init Table of user login names, passwords, and shells

/bin /bin/su /bin/sh /bin/csh

Commands directory Used to set environment before execing shell Bourne shell C shell

Table 4-4: Files Critical to Un i x Operation

The following subsections describe three procedures for diagnosing the problem and recovering a system that does not boot:

•Usingtheinitializationprogram,init, to identify the cause of the problem.

• Usinga bootablebackup tapetoloadanewrootfilesystemonto thedisk.

This procedure deletes any data that was on the root file system of the disk.

•Booting the Un i x kernel from a second disk and reloading the key files. This approach requires a second disk with a copy of the files needed to boot the system.

4-28 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Workstation Administration

4.5.2 Recovery with init

When Un i x software is booted, it starts the initialization program, init, which controls the startup sequence.

The init program provided with an IRIS workstation has been modified so that it attempts to recover from the most common file system errors. For most errors, init recovers automatically but does not repair the cause of the problem. Therefore, once the system comes up, you should repair the source of the problem.

Repairing the problem usually entails editing the damaged files or reloading the files from a backup tape.

When it starts running, the init program invokes a single-user shell by calling the switch user program, su. Upon startup, su looks in the file /etc/passwd for an account called root. The su program then starts a shell of the type specified in the file /etc/passwd for the account root. (The default shell is the C shell, /bin/csh.)

During this process, the system does not boot correctly if it encounters any of these conditions:

1. The /etc/passwd file is missing.

2. The entry for root is missing or in error in the /etc/passwd file.

3. Any other files critical to starting Un i x are missing or corrupted.

If any of these problems exists, init may be unable to execute the su program, or su may execute too quickly. The first time an error occurs, su should take no more than 15 seconds to execute; on subsequent errors, su should take no more than 30 seconds to execute.

If init cannot execute su, it displays this message:

execlp of /bin/sh failed; errno = n

Refer to the error numbers listed in the introduction to Section 2 in the Un i x Programmer’s Manual for the meaning of n.

If su executes too quickly, it displays a message explaining the problem. For example:

SINGLE USER MODE SU is broken

If su does not execute correctly, init tries to execute the Bourne shell, /bin/sh, bypassing su. If sh fails to execute or executes too quickly, init prints the error message:

execlp of /bin/sh failed; errno = n

or the message:

SINGLE USER MODE /bin/sh is broken

If the Bourne shell fails to execute, init tries to execute the C shell, /bin/csh. If init is able to execute one of these shells, you may be able to identify the

problem and repair it yourself.

If init is unable to execute either shell, it tries to execute this command:

/bin/tar xv /vmunix /vmunix1 /bin /dev/etc vmunix vmunix1 bin dev etc

With this command, init attempts to extract key files from a cartridge tape in any possible way (both with and without leading slashes).

If this fails, /etc/tar xvpU is tried instead of /bin/tar xv. This new attempt extracts everything on tape, unlinking existing files to overwrite them, and giving precedence to the modes on tape.

If this fails, init attempts to extract whatever it can from tape (hoping for a bootable kernel), and reads it into a file called /lastditch. It then attempts to execute this file.

Whether or not init is able to recover the system, you may want to rebuild the file system from a backup copy. See the procedures below for recovering from a backup tape and recovering from a backup disk.

4.5.3 Recovery by Booting from Tape

If the root or usr file system on the workstation’s disk is damaged, you can rebuild them system from a bootable backup tape made for this purpose (see Section 4.4.1). This procedure writes over the contents of the disk. If the bootable backup tape does not contain the most recent user file system, you should update the user file system from the periodic backup tapes after rebuilding the disk. When recovering files from a periodic backup tape, you need to change directories to the directory from which the tape was made.

To restore a disk from a backup tape, follow these steps:

1. Set configuration switches 1 through 5 for booting from the PROM monitor (see Table 3-1).

Version 1.1 SERIES 3000

IRIS OWNER’S GUIDE 4-29 Workstation Administration

2. Reset the workstation by pressing the

Reset

button.

The IRIS displays the PROM monitor prompt:

iris>

3. Insert the bootable backup tape in the tape drive.

4. Boot the mdfex or sifex program.

IRIS 3020:

b ct0: mdfex

IRIS 3030:

b ct0:sifex

CAUTION

You must follow all instructions exactly when you use the fex programs. Failure to follow instructions could result in serious damage to your file system.

The mdfex or sifex initial screen and prompt appear.

SGI Formatter/Exerciser Version :x Date Drive: 0, Name: name, Serial: serial number

IRIS 3020:

mdfex x>

IRIS 3030:

sifex x>

NOTE: If an error message appears instead, call your local System

Engineer or the Geometry Hotline (see Chapter 1).

5. Instruct mdfex or sifex to create the root file system by entering the t command:

4-30 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.1

Workstation Administration

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 4-31 Workstation Administration

6. Accept the mdfex/sifiex defaults for tape file and unit numbers by pressing

RETURN

after each of these prompts:

Tape file (2)? Unit (0)?

7. Confirm file system a by pressing

RETURN

in response to the file

system prompt:

File System (a)?

mdfex/sifiex displays a message about the block sizes it will use

for the copy. When it is ready it displays the message:

Type ‘go <return>’ to begin ...

8. Type:

followed by

RETURN

The system displays these messages:

Copy started...

1 2 3 4....

Tape to Disk Copy complete

IRIS 3020:

mdfex x>

IRIS 3030:

sifex x>

9. Re-enter the PROM monitor by entering the quit command:

Confirm your intention to quit by entering y.

10. Boot the disk:

4-32 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Workstation Administration

Un i x should come up in single-user mode. If the user file system

was not damaged, go to step 14.

If the /usr file system suffered major damage, perform the remaining

steps in this section to restore it.

If you made a separate backup tape for /usr, remove the bootable

backup tape and put the /usr tape in the tape drive.

11. Make a clean user file system:

IRIS 3020:

mkfs /dev/rmd0c labelit /dev/rmd0c usr sgi

IRIS 3030:

mkfs /dev/rsi0f labelit /dev/rsi0f usr sgi

12. Mount the new /usr file system and change to that directory:

IRIS 3020:

mount /dev/md0c /usr cd /usr

IRIS 3030:

mount /dev/si0f /usr cd /usr

13. Rewind the tape, position the tape to the third file on it, and copy /usr from the tape to the disk:

mt rewind mt fsf 2 cpio -ivhmud2

14. Any periodic backup tapes more recent than the bootable backup tape should now be used to recover the root and, if necessary, user file systems as fully as possible.

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 4-33 Workstation Administration

4.5.4 Recovery by Booting from the Second Disk

A small number of key files stored on a second disk is sufficient to reboot the system if the original root file system becomes corrupted. If you have copies of the key Un i x files on a second disk, you can use them to boot the workstation. It is not possible to boot from a second disk drive that has been configured as only one file system (see Chapter 6). You can then try to rebuild the root file system by copying these key files from the second disk to the first.

The procedure in this section assumes that the key Un i x files have been stored on the second disk using the procedure in Section 4.4.3.

To boot from the second disk, follow these steps:

1. Set configuration switches 1 through 5 for booting from the PROM monitor (see Table 3-1).

2. Reset the workstation by pressing

Reset

button.

The IRIS displays the PROM monitor prompt:

iris>

3. Boot the file vmunix1 on the second disk:

hd1:vmunix1

The system displays the superuser shell prompt:

4. Run the file system check program, fsck, on the first disk (the disk you are recovering). List the file systems explicitly on the command line:

IRIS 3020:

fsck /dev/rmd0a /dev/rmd0c

IRIS 3030:

fsck /dev/rsi0a /dev/rsi0f

Repair any problems reported by fsck.

5. Make a /root directory:

mkdir /root

4-34 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Workstation Administration

6. Mount the root file system:

IRIS 3020:

mount /dev/md0a /root

IRIS 3030:

mount /dev/si0a /root

7. Change to the root directory and copy the key system files from the second disk to the first disk using cpio(1):

cd / cpio -pdaumv /root < /keyfiles

8. Shut down the system with the reboot command. Try to boot Un i x from the first drive. If this is successful, recreate the file system on the b partition of the second disk. (This is required because it was used as the swap partition while (vmunix1 was running.)

IRIS 3020:

mkfs /dev/md1b labelit /dev/rmd1b tmp sgi

IRIS 3030:

mkfs /dev/si1b labelit /dev/rsi1b tmp sgi

If problems persist, call your local System Engineer or the Geometry Hotline.

Version 1.0 SERIES 3000

5. IRIS 3010 System Administration

This chapter contains operation and configuration procedures for the IRIS 3010. Topics covered are shown in the table below. At this point, it is assumed that you have installed and booted the IRIS (see Chapters 2 and 3).

5.1 Host Software Installation

5.2 Operation

5.2.1 Connecting to the Host

5.2.2 Issuing Commands to the Terminal Emulator

5.2.3 Running a Demonstration Program

5.2.4 Shutting Down the IRIS Terminal

5.2.5 Boot Failure Recovery

5.3 Software Configuration

5.3.1 Configuration Tools

5.3.2 Configuring the Startup Environment

5.3.3 XNS Configuration

5.3.4 TCP/IP Configuration

5.3.5 Miscellaneous Un i x Configuration

5.1 Host Software Installation

This section contains instructions for installing the host-resident IRIS 3010 support software in a VAX Un i x 4.2BSD environment. For an IRIS workstation System V environment, install the software according to Section 4 of Installing

Software Updates. The entry name for the workstation host-resident software is host. Instructions for installing host software in other environments are

shipped with the software.

The software is delivered on a 1600 bpi half-inch magnetic tape in tar(1) format.

The software can be stored anywhere on the host file system. The procedure below assumes that the distribution software is installed in a directory called /usr/iris.

To install the host software, follow these steps:

1. Log in to Un i x from a terminal that is already attached to the host.

5-2 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

IRIS 3010 System Administration

2. Create a directory to hold the distribution software:

mkdir /usr/iris

3. Change to the new directory:

cd /usr/iris

4. Load the distribution tape onto a tape drive and read the distribution software into the new directory, using the tar command:

tar xv

5. Add the TERMCAP entry for the IRIS Terminal in /usr/iris/c/iris.termcap to the terminal description data base in /etc/termcap.

6. Change directories to /usr/iris/c:

cd /usr/iris/c

7. Compile the C language remote host Graphics Library (librgl2.a), the IRIS 3010 configuration tools, and the demonstration programs, using the /usr/iris/c makefile:

make all

8. To install the library in /usr/lib execute:

make install

9. If a FORTRAN language remote host Graphics Library (libfrgl2.a) is desired, change directories to /usr/iris/f77 and compile it:

cd /usr/iris/f77 make all

The FORTRAN demonstration programs are also compiled. To install

the library in /usr/lib, execute:

make install

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 5-3 IRIS 3010 System Administration

For a terminal with network communication capabilities, the host must also be equipped with the network communication support software and hardware. See VAX 4.2BSD UNIX XNS Release N1.0 Installation Guide for the hardware and software installation procedures for a host running 4.2BSD Un i x .

5.2 Operation

The IRIS 3010 is configured to run a terminal emulation program automatically after booting. The program is named wsiris(1). It causes the IRIS to behave like a regular character terminal, with two additional capabilities:

• Settingupcommunicationwiththehost.

•Interpretinggraphicscommandsequencesfromthehost.

The terminal emulator program can be told to execute an interactive subshell from which Un i x commands can be issued. A complete Un i x operating system is not provided on the IRIS 3010. Only those commands necessary to boot and perform basic system administration are included.

With the IBM option installed, the IRIS 3010 runs a different terminal emulator, t3279(1). Its user interface is completely different from that described below.

5.2.1 Connecting to the Host

This section describes the terminal emulator interface used for connecting to the host. See Section 3.2 for the procedures for booting the terminal emulator program. See Section 5.3.2 for the procedure for configuring the terminal emulator program for the needs of a specific host. See Section 5.2.2 for the commands recognized by wsiris.

When wsiris first comes up on the IRIS, it displays the startup message:

IRIS GL2 Terminal Emulator

The terminal then prompts for instructions regarding the connection to the host. The prompt varies, depending on the configuration of the system.

•An IRIS 3010 with no Ethernet controller, with only XNS Ethernet

communication software, or with previously configured TCP/IP communication software prompts for the name of the host computer:

Connect to what host?

— To establish communication over the serial line, enter serial.

— To establish communication over the IEEE-488 bus, enter either serial or

ieee488. If the host does not support logins on the IEEE-488 bus, enter serial. Once you are logged in, set the environment variable IRISFILE

5-4 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

IRIS 3010 System Administration

to the name of the IEEE-488 device. The serial line will be used for the

— To establish communication over an Ethernet, enter the name of the

host.

For Ethernet communication, the host must have network support

software installed. For XNS communication, the host must be running the xnsd(1M) daemon. For TCP/IP communication, the host must be running the telnetd(1C) daemon. If you do not know the name of a Un i x host, enter the hostname(1) command on a terminal that is already logged onto such a host.

The IRIS establishes a connection with the host, which should display its

usual login prompt.

•An unconfigured IRIS 3010 with TCP/IP communication capabilities

prompts for the Internet addresses of the IRIS and the host:

Enter IRIS IP address:

Enter host IP address:

Only Internet addresses consisting of four numbers separated by periods

(n.n.n.n) are accepted.

To convert a two-field Internet address to the correct format, insert two

fields of zeros in the middle of the address. For example, if the representation of a host name in the /etc/hosts table on a 4.2BSD Un i x system is “42.2”, enter the address as “42.0.0.2”.

The IRIS establishes a connection with the host, which should display its

usual login prompt.

Once communication with the TCP/IP host has been established, you can

copy an Internet host table onto the terminal’s hard disk (see Section 5.3.4). You can then connect to an TCP/IP host by simply entering the name of the host when prompted. See the documentation that accompanies the communications software.

5.2.2 Issuing Commands to the Terminal Emulator

After a connection with the host has been established, the terminal emulator program recognizes some local commands, which are stripped from the data stream and processed locally instead of being transmitted to the host. The commands begin with ~.

To issue a command to the terminal emulator, enter the escape character at the beginning of a line, followed by the rest of the command. The character prior

to the ‘~’ must have been a

RETURN

or a

LINEFEED

. wsiris examines the next few

characters to see if they are any of the following commands:

~~ Send a single ‘~’.

~. Force wsiris to exit. Ethernet connections are closed, but serial

connections may remain open.

~! Escape to a C shell on the IRIS 3010. The shell allows the user to run

programs from the local disk, such as the flight simulator:

~demos/flight

If you are familiar with the Un i x editor vi, you can edit the

configuration files from the local C shell.

To return to communication with the remote host, exit the C shell by

entering the exit command.

~! can also be entered in response to the hostname prompts before a

connection is established.

DEL

Reboot the IRIS with /etc/reboot. You are asked for confirmation. This

command succeeds only for the super-user.

BREAK

If using serial communications, send a break character.

~%Dn Toggle the value of the –d n debugging option (see Section 5.3.2).

~%D1 interactively turns logging on and off. When you turn logging

on, log output is appended to the current log file. If n is 3, the new logfile name consists of all characters following the 3 until terminated by a

RETURN

. If logging is on, the current log file is closed and the newly named one is opened. Subsequent log output is appended to it. If you specify a null file name, the name of the current log file is displayed. ~%D2 is ignored.

~%Mn Set the monitor type to n. n can have one of five values:

0 30Hz 1 60Hz 2 NTSC 3 50Hz 9 PAL

~%P Toggle the value of the –p option (see Section 5.3.2). The –p option

controls whether textport output is printed when the textport is off.

~%R Reset the display by forcing a ginit and a tpon to be executed. This

will load the default color map and turn on the textport. If the window manager is running, the terminal also executes any mapcolor commands stored in the window manager configuration file (see Section 5.3.2).

Version 1.1 SERIES 3000

IRIS OWNER’S GUIDE 5-5 IRIS 3010 System Administration

~%Sspeed Change the serial communications baud rate to speed. The

parameter speed can have these values:

75 110 134 150 300 600 1200 2400 4800 9600 19200

The default is 9600 baud.

~%T Toggle the textport. That is, turn the textport on if it is off, and off

if it is on.

The textport does not automatically disappear when it is turned off.

If the remote system seems not to be echoing input, especially after a graphics program has been interrupted, the problem may be that the textport has been left off. Issue this command to turn it back on.

~%U Unlock the keyboard. Whenever the IRIS is accepting graphics

commands, the keyboard is locked and any input from it is thrown away. Use this command to force characters through to the remote system, such as the interrupt character to kill the remote program. The keyboard will be locked again at the next switch back into graphics mode.

~%X Toggle the value of the –x option (see Section 5.3.2). This option

determines whether the handling of x o n (

CTRL-q

) and x o f f

(

CTRL-s

) is done locally.

~%Zn Toggle the value of the –z n option (see Section 5.3.2). Currently,

the only valid value for n is 1.

The escape character can be changed from ‘~’ with the –e option specified in the wsiris configuration file (see Section 5.3.2). If –e none is specified, there is no escape character and none of the above interpretations occur. In this case, if the window manager is not running, there is no way to force wsiris to exit.

If the remote program queues the keyboard, all keystrokes will normally accumulate in the event queue. To divert them to wsiris—in order to, for example, issue one of the ‘~’ commands described above—hold the

SETUP

key down while typing. The events from individually queued keyboard keys are also not placed in the queue while

SETUP

is down. See the IRIS User’s Guide for

further information on queuing the keyboard and the event queue.

5.2.3 Running a Demonstration Program

After booting a new IRIS 3010 and connecting to a host, you should test the system by running a demonstration program. The hard disk that comes with the IRIS 3010 contains a non-bootable copy of the flight demonstration program. To run flight from the hard disk, you must first boot Un i x on the terminal, then escape into the C shell and run the program from the shell.

5-6 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.1

IRIS 3010 System Administration

1. Boot the terminal from the hard disk, as described in Section 3.2.

2. When the wsiris terminal emulator is running, enter the sequence ~! to enter the C shell:

Connect to what host? ~!

The terminal displays the C shell prompt:

3. To run the demonstration program, enter the pathname:

~demos/flight

The first screen of the flight program appears.

4. To leave the flight program, press the

ESC

key.

The IRIS again displays the C shell prompt.

5. To return to the terminal emulator program, enter the exit command:

exit

5.2.4 Shutting Down the IRIS Terminal

To shut down an IRIS 3010 running wsiris:

1. Issue the ~

DEL

command.

2. Set the

Power

switch on the front of the cabinet to the

Off

position.

5.2.5 Boot Failure Recovery

If a critical file on the IRIS 3010 disk becomes corrupted, the boot procedure fails and the terminal emulator does not run. If this happens, use the procedure in this section to restore the file system from the copy stored on the backup partition of the disk.

1. Turn control of the IRIS over to the PROM monitor by setting configuration switches 1 through 5 to “OCOCC” and resetting the terminal (see Section 3.4).

Version 1.1 SERIES 3000

IRIS OWNER’S GUIDE 5-7 IRIS 3010 System Administration

2. Boot the recovery system:

iris> b md0c:recover

This will boot a copy of the Un i x kernel on the backup partition,

and run a program to copy the backup partition onto the normal operating partition. After this program is finished, it returns control of the IRIS to the PROM monitor, which displays its prompt:

iris>

3. Boot the terminal normally from the local disk (see Section 3.2).

4. Repeat the configuration sequence described in Section 5.3 .

If this procedure fails to return the IRIS to its former working state, the problem may be more serious than a corrupted file system. Contact Silicon Graphics field service personnel through the Geometry Hotline number listed in Chapter 1.

If you are familiar with Un i x , you can use a 9600 baud ASCII terminal connected to

Port 2

of the IRIS 3010 to log in as root. This may be useful for diagnostic purposes in case the standard console textport is not functioning properly. To connect an ASCII terminal to the IRIS, see Section 7.1.

5.3 Software Conguration

The IRIS 3010 software is based on the same System V Un i x kernel used on the IRIS 3020 and 3030. IRIS 3010 users do not necessarily interact with Un i x , however, because the terminal emulator program running on top of Un i x provides an interface almost identical to the interface on IRIS terminals. The terminal emulator interface is described in Section 5.2.

Because the IRIS 3010 is Un i x -based, the IRIS window manager runs on it. The window manager is described in the IRIS User’s Guide, Version 2.1.

An IRIS 3010 can be ordered with both XNS and TCP/IP Ethernet communication capabilities. Configuration of the IRIS 3010 for network communication is not necessary for normal operation, but some configuration can simplify the process of communicating over the network and can increase the terminal’s communication capabilities.

5.3.1 Conguration Tools

A number of files stored on the IRIS 3010’s hard disk allow for three kinds of configuration:

•Startupenvironmentconfiguration(seeSection5.3.2).

5-8 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.1

IRIS 3010 System Administration

•Networkcommunicationconfiguration(seeSections5.3.3and5.3.4).

•MiscellaneousUn i x configuration (see Section 5.3.5).

The following subsections describe these files in detail. Samples of the configuration files are duplicated in the host software distribution.

If you are familiar with Un i x and its utilities, you can edit these files locally on the IRIS 3010, using the wsiris shell escape command (~!) and the vi editor. If you prefer, you can edit the files on the host, using whatever text editor is most familiar to you, then transfer the files to the disk on the IRIS 3010. This strategy has the advantage of leaving backup copies of the customized configuration files on the host.

To support configuration of the IRIS 3010 from a host, the host software distribution includes two utility programs: iftp and irsh. Both programs are available when you are logged on to the remote host from the IRIS 3010. These commands are run from the host while the IRIS 3010 is running wsiris.

File Transfer Program

The iftp program transfers files between the host and the IRIS 3010. The command takes three arguments:

iftp mode hostfile 3010file

Mode can have one of three values:

w Write hostfile to 3010file. A temporary file on the IRIS 3010 is written

to and then renamed.

o Overwrite. As w, but the temporary file is not made.

r Read from 3010file, write to hostfile.

3010file must be an absolute pathname (i.e., it must start with ‘/’).

Local Execution Program

The irsh program issues commands to the Un i x operating system running on the IRIS 3010 from the host. The program takes the IRIS 3010 Un i x command and arguments as its arguments:

irsh 3010cmd arg ...

The main uses of irsh are renaming and removing files on the IRIS 3010 disk.

To rename the file oldname to newname, enter this sequence:

irsh mv oldname newname

Version 1.1 SERIES 3000

IRIS OWNER’S GUIDE 5-9 IRIS 3010 System Administration

To remove file, enter:

irsh rm file

Conguration from a Unix Host

After the distribution software has been installed on the Un i x host, you can use this procedure to configure the IRIS 3010 from the host:

1. Boot the IRIS 3010 from its local disk and log in to the host (see Section 3.2).

2. Change directories to /usr/iris/c.

$ cd /usr/iris/c

3. Edit the configuration files as described in the remainder of this chapter.

4. Transfer the files to the IRIS 3010 by invoking the iftp program for each file. To transfer all files in a single step, use the makefile argument install-config-files.

$ make install-config-files

5.3.2 Conguring the Startup Environment

You can configure the startup environment on the IRIS 3010 in these ways:

1. Custom-configuring the terminal emulator program, wsiris.

2. Causing the window manager to start automatically during bootstrap.

3. Installing your own startup program.

The next three sections describe these procedures.

Terminal Emulator Conguration

The terminal emulator program, wsiris, is customized through the file .wsirisrc. The working copy of .wsirisrc is stored on the IRIS 3010’s hard disk. The file contains any number of the option flags listed below, separated by whitespace (spaces, tabs, and newlines), and possibly followed by a hostname. Arguments to individual option nags are separated from their options by whitespace.

5-10 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.1

IRIS 3010 System Administration

The file may contain any of these options:

–d n Debug. You may use multiple –d options. The legal values for n are:

1 Generate a logfile, named /LOGFILE.0, of the communication

between the IRIS 3010 and the host. Graphics commands and data are interpreted and written to the logfile as a command name and a series of arguments. The arguments are shown as type=value, where type is a single character representing the argument type:

a, A array b, B byte (8 bits) c, C character string f, F float (32 bits) l, L long (32 bits) s, S short (16 bits) o logical (8 bits) O logical (32 bits)

If the character is capitalized, then the the argument was sent

by the IRIS, otherwise it was sent by the remote system. The value of array types is always ‘array’.

3 Use the next argument for the name of the logfile created by

the –d 1 option in place of /LOGFILE.0.

–e c Set the escape character from the default ‘~’ to c. Lines beginning

with the escape character can be commands to wsiris. If c is none, there will be no escape character.

–h Use half-duplex serial communications. The default is full-duplex.

–i Try the TCP/IP communication protocol first. When using Ethernet

communications in the absence of the –i option, the system first attempts a connection to hostname using XNS protocols. If that fails, a connection using TCP/IP is then attempted.

–l line Use device line for the serial connection. The device names of the

three available serial ports of the IRIS 3010 are:

Port 2 ttyd1 Port 3 ttyd2 Port 4 ttyd3

The default line is ‘ttyd2’.

–p Print textport output even when the textport has been turned off. By

default, after the receipt of a tpoff command from the remote system, all textport output is thrown away until a tpon is received. (See the IRIS User’s Guide for information on tpoff and tpon.) The -p option inhibits this, and characters written to the textport will appear when

Version 1.1 SERIES 3000

IRIS OWNER’S GUIDE 5-11 IRIS 3010 System Administration

it is turned on again.

–s speed Use speed baud for serial communications. The legal values for speed

are:

75 110 134 150 300 600 1200 2400 4800 9600 19200

The default is 9600.

–x Enable local x o n /x o f f flow control. Normally, when read from the

standard input, the characters x o n (

CTRL-q

) and x o f f (

CTRL-s

) are sent to the remote system. Specifying this option causes them to be used locally to stop and restart the display of text. When using serial communications, this option also enables the use of these characters by the serial driver of the IRIS for automatic flow control of data being received from the host. This automatic flow control is normally disabled as it will not work correctly if there are two independent sources of these characters.

–y If using serial communications, interpret x o n and x o f f characters

from the remote host as output flow control commands. By default, they are treated as ordinary data. You must not give this flag if you are using eight-bit (fast mode) communications.

–z n Special instructions. Multiple –z options can be given. The legal

values for n are:

1 Interpret ginit commands as gbegin commands. (See the

IRIS User’s Guide for information on ginit and gbegin.)

2 Execute a ginit immediately upon startup. This is useful

when wsiris has had to be restarted and the remote program is still sending graphics commands.

3 When attempting a connection using Ethernet

communications, try only one network protocol instead of both. TCP/IP is tried if the –i flag is given, and XNS if it isn’t.

4 Emulate a Tektronics 4010.

5-12 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.1

IRIS 3010 System Administration

Following the option flags, a hostname can be specified. Doing this causes wsiris always to connect to this host and not to give the prompt:

Connect to what host?

The IRIS 3010 is shipped with a default /.wsirisrc file that contains these options:

-z 3 -x

The host distribution contains a copy of this file named wsirisrc. To configure the IRIS 3010 from the host, edit the host copy of the file, then transfer it to the IRIS with this command:

iftp w wsirisrc /.wsirisrc

The default configuration file may not work for some serial communications environments, e.g., if half-duplex is required. In this case, /.wsirisrc will have to be edited locally on the IRIS 3010.

If an invalid /.wsirisrc is put on the IRIS 3010 disk, it will not boot correctly. If this happens, use the boot failure recovery procedure described in Section

5.2.5.

Window Manager Conguration

The IRIS 3010 can be configured to start the window manager, mex, automatically. The window manager options are controlled through the file /.mexrc. The IRIS User’s Guide contains a description of what mex expects to find in this file. The default configuration file on the IRIS 3010 is different from the one described in the IRIS User’s Guide.

The boot sequence checks for the existence of /.mexrc. Only if it finds one will mex be started. The IRIS 3010 is shipped with the default window manager configuration file with the name /mexrc, which means that mex is not started up during bootstrap. To have mex start automatically, change the filename to /.mexrc by entering this command on the host:

irsh mv /mexrc /.mexrc

To disable mex once it’s been enabled, enter:

irsh mv /.mexrc /mexrc

Version 1.1 SERIES 3000

IRIS OWNER’S GUIDE 5-13 IRIS 3010 System Administration

The host distribution contains a copy of mexrc. After editing this file, you can copy it to the IRIS with this command:

iftp mexrc /.mexrc

Installing Your Own Startup Program

The program that the IRIS 3010 runs after booting can be changed from wsiris to a custom startup program. To do this, edit the file /bin/tesh and find the line:

set termemul = /bin/wsiris

Replace /bin/wsiris with the pathname of the program you want to have run.

If the IBM option is installed, t3279 is run instead of wsiris, and this line in /bin/tesh must be changed:

set termemul = /bin/t3279

Replace /bin/t3279 with the pathname of the program you want to have run.

If you add custom files to the root partition, you should duplicate them on the backup partition so that they can be restored in case of boot failure. Before copying these files, make sure that the IRIS boots and correctly runs your startup program. The IRIS 3010 disk contains a script, /etc/rootcopy, that copies the entire root partition to the backup partition. Run rootcopy, specifying the argument ok:

rootcopy ok

5.3.3 XNS Conguration

Operation of the IRIS 3010 using XNS requires no configuration. The IRIS does not need a hostname, since it initiates all connections, and the XNS protocol does not require that both ends of a circuit have a name.

The terminal emulation program can be configured to initiate a connection to a single host automatically every time it is started up. This procedure is documented in Section 5.2.1.

5.3.4 TCP/IP Conguration

The TCP/IP option to the IRIS 3010 terminal is configured with the hostname file /etc/sys_id, and the host tables /etc/hosts and /etc/hosts.equiv. The hostname

5-14 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.1

IRIS 3010 System Administration

Version 1.0 SERIES 3000

IRIS OWNER’S GUIDE 5-15 IRIS 3010 System Administration

file contains the hostname of the IRIS 3010. The information that goes into the host tables is described in the documentation that accompanies the communications software.

A sample hostname file, sys_id, is included in the host distribution. To give the IRIS 3010 a hostname, edit this file to contain the desired name, and then enter the command:

iftp w sys_id /etc/sys_id

Hostnames must not be more than eight characters.

Next, create the two host table files on the host. Then transfer them to the IRIS 3010 terminal disk. If, for example, the two files on the host are named hosts and hosts.equiv, enter these commands:

iftp w hosts /etc/hosts iftp w hosts.equiv /etc/hosts.equiv

Until these files exist on the IRIS 3010, the terminal emulator always prompts for the Internet addresses of the IRIS and the host. Once the terminal emulator knows the local address, it prompts only for the host address.

The terminal emulator can be configured to initiate a connection with a single host automatically each time it is started up. This procedure is documented in Section 5.2.1.

If the IRIS 3010 disk contains an invalid /etc/hosts file, it will probably not be able to communicate with the host. To recover from this situation, use one of these strategies:

•Edit/etc/hosts locally on the IRIS 3010.

•Transferavalidcopyfromthehostovertheserialcommunicationsline.

•UsethebootfailurerecoveryproceduredescribedinSection 5.2.5 tostart

over.

5.3.5 Miscellaneous Unix Conguration

Time Zone

Several Un i x utilities need to know the time zone in order to display the time correctly. The time zone entry is contained in the file /etc/TZ. The file has three fields:

1. A three-character abbreviation for the time zone.

5-16 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

IRIS 3010 System Administration

2. The offset in hours of the time zone from Greenwich Mean Time.

3. A three-character abbreviation for the time zone when in daylight savings time. If daylight savings time is not used, this field should be omitted.

The IRIS 3010 is shipped with the time zone set for Pacific Standard Time:

PST8PDT

The file TZ in the host distribution contains a sample time zone file. After you edit it, to transfer it to the IRIS 3010 disk, execute:

iftp w TZ /etc/TZ

Automatic Date Setting

By default, the IRIS 3010 prompts the user to check the date each time it is booted. If an executable file /etc/rc.getdate is found, the user is not prompted, and the result of its execution is used in place of what the user would have typed to the prompt:

Enter the correct date (mmddhhmm[yy][.ss]):

A sample version of this file named rc.getdate is included in the host distribution. It is a shell script that gets the date from an IRIS workstation designated to be the network date server. To use it, edit it and change “host” to be the name of the date server machine. Then execute:

iftp w rc.getdate /etc/rc.getdate irsh chmod a+w /etc/rc.getdate

To disable the automatic date setting, remove /etc/rc.getdate:

irsh rm /etc/rc.getdate

Version 1.0 SERIES 3000

6. Disk Conguration

This chapter covers these topics:

6.1 Disk Specifications

6.2 IRIS Workstation Disk Configuration

6.3 IRIS Terminal Disk Configuration

The tables in Section 6.1 should be used as reference material for the procedures described later in the chapter. Table 6-1 shows the default division of all the available disks into partitions. This chapter explains how to change partition size.

The disks on the IRIS 3010 and 3020 are called md; the disks on the IRIS 3030 are

si. To find out what brand of disk you have on your workstation, issue the

sgilabel command:

IRIS 3010/3020:

sgilabel md0

IRIS 3030:

sgilabel si0

A first disk is disk zero; a second disk is disk 1. Disks are divided into a number of partitions depending on the brand and size; the partitions are labeled with lower-case letters a through g. The two formatter/exerciser programs, mdfex and sifex, correspond to the two types of disk, md and si. These programs enable you to change the size of the swap partition on your disk.

The commands mkfs(1M) and labelit(1M) enable you to configure a second disk. The basic steps in this procedure are making file systems, labeling them, and modifying configuration files so that the file systems are mounted and checked by fsck(1).

6-2 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.0

Disk Conguration

6.1 Disk Specications

Table 6-1 shows the disks available on IRIS series 3000 models, the number of megabytes per cylinder on each disk, and the size of the partitions.

NOTE

The disk on your IRIS 3020 may appear to have more space than is shown below, but this space is not supported by Silicon Graphics’ software.

On all disks, partition g represents the entire disk and can be used in place of, not in addition to, the other partitions. For the IRIS 3030 only, the f partition is a combination of the c and d partitions.

Table 6-2 contains estimates of the disk storage requirements for Un i x software, the IRIS Graphics Library, and options that are available for the IRIS. These estimates fluctuate slightly from one release to the next as new utilities and other software are added to the system.

IRIS Model/ Disk Drive

Mb/Cyl. Partitions Cylinders Mb

IRIS 3010

Tandon

.0348

md0a md0b md0c md0g

123 360 123 606

4.28

12.53

4.28

21.1

IRIS 3020

Vertex (Priam)

Maxtor

.0609

.0696

md0a md0b md0c md0g

150 149 670 969

150 149 586 885

9.14

9.08

40.82

59.04

10.4

10.38

40.8

61.58

IRIS 3030

.163

si0a si0b si0c si0d

si0f

si0g

56 103 200 446

646

805

9.18

16.88

32.77

73.07

105.84

131.89

Table 6-1: Disk Partition Sizes

Software Category Space Required

(Megabytes)

Total, minimum system: 16.00

On-line manual pages (/usr/man/*) Demonstration programs (/usr/people/demos/*) Games (/usr/games/*)

2.50

4.25

1.25

Compiler Options:

FORTRAN compiler option Pascal compiler option

1.00

0.50

Other Options:

IEEE 488 communications option TCP/IP communications option IBM option Emacs text editor

Total with all options installed:

0.50

1.00

0.75

2.00

30.00

Table 6-2: Disk Storage Requirements

6.2 IRIS Workstation Disk Conguration

The three subsections below describe these procedures:

• ChangingtheswappartitionsizeonanIRIS3020

• ChangingtheswappartitionsizeonanIRIS3030

•ConfiguringaseconddiskonanIRIS3020/3030

If you have an IRIS 3010, see Section 6.3.

On an IRIS 3020 or 3030, disk zero is divided into three partitions: the root partition, which contains the root file system; the swap partition, which is used by Un i x for paging; and the user partition, which contains the /usr file system. On an IRIS 3020, the root partition is device md0a, the swap partition is md0b, and the user partition is md0c. On an IRIS 3030 the root partition is device si0a, the swap partition is si0b, and the user partition is si0f.

The size of the swap partition determines the maximum amount of virtual memory that can be used. At any instant in time, the sum of the sizes of all the processes known to Un i x cannot exceed the size of the swap partition.

If the simultaneous processes running on your workstation require more space on the swap partition, you can make it larger at the expense of some of the free space in the user file system. You can increase the space available for user files by reducing the swap partition size, but this reduces the total of the process sizes that can exist simultaneously on the system.

Version 1.1 SERIES 3000

IRIS OWNER’S GUIDE 6-3 Disk Conguration

To find out the size of the swap partition on your workstation, issue the command:

IRIS 3020:

sgilabel md0

IRIS 3030:

sgilabel si0

The sgilabel command prints out the disk drive label. The label includes the brand of disk drive and the size of each partition. Table 6-1 also gives the size of each partition for the IRIS 3020/3030.

6.2.1 Changing the Swap Partition Size on an IRIS 3020

To change the size of the swap partition on an IRIS 3020, follow the steps below. For simplicity, the procedure describes a specific, although arbitrarily chosen, change: an increase of 100 cylinders.

1. Log in as root:

2. Back up the /usr file system and make sure you have a bootable backup tape, in case the root file system is unintentionally corrupted (see Section 4.4).

3. Reboot the workstation:

reboot

4. Boot the disk formatter program:

b stand/mdfex

CAUTION

You must follow all instructions exactly when you use the fex disk formatter programs. Failure to follow instructions could result in serious damage to your file system.

5. When the mdfex prompt appears, enter the letter s, then l, to display the drive label on your screen.

6-4 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.1

Disk Conguration

6. Press

RETURN

.The entry below appears.

a: base; (1) size; (150)

Press

RETURN

to accept this entry. This entry indicates that partition

md0a begins at cylinder 1 and has a size of 150 cylinders.

Partition md0a is the root partition and does not change.

7. To add 100 cylinders to the swap partition (md0b), 100 cylinders must be subtracted from the user partition (md0c). The base, or beginning, of partition c changes by 100 cylinders. Type the revised entries after the numbers in parentheses:

Vertex:

b: base; (151) size; (149)249 c: base; (300)400 size; (586)486

Maxtor:

b: base; (151) size; (149)249 c: base; (300)400 size; (670)570

8. Continue to press

RETURN

until the workstation displays the Set?

prompt.

9. Enter q twice to quit both the set function and mdfex. The workstation displays the mdfex prompt and the message:

Quit Label on drive 0 needs updating... do it?

10. Confirm your intention to update the drive label by entering y. The workstation displays the message:

--confirm quit with ‘y’:

11. Type y to confirm your intention to quit mdfex and return to the PROM monitor. The PROM monitor prompt appears.

12. Boot the system in single-user mode:

Version 1.1 SERIES 3000

IRIS OWNER’S GUIDE 6-5 Disk Conguration

13. Make the new, smaller user file system:

mkfs /dev/rmd0c

14. Name the file system and give it a volume name with the labelit command:

labelit /dev/rmd0c usr sgi

15. Mount the /usr file system:

mount /dev/md0c /usr

16. Restore the /usr files from tape:

cd /usr tar xv or cpio -ihmud1v

17. Unmount /usr.

umount /dev/md0c

18. Check the file system:

fsck /dev/rmd0c

19. Make a new bootable backup tape (see Section 4.4.1).

20. Begin multi-user mode:

multi

6.2.2 Changing the Swap Partition Size on an IRIS 3030

To change the size of the swap partition on an IRIS 3030, follow the steps below. For simplicity, the procedure describes a specific, although arbitrarily chosen, change: an increase of 100 cylinders.

1. Log in as root:

6-6 IRIS OWNER’S GUIDE

SERIES 3000 Version 1.1

Disk Conguration

2. Back up the /usr file system on partition si0f and make sure you have a bootable backup tape, in case the root file system is unintentionally corrupted (see Section 4.4).

3. Reboot the workstation:

reboot

4. Boot the disk formatter program:

b stand/sifex

CAUTION

You must follow all instructions exactly when you use the fex disk formatter programs. Failure to follow instructions could result in serious damage to your file system.

5. When the sifex prompt appears, enter the letter s, then l, to display the drive label on your screen.

6. Press

RETURN

. The entry below appears.

a: base (1) size (56)

This entry indicates that partition si0a begins at cylinder 1 and has a

size of 56 cylinders.

Partition si0a is the root partition and does not change. Press

RETURN

7. To add 100 cylinders to the swap partition, subtract 100 cylinders from the /usr partition (partition f). Type the revised entries after the numbers in parentheses:

b: base; (57) size; (103)203 c: base; (160) size; (200) b: base; (360) size; (446) c: base; (160)260 size; (646)546

8. Continue to press

RETURN

until the workstation displays the Set?

prompt.

Version 1.1 SERIES 3000

IRIS OWNER’S GUIDE 6-7 Disk Conguration

9. Enter q twice to quit both the set function and sifex. The workstation displays the sifex prompt and the message:

Quit Label on drive 0 needs updating... do it?

10. Confirm your intention to update the drive label by entering y. The workstation displays the message:

--confirm quit with ‘y’:

11. Type y to confirm your intention to quit sifex and return to the PROM monitor. The PROM monitor prompt appears.

12. Boot the system in single-user mode:

13. Make the new, smaller user file system:

mkfs /dev/rsi0f

14. Name the file system and give it a volume name with the labelit command:

labelit /dev/rsi0f usr sgi

15. Mount the /usr file system:

mount /dev/si0f /usr

16. Restore the /usr files from tape:

cd /usr tar xv or cpio -ihmud1v

17. Unmount /usr.

umount /dev/si0f

18. Check the file system:

fsck /dev/rsi0f
