+ code”.
Mobile Ext. enhanced, mobile receives hunt calls and support for Attd. Recall.
4. d3
30-Sep-07
Updates for iPECS release 4 software (General edits for errata).
Emergency Call Attendant Alert
Automatic Daylight Savings Time (DST) Adjustment
Direct Inward Dialing (DID)
Automatic System Time Synchronization
Distributed Systems Network, paging
E-911 support for Emergency dialing
VSF/VMIM Outbound Notification to Pager or External Phone
TLS for Web Admin and Webphone
5.0
26-July-08
General updates & errata
Change “MFIM” references to “iPECS, include iPECS 50 and updated
capacity table
Reference to VSF/VMIM announcement changed, expansion from 20 to 70
codes, VSF MOH code 21 or 71) Multi-language code 22 or 72 throughout.
Updates for iPECS release 5 software
One-time DND forward
For TNET added paging reference and RTP description.
Device Zone Management
Call Coverage enhancement
SIP Extension support
Tenancy Group ring mode for Flexible DID/ICLID
Station ICR
Conference Group w/recording)
iP Bridge
Cabinet Alarm
NMS
System DECT
DISA Call Forward removed
Added LIP-8000 series soft key operation for auto dial features (LNR, SAVE,
etc.
Added Attendant active MFIM display
Updated Table 1.2-1 and updated VSF capacity
Call Forward using external number added
Added Option for voice mail attachment to e-mail
Change BGM operation
SMDR ICM added
5.0d1
07-Jan-09
Add in capacity table and Changed for iPECS-1200
5.0d2
17-Feb-09
Add group name for Terminal/Circular/VM/UCS.
5.0d3
13-Apr-09
Add condition 3 in 2.72.3.6 (Voice Mail Back-up Station).
5.0d4
12-May-09
Update for outgoing mailbox destination
5.0d5
02-Feb-10
Update description of DID call wait feature
5.5
09-JUL-10
Updates for iPECS release 5.5B software
Add IP Watch timer for cpu redundancy and IPCR
5.5d1
30-DEC-10
Updates for iPECS release 5.5C software
5.5d2
30-JUL-11
Updates for iPECS release 5.5D software
5.6
01-NOV-11
Updates for iPECS release 5.6 software
Add IP-Attendant
This document provides detailed information covering description and operation of the
numerous features available in the iPECS Series Release 5 system software. The document
is written assuming the system employs the default-numbering plan for North America.
1.1.1 Organization
Features are arranged alphabetically in six different major groupings as follows:
Section 2 System Features
Section 3 Intercom Features
Section 4 CO/IP
Section 5 iPECS Phone
Section 6 Attendant Position
Section 7 SLT
1.1.2 Feature Information
Each section is an alphabetical listing of features with the description and operation of each.
The structure is divided into 6 parts as below:
Description: explains the nature of the feature.
Operation: gives detailed step-by-step operation of the feature for iEPCS IP
Phones and SLTs.
Conditions: explains known feature interactions and constraints related to
the feature.
Programming: lists database entries that may be required for proper
feature operation.
Reference: lists related topical information to aid in understanding the
feature.
Hardware: lists hardware required for proper feature operation.
The iPECS Series is available in several configurations as listed in Table 1.2-1. Total port
capacities range from the 31-channel iPECS-Micro to iPECS-1200 at 1200 ports.
The station and CO Line maximums are not simultaneously achievable ; total ports cannot
exceed the specified System Port capacity.
Note 2
For maximum RSGM connection ports, calculation formula is ports = available system station
ports)/2, there must be sufficient VoIP channels to support packet relay for RSGM rtp packets.
Note 3
Approximately 35 minutes (16 Mbytes) of the VSF memory are used to provide basic system
prompts, the remaining memory can be used for announcements and voice message storage.
Values in parenthesis are the announcement and storage time available.
Note 4
Using G.711 codecs, 8 VoIP channels are available. Due to additional processing needs,
complex codecs reduce the available channels; four (4) channels are available using G.723
or G.729.
Note 5
Issue 0, 1, 2 : Support up to 100 channels (SIP extension + CO trunk) simultaneously Issue
3 : Support up to 200 channels (SIP extension + CO trunk) simultaneously
Note 6
Only Issue 3 MFIM MPB’s ( specifically MFIM100, 300, 600) are suitable/supported for
upgrade to Phase 6 firmware versions. Attempts at upgrading the older MFIM MPB versions
( i.e. issue 0,1 and 2 ) will result in MFIM database and functional failure.
The MFIM50A/B, and MFIM1200 are excluded from this rule.
Station users may allow tracking of specific calls by entering a non-verified variable length (up
to 12 digits) identifier for a call. The identifier or “Account Code” is output as part of the Station
Message Detail Record (SMDR) for the call.
Operation
iPECS Phone
To assign a Flex button for {ACCOUNT CODE} operation:
1. When entering an Account Code during a call, DTMF digits are not heard by the
connected party.
2. A maximum of 1000 {ONE-TOUCH ACCOUNT CODE} buttons may be assigned in
the system.
3. If an Authorization Code is entered as the Account Code, the SMDR record will
show the station number or the bin number for a System Authorization Code rather
than the user entered Authorization Code.
4. If the Forced SMDR Account Code of station is set to “ON”, user should enter an
Account Code prior to placing an outgoing call.
The system can be configured to recognize the status of an external contact (normally open or
closed). The system will signal assigned iPECS Phones when the contact activates. This
capability is commonly employed to provide remote Alarm or Door Bell signals to the user.
Assigned stations receive the Alarm Signal, either a single tone burst repeated at 1-minute
intervals or a continuous tone. The Alarm Signal may be terminated at the user’s phone by
dialing the Alarm Stop code or, if assigned, pressing the {ALARM STOP} button. To rearm the
Alarm function, the alarm condition must be cleared and the Alarm signal terminated.
When used as a Door Bell, assigned iPECS Phones receive a single tone burst each time the
external contact is activated and no reset is required.
Operation
System
At detection of contact operation, the Alarm/Door Bell signal is sent to assigned stations.
iPECS Phone
To assign a Flex button as an {ALARM STOP} button to terminate the Alarm Signal:
[PGM] + {FLEX} + “565” + [SAVE]
To terminate an Alarm Signal while idle:
1. Dial the Flex Numbering Plan code 565, confirmation tone is received and the Alarm
Signal is terminated. If the alarm condition is cleared, the system will automatically
rearm the alarm monitoring.
Or,
2. Press the {ALARM STOP} button.
Conditions
1. The Alarm contacts must be “dry”, no voltage or current source connected.
2. Only an iPECS Phone may be assigned to receive Alarm/Door Bell signals.
3. An iPECS Phone with LCD assigned to receive Alarm/Door Bell signals will show
“ALARM” or “DOOR BELL” as appropriate.
Authorization Codes provide a means to control access to Off Premise Call Forward, Walking
COS, or DISA and may be required for outgoing CO/IP Line or LCR access based on
configuration of the iPECS database. When users dial an Authorization Code that matches an
Authorization Code stored in the database, the system invokes the Station COS or the COS
assigned to Authorization code. Each Authorization code has separate Day/Night mode COS
assignments.
There are two types of Authorization Codes, Station and System. A Station Authorization Code
is specifically related to a given station and intended for a single user. The System
Authorization Codes are intended for use by any station in the system.
The Station Authorization Codes includes the associated station number and the assigned
code. The structure of the System Authorization code can be set as either “*”, or “*” the
Authorization table index and the code digits. The later allows duplicate codes to be employed
using entry of table index to provide a unique identification of the entry.
The Administrator and Attendants are permitted to assign any Authorization code including
codes for another station. Normal users may only assign the Station Authorization code for the
specific station.
Operation
iPECS Phone
To assign a Station Authorization Code:
1. Press the [PGM] button.
2. Dial “33”, the Authorization Code Program Code.
3. Dial the Station number.
4. Dial the Authorization Code (1 to 12 digits).
5. Press the [SAVE] button.
To enter an Authorization Code when second dial tone is received:
1. Dial the station number for the Station Authorization code or, for a System
Authorization Code, dial “*” or “*” and the Authorization table index.
2. Dial the corresponding Authorization Code.
3. Place call as normal.
SLT
To assign a Station Authorization code:
1. Lift the handset.
2. Dial SLT Program Mode Entry code “561”.
3. Dial Station User Program code “33”.
4. Dial Authorization Code (1 to 12 digits).
5. Momentarily press the Hook-switch, receive confirmation tone.
To enter an Authorization Code when second dial tone is received;
1. Dial the station number for the Station Authorization code or, for a System
Authorization Code, dial “*” or “*” and the Authorization table index.
2. Dial the corresponding Authorization Code.
3. Momentarily press the Hook-switch.
4. Place call as normal.
DISA
To enter an Authorization Code when second dial tone is received:
1. Dial the station number for a Station Authorization code or, for a System code, “*” or
“*” and the Authorization table index,
2. Dial the corresponding Authorization Code.
3. Place call as normal.
System Attendant
To assign an Authorization Code:
1. Press the [PGM] button.
2. Dial Attendant Station Program Code ‘031’.
3. Dial station number for a Station code or, for system code, “*” or “*” and the
Authorization table index.
4. Dial Authorization Code.
5. Press the [SAVE] button.
Conditions
1. When a DISA Line is marked for Authorization Code entry, the caller will hear DND
2. A user must enter a valid code within the number of attempts assigned as the FAC
3. A user may enter an Authorization Code from any station to place a CO/IP call using
4. The default Station Authorization code is the station number and “*”.
5. The total number of Authorization codes is provided in Table 1.2-1.
6. CO/IP groups may be configured to require entry of a valid Authorization Code. In
7. If the Check Password option is enabled in the LCR database, when dialed digits
8. An Authorization code may include any dial pad digit except “*” and “#”.
9. Duplicate or conflicting System Authorization codes are not allowed when using the
10. Use of Authorization codes varies based on the system nation code. In some
Warning tone and must input a valid Authorization Code to continue. In case of an
entry error, the user may retry entry of the code. In case of multiple entry errors,
the user may retry entry based on the DISA Retry counter. The station, if assigned,
is forced to COS 7 after repeated attempts fail.
(Forced Account Code) Retry Count. The station, if enabled, is placed to COS 7
after repeated failure attempts.
Walking COS.
this case, a second dial tone is provided when the CO/IP group is accessed. If the
code entered is invalid, error tone is returned and the user must enter a valid code
within the FAC Retry Count.
match the LDT table digits, the system will send second dial tone to request the
user input a valid Authorization code.
older “*” and code operation. For example, code “1234” conflicts with code “123”
and cannot be recognized as a unique code. Since the index operation employs
the table index and the station number forms part of the Station code, conflicts will
not occur and duplicate codes are allowed for these types of Authorization code.
9
iPECS-LIK
STATION
1 Station Account (PGM 112-Btn 19)
2 CO/IP 1 CO/IP Group Authorization (PGM 141-Btn
8)
3 DISA Authorization Code (PGM 142-Btn 5)
SYSTEM
1 DISA Retry Counter (PGM 160-Btn 5)
2 FAC Retry Count (PGM 160-Btn 16)
3 Old Auth Code Use (PGM 161-Btn 16)
4 COS 7 When Auth fails (PGM 161-Btn 17)
regions, particularly the US and UK, a System Authorization code may be required
for DISA access. Entering a Station code on a DISA line will fail in these areas. In
other regions, a System Authorization code can be used with Walking COS.
11. In case of System Authorization code, there is a system base admin option - End
code (#) usage in System Auth Code (PGM 160 – Btn 26).
If this value is set to ON, user must enter End Code (#) after entering authorization
code.
Programming
Related Features
Account Code
Auto Service Mode Control
Direct Inward System Access (DISA)
CO/IP Line Groups
CO/IP Access
Temporary Station COS/Lock
Walking COS
Call Forward
Station User Programming & Codes
CO/IP or intercom calls (except Hands-free Answerback), will be released automatically if the
user does not complete dialing or, for intercom calls, the called party does not answer after a
pre-determined time.
Operation
System
Auto Call Release of Intercom calls:
1. If a station places an intercom call and the called station does not answer in the
Intercom Call Release Time, the call is terminated and the calling user receives
error tone.
Auto Call Release of CO/IP calls:
1. If a station seizes an idle CO/IP Line and does not dial within the CO/IP Call
Automatic Release Time, the call is terminated and the user will receive error tone.
Conditions
1. If the Automatic Call Release Timer is set to “0”, Auto Call Release is disabled.
2. When the handset is used to place a call, the user will receive error tone for 30
seconds followed by 30 seconds of Howler tone and the station is placed in a fault
mode. If on-hook dialing is used, the station receives error tone for one (1) second
and returns to idle automatically.
iPECS ACD incorporates flexible incoming call routing, real-time agent monitoring and
supervision, and call record statistics as well as ACD Event messages for management
reporting. Calls route to an ACD group directly or otherwise including via call transfer, CCR and
ICLID routing.
2.5.1 Agents
2.5.1.1 Agent Auto Connect/Zap Tone
Description
Agents using a headset can have calls from enabled ACD groups connected to them
automatically. This feature removes the requirement for the agent to answer ACD calls
manually. The Agent receives a short tone (Zap Tone), if assigned, and is then connected to
the ACD caller.
Operation
System
When Zap tone is enabled, operation of this feature is automatic.
Conditions
1. The station must be in the headset mode for this feature to operate.
Programming
Related Features
Station Groups
Hardware
iPECS Phone
2.5.1.2 Agent Id Login/Logout
Description
Stations or 4-digit Agent Ids are assigned as members of an ACD group. A station or Agent ID
can be assigned to a maximum of two (2) ACD groups. Each Agent has a unique 4-digit Agent
Id used to login and logout of active ACD group participation. Agents can login from any station
in the system but only at one station. When an Agent logs in, any active login for the Agent is
terminated and the new login is honored. An Agent may login to two (2) groups at one time,
logging into and out of the primary and secondary group separately.
Operation
Agent iPECS Phone
To assign {LOGIN} or {LOGOUT} buttons:
1. [PGM] + {FLEX} + Login or Logout code + ACD Group Number (optional) + [SAVE]
To Login to a primary group using the Agent Id;
1. Lift handset or press [SPEAKER] button,
2. Dial “581” the ACD Agent Primary Login code or press the Login Flex button,
3. Dial the ACD group number,
4. Dial the Agent ID, the agent is logged into the ACD group.
To Logout of the primary ACD Group;
1. Lift handset or press [SPEAKER] button,
2. Dial “582” the ACD Agent Primary Logout code or press the Logout Flex button.
3. Dial the ACD group number,
4. Dial the Agent ID, the agent is logged into the ACD group.
To Login to a secondary group using the Agent Id;
1. Lift handset or press [SPEAKER] button,
2. Dial ‘583’ the ACD Agent Secondary Login code or press the Login Flex button,
3. Dial the ACD group number,
4. Dial the Agent ID, the agent is logged into the ACD group.
To Logout of the secondary ACD Group;
1. Lift handset or press [SPEAKER] button,
2. Dial “584” the ACD Agent Secondary Logout code or press the Logout Flex button.
3. Dial the ACD group number,
4. Dial the Agent ID, the agent is logged out of the ACD Group.
SLT
To Login to a primary group using the Agent Id;
1. Lift handset,
2. Dial “581” the ACD Agent Primary Login code,
3. Dial the ACD group number
4. Dial the Agent ID, the agent is logged into the ACD group.
To Logout of the primary ACD Group;
1. Lift handset,
2. Dial “582” the ACD Agent Primary Logout code.
3. Dial the ACD group number
4. Dial the Agent ID, the agent is logged out of the ACD Group.
4. Dial the Agent ID, the agent is logged into the ACD group.
To Logout of the secondary ACD Group;
1. Lift handset,
2. Dial “584” the ACD Agent Secondary Logout code.
3. Dial the ACD group number,
4. Dial the Agent ID, the agent is logged out of the ACD Group.
Conditions
1. The system outputs ACD events including Login/Logout messages when Discovery
Manager Print is enabled.
2. The Agent Id can be any 4-digit number (0000-9999). iPECS does not verify the
Agent Id, other than requiring that four digits be entered.
3. Any Agent Id may be used to login except at a Hot Desk station where the user
Authorization code is required.
Programming
Related Features
Station Groups
Hot Desk
Authorization Codes (Password)
Hardware
2.5.1.3 Agent Help Request
Description
Agents request assistance from a Supervisor using the ACD Help Code, default 574. Using
iPECS Phones, agents with the {HELP} button can request assistance without interrupting an
active conversation.
Operation
Agent iPECS Phone
To assign {HELP} buttons:
1. [PGM] + {FLEX} + “574” + ACD Group Number (optional) + [SAVE]
To request Supervisor assistance while on an active ACD call,
1. Press the {HELP} button.
SLT
To request Supervisor assistance while on an active ACD call,
1. Hook-flash.
2. Dial “574”, the Agent Help code.
3. Dial the desired ACD Group number.
Conditions
1. Agents receive error tone to indicate there is no active Supervisor.
2. Using the {HELP} button during a call, no signals are sent on the active
conversation and the connected party is unaware of the request for assistance.
Programming
Related Features
Station Groups
Supervisor Help Response
Hardware
2.5.1.4 Agent Queued Calls Display
Description
An Agent can view the queued call status for an ACD group when not on a call, in off-duty or
wrap-up status. In addition, an active Agent can view the queued call status for an ACD
group
while on a call using {Display Call Queue} Flex button. The Call Queue display will show the
ACD group number, the number of calls in queue and the longest queue time.
Operation
Agent iPECS Phone
To assign a {DISPLAY CALL QUEUE} buttons;
1. [PGM] + {FLEX} + “575” + ACD Group Number + [SAVE]
To display ACD Call Queue status when the Agent is idle and on-duty;
1. Lift the handset or press the [SPEAKER] button.
2. Dial “575”, the ACD Call Queue status code
3. Dial the ACD Group number. The display shows the Queued call status and will
update as the queue status changes. If no calls are in queue, the phone returns to
idle.
4. Hang-up to return to idle and normal display.
Or,
1. Lift the handset or press the [SPEAKER] button.
2. Press the {DISPLAY CALL QUEUE} button. The display shows the Queued call
status and will update as the queue status changes. If no calls are in queue, the
phone returns to idle.
3. Hang-up to return to idle and normal display.
To display ACD Call Queue status when the Agent is on a call;
1. Press the {DISPLAY CALL QUEUE} button, the displays shows the queued status
for seconds and then returns to the normal call display.
Conditions
1. The Agent cannot display queued call status while the phone is ringing.
2. If there are no queued calls to display, the phone returns to idle after providing error
tone.
Programming
Related Features
Station Groups
Hardware
iPECS Phone with Display
2.5.1.5 Agent Automatic Wrap-Up
Description
When an Agent completes an ACD group call, the Agent automatically enters into the Wrap-up
state. In this state, an Agent will not receive ACD calls, allowing the Agent to complete
paperwork, etc. The Agent remains in this automatic Wrap-Up state for the duration of the ACD
group Wrap-Up Timer. After the Wrap-Up Timer or by using “Wrap-Up-End” feature, the Agent
returns to available status and can receive ACD group calls.
Operation
Agent iPECS Phone
To assign a {WRAP-UP-END} button;
1. [PGM] + {FLEX} + “585” + [SAVE]
Activation;
1. Automatic when Agent completes an ACD group call
1. Press {WRAP-UP-END} flexible button, before expiration of the Wrap-Up Timer.
Conditions
1. During Agent automatic Wrap-Up, the assigned {WRAP-UP-END} flexible button
flashes. The button LED extinguishes when the Wrap-Up Timer expires or if the
button is pressed, both return the Agent to available.
Programming
Related Features
Hardware
2.5.1.6 Agent On/Off Duty w/Reason Code
Description
Agents can control their status, On/Off-duty, and assign a Reason code for an Off-duty state.
The system outputs the Reason code as part of the ACD Event message output. The Reason
code may be any digit (0 ~ 9, * and #). With the exception of Reason code “0”, when the Agent
goes Off-duty manually, the Agent must return to the On-duty state manually.
If assigned as the Auto ACD DND code, using Reason code “0” activates the ACD DND Wrapup timer. At expiration of the timer, the Agent is placed back On-duty. This provides the
flexibility of an Agent activated Wrap-up time.
The Agent may assign an {ACD ON/OFF DUTY} button to for easy access. The ACD group
number and the Reason code can be assigned for an {ACD ON/OFF DUTY (GROUP) (REASON)} button. By entering the Auto ACD DND code, the Agent will have an ACD DND
button and, if assigned Reason code “0”, the Agent will return to On-duty status after the ACD
DND Wrap-up time.
Operation
Agent iPECS Phone
To assign an {ACD ON/OFF DUTY (GROUP)} button;
If a station is included in two or more hunt group, To go to ON duty in all hunt group when the
user is OFF duty in more one hunt group
1. Lift handset or press [SPEAKER] button,
2. Dial the code for {Agent On/Off duty in all hunt group} button.
If a station is included in two or more hunt group, To go to OFF duty in all hunt group when
the user is ON duty in all hunt group;
1. Lift handset or press [SPEAKER] button,
2. Dial the code for {Agent On/Off duty in all hunt group} button.
3. Dial Reason Code (“0” ~ “9”, “*” or “#”).
Conditions
1. The system will output an Agent Availability message with the dialed Reason code
when an Agent changes availability status. The message will include the button
type “Wrap” if the ACD DND timer is activated.
2. The {ACD ON/OFF-DUTY} flex button will flash while the agent is Off-duty for any
reason. The button LED extinguishes when the Agent returns to On-duty status.
3. While Off-duty, the supervisor's flex button LED assigned for the Agent’s station
flashes at the DND rate. The supervisor may call the station overriding the Offduty status.
4. The {ACD ON/OFF-DUTY (GROUP)(0)} button overwrites other {ACD DUTY (GROUP)} buttons, only one {ACD ON/OFF-DUTY (GROUP)} button can be
assigned at a station.
5. The default value of the ACD DND Wrap-Up Timer is 10 seconds.
Programming
Related Features
Agent Automatic Wrap-Up
Auto ACD DND Unavailable Service
Event Messages
Hardware
2.5.2 Announcements
Description
Each ACD group can provide announcements to incoming callers. Primary and secondary
announcements are available with control timers. The first announcement is played after 1st
control timer. The 2nd control timer determines the period between the first and second
announcement. The second announcement can be replayed at defined intervals. If desired, the
primary message can be defined to play in full to all callers as a “guaranteed announcement” or
only for calls that queue.
When enabled, a CIQ (Calls in Queue) announcement is played to callers that are queued to
the ACD group. The CIQ announcement (“Your Call is number xx in Queue”) is played to
queued callers after the 1st announcement is played and again after each time the 2nd
announcement is played. Internal callers with an iPECS Display Phone also receive the “You
are xx in queue” display message.
Operation
System
ACD group announcements are played automatically based on the ACD group assignments.
System Attendant
To record a VMIM/VSF Announcement for an ACD Group;
1. Press the [PGM] button.
2. Dial “06”, the VMIM/VSF Record code.
3. Dial VSF/VMIM sequence number to select a VSF/VMIM.
4. Dial the VMIM/VSF Announcement number (01-70)
5. Dial record language type (1~3), the current announcement is played followed by
the “Press # to record” prompt.
6. Dial “#”.
7. After the beep-tone, record message.
8. Press the [SAVE] button to stop recording and save the message
To delete a recording
1. Press the [PGM] button.
2. Dial “06”, the VMIM/VSF Record code.
3. Dial VSF/VMIM sequence number to select a VSF/VMIM.
4. Dial the VMIM/VSF Announcement number (01-70).
5. Dial record language type (1~3), the current announcement is played followed by
the “Press # to record” prompt.
6. Press the [SPEED] button during playback to erase message
Conditions
1. ACD group announcements are recorded in the VSF or VMIM. Up to seventy (70)
Announcements are available for group announcement recordings.
Announcements 71 and 72 are reserved for MOH and Multi Language selection
announcements, respectively.
2. The CIQ Message must be recorded in the VMIM/VSF.
3. When equipped to support multiple languages, the Language selection
announcement is played prior to a guaranteed announcement.
4. To define a guaranteed announcement, assign 0 seconds to the 1st announcement
control timer.
VMIM/VSF-Auto Attendant
ACD Caller Controlled ICLID Routing
Multiple Language Support
Hardware
2.5.3 Auto ACD DND Unavailable Service
Description
An Agent who does not answer a call offered from an ACD group during the ACD No-Answer
timer is placed in a “No response” unavailable status, called ACD DND. In this state, the Agent
will not receive ACD calls from the group. The status is maintained until the agent manually
returns to available status or, if the Auto ACD DND Reason code is set to “0”, after the ACD
DND Wrap timer the Agent returns to available status.
The Agent On/Off Duty code toggles the Agent duty status On and Off. The station may be
assigned an {ACD ON/OFF-DUTY (GROUP)} button to set the active Agent duty status. The
{ACD ON/OFF-DUTY (GROUP)} button LED will flash to indicate an unavailable status.
Operation
Agent iPECS Phone
To assign a {ACD ON/OFF-DUTY (GROUP)} button;
2. While Unavailable, the supervisor's flex button LED assigned for the station number
of the agent will flash at the DND rate and the supervisor may call the station.
Programming
Related Features
Agent On/Off Duty w/Reason Code
Hardware
2.5.4 Calls-In-Queue routing
Description
When a caller is queued to an ACD Group, various announcements may be played and music
on hold may be sent to the caller. The caller may dial a digit at any time while queued to exit
the queue, except during a Guaranteed Announcement. The dialed digit is compared to digits
defined in the ACD Group CIQ Route Table. If a match is found, the call is routed to the defined
destination (Station, Station Group, etc.). If a match is not found, external callers receive an
error message and are placed back in queue; internal callers are simply placed back in queue.
Operation
Operation of this feature is automatic based on caller input
Conditions
1. ACD CIQ routing is not supported during or within 5 seconds of a Guaranteed
Announcement. Digits dialed during a Guaranteed Announcement use Caller
Controlled ICLID routing.
2. The call must be in queue for the ACD group, dialing during ring back tone is not
recognized by the iPECS.
Programming
Related Features
Station Groups
Announcements
ACD Caller Controlled ICLID Routing
The administrator can establish CIQ (Calls-In -Queue) thresholds for each ACD Group so that
an assigned VMIM/VSF announcement plays over a defined Page zone, if the number of calls
in queue equals or exceeds a CIQ threshold. The message, which is recorded by an Attendant,
plays immediately or after a defined delay. The message repeats at assigned intervals until the
number of Calls in Queue falls below the threshold. iPECS allows different treatment and
VMIM/VSF announcements for up to three different Calls-In -Queue thresholds.
Operation
System
When the number of Calls-In-Queue changes, up or down the iPECS;
1. Checks CIQ thresholds,
2. Determines if threshold is reached,
3. Queues announcement for threshold (sets Delay timer),
4. Plays CIQ announcement.
5. Repeats announcement as defined.
System Attendant
To record a CIQ Announcement for an ACD Group;
1. Press the [PGM] button.
2. Dial “06”, the Message Record code.
3. Dial VSF/VMIM sequence number to select a VSF/VMIM.
4. Dial the VMIM/VSF Announcement number (01-70)
5. Dial language selection (1~3), the current announcement is played followed by the
“Press# to record” prompt.
6. Dial “#”.
7. After the beep-tone, record message.
8. Press the [SAVE] button to stop recording and save the message.
To delete a recording
1. Press the [PGM] button.
2. Dial “06”, the Message Record code.
3. Dial VSF/VMIM sequence number to select a VSF/VMIM.
4. Dial the VMIM/VSF Announcement number (01-70)
5. Dial language selection (1~3), the current announcement is played followed by the
“Press # to record” prompt.
6. Press the [SPEED] button during playback to erase message.
Conditions
1. Thresholds are assigned as total Calls-In-Queue to activate a Page alert and are
checked from lowest priority (CIQ #1) to highest priority (CIQ #3). Thus, the
port. These event messages are employed by 3rd party applications to provide enhanced Call
Center functionality. Details of the event messages are provided in the iPECS 3rd Party Support
Guide.
Operation
System
When enabled, Event messages are sent automatically
Conditions
Programming
Related Features
• Station Groups
Hardware
2.5.7 Group Mail Box
Description
A mailbox can be associated with a Station Group. Calls to the group are assigned to overflow
and can be otherwise re-routed to the Station Group Mail box. When routed to Voice Mail,
messages are placed in the assigned Station Group Msg Wait Station mailbox.
Messages are retrieved in the same manner as normal voice messages employing the Station
Group number as the station number and the defined Station Mailbox Password. Messages
can be retrieved only if a {GROUP MAILBOX} Flex button is assigned to the station.
Operation
Agent iPECS Phone
To assign a {GROUP MAILBOX} Flex button;
1. [PGM] + {FLEX} + VM Group + Group Msg Wait Station + [SAVE]
To retrieve Station Group Voice Mail
1. Lift the handset or press the [SPEAKER] button
2. Press {GROUP MAILBOX} button to receive the “Password” prompt.
3. Dial the ACD Group number + Group Mailbox password to receive the “Number of Messages” prompt.
4. Dial desired option code.
5. At completion of session, hang-up to return to idle.
25
iPECS-LIK
STATION GROUPS
1 Group Attributes (PGM 191)
2 Mailbox Message Wait Station (PGM 191-Btn 24-2)
3 Mailbox Password (PGM 191-Btn 24-3)
STATION GROUPS
1 Station Group Attributes (PGM 191)
2 Terminal/Circular Group Name (PGM 191-Btn 20)
3 ACD Group Name (PGM 191-Btn 22)
4 Ring Group Name (PGM 191-Btn 18)
5 VM Group Name (PGM 191-Btn 9)
2. Hang up to quit recording or dial “*” for further options.
Conditions
1. The System Administrator or Supervisor may change the Group Mailbox password.
2. An external caller (CO/IP call) cannot access the Group Mailbox to retrieve
messages.
Programming
Related Features
External Auto Attendant/Voice Mail
Station Groups
VMIM/VSF Voice Mail
Supervisors
Hardware
iPECS Phone
2.5.8 Group Name
Description
Each hunt group is assigned a name of up to 12 characters. The name is employed as the
called party display for internal callers in the output of group statistics.
Operation
System
Operation of this feature is automatic when programmed.
Conditions
Programming
26
iPECS-LIK
6 UCS Group Name (PGM 191-Btn 16)
STATION GROUPS
1 ACD Group (PGM 191)
2 Overflow Destination (PGM191-Btn 7)
3 Overflow Time (PGM 191-Btn 8)
4 Music Source (PGM 191-Btn 11)
5 Alternate Destination (PGM 191-Btn 13)
6 Report No Members (PGM 191-Btn 10)
7 Agent Priority (PGM 191-Btn 19)
Incoming calls to an ACD group route directly to the station/agent that has been idle the longest
(Uniform Call Distribution) or an ACD group announcement recorded by an Attendant. If all
agents are busy, the call is queued to the group or routes to the Alternate Destination. The
queued caller receives ACD group announcements or audio from the defined music source.
Callers that remain in queue receive audio from the defined music source or ring-back tone and,
after the defined Overflow time, route to an Overflow destination.
Agents can be assigned a priority from“0” ~ “9”, “0” being the lowest priority and “9” the highest.
When priorities are assigned, calls are routed to the highest priority Agent that has been idle
the longest.
If there are no Agents active in the group when a call arrives, the call will receive the “No
Member” treatment. Intercom calls receive re-order and external callers are routed to an
Attendant.
Operation
System
Routing of ACD group calls is automatic based on the ACD group assignments.
Conditions
1. The Alternate ACD Destination can be a station or a group but cannot be a member
of the ACD group.
2. The Overflow destination may be any station or group including the ACD group
VMIM/VSF Mailbox but cannot be a member of the overflowing ACD group.
3. If an agent becomes available during an announcement, except a guaranteed
announcement, the call is passed immediately to the agent.
Programming
27
iPECS-LIK
STATION GROUPS
1 ACD Group (PGM 191)
2 ICLID Usage (PGM191-Btn 21)
TABLES
1 ICLID Table (PGM 203)
2 ICLID Ring Assignment (204)
With Caller Controlled ICLID enabled (ICLID Usage) for the ACD Group, at any time during or
within 5 seconds after a Guaranteed Announcement, the system will monitor for digits dialed by
the caller. Received digits are compared to the ICLID Table entries. If a match is found, the call
routes to the destination defined in the ICLID Ring Assignment Table. Available destinations
are a Voice Mail announcement, system speed dial, a station or a station group. If a match is
not found, the call returns to the queue and is handled as defined for the ACD group.
Operation
System
ICLID Routing of ACD group calls is automatic based on the ACD group assignments.
Conditions
1. The conditions of VMIM/VSF AA Announcements and ICLID Call Routing apply.
2. Only the caller-entered digits are employed for ACD ICLID routing.
3. The ICLID Table routing is only followed if the 1st ACD announcement is
Guaranteed, ICLID Usage is enabled and the digits are entered during the 1st
Announcement.
4. The caller may correct an entry by dialing * and dialing the correct entry.
Each ACD group is assigned up to five (5) Supervisors to monitor and control real-time status
of the ACD group and Agents assigned to the group. A Supervisor can be assigned to multiple
groups. The Supervisor login/logout feature provides a means for a supervisor to log into one or
more ACD groups and monitor calls.
Each Supervisor has a unique 4-digit Agent Id used to login and logout of active ACD group
participation. Supervisors can login from any station in the system but only at one station at a
time. If a Supervisor logs into a group from a station while logged in at another station, the
active login is terminated and the new login is honored.
Operation
Supervisor iPECS Phone
To login;
1. Dial “572” the ACD Supervisor Login code or press the Flex button.
2. Dial the ACD group number
3. Dial supervisor Id code (“0000”-“9999”)
To Logout;
1. Dial “573” the ACD Supervisor Logout code or press the Logout Flex button.
2. Dial the ACD group number
3. Dial supervisor Id code (“0000”-“9999”)
Conditions
1. The system will output a Login/Logout message when a Supervisor logs-in or out.
2. The Supervisor Id can be any 4-digit number (“0000”-“9999”).
3. iPECS system does not verify the Supervisor Id codes, other than requiring four
digits are entered.
4. Any Agent Id may be used to login through stations not assigned as a Hot Desk.
5. The ACD Supervisor can have an ACD Group Status button for each group to
indicate Group activity.
Programming
Related Features
Automatic Call Distribution
Hot Desk
Hardware
29
iPECS-LIK
NUMBERING PLAN
1 ACD Group Help Code (PGM 107-Btn 5)
STATION GROUPS
1 ACD Groups (PGM 191)
2 ACD Group Supervisor (PGM 191-Btn 18)
An Agent may request assistance from a Supervisor using the ACD Group Help Code, default
574 or {HELP} button. The Supervisor is then notified of the Help request in the iPECS Phone
display and a flashing {HELP RESPONSE} button. The Supervisor can respond using the Help Response button, which is required, and be connected to the Agent’s active call with the
microphone muted. The Supervisor hears the Agent and connected party and may join the
conversation by pressing the [MUTE] button to activate the microphone.
Operation
Agent iPECS Phone
To request Supervisor assistance,
1. Press the {HELP} button.
SLT
1. Hook-flash and dial “574”, the Agent Help code
2. Dial the desired ACD Group number.
Supervisor iPECS Phone
To assign a {HELP RESPONSE} button
To respond to a Help request, at the Supervisor Phone,
1. Lift the handset or press the [SPEAKER] button,
2. Press the flashing {HELP RESPONSE} button, the Supervisor is connected to the
active Agent call with the microphone muted, the [MUTE] button LED is On.
To converse with the Agent and connected party
1. Press the illuminated [MUTE] button.
Conditions
1. The Agent Help request is sent to the lowest numbered available Supervisor station
for the associated ACD Group.
2. If no Supervisor is available, the Agent receives error tone.
3. A Warning Tone, if enabled, will be sent to the Agent as the Supervisor is connected
to the conversation.
4. Only one active Help request is allowed at a time, a second help request will cancel
any active help request.
Programming
30
iPECS-LIK
3 ACD Warning Tone (PGM 191-Btn 12)
NUMBERING PLAN
1 Supervisor Monitor Code (PGM 107-Btn 8)
STATION GROUPS
1 ACD Groups (PGM 191)
2 ACD Group Supervisor (PGM 191-Btn 18)
3 ACD Warning Tone (PGM 191-Btn 12)
Automatic Call Distribution
Agent Help Request
Hardware
iPECS Phone
2.5.11.3 Agent Call Monitor
Description
Agent Call Monitor permits an active Supervisor to monitor an Agent’s call in progress for
training purposes or to assist the Agent. When used, the Supervisor is connected to the call
with the microphone muted, the [MUTE] button LED is On. If ACD Warning Tone is enabled, a Warning Tone is provided to the Agent’s call indicating the Supervisor has entered the call. The
Supervisor hears the Agent and connected party and may join the conversation by pressing the
[MUTE] button to activate the microphone.
The Supervisor station must be assigned an {AGENT MONITOR} button to activate the Agent
Call Monitor feature.
Operation
Supervisor iPECS Phone
To assign an {AGENT MONITOR} button
An ACD Supervisor may view the status of each of the ACD groups to which the Supervisor is
assigned. The display will give the status of the active ACD group at the time of the request.
The display indicates the following statistics:
Number of calls in Queue
Wait time for the call in queue longest and
Agents in service and available
When a call is queued to the group, the ACD Supervisor is notified, in real-time, by the LED of
the {GROUP STATUS} button. The {GROUP STATUS} button allows access to the ACD
Group status display or the Group Status code may be used to display the status information.
Operation
Supervisor iPECS Phone
To assign a {GROUP STATUS} button at the Supervisor
To display the Group status when the {GROUP STATUS} button is flashing
1. Lift the handset or press the [SPEAKER] button,
2. Dial “576”, the Group Status display code,
3. Dial “1” to see the Group Status information,
Or,
1. Press the flashing {GROUP STATUS} button,
2. Dial “1” to see the Group Status display.
Conditions
1. The Supervisor must be assigned as a Supervisor for the ACD Group and be
logged into the group to access the Group Status display information.
2. The {GROUP MONITOR} button will flash when the count of Calls-in-Queue
reaches to or exceed the programmed ‘Supervisor Call Count’ after programmed
‘Supervisor Timer’.
3. Dial “0” or “1”, (“0”: Off Duty, “1”: On Duty).
Conditions
1. The Supervisor must be assigned as a Supervisor for the ACD Group and be
logged into the group to access the Group Status display information.
Programming
Related Features
Station Groups
Hardware
iPECS Phone
2.5.12 ACD Statistics Report
ACD reports can be requested by the Supervisor and can be programmed for periodic output
over the SMDR port or selected TCP port. The system will provide reports for the ACD Group
and Agent statistics as follows:
ACD Group Statistics Report
Group Number
Time stamp
Total calls
Number of unanswered calls
Average queue time
Longest queue time
Total number of calls placed in queue
Number of times calls experience all agents busy
Total time all agents were busy
Average ring time before answer
Group Number
Agent Number
− Number of ACD calls served
− Number of unanswered ACD Calls
− Average ring time before answer
− Average ACD call service time after answer.
Operation
35
iPECS-LIK
1STATUS
2DBASE
3AGENT
#PRINT
1STATUS
2DBASE
3AGENT
#PRINT
1STATUS/2ON/OFF)/#PRINT
NUMBERING PLAN
1 ACD Group Status Code (PGM 107-Btn 7)
STATION GROUPS
1 ACD Group (PGM 191)
2 ACD Group Supervisor (PGM 191-Btn 18)
1. Lift the handset or press the [SPEAKER] button,
2. Press the {GROUP STATUS} button,
3. Dial “#”, ACD Group Statistics Reporting Code,
4. Press the [MUTE] button to initialize the ACD database after printing; this eliminates
overlap of future reports.
To output the Agent Statistics Report
1. Lift the handset or press the [SPEAKER] button,
2. Press the {GROUP STATUS} button,
3. Dial “3”, Agent Code, the LCD menu will update:
4. Dial “#”, Agent Statistics Reporting Code,
5. Press the [MUTE] button to initialize the ACD database after printing; this eliminates
overlap of future reports.
Conditions
1. The ACD status can be printed periodically. The period is assigned in Admin
Programming. The ACD records contain information for both ACD agents and
ACD group.
2. The Supervisor must be assigned as a Supervisor for the ACD Group and be
logged into the group to access the Group Status display information.
In addition to a manually entered Pause, the system will automatically pause dialing to allow for
potential connection delays. The pause will be inserted when any of the following occur:
After a Flash is encountered in a Speed Dial number,
After a PABX access code is encountered in a Speed Dial or redial number,
After a Pulse to Tone Switchover is encountered in a Speed Dial or Redial
number.
When a connect message is received on an ISDN Line.
Operation
System
The system automatically pauses dialing after an appropriate event.
Conditions
1. An automatically inserted pause is not counted as a digit in a Speed Dial number.
2. The LCD of the iPECS Phone will show a "P" when a pause is encountered. This
indication is not shown if the system inserts the Pause automatically.
Programming
Related Features
Station Speed Dial
System Speed Dial
Auto Called Number Redial (ACNR)
LNR (Last Number Redial)
Dial Pulse to Tone Switchover
Privacy is insured on all communications in the system. If desired, the customer may elect to
disable the Automatic Privacy feature, allowing another station to join in an existing external
conversation uninvited. In such a case, a conference is established.
Operation
iPECS Phone
To intrude into a call when Privacy is disabled
1. Press a busy (lit steady) individual {CO}/{IP} access button, user connected to the
call with existing internal station user.
Conditions
1. With Automatic Privacy disabled, privacy is still assured on all intercom and
conference calls.
2. To override privacy, Privacy must be disabled and the intruding station must have
Override enabled as well as a direct appearance for the desired {CO}/{IP} line.
3. Only one station can intrude on an active call.
4. An intrusion tone can be provided to the call indicating another station has accessed
the line.
5. If either internal party presses another {CO}/{IP}, a {DSS}, {PAGE}, [CONF] or
other conflicting button, the party is removed from the “Conference” and must
press the {CO}/{IP} button again to reenter the conversation.
Programming
Related Features
Multi-Party Voice Conference
Station Flexible Buttons
Hardware
iPECS Phone
38
iPECS-LIK
STATION
1 Station COS (PGM 116)
CO/IP
1 CO/IP CO Ring Assignment (PGM 144)
2 CO COS (PGM 141-Btn 2)
The service mode defines different ring assignments, COS and answering privileges for the
system. The service mode can be controlled automatically through definitions in the Auto Ring
Mode Selection Table, which defines the time of day for the Day, Night and Timed shift modes.
The Attendant may change the system mode selection from automatic to manual.
Operation
System
Operation of this feature is automatic.
Conditions
Programming
Related Features
Off-Hook Signaling
Authorization Codes (Password)
Direct Inward System Access (DISA)
Day/Night/Timed/Scenario Ring Mode
System Clock Set
CO/IP Ring Assignment
LBC (Loud Bell Control)
Dialing Restrictions
Hardware
39
iPECS-LIK
SYSTEM
1 System Time (PGM 178-Btn 1)
2 System Date (PGM 178-Btn 2)
3 DST Enable (PGM 178 – Btn 3)
4 DST Start & End Time (Web only)
The system can automatically adjust for Daylight Saving Time (DST). When DST is enabled,
the system will adjust the system time forward one (1) hour at the DST Start time and back one
(1) hour at the DST End time. The system time is sent for display to all devices and terminals
and is the basis of the system various time-based features (Walking COS, Wake-up Alarm,
etc.).
Operation
System
Operation of this feature is automatic.
Conditions
1. The DST Start and End times are set through the Web Admin interface only.
2. The interval between the DST Start and End times must be at least 7 days.
Programming
Related Features
Auto Service Mode Control
Automatic System Time Synchronization
System Clock Set
Hardware
40
iPECS-LIK
SYSTEM
1 Network Time/Date (PGM 161 – Btn 12)
2 NTP Active (PGM 195 – Btn 1)
3 NTP Sever address (Web only)
4 Std system time, local Time Zone (Web only)
When enabled, the system automatically determines and sets the time of day employing
Network Time Protocol (NTP) or ISDN time messages. When using NTP, the system, at ten
(10) minute intervals, requests the time from the specified NTP time server and receives GMT
time. This feature allows the System Time to synchronize with the NTP time server
automatically. If the time deviates more than two (2) seconds, the system clock is adjusted to
match the NTP server.
When using ISDN, the system receives the time of day in ISDN messages and automatically
adjusts the time if the time in the system deviates from the ISDN time.
Operation
System
Operation of this feature is automatic.
Conditions
1. NTP packets are expected over UDP port 123. Assure this port is open and
available.
2. A secondary NTP server address can be defined should the first server not respond.
3. The system adjusts for the local time zone assigned in the system as the Standard
System Time as well as Daylight Savings Time (DST), if set.
Programming
Related Features
Auto Service Mode Control
Automatic System Daylight Savings Time
System Clock Set
The system database is protected from power-loss by a long life (10-year) lithium dry cell
battery. Should local power fail, the battery will maintain the system memory and proper
operation of the system clock.
Operation
System
Operation of this feature is automatic.
Conditions
1. The Initialization switch must be in the OFF position to enable Memory Battery
Back-up. Otherwise, should power fail, the system will initialize the database on
power-up. Refer to the iPECS Hardware Description and Installation manual
section 4.4.2.
2. The Lithium battery is not field-replaceable.
Programming
Related Features
Hardware
42
iPECS-LIK
Code 0:
Remote Call Forward, forwards all calls to the station, except recalls, activated from a
remote station, Call Forward, Follow-me.
Code 1:
Unconditional, all calls to the station, except recalls, are forwarded internally or externally
immediately upon receipt.
Code 2:
Busy, if the station is busy, forwards all calls, except recalls, to the selected station.
Code 3:
No Answer, forwards all calls, except recalls, to the selected station when the station does
not answer within the No Answer timer.
Code 4:
Busy/No Answer, forwards calls if the selected station is busy or does not answer within the
No Answer timer.
Code 5:
Attendant Off-Premise, forwards incoming CO/IP calls to an outside number.
Code 6:
Off-Net Unconditional, all calls to the station, except recalls, are forwarded internally or
externally, only SLT.
Code 7:
Off Net Busy, forwards all calls, except recalls, to the selected station when station is busy,
only SLT.
Code 8:
Off Net No Answer, forwards all calls, except recalls, to the selected station when the station
does not answer within the No Answer timer, only SLT.
Code 9:
Off Net Busy/No Answer, forwards calls if the selected station is busy or does not answer
within the No Answer timer, only SLT.
Users may have selected incoming calls re-routed to other stations (local or networked), station
groups, the VMIM/VSF, or over a system CO/IP line (Off Net).
The user selects the type and condition under which calls will forward by entering a Call
Forward code as follows:
Operation
iPECS Phone
To activate Call Forward, Unconditional or Busy/No Answer
1. Lift the handset or press the [SPEAKER] button to receive dial tone.
2. Press the [FWD] button
3. Dial desired Call Forward code (“1”~“4”).
4. Dial the station or station group to receive calls.
Or,
Dial CO access code (9, 8xx, 88xx) and desired external phone number.
Press [SAVE] button to save.
Or,
Press [SPEED] button
Dial desired bin number.
1. Lift the handset or press [SPEAKER] button to receive dial-tone
2. Press the [FWD] button,
3. Dial Call Forward code “0”,
4. Dial the station’s Authorization Code (Station number + password),
5. Dial Forward condition (“1”~“4”),
6. Dial the destination station or station group,
Or
Dial CO access code (9, 8xx, 88xx) and desired external phone number.
Press [SAVE] button to save.
Or
Press [SPEED] button
Dial desired bin number
7. Replace the handset, return to idle.
To deactivate Call forward
1. Press flashing [FWD] button, Call Forward will deactivate and the [FWD] button
LED is off.
SLT
To activate Call Forward, Unconditional, Busy/No-Answer to an internal number
1. Lift the handset to receive dial tone.
2. Dial Call Forward feature dial code “554”
3. Dial desired Call Forward code (“1”~“4”).
4. Dial the destination station, station group or dial CO access code (9, 8xx, 88xx) and
desired external phone number.
5. Momentarily press the hook-switch, receive confirmation tone.
1. A station receiving a forwarded call can transfer the call to the forwarding station.
2. A station, denied the use of Call Forward, will receive error tone in response to
attempts to activate Call Forward.
3. A forwarded intercom call will signal the receiving station in the Tone Signaling
mode, regardless of the Intercom Signaling Mode at the station.
4. Calls cannot be forwarded to a station in DND and, if attempted, error tone is
returned.
5. Attempting activation of Call Forward will automatically deactivate any activate
Display Text Message. Active Call Back or Queue requests are not canceled.
6. When Call Forward is active, a station can make outgoing calls (internal or external)
but cannot activate a Call back or Queue request.
7. Private lines can be forwarded if the forwarding and receiving station have a direct
appearance {CO} button for the Private line or if calls are forward to a VSF, VMIM
or Voice Mail group.
8. For CO/IP calls, manually activated Call Forward will override any Preset Call
Forward assigned for the station or CO/IP line.
9. Users may forward calls to the VMIM/VSF without recording a greeting, in which
case, calls are still forwarded to the VMIM/VSF but callers receive the "No
announcement recorded" message before they can leave a voice mail.
10. Call Forward status is maintained in the system’s non-volatile memory for
protection from power outage.
11. A station in a Station Hunt Group (ACD, Circular or Terminal) can be assigned to
receive incoming hunt calls, overriding any Call Forward. That is, the system either
recognizes the Forward condition and bypasses hunt calls around the station or
routes hunt calls to the station based on the system database (Member Forward).
12. Off-Net Call Forward of incoming CO/IP calls is essentially an automated DISA call,
which will establish an Unsupervised Conference. Such calls are subject to the
conditions of a DISA call and Unsupervised Conference and may require entry of
an Authorization Code.
13. Off-Net forward calls are not answered until the system completes dialing of the
external call. The call, internal or external, is then connected to the Off-Premise
call.
14. If the Speed Dial number used in Off-Net Call Forward contains a Flash, only digits
prior to the Flash are dialed.
15. An unlimited number of stations may be set-up in a Call Forward chain, forwarding
calls from one station to the next. However, a station cannot forward calls to a
station already a part of the chain.
16. Calls to a Call Forward chain will progress as appropriate through the chain to the
last station. If the last station enters DND, CO/IP calls revert to the previous station
while intercom calls receive DND tone.
17. No Answer forward employs the Station No Answer Forward Timer unless it is set
to zero in which case the System No Answer Timer is used.
Programming
45
iPECS-LIK
STATION
1 Call Forward (PGM 111-Btn 2)
2 Station Call Forward No Answer Timer (PGM 123-Btn
Call Forward, Attendant
Authorization Codes (Password)
DND (Do Not Disturb)
DND - One Time DND
Direct Inward System Access (DISA)
Unsupervised Conference
Dialing Restrictions
Station Groups
Station Speed Dial
System Speed Dial
Intercom Signaling Mode
Call Forward, Preset
With Call Forward, Preset, calls to a station forward to a pre-determined destination assigned in
the system database. Preset Station Call Forward can define separate treatment of CO/IP calls
and intercom calls. In addition, separate busy and no-answer treatments are defined.
Treatments available are:
Unconditional, all calls immediately forward,
Internal Busy, Intercom calls that encounter busy, forward immediately.
Internal No-Answer, Intercom calls, which are not answered in the No-
Answer time, forward. Note calls to a busy station also forward after the NoAnswer time.
Internal DND, If initial destination is DND state, ICM call can be routed to
preset forward destination.
External Busy, external calls that encounter busy forward immediately.
External No-Answer, external calls, not answered in the No-Answer time,
forward. Note calls to a busy station also forward after the No-Answer time.
External DND, If initial destination is DND state, Incoming call can be routed
to preset forward destination.
In addition, calls can be directly forward to the users Voice Mail box using Call Forward, Preset.
Operation
System
Operation of Preset Call Forward is automatic.
Conditions
1. A station receiving a forwarded call can transfer the call to the forwarding station.
2. Manual Forward has higher priority than Preset Forward and overrides any Preset
Forward setting.
3. Calls to a Preset Call Forward chain will progress as appropriate through the chain
to the last station. If a station in manual Call Forward or DND is encountered, it is
bypassed and the next station in the chain is signaled. If the last station has
entered DND, CO/IP calls revert to the previous station, signaling until answered or
abandoned.
4. Internal Busy or No Answer will only operate when the internal call encounters a
busy state or no answer, respectively. External Busy or External No Answer will
only operate when the external call encounters a busy state or no answer,
respectively.
5. Preset call forward status is not shown in the station’s LCD display.
6. A station in a Station Hunt Group (ACD, Circular or Terminal) can be assigned to
receive incoming hunt calls, overriding any Call Forward. That is, either the system
recognizes the Forward condition and bypass hunt calls around the station or
routes hunt calls to the station based on the system database.
7. No Answer forward employs the Station No Answer Forward Timer unless it is set to
zero in which case the System No Answer Timer is used.
47
iPECS-LIK
STATION
1 Preset Call Forward (PGM 120)
2 Station Call Forward No Answer Timer (PGM 123-Btn
1)
3 Direct Transfer Mail Box Destination (PGM 120-Btn 6)
Call Forward
Off-Hook Signaling
External Auto Attendant/Voice Mail
VMIM/VSF Integrated Auto Attd/Voice Mail
DND (Do Not Disturb)
DND - One Time DND
Private Line
A station may answer (“Pick-Up”) incoming and transferred intercom, CO and IP calls ringing at
another station. All ringing calls are subject to Directed Call Pick-up except Private Line and
queue Callbacks.
iPECS phone users may assign a Flex button as a {DIRECTED CALL PICK-UP} button.
Operation
iPECS Phone
To assign a {DIRECTED CALL PICK-UP} button
1. [PGM] + {FLEX} + “7” + [SAVE]
To Pick-up a call ringing at another station
1. Lift the handset or press [SPEAKER] button.
2. Dial “7”, the Directed Call Pick-up feature code.
3. Dial the ringing station’s intercom number.
Or,
1. Lift the handset or press [SPEAKER] button.
2. Press the {DIRECTED CALL PICK-UP} button.
3. Dial the ringing station’s intercom number.
SLT
To Pick-up a call ringing at another station
1. Lift the handset
2. Dial “7”, the Directed Call Pick-up code.
3. Dial the ringing station’s number.
Conditions
1. To pick-up a CO/IP call, the station must have an idle appearance button available.
2. When several calls are ringing at a station simultaneously, Call Pick-up will connect
the oldest highest priority call (Ringing Line Preference, PGM 173).
3. Queue callback and Private Line calls are not subject to Call Pick-up and such
attempts receive error tone.
4. Hands free announced intercom calls cannot be picked up by another station. Only
ringing intercom calls are subject to Call Pick-up.
Intercom Signaling Mode
Ringing Line Preference
Group Call Pick-Up
Private Line
Hardware
2.15.2 Group Call Pick-Up
Description
A station can answer (“Pick-Up”) incoming and transferred intercom, CO and IP calls ringing at
another station in the same station group. All ringing calls, except Private Line and Queue
Callbacks, are subject to Pick-up by other stations in the same group.
iPECS phone users may assign a Flex button as a {GROUP CALL PICK-UP} button.
Operation
iPECS Phone
To assign a {GROUP CALL PICK-UP} button
1. [PGM] + {FLEX} + “566” + [SAVE]
To Pick-up a call ringing at another station
1. Lift the handset or press [SPEAKER] button.
2. Dial “566”, the Group Call Pick-up feature code.
Or,
1. Press the {GROUP CALL PICK-UP} button.
SLT
To Pick-up a call ringing at another station
1. Lift the handset
2. Dial “566”, the Group Call Pick-up code.
Conditions
1. To pick-up a CO/IP call, the station must have an idle appearance button available.
2. When several calls are ringing simultaneously, Call Pick-up will connect the oldest
highest priority call (Ringing Line Preference, PGM 173).
3. Queue callback and Private Line calls are not subject to Call Pick-up and such
attempts receive error tone.
4. Hands free announced intercom calls cannot be picked up by another station. Only
ringing intercom calls are subject to Call Pick-up.
5. When a station belongs to multiple groups, calls to the group with the lowest
number are answered first.
Intercom Signaling Mode
Ringing Line Preference
Directed Call Pick-Up
Station Groups
Private Line
Hardware
2.15.3 Pick Up Group Call Pick-Up
Description
A station can answer (“Pick-Up”) incoming and transferred intercom, CO and IP calls ringing at
another station in the same pick up group. All ringing calls, except Private Line and Queue
Callbacks, are subject to Pick-up by other stations in the same group.
iPECS phone users may assign a Flex button as a {PICK UP GROUP CALL PICK-UP} button.
Operation
iPECS Phone
To assign a {PICK UP GROUP CALL PICK-UP} button
1. [PGM] + {FLEX} + “588” + [SAVE]
To Pick-up a call ringing at another station
1. Lift the handset or press [SPEAKER] button.
2. Dial “588”, the Pick Up Group Call Pick-up feature code.
Or,
1. Lift the handset or press [SPEAKER].
2. Press the {PICK UP GROUP CALL PICK-UP} button.
SLT
To Pick-up a call ringing at another station
1. Lift the handset
2. Dial “588”, the Pick Up Group Call Pick-up code.
3. Dial Pick Up Group Number.
Conditions
1. When a user dial “Group Call Pick-up feature code(566)”, a station can answer calls
ringing at another station in the same pick up group in PGM190 and PGM192. But
when a user dial “Pick Up Group Call Pick-up feature code(588)”, a station can
answer calls ringing at another station in the same pick up group in PGM192. A
iPECS Phone users can be configured in the system to record all calls to a mailbox or the hard
disk drive of an iPECS Phontage or UCS Client. When recorded to a mailbox, users manage
the recording through voice mail. For recordings to the Phontage or UCS Client, recordings are
managed directly by Phontage or UCS Client with the ability to listen to, delete or send the
recording to others via e-mail.
Operation
Recording of calls is automatic when assigned.
To manage the recordings, use the procedures outlined in the Phontage or UCS Client User
Guide.
Conditions
1. The Phontage or UCS Client can record one call at a time and must be idle. While
recording, if the Phontage or UCS Client places or receives a call, recording
terminates.
2. When call recording begins, the station will receive a Call Recording confirmation
tone.
3. A remote Phontage or UCS Client will not support call recording.
4. If user want to record in case of CO call, he can set CO in PGM 112-Btn 20. If he
set ALL, all calls can be recorded.
CO/IP calls can be transferred to other stations in the iPECS system. Calls can be transferred
announcing the call (screened) or without an announcement (unscreened).
When a call is transferred, the Transfer Recall Timer is initiated. If the timer expires before the
call is answered, the Hold Recall process is initiated.
Operation
iPECS Phone
While on a CO/IP call, Screened Call Transfer
1. Press [TRANS] button.
2. Dial the station to receive the transfer.
3. At answer or splash tone, announce the call.
4. Hang-up to complete the transfer.
Or,
1. Press the {DSS/BLF} button for the desired station.
2. At answer or splash tone, announce the call.
3. Hang-up to complete the transfer.
While on a CO/IP call, Unscreened Call Transfer
1. Press [TRANS] button.
2. Dial the station to receive the transfer.
3. Hang-up to complete the transfer.
Or,
1. Press the {DSS/BLF} button for the desired station.
1. The transferring station may camp a call on to a busy station.
2. The LED of a {LOOP} or {POOL} button will display the status of a call until the
station no longer has call supervision i.e.; the call is successfully transferred.
3. To prevent Toll abuse, CO/IP lines without an active call (either incoming or dialed
digits on outgoing) cannot be transferred.
4. For outgoing CO Line calls, the system will monitor the CO Line for dial tone to
prevent Toll abuse. When an IP Line is seized, the system does not monitor for
dial tone.
Programming
Related Features
Hold Recall
Call Transfer, CO/IP
Call Waiting/Camp-On
Station Flexible Buttons
Hardware
2.17.2 Call Transfer, CO/IP
Description
A station may be permitted to transfer a CO/IP call to another CO/IP line, establishing an
Unsupervised Conference between the two external parties.
If the receiving party is called through an ISDN or VoIP path, the Transfer Hold Recall Timer is
initiated and if it expires, Hold Recall is initiated.
Operation
iPECS Phone
While on a CO/IP call, Screened Call Transfer
1. Press [TRANS] button.
2. Place CO/IP call in normal manner.
3. At answer, announce the call.
4. Hang-up to complete the transfer.
While on a CO/IP call, Unscreened Call Transfer
1. Press [TRANS] button.
2. Place CO/IP call in normal manner.
3. Hang-up to complete the transfer.
56
iPECS-LIK
STATION
1 Off Net Forward (PGM 111-Btn 14)
SYSTEM
1 Transfer Recall Timer (PGM 180-Btn 7)
2 Off Net Prompt Usage (PGM 160-Btn 11)
3 CO to CO US Timer Extension (PGM 160-Btn 12)
4 Unsupervised Conference Timer (PGM 182-Btn 5)
1. For this feature, at least one of the two CO/IP lines (transferred or receiving) must
provide detection of disconnect supervision and lost loop condition.
2. ISDN and VoIP calls can provide “Answer Supervision”, thus the iPECS system can
provide Transfer Recall.
3. If, during the transfer to an external party, the user presses the CO/IP line of the
original call, the outgoing call is disconnected and the original call is connected to
the user.
4. An H.323 or SIP call cannot be transferred to a like VoIP call using unscreened call
transfer.
Programming
Related Features
Hold Recall
Call Transfer, Station
Unsupervised Conference
Hardware
2.17.3 Call Transfer, Voice Mail
Description
CO/IP calls can be transferred directly to a station’s voice mailbox, either VMIM/VSF or an
external Voice Mail system.
57
iPECS-LIK
STATION
1 Direct Transfer Mail Box Destination (PGM 120-Btn
7. Dial the number or press the {DSS/BLF} button for the desired station.
8. Hang-up to complete the transfer.
Conditions
1. The LED of a {LOOP} or {POOL} button will display the status of a call until the
station no longer has call supervision i.e.; the call is successfully transferred.
Programming
Related Features
Hold Recall
Call Waiting/Camp-On
External Auto Attendant/Voice Mail
VMIM/VSF Voice Mail
Hardware
iPECS Phone
2.17.4 Call Transfer, System Announcement No.
Description
CO calls can be transferred directly to a system announcement number.
After transferring to system announcement number, system starts DISA service.
Call Waiting is used to notify a busy station that a call is waiting to be answered. The busy
station is notified of the waiting call by a “Camp-On” tone. For users of an iPECS Phone, the
LED of the [HOLD] button will flash.
After receiving a busy signal, the calling station camps on to the called station. The called
station can respond by:
a. answering the waiting call, which places the active call on hold first,
b. sending a silent text or voice message,
c. activating One-Time DND, or
d. ignoring the Camp-On tone.
Operation
iPECS Phone
To activate a Camp-On while receiving Intercom busy tone
1. Press the “*” button, called and calling stations receive Camp-On tone.
SLT
To activate a Camp-On while receiving Intercom busy tone
1. Press the “*” button, called and calling stations receive Camp-On tone.
Conditions
1. The user may only Camp-On to a station in the busy mode. A user may not CampOn to a station in DND, in a conference, receiving a Page, etc.
2. The Camp-On procedure is employed by an Attendant or Secretary of an
Executive/Secretary pair to activate DND Override.
3. A Camp-On tone is sent each time the calling user presses the “*” button.
4. A text or voice message, Pre-defined or Custom may be used to respond to a
Camp-On.
Programming
Related Features
Pre-defined & Custom Text Display Messages
DND (Do Not Disturb)
Intercom Call (ICM Call)
Silent Text Message
Voice Over
Stations can access outgoing CO/IP lines based on CO/IP Group Access programming. iPECS
Phones may use flexible buttons assigned to access a specific {CO} line, {POOL} button for
outgoing calls or a {LOOP} button.
Individual users may be allowed to assign CO/IP access flexible buttons.
Operation
iPECS Phone
To assign a {LOOP} button
1. [PGM] + {FLEX} + [PGM] + “85” + [SAVE]
To assign a {POOL} button
1. [PGM] + {FLEX} + “8x” + [SAVE]
To place an outgoing CO/IP call
1. Lift the handset or press the [SPEAKER] button.
2. Press desired {CO} line, {POOL}, {LOOP} button or dial the CO line or Group
access code.
To answer an incoming CO/IP call
1. Lift the handset or press the [SPEAKER] button.
Or,
1. Press flashing {CO} line, {POOL} or {LOOP} button; lift the handset to speak
privately.
SLT
To place an outgoing CO/IP call
1. Lift handset.
2. Dial the CO line or Group access code.
3. Dial the desired number.
To answer an incoming CO/IP call
1. Lift handset.
Conditions
1. When a user dials “9”, the system will search the preferred CO group for idle CO/IP
line, if there is no idle CO/IP line then the system will search the 1st CO/IP Group
for an idle CO/IP line. The system may continue the search through all CO/IP line
groups for an available line if “1st CO/IP Group Override” is enabled.
2. A telephone user not allowed access to a CO/IP line receives error tone when
access is attempted. The station may receive transferred calls on such denied
access lines but will not be able to flash or use the CO/IP line for an outgoing call.
3. A station denied access to a CO/IP line but assigned to have ring for the CO/IP line
will receive ring, a flashing {CO}/{IP} line LED and may answer the call. The user
may transfer the call but cannot make an outgoing call on the CO/IP line.
61
iPECS-LIK
STATION
1 CO/IP Line Access (PGM 112-Btn 4)
2 CO Line Programming (PGM112-Btn 6)
3 Prefer CO/GROUP (PGM112-Btn 14th)
4 CO Line Group Access (PGM 117)
CO/IP
1 CO/IP Line Group (PGM 141-Btn 1)
2 CO/IP Ring Assignment (PGM 144)
The system can be programmed to limit the length of outgoing calls by specified stations. When
a specified station places an outgoing call, the system initiates the Call Restrict timer and, 15
seconds prior to expiration, a warning tone is delivered. At expiration, the system terminates
the call returning the external CO/IP line to idle.
In PGM 142 – 21 : CO CUT OFF TIMER is added.
By using this timer, CO Base call time restriction is possible.
Operation
System
Operation of this feature is automatic when assigned
Conditions
1. Once activated, the Call Warning Tone timer continues timing while the call is
connected to the system even if the call is transferred or picked up at another
station.
2. There are two kinds of CUT OFF timer. One is Station base, the other is CO base(It
is newly added). If two timers are assigned simultaneously, call can be followed by
shorter timer.
Stations can receive a tone indicating the elapsed time of a CO/IP call has reached the
Warning Tone time. The station hears the tone after the CO Warning Tone Timer has elapsed.
Operation
System
Operation of this feature is automatic when assigned
Conditions
1. Warning tone is received 15 seconds prior to expiration of the timer and is repeated
at intervals equal to the Warning Tone Timer.
When CO/IP lines are busy, permitted users can request to be placed in queue awaiting the
CO/IP line or a CO/IP line in the same group to become available. When an appropriate CO/IP
line becomes available, the system calls the waiting station on a first in first out basis.
Operation
iPECS Phone
To request to be placed in queue for a busy CO/IP line
1. Press busy {CO/IP} or {CO/IP GRP} button.
2. Press the [MSG/CALLBK] button, confirmation tone is received.
3. Hang-up, the [MSG/CALLBK] LED flashes.
To cancel the queue from the queued station
1. Press the [MSG/CALLBK] button, the [MSG/CALLBK] LED extinguishes.
SLT
To request to be placed in queue while receiving “All Lines Busy” signal
1. Momentarily press the hook-switch.
2. Dial “556”, the Callback feature code.
To cancel the queue from the queued station
1. Lift the handset.
2. Dial “556”, the Callback feature code.
System
When a CO/IP line becomes available
1. Send distinctive Queue recall to the station with oldest queue, flash appropriate
{CO}/{IP} line button LED. Make CO/IP line and station busy to all other users.
Conditions
1. A CO/IP line can have any number of simultaneous queue requests.
2. A station may only have a single active CO/IP queue request. Activating a new
queue request will replace, and thus cancel, an existing queue.
3. A Queue recall will always signal the station with tone ring, ignoring the station’s
assigned Intercom Signaling mode.
4. Queue recall will bypass a busy station, and place the station at the bottom of the
queue list.
5. Queue recall will signal a station for 15 seconds, after which, the station is removed
from the queue; the queue is cancelled.
In addition to ad-hoc conferencing, users may establish a Conference Room. Other internal
and external parties are invited to the conference and can join the conference without further
action by the user who established the Conference Room. A user can transfer an active call to
a Conference Room. A Conference Room can be password protected so that only parties that
enter the password are allowed to join the Room.
Up to 9 Conference Rooms can be set-up and each can support a maximum of 32 parties with
the g.711 or g.729 codec or 24 parties with the g.723 codec. Conference Rooms employ
channels from an MCIM (Multi-party Conference Interface Module). Each MCIM supports up to
32 parties and multiple MCIM units may be installed as shown in the chart below.
Operation
Attendant Phone
To view Room participant list
1. Press the [PGM] button.
2. Dial “054”.
3. Dial Room number (1~9).
To delete a Conference Room
1. Press the [PGM] button.
2. Dial “055”.
3. Dial Room number (1~9).
iPECS Phone
To set-up a Conference Room
1. Press the [PGM] button.
2. Dial 53 to create a Conference Room.
3. Dial the desired Conference Room number (1~9).
4. If desired, enter a password for the Conference Room (must be exactly 5 digits).
6. Momentarily press the hook-switch, receive confirmation tone.
Conditions
1. Once established, a Conference Room will remain opened until the Room is deleted.
2. The Conference Room feature employs the Multi-party Conference Interface
Module (MCIM), which must be installed for proper operation.
3. iPECS Phontage and UCS Client may also create, delete and join a Conference
Room. For operation, refer to the iPECS Phontage or UCS Client User Guide.
The system allows multiple internal and external parties to be connected on a call, conference.
An unlimited number of 3-party conferences may be established using iPECS Phones. In
addition, each MCIM (Multi-party Conference Interface Module) up to 32 parties with the g.711
or g.729 codec and 24 with the g.723 codec may be connected in a single voice conference.
The MCIM will support any combination of parties and conferences to the maximum total
number of parties in conference. Multiple MCIMs, see chart below, are installed to support
multiple multi-party conferences with a maximum of 32 parties in any single conference.
Operation
iPECS Phone
To establish an ad-hoc conference
1. Establish first call.
2. Press the [CONF] button. The LED will light, the connected party is placed on
exclusive hold and the user receives dial tone.
3. Place second call.
4. When connected, press [CONF], new call is placed on exclusive hold.
5. Repeat steps 3 and 4 above to add additional conference parties.
6. Press [CONF] button to establish conference.
To place a conference on hold
1. Press the [HOLD] button, the [CONF] button LED will flash.
2. Momentarily press the hook-switch, the connected party is placed on exclusive hold
and the user receives dial tone.
3. Place second call.
4. When connected, repeat steps 2 and 3 above to add additional parties.
5. When completed adding parties, momentarily press hook-switch twice in 2 seconds,
all parties are connected.
Conditions
1. The [CONF] button remains illuminated at the initiators phone for the duration of the
conference.
2. There is no limit on the number of 3-way conferences the system will support with
iPECS Phones. With the MCIM, the system can support conferences of more than
3 parties. Each MCIM supports 32 conference channels with the g.711 or g.729
codec or 24 with the g.723 codec and can support multiple conferences with a total
maximum number of 32 or 24 users.
3. If all MCIM channels are busy when a request for a channel is received, the user will
receive error tone and the display will indicate that no Conference channels are
available.
4. If the system receives a disconnect signal and no internal parties remain in the
conference, the conference is terminated and all parties are disconnected. If an
internal party is still connected when a disconnect signal is received, the
connection to remaining parties is maintained.
5. The normal Hold Recall process is applied to a conference on hold using the
Unsupervised Conference recall Timer for recall timing.
6. If while setting up a conference, system error tone is received, the initiator must
press the [CONF] button (SLT must hook-flash) to regain Intercom dial tone.
7. A station that is busy, in DND or other non-idle state cannot be added to a
conference.
8. 8. The MCIM is also employed to support the Conference Room feature.
An iPECS phone user may establish a conference with external parties and exit the conference
while allowing the external parties to converse privately without supervision from the user.
The system will disconnect the Unsupervised conference if disconnect is detected with only two
parties connected or at expiration of the Unsupervised Conference timer. Fifteen seconds prior
to expiration of the timer, a Disconnect Warning Tone is provided.
If enabled, either party in an Unsupervised Conference can request the Unsupervised
Conference timer be extended. The party enters the Timer Extension feature code and a digit 1
to 9 indicating the Timer extension multiplier. The system will then extend the timer based on
the dialed digit multiple of the Timer. For example, if the Unsupervised Conference timer is 5
minutes and the user dials the digit 4, the timer will extend to 20 minutes (4 multiplied by 5
minutes).
Operation
iPECS Phone
To set up an Unsupervised conference
1. Establish normal conference.
2. Press the [CONF] button. The [CONF] button LED flashes to indicate the
Unsupervised Conference state.
To reenter the Unsupervised conference
1. Press the flashing [CONF] button.
Conf Party
To extend the Unsupervised Conference from a connected party
1. Dial “# #”.
2. Dial the Timer extension multiplier (1~9).
Conditions
1. The Unsupervised Conference Timer also applies to an external call placed by a
DISA user.
2. An Unsupervised conference will be terminated if the system receives a disconnect
signal or the Unsupervised Conference Timer expires.
3. An Unsupervised Conference will not recall the user.
Direct Inward System Access (DISA)
Multi-Party Voice Conference
Hardware
iPECS Phone to establish Unsupervised Conference
MCIM required to support conferences with more than 3 parties
2.23.4 Conference Group
Description
Stations and external contacts can be arranged in groups so that a user may create a
conference with all members of the group through a single call. Each conference group can
have up to 32 members that can be a station or an external telephone number. Conference
groups are assigned in the iPECS User Portal (Station Web Admin) by assigning a conference
group number and the members of the group. A voice recording, which is played to members
receiving the Conference group call, can be associated with the group. Initiation of a Group call
can be password protected with a 5-digit password assigned when the group is created.
There are two (2) types of Conference Groups, Station and System. The Station Conference
group is created by the station user, who is assigned as the group supervisor, and is the only
member that can initiate a Conference group call. The System Conference Group is created by
an Attendant or system administrator and any member can initiate the Conference Group call.
The member initiating the call becomes the supervisor for that Conference Group call.
The supervisor can manage membership in the conference and can monitor the status of each
member, in/out of conference. The Supervisor can remove members from the conference or, if
members are absent, the supervisor can add a non-member to the conference. An Absent
Supervisor timer terminates the conference if the supervisor is not in the conference for the
timer interval. Setting the interval to “0” disables this feature.
Once a group is created, the supervisor imitates the conference by calling the conference
group. The system then attempts to call each member of the group either simultaneously or in
turn using the Interval timer assigned for the group. Members that answer the call receive the
recorded voice announcement, if any, and can enter the conference, dial “1”, or reject the
conference, hang-up. The system will attempt to contact a busy or no-answer member based
on the assigned Retry Count. A call is consider no-answer using the no-answer timer set when
the group was created.
Operation
To create a conference group from the iPECS User Portal:
1. Access Station Program in the Web Admin.
2. Select Conference Group button.
3. Create the Conference group entering:
The name of group : up to 12 character,
The password: Passwords must be 5-digits.
Announcement number for the group: (pre-recording the announcement is
The No answer timer,
The busy/no-answer Retry count,
The Interval time: Each member is called in turn at expiration of the interval
timer.
4. Set the Member Attributes by entering:
Index number
Type: Station, Individual CO, CO group, loop or Transit-out code (access loop
for networking call).
The CO value: the supervisor wants to select a specific CO line or CO group.
Dial number: The station number or Co dial number.
Operation
IPECS phone
To assign a {GRP MONITOR} button
1. [PGM] + {FLEX} + [PGM] + “55” + [SAVE]
To initiate a Conference Group call:
1. Lift the handset.
2. Dial 68xxx, the Group Conference code and group number.
3. Enter the Conference group password, if assigned, members receive the
Conference Group call.
To enter a Conference Group call:
1. Answer the ringing call and receive recorded announcement, if assigned and
recorded.
2. Dial “1” to enter the conference or hang-up to reject the conference. For iPECS
Phontage or UCS clients, use Accept or Deny when notified of the conference.
To monitor member conference status or delete members while in the conference:
1. Press the Monitor flex button, the state of the first member is displayed.
2. Press [VOL UP/VOL DWN] button to display the state of other members.
3. Press the [DND] button to delete a participant from the conference.
To monitor the Group member conference status while Not in the conference:
1. Press the [PGM] button.
2. Dial 55, the Monitor Conference Group code.
3. Press [VOL UP/VOL DWN] button to display the state of other members.
To add a non-member to the Group:
1. Press the [HOLD] button to place the conference on hold.
In Multi-Party conference,
Conference supervisor can see the conference member and remove the member from
conference.
Operation
1. Conference supervisor press {VIEW} soft button in conference.
2. LCD displays the first member. If member is a station, “STA XXX” display. If
member is a co line, telephone number of caller/called party in the co line display.
3. Conference supervisor can see other members by pressing [VOLUME UP/DONW]
button. (Next member if [VOLUME DOWN] button, previous member if [VOLUME UP] button)
4. If press {DELETE} soft button, the current member will be removed from
conference.
5. If press {ADD} soft button, the conference supervisor can add a new member.
6. If press {BACK} soft button, conference supervisor will be back to normal
conference state.
A Customer Name, up to 23 characters, may be entered into the system database. The name
is displayed on the SMDR and database outputs as well as during an Admin session.
Operation
System
Operation of this feature is automatic when a name is assigned
Data transmitted over analog CO lines is subject to distortion and errors if system tones such
as Camp-On and Override are applied during transmission. To eliminate such errors, stations
that use analog data (modems or Fax) can be assigned to block incoming system tones.
Operation
System
System tones are automatically blocked when Data Line Security is assigned
Conditions
1. Stations or an Attendant attempting to Camp-On or Override a station with Data
Line Security will receive error tone.
2. When Data Line Security is enabled, the system will not apply audio gain to the call.
Ring signals for an incoming CO/IP call can be sent to stations immediately upon detection or
after an assigned ring cycle delay. The delay can be up to 9 system ring cycles, thus allowing
other stations to answer the call.
Operation
System
Delay Ring operation is automatic when assigned
Conditions
1. Delay Ring can be assigned for a station or Station Group.
2. If no delay is entered when programming Ring assignments, the station will receive
immediate ring.
3. Private Lines may be assigned with delayed ring.
4. If no station or Station Group is assigned for immediate ring, the call will ring
immediately at the first available Attendant.
Programming
Related Features
Private Line
Station Groups
CO/IP Ring Assignment
An incoming CO/IP call can be routed to the VMIM/VSF Auto Attendant either immediately
upon detection or after a delay of up to 30 seconds. This allows other stations assigned
immediate ring the opportunity to answer before the call is routed to the Auto Attendant.
Operation
System
Operation of this feature is automatic when assigned
Conditions
1. When Delayed Auto Attendant Ring is assigned, after the delay, the call will no
longer ring assigned stations and will only ring to the VMIM/VSF Auto Attendant.
2. If no delay is entered, the call will ring to the VMIM/VSF Auto Attendant immediately.
3. To assign Delayed Attendant ring, at least one station or Station Group must be
assigned immediate ring.
4. Ring is assigned to a VMIM/VSF Auto Attendant announcement (01-70) as a
“station type” with a delay from 00 to 30 seconds.
Programming
Related Features
• CO/IP Ring Assignment
Hardware
2.27.2 DISA Incoming Case (Russia Only)
Description
In case of DISA incoming call, there are two Timers that is related with DISA Delay. These
timers can be set in PGM 142 – Co-line Base.
DISA Answer Timer : When DISA incoming call is routed to a system, after this time, system is
answered.
DISA Delay Timer : When system is answered, after this time, VSF system announcement start
to play.
The system software incorporates various diagnostic and maintenance routines that may be
“called” remotely or locally through the systems RS-232 serial ports, a TCP/IP connection using
a Web browser established over IP networks or a PPP connection over ISDN. Routines that
can be accessed include trace functions at the device level, commands for diagnostics and
maintenance, and tools for manipulation at the OS level.
An optional Network Management System application is available providing remote access to
the system for maintenance and diagnostics. For details on the iPECS NMS application, refer
to the iPECS NMS Manual.
A name, up to 16 characters, may be assigned to each Station and System Speed dial. In
addition, each station may be assigned a 12-character name. When assigned, a user may
place an intercom call to another station or select a Station or System Speed dial using the
name.
The user selects from one of three Dial-by-Name directories and enters characters employing 2
dial pad buttons for each character. The system finds and displays the nearest match to the
user entries. The user may continue entering characters or scroll the directory at any point
using the [VOL UP]/[VOL DWN] button and select a name to call. The number associated with
a selected name is displayed by using the [TRANS] button.
Operation
iPECS Phone
To use Dial by Name using a [SPEED] button
1. Press the [SPEED] button twice.
2. Dial the desired directory, I: Intercom, U: User Speed Dial, S: System Speed Dial.
3. Search the directory using the [VOL UP]/[VOL DOWN] button or by entering
characters. See Station Speed Dial for character entry procedure.
4. Press the [SAVE] button to place the call.
To use Dial by Name using the LIP-8000 series soft buttons
1. Press the [DIR] soft button.
2. Dial the desired directory, 1: User Speed Dial, 2: System Speed Dial 3: Intercom.
3. Search the directory using the [Navigation] button or by entering two digits for each
character, see section 2.65.3 for character entry procedure.
4. Press the [HOLD/SAVE] button to place the call.
To toggle between the name and number display
1. Press the [TRANS] button.
To program the station user name
1. Press the [PGM] button.
2. Dial “74”, the User Name Program code.
3. Dial the name, up to 12 characters; refer to Station Speed Dial for character entry.
4. Press [SAVE].
SLT
To program the station user name
1. Lift the handset.
2. Dial “561”, SLT Programming code.
3. Dial “74”, the User Name Program code.
4. Dial the name, up to 12 characters; refer to Station Speed Dial for character entry.
5. Momentarily press the hook-switch, confirmation tone is received.
2. Dial “071”, the Attendant User Name Program code.
3. Dial the station number.
4. Dial the name, up to 12 characters; refer to Station Speed Dial for character entry.
5. Press [SAVE].
Conditions
1. Available characters are A to Z, space and period.
2. The LCD will display multiple names, one per LCD line up to 16 characters.
3. If a user selects a directory with no entries or there is no match to the user entry, the
“No Entries” message is displayed and error tone is provided.
4. Dial-by-Name is only available to iPECS Phones with a display. Other users will
receive error tone if an attempt is made to access Dial-by -Name.
5. A user may both scroll and enter characters to search a directory.
Programming
Related Features
Station Speed Dial
System Speed Dial
Hardware
iPECS Phone w/Display
83
iPECS-LIK
CO/IP
1 CO Line Type (PGM 141-Btn 4)
2 CO Line Signal Type (PGM 141-Btn 5)
On a pulse dial CO line, the user can request the system to change the signaling mode from
pulse to DTMF. This allows the user to access outside facilities that require DTMF signals such
as banking services, voice mail, etc.
Operation
To switch from pulse to DTMF while on a pulse CO line
1. Dial “*”, signaling changed to DTMF.
Conditions
1. In a Speed Dial, the “*” will automatically insert a pause before dialing the remaining
digits.
2. This command is only recognized for analog pulse dial CO lines.
3. Dial pulse to tone switchover is not available in the Redial features.
4. When “*” is the first digit of a dialed number, the Display Security feature is enabled
and not Pulse to tone switchover.
5. For VoIP calls, pulse dialing is not available thus; switchover is not required or
supported.
Programming
Related Features
Speed Dial
Display Security
Hardware
84
iPECS-LIK
Station COS
Dialing Restriction
1
No restrictions are placed on dialing.
2
Assignments in Exception Table A are monitored for allow and deny numbers.
3
Assignments in Exception Table B are monitored for allow and deny numbers.
4
Assignments in Exception Tables A & B are monitored for allow and deny numbers.
5
The leading digit cannot be a Long Distance code and assignments in Exception Table C
apply.
6
Number of digits cannot exceed LD digit count and assignments in Exception Table C
apply.
7
Intercom and Emergency number calls are allowed. Incoming and transferred calls are
allowed.
8
Assignments in Exception Table D are monitored for allow and deny numbers.
9
Assignments in Exception Table E are monitored for allow and deny numbers.
10
The assignments in the Exception Table D & E are monitored for allow and deny numbers.
11
The assignments in the Exception Table A & B and D & E are monitored for allow and deny
numbers.
Station COS
Dialing Restriction
1
Dialing privileges are governed by the Station COS only.
2
Assignments in Exception Table A govern dialing privileges for Station COS 2 & 4.
3
Assignments in Exception Table B govern dialing privileges for Station COS 3 & 5.
4
No LD calls (LD code & digit count) and assignments of Exception C apply to Station COS
2 & 6 only.
5
No dialing restrictions applied, overrides Station COS 2 through 6.
Dialing privileges can be assigned for each station, DISA line and Authorization Code. The
dialing privileges are the result of the interaction of the Station and CO Class of Service (COS)
assignments as shown in the following tables. Users placing an outgoing call or dialing after
answering a call will be allowed the dialing privileges assigned.
Station/DISA/Code Class of Service – There are eleven (11) Station Class of Service
assignments, which also apply to DISA and Authorization Code users based on the assigned
COS.
CO Class of Service – There are five (5) CO line COS assignments.
85
iPECS-LIK
Station
COS
Restriction
CO COS 1
CO COS 2
CO COS 3
CO COS 4
CO COS 5
1
No restriction
No restriction
No restriction
No LD calls &
Table C
No restriction
2
Exception Table A
Exception Table A
No restriction
No LD calls &
Table C
No restriction
3
Exception Table B
No restriction
Exception Table B
No LD calls &
Table C
No restriction
4
Exception Table A
& B
Exception Table A
Exception Table B
No LD calls &
Table C
No restriction
5
Local call & Table
C
Local call & Table
C
Local call & Table
C
No LD calls &
Table C
No restriction
6
Local call & Table
C
Local call & Table
C
Local call & Table
C
No LD calls &
Table C
No restriction
7
Intercom only
Intercom only
Intercom only
Intercom only
Intercom only
8
Exception Table D
Exception Table D
No restriction
No LD calls &
Table C
No restriction
9
Exception Table E
Exception Table E
No restriction
No LD calls &
Table C
No restriction
10
Exception Table D
& E
Exception Table D
& E
No restriction
No LD calls &
Table C
No restriction
11
Exception Table
A, B, D & E
Exception Table
A, B, D & E
No restriction
No LD calls &
Table C
No restriction
Rule 1
If a table has no entries, no restrictions are applied.
Rule 2
If there are only Deny entries, restrictions are provided as Deny only.
Rule 3
If there are only Allow entries, restrictions are provided as Allow only.
Rule 4
If there are both Allow and Deny entries, the Deny entries are searched. If the
dialed number matches a Deny entry, the call is restricted; if no match is found
the call is allowed.
Station & CO COS Interaction The following chart displays the dialing capabilities based on the
interaction between the Station COS and CO line COS assignments.
PBX Dialing Codes – Four (4) one or two-digit PBX Trunk Access Codes can be defined in the
system database. When dialed as the first digit(s), these codes signal the system to apply the
appropriate COS. If not dialed, the call is treated as an internal PBX call and dialing is not
restricted.
Exception Tables – Each Exception Table permits entry of 50 Allow codes and 50 Deny codes.
Each code can contain up to 20 digits including digits 0-9, “#” as a wild card (any digit) and “*”
as the end of entry mark. Reference the previous charts for application of the Exception Tables.
Exception Table process – As digits are dialed, they are compared to entries in the appropriate
Exception Table. Based on the Allow and Deny entries, the system applies the following rules
to allow or deny the call.
1. The dialing privileges are based on the CO and Station COS.
2. The selection of the COS is made based on the Authorization code entered by the
user.
3. COS does not apply to calls placed over a VoIP channel.
Programming
Related Features
Day/Timed & Night Station COS
Direct Inward System Access (DISA)
Temporary Station COS/Lock
Walking COS
Hardware
2.31.2 Day/Timed & Night Station COS
Description
Each station, DISA line and Authorization code is assigned a COS for two modes: Day, which
includes Timed, and Night service modes. The service mode is generally controlled by the
System Attendant and, based on the mode, appropriate dialing privileges are established.
Operation
System
Dialing restrictions are automatically applied based on COS assignments
Conditions
87
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
