Irig HD 2 User Manual

Guitar interface

USER MANUAL

Contents

Table of Contents

Contents 2

English 3

iRig HD 2 3
Register your iRig HD 2 3
Installation and setup 4

iOS devices 4
Mac 7

Setting input gain on iRig HD 2 8
Amplifier output jack 8

THRU-FX switch 9

Headphone output jack 9
Stand adapter 9
Troubleshooting 10
Specifications 10
Warranty 10
Support and more info 10

Regulatory 11

2

English

iRig HD 2

Thank you for purchasing iRig HD 2.

Your package contains:

• iRig HD 2

• USB cable

• Lightning cable

• Velcro clip

• Velcro strip

• Quick Start Guide

• Registration Card

1x

1x

1x

1x

1x

iRig HD 2 is the successor of the wildly popular iRig HD digital guitar interface for iPhone, iPad, Mac & PC. This
new version of the iRig HD 2 is packed full of player-centric features in an all new enclosure. A new micro-USB
port replaces the mini-DIN connector, and lightning and USB cables are included. iRig HD 2 includes a new
1/8” headphone output with preamp and level control, perfect for newer devices without dedicated headphone
output jacks. There’s also a new 1/4” unbalanced T/S (Tip/Sleeve) “Amp Out” jack that works in two modes
thanks to the amp out switch: THRU and FX. The THRU setting sends the dry, unprocessed guitar signal to the
Amp Out jack, the FX setting sends the processed signal coming from your device or computer to the Amp Out
jack. These settings are designed to allow you to use your device in live playing and recording situations. Also
you can optimize the input level of your instrument with the input gain control thumbwheel.

Register your iRig HD 2

By registering, you can access technical support, activate your warranty and receive free JamPoints™ which will
be added to your account. JamPoints™ allow you to obtain discounts on future IK purchases! Registering also
keeps you informed of all the latest software updates and IK products.

Register at: www.ikmultimedia.com/registration

3

English

Installation and setup

iOS devices

1. Connect the included micro-USB cable to the iRig HD 2.

2. Connect the cable to the Lightning port on your device.

1

2

3. Connect your guitar, bass or other mono instrument to the 1/4” input jack on iRig HD 2.

1/4"

4
