Ipevo S0-10 Specifications

Skype Desktop Phone

Make Skype Calls to Anywhere in the World Without a
Computer

S0-10

NO COMPUTER REQUIRED

IPEVO S0-10 is a Skype-embedded Internet phone that enables Internet calls
without using a computer. An always on, dedicated device, S0-10 makes Skype
calls as easy as using a regular telephone.

Always on, always available

S0-10 is developed to allow users to use Skype with the familiarity of a regular
desktop phone. It is always on and always available for Skype-to-Skype, SkypeIn,
SkypeOut and Skype Voicemail.

Simple set-up: plug in, log in, and call

S0-10 works wherever a broadband Internet connection is available. Setting up is
as easy as plugging in the network cable, log in to your Skype account, and just
pick up to make a call!

Friendly operation, with familiarity and functionality of a traditional telephone

The user-friednly Skype interface is displayed on 2.4" TFT color LCD, making
operating the functions simple and easy. Additional convenient features include a
built-in speakerphone and 3 quick-dial keys.

Key Features

• No computer required

• Simple plug-and-connect to set up

• 2.4" TFT color LCD display with adjustable viewing angle

• Excellent voice quality with echo cancellation

• Support Skype-to-Skype, SkypeOut, SkypeIn and Skype Voicemail

• One click speakerphone function for hands-free talks

• Memory keys for speed dials

• LED for indications of power on/off, missed call, message, mute and
speakerphone mode

CHIP Magazine, Germany
Product of the Month, October 2007

IPEVO creates Internet devices that expand and enhance the overall Experience over the Internet. Renowned for its iconic line of best-selling VoIP and Skype hardware, IPEVO has established a reputation for
innovating award-wining designs and affordable products to help make the Internet a better place for what matters most – connecting, communicating, and sharing with the world around us.

www.ipevo.com | Email: [email protected] | TW Tel: [phone] | TW Fax: [phone] | USA Tel: [phone] | USA Fax: [phone]

Package Content

• IPEVO S0-10 Skype Desktop Phone

• Switching power adaptor (100-240V 50-60Hz)

• CAT5 Ethernet cable

• Quick Guide

Dimension / Weight

• Size: 19.3x16.8x6.2cm (LxWxH)

• Weight: 600g

Color

• Black body with white handset

Control Button

• Dial / Answer

• Redial

• Mute on / off

• Speakerphone on / off

• Volume

• Status indication

• Full color LCD display

• Function command

• Main menu navigation key

• Cancel / Hang up

• Speed dial keys

LED Indication

• Blue Power LED:

Power on / off

• Green Active LED to indicate:

Incoming calls

Unread voicemails

Missed calls

Call established

Network protocols

• Static IP, DHCP, PPPoE

• TCP/UDP/IPV4

• DNS

Audio Performance

• Voice codecs: G.729AB

• Voice sampling rate: 8KHz

• Communication: Full Duplex

• Echo cancellation in speakerphone mode

Hardware Descriptions

• USB interface 1.1 reserved for extension modules

• Audio

• 8Ω 2W Speaker

• Network interface

• Fast Ethernet 100Mbps

• Auto crossover detection

• Auto rate detection

• Integrated 2-port fast Ethernet switch (2xRJ-45)

Electrical Specifications

• Operating Voltage: 5VDC 2000mA

System Requirements

• Broadband Internet connection (DSL, Cable Modem…, etc)

• Broadband modem, router or gateway

Regulatory Compliance

• FCC

• CE

• VCCI

• RoHs

WiFi Network Adapter

For IPEVO S0-10 Skype Desktop Phone

• Upgrade S0-10 to access wifi connection

• Adjustable antenna to maximize wifi reception

• High speed wireless transmission. Clear and stable sound quality

Package Content

• IPEVO WiFi Network Adapter

• USB cable

• CD-ROM containing installation guide and S0-10 upgraded firmware

• Quick Guide

Dimension / Weight

• Size: 57.15(L)x76.2(W)x12.7(D)mm

• Weight: 30g

LED Indication

WIFI activity LED: Green Blinks when there is activity on the wifi connection

USB activity LED: Steady green when the USB connection is active

Wifi protocols support

• IEEE 802.11b/g

• WEP64/WEP128

• WPA-PSK/WPA2-PSK/TKIP/CCMP

Regulatory Compliance

• FCC class B • CE class B • NCC • RoHs

Color

• Black

Hardware Descriptions

• USB 1.1/2.0

System Requirements

• S0-10 Skype Desktop Phone
