GasClam Instrument User Manual V1.5
Gasclam Ion Science Ltd
Page 1 of 37
Gasclam Ion Science Ltd
Page 2 of 37
Contents
Declaration of Conformity . . . . . . . . . 3
Introduction to GasClam . . . . . . . . . 4
Effect of Water . . . . . . . . . . 5-6
Keeping GasClam Dry and Clean . . . . . . . 5
Effects of Flooding . . . . . . . . 6
Getting Started . . . . . . . . . . 7-11
Packaging List . . . . . . . . . 7
Turning on the GasClam . . . . . . . . 7
Physical Charateristics . . . . . . . . 8
How GasClam Works and Access Areas . . . . . . 9
Software Installation . . . . . . . . 10
Running Installation . . . . . . . . 10
Battery Change . . . . . . . . . 11
Software . . . . . . . . . . . 11-16
Connecting . . . . . . . . . 12
Main Screen . . . . . . . . . 13
Last Reading Stored . . . . . . . . 14
Errors . . . . . . . . . . 15
Switching Off The Unit . . . . . . . . 17
Set Up . . . . . . . . . . 18
Sampling Rate . . . . . . . 18
Sampling Count . . . . . . . 18
Device ID . . . . . . . 18
Venting . . . . . . . . 19
Water Height . . . . . . . 19
Unit Date and Time . . . . . . 20
Write Setting to GasClam . . . . . 20
Erasing Data Memory . . . . . . 20
Returning to Main Screen . . . . . 20
Downloading . . . . . . . . . 21
Viewing Data . . . . . . . . . 22
Selecting File for Display. . . . . . 22
Data Display Options . . . . . . 22
Sampling Data . . . . . . . 23
Selecting Data Channel . . . . . . 24
Displayed Multiple Parameters . . . . . 25
Importing Data to an Excel Spreadsheet . . . . 26
Infrograph . . . . . . . 27
Start-Stop Data . . . . . . . 27
Calibration Data . . . . . . . 28
Error Messages . . . . . . . 28
Eeprom . . . . . . . . 28
Bump Test . . . . . . . . . 29
Other Test . . . . . . . . . . . 30
Installation . . . . . . . . . . . 31
Service and Calibration . . . . . . . . . 32-34
Unit Calibration . . . . . . . . . 32
Service . . . . . . . . . . 32
User Serviceable Parts . . . . . . . . 32
Spare Parts . . . . . . . . . 34
Technical Specification . . . . . . . . . 35
Update Log . . . . . . . . . . . 36
Gasclam Ion Science Ltd
Page 3 of 37
Declaration of Conformity
The manufacturer, Elok-Opava, hereby declares and confirms that the characteristics of the product conform to the
technical requirements stipulated by the technical standards. Furthermore, the manufacturer declares the product to be
safe whilst adhering to the correct conditions for its installation, maintenance and use.
Manufacturer: Elok-Opava s r.o., Sàdek 17, 747 75 Velké Heraltice, Czech Republic
Product Description: A landfill Gas monitor designed for in-situ borehole monitoring. The entire casing is made from
solid stainless steel. The battery pack is in the upper part of the housing in a flame-proof casing. The measuring unit
consisting of four gas sensors is located in the intrinsically safe lower part of the housing. The valves, pump and filter
assembly are located at the bottom of the housing.
Authorised Subject: FTZÚ, AO 210, NB 1026, Pikartská 7, 716 07 OSTRAVA-RADVANICE, IČO-00577880
Type of Protection: II 2G Ex d ib [ib] IIB T4
Certificate Number: Quality assurance notification: FTZÚ 02 ATEX Q 025 according to EN 13980, CE 1026
FTZÚ 07 ATEX 0105X
Method of Determining Conformity: The product‟s conformity with the respective requirements of directive 94/9/EC
- it was compared with the submitted documentation
- it was tested according standards
List of Technical Regulations and Standards:
02600-00-001, NKO
PTTI EN 60079-0:2006 Electrical Apparatus for Potentially Explosive Atmospheres – General Requirement
PTTI EN 60079-1:2004 Electrical Apparatus for Explosive Gas Atmospheres. Flameproof enclosures „d‟
PTTI EN 60079-11:2007 Explosive Atmospheres – Equipment Protection by Intrinsic Safety „I‟
Directive 2004/108EC EN 61326-1:2006 – Electrical Equipment for Measurement
Name: Ing. Jiri Klein Position: Managing Director
Signature: Date: 03/06/2008
Gasclam Ion Science Ltd
Page 4 of 37
Introduction to GasClam
GasClam is the world‟s first in-situ borehole gas monitor, suitable for the detection of a wide range of gasses commonly
found in borehole monitoring, including Methane (CH4), Carbon Dioxide (CO2) and Oxygen (O2). In addition to this the
GasClam monitors temperature, barometric pressure and borehole pressure.
All of these readings can be taken at programmable intervals, providing an invaluable set of data to the user. The default
setting for the Gasclam is to take readings every hour, giving it approximately one months‟ operational life. Data is
downloaded either using a computer or via an optional modem and can be viewed within the GasClam software or
exported for analysis in Excel. Whilst connected to the software the settings of the GasClam unit can be altered,
including the frequency at which samples are taken and selecting venting options.
In addition to the sensors already mentioned, the GasClam can be upgraded with a Photo ionisation Detector (PID) for
detection of Volatile Organic Compounds (VOC‟s), a Carbon Monoxide (CO) sensor, Hydrogen Sulphide (H2S) sensor and
a water depth sensor should the data be required.
Ion Science Ltd recommends that regular customer bump tests take place in conjunction with an annual service and
calibration, which is performed by the Ion Science service department or an Ion Science approved service centre. Before
using the GasClam you must read this manual paying particular attention to the section on the effects of water on your
GasClam.
Note: Before removing the GasClam from the field it must be run once in atmosphere to purge any hazardous gasses.
Gasclam Ion Science Ltd
Page 5 of 37
The effects of water on your GasClam
GasClam is designed to overcome – as far as possible – the requirement to:
measure gas concentrations,
measure borehole and atmospheric pressure,
allow a venting pathway between the borehole and atmosphere.
To measure gas concentrations the gas must be dry and measurements of atmospheric pressure should not include the
pressure of overlying water. As the GasClam can be in a position liable to flooding from above (flooded headworks) and
below (high borehole water level) your help is required to optimise the performance of your GasClam by:
carrying out simple preventive and remedial maintenance
being aware of the limitations of data gathered under flood conditions.
1. Keeping your GasClam dry and clean in regular use
To dry the gas before measurement there is a moisture stripping filter in the bottom section of the GasClam. Over time
this will hydrate and its ability to remove moisture will decrease. If moisture is not successfully removed, concentration
readings will be affected. If the moisture stripping filter is completely saturated it can dissolve, and it will then be
pumped in to other sections of the GasClam resulting in catastrophic failure. This will always be avoided if the GasClam
is installed vertically and the filter is replaced after every 800 samples. However, it is recommended to renew the filter
whenever a visit is made to the GasClam to ensure optimal performance during data collection (see service and
calibration section).
To prevent water reaching the vent pathway the snorkel should always be attached to the vent hose barb. The top of
this should be supported so it is located at the top of the headworks to reduce the chance of water ingress. In situations
where the headworks is likely to be flooded the hose barb must be replaced by the vent blank. The supplied box spanner
can be used to remove the hose barb and the supplied vent Alan key used to replace with the vent blank and washer.
The GasClam should always have the snorkel attached to the vent hose barb (a). In situations where the
headworks is likely to flood the hose barb must be replaced by the vent blank and washer (b).
A
B
Gasclam Ion Science Ltd
Page 6 of 37
The effects of water on your GasClam
2. Effects of flooding on data and GasClam
When the unit is not sampling it has an ingress protection rating of IP-68 (submersible to 10 meters for 1 week).
However,
Immersion will effect data and
May require subsequent corrective action
These effects and requirements will differ whether immersed from above, i.e. flooded headworks, or from below, i.e. rise
in borehole water level, see table below:
Flooded
Headworks
Remedial action
Preventive maintenance
Effects on
data
should vent breather be
submerged:
atmospheric pressure
reading will be incorrect
and will remain incorrect
Scheduled venting will be
ineffective.
Use borehole pressure as approximate
replacement or use data from another
source.
If chamber is known to
flood, or is already full of
water
Chose another
chamber
Or replace
snorkel with
bolt
Effects on
GasClam
If submerged for an extended
period the vent pipe may become
flooded.
The vent breather may become
clogged by dirty water.
When GasClam is visited
Check data and call service
centre if atmospheric
pressure looks strange and
they will advise
If chamber is liable to
flooding
replace vent
breather each visit
Flooded
Borehole
Remedial action
Preventive maintenance
Effects on
data
Should water reach the bottom of
the GasClam the inflow and
outflow valves will remain closed
and no samples will be taken:
borehole pressure reading
will be incorrect
gas concentration
readings will be incorrect
Data points collected whilst the
sampling cycle was disabled will be
marked
If borehole water level is
known to be high or is
already full of water
Chose another
chamber
Or extend the
borehole above
ground level
Effects on
GasClam
None
None
Gasclam Ion Science Ltd
Page 7 of 37
Getting Started
Packing list
Please take a little time to examine the contents of the GasClam package.
Item Description Qty
Barbs (Fitted) 3
Box spanner for removing barbs 1
Blank (NOT Fitted) + washer 1
Length of pipe (30cm) 3
Battery Allen Key 1
Vent blank Allen Key 1
Communication cable 1
Start cable 1
Manual and software (on CD) 1
Rubber Collar 1
GasClam Unit 1
1.5v Duracell Batteries (Fitted) 2
Moisture Stripping Filter 1
Accessory Kit 1
Moisture stripping filter 6
Snorkel (complete) 1
Snorkel filter 2
O-ring (part 22) 5
O-ring (part 21) 5
Turning on the GasClam
The GasClam can be switched on and off using the remote. The remote connects to the
communication port on top of the GasClam.
To start the GasClam hold the button down for two seconds, the red LED will flash rapidly
indicating the GasClam has started and is currently going through the processes in a sampling
cycle, this equates to „sampling‟ mode.
After the sampling processes have finished the red LED flashes intermittently, this equates to
the „measuring‟ mode.
To stop the GasClam press the button for two seconds, when it has stopped the LED will stop flashing, this equates to
„sleeping‟ mode
No flashing
Sleeping
Rapid flash
Sampling
Intermittent flash
Measuring
Gasclam Ion Science Ltd
Page 8 of 37
1
8
Getting Started
Physical Characteristics
1. Communication port
2. Pressure transducer port
3. Pressure transducer port cap
4. Gas inlet
5. Gas Outlet
6. Water proximity sensor
7. Pressure transducer hook
8. Battery compartment lid
9. Vent (with hose barb)
10. Rubber Collar
GasClam identification plates with intrinsic safety specifications.
9
10
3
5 6 4
2
7
Gasclam Ion Science Ltd
Page 9 of 37
Getting Started
How the GasClam Works and access areas
Gasclam Ion Science Ltd
Page 10 of 37
Getting Started
Software Installation
System Requirements
The GasClam software needs 30MB free space on the hard disk for installation.
The programme will run on the following platforms:
- Windows 98
- Windows 98 Second Edition
- Windows 2000 service pack 3
- Windows ME
- Windows Server 2003
- Windows XP service pack 2
- Windows Vista
- Windows 7
The programme needs .Net Framework 2.0 (x86) installed to run properly. This version is included on the software CD,
alternatively it can be downloaded from the Microsoft website.
Running the installation software
Insert the installation CD or USB stick and copy the software folder on to the PC.
There are two installation options.
1) If you have an old version of DotNetFX, 2.0 (x86) then double click the „setup‟ icon to update the DotNetFX. (If
you already have this version and you try to upgrade an error will occur, ignore this and go to the next option)
2) If you already have this version of DotNetFX then double left click the „GasClamUnit‟ icon.
The guide will then take you through the installation process step by step.
The default location for the GasClam software is:
C:\Program Files\Salamander\GasClam
Gasclam Ion Science Ltd
Page 11 of 37
Getting Started
Battery Change
Warning:
For reasons of intrinsic safety, batteries MUST NOT be changed within potentially flammable areas. Always ensure you are in a safe
area before carrying out any type of maintenance on your GasClam
Battery types that can be used:
For Intrinsic Safety and reduced risk of explosion you must only use Duracell 1.5 V LR20 Alkaline-Manganese
MN1300 batteries or a 2 x 1,2V LR20 Nickel-metal hydride Saft VH D 9500 rechargeable pack. Do not mix old and new
batteries within the same unit, change both batteries at the same time. Failure to do so will reduce battery
life of the new cell fitted.
The battery compartment is accessed by removing the 4 screws from the battery compartment lid, see diagram. To remove the
batteries tilt the GasClam until they fall out. Replace with the stipulated batteries positive terminal facing down. Take care when
replacing the cover to ensure the O-ring is not damaged by following the instructions below:
The integrity of this O-ring should be
checked every time the batteries are
replaced. This needs to be replaced if any
damage is noticed.
When tightening the cover alternate between
screws to ensure the cover sits on the
GasClam squarely. If this is not done the Oring may be damaged.
Push the battery compartment lid down square on the
GasClam
When the O-ring is resting on the battery compartment
push the lid down evenly on both sides to ensure it
travels down square. This will prevent damage to the
O-ring. When the O-ring is sitting in the compartment
loosely tighten the screws.
Loading...
