Page 1
G3310P-8-150W
8GE+2SFP Cloud Managed PoE Switch
www.ip-com.com.cn
Page 2
G3310P-8-150W
8GE+2SFP Cloud Managed PoE Switch
Products Description
G3310P-8-150W is a smart cloud management
www.ip-com.com.cn
PoE switch designed by IP-COM. It provides 8
gigabit PoE ports and 2 SFP ports, supports IEEE
802.3af/at standards, and can smartly identify
powered devices. The maximum output power
of a single port is 30W and the power of the
whole switch is 150W. It supports IMS Cloud,
web UI, and IP-COM IMS app management,
making network maintenance more efficient,
after-sales cost lower, and management and
configuration simpler. It is an ideal choice for
video surveillance and wireless networking in
such scenarios as small and medium-sized
enterprises, hotels, schools, and parks.
01
G3310P-8-150W 8GE+2SFP Cloud Managed PoE Switch
Page 3
Key Feature
www.ip-com.com.cn
•
Compliance with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3z,
IEEE 802.1p/q/w/d, and IEEE 802.3af/at standards
•
8 x 10/100/1000 Base-T Ethernet ports (Data/Power); 2 x 100/1000 Base-X SFP ports
•
8K MAC address and MAC address automatic learning
•
IEEE 802.3x full-duplex flow control and half-duplex backpressure flow control
•
Non-blocking line-rate forwarding for all ports
•
Maximum output power of a single PoE port: 30W; Maximum output power of the whole
switch: 130W
•
IMS Cloud and IP-COM IMS app remote cloud management
•
IEEE 802.1Q VLAN; Link aggregation; QoS; MAC address binding
Main Features
App remote management
With one-tap, you can add the device to automatically configure and bring online the
switch, enabling you to check device status anytime, anywhere.
IMS Cloud management
You can remotely divide VLAN and restart PoE port, making network maintenance
easier.
Smart PoE power supply
The 8 IEEE 802.3af/at gigabit PoE ports, the maximum 130W power output of the
whole switch, the maximum 30W power output of a single port all guarantee a stable
02
power supply and data transmission for such devices as HD PoE IP cameras and APs.
Various layer-2 management features
The 250-meter power supply distance, and such smart management functions as
QVLAN, link aggregation, QoS, and MAC address binding make construction easier
and faster, reducing investment to the greatest extent.
G3310P-8-150W 8GE+2SFP Cloud Managed PoE Switch
Page 4
Typical Application
www.ip-com.com.cn
Core Switch
G5528X-EI
G3310P-8-150W
AC3000
Conference Room
AP355 AP355AP355
Dining Hall Dining Hall
Conference Room
Conference Room
Dining Hall
Core Layer
Aggregation Switch
G3328F
Reception hall
monitoring
G3310P-8-150W G3310P-8-150W G3310P-8-150W G3310P-8-150W G3310P-8-150W G3310P-8-150W
Conference room
WiFi network
AC Controller
Aggregation
Aggregation Switch
G3328F
Aggregation Switch
G3328F
Layer
Access Layer
Office monitoring Office WiFi network Corridor monitoring Outdoor monitoring
03
G3310P-8-150W 8GE+2SFP Cloud Managed PoE Switch
Page 5
Specifications
Hardware
Product Model G3310P-8-150W
www.ip-com.com.cn
Network Standard
LED Indicator
Fixed Port
Port Lightning Protection ≥6 kV
Forwarding Mode Store and forward
Switching Capacity 20 Gbps
Packet Forwarding Rate 14.9 Mpps
MAC Address Table 8K
PoE Power Supply Ports 1 to 8 support 802.3af/at standard
Input Voltage AC: 100-240V 50/60Hz
Dimensions (L * W * H) 294 mm * 179.6 mm * 44 mm
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3z, IEEE 802.1p,
IEEE 802.1q, IEEE 802.1w, IEEE 802.1d, IEEE 802.3af, IEEE 802.3at
1 Link/Ack LED indicator for each port
1 PoE Max LED indicator for each device
1 Power LED indicator for each device
1 SYS LED indicator for each device
8 x 10/100/1000 Base-T Ethernet ports (Data/Power)
2 x 100/1000 Base-X SFP ports
1 2 4 5 +, 3 6 7 8 -
Whole Switch Power Consumption Whole switch power consumption: <150W; Maximum PoE output power: 130W
Operating temperature: 0°C - 45°C
Operating Environment
Storage temperature: -40°C - 70°C
Operating humidity: (10% - 90%) RH, non-condensing
Storage humidity: (5% - 90%) RH, non-condensing
Software Specifications
Port PoE configuration and power supply priority configuration supported
PoE Power Supply Management
Security Features MAC address binding supported
VLAN IEEE 802.1Q VLAN supported
Port Aggregation
Spanning Tree IEEE 802.1w RSTP (Rapid Spanning Tree Protocol) supported
PoE over-temperature protection supported
Smart graphical management and PoE-powered device detection supported
(port status, power assignment, and PoE-powered device status)
Static aggregation supported
Dynamic aggregation supported
04
G3310P-8-150W 8GE+2SFP Cloud Managed PoE Switch
Page 6
Specifications
Software Specifications
Port Mirroring N: 1 port mirroring supported
FIFO (First-In, First-Out) supported
QoS
SP (Strict Priority) supported
WP (Weighted Priority) supported
www.ip-com.com.cn
Loading & Upgrade
Management & Maintenance
Certificates CCC, FCC, CE, RoHS
HTTP upgrade supported
Configuration import and export supported
IP-COM IMS app management supported
Web UI management supported
IMS Cloud management supported
05
G3310P-8-150W 8GE+2SFP Cloud Managed PoE Switch
Page 7
www.ip-com.com.cn
IP-COM NETWORKS CO.,LTD.
Tower E3, No.1001, Zhongshanyuan Road,
Nanshan District, Shenzhen, China. 518052
Service: [email protected]
Inquiry: [email protected]
Tel: +86-755-27653089
Specifications are subject to change without notice.Copyright ©2021 IP-COM Networks Co., Ltd. All Rights Reserved. IP-COM is the trademark of IP-COM TECHNOLOGY CO.,LTD. All other
brand names mentioned herein are the trademark or registered trademarks of their respective holders.
