Page 1
F1016
16-Port Fast Ethernet Rackmount Switch
www.ip-com.com.cn
Page 2
F1016
16-Port Fast Ethernet Rackmount Switch
Products Description
www.ip-com.com.cn
F1016 provides 16 10/100Mbps autosensing ports and all
ports support Auto MDI/MDIX for parallelwire and
crosswire, making this device not only can be
connection to common terminal equipments, but also
can be cascade connection to other nerworking
equipments to extend your networking easily.F1024 can
provide you a easy, economic, high-performance
solution for 100M networking, which is your ideal chioce
for high-speed networking.
• 16 10/100Mbps RJ45 ports
• 19-inch rack-mountable, 1U steel case
• Plug and play, Without configuration
01
F1016
16-Port Fast Ethernet Rackmount Switch
Page 3
Key Feature
www.ip-com.com.cn
•
Compliant with IEEE802.3, IEEE802.3u, IEEE802.3x
•
Store & forward, share memory, non-blocking architect
•
Supports MAC address self-learning and auto MDI/MDIX
•
Provide 16 10/100Mbps auto-negotiation ports
•
Support full-deplux 802.3x flow control and half-duplux backpressure flow control
•
Supports 4K MAC address list, MAC address learning and auto-ageing
•
Built-in switching power adapter, support AC 110-240V 50/60Hz input
•
Fanless design
•
Standard 19-inch rack-mountable, 1U steel case
•
Plug and play, no need configuration
Product Features
Full wire-speed
Provide 16 10/100M auto-negotiation RJ45 ports. All ports have the
the wire-speed forwarding capability and support IEEE 802.3x
full-duplex flow control and half-duplex backpressure flow control.
Excellent Lightning-Proof design
Integrated professional lightning-proof circuit which supports
lightning-proof grade of the power is 4 (common mode protection
6KV). Excellent lightning-proof, anti-static and anti-interference
capabilities ensure the switch to operate stably even in an unstable
environment.
Quiet and Green Energy Conservation Design
Adopts low-power consumption IC Plus chipset solution. Fanless
design enables quiet and energy conservation. When no data
transmits in the port, it will automatically change into power-saving
state and utmost reduce power consumption and operating costs.
Easy to use
plug-and-play. which helps you quickly build 100Mbps wired network
and greatly simplify the management and maintenance of
equipment. It supports desktop and standard 19-inch rack mounted
installation with two pairs of rack-mounted hangers, which can be
easily installed in a standard 19-inch machine room cabinet.
02
F1016
16-Port Fast Ethernet Rackmount Switch
Page 4
Application Scenarios
100M 网线
www.ip-com.com.cn
F1016
Work Group
IP Phones
Work GroupIP Phones
03
F1016
16-Port Fast Ethernet Rackmount Switch
Page 5
www.ip-com.com.cn
Product Model
Standards&Protocols
LED
Interface
Transfer Method
Switching Capacity
Packet Forwarding Rate
Address Table
Power input
Power Consumption
Fan Quantity
Dimension（L×W×H）
Environment
Lightning Proof
Certification
F1016
Hardware Features
IEEE 802.3、IEEE 802.3u、IEEE 802.3x
16*Link/Ack ,1*Power
16*10/100Mbps RJ45 Ports
Store-and-Forward
3.2 Gbit/s
2.38Mpps
4K
AC:100～240V;50/60Hz
6W
Fanless
294mm* 178mm*44mm
Operating Temperature:：0℃～40℃
Storage Temperature：-40℃～70℃
Operating Humidity：10%～90% non-condensing
Storage Humidity：5%～90% non-condensing
Power supply>6KV
FCC、 CE、 RoHS
04
F1016
16-Port Fast Ethernet Rackmount Switch
Page 6
Headquarters
IP-COM Networks Co.,Ltd.
Tel: +86 755-27653089
Fax: +86 755-27657178
Email: [email protected]
Website: www.ip-com.com.cn
ADD: Tower E3,No1001,Zhongshanyuan Road,Nanshan District,Shenzhen,China.
C o p yrigh t 2 0 1 6 IP - C O M N e tw ork s C o ., Ltd . All Rig h ts R e s e rve d .
