IOGear GIC320U User Manual

Page 1
Quick Start Guide
2-Port USB 3.0 PCI Express Card
GIC320U
PART NO. Q1136
Page 2
Package Contents
1 x USB 3.0 PCI Express Card 1 x Quick Start Guide 1 x Installation CD 1 x Warranty / Registration Card
System Requirements
• Windows XP, Windows Vista, Windows 7
• Available PCI Express Card Slot
ʳ
1
Page 3
Software Installation Start Here!
1. Insert the CD-ROM, double–click Setup.exe to start the software installation.
Version.
Software CD and User Manual
GIC320U
SuperSpeed USB 3.0 PCI Express Card
1
2. Follow the onscreen instructions to install the driver software.
9
6
4
1
D
a
V
i
n
c
i
,
F
o
o
t
h
i
l
l
R
a
n
c
h
,
C
m
o
c
.
r
a
e
g
o i
.
w
w
w
:
W
5
8
7
8
.
3
5
4 .
A
9
4
9
9
2
:
6
F
1
0
2
8
P
7
:
8
.
9
3
4
5
9
.
4
3. When finished, shut down your computer and unplug the AC power source.
2
Page 4
Hardware Installation
1. Open your computer case, touch any metal part of the case to ground yourself. Insert the GIC320U into an available PCI Express Card™ slot (refer to your computer’s manual for more instructions). You may use the included Low-Profile bracket for a system with a low-profile chassis.
Note: Depends on your computer’s power supply design, you may choose to connect the power connector on GIC320U with the power cable from the power supply.
Attaching Screw
System Frame
Bracket
GIC320U
PCI-Express Slot
Motherboard
2. Plug in and turn on your computer. When Windows starts, it should load the driver you just installed automatically.
3
Page 5
3. If your Windows system tries to obtain the driver from Windows Update, please click “Skip obtaining driver software from Windows Update”.
Connect to USB Devices
When the dialog box indicates that the installation has finished, your computer is now ready for USB 3.0 SuperSpeed devices. This card also supports USB 2.0 or USB 1.1 devices.
4
Page 6
Federal Communications Commission (FCC) Statement
This product has been tested and found to comply with the limits for a Class B device, pursuant to part 15 of the FCC Rules. It is intended for use in residential setting, but may also be used in commercial or industrial setting.
CE Compliance
This device has been tested and found to comply with the following European Union directives: Electromagnetic Capability (89/336/EMC), Low Voltage (73/23/EEC) and R&TTED (1999/5/EC).
5
Page 7
Warranty
WE’RE HERE TO HELP YOU! NEED ASSISTANCE SETTING UP THIS PRODUCT?
Make sure you:
1. Use the live chat at www.iogear.com to try and solve any issues you may be having with the product
2. Visit the Tech Info Library/FAQ on www.iogear.com (under the Support tab)
3. Call the tech support line at 1(866) 946-4327 (U.S. only) or (949) 453-8782
Warranty Information This product carries a 3 Year Limited Warranty. For the terms and conditions of this warranty, please go to http://www.iogear.com/support/warranty or call 1-866-946-4327
Register online at http://www.iogear.com/register
Important Product Information Product Model ___________________________ Serial Number ___________________________
Contact
Toll Free 866-946-4327 (USA) Phone: 949-453-8782 19641 Da Vinci Foothill Ranch, CA 92610 www.iogear.com support@iogear.com
