G1118P-16-250W
16GE+2SFP Ethernet Unmanaged Switch With 16-Port PoE
www.ip-com.com.cn
Page 2
www.ip-com.com.cn
G1118P-16-250W
16GE+2SFP Ethernet Unmanaged Switch With 16-Port PoE
Descriptions
G1118P-16-250W is a unmanaged PoE switch independently designed by IP-COM. Compliant
with IEEE 802.3af and IEEE 802.3at standards, it can identify PoE-powered devices intelligently. With a maximum PoE power output of 230 W, and 30 W for a single port, it can supply
power when transmitting data with APs, IP cameras, and IP phones. The switch supports 4
working modes, including standard, priority, extend and VLAN modes, is an ideal choice for
SMBs, hotels, schools, factories with video surveillance and wireless networking requirements.
G1118P-16-250W 16GE+2SFP Ethernet Unmanaged Switch With 16-Port PoE
01
Page 3
Features
www.ip-com.com.cn
Compliant with IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x and
*
IEEE802.3af/at standards.
16 * 100/1000 Mbps Base-T RJ45 ports for data transmission and power supply,
*
2 * 1000 Mbps Base-X SFP slots.
8K MAC address table and MAC address auto-learning.
*
IEEE 802.3x-compliant full-duplex flow control and half-duplex backpressure flow control.
*
36Gbps backplane bandwidth.
*
Maximum power consumption of a single port: 30W; Maximum power consumption of the
*
switch: 250W.
*
4 modes: standard, priority, extend and VLAN.
Rack mounting.
*
USPs
6kV lightning protection
The switch offers various safety and protection types, including 6kV
lightning protection, PSE short-circuit protection, PoE overload protection, surge current protection etc.
Gigabit uplink port
With two 1000 Mbps SFP slots, the switch can meet the current
demand for uplink bandwidth of Gigabit WLAN and HD digital
surveillance.
230 W PoE power supply
The switch features 16 IEEE 802.3at/af-compliant RJ45 ports. The entire
switch offers a maximum PoE power output of 230W, and 30W for a
single port, to supply power to and data transmission with 16 PoE-powered devices such as APs and IP cameras.
One-key to switch 4 modes
It supports 4 working modes, including standard, priority, extend and
VLAN modes. The hardware DIP mode switch makes networking straightforward and effortless.
02 G1118P-16-250W 16GE+2SFP Ethernet Unmanaged Switch With 16-Port PoE
Page 4
Appliation
www.ip-com.com.cn
Gateway
Gateway
G1118P-16-250W
AC2000
Conference Room
W63AP W63AP
restaurant restaurant restaurant
Conference Room Conference Room
W63AP
Management Server
G5328F G5328F G5328F
G1118P-16-250W G1118P-16-250W G1118P-16-250W G1118P-16-250W G1118P-16-250W G1118P-16-250W
03 G1118P-16-250W 16GE+2SFP Ethernet Unmanaged Switch With 16-Port PoE
Page 5
www.ip-com.com.cn
Specifications
Specifications
Standards IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x, IEEE802.3af/at
16 * Link/Act LED
LEDs indicator
Interfaces
2 * SFP LED
1 * PoE-MAX LED
1 * Power LED
16 * 100/1000 Mbps Base-T RJ45 ports (Data/Power)
2* 1000 Mbps Base-X SFP port
Forwarding Rates
Switching capacity
MAC Address Table
Lightning protection
Input voltage
PoE supply
Power consumption
Dimensions
Four Modes
26.8 Mpps
36 Gbps
8K
≥6KV
AC: 100-240V~50/60Hz
Ports 1-16 support standard IEEE802.3af/at
30W output per PoE port
230W output of the total PoE Power
250W output the whole device
440*178.8*44mm
Standard: Default mode of the switch. In this mode, it works as an unmanaged switch;
all ports can communicate with each other separately.
Priority: In this mode, port 15,16,SFP1 and SFP2 serve as uplink ports, ports 1 ‒ 8 serve as high priority
port. All ports can communicate with each other separately.
Extend: In this mode, data rate of ports 9 - 14 reduces to 10 Mbps, the maximum transmission
distance can be 250 meters, and all ports can communicate with each other.
VLAN: In this mode, ports 1 - 14 of the switch can communicate with port15,16, SFP1, SFP2 separately,
but cannot communicate with each other. You can enable this mode to reduce broadcast storm and
isolate DHCP broadcast.
Environment
Certifications
G1118P-16-250W 16GE+2SFP Ethernet Unmanaged Switch With 16-Port PoE
04
Operating Temperature: 0℃~45℃ (32℉~113℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
FCC、CE、RoHS
