IP-COM I-SWHUB G1050F Datasheet

W63AP

G1050F

AC1200 Wave 2 Gigabit Access Point

48GE+2SFP Unmanaged Switch

www.ip-com.com.cn

www.ip-com.com.cn

G1050F

48GE+2SFP Unmanaged Switch

Product Introduction

Developed by IP-COM, G1050F is a Gigabit unmanaged

www.ip-com.com.cn

Ethernet switch designed for establishing wired networks of
high density and high speed in such scenarios as enterprises,
parks, schools, and internet cafes, providing a simple, easy,
cost-effective, and rapid internet access solution for video
surveillance and SMBs' networking. With 48 10/100/1000
Mbps RJ45 ports, and 2 independent Gigabit SFP slots that
can be paired with IP-COM's SFP modules, this switch can
be used to deploy a long-distance network up to 20 km. Its
full-duplex transmission rate can reach 2000 Mbps, ensuring
the timely transmission of large files and smoothness of
videos. Its one-key VLAN function can isolate broadcast
storms. Its integrated professional lightning protection circuit
offers 6 kV lightning protection for the built-in power supply
and all Ethernet ports, ensuring the stability and reliability of
the switch. The switch supports desktop mounting, rack
mounting and wall mounting, and features a 1U 19-inch
standard rack-mount shell design and plug & play function.
With these advantages, it is an ideal choice for deploying a
cost-effective and high-speed network.

01

G1050F 48GE+2SFP Unmanaged Switch

Key Features

Product Features

www.ip-com.com.cn

* Comply with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, and IEEE 802.3x standards.
* Provide 48 10/100/1000 Mbps Base-T Ethernet ports and support auto MDI/MDIX.
* Provide 2 independent 1000 Mbps Base-X SFP ports and support 20 km long-distance networking.
* Support 16 K MAC address table and MAC address auto-learning.
* Support full duplex IEEE 802.3x flow control and half duplex back pressure flow control.
* Support unblocked wire speed forwarding for all ports.
* Support 12 Mb large buffer queue.
* Integrated professional lightning protection circuit offers 6 kV lightning protection for the built-in
power supply and all Ethernet ports.
* One-key VLAN function helps isolate broadcast storms effectively.
* Feature a 19-inch/1U standard rack-mount shell design.

High-density Gigabit Ports

The switch provides 48 10/100/1000 Mbps auto-negotiation RJ45 ports, and 2 independent
1000 Mbps SFP ports. The full-duplex transmission rate of the switch can reach 2000 Mbps,
and all ports feature wire speed forwarding, ensuring high performance for processing
applications that require high bandwidth.

12 Mb Large Buffer

With 12 Mb large buffer, the switch can meet the needs of such network applications with burst
traffic as search engine, IPTV, and P2P downloads, ensuring no packet loss, timely transmis­sion of large files, and smoothness of videos.

6 kV Lightning Protection

This switch provides 6 kV lightning protection for both Ethernet ports and the power supply,
and supports over-temperature, over-voltage and surge current protection.

One-key VLAN

Under the VLAN mode, ports 1 to 46 cannot communicate with each other, but can communi­cate with uplink ports 47 to 50, isolating broadcast storms and enhancing network security.

02

Ease of Use

The switch features a 1U 19-inch standard rack-mount shell design and can be easily installed
on a 19-inch rack using the included L-shaped brackets. With plug & play function, it needs no
professional settings and can be used for networking directly, greatly reducing the maintenance
cost.

G1050F 48GE+2SFP Unmanaged Switch

Application Scenarios

www.ip-com.com.cn

1000M Ethernet cable

1000M fiber cable

G1050F

Servers

1000 Base-T

G1016G

10/100/1000 Base-T

G1008 G1005

10/100/1000 Base-T 10/100/1000 Base-T

03

G1050F 48GE+2SFP Unmanaged Switch

www.ip-com.com.cn

Packaging

Product model

Product model G1050F

Network standards IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3z

One Link/Act LED indicator for each Gigabit port

LED indicators

One Power LED indicator for each device
One VLAN LED indicator for each device

Ports

Transmission medium

Dimensions (L x W x H) 440 mm x 240 mm x 44 mm

Product material Steel shell

Fan Fanless

Protection

Forwarding mode Store-and-forward

48 10/100/1000Base-T Ethernet ports
2 independent 1000 Mbps SFP ports

Ethernet: CAT3 UTP or better
Fast Ethernet: CAT5 UTP or better
Gigabit Ethernet: CAT5e UTP or better
1000Base-SX: MMF
1000Base-LX: MMF or SMF

Port lightning protection: 6 kV

Power supply lightning protection: 6 kV

Electrostatic protection:

- Air discharge: ±8 kV

- Contact discharge: ±6 kV

Switching capacity 100 Gbps

Packet forwarding rate

Buffer 12Mb

MAC address table 16K

Jumbo frame 12K

04

10 Mbps: 14880 pps
100 Mbps: 148800 pps
1000 Mbps: 1488000 pps

G1050F 48GE+2SFP Unmanaged Switch

Packaging

www.ip-com.com.cn

Power supply

Input: 100 - 240V AC 50/60Hz
Output: 12V 4A

Whole switch consumption Whole switch consumption: <48 W

Support desktop mounting

Mounting methods

Support wall mounting

Support rack mounting

Operating temperature: 0°C - 45°C

Environment

Storage temperature: -40°C - 70°C
Operating humidity: (10% - 90%)RH, non-condensing
Storage humidity: (5% - 90%)RH, non-condensing

Certificates CCC, FCC, CE, RoHS

Software features

Protocol CDMA/CD

MAC address learning Auto learning and auto updating

Function

One-key VLAN (In this mode, ports 1 to 46 cannot communicate
with each other, but can communicate with ports 47 to 50.)
