Page 1
W63AP
EW12
AC2600 Tri-band Cable-Free WiFi System
AC1200 Wave 2 Gigabit Access Point
(Mini Basestation)
www.ip-com.com.cn
www.ip-com.com.cn
Page 2
www.ip-com.com.cn
EW12
AC2600 Tri-band Cable-Free WiFi System(Mini Basestation)
Product Introduction
The EW12 Series Mesh Wi-Fi with 802.11ac wave2
combined with our intelligent software innovations are
designed to deliver high-performance connectivity for
extreme high-density deployments of mobile and IoT.
The EW12 Series is designed to simultaneously
serve multiple clients and traffic types with tri-radio
(2x2 + 2x2+3x3 MIMO) boosting overall network
performance by up to 3X versus dual-band APs.
In addition to the benefits that MU-MIMO delivers,
the EW12 Series provide differentiated capabilities
which include AI-powered Wi-Fi RF optimization,
always-on connectivity, true Mesh network, and
802.11k/v/r fast roaming. EW12 also features on
independent 5GHz band for video&data backhaul.
01
EW12 AC2600 Tri-band Cable-Free WiFi System(Mini Basestation)
Page 3
Key Features
Product Features
www.ip-com.com.cn
* 2.6 Gbps maximum real-world speed
* Cable-free true mesh technology
* Tri-radio mode with two 5GHz and one 2.4GHz radio
* MU-MIMO & beamforming for enhanced multi-user efficiency
* Built-in RF optimization and QoS policy
Easy Cable-free deployment
No need to run cables, power up the satellite mesh AP and it will automatically
connect to the EW12 mesh router.
Ultra-fast 2.6Gbps Wi-Fi experience
Reliable and high performance AC2600 Wi-Fi for up to 5000 sq ft with optimized
simultaneous connections for 100 users.
Seamless roaming
EW12 uses 802.11k/v/r handover technology that allows the AP controller to
determine the best timing and target AP for the handover. In this way, users enjoy
seamless service during voice calls and video, and a greater throughput that is
double than what legacy Wi-Fi handover guarantee.
Separate Guest User Access
EW12 comes with 3 independent band with traffic isolation for network administrator, employees and customers, etc And includes a default Guest VLAN for guest
access.
02
Easy-to-use & Insight management
Thanks to mesh technology, EW12 is easy to expand Wi-Fi coverage with extra
effort by add satellite AP, it will automatically learn configuration by themself. Easy
plug and play Also EW12 support APP or cloud control for remote management.
EW12 AC2600 Tri-band Cable-Free WiFi System(Mini Basestation)
Page 4
Application Scenarios
EW12 is an AC2600 Tri-band Cable-Free WiFi System(Mini Basestation) from IP-COM specially designed for offices,
restaurants, and other places. With advanced true Mesh technology and innovative built-in antennas design, enterprise users
can adjust the quantities of EW12 according to the application area and combined with EW12 to form a distributed Mesh
network without a dead zone. EW12 supports router mode and AP mode, which can meet the requirements of a small project
with Mesh network, or partial Mesh network for large projects. The device adopts a full gigabit network interface design with
maximum support for single WAN. It integrates various enterprise functions such as intelligent bandwidth control, WEB
authentication, SMS authentication, etc., and can be applied to a variety of application scenarios.
www.ip-com.com.cn
Interent
IP-COM IMS
APP management
IP-COM IMS cloud
platform management
Cable-Free MAP
Cable-Free MAPCable-Free MAP
03
Cable-Free MAP Cable-Free MAP
EW12 AC2600 Tri-band Cable-Free WiFi System(Mini Basestation)
Page 5
Application Scenarios
www.ip-com.com.cn
Interent
IP-COM IMS
APP management
Cable-Free MAP
Router
Switch
Cable-Free MAP
IP-COM IMS cloud
platform management
Open Wired Networking
04
Cable-Free MAP Cable-Free MAP
Cable-Free sub-network 1
Cable-Free MAP Cable-Free MAP
Cable-Free sub-network 1
EW12 AC2600 Tri-band Cable-Free WiFi System(Mini Basestation)
Cable-Free MAP
Tri-band AP
Page 6
Packaging
Hardware Specification
CPU Quad-core 717Mhz
Memory 256MB
Flash 16MB
Frequency band Tri-band: 2.4G+5.2G+5.8G
Wireless rate 400+867+1300Mbps
11AC Wave 2 Support
Beamforming Support
Networking technology True Mesh
Antenna 5*4dBi, Horizontal omnidirectional antenna
www.ip-com.com.cn
1*Power Interface
Interface
1*Reset Button
2*Gigabit Ethernet Port (1*PoE WAN/LAN, 1*LAN)
Software Specification
Operating Mode Router Mode & AP Mode
WAN Ports Single WAN
Port Forwarding Support
Port Mirroring Support
UPNP Support
Security Settings Support
DDNS Support
VPN IPSec/PPTP/L2TP
Filter Management Support
Guest Network Support
Static Routing Support
Dedicated Backhaul Support
05
Bandwidth Control(QoS) Support
Diagnostic Tool Support
Fast Roaming Support
EW12 AC2600 Tri-band Cable-Free WiFi System(Mini Basestation)
Page 7
Packaging
Installation and Deployment
Mounting Wall mount/Ceiling mount/Pole mount/Desk mount
APP Installation and Configuration Support
Managed by AC Support
Management and Maitainance
APP/cloud management Support
Web local and remote management Support
Performance Parameter
Maximum number of User 100
Mesh nodes in one Mesh System Typical:5; Max:18
www.ip-com.com.cn
Maximum hop limit 3 hop
Other
Dimensions(L×W×H) 170mm*170mm*36mm
Power Dimensions
Enviorment
External switching power supply48V/0.8A
48V Passive PoE power supply
Working Temperature: 0~40°C Storage Temperature: -40~70°C
Working Humidity: 10%~90%RH Storage Temperature: 5%~90%RH
IP-COM NETWORKS CO., LTD.
Tower E3, No.1001, Zhongshanyuan Road,
Nanshan District, Shenzhen, China. 518052
Service: [email protected]
Inquiry: [email protected]
Tel: +86-755-27653089
Specications are subject to change without notice. Copyright ©2020 IP-COM Networks Co., Ltd. All Rights Reserved. IP-COM is the trademark of IP-COM Networks Co., Ltd. All other brand
names mentioned herein are the trademark or registered trademarks of their respective holders.
