Page 1
AP255v2.0
300Mbps Wireless In-wall Access Point
www.ip-com.com.cn/en
Page 2
AP255v2.0
300Mbps Wireless In-wall Access Point
Product Description
AP255v2.0 is designed to provide wi for
www.ip-com.com.cn/en
hotel rooms,villa, large apartment etc prem-
ise. Adopt of 86 Type wall mount junction
box design, it can blend into existing decora-
tion perferctly without any damage. Compli-
ant with PoE 802.3af standard enable it to be
deployed quickly. It is easy to setup, manage
and monitor with IP-COM AP controller.
01
AP255v2.0
Wireless Access Point
Page 3
Key Features
Product Features
www.ip-com.com.cn/en
* 2.4GHz 11n 300Mbps
* Two 10/100Mbps LAN ports
* Compliant with PoE 802.3af
* Vlan tagging for multi SSID
* 86 Type wall mount junction box design
* Centralized managed by AC1000/AC2000/AC3000
11n Wireless 300Mbps
AP255v2.0 adopts of 11n wireless standard and wireless rates up to 300 Mbps on the 2.4GHz
frequency band. The devices such as smart phone, laptop connect to it can enjoy smoother
video streaming and faster le.
86 Type wall mount junction box design
AP255v2.0 adpots of 86 Type wall mount junction box design to blend into the existing
decoration.It will pose no problem to neighbourhood panels or other decorations.
Compliant with PoE 802.3af
The port on the back panel support Power over Ethernet (PoE) functionality, which allows
both power and data to be carried over a single Ethernet cable to W30AP.
Advanced Wireless Security
AP255v2.0 oers multi mechanism to prevent unauthenticated acces and protect
data privacy .
1.64/128bit WEP,WPA-PSK,WPA2-PSK,WPA&WPA2-PSK,WPA,WPA2
2.Wireless Access Control based on the mac address of wireless adapter
3. Client Isolation and SSID isolation
Advanced Wireless Security
AP255v2.0 oers multi mechanism to prevent unauthenticated acces and protect
data privacy .
1.64/128bit WEP,WPA-PSK,WPA2-PSK,WPA&WPA2-PSK,WPA,WPA2
2.Wireless Access Control based on the mac address of wireless adapter
3. Client Isolation and SSID isolation
VLAN Tagging For multi SSID
AP255v2.0 can be congured to broadcast up to two SSID. Each SSID can be tagged to a
specied networkVLAN for dierent user access based on established access rights.
02
Easy to setup, Easy to manage
AP255v2.0 can be managed by AP Controller, the administrator can setup, manage and
monitor all the Aps online status more easily.
AP255v2.0
Wireless Access Point
Page 4
Application Scenarios
www.ip-com.com.cn/en
AP255v2.0 is designed to provide wi for hotel
rooms,villa, large apartment etc premise.
Adopt of 86 Type wall mount junction box
design, it can blend into existing decoration
perferctly without any damage. Compliant
with PoE 802.3af standard enable it to be
deployed quickly. It is easy to setup, manage
and monitor with IP-COM AP controller.
Internet
Poom 201
Room 203
M50
G3224P
Room 202
AP255 AP255
Room 204
AP255 AP255
Hotel Guest Room Area
Ethemet Cable
PoE Power
2.4G WiFi
AC2000
Related Products
03
AP365
AC2000
M50
* 11AC dual band 1750Mbps
* Ceiling and wall mount design
* Compliant with PoE 802.3at
* Two gigabit ethernet port
* Tagging VLAN ID for multi SSID
* 5GHz band steering
* Centralized management by AC1000/AC2000/AC3000
* Easy to congure, manage and monitor Aps
* Maximum AP managed number up to 512
* Remote manage multi branch AP and AC
* Built-in captive portal server and customerized welcome page
* Access device type and customer behavior statistic
* Maximum user capacity up to 150
* Smart QoS Bandwidth Management
* Multi WAN load balance and bandwidth combination
* PPTP,L2TP,Ipsec VPN server and client supported
* Integrated with AP controller feature to manage 16 IP-COM AP
* Built-in captive portal server and customize user connection time
03
AP255v2.0
Wireless Access Point
Page 5
Product Specications
Physical Specification
Product Info
www.ip-com.com.cn/en
Model
Deployment
Dimensions
Weight (package included)
Application Scenarios
Hardware Specications
Frequency Range
Maximum wireless speed
Interface
Button
Antennas
Maximum Power Consumption
LED indicator
Power Supply
Software Specications
AP255v2.0
In Wall
86*86*35mm
140.1g
WiFi coverage for hotel rooms,villa
2.4GHz
300Mbps
1*PoE+Data Input LAN
1*Data Output LAN
1*Reset
2dbi
3.4W
SYS
PoE 802.3af
Operating mode
Compliant Standards
Wireless Features
Wireless Security
Transmission Power
AP/Client AP
IEEE 802.11n/g/b
2 SSID
Enable/Disable Wireless Radio
SSID Hidden
Wireless Client isolation
Sensitivity Threshold
WMM Capable
APSD Capable
Wireless Access Control
Client Number Limitation For SSID
Wireless Client list
VLAN Tagging for SSID
64/128 WEP,WPA-PSK,WPA2-PSK,WPA&WPA2-PSK,WPA,WPA2
Adjustable power by 1dBm
Receiver sensitivity
DHCP Server
04
MCS0: -90dbm MCS7: -70dbm
DHCP Server &Clients list
AP255v2.0
Wireless Access Point
Page 6
Product Specications
Product Info
VPN Pass-Through PPTP,L2TP
Schedule Reboot Support
Diagnosis Tool Ping,Signal Scan
System Log
www.ip-com.com.cn/en
Management Tool
Managed By Controller AC1000,AC2000,AC3000
Firmware upgrade
Backup/Restore Conguration
Username Managerment
Working Environment
1*Wireless Access Point
Package Contents
Operating Temperature -10℃ ~ 45℃
Storage Temperature -30℃ ~ 70℃
Operating Humidity 10%~90% non-condensing
Storage Humidity 10%~90% non-condensing
Default IP
Default Login Username admin
1*GPL
2*Screws
1*Quick Installation Guide
192.168.0.254
Default Login Password admin
Certications CE/RoHS
05
AP255v2.0
Wireless Access Point
Page 7
www.ip-com.com.cn/en
IP-COM NETWORKS CO.,LTD.
Tower E3, No.1001, Zhongshanyuan Road,
Nanshan District, Shenzhen, China. 518052
Service: [email protected]
Inquiry: [email protected]
Tel: +86-755-27653089
Specications are subject to change without notice.Copyright ©2015 IP-COM Networks Co., Ltd. All Rights Reserved. IP-COM is the trademark of IP-COM TECHNOLOGY CO.,LTD. All other brand
names mentioned herein are the trademark or registered trademarks of their respective holders.
