IOGEAR HVER PRO X Quick Start Guide

Quick Start Guide

™

HVER RGB Optical Mechanical Keyboard

Guide de démarrage rapide

HVER™ PRO X Clavier de Jeu Mécanique Optique RVB

Guía de inicio rápido

HVER

Teclado de Juego Mecánico Ōptico RGB

GKB730

PART NO. Q1506

PRO X

™

PRO X

Welcome to Kaliber Gaming

Congratulations! You are now officially a new owner of Kaliber Gaming’s HVER™ PRO X RGB Optical Mechanical Keyboard. Designed for gamers, HVER PRO X offers an array of functions that will increase your gaming skills. You can customize your HVER PRO by choosing from the an assortment of pre-programmed color patterns, or download the HVER PRO X user interface software and fine-tune the multi-zone RGB backlighting to match your PC, mouse and other devices. The HVER PRO X software also allows you to create custom macros and change the bindings of up to 65 different keys, then store them along with your favorite RGB backlight setting to one of three programmable user profile slots. Make sure to read through the full list of features, and take your time following through the operational guidelines in order to get the maximum enjoyment out of your new HVER PRO X!

Package Contents

1 x HVER™ PRO X 1 x Quick Start Guide 1 x Warranty Card

Requirements

• Windows

• USB 2.0 port

7, Windows® 8, Windows® 8.1, Windows® 10

Hardware Installation

Simply connect the USB plug of HVER PRO X to an available USB port on your computer. Your operating system will automatically install the device.

Software Installation

The HVER PRO X user interface software allows creating custom macro functions and specialized hotkeys, as well as fine-tuning the RGB backlighting. The HVER PRO X user interface software is a free download available on the IOGEAR website location below: https://www.iogear.com/product/GKB730-BN/

Operation

Keyboard - Front View

1. Num Lock LED – turns on when Num Lock key is pressed

2. Caps Lock LED – turns on when Caps Lock key is pressed

3. Scroll Lock LED – turns on when Scroll Lock key is pressed

4. Windows Lock LED - turns on when Fn + is pressed to indicate the Windows key is disabled

1 42 3

Windows Key Lockout

The Windows key lockout prevents the Windows menu from popping up and interfering with your game if accidentally pressed while gaming. Press Fn + key to lockout the Windows menu function. The Windows Lock LED will light up to confirm the Windows key is locked out Press Fn + again to unlock the Windows key.

Anti-Ghosting / NKRO

As gaming has exploded in popularity, the term Anti-Ghosting has evolved from its original meaning to now describe a non-mechanical keyboard’s ability to accurately detect individual keystrokes when certain combinations of buttons are pressed. Mechanical keyboards do not suffer this problem, and may instead have a limit to the total number buttons that can be pressed simultaneously. This limit is expressed as N-Key Rollover (NKRO) where N equals the number of keys that can be pressed simultaneously. HVER PRO has no limit and features full NKRO, meaning every keystroke will be detected no matter how many keys are simultaneously pressed. Now you can play with confidence knowing your keyboard won’t hold you back!

LED Backlight Functions

The HVER PRO X has 8 built-in backlight modes with 47 different color/pattern combinations, plus 3 DYI per-key user programmable lighting modes. The backlighting can be further customized issuing the downloadable HVER PRO X user software. Press Fn + PrtSc to cycle through the 8 different color modes: Sparkle, Monochrome, Fixed Single-Color, Breathing, Follow, Rainbow Ripple, Explode and Wave.

Backlight Color Adjustments

Press Fn + Home or Fn + End to cycle up or down through the 9 color options available within each backlighting mode: Rainbow, White, Purple, Blue, Cyan, Green, Yellow, Orange and Red. Note: Sparkle and Monochrome backlight modes do not have color options available.

Backlight Pattern Adjustments

Press Fn + PgUp to increase brightness Press Fn + PgDn to decrease brightness

Press Fn + ◄ to shift light flow direction left Press Fn + ► to shift light flow direction right

Press Fn + + to increase light speed Press Fn + - to decrease light speed

DIY Custom Lighting

The HVER PRO X has three DIY lighting modes that can be programmed without using the HVER PRO X user software.

To set the DIY lighting mode:

1. Press Fn + F9, Fn + F10 or Fn + F11 to select a DIY backlighting mode.

2. Press Fn + Pause to start DIY programming. The 4 status LEDs will begin flashing.

3. Press the keys you want to light. Each press will cycle the key color as follows: Off, Red, Green, Blue, Yellow, Purple, Cyan, White.

4. Press Fn + Pause to exit and save the setting. The 4 status LEDS will stop flashing.

Note: Change the FN key color last. When changing the Fn key color, cycle to the color you want but do not release the key. Continue holding down the key and press Pause to save, then you can release the key.

Hotkeys

There are 9 hotkeys offering quick access to the most commonly used functions. Press the F key to activate the desired function.

Windows Hotkeys Function

Fn + F1 Media Player Fn + F2 Volume Down

Fn + F3 Volume up

Fn + F4 Mute Fn + F5 Stop Fn + F6 Previous Track Fn + F7 Play/Pause Fn + F8 Next Track Fn + F12 Calculator

HVER PRO X User Software

The following features require installation of the HVER PRO X user interface software, available as a free download the from the IOGEAR website.

Macro Keys

The HVER PRO X keys can be programmed to execute a series of keystrokes with only a single press. These are great gaming tools for casting spells, etc. but they can also be used to simplify your life outside of gaming. You can use programmable buttons for simple text shortcuts like entering passwords or email addresses, accessing special menus and executing multi-key commands when using powerful programs like Photoshop and Solidworks. To create and store Macro Key functions you will need to download the HVER PRO X user interface software from the IOGEAR website.

User Profiles

The HVER PRO X can store up to three custom user profiles, each with differently programmed macro keys and LED backlighting. To create and store custom user profiles you will need to download the HVER PRO X user interface software from the IOGEAR website.

Keyboard - Rear View

Foldout Leg (see Foldout Leg Keycap Removal Tool)

Foldout Legs

For greater comfort during long gaming sessions, you can adjust the typing angle of your HVER PRO X by folding the legs in or out on the back of the keyboard.

Keycap Removal Tool

The HVER PRO X includes a tool that assists in removing the keycaps for cleaning, or when exchanging them for a custom set. To remove a keycap, center the tool over the keycap and press downward until it snaps over the cap. Lift up with even pressure until the keycap is removed.
