Silent RGB Case Fan
User Manual‧English
* The Polaris RGB fans cannot operate independently. Make sure
you have the Polaris RGB lighting fan set before attempting to
use this fan.
★ Package Contents
1. Polaris fan x 1
2. Screws x 4
3. 8-8 pin short connecting wire
(connect fan to fan) 100mm x 1
4. 8-8 pin long connecting wire
(connect fan to fan) 800mm x 1
x 1
x 4
x 1
x 1
★ Installation
1. Please make sure the power is off.
2. Install the fans in your PC case, and screw it in the
designated areas.
3. Using 8-8 pin long or short connecting wire to connect
the fan.
Motherboard
FanRGB
★ Troubleshooting
If your fan does not operate properly, please follow the
instructions below:
1. Please check your system’s power.
2. Please make sure all the connectors are connected
properly.
★ Note to use
1. Please install the fan by following our instructions.
2. When storing the fan, please keep this product away
from high temperatures. Keep away from machines
such as heaters that might cause high temperatures.
3. Please do not put anything in the impeller.
4. Please do not modify the wire or the connector
provided by In Win.
5. Please only use your fan in the computer case.
6. Please keep this product away from any liquid.
Polaris RGB
★ Specifications
Product Name
Fan Size
Material
Starting Voltage
Fan Rated Voltage
Polaris RGB
120 x 120 x 25mm
PBT, PC
5V
12V
Fan Rated Power
Fan Rated Current
RGB LED Rated Voltage
RGB LED Rated Power
RGB LED Rated Current
1.2W
0.10A
12V
1.2W
0.10A
Speed Mode
Air Flow
Air Pressure
Noise Level
Bearing Type
500~1280R.P.M
43.31CFM
1.26mm/H2O
20.2dB(A)
Sleeve Bearing
Life Expectation
Warranty
35,000 hrs/ 25℃
2 years
Polaris RGB Aluminium
★ Specifications
Product Name
Fan Size
Material
Starting Voltage
Fan Rated Voltage
Polaris RGB Aluminium
120 x 120 x 25mm
PBT, PC, Aluminium
5V
12V
Fan Rated Power
Fan Rated Current
RGB LED Rated Voltage
RGB LED Rated Power
RGB LED Rated Current
1.2W
0.10A
12V
1.2W
0.10A
Speed Mode
Air Flow
Air Pressure
Noise Level
Bearing Type
500~1280R.P.M
43.31CFM
1.26mm/H2O
20.2dB(A)
Fluid Dynamic Bearing (FDB)
Life Expectation
Warranty
60,000 hrs/ 40℃
5 years
Silent RGB Case Fan
