Outdoor
Outdoor
Outdoor
Outdoor LED
1. Size: 57*33.5*27.3cm
2. Weight: 18.5KG
3. Power input: AC100-240V/50-60HZ
4. Wattage: 225W
5. LEDs: 15*tri-15W
6. IP65
7. LED display for easier operation.
8. Built-in Programs, Auto Running, DMX Mode, M/S Mode
9. DMX Channels: 1, 3, 4, 6DMX channels mode.
This product has many effect programs with simplicity of operation. There are four working modes:
� Built-in Program
� Auto Running
� DMX Mode
� M/S Mode
1.
BUILT-IN
1.
BUILT-IN
1.
1. BUILT-IN
BUILT-IN PROGRAM
1) Press MODE button to select the program “ Pr.XX ”
2) Press UP or DOWN button to select the effect programs from Pr.01~Pr.10.
Press SETUP button to edit the static color when the display board shows Pr.01, then press UP or DOWN button to
select the seven built-in static colors(1.-r ； 2.-rg ； 3.-g ； 4.-gb ； 5.-b ； 6.-rb ； 7.rgb). Press SETUP button to adjust
the brightness of red, green and blue through UP or DOWN button when it shows 7.rgb. Press SETUP button again
could set up the strobe “ FSxx ” for the color that is chose, and press UP or DOWN button to adjust the strobe speed
from FS00~FS99.
PROGRAM
PROGRAM
PROGRAM
LED
LED
LED Flood
Flood
Flood
Flood Light,
Light,
Light,
Light, 15*tri-15W
15*tri-15W
15*tri-15W
15*tri-15W
When the display board shows Pr.02~Pr.10, the first time to press SETUP button, it will show “ SP.XX ” , the
program running speed could be adjusted through UP or DOWN button from SP01~SP100 (FL). The second time
to press SETUP button, it will show “ FSxx ” , the strobe speed could be adjusted through UP or DOWN button from
FS00~FS99.
2.
AUTO
2.
AUTO
2.
2. AUTO
AUTO RUNNING
Press MODE button to enter into Auto Running mode “ AUTO ” , the fixture will run the built-in program from
Pr.02~Pr.10 automatically. The running and strobe speed of each program from Pr.02~Pr.10 could be set up, and the
preset effect will run sequentially under the mode of Auto Running.
3.
DMX
3.
DMX
3.
3. DMX
DMX MODE
1) Press MODE button to enter into the DMX Mode “ d.XXX ” .
2) Press UP or DOWN button to set the DMX address d.001~d.512.
3) Press SETUP button to enter into DMX working mode menu X-ch.
4) Press UP or DOWN button to set the DMX working mode, there are four modes: 1-ch ， 3-ch ， 4-ch ， 6-ch
RUNNING
RUNNING
RUNNING
MODE
MODE
MODE
Page 3
DMX
Mode1:
DMX
Mode1:
DMX
DMX Mode1:
Mode1: 1-ch
DMX
Mode2:
DMX
Mode2:
DMX
DMX Mode2:
Mode2: 3-ch
CHANNEL VALUE FUNCTION
CH1 0-255 RED
CH2 0-255 GREEN
CH3 0-255
1-ch
1-ch
1-ch
CH1
NO. DMX value FUNCTION
1 0 No use
2 1-22 Red
3 23-45 Green
4 46-68 Blue
5 69-91 Cyan
6 92-114 Yellow
7 115-137 Orange
8 138-160 Pink
9 161-183 Purple
10 184-206 Dark Blue
11 207-229 Light Green
12 230-252 White
13 253-255 Warm White
3-ch
3-ch
3-ch
BLUE
DMX
Mode3:
DMX
Mode3:
DMX
DMX Mode3:
Mode3: 4-ch
CHANNEL VALUE FUNCTION
DMX
Mode
DMX
Mode
DMX
DMX Mode
Mode 4:
CHANNEL VALUE FUNCTION
CH1 0-255 General Dimming
CH2
4-ch
4-ch
4-ch
CH1 0-255 MASTER DIMMER
CH2 0-255 RED
CH3 0-255
CH4 0-255
4:
6-ch
4:
4: 6-ch
6CHs
6-ch
6CHs
6-ch （ 6CHs
6CHs ）
Red Dimming 0-255 Red Dimming 0-255
Selection of Static Colors (it is
in valid while 6CH is 0~25)
0-8 R(255)
9-17 R(255) G(50)
18-26 R(255) G(150)
27-35 R(255) G(255)
36-44 R(200) G(255)
45-53 R(100) G(255)
54-62 R(40) G(255)
63-71 G(255)
GREEN
BLUE
Page 4
72-80 G(255) B(50)
81-89 G(255) B(150)
90-98 G(255) B(255)
99-107 G(150) B(255)
108-116 G(50) B(255)
117-125 B(255)
126-134 R(50) B(255)
135-143 R(150) B(250)
144-152 R(255) B(255)
153-161 R(220) B(50)
162-170 R(150) G(50) B(100)
171-179 R(50) G(180) B(220)
180-188 R(50) G(220) B(100)
189-197 R(150) G(220)
198-206 R(150) B(220)
207-215 G(180) B(220)
216-224 G(220) B(50)
225-233 R(220) G(100) B(50)
CH3
CH4
CH5
CH6
Speed Adjustment (control the
program speed of CH6
(26-255))
0-255
0-255
0-9 NO FUNCTION
10-255 STROBE Slow-Fast
0-25 29 static colors could be selected
26-51 Pr02 (7 colors’gradual changing)
52-77 Pr03 （ 3 colors ’ gradual changing ）
78-103 Pr04 （ 7 colors flickering ）
104-129 Pr05 （ 3 colors flickering ）
130-155 Pr06 （ illusion 1 ）
156-181 Pr07 （ illusion 2 ）
182-207 Pr08 （ red gradual changing ）
208-233 Pr09 （ green gradual changing ）
234-255 Pr10 （ blue gradual changing ）
234-242 R(220) G(200) B(100)
243-251 R(255) G(200) B(150)
252-255 R(255) G(255) B(255)
0-255 0 — 255 Slow-Fast
Green Dimming 0-255
Blue Dimming 0-255
through 2CH
4.
M/S
4.
4.
4. M/S
MODE
M/S
MODE
M/S MODE
MODE
Press MODE button to enter into M/S Mode “ SLAV ” .
Page 5
REMARK
REMARK
REMARK
REMARK
1. If no touch be pressed within 20 seconds, the display board will be turned off, if presses any button at this time,
the display board will regain the original status, all the buttons will regain their own functions.
2. This fixture has the self-protection function against the excess temperature. The system will adjust the service
power automatically according to the heat dissipation of the fixture while the user makes all the LEDs worked for a
long time, please keep the surroundings ventilated under this working condition.
3. The display board will show the system’s version after the fixture is turned on, such as V1.0, after 2 seconds it
will work according to the preset modes.
