IOGear GCS52U User Manual

MiniView

2-Port KVM Switch with Built-in KVM Cables

Installation Manual (GCS52U)

™

Micro USB

IOGEAR, the IOGEAR logo, MiniView, VSE are trademarks or registered trademarks of IOGEAR, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. IBM is a registered trademark of International Business Machines, Inc. Macintosh, G3/G4 and iMac are registered trademarks of Apple Computer, Inc. IOGEAR makes no warranty of any kind with regards to the information presented in this document. All information furnished here is for informational purposes only and is subject to change without notice. IOGEAR, Inc. assumes no responsibility for any inaccuracies or errors that may appear in this document.

Thank you for purchasing one of the most feature-rich keyboard, video, and mouse switches on the market. IOGEAR’s MiniView™ Micro switches are first-rate connectivity accessories designed to help reduce the frustration of managing multiple computer systems. With the MiniView™ Micro by IOGEAR, you can access two computers from a single console(keyboard, mouse and monitor). MiniView™ Micro allows you to change ports easily by entering Hot Key combinations from the keyboard. Setup is fast and easy; plugging cables into their appropriate ports is all that is entailed.

We hope you enjoy using your MiniView™ Micro USB KVM, yet another first-rate connectivity solution from IOGEAR.

Table of Contents

Package Contents Overview Features

○○○○○○○○○○○○○○○○○○○○○○○○○

Requirements Introduction Installation Operation

○○○○○○○○○○○○○○○○○○○○○○○○○

Appendix (HotKey) Specification Troubleshooting Tech Support Radio & TV Interference Statement

Limited Warranty

○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○

02 03 04 05 06 07 10 13 14 16 18 19 20

Package Contents

This package contains:

1 MiniView 1 User Manual 1 Quick Start Guide 1 Warranty Registration Card

If any items are damaged or missing, please contact your dealer.

Micro USB 2-port KVM switch

Overview

The MiniView™ Micro USB (GCS52U) KVM switch allows access to two USB computers from a single console (keyboard, monitor, and mouse). This cost-effective way to access two computers, without extra hardware, is highly efficient and easy to use. By allowing a single console to manage both computers, the MiniView™ Micro eliminates the expense of purchasing extra keyboards, monitors, mice, and the MiniView™ Micro eliminates the extra space they would take up.

The MiniView™ Micro USB KVM is small, portable, and fits right on or under your desktop. It also comes with a built-in KVM cable set to simplify the installation. Setup is fast and easy: plugging cables into the appropriate ports is all that is entailed. There is no software to configure, and no imcompatibility problems. Since the MiniView™ Micro intercepts keyboard input directly, it works on virtually any hardware platform and with virtually all operating system.

The MiniView™ Micro USB KVM provides a convenient method to access the computers by simple Hot Key combinations from the keyboard.

Features

- Use one keyboard, monitor and mouse to control two computers

- Very compact KVM switch with molded cables for computer connections

- Supports Microsoft IntelliMouse and the scrolling wheel on most mice

- Easy to install – No Software Required !

- Easy to operate – PC selection via convenient Hot Keys

- AutoScan function to monitor computer operation

- LED display for easy status monitoring

- Caps Lock, Num Lock, and Scroll Lock states are saved and restored when switching

- Hot pluggable – add or remove computers without powering down the switch

- Keyboard and mouse emulation for error free PC booting

- Self Powered – No need for external power supply

- Superior video quality – up to 1920x1440; DDC, DDC2, DDC2B

Requirements

Computers with a PS/2 mouse and keyboard connection, VGA connection, and an available USB port.

PS/2 connection

VGA connection

USB port
