IOGear GCS1004 User Manual

User Manual

2/4-Port USB DVI KVM Switch

GCS1002 / GCS1004

PART NO. M1265-a

www.iogear.com

©2014 IOGEAR. All Rights Reserved. Part No. M1265-a IOGEAR, the IOGEAR logo, MiniView®, VSE are trademarks or registered
trademarks of IOGEAR. Microsoft and Windows are registered trademarks of Microsoft Corporation. IBM is a registered trademark
of International Business Machines, Inc. Macintosh, G3/G4 and iMac are registered trademarks of Apple Computer, Inc. IOGEAR
makes no warranty of any kind with regards to the information presented in this document. All information furnished here is for
informational purposes only and is subject to change without notice. IOGEAR. assumes no responsibility for any inaccuracies or
errors that may appear in this document.

Table of Contents

Introduction 4

Package Contents 4

Features 4

Requirements 5

Overview 6

Hardware Installation 8

Basic Operation 10

Hotkey Operation 11

Keyboard Emulation 16

The Firmware Upgrade Utility 18

Specications 21

Troubleshooting 22

Federal Communications Commission (FCC) Statement 23

CE Compliance 23

Limited Warranty 23

Contact 23

3

Introduction

This IOGEAR DVI KVM Switch GCS1002 / GCS1004 allows users to access up to two
(GCS1002) or four (GCS1004) computers from a single USB keyboard, USB mouse, and
DVI monitor. It supports resolutions up to 1920x1200 @60Hz. With IOGEAR’s DynaSyncTM,
there is no more delay or change of video resolution when switching between, or booting the
computers. It also comes equipped with an audio line out and has power on detection – it will
automatically switch to the next powered-on computer when the other is turned off. It also
allows each computer to access any peripherals connected to the USB 2.0 port. And with its
audio enabled, users can listen to the audio output of each computer on one set of speakers.

The setup is quick and easy; users just need to plug the cables into their appropriate ports.

There is no software to congure. Since the GCS1002 / GCS1004 intercepts keyboard input

directly, it supports multiple computing platforms (PC x86 / x64, Macintosh PowerPC, and Sun
Microsystems Sparc).

There are three convenient methods users can use to access the computers: port selection
pushbuttons located on the unit’s front panel; hotkey combinations entered from the keyboard;
and mouse port-switching by simply double-clicking on the scroll wheel of a USB mouse to
change the ports.

Package Contents

1 x GCS1002 / GCS1004 2/4-Port USB DVI KVM Switch
1 x 4ft 44-pin Custom KVM Cable set
1 x 6ft 44-pin Custom KVM Cable set (for GCS1004 only)
1 x Power Adapter (for GCS1004 only)
1 x User Manual
1 x Warranty Card

Features

• One DVI console controls up to two (GCS1002) or four (GCS1004) USB

interface computers

• DVI-D KVM cable set - includes one 4ft 44-pin custom KVM cable and one 6ft 44-pin

custom KVM cable (GCS1004 only) to connect up to four computers

• Fully compliant with DVI specication (Digital only)

• Supports multi-function and wireless mouse / keyboard

• Audio enabled – full bass response provides a rich experience for 2.1 channel surround

sound systems

• Superior video quality – up to 1920 x 1200 @60Hz

• Auto Scan Mode for monitoring all computers

• Multiplatform support – Windows, Linux, Mac, FreeBSD and Sun

• Console mouse port emulation / bypass feature supports most mouse drivers and

multifunction mice

4

• Hot Pluggable - Add or remove computers for maintenance without powering down the

switch

• HDCP compliant

• Video DynaSyncTM

• Power on Detection - Automatically switches to the next powered-on computer when the

other is turned off

• Computer selection via front panel pushbuttons, hotkeys, and mouse switching function

• USB 2.0 mouse port can be used for USB hub and USB peripheral sharing

• Complete keyboard emulation for error-free booting

• Mac / Sun keyboard support and emulation

• Firmware Upgradable

• Plug & Play - No software installation required

Requirements

Console:

• 1 DVI display

• 1 set of USB keyboard and mouse

• Speakers (optional)

Computers:

• 1 DVI Port

• 2 USB Ports

• Audio ports (optional)

• Computers with sound support

Cables:

• DVI-D KVM cable set – 4ft 44-pin cable / 6ft 44-pin cable (GCS1004 only) specically de­signed to work with this switch, may be used to link the computers. One (GCS1002) or two
(GCS1004) cable set(s) are provided with this package.

Note: The quality of the display is affected by the quality and length of the cables. If you

need additional cable sets, please contact your dealer to purchase the appropriate ones for
your switch.

• DVI cable for your DVI monitor

5

Operating Systems:

The supporting operating systems are listed in the table below:

OS Version

Windows XP / 2003 / 2008 / Vista / X86 / X64 / 7 / 8 / 8.1

Linux RedHat 9.0 and higher

SuSE 10 / 11.1 and higher

Mandriva (Mandrake) Linux 2006 and higher

Debian 3.1 / 4.0

Ubuntu 7.04 / 7.10

Unix FreeBSD 5. 5 and higher

Sun Solaris 8 and higher

Novell Netware 6.0 and higher

Sun Solaris 9 and higher

Mac OS 9 to 10.5

Note: Supports Linux Kernel 2.6 and higher.

Overview

GCS1004 Side View

1

Audio

2

No Component Description

1

Audio Port The cable from your speakers plugs in here.

2

USB Console Ports: Your USB keyboard and USB mouse plug in here. The USB 2.0

mouse port can be used for connecting a USB hub and USB
peripheral sharing with mouse emulation off. An additional power
adapter might be required for the hub.

6

GCS1004 Front View

1

4-Port USB DVI KVM Switch

GCS1004

1 2 3 4

2

No Component Description

1

Port Selection
Pushbuttons

For manual port selection, press a port selection pushbutton to bring
the KVM focus to the computer attached to is corresponding port.

See Manual Port Switching, page 10 for more details.

2

Port LEDs The Port LEDs are built into the Port Selection Switches.

• Flashes indicate that the computer attached to the

corresponding port has the KVM focus and is being accessed in
Auto Scan Mode (see Auto Scanning, page 12).

• Lights steady to indicate that the computer attached to its

corresponding port is the one that has the KVM focus.

• The LED is off when the port is not selected.

GCS1004 Back View

1

CPU 3 / 4 CPU 1 / 2

2

3

No Component Description

1

DVI Console Port The cable from your DVI monitor plugs in here.

Note: The USB keyboard and USB mouse ports are located on the
unit’s side panel.

2

Computer Port(s): The cable(s) that link the switch to your computers plug in here.

Note: You can identify the computers by the port they are con­nected to – they are labeled CPU1 / CPU2 for GCS1002; CPU1 /
CPU2 / CPU3 / CPU4 for GCS1004.

3

Power Jack

The power adapter cable plugs into this power jack.

(GCS1004 only)

7

Hardware Installation

Make sure that power to all the devices you will be installing has been turned off. You must
unplug the power cords of any computers that have the Keyboard Power On function.

Cable Connections:

To set up your GCS1002 / GCS1004, refer to the installation diagram (the numbers in the
diagram correspond to the steps below), and follow the steps below:

1. Plug your speakers into the Audio port located on the unit’s side panel (optional).

2. Plug your USB keyboard and mouse into the USB Console ports located on the unit’s
side panel.

Note: The USB mouse port can also be used for other USB peripherals that you want

share between the computers with mouse emulation off.

Audio

1

2

8

2

3. Plug your DVI monitor into the DVI Console port located on the unit’s rear panel and power on
the monitor.

4. Using the provided 44-pin cable set, plug the 44-pin connector into the Computer port(s) of
the switch.

5. At the other end of the cable, plug the USB, DVI-D and speaker connectors into their respec­tive ports on the computer.

6. For GCS1004 only, plug the power adapter that came with your switch into a power source,
then plug the power adapter into the switch’s Power Jack.

7. Turn on the power to the computers.

6

3

CPU 3 / 4 CPU 1 / 2

5

9

4

Basic Operation

Manual Port Switching

There are three convenient methods to access the computers: Manual – which involves press­ing the port selection pushbuttons located on the unit’s front panel; Mouse – which involves
clicking the scroll wheel of the mouse; and Hotkey – which involves entering combinations from
the keyboard. Hotkey port selection is discussed in the next chapter.

For manual port selection:

• Press and release a port selection pushbutton to bring the KVM focus to the computer

attached to its corresponding port.

• Press and release either port selection pushbutton to stop Auto Scan Mode. The KVM fo-

cus goes to the computer attached to the corresponding port of the switch you pressed.

Mouse Port Switching

The GCS1002 / GCS1004 support the very latest in mouse port switching – simply double­click the scroll wheel of your USB mouse to cycle through the ports.

Note:

1. This feature is only supported by USB 3-key scroll wheel mice.

2. The default setting is off.

3. It is only supported when Mouse Emulation is enabled. See Mouse Emulation Control on

page 13 for details.

Hot Plugging

The GCS1002 / GCS1004 support USB hot plugging – components can be removed and
added back into the installation by unplugging their cables from the USB hub ports without the
need to shut down the unit.

Firmware Upgrade

Refer to The Firmware Upgrade Utility on page 18 for a step by step guide on upgrading the

rmware. In summary, do the following steps:

1. Push and hold the Port 1 pushbutton located on the unit’s front panel, and power on the

unit.

- For GCS1002: The front panel LEDs ashes.

- For GCS1004: The LEDs for Port 3 and Port 4 will stay on, while the LEDs for Port 1
and Port 2 will stay off.

2. Update the rmware manually via command line by following the instructions shown on

the screen.

Powering off and Restarting
If it becomes necessary to Power Off the GCS1002 / GCS1004 unit, before starting it back up
you must do the following:

1. Shut down all computers that are attached to the switch.

2. Unplug the switch’s power adapter cable.

3. Wait 10 seconds, then plug the switch’s power adapter cable back in.

4. After the switch is up, power on the computers.

10

Hotkey Operation

The GCS1002 / GCS1004 provide an extensive, easy-to-use, hotkey function that makes it

convenient to control and congure your KVM installation from the keyboard.

Hotkey Setting Mode

All hotkey operations begin with tapping the Scroll Lock key twice. This invokes the Hotkey
Setting Mode (HSM), which can be followed by tapping key combinations and the [Enter] key
to perform various operations.

The table below describes the actions that each combination performs.

Note: If using the Scroll Lock key conicts with other programs running on the computer, the

Ctrl key can be used instead. See Alternate Hotkey Setting Mode on page 12 for details.

Hotkey Action

[Scroll Lock] [Scroll Lock] [Enter]

Brings the KVM and audio focus from the
port that currently has the KVM focus to the
next port on the installation (1 to 2; 2 to 1 for
GCS1002; 1 to 2; 2 to 3; 3 to 4; 4 to 1 for
GCS1004).

[Scroll Lock] [Scroll Lock] [Port ID] [Enter]

[Scroll Lock] [Scroll Lock] [X] [Enter] Changes [Scroll Lock] [Scroll Lock] to [Ctrl]

[Scroll Lock] [Scroll Lock] [K] [Enter] Brings only the KVM focus from the port

[Scroll Lock] [Scroll Lock] [S] [Enter] Brings only the audio focus from the port

For GCS1004 only – replace [Port ID] with
the port ID (1-4) to which port you want to
switch the KVM and audio focus.
Note: The KVM and audio all go to this port
even if they were on different ports to begin
with.

[Ctrl]. Press combination again to change
back.

that currently has it to the next port on the
installation.

that currently has it to the next port on the
installation.

11

Alternate Hotkey Setting Mode

The port switching activation keys can be changed from tapping the Scroll Lock key twice
([Scroll Lock] [Scroll Lock]) to tapping the Ctrl key twice ([Ctrl] [Ctrl]). To change the port switch­ing activation keys, do the following:

1. Invoke HSM (see page 11).

2. Press [X] [Enter].

Note: This procedure is a toggle between the two methods. To revert back to the original
[Scroll Lock] [Scroll Lock] method, invoke HSM, then press and release the X key again.

Auto Scanning

The GCS1002 / GCS1004’s Auto Scan feature automatically cycles the KVM focus through the
computer ports at regular intervals. This allows you to monitor the computer activity without
having to take the trouble of switching from port to port manually. Although the video focus
switches from port to port, the keyboard, mouse, and USB focus doesn’t switch. They stay at
the port they were on when Auto Scanning started. See the table below for details

Hotkey Action

[Scroll Lock] [Scroll Lock] [A] [Enter] Invokes Auto Scan. The KVM focus cycles

from port to port in 5 second intervals. A Five
second interval is the default setting.

[Scroll Lock] [Scroll Lock] [A] [Enter] [n] Starts Auto Scan. The KVM focus cycles

from port to port at n second intervals
Note: Replace n with a number between 1
and 4 when entering in this hotkey
combination.

• [1] changes scan interval to 3 seconds

• [2] changes scan interval to 5 seconds

(default)

• [3] changes scan interval to 10 seconds

• [4] changes scan interval to 20 seconds

To exit Auto Scan, press [Esc] or [Spacebar].
Auto Scanning stops when you exit Auto
Scan Mode.

When you use the port switching hotkey or HSM, the mouse cursor must be in the current
computer display.

While Auto Scan Mode is in effect, ordinary keyboard and mouse functions are suspended
– only Auto Scan Mode compliant keystrokes and mouse clicks can be inputted. You must
exit Auto Scan Mode (press the Esc key or Spacebar) in order to regain normal control of the
console

12

Video DynaSyncTM

Video DynaSyncTM is IOGEAR’s exclusive technology that eliminates boot-up display problems
and optimizes resolution when switching between ports.

To manually detect and remember monitor EDIDs, do the following:

1. Invoke HSM (see page 11).

2. Press [D] [Enter].

Note: If the monitor is disconnected and reconnected, the GCS1002 / GCS1004 will re-exe­cute Video DynaSyncTM.

Mouse Emulation Control

The default setting is enabled. To disable, do the following:

1. Invoke HSM (see page 11).

2. Press [M] [Enter].

This procedure is a toggle. Repeat to enable.

Mouse Port Switching

The Mouse Port Switching function can be enabled or disabled. The default setting is disabled.
To enable, do the follow:

1. Invoke HSM (see page 11).

2. Press [W] [Enter].

This procedure is a toggle. Repeat to disable.

Note: The feature is only supported when mouse emulation is enabled. See Mouse Emulation
Control above.

Power on Detection

With the Power On Detection feature, the switch automatically switches to the next powered­on computer if one computer is powered off. This feature is enabled by default, to disable:

1. Invoke HSM (see page 11).

2. Press [E].

This procedure is a toggle. Repeat to enable.

13

Keyboard Operating Platform

The GCS1002 / GCS1004’s default port conguration is for a PC compatible keyboard

operating platform. For example, if your console uses a PC compatible keyboard and you have

a Mac attached to a port, you can change the port’s keyboard operating platform conguration

so that the PC compatible keyboard emulates the Mac keyboard. Follow this procedure:

1. Bring the KVM focus to the port you want to set.

2. Invoke HSM (see page 11).

3. Press and release the appropriate Function Key (see table below). After completing this
procedure, you will automatically exit HSM.

Function Key Operation

[F2] [Enter] Enables Mac keyboard emulation, See Mac

Keyboard on page 16 for details.
To cancel, press [Scroll Lock] [Scroll Lock]
[F10] [Enter].

[F3] [Enter] Enables Sun keyboard emulation, see Sun

Keyboard on page 17 for details.
To cancel, press [Scroll Lock] [Scroll Lock]
[F10] [Enter].

[F10] [Enter] Automatically detects and sets the keyboard

operating platform.

List Switch Settings

To see a list of the current switch settings, do the following:

1. Open a text editor or word processor, and place the cursor in the page window.

2. Invoke HSM (see page 11).

3. Press [F4] [Enter] to display the settings.

USB Reset

If the USB loses focus and needs to be reset, do the following:

1. Invoke HSM (see page 11).

2. Press [F5] [Enter].

Keyboard Language

To change the keyboard language, do the following:

1. Invoke HSM (see page 11).

2. Press [F6] [nn] [Enter].
Note: nn is a two-digit number that represents the keyboard language code
(US English: 33; French: 08; Japanese: 15).

Restore Default Settings

To reset the GCS1002 / GCS1004 to its default hotkey setting, do the following:

1. Invoke HSM (see page 11).

2. Press [R] [Enter].

See Hotkey Summary Table on the next page.

14

Hotkey Default Settings

After invoking HSM (see page 11), key in one of the following keys to perform the
corresponding function:

Key Function

[X] [Enter] Toggles between the default ([Scroll Lock] [Scroll

Lock]) and alternate ([Ctrl] [Ctrl]) Port Switching
keys.

[K] [Enter] Toggles the KVM focus.

[S] [Enter] Toggles the audio focus.

[A] [Enter] [n] Starts Auto Scan. The KVM focus cycles from

port to port at n second intervals.
Note: Replace n with a number between 1 and 4:

• [1] changes scan interval to 3 seconds

• [2] changes scan interval to 5 seconds (default)

• [3] changes scan interval to 10 seconds

• [4] changes scan interval to 20 seconds

To exit Auto Scan, press [Esc] or [Spacebar].

[D] [Enter] Invokes Video DynaSyncTM, IOGEAR’s exclusive

technology that eliminates boot-up display
problems and optimizes resolution when
switching between ports.

[M] [Enter] Enables / disables mouse emulation.

[W] [Enter] Enables / disables mouse port switching.

[double-click scroll wheel] If mouse port switching is active, double-clicking

the scroll wheel of your USB mouse will switch it
to the next port.

[E] Enables/disables Power On Detection.

[F2] [Enter] Enables Mac keyboard emulation.

[F3] [Enter] Enables Sun keyboard emulation.

[F10] [Enter] Automatically detects and sets the keyboard

operating platform.

[F4] [Enter] Lists the current switch settings via the paste

function of a text editor.

[F5] [Enter] Performs a reset on all USB devices.

[F6] [nn] [Enter] Sets the keyboard language.

Note: nn is a two-digit number that represents
one of the following keyboard language code:
US English: 33; French: 08; Japanese: 15.

[R] [Enter] Resets the hotkey settings to their default status.

15

Keyboard Emulation

Mac Keyboard

The PC compatible (101 / 104 key) keyboard can emulate the functions of the Mac keyboard.
The emulation mappings are listed in the table below

Note: When using key combinations, press and release the rst key (Ctrl), then press and

release the activation key.

16

Sun Keyboard

The PC compatible (101 / 104 key) keyboard can emulate the functions of the Sun keyboard
when the Control key [Ctrl] is used in conjunction with other keys. The corresponding functions
are shown in the table below.

Note: When using key combinations, press and release the rst key [Ctrl], then press and

release the activation key.

17

The Firmware Upgrade Utility

The Windows-based Firmware Upgrade Utility (FWUpgrade.exe) provides a smooth, automated

process for upgrading the KVM switch’s rmware. The Utility comes as part of a Firmware
Upgrade Package that is specic for each device. Check the website regularly to nd the latest

packages and information relating to them at http://www.iogear.com.

Before you begin:

1. From a computer that is not part of your KVM installation go to our Internet support
website (http://www.iogear.com/support/dm) and search the model name that relates to
your device (GCS1002 / GCS1004) to get a list of available Firmware Upgrade Packages.

2. Choose the Firmware Upgrade Package you want to install (usually the most recent), and
download it to your computer.

3. Power off the GCS1002 / GCS1004 and disconnect it from your KVM installation. Connect
the 44-pin connector of the custom KVM cable set to the 44-pin Computer Port 1.

Limited Warranty

4. Press and hold the Port 1 pushbutton on the unit’s front panel. While pressing down on the
Port 1 pushbutton, connect CPU1’s USB Keyboard Type A connector of the custom KVM
cable set to a USB port on your computer.
Note: The Computer Port 1 at the rear panel of the unit is labeled accordingly – use the
cable that is attached to the CPU1 port.

5. Power on the unit, and release the Port 1 pushbutton. Firmware Upgrade mode is in

effect when:

- For GCS1002: The front panel LEDs ashes.

- For GCS1004: The LEDs for Port 3 and Port 4 will stay on, while the LEDs for Port 1
and Port 2 will stay off.

4

4-Port USB DVI KVM Switch

GCS1004

1 2 3 4

5

4

CPU 3 / 4 CPU 1 / 2

3

18

Starting the Upgrade

1. Run the downloaded Firmware Upgrade Package le – either by double clicking the
le icon, or using a command line to enter the full path. The Firmware Upgrade Utility

Welcome screen will appear.

2. Read the License Agreement (click the I Agree button).

3. Click Next. The Firmware Upgrade Utility main screen will appear. The Utility will inspect
your installation. All the devices capable of being upgraded by the package are listed in the
Device List panel.

19

4. As you select a device from the list, its description appears in the Device Description
panel. After you have made your device selection(s), click Next to perform the upgrade.

If you enabled Check
Firmware Version, the Utility
compares the device’s

rmware level with that of
the upgrade les. If the

device’s version is higher
than the upgrade version,
a dialog box gives you
the option to Continue or
Cancel.

If you didn’t enable Check
Firmware Version, the Utility in-

stalls the upgrade les without

checking whether they are a
higher level, or not.

As the Upgrade proceeds status messages appear in the Status Messages panel, and the
progress toward completion is shown on the Progress bar.

Upgrade Successful

After the upgrade has completed, a screen appears to inform you that the procedure was suc­cessful:

Click Finish to close the
Firmware Upgrade Utility.
After a successful
completion, the GCS1002
/ GCS1004 exits Firmware
Upgrade Mode, and resets.

Upgrade Failed

If the Upgrade Successful screen doesn’t appear, it means that the upgrade failed to complete
successfully, in which case you should do the following:

1. Power off the GCS1002 / GCS1004 by removing the power jack.

2. Invoke Firmware Upgrade Mode by holding down the front panel Port 1 pushbutton (see
page 19) and power on the GCS1002 / GCS1004.

- For GCS1002: The front panel LEDs ashes.

- For GCS1004: The LEDs for Port 3 and Port 4 will stay on, while the LEDs for Port 1
and Port 2 will stay off.

3. Follow the rmware upgrade procedure again.

20

Specications

Function GCS1002 GCS1004

Computer Connections 2 4

Console Connections 1 1

Port Selection Hotkey, Mouse switch, Front panel pushbuttons

KB 1 x USB Type A F (Iron)

Video 1 x DVI-D F (White)

Mouse 1 x USB Type A F (Iron)

Speakers 1 x Mini Stereo Jack F (Green)

KB/
Mouse/
Video/
Speakers

1 x 44-pin Connector F

Connectors

Console
Ports

Computer
Port 1

Computer
Port 2

Power N/A 1 x DC Jack

Pushbuttons 2 (Green) 4 (Green)

Cable Length 4ft x 1 (44-pin) 4ft x 1, 6ft x 1 (44-pin)

Power Consumption DC 5.0V, 5.0W DC 5.3V, 5.3W

Emulation KB / Mouse USB

Video 1920 x 1200 @60Hz

Scan Interval 3, 5, 10, 20 seconds (5s default)

Operating Temp. 0-50ºC

Environment

Physical
Properties

Storage Temp. -20-60ºC

Humidity 0-80% RH, Non-condensing

Housing Metal

Weight 0.33kg 0.51kg

Dimensions
(L x W x H)

KB/
Mouse/
Video/
Speakers

N/A 1 x 44-pin Connector F

12.30 x 7.54 x 2.28cm 19.80 x 7.54 x 2.28cm

21

Troubleshooting

Operation problems can be due to a variety of causes. The rst step in solving them is to make

sure that all cables are securely attached and seated completely in their sockets. In addition,

updating the product’s rmware may solve problems that have been discovered and resolved
since the prior version was released. If your product is not running the latest rmware version,

we strongly recommend that you upgrade. See the Firmware Upgrade Utility for details

Symptom Possible Cause Action

Erratic behavior. Unit not receiving

USB devices not
responding.

Cannot switch
ports by pressing
[Scroll Lock]
twice

Monitor does not
display after
KVM
cable set is hot
plugged.

When switching
ports, the
monitor
does not display.

enough power.

Keyboard and/or
mouse need to be
reset.

No connection to the
computer.

KVM switch needs
to be reset.

USB ports need to
be reset.

Keyboard is
incompatible with
Scroll Lock
invocation.

Some graphics
cards are
incompatible with
cable set hot
plugging.

Monitor is new or

this is the rst time

installation.

The monitor’s EDID
has not passed
through to the PC
when switching
ports.

Use a DC 5.3 V power adapter if you are not
already using one. If you are already using a
power adapter, check that it matches the system
specications, and that it is plugged in and func­tioning properly.

Unplug the cable(s) from the console
port(s), then plug it/them back in.

Check the cable from the switch to the computer
to make sure it is properly connected.

Power off all devices on the installation; power off

the KVM switch; wait ve seconds; then power

up.

Unplug the device’s USB cable from
the USB port on the switch’s rear
panel, then plug it back in.

Use the USB Reset hotkey combination (see
page 14), to reset the USB ports.

Switch to the Alternate HSM invocation keys.
See Alternate HSM Invocation Keys, page 12, for
details.

Power off all devices on the installation; power off

the switch; conrm all KVM cables are properly

connected; power on the switch; power on the
computers

Switch ports again and wait two or more sec­onds for the PC’s EDID to pass to the monitor.

Use the [D] hotkey to invoke Video
DynaSync one more time or switch
to another PC to reconnect the switch. See
Hotkey Summary Table, page 15.

22

Federal Communications Commission (FCC) Statement

This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential setting. This product
generates, uses, and can radiate radio frequency energy and, if not installed and used as
directed, it may cause harmful interference to radio communications. Although this product
complies with the limits for a Class B digital device, there is no guarantee that interference
will not occur in a particular installation.

CE Compliance

This device has been tested and found to comply with the following European Union
directives: Electromagnetic Capability (2004/108/EC), Low Voltage (2006/95/EC) and

R&TTED (1999/5/EC).

Limited Warranty

WE’RE HERE TO HELP YOU!
NEED ASSISTANCE SETTING UP THIS PRODUCT?

Make sure you:

1. Visit www.iogear.com for more product information

2. Visit www.iogear.com/support for live help and product support

Warranty Information
This product carries a 3 Year Limited Warranty. For the terms and conditions of this warranty,

please go to http://www.iogear.com/support/warranty

Register online at http://www.iogear.com/register

Important Product Information
Product Model

Serial Number

Contact

IOGEAR

19641 Da Vinci, Foothill Ranch, CA92610
www.iogear.com
iogear.custhelp.com
[e-mail]

23

© 2014 IOGEAR

®
