ioSafe NAS User's Guide

Based on Synology DSM 5.0

Document ID

910-11569-00 REV01 USER GUIDE, NAS, ENG , DSM5_0

Table of Contents

Chapter 1: Introduction Chapter 2: Get Started with Synology DiskStation Manager (DSM)

Install ioSafe NAS and DSM .................................................................................................................................................. 6

Sign into DSM .......................................................................................................................................................................... 6

DiskStation Manager Desktop ............................................................................................................................................... 7

Open Applications and Packages with Main Menu ............................................................................................................ 9

Shutdown, Restart, Logout, or Manage Personal Options .............................................................................................. 10

Chapter 3: Modify System Settings

Use Control Panel ................................................................................................................................................................. 12

Change Network Settings .................................................................................................................................................... 13

Join Wireless Network .......................................................................................................................................................... 13

Modify Regional Options ...................................................................................................................................................... 14

Use Energy Saving Features .............................................................................................................................................. 15

Chapter 4: Perform Advanced Management Tasks

Check System Information ................................................................................................................................................... 16

View System Logs ................................................................................................................................................................ 17

Monitor System Resources .................................................................................................................................................. 18

Automate Tasks .................................................................................................................................................................... 18

Update DSM or Restore Defaults ....................................................................................................................................... 18

Receive Event Notifications ................................................................................................................................................. 19

Access Applications with Independent Login .................................................................................................................... 19

Index Multimedia Files for Applications .............................................................................................................................. 19

Reset Admin Password ........................................................................................................................................................ 19

Reinstall IoSafe NAS ............................................................................................................................................................ 20

Enable SNMP Service .......................................................................................................................................................... 20

Enable Terminal Services .................................................................................................................................................... 20

Chapter 5: Manage Storage Space

Volumes and Disk Groups ................................................................................................................................................... 21

Repair Volumes or Disk Groups ......................................................................................................................................... 23

Change RAID Type ............................................................................................................................................................... 23

Expand Volumes or Disk Groups ........................................................................................................................................ 24

Data Scrubbing ...................................................................................................................................................................... 25

SSD TRIM .............................................................................................................................................................................. 25

iSCSI Targets and LUNs ...................................................................................................................................................... 25

Manage Hard Disks .............................................................................................................................................................. 26

SSD Cache ............................................................................................................................................................................ 26

Hot Spare ............................................................................................................................................................................... 27

Manage External Disks ........................................................................................................................................................ 27

3 Table of Contents

Chapter 6: Access your IoSafe NAS from the Internet

Use the EZ-Internet Wizard ................................................................................................................................................. 28

Set Up Port Forwarding Rules for Router .......................................................................................................................... 29

Register DDNS for the IoSafe NAS .................................................................................................................................... 29

Access DSM Services via QuickConnect .......................................................................................................................... 30

Set up VPN Connection ....................................................................................................................................................... 31

Chapter 7: Enhance Internet Security

Prevent Unauthorized Connection with Firewall ............................................................................................................... 32

Prevent Attacks over the Internet ....................................................................................................................................... 32

Automatically Block Suspicious Login Attempts ............................................................................................................... 33

Chapter 8: Set Up File Sharing

Enable File Sharing Protocols for All Platforms ................................................................................................................ 34

Join IoSafe NAS to Directory Service ................................................................................................................................ 35

Host LDAP Service with Directory Server ......................................................................................................................... 36

Manage Users and Groups.................................................................................................................................................. 37

Set Up Shared Folders ......................................................................................................................................................... 39

Define Windows ACL Privileges for Shared Folder .......................................................................................................... 41

Index Shared Folder Contents ............................................................................................................................................ 41

Chapter 9: Access Files from Anywhere

Access Files within the Local Network ............................................................................................................................... 42

Access Files via FTP ............................................................................................................................................................ 44

Access Files via WebDAV ................................................................................................................................................... 45

Sync Files via Cloud Station ................................................................................................................................................ 45

Access Files via File Station ................................................................................................................................................ 46

Chapter 10: Back Up Data

Back Up Computer Data ...................................................................................................................................................... 49

Back up Data or iSCSI LUN on IoSafe NAS ..................................................................................................................... 51

Backup and Restore System Configurations .................................................................................................................... 51

Sync Shared Folder Contents between IoSafe NAS ....................................................................................................... 51

Back up Data on USB Device or SD Card......................................................................................................................... 51

Chapter 11: Host Websites and Print Server

Use Web Station to Host Websites .................................................................................................................................... 52

Set IoSafe NAS as Print Server .......................................................................................................................................... 53

Chapter 12: Discover Various Applications with Package Center

What Package Center Offers .............................................................................................................................................. 54

Install or Buy Packages ........................................................................................................................................................ 55

Chapter 13: Communicate with Mobile Devices

Manage DSM Settings with DSM mobile ........................................................................................................................... 56

Use iOS, Android, and Windows Apps .............................................................................................................................. 56

Use Other Mobile Devices ................................................................................................................................................... 57

Chapter

Chapter 1: Introduction

Congratulations on your purchase of IoSafe NAS powered by Synology. IoSafe NAS is a multi-functional Network-Attached Storage server, serving as a file-sharing center within your Intranet. Moreover, it is specially designed for a variety of purposes, allowing you to perform the following tasks with the web-based Synology DiskStation Manager (DSM):

Store and Share Files over the Internet

Windows users, Mac users, and Linux users can easily share files within the Intranet or through the Internet. Unicode language support makes sharing files in different languages from IoSafe NAS simple.

Manage Files with Web-Based File Station

One of Synology DiskStation Manager’s applications, File Station, can make it possible for users to manage their files on IoSafe NAS easily through a web interface. You can also access the files stored on IoSafe NAS with a mobile device.

Transfer Files via FTP

Synology DSM provides FTP service with bandwidth restriction and anonymous login. To transfer data safely, FTP over SSL/TLS and uninvited IP auto-block are also available.

Sync Files with Cloud Station

Cloud Station is a file sharing service that allows you to synchronize files between a centralized IoSafe NAS and multiple client computers, mobile and IoSafe NAS devices.

Share Storage Capacity as iSCSI LUNs

You can designate portion of your IoSafe NAS volume space to be an iSCSI LUN, which will allow the iSCSI initiator to access the space like a local disk.

Back up Files on Computer and Server

Synology DSM provides various backup solutions to back up computer data to IoSafe NAS, back up IoSafe NAS data or iSCSI LUN to an external hard drive, another IoSafe NAS, an rsync-compatible server, Amazon S3 server, HiDrive backup server, etc.

Enjoy Entertainment Content on the Server

Download Station allows you to download files from the Internet through BT, FTP, HTTP, eMule and NZB to IoSafe NAS. The Media Server and iTunes support allows computers or DMA devices within LAN to playback multimedia files on IoSafe NAS

With the USBCopy or SDCopy function, you can press the Copy button on your IoSafe NAS to instantly copy files from a camera or SD card to IoSafe NAS.2

Organize Videos with Video Station

Video Station allows you to organize your collection of movies, TV shows, and home videos into a media platform on which you can watch and play video clips, live stream and record digital TV programs with a USB DTV dongle plugged into your IoSafe NAS, view and edit video metadata whose information is retrieved automatically from the Internet. You can also stream videos to your iPhone or iPad for playback.

---------

For recommended peripheral models, including hard drive, USB printer, DMA, and UPS, please visit www.synology.com.

USBCopy or SDCopy is supported on specific models only. Visit www.synology.com for more information.

ioSafe NAS User's Guide

Based on Synology DSM 5.0

Share Photos, Videos, and Blogs with Photo Station

Photo Station gives you the freedom to share photos and videos over the Internet without complicated upload steps. Furthermore, a blogging system is integrated for you to easily share your life and thoughts over the Internet.

Enjoy Music Anytime and Anywhere

Audio Station allows you to listen to music stored on the IoSafe NAS, from a connected iPod, or even stream Internet Radio stations. In addition, you can stream music from the IoSafe NAS with a web browser over the Internet.

Host Websites

The Virtual Host feature allows you to host up to 30 websites using Web Station, with PHP and MySQL supported.

Record Videos with IP Cameras

Surveillance Station allows you to manage, view, and record videos from multiple IP cameras over the network. By accessing the web-based mana gem ent interface of Surveillance Station, you can watch the real-time image the camera is monitoring, and record videos continuously in motion-detection mode or in alar m-re cord ing mod e.

Manage Multiple IoSafe NAS Devices

Synology CMS (Central Management System) allows you to quickly and conveniently manage multiple Synology DSM based NAS servers made by both Synology and ioSafe. Once CMS is installed, you can designate your IoSafe NAS server as the CMS Host and designate other servers as managed servers. The CMS Host provides a single interface to monitor and maintain the manag ed serv er s.

Discover More Apps with Package Center

Package Center brings intuitiveness and convenience for users to easily install and upd ate a variety of applications (which are packed into packages). Just browse all available applications and select the ones that best suit your needs. All can be done with just a few clicks.

Set up Print Server

USB or network printers connected to your IoSafe NAS can be shared by client computers over the local area network. AirPrint support allows you to print to the printer from an iOS device, while Google Cloud Print support allows you to print to the printer when you are using Google products and services.

Online Resources

If you cannot find what you need here, please see DSM Help or take a look at Synology's online resource s

below.

 Knowledge Base: www.synology.com/support  Forum: forum.synology.com  Download Center: www.synology.com/support/download.php  Technical Support: myds.synology.com/support/support_form.php

---------

For recommended peripheral models, including hard drive, USB printer, DMA, and UPS, please visit www.synology.com.

Chapter

Chapter 2: Get Started with Synology’s DiskStation

Manager (DSM)

This chapter explains how to sign into Synology’s DiskStation Manager (DSM), customize your desktop, use the taskbar and widgets, and open applications and packages with the Main Menu.

Install your ioSafe NAS and DSM

For more information about setting up your ioSafe NAS and installing DSM, see the Quick Installation Guide for your ioSafe NAS model available at www.iosafe.com .

Sign into DSM

After setting up and installing DSM on your ioSafe NAS, you can sign into DSM using a web browser on your computer.

To log in with Web Assistant:

1 Make sure your computer is connected to the same network as the ioSafe NAS and can access the Internet. 2 Open a web browser on your computer and go to find.synology.com. 3 Web Assistant will f ind your ioSafe NAS within the local network. Click Connect to go to the login screen.

To log in with the server name or IP address:

1 Make sure your computer is connected to the same network as your IoSafe NAS. 2 Open a web browser on your compu t er, enter any of the following in the address field, and then press Enter on

your keyboard:

 http://IoSafe_Server_IP:5000  http://IoSafe_Server_Name:5000/ (or http://IoSafe_Server_Name.local:5000/ on a Mac)

IoSafe_Server_Name should be replaced with the name you set up for IoSafe NAS during the initial installation process. If you choose One-step Setup during the installation process, the IoSafe_Server_Name will be DiskStation, CubeStation, USBStation, or RackStation.

3 Enter your user name and password, and click Sign in. The default password for admin is empty.

Note: To ensure your connection to DSM runs smoothly, please use the following browsers.

 Chrome  Firefox  Safari: 5.0 or later  Internet Explor er: 8.0 or later

ioSafe NAS User's Guide

Based on Synology DSM 5.0

DiskStation Manager Desktop

When you sign into DSM, you will see the desktop. Fro m her e, you can start gett ing thin gs done, li ke mana ge settings, use packages, or view notifications.

Desktop

The desktop is where your application and package windows are displayed. You can also create desktop shortcuts to frequently used applications.

Taskbar

The taskbar at the top of the desktop includes the following items:

1 Show Desktop: Minimize all open application and package windows. 2 Main Menu: View and open applications and packages installed on your IoSafe NAS. You can also click and

drag to create desktop shortcuts.

3 Open applications:

 Click the icon of an application to show or hide its window on the desktop.  Right-click the icon and choose from the shortcut menu to manage the application window (Maximize,

Minimize, Restore, Close) or its taskbar icon (Pin to Taskbar, Unpin from Taskbar).

ioSafe NAS User's Guide

Based on Synology DSM 5.0

4 Upload Queue: Appears when you start uploading files to the IoSafe NAS. Click to see more details, like

progress and upload speed.

5 Notifications: Displays notifications, like errors, status updates, and package installation notifications. 6 Options: Shutdown, restart, logout, or modify personal account options. 7 Search: Quickly find specific applications, packages, or DSM Help articles here. 8 Widgets: Show or hide widgets. 9 Pilot View: See a preview of all open application and package windows.

Widgets

Widgets display various types of system information related to your IoSafe NAS.

To open/close the widget panel:

Click Widgets to show or hide the widgets panel. Click the + to select which widgets to display. You can choose from the following:

 Current Users: See a list of users who are currently accessing IoSafe NAS resources.  File Change Log: View the file change log records of IoSafe NAS services.

 No active logs: Appears when none of the logs (Samba, WebDAV, FTP, File Station) is enabled.

 No logs available: Appears when any one of the logs (Samba, WebDAV, FTP, File Station) is enabled.  Recent Logs: View the log records of IoSafe NAS services.  Resource Monitor: Monitor the CPU usage, memory usage, and network flow.  Scheduled Backup: View the status of your backup tasks.  Scheduled Tasks: View a list of upcoming tasks.  Storage: View the volume usage and disk status of your IoSafe NAS.  System Health: Obtain an overall status of your IoSafe NAS and all connected devices (if any). You will be

advised to take corrective action when system error occurs.

ioSafe NAS User's Guide

Based on Synology DSM 5.0

Open Applications and Packages with Main Menu

The Main Menu (the button at the top-left of the desktop) is where you can find all the applications and packages installed on your IoSafe NAS.

To open applications or packages:

Open Main Menu and click the icon of the application or package that you want to open.

To reorder icons:

Open Main Menu and drag an icon to any position you want.

To create a desktop shortcut:

Open Main Menu and drag an icon to the side.

ioSafe NAS User's Guide

Based on Synology DSM 5.0

Shutdown, Restart, Logout, or Manage Personal Options

Click the Options menu (the person-shaped icon at the top right) to shutdown, restart, logout, or manage your user account settings

To manage personal options:

Select Options from the drop-down menu to manage personal account options, like password, 2-step verification, desktop, etc.

ioSafe NAS User's Guide

Based on Synology DSM 5.0

Account

Under Account, you can edit your account settings, enable 2-step verification, and view recent login activity of your DSM account.

Limitations:

 The user description is case sensitive and can be 0 to 64 dis playable Unicode characters.  The password is case sensiti ve and should be 0 to 127 displayable characters, including letters , numbers, signs,

and space.

2-Step Verification

2-step verification provides improved security for your DSM account. If 2-step verification is enabled, you will need to enter your password in addition to a one-time verification code when logging into DSM. Verification codes are obtained from authenticator apps installed on your mobile device. Therefore, if someone wants to access your account, he will not only need your username and password, but also your mobile device.

Requirements:

2-step verificati on requires a mobile device and an authenticator app which supports the Time-based One-Time Password (TOTP) protocol. Authenticator apps include Google Authenticator (Android/iPhone/BlackBerry) or Authenticator (Windows Phone).

Account Activity

Account activity displays recent login activity of your DSM account, such as the time your account was accessed or from what IP address.

Volume Usage

Under Volume Usage, you can view your quota on all IoSafe NAS volumes set by DSM administrators, as well as the amount of capacity you have used on each volume.

Desktop

Under Desktop, you can customize the appearance of your desktop by changing the background and text color of the desktop, or uploading images to be used as the desktop wallpaper.

Photo Station

This tab is viewable only when users belonging to the administrators group enable Personal Photo Station service in Photo Station. IoSafe NAS provides the home/photo folder for you to store photos and videos that you want to share. The system will create index thumbnails of the photos and videos automatically, and then people can view photo albums via a web browser.

Social Network

You can sign into a social network account (e.g. Facebook, Google+) and take advantage of more features, such as creating file sharing links in File Station that will be accessible to select social network friends only.

Others

Under Others, you can customize other personal options. For more information about personal options, please see DSM Help.

Chapter

Chapter 3: Modify System Settings

After you have connected to Synology DiskStation Manager (DSM) and learned how to access its functions and customize its appearance, users belonging to the administrators group can begin to modify basic settings.

This chapter explains the basics of modifying network settings, display languages, time, and energy saving features. For more detailed instructions, please see DSM Help.

Use Control Panel

Choose Control Panel from the Main Menu to configure DSM settings.

The DSM settings on the Control Panel are grouped into the following categories:

 File Sharing: Manage file sharing options to host your files and share with other people easily.  Connectivity: Make your IoSafe NAS accessible over the Internet, and protect it with security mechanisms

such as firewall and auto block.

 System: Manage system settings for your IoSafe NAS devic e.  Applications: Manage general settings related to Synology-designed applications.

Note: Control Panel is accessible only t o users belonging to the administrators group. See "Create Groups" for

more information.

ioSafe NAS User's Guide

Based on Synology DSM 5.0

Change Network Settings

Go to Control Panel > Network to configure network settings and connect your IoSafe NAS device to the Internet. You can also manage traffic control rules to adjust the outgoing traffic allowed when clients access services on your IoSafe NAS. For more detailed instructions, please see DSM Help.

General

The General tab provides options to edit the name and default gateway of the IoSafe NAS, as well as configure domain name server, proxy server settings and IPv6 tunneling.

Network Interface

The Network Interface tab provides options to manage the network interfaces with which your IoSafe NAS connects to the network.

Traffic Control

Traffic control aims to control the outgoing traffic of services running on IoSafe NAS. Click Create to create traffic control rules.

DSM Settings

Change the port number for accessing DSM or configure HTTPS settings. When the HTTPS connection function is enabled, any connection to IoSafe NAS via the HTTPS protocol will be encrypted with the SSL/TLS encrypting mechanism.

Join Wireless Network1

At Control Panel > Wireless, you can connect your IoSafe NAS device to a wireless network, or create a wireless hotspot to share its Internet connection with other devices wirelessly. Also, you can manage Bluetooth adapters and connect Bluetooth devices to your IoSafe NAS. For more detailed instruc t ion s, please see DSM

Help.

---------

Supported on specific models only.

ioSafe NAS User's Guide

Based on Synology DSM 5.0

Modify Regional Options

Go to Control Panel > Regional Options to configure the following regional options. For more detaile d instructions, please see DSM Help.

Time

Click the Time tab to set up the system time settings of the IoSafe NAS. You can check the current time, manually set the server's date and time, or automatically set the time using a network time ser v er.

Language

Click the Language tab to set the language for Synology DiskStation Manager, notification s, and specify the codepage for Unicode filename conversion.

 Display Language: Choose your preferred display language, or have it the same as your default browser

setting.  Notification Language: Set your preferred language for email and instant me ssagin g notifications from IoSafe

NAS.  Codepage: IoSafe NAS uses Unicode to avoid file inaccessibility from computers using different languages.

But for the following devices or applications to use IoSafe NAS services without problem, you need to choose

the appropriate codepage for them:

 Computers without Unicode support

 Applications that convert non-Unicode strings to Unicode, such as FTP service, UPnP support, music

metadata indexing

NTP Service

Click the NTP Service tab to have your IoSafe NAS serve as a network time server to synchronize time between different network devices and the IoSafe NAS over network.

Note: The NTP service is required for Sur veillance Station and Synology High Availability. Therefore, if you have

Surveillance Station installed and r un on your IoSafe NAS, the service cannot be dis abled while the package i s running.

ioSafe NAS User's Guide

Based on Synology DSM 5.0

Use Energy Saving Features

Go to Control Panel > Hardware & Power to manage the following energy saving features provided by DSM. For more detailed instructions, please see DSM Help.

General

Click the General tab to enable power recovery, Wake on LAN (WOL) and Memory Compression. You can also modify beep control and fan speed mode here.

Power Schedule

Click the Power Schedule tab to start up or shut down automatically at a specified time.

HDD Hibernation

Click the HDD Hibernation tab to manage disk hibernation for all internal or external disks on your IoSafe NAS. When a disk enters HDD hibernation mode, it will stop spinning and become inactive, which not only saves

energy but also extends the disk's lifespan.

UPS

Under the UPS tab, you can modify UPS-related settings. UPS (Uninterruptible Power Supply) is a backup power device that allows the IoSafe NAS to continue operating for a short time if power failure occurs. This function helps prevent data loss by giving the IoSafe NAS enough time to save data and unmount volumes before losing power and shutting off. IoSafe NAS supports connecting to local or SNMP UPS devices.

Chapter

Chapter 4: Perform Advanced Management Tasks

Synology DiskStation Manager comes with a variety of management functions, allowing you to check system information, monitor system resour ces , manage notification services, restore or upgrade DSM, access applications with independent login, index multimedia files for applications a nd more.

This chapter explains how to comprehend advanced management functions to make sure your IoSafe NAS is providing the best performance. For detailed instructions, ple ase see DSM Help.

Check System Information

Info Center provides an overview of the status of the IoSafe NAS and other connected devices. Go to Control

Panel > Info Center to check the below information. For more detailed instructions, please see DSM Help.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

General

Under the General tab, you can see the basic information about your IoSafe NAS, including serial number, model name, amount of physical memory, DSM version, time information, thermal status, and external devices.

Network

Under the Network tab, you can view the status of network configuration and network interfaces.

Storage

Under the Storage tab, you can check the free or used space of your IoSafe NAS volumes and check the status of the hard disks.

Service

Under the Service tab, you can see the list of DSM services, which can be enabled or disabled by clicking

Enable or Disable under the Action column. The checkmarks under the Status column indicate whether the

services are enabled.

Report1

Under the Report tab, you can collect data and generate reports that provide information about disk usage trends. You can select report types, set a schedule to receive periodic storage reports or generate reports on demand. For more detailed instructions, please see DSM Help.

View System Logs

Log Center is a centralized log management application that allows you to view and manage log records of

IoSafe NAS services easily and efficiently. For detailed instructions, please see DSM Help.

---------

Only available on specific models.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Monitor System Resources

Resource Monitor allows you to monitor the CPU usage, memory usage, disk utilization and network flow. You

can choose to monitor in real time or view previous data. For more detailed instructions, please see DSM Help.

Automate Tasks

Go to Control Panel > Task Scheduler to schedule and run services or scripts at pre-defined times. You can create and manage tasks to automatically run user-defined scripts, empty shared folder recycle bins, or start and stop certain services. For more detailed instru cti on s, plea se see DSM Help.

Update DSM or Restore Defaults

At Control Panel > Update & Restore, you can update DSM to a newer version, back up and restore system configurations or restore IoSafe NAS device to its original manufacturer set t ing s.

Important: The data saved on the IoSafe NAS will not be erased during the updating process. However, for s ecurity

reason, we recommend t hat you back up the dat a first.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Receive Event Notifications

At Control Panel > Notification, you can set your IoSafe NAS to send notifications when specific events or errors occur, notifying you via email, SMS, mobile devices, Skype, or Windows Live Messenger. For more detailed instructions, please see DSM Help.

Access Applications with Independent Login

With Application Portal, you can configure the connection settings of various applications, allowing you to access and run these applications in independent browser tabs or windows. To enable Application Portal, go to Control

Panel > Application Portal.

Customized Alias

Applications can be opened in an independent browser window at [http(s)://DSM server address:DSM server port number [HTTP(S)]/alias name/] once the portal alias is set up.

Customized HTTP(S) Ports

Applications can be opened in an independent browser window at [http(s)://DSM server address:customized port number] once the HTTP(S) port is set up.

Index Multimedia Files for Applications

Go to Control Panel > Media Library to automatically scan multimedia files, such as photos, music, and videos stored on your IoSafe NAS, and compile them into a multimedia library to be used by multimedia applications. For more detailed instructions, please see DSM Help.

Reset Admin Password

If you forgot the password for admin and are therefore unable to log in to DSM, you can reset the password to blank and set a new password.

To reset admin's password:

Press and hold the RESET button on the back panel of your IoSafe NAS for 4 seconds until you heard a beep sound.

Note: Other than resetting administrator's password, using the RESET button will also restore the IP and DNS of

IoSafe NAS to the default value.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Reinstall IoSafe NAS

If you want to reinstall your IoSafe NAS without losing its data, you can use the RESET button on the back panel.

To reinstall IoSafe NAS:

1 Press and hold the RESET button for about 4 seconds until the IoSafe NAS emits a beep sound. 2 Within the next 10 seconds, press and hold RESET button for about 4 seconds until the IoSafe NAS emits a

beep sound. 3 Follow the installation instructions in the Quick Installation Guide for your model available at IoSafe’s Support

Section to set up the ioSafe NAS.

Important: The data saved on the IoSafe NAS wil l not be erased during the r einstallation. How ever, for security

reason, we strongl y recommend that you back up the data first .

Enable SNMP Service

Go to Control Panel > Terminal & SNMP to enable SNMP service, which allows users to monitor IoSafe NAS network flow with the network management software.

Enable Terminal Services

Go to Control Panel > Terminal & SNMP to enable Terminal service, which allows you to use Telnet or SSH to log in to IoSafe NAS and modify its settings.

Important: Use the Term inal service with caution. Improper mani pulation or modific ation to IoSafe NAS may result in

system malfunc ti on or data loss.

Chapter

Chapter 5: Manage Storage Space

Before taking advantage of the various features of your IoSafe NAS, you need to set up at least one storage space. This chapter explains how Storage Manager can help you manage storage spaces, such as volumes, Disk Groups, iSCSI Targets, or iSCSI LUNs, as well as view the status of hard drives. For more deta ile d instructions, please see DSM Help.

Volumes and Disk Groups

Volumes are the basic storage spaces on your IoSafe NAS. Before you start storing or ser v ing any data, you will need to create at least one volume. With DSM’s Storage Manager, volumes can be created with various options, such as different RAID types or customized capacity allocation. For detailed instructi ons, ple ase see DSM Help.

Create Volumes

To create a volume, go to Storage Manager > Volume and click Create. This action launches a setup wizard which helps create a volume based on your individual needs.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Quick or Custom Volumes

When creating a new volume, the following options are available:

Method

Features

Quick

Creates an SHR (Synology Hybrid RAID) volume. Automatically optimizes volume capacity and performance based on member hard disks. Recommended for saving time and simplifying storage management.

Custom

Supports different RAID types. Supports creating single or multiple volumes on Disk Groups. Provides options to allocate specific amounts of capacity for each volume (only when creating

multiple volumes on RAID) Recommended for users who want to precisely control storage management on your IoSafe

NAS.

Single or Multiple Volumes on RAID

When creating a custom volume, the following options are available:

Option

Feature

Single Volume on RAID

Uses all of the available capacity of the selected disks to create a single volume. Provides better speed and performance. Supports different RAID types.

Multiple Volumes on

RAID

Allows you to create multiple volumes on a Disk Group. Supports allocating specific amounts of capacity to each volume. Provides greater storage management flexibility. Supports different RAID types.

RAID Types

Depending on your model and number of installed hard disks, the below RAID types can be implemented when creating custom volumes or Disk Groups.

RAID Type HDD #

Allowed

Failed HDD #

Description Capacity

SHR1

1 0

A Synology Hybrid RAID volume optimizes storage capacity and performance when combining hard drives of different sizes. SHR volumes consisting of two or three hard disks provide 1-disk fault tolerance, while SHR volumes consisting of four or more hard disks can provide 1- or 2-disk fault tolerance.

1 x (HDD size)

2-3 1

Optimized by the

system

≧

4 1-2

Basic 1 0

A Basic volume is created with one hard drive as an independent unit. When creating a Basic volume, you can select only one hard drive at a time.

1 x (HDD size)

JBOD

≧

2 0

JBOD is a collection of hard drives.

Sum of all HDD

sizes

RAID 0 ≧ 2 0

Combining multiple disks to build a storage space, RAID 0 offers Striping, a process of dividing data into blocks and spreading the data blocks across several hard drives, but without safety measures.

(HDD #) x

(Smallest HDD

size)

---------

RAID types except for Basic are supported on specific models only. Visit www.synology.com for more information.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

RAID Type HDD #

Allowed

Failed HDD #

Description Capacity

RAID 1 2-4 (HDD #) - 1

The system will write identical data to each hard drive at the same time, so data integrity is protected when at least one disk is normal.

Smallest HDD

size

RAID 5 ≧ 3 1

This configuration includes a backup option. It uses parity mode to store redundant data on space equal to the size of one disk for later data recovery.

(HDD # – 1) x

(Smallest HDD

size)

RAID 5+Spare ≧ 4 2

A RAID 5+Spare storage space requires at least four drives, one of which will act as a hot spare drive to rebuild the failed drive of the volume automatically.

(HDD # – 2) x

(Smallest HDD

size)

RAID 6

≧

4 2

RAID 6 provides extra data protect i on. It uses parity mode to store redundant data on space equal to the size of two disks for later data recovery.

(HDD # – 2) x

(Smallest HDD

size)

RAID 10

≧

(even

number)

1 HDD within each RAID 1

group

RAID 10 has the performance of RAID 0 and data protection level of RAID 1. RAID 10 combines two hard drives into a RAID 1 group, and combines all the groups with RAID 0.

(HDD # / 2) x

(Smallest HDD

size)

Create Disk Groups

As stated above, creating Disk Groups provides more flexibility when managing storage spaces. Disk Groups can be created within the volume creation setup wizard, or you can go to Storage Manager > Disk Group and click

Create.

Repair Volumes or Disk Groups

The repair function is available for RAID 1, RAID 10, RAID 5, RAID 5+Spare, RAID 6, and SHR volumes or Disk Groups. Depending on your RAID types, when one of the hard drives in the volume or Disk Group fails, it will be in the degraded mode. You can repair the volume or Disk Group by replacing the crashed disk(s) to keep the data on the volume or Disk Group protected. For more detailed instructions, please see DSM Help.

Change RAID Type

The RAID types of existing volumes and Disk Groups can be changed without losing existing data, allowing you to easily and economically manage storage capacity. For example, you can create a RAID 1 volume on your IoSafe NAS, and later change to RAID 5 if you install more hard disks.

The sections below provide basic information regarding changing RAID types. For more detailed instructions, please see DSM Help.

Supported RAID Types

RAID types can be changed as follows.

RAID Type

Can be changed to...

Basic RAID 1, RAID 5, RAID 5+Spare RAID 1 RAID 5, RAID 5+Spare RAID 5 RAID 5+Spare, RAID 6 Add mirror disk to RAID 1 RAID 1

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Hard Disk Requirements

In order to change the RAID type of a volume or Disk Group, there must be a sufficient number of available hard disks installed in your IoSafe NAS. Please see below for the minimum number of hard disks required for each RAID type.

RAID Type

Minimum Hard Disks

RAID 1 2 or 4 RAID 5 3 RAID 5+Spare 4 RAID 6 4

Expand Volumes or Disk Groups

The storage capacity of volumes or Disk Groups can be gradually expanded by installing more or larger hard disks. This feature allows you to expand the capacity of your volume or Disk Group according to your budget and with no need to worry about losing any existing data.

The sections below provide basic information regarding expanding volumes and Disk Groups. For more detailed instructions, please see DSM Help.

Expand a Volume by Changing Volume Size

When creating multiple volumes on RAID, specified amounts of Disk Group storage capacity can be allocated to each volume. If you want to change the amount of allocated storage capacity for a volume, please select the volume and click Edit.

Expand a Volume or Disk Group by Replacing Hard Disks

For SHR, RAID 1, RAID 5, RAID 5+Spare, or RAID 6, the storage capacity of volumes and Disk Groups can be expanded by replacing smaller hard disks with larger ones. When expanding storage capacity with this method, please be careful to replace each hard disk one-by-one. After replacing one hard disk, the volume or Disk Group must be repaired before the next hard disk is replaced. For more detailed instructions, please see DSM Help.

Please see the following table to see which hard disk should be replaced first.

RAID Type

Minimum Hard Disk Size

RAID 5 and RAID 6

When replacing hard disks of RAID 5 or RAID 6 volumes or Disk Groups, the smallest hard disk should always be replaced first. The storage capacity of RAID 5 volumes is (number of hard disks – 1) x (smallest hard disk size), and RAID 6 is (number of hard disks – 2) x (smallest hard disk size). Therefore, the smallest hard disk should always be replaced first in order to maximize hard disk usage.

SHR (Synology Hybrid RAID)

If the capacity of all member hard disks is equal, then you should replace at least two hard disks. Otherwise, the capacity of your volume will not expand.

If the capacity of member hard disks is different, then the new, replacement hard disks should be equal to or larger than the largest existing hard disk. In addition, you should replace smaller member hard disks first in order to optimize capacity usage.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Expand a Volume or Disk Group by Adding Disks

For SHR, JBOD, RAID 5, RAID 5+Spare, and RAID 6, the storage capacity of volumes and Disk Groups can be expanded by adding more hard disks if there are empty hard drive bays in your IoSafe NAS. For more detailed instructions, please see DSM Help.

Please see the following table regarding the minimum size of new hard disks.

RAID Type

Minimum Hard Disk Size

SHR

The capacity of the hard disk you wish to add must be equal to or larger than the largest hard disk in the volume or Disk Group. For example, if your volume is composed of three hard disks – 2 TB, 1.5 TB, and 1 TB respectively – then the capacity of the new hard disk must be at least 2 TB.

RAID 5, RAID 5+Spare, or RAID 6

The capacity of the hard disk you wish to add must be equal to or larger than the smallest hard disk in the volume or Disk Group. For example, if your volume is composed of three hard disks – 2 TB, 1.5 TB, and 1 TB respectively – then the capacity of the new hard disk must be at least 1 TB.

Data Scrubbing

Data scrubbing is a data maintenance function that inspects volumes or Disk Groups and repairs any detected data inconsistencies. This function can be used with volumes or Disk Groups that implement SHR (comprised of three or more disks), RAID 5, or RAID 6.

We recommend regularly performing data scrubbing in order to maintain data consistency and avoid losing any critical data in the event of disk failure. For detailed instructions, please see DSM Help.

SSD TRIM

If a volume consists entirely of SSDs (Solid State Drives), we recommend enabling SSD TRIM. This feature optimizes the read and write performance of volumes created on SSDs, increasing efficiency as well as extending the lifetime of your SSD s.

Before trying to set up SSD TRIM, please see DSM Help for detailed instructions and more limitations.

Note:

 SSD TRIM is only available on certain IoSafe NAS models and RAID types.  Some SSD models are not able to perform SSD TRIM on RAID 5 and RAID 6 volumes. Please refer to the

compatibility list at www.ioSafe.com.

iSCSI Targets and LUNs

iSCSI (Internet Small Computer System Interface) is a type of storage area networking (SAN) service that provides access to consolidated, block level data storage. The main use of iSCSI is to facilitate data transfers over intranets, allowing users to manage storage over long distances.

The sections below provide basic information regarding iSCSI Targets and LUNs. For mor e detai led in stru ctio ns, please see DSM Help.

Manage iSCSI Targets

Go to Storage Manager and clic k the iSCSI Target tab to manage iSCSI Targets on your IoSafe NAS. The maximum number of iSCSI Targets varies depending on the model. For more information, please refer to “Manage iSCSI LUNs”.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Manage iSCSI LUNs

An iSCSI LUN (logical unit number) represents an individually addressable portion of an iSCSI Target. An iSCSI LUN can be mapped to multiple iSCSI Targets to perform storage operations such as read or write.

Go to Storage Manager and clic k the iSCSI LUN tab to manage iSCSI LUNs on your IoSafe NAS. The maximum number of iSCSI LUNS varies depending on the model. For detailed product specifications, please refer to www.ioSafe.com.

Clone iSCSI LUNs

LUN Clone1 allows you to create near-instantaneous virtual copies of a LUN. It means much higher productivity and less complex deployment during system-wide operations. LUN Clone also consumes only a fraction of storage at the time of creation.

Go to Storage Manager and clic k the Clone button to make a writable copy of an iSCSI LUN or an iSCSI LUN snapshot

Take iSCSI LUN Snapshots

LUN Snapshot1 allows you to create up to 256 snapshots per LUN using point-in-time technology without having any impact to system performance. It is efficient for your valuable storage space and also increases the level of protection, letting you easily recover valuable data.

Go to Storage Manager and click the Snapshot button to take iSCSI LUN snapshots.

Manage Hard Disks

The HDD/SSD tab allows you to monitor the status of the hard disks installed in your IoSafe NAS, providing options to manage and analyze hard disk performance and health. To see this tab, go to Storage Manager and click HDD/SSD. For more detailed instructions, please see DSM Help.

Enabling Write Cache Support

Enabling write cache support enhances the perf orm anc e of your IoSafe NAS. Only certain hard disk models support this feature. To ensure data protection while using write cache support, usage of a UPS device is strongly recommended. We also suggest the system be shut down properly every time after use. Disabling write cache will reduce the chances of data loss caused by abnormal power outages, but system performance will decline.

Running S.M.A.R.T. Tests

Disk S.M.A.R.T. tests examine and report the status of your hard disk, alerting you to possible disk failures. We recommended promptly changing your disk if any errors are detected. S.M.A.R.T. tests can also be scheduled to run automatically by creating tasks.

Checking Disk Info

The Disk Info section displays a hard disk's model name, serial number, firmware version, and total size.

SSD Cache

SSD cache2 drives can be installed and mounted in a RAID 0 configuration to boost the read speed of a volume, including iSCSI LUN (Regular Files) on a volume, or iSCSI LUN (Block-Level) on your IoSafe server. You can mount, check SSD compatibility, and view related information by going to Storage Manager > SSD Cache.

Please refer to your IoSafe server Quick Installation Guide for information regarding SSD installation. For more detailed information regar din g S SD management, ple ase see DSM Help or Synology SSD Cache White Paper.

---------

LUN Clone and Snapshot are only available on specific models.

SSD cache is supported on specific models only. Visit www.synology.com for more information

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Hot Spare

Hot spare1 disks are standby hard disks that can repair a degraded volume/Disk Group/iSCSI LUN by automatically replacing a failed disk. Hot spare disks can be globally assigned to protect any volume/Disk Group/iSCSI LUN within your IoSafe NAS, as long as the volume/Disk Group/iSCSI LUN matches the following criteria:

 The RAID type of the volume/Disk Group/iSCSI LUN must be one with data protection (i.e. RAID 1, RAID 5,

RAID 6, RAID 10).  The hot spare disk size must be equal to or larger than the size of the smallest disk in the volume/Disk

Group/iSCSI LUN.

Managing Hot Spares

Go to Storage Manager > Hot Spare > Manage to assign and manage hot spare disks. For more detailed information, please see DSM Help.

Manage External Disks

External USB or eSATA disks can be attached to the USB or eSATA port of your IoSafe NAS for backup or file sharing purposes.

Go to Control Panel > External Devices to manage attached external disks or setup printers. The External

Devices tab provides options to view device information, change formats, or eject the device. The Printer tab

provides options to setup USB or network printers. For more detailed instructions, please see DSM Help.

---------

The hot spare feature is available on specific models only.

eSATA is supported on specific models only. Visit www.synology.com for more information.

Chapter

Chapter 6: Access your IoSafe NAS from the

Internet

You can connect to your IoSafe NAS over the Internet, allowing its services to be accessible from anywhere and anytime.

This chapter explains the basics regarding us ing the Synology EZ-Internet wizard, advanced port forwarding functions, and DDNS hostname registration to connect your IoSafe NAS to the Internet. For more detailed instructions, please see DSM Help.

Use the EZ-Internet Wizard

The EZ-Internet Wizard can set up access via the Internet with an easy-to-use wizard, without going through the complicated firewall settings, PPPoE setup, DDNS registration, and router port forwarding configuration.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Set Up Port Forwarding Rules for Router

If your IoSafe NAS is within the local network, you can set up port forwarding rules for the router to allow your IoSafe NAS to be accessible over the Internet.

Note: Before you start, make sure you have manually assigned a static IP address for your IoSafe NAS. See

"Network Interf ace" for more informat ion.

Go to Control Panel > External Access > Router Configuration to set up your router and port forwarding rules. For more detailed instructions, please see DSM Help.

Note: To configure port forwarding rul es and assign static IP address, you must have the administrative permission

to the router.

Set up Router

Before adding port forwarding rules with DSM, you need to set up IoSafe NAS device’s connection to the router. To begin, please click the Set up router button.

Add Port Forwarding Rules

Add port forwarding rules to specify the destination ports of your IoSafe NAS that will receive packages from specific router ports. Click Create to start creating port forwarding rules.

DDNS (Dynamic Domain Name Service) simplifies connecting to your IoSafe NAS over the Internet by mapping a hostname to its IP address. For example, DDNS allows you to access your IoSafe NAS using a domain name (e.g. www.john.synology.me), with no need to remember an IP address (e.g. 172.16.254.1).

Service Requirement

 The servers of the DDNS service provider are working normally.

 The IoSafe NAS is able to connect to the Internet.  DDNS will only run in a network environment where there is no proxy server required.  You can only enter one hostname for each DDNS provider.

Go to Control Panel > External Access > DDNS. You can point an existing hostname at the IP address of your IoSafe NAS, or register for a new one provided by Synology or several other DDNS providers. Please consult each provider for more details regarding hostname registration.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Access DSM Services via QuickConnect

QuickConnect is a solution that helps client applications (such as DS file, Cloud Station, DS audio, etc.) connect to your IoSafe NAS via the Internet without setting up port forwarding rules. Go to Control Panel >

QuickConnect to manage the QuickConnect serv ic e. For more details regarding QuickConnect, please see DSM Help.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Set up VPN Connection

VPN Server is an add-on package that enables your IoSafe NAS to become a PPTP, OpenVPN, or L2TP/IPSec

VPN (virtual private network) server, allowing DSM local users over the Internet to access resources shared within local area network of the IoSafe NAS.

Set up your IoSafe NAS as a VPN Server

To install VPN Server on your IoSafe NAS, go to Package Center. For more information about VPN Server, run and launch the package, and then click on the DSM Help button (with a question mark) at the top-right corner.

Connect your IoSafe NAS to a VPN Server

Go to Control Panel > Network > Network Interface to set your IoSafe NAS as a VPN client to connect to a VPN server, and then gain access to the virtual private network. For each VPN server, you can create or modify its connection profile, and then use the profile to connect to the server with a simple click.

Note: Your IoSafe NAS cannot be set as a VPN server and client at the same time.

Chapter

Chapter 7: Enhance Internet Security

After your IoSafe NAS is available on the Internet, you will need to safeguard it against any attacks from Internet hackers.

This chapter explains how to set up firewall, enable DoS protection and enable auto block. For more detailed instructions, please see DSM Help.

Prevent Unauthorized Connection with Firewall

The built-in firewall can prevent unauthorized logins, and control which services can be accessed. In addition, you can choose to allow or deny access to certain network ports from specific IP addresses.

Go to Control Panel > Security > Firewall, and click Create to create firewall rules.

Apply Firewall Rules to Ports

In the Ports section, apply firewall rules to all ports or selected ports using one of the following options:

 All: Choose this option to apply the rule to all ports on IoSafe NAS.  Select from a list of built-in applications: Tick the system services that will be included in the rule.  Custom: Specify the type and protocol of the port, and enter the custom port number.

You can enter up to 15 ports separated with comma, or by specifying a port range.

Apply Firewall Rules to Source IP Addresses

In the Source IP section, choose to allow or deny access from a source IP addresses using one of the following options:

 All: Choose this option to apply the rule to all source IP addresses.  Single host: Choose this option to apply the rule to an IP address.  Subnet: Choose this option to apply the rule to a subnet.

Prevent Attacks over the Internet

Denial-of-service (DoS) protection helps to prevent malicious attacks over the Internet. Go to Control Panel >

Security > Protection to enable DoS protection and improve network security.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Automatically Block Suspicious Login Attempts

Auto block allows you to prevent unauthorized login. After enabling the service, an IP address will be blocked if it has too many failed login attempts. Go to Control Panel > Security > Auto Block to create and manage your block list and allow list.

Chapter

Chapter 8: Set Up File Sharing

ioSafe NAS can become the file sharing cent er within the local network or over the Internet, allowing users to access its files anytime and anywhere. For more detailed instructions, please see DSM Help.

This chapter explains how to enable the support for file sharing protocols for all platforms, create and manage users and groups, set up shared folders, and allow or deny access to the shared folders, applications or subfolders from specific users or groups.

Enable File Sharing Protocols for All Platforms

This section tells you how to allow the IoSafe NAS to support file sharing protocols for all platforms.

IoSafe NAS supports the following file sharing protocols:

 For Windows: SMB/CIFS (My Network Places), FTP, WebDAV  For Mac: SMB, FTP, AFP, WebDAV  For Linux: SMB, FTP, NFS, WebDAV

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Join IoSafe NAS to Directory Service

Go to Control Panel > Directory Service to join your IoSafe NAS to a directory service as a Windows domain or LDAP client. When the IoSafe NAS is joined to a directory service, you can manage domain/LDAP users' access privileges to shared folders and DSM applications and enable their home service.

Joining a Windows Domain

Click the Domain tab, and enter domain name and DNS server (optional) to join the IoSafe NAS to a Windows ADS domain. In the window that appears, enter the user name and password for the administrator of the domain server.

After IoSafe NAS joins the domain, domain users can log in to IoSafe NAS with their domain account and password.

Note:

 If your domain user name includes “%” and “$”, you might not be able to access your hom e folder. Please ask your

domain administrator to give you a new user name.

 Domain groups Domain Admins and Enterprise Admins w ill be added to the local group administrators

automatically. In other words, domain users in these groups have administrative right on the IoSafe NAS, including performing DSM/CIFS/FTP/AF P/WebDAV applications.

 You can also c onfigure domain users’ access privileges to the shared folders on IoSafe NAS. See "Allow Domain

Users or Groups to A ccess Shared Folders" for more information.

Binding to an LDAP Server

LDAP allows your IoSafe NAS to join an existing directory service as an LDAP client, and then retrieve user or group information from an LDAP server (or "director y server "). The profiles option allows you to smoothly connect to different types of LDAP servers, such as standard (Synology Directory Servers or Mac Open Directory), IBM Lotus Domino servers, or customize your own profile settings. You can manage LDAP users' or groups' access privileges to DSM applications and shared folders, just as you would with DSM local users or groups.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Host LDAP Service with Directory Server

Directory Server is an add-on package based on LDAP version 3 (RFC2251) that allows your IoSafe NAS to become an account administration center to centralize the account management of all connecting clients, and provides authentication service for them.

In addition, with Google Apps Single Sign-On support, Directory Server can become an identity provider for your Google Apps domain. This allows users to log into Google Apps services (such as Gmail or Google Calendar) using their accounts and passwords stored on Directory Server, eliminating the need for users to remember another set of accounts and passwords.

To install Directory Server on your IoSafe NAS, go to Package Center. For more information about Directory Server, please refer to DSM Help. To learn more about how to access Directory Server with a LDAP client, refer to the Directory Server User's Guide available at Synology's Download Center.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Manage Users and Groups

Go to Control Panel > User or Group to create users or groups, and allow or deny their access to different shared folders.

Create Users

Click Create to create a user account. The user can log in to edit his/her account info after the user account has been established. You can also choose to set an account expiration date or disallow the user to change account password.

Allow Self-service Password Reset

If you would like to allow users to reset forgotten passwords via email, you can click Password Settings and tick the box marked Allow non-admin users to reset forgotten passwords via email. When this option is enabled, a link marked Forgot your password? will appear on the DSM login page. If a user forgets his password, he can click this link and enter his username. In this case, the system will send a message to the user containing a link to reset his forgotten password.

For detailed instructions and notes, please see DSM Help.

Apply Password Strength Rules

You can enable password strength service to make sure DSM users’ passwords are secure enough to withstand malicious login attempts. Click Password Settings to configure this measure of the effectiveness of a password.

Note:

 Password Strength rules only work for passwords created or modified after the Password Strength service is

enabled. Existing passwords won’t be af fected by the rules.

 The rules won’t apply to the passwords of users created by im porting user lis t.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Create User's Home Folder

Each DSM user (except for guest) can have his/her own folder called the home folder, which is accessible only by the user and the system administrator. Click User Home to enable user home service.

For users belonging to the administrators group, DSM users’ home folders are here: homes/[Username]

Note:

 When the user home service is disabl ed, the homes folder will be kept but accessible by users belonging to the

administrators group only. Users can access their home folders again if the user home service is enabled again.

 To delete the homes folder, the user home service must be disabled first.

Create Domain/LDAP User’s Home Folder

If you have joined your IoSafe NAS to a directory service as a Windows domain or LDAP client, you can go to

Control Panel > Directory Service > Domain users or LDAP user to creat e domain/LDAP users' home folder.

Click User Home and tick Enable home service for domain users or Enable home service for LDAP users. Like local users, all domain/LDAP users can access their own home folder via CIFS, AFP, FTP, WebDAV, or File

Station. Users belonging t o the administrators group can access all personal folders located in the homes default shared folder. For users belonging to the administrators group, domain/LDAP users’ home folders are in the folder named @DH-domain name (for domain users) or @LH-FQDN name (for LDAP users). The name of the user's home folder is the user account plus a unique number.

Note:

 To delete the homes shared folder, user home service must be disabled first.  Enabling domain/LDAP user home service will als o enable the local user home service if it's not enabl ed yet.  The domain user home service would be disabled if the loc al user home service is disabled.

Create Groups

Go to Control Panel > Group to create and edit a group, add users to the group, and then edit the group's properties, saving you the trouble of editing users one by one.

Groups created by default include the following:

 administrators: Users belonging to the administrators group have the same administrative privilege as

admin.  users: All users belong to the users group.

Note: For more inf ormation about editi ng a group's access pr ivileges to shared folders or applicati ons, see "Allow

Users or Groups to A ccess Shared Folders" and "Allow Users t o Access Applications" for more information.

Allow Users to Access Applications

Go to Control Panel > Privileges to decide which applications could be accessed by a user.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Set Up Shared Folders

Go to Control Panel > Shared Folder to manage the shared folders, which are the root folders of IoSafe NAS. You can store data in the shared folders and share them with users or groups with access privileges.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Built-in Shared Folders Created by the System

System built-in shared folders are created when the services or applications requiring the folders are enabled.

Name

Description

public

The public folder will be created automatically after the first time you set up IoSafe NAS.1

web

The web folder contains contents of your website. It will be created automatically when Web Station is enabled.


The photo folder contains photos and videos you want to share on Photo Station. It will be created automatically when Photo Station or DLNA/UPnP Media Server is enabled.

music

The music folder contains music you want to share on Audio Station. It will be created automaticall y when Audio Station is enabled.

video

The video folder contains videos you want to browse through DLNA/UPnP DMA. It will be created automatically when Media Server is enabled.

surveillance

The surveillance folder contains Surveillance Station recordings. It will be created automatically when Surveillance Station is enabled. It is read-only and can only be accessed by the system administrator.

home

The home folder provides a private space for each user to store data where only the user can access. It will be created automatically when User Home is enabled.

homes

The homes folder contains t he home folders of all users. It will be created automatically when User Home is enabled. Only system administrator can access and manage all users' home folders.

NetBackup

The NetBackup folder is created automatically when Network Backup Service is enabled.

usbshare

The usbshare[number] folder is created automatically when you connect an USB disk to IoSafe NAS device’s USB port.

esatashare

The esatashare folder is created automatically when you connect an eSATA disk to IoSafe NAS device’s eSATA port.

Create a Shared Folder

If you are a user belonging to the administrators group, you can click Create to create shared folders and assign access privileges to the folders.

Remove a Shared Folder

If you are a user belonging to the administrators group, you can click Delete to remove any shared folder created by yourself.

Important: Removing any shared folder also removes all data within it. If you still need the data, back them up first.

Encrypt a Shared Folder

When creating a shared folder, you can choose to encrypt it.2 After a folder is encrypted, you can use the

Encryption drop-down menu to edit the folder.

The AES 256-bit encryption can block off all unauthorized access attempts. Without the encryption key, other people will not be able to use the encrypted data even if they remove the hard drives from your IoSafe NAS and mount it on their device.

Note: Tick Mount automatically on star tup to mount the encrypted folder automat ically after IoSafe NAS starts up

next time. By default, encrypted shared folder will be unmounted automaticall y on startup for securi ty reasons. If you reset default passwords with the res et button located on the IoSafe NAS, encrypted shares will be unmounted, and the option to automat ically mount will be disabled.

---------

This is applied to 1-bay models only.

Shared folder encryption is supported on specific models only.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Allow Users or Groups to Access Shared Folders

Go to Control Panel > Shared Folder, click Edit and go to Permissions to allow or deny users' or groups' access to a shared folder.

Allow Linux Clients to Access Shared Folders

Go to Control Panel > Shared Folder, click Edit and go to NFS Permissions to assign NFS permissions to any shared folder, allowing Linux clients to access it.

Allow Domain Users or Groups to Access Shared Folders

If you have joined your IoSafe NAS to a directory service as a Windows domain or LDAP client, you can go to

Control Panel > Directory Service > LDAP User, LDAP Group, Domain users, or Domain Group to set up

and modify the shared folder privileges of a domain/LDAP user or group.

Note: In the event of privilege conflicts, the privilege priority will be: No access (NA) > Read/Write (RW) > Read only

(RO).

Define Windows ACL Privileges for Shared Folder

Windows Access Cont rol List (ACL) is a list of privileges or permissions that determine s pecific ac c ess rights under the Windows environment. This can help administrator define access control rules for an individual file or a directory, and give different access rights for individual user or group. Go to Control Panel > Shared Folder and click Edit. On the Permissions tab, click Customize.

Through Windows ACL, you can assign different privileges to local and domain users in the system. The privileges apply to all file-related applications, such as FTP, File Station, NFS, AFP, WebDAV, etc.

Index Shared Folder Contents

Go to Control Panel > Shared Folder, click Edit and go to the File Indexing tab to enable file indexing. This option indexes the contents of a shared folder so you can find files or folders more quickly during file search.

Note: See "Search f or Files or Folders" for more information about searching fil es w ith File Station.

Chapter

Chapter 9: Access Files from Anywhere

When you have set up users or groups with proper access privileges to the shared folders, they can share their files with your IoSafe NAS from anywhere.

This chapter explains the ways to access the IoSafe NAS sh ared folders within the local network or over the Internet. For more detailed instructions, please see DSM Help.

Access Files within the Local Network

This section explains how to allow users to use Windows, Mac, or Linux computer to access shared folders on IoSafe NAS within the local network.

Note: Before acc essing, make sure the relative file sharing protocols have been enabled for your IoSafe NAS. See

"Enable File Sharing Protocols for All Platforms" for mor e information.

Access Shared Folders from Windows

To access shared folders from Windows, you can use any of the following methods.

Method 1: Use Synology Assistant to map the shared folders as network drives.

Run Synology Assistant (av ai l able at www.ioSafe.com/support) and select the server from the server list. Click

Map Drive and follow the onscreen steps to finish the setup.

Upon completion, you can access the mapped shared folder directly in Windows Explorer.

Method 2: Use Windows Explorer.

Open a Windows Explorer window and choose Tools > Map net work drive to show the Map Network Drive window. Choose a drive number from the Drive drop-down menu.

Locate the shared folder by doing one of the following:

 Enter \\IoSafe_Server_Name\Shared_Folder_Name in the Folder field.  Click Browse to locate the shared folder, and then click OK.

Enter your user name and password for Synology DiskStation Manager and click OK. Upon completion, you can access the mapped shared folder directly in Windows Explorer.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Access Shared Folders from Mac

Choose Go > Connect to Server from the menu bar. Type the IP address or name (appended with .local) of the IoSafe NAS preceded by smb:// or afp:// in the Server Address field and click Connect. (e.g. smb://EricaWang.local or afp://192.168.0.2)

Note: For better performance, it is recommended that you con nect to the shared fol ders via SMB.

Select the shared folder you want to access. Upon completion, you can access the shared folder in the Finder window.

Access Shared Folders from Linux

In Synology DiskStation Manager, Go to Main Menu > Control Panel > Shared Folder. Select the shared folder you want to access, click NFS Privileges, and find the mount path at the bottom of the window that appears.

On a Linux computer, enter the mount path to mount the shared folders.

Note: For more information about NFS Pri vileges, see "Allow U sers or Groups to Acc ess Shared Folders".

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Access Files via FTP

If your IoSafe NAS is accessible over the Internet, you can use a FTP application to access the shared folders.

Note: For more inf ormation about maki ng IoSafe NAS accessi ble over the Internet, see "Chapter 7: Access your

IoSafe NAS from the Internet".

Go to Control Panel > File Services > FTP to enable FTP service, allowing users to upload or download IoSafe NAS data via FTP.

Connect to IoSafe NAS Using a FTP Application

Open any FTP application on your computer and enter the following information to connect to IoSafe NAS:

 IP address or domain name of the IoSafe NAS  Your user account and password  The port number (The default number is 21)

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Access Files via WebDAV

By enabling WebDAV or CalDAV (at Control Panel > File Services > WebDAV), you can remotely manage and edit files or calendars stored on the IoSafe NAS.

Sync Files via Cloud Station

Cloud Station is a file sharing service that allows you to synchronize files between a centralized IoSafe NAS and multiple client computers, mobile and IoSafe NAS devices. Go to Package Center to install and run the Cloud Station package.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Access Files via File Station

File Station is DSM's file management tool, allowing DSM users over the Internet to access the IoSafe NAS folders with their web browsers. By launching two or more File Stations, you can manage all your IoSafe NAS data by dragging and dropping them between different File Stations.

File Station Appearance

 Left panel: Displays shared folders and their subfolders in the upper part, and the folders on your local

computer in the lower part.

 Main section: Displays contents of the currently selected folder.  Help button (top-right corner): Click the Help button (with a question mark) to reveal the DSM Help, where

you can get useful help about how to use File Station.

 Search field: Enter a keyword to filter through files or folders in the current folder.  Advanced Search (magnifying glass button): Search for refined search results.

Manage File Station Options

Click Settings to configure general settings, enable File Station log, mount remote folders or virtual drives, determine who can share file links, and set speed limit to control the bandwidth usage for DSM file transfer services.

Note:

 For more inf ormation about remote folders or virt ual drives, see "Mount Remote Folders or Virtual Drives".  For more inf ormation about shared links, see "Share Fi le Links".

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Search for Files or Folders

You can type keywords in the Filter field at the top-right corner of File Station to filter through files or folders in the current folder. Additionally, you can also perform advanced search in the Advanced Search panel for more refined search results.

Note: For quick er search result, it is recommended that you in dex shared folder contents. See "Index Shared Folder

Contents" for mor e information.

Set File Station in Action

With the Action menu, right-clicking, and dragging-and-dropping, you can easily download, upload, copy, move, rename, delete, extract, and compress files or folders, and more.

Edit the Properties of Files and Subfolders

You can edit the access privileges to files and subfolders (meaning folders and their subfolders in a shared folder), copy download links and open file in a new browser window in the Properties window. Select the files and folders for which you want to set access privileges. Right-click one of the files or folders, or choose the

Action menu, and then choose Properties.

Note:

 To set access privileges to shared folders, please see "Allow Users or Groups to Access Shared Fol ders" for more

information.

 You are not allowed to edit the access privileges to files and subfolders in the photo shared folde r here. To set

access privil eges to photo albums for Photo Station users , open Photo Station, go to the Settings page, and click the Help tab for more information.

 With File S tation, you can only per form the upload action f or files and folders on your computer. All the other File

Station actions and properties setti ng are available for files and folders on IoSafe NAS only.

Share File Links

Files or folders stored on your IoSafe NAS can be shared quickly and easily. Simply right-click a file or folder and select Share file links. This generates a link and QR code, which can be sent to friends or other users. They can follow the link to download the selected file or folder, whether or not they possess a DSM account.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Mount Remote Folders or Virtual Drives

File Station allows you to mount remote folders to access contents shared by network computers or other IoSafe NAS, or virtual drives to access contents within disc images. That way, you can easily navigate all available network resources or disc images with File Station. For more information about remote folders or virtual drives, click the Help button (with a question mark) at the top-right corner .

Edit Music Information

With File Station’s Music Information Editor, you can view or edit the information of music files. Simply right-click the music files and choose Edit music information.

View Documents, Photos, or Videos

With File Station, you can view documents, videos or photos easily. For more information, click the Help button (with a question mark) at the top-right corner.

Edit Photos

With File Station, you can edit photos with web-based editors, such as Pixlr Editor or Pixlr Express. For more information, click the Help button (with a question mark) at the top-right corner.

Chapter

Chapter 10: Back Up Data

IoSafe offers comprehensive backup solutions for your computer and IoSafe NAS, allowing you to back up data on your computer to IoSafe NAS. If you are a user belonging to the administrators group, you can also back up the IoSafe NAS data with local or network backup, or sync shared folder contents between IoSafe NAS. The creative Copy button simplifies external storage devices backup with One-touch design. The support for the Amazon S3 backup service and the innovative Time Backup package give you other choices for server backup.

This chapter explains how the various backup solutions of DSM can help protect your data. For more detailed instructions, please see DSM Help.

Back Up Computer Data

Synology-designed Data Replicator 3 allows you to back up data from a Windows computer to IoSafe NAS. If you are using a Mac or Linux, IoSafe NAS can also serve as th eir backup de stin atio n.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Use Data Replicator for Windows

The Synology Data Replicator installation package can be found at Synology's Download Center at:

http://www.synology.com/support/download.php

What Can Data Replicator Do?

 Monitor specific folders on your Windows computer and perform real-time backup when any modification to the

contents within a monitored folder is made.

 Adjust backup versions and restore points.  Restore backup data from IoSafe NAS to your Windows computer according to your preference.

Important:

 Your computer and IoSafe NAS should use the same encoding. See "Language" for m ore information.  Synology Data Replicator 3 is the next generation of Synology Data Replicator. It can only restore the data on

IoSafe NAS that was backed up after Data Replicator 3 was installed. If users have backed up data on IoSafe NAS using Synology Data Replicator, we recommend restoring data on IoSafe NAS to PC first before using Synology Data Replicator 3.

 The ioSafe NAS can be used with almos t any backup program th at can recognize a network or iSCSI drive as a

target destination. Use any suitable backup program you desire with this devic e if you have a preference.

Data Replicator Requirement:

 Free HDD Space: 5MB  Operating System: Windows 2000 or later  Best Screen Resolution: 1024 x 768 or above  Network Environment: Microsoft Networking over TCP/IP enabled and has network connection with IoSafe

NAS

To install Data Replicator:

Unzip the file downloaded from Download Center. Find and double-click the setup.exe file, then follow the onscreen instructions.

To use Data Replicator:

For detailed instructions on how to use Data Replicator, see its Help by clicking the Help button.

Use Time Machine for Mac

IoSafe NAS provides compatibility for backup with Apple Time Machine. Mac users can back up their data to the shared folder of the IoSafe NAS without problem. Go to Control Panel > File Services > Win/Mac/NFS, tick

Enable Mac file service, and choose a shared folder from the Time Machine drop-down menu. The chosen

shared folder will become Time Machine's backup destination

Note: For more inf ormation about using T ime Machine, see the help on your Mac computer.

Use rsync for Linux

You can use rsync to back up Linux data to the IoSafe NAS.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Back up Data or iSCSI LUN on IoSafe NAS

Other than backing up computer data to IoSafe NAS, users belonging to the administrators group can perform backup tasks, restore files, and sync shared folders from one IoSafe NAS device to another with Backup &

Replication. For more detailed instructions, please see DSM Help.

Backup and Restore System Configurations

Go to Control Panel > Update & Restore > Configuration Backup to back up and restore the system configurations of your IoSafe NAS. You can back up system configurations to a configuration file (.dss) and then restore the configurations at a later time.

Sync Shared Folder Contents be tw e en IoSafe NAS

Shared Folder Sync allows you to sync shared folder contents from a source IoSafe NAS (or "client") to a destination IoSafe NAS (or "server") over the network. Shared Folder Sync backup tasks can be viewed and managed by going to Backup & Replication > Shared Folder Sync. For detailed instructions regarding how to enable Shared Folder Sync, please see DSM Help.

Back up Data on USB Device or SD Card

You can go to Control Panel > External Devices to specify a shared folder for use with USBCopy or SDCopy, and then use the Copy button on the front panel of your IoSafe NAS to copy data from a USB device or SD card to the shared folder.

---------

USBCopy and SDCopy are supported on specific models only. Visit www.synology.com for more information.

Chapter

Chapter 11: Host Websites and Print Server

IoSafe NAS is designed for small and medium businesses (SMB), providing the ability to set up web and print servers on a single IoSafe NAS without spending extra money. This chapter provides basic information regarding these features. For more detailed instructions, please see DSM Help.

Use Web Station to Host Websites

Go to Control Panel > Web Services to set up your website with Web Station, which is integrated with support for PHP and MySQL. For detailed instructions, please see DSM Help.

Enable Web Station

With the Web Station feature, you can create a website with web pages on the IoSafe NAS. With built-in PHP and MySQL support, you can create dynamic, database-driven website for your business. There is also a variety of 3rd party packages such as Content Management, Customer Relationship Management & e-Commerce system in Package Center, so that you can install them with a few clicks. The default shared folder, "web" will store the web page files for your website.

Enable Virtual Host to Host Websites

You can host multiple websites on a single server with virtual host feature. Each website can have different port numbers or even different hostname s.

Enable Personal Website

The personal website function is a convenient way to allow IoSafe NAS users to host their own personal websites. Each local user, domain user and LDAP user will have a unique website address.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

Modify HTTP Service Options

In addition to the default port number 80, you can add another port for the use of Photo Station and Web Station. For more detailed instructions, please see DSM Help.

Manage PHP Settings

After you have enabled Web Station, you can click the PHP Settings tab to configure PHP related settings. For more detailed instructions, ple ase see DSM Help.

More Information

Install Featured Applications

 After you have finished setting up your web environment, you can install applications to enhance the features

of your website using many of the free Open Source applications.

 For a list of featured applications tested to be compatible with IoSafe NAS, visit

http://www.synology.com/support/faq_show.php?q_id=404. For the download links and installation

instructions of those applications, visit their official websites.

Set IoSafe NAS as Print Server

Go to Control Panel > External Devices > Printer to set the IoSafe NAS as a print server over your local area network, allowing client computers or mobile devices to access printers connected to the IoSafe NAS. The IoSafe NAS can connect to USB printers or network printers. In addition, AirPrint support allows you to print from an iOS device, and Google Cloud Print support allows you to print using Google products and services.

For more

detailed instructions, please see DSM Help.

Set up Computer to Access Print Server

After the print server is set up on your IoSafe NAS, Windows, Mac, and Linux clients within the local area network can connect to the print server and access its print/fax/scan service.

Access Print Server with iOS Devices

If you have enabled DSM's AirPrint support, any iOS devices running on iOS 4.2 or later can print to the printer connected to your IoSafe NAS.

---------

For recommended peripheral models, including hard drive, USB printer, DMA, and UPS, please visit www.synology.com.

Chapter

Chapter 12: Discover Various Applications with

Package Center

Synology has integrated third party or Synology-designed applications into packages that can be installed on IoSafe NAS and managed with Package Center.

Coming with full-featured applications, IoSafe NAS provides you with a variety of privileges to enjoy multimedia contents, share photos, videos, and blogs, access files anytime and anywhere, monitor live actions from cameras, live stream and record digital TV programs, search and download files from the Internet, back up precious data, and build your own cloud.

This chapter introduces packages availa ble at Package Center and how to install packages. For more detailed instructions, please see DSM Help.

What Package Center Offers

Go to Package Center to find out what Package Center has to offer.

Audio Station

Audio Station is a web-ba sed audio application, allowing you to access the music library on your IoSafe NAS, choose available audio sources on the local area network, and add your favorite music to playlists for playback.

Central Management System

Synology CMS (Central Management System) allows you to efficiently and conveniently manage multiple IoSafe NAS servers. It provides a single interface to monitor the status of multiple servers, create policies for batch editing the settings of server groups, and keep each server in your fleet up-to-date and run ning sm ooth ly .

Cloud Station

Cloud Station is a file sharing service that allows you to synchronize files between a centralized IoSafe NAS and multiple client computers, mobile and IoSafe NAS devices.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

DNS Server

DNS (Domain Name System) is a naming system that facilitates the exchange of data between computers over the Internet and other networks. Its main function is to translate user-friendly domain names (e.g. www.ioSafe.com) into corresponding fixed, public IP addresses (e.g. 120.89.71.100). This function allows users to easily find web pages, computers, or other devices over the Internet or local network.

Download Station

Download Station is a web-based download application which allows you to download files from the Internet through BT, FTP, HTTP, NZB, Thunder, FlashGet, QQDL, eMule, and Xunlei-Lixian, and subscribe to RSS feeds to keep you updated on the hottest or latest BT.

Photo Station

Photo Station is an online photo album integrated with a blog for you to easily share photos, videos, and blog posts over the Internet. With Photo Station, you can upload, organize, edit, and share your photos in quick, easy steps.

Video Station

Video Station is an ideal video organizer of your collection of movies, TV shows, home videos, and TV recordings, allowing you to watch videos on your computer, DLNA/UPnP-compliant DMAs, and mobile devices.

Surveillance Station

Surveillance Station is a professional Network Video Recording (NVR) software bundled with DiskStation Manager (DSM), allowing you to remotely record and monitor video footages from IP cameras which are paired with your IoSafe NAS.

Synology High Availability

High Availability refers to a server layout solution designed to reduce interruptions of services caused by server malfunctions. With Synology High Availability, two servers form a “high-availability cluster,” in which one assumes the role of the active server while the other acts as the stand-by server. If the server malfunctio ns, the stand-by server takes over all services, thus minimizing serv er downtime.

Install or Buy Packages

Click Install, Try or Buy, and follow the onscreen instructions to install packages. You can also click Manual

Install and follow the wizard to install packages by uploading .spk files (available at Synology's Download

Center or third party websites).

Chapter

Chapter 13: Communicate with Mobile Devices

As Internet access grows popular on mobile devices, Synology provides you with several creative alternatives to communicate with your IoSafe NAS using iOS/Android, Windows Phone, or other mobile devices.

Manage DSM Settings with DSM mobile

DSM mobile allows DSM users belonging to the administrators group to manage DSM settings and check DSM information with the web browser of an iOS (iPhone, iPad or iPod touch) , Android device, or Windows Phone.

To log in to DSM mobile:

1 Use the web browser of your iOS/Android device or Windows Phone to connect to

http://IoSafe_Server_IP:5000. 2 Enter your DSM user credentials and tap Login.

Note: For more inf ormation about DSM mobile, tap Help on the home page.

Use iOS, Android, and Windows Apps

The Synology mobile apps are now available on Apple's App Store, Android Market, and Windows Marketplace, allowing you to communicate with IoSafe NAS wherever Wi-Fi access is available. You can manage files, music, photos, videos, even the surveillance videos on your NAS, sync folders between your mobile devices and NAS, download files, and watch videos on the go.

DS audio

DS audio allows you to access Audio Station with an iOS/Android device or Windows Phone and listen to your favorite music on the go. Besides, the remote controller feature allows you to control Audio Station's music playback when there is an audio output device connected to the USB port of your IoSafe NAS, such as a USB speaker, or an external speakers or home stereo equipment connected to the audio dock of Synology Remote (sold separately).

DS cam

DS cam allows users who own an iOS/Android device to live view their IP cameras, take snapshots, and view recorded events from your Surveillance Station whenever a network connection is available.

DS cloud

DS cloud is the mobile counterpart to Synology's Cloud Station and allows you to easily sync folders between an iOS/Android device and IoSafe NAS.

DS download

DS download allows you to access Download Station and download files directly with an iOS/Android device or Windows Phone. You can create download tasks by adding a URL, via a built-in mini browser of the application, or the integrated Safari browser for user convenience. Mana ging bas ic sett ing s such as transfer spe ed limits or activating the advanced schedule is also possible.

DS file

DS file allows you to access and manage files on your IoSafe NAS with an iOS/Android device or Windows Phone.

ioSafe NAS User's Guide

Based Synology o n D S M 5.0

DS finder

DS finder allows you to monitor or email the status of your IoSafe NAS, and request it to perform wake on LAN (WOL), restart, shut down, or play beep sounds (to help you quickly find the its location) with an iOS/Android device or Windows Phone.

DS photo+

DS photo+ allows you to access Photo Station with an iOS/Android device or Windows Phone and share your precious moments on the go. Download and save photos from Photo Station to your mobile device so you can enjoy the flashbacks anytime anywhere. You can also use DS photo+ to upload snapshots or videos from your camera phone straight to Photo Station. Besides, you and your friends can interact by leaving comments on any photos, adding more fun to your photo sharing experiences.

DS video

DS video allows you to access Video Station and watch videos both at home and on the move with an iOS/Android device or Windows Phone. You can browse and organize your collections of videos, record digital TV programs available at the place you are located with a USB DTV dongle (sold separately) plugged into your IoSafe NAS, and manage your recording tasks and schedules.

Note: For more inf ormation about those m obile Apps, refer t o the Help files that come with the Apps.

Use Other Mobile Devices

If you have a mobile device running on Windows Mobile 6.0 (with Internet Explorer Mobile or Opera 9.0 or later), Symbian OS 9.1 (with S60 3rd Edition or later), or iPhone OS 2.3.1 or later, you can use the device to log in to IoSafe NAS to view photos with Mobile Photo Station and read supported file formats with Mobile File Station around the world where Internet access is available.

Troubleshooting

For any questions about managing your DSM, go to DSM Help or click the Help button (with a question mark) at the top-right corner of every window. For any questions other than that, please visit IoSafe Inc. website

www.ioSafe.com for further assistance.

Customer Support USA Toll Free Phone: 888.98.IOSAFE (984.6723) x400 International Phone: 530.820.3090 x400 Email: customersupport@iosafe.com

Technical Support USA Toll Free Phone: 888.98.IOSAFE (984.6723) x450 International Phone: 530.820.3090 x450 Email: techsupport@iosafe.com

Disaster Support US Toll Free Phone: 888.98.IOSAFE (984.6723) x430 International Phone: 530. 820.3090 x430 Email: disastersupport@iosafe.com

Corporate Headquarters ioSafe, Inc. 12760 Earhart Avenue Auburn CA 95602

ioSafe NAS User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
