IOGear GMP10K User Manual

Quick Start Guide

Gear Power Ultra Capacity Mobile Power Station

GMP10K

PART NO. Q1363

www.iogear.com

Package Contents

Charging GearPowerCharging GearPower

4. LED Charging/Capacity indicator4. LED Charging/Capacity indicator

5. Battery capacity button5. Battery capacity button

1

1 x Mobile Power Station
1 x 3’ USB Charging Cable
1 x 5V 1A Power Adapter

Overview

1. USB Type A Female port (Output) (1A)

2. Micro-USB Female port (Input)

3. USB Type A Female port (Output) (2.1A)

4. LED Charging/Capacity indicator

5. Battery capacity button

1 2 3

5V1A Output Input

5V2.1A Output

4

5

Charging GearPower

Connect the GearPower Mobile Power Station to
a power source using the included Micro USB
cable and power adapter.

1. Plug the USB type A connector into the USB
port of the 5V 1A power adapter. Plug power
adapter into power outlet

2. Insert the Micro USB connector into the Micro
USB port of the Mobile Power Station.

3. The LED charging indicator will light up
“Green” and blink. Once the Mobile Power
Station is fully charged, all four LED charging
indicators will light up solid “Green”.

The USB charging cable can be plugged in to
your computer’s available USB port or any
wall-plug style power source with the included
5V 1A power adapter.

1 x Carrying Pouch
1 x Quick Start Guide
1 x Warranty / Registration Card

5V1A Output Input

or

by IOGEAR

5V2.1A Output
