Page 1
Skype USB Handset
The First USB Handset Designed Exclusively for Skype
FR-33.1
IPEVO's Best-selling USB handset for Skype
As one of the first plug-in handsets designed exclusively for Skype, IPEVO FR-33.1
has earned a reputation for its seamless integration with the world's most popular
VoIP software in an easy-to-use device.
Simple, intuitive and fully integrated with Skype
The functions and buttons on the FR-33.1 are tailor-made for the Skype experience,
which takes a lot of the guesswork out of placing calls via a computer. A "s" key
activates the Skype window on your desktop, a toggle "buddy job" to let you
effortlessly scroll through your contact list. Or simply press the "+" key to initiate a
SkypeOut call, and use the number pad to dial out just like a regular telephone.
Exceptional sound quality with noise and echo cancellation
Engineered and optimized for Skype, FR-33.1 delivers exceptionally clear call
quality with 16K sampling rate for Skype-to-Skype calls, and 8K sampling rate for
calls to landlines. The unique "hollow" mouthpiece design minimizes the annoying
"echo" effect.
Key Features
• PC and MAC compatible
• Integrated Skype interface
• Excellent voice quality with echo cancellation
• Programmable buttons to enable customization
• Lightweight and ergonomic design
• Available in black and white
• Awards: iF, reddot, G-Mark, I.D. magazine honorable mention
Also available for a wide range of VoIP platforms
(incl. Microsoft Office Communicator, Avaya solutions, etc)
IPEVO creates Internet devices that expand and enhance the overall Experience over the Internet. Renowned for its iconic line of best-selling VoIP and Skype hardware, IPEVO has established a reputation for
innovating award-wining designs and affordable products to help make the Internet a better place for what matters most – connecting, communicating, and sharing with the world around us.
www.ipevo.com | Email: [email protected] | TW Tel: +886-2-5550-8686 | TW Fax: +886-2-2382-0420 | USA Tel: +1-877-269-4738 | USA Fax: +1-408-324-0718
Page 2
Package Content
• IPEVO FR-33.1 Skype USB Handset
(USB cord with Type A connector)
• Installation CD (including API driver, E-Manuals, link to online
download of Skype™ software)
• Quick Guide
Dimension / Weight
• Size: 15x3.8x2.5cm (LxWxH)
• Weight: 65g
Color
• Black
• White
Control Button
• Dial / Answer
• Select contacts
• Skype window launch
• SkypeOut [+]
• Contact list
• Cancel / Hang up
• Numeric, *, #
• MIC mute
• Programmable keys*3
• Volume control
LED Indication
• Green light to indicate incoming call, call in progress, mute, and
hang-up status
USB Audio Features
• Support AGC (auto gain control) function
Ring Tone
• 11 selected ring tones (including silent mode)
Electrical Specifications
• Operating Voltage: 4.5V ~ 5.5V
• Power Consumption:
Suspend Mode < 1mA ;
Standby mode < 70mA ;
Operating < 100mA @ Full Scale 1KHz Tone
• Dynamic Receiver (speaker):
Impedance: 32 Ohm +/- 15%
Maximum Output power: 96mW
Frequency Range: 300Hz ~ 3400Hz
• Magnetic Transducer (Buzzer):
Coil Resistance: 5.5 +/- 2.0 Ohm
Sound Pressure Level: Min 80dB @ 10cm
Condenser Microphone
• Omni directional
• Sensitivity: -46 +/- 3 dB
• Frequency Range: 70 ~ 20,000 Hz
System Requirements
• Microsoft Windows XP and Vista
• Mac OS X 10.4 up
• 400MHz processor
• 128MB RAM
• 40MB free hard disk space
• USB port (USB 2.0 compatible)
• CD-ROM drive
• Broadband Internet connection (DSL, Cable Modem and etc)
Regulatory Compliance
• FCC
• CE
• RoHs
IPEVO corp
3F, No.53, Bo-ai Road, Taipei 100, Taiwan
Tel: +886-2-5550-8686 | Fax: +886-2-2382-0420
Email: [email protected] | www.ipevo.com
IPEVO, Inc. (USA)
2860 Zanker Road, Suite 100, San Jose, CA95134, USA
Tel: +1-877-269-4738 | Fax: +1-408-324-0718
Email: [email protected] | www.ipevo.com
Also available for a wide range of VoIP platforms
(incl. Microsoft Office Communicator, Avaya solutions, etc)
