INVISIO S10
Lightweight Hearing Protection System
INVISIO S10 is an in-ear hearing protection headset with
electronic situational awareness and impulse noise protection. It is
connected directly to a radio.
The system consists of an in ear hearing protection headset with
a cable mounted control unit housing the electronics for situational
awareness and impulse noise protection.
The control unit includes situational awareness electronics, on/off
switch and an AA battery to power the system. As radio communication is separate from situational awareness, radio communication is
still possible even if the battery is fully discharged or removed. The
situational awareness turns on/off automatically with the radio. It
can also be manually turned on/ off as desired by pressing the on/
off button.
The INVISIO S10 (including the battery) has a combined weight of only
150 grams. The control unit has the same width as a credit card and
only 3/4 of the length. Overall cable lengths have been optimised to
ensure efcient cable management on the soldier.
The INVISIO S10 is optimised for use with Selex PRR / EZ PRR
With the use of adapter cables the INVISIO S10 can support the
use of other tactical radios (including the Thales MBITR series and
HARRIS Falcon II and III series), and intercom systems on land and
air platforms such as ROVIS, SOTAS, VIC-3.
• Industry leading levels of hearing protection (SNR32 dB) and full
situational awareness.
• Crystal clear communication even in high noise conditions.
• Supports existing radio functionality.
• Compatible with helmets, gas masks and circumaural headsets.
• Unique headset design with INVISIO soft spring for secure t and
comfort with all day use.
Radio communication and transmission is controlled by the radio.
Examples of radio functionality supported by the INVISIO S10 are
transmission using a wireless remote PTT, radio side-tone, warning
tones from either primary or secondary radio, dual com (primary and
secondary radio simultaneously),full duplex (primary radio and
vehicle intercom system), as well as older radio types.
The radio signal is received in the left ear and transmission is
picked-up in the right ear. Cross talk between encrypted secondary
radio and primary radio is eliminated by separating the Rx from the
secondary radio and the Tx from the primary radio.
Overview
Hearing protection headset with situational awareness
Situational Awareness
360° unimpeded awareness
System Size and Weight
Reducing the burden
Key Features
INVISIO Bone Conduction Technology
Radio Communication
Open microphone
Direct Radio Connect
Optimised for use with SELEX PRR
2
INVISIO S10 / Hearing Protection Headset with Hear-Thru
Page 3
The gure above illustrates the different components in the headset system, along with the radio. The headset is hard wired without the need
for connectors into the control unit which houses the hear-thru electronics and power supply. A short cable with the radio connector is also
hard wired into the control unit, creating a trouble free solution that easily mounts on the soldier. The images below illustrate the INVISIO S10
mounted on the Selex PRR / EZ PRR. It has been designed to ensure that no additional space is required on the soldier.
INVISIO S10
Product System Diagram
Selex PRR
Radio
Hear-Thru
ON/OFF
S10 Control Unit
Internal
AA Battery
X5 Headset
Secondary Radio
via Selex PRR
Other Communication Device
via Adapter Cable
3
INVISIO S10 / Hearing Protection Headset with Hear-Thru
Page 4
Control Unit Dimensions
INVISIO S10 is an in-ear hearing protection and communication system for use on a single radio and includes electronic situational awareness and impulse noise protection.
The system consists of an in-ear hearing protection headset
with a cable mounted control unit housing the electronics for
situational awareness and impulse noise protection.
The radio remains as the push-to-talk and only situational
awareness is controlled by the INVISIO S10 control unit.
INVISIO S10 Overview
AA Battery
Compartment
Headset
Hear-thru On/Off
Radio
4
INVISIO S10 / Hearing Protection Headset with Hear-Thru
Page 5
Technical Specications
INVISIO Communications A/S
Stamholmen 157, 2650 Hvidovre, Denmark
Tel: +45 7240 5500
Fax: +45 7240 5501
www.invisio.com
© 2013 INVISIO Communications A/S. All rights reserved.
Specications are subject to change without notice.
The Soft Spring™ system and Bone Conduction Microphone Technology
are patents of INVISIO Communications A/S.
INVISIO® is a registered trademark of INVISIO Communications A/S.
INVISIO S10 (GDO12564-6)
Headset
Colour Black
Material Plastic
Conguration Dual
Weight 5 grams
Dimensions W 13.0 x H 11.0 x L 24.0 mm
Wearing Style In-ear with Soft Spring™
Control Unit
Colour Black
Material Aluminium
System Weight 151 grams (Lithium battery)
Dimensions L 65.0 x W 57.5 x H 20 mm
Cable
Colour Black
Length Headset 1150 mm and radio 200 mm
Pull Strength 20 kg
Connector ODU Push-Pull (Quick Disconnect)
Number of matings > 5000 times
Box Contents
Headset system
including headset, control unit and integrated radio cable (x1)
Cerumen Stick
for removal of ear wax from headset speaker outlet (x1)
Wind protection foam tips (x9)
User manual (x1)
Velcro strap (x3)
Packaging box (x1)
Headset Hearing Protection
SNR 32 (EN352-2:2002)
NRR 29 (ANSI S3.19-1974)
Test results (ANSI S12.6-1997)
Frequency (Hz) 125 250 500 1000 2000 4000 8000
Average Attenuation (dB) 32.1 34.2 35.9 36.7 38.7 43.5 45.9
These results have been obtained and certied at a certied test institute ref. ANSI S3.19-1974.
This is in compliance with MIL-STD-1474D Appendix B Hearing Protector Noise Attenuation.
CE Personal Protection Equipment.
Power Supply
Power Consumption 60 mA
Power Supply Replaceable AA battery
Operating Time 50 hours (Lithium battery 3000mAh)
Environmental
Tested to MIL-STD-810G Immersion 2 meters for 2 hours
Operating Temperature -40 to +63°C (Lithium battery)
Storage Temperature -40 to +63°C (Lithium battery)
Humidity MIL-STD-810G
Mechanical Drop MIL-STD 810G
Specications with Alkaline Battery
Operating Time 42 hours (Alkaline battery 2500mAh)
System Weight 159 grams (Alkaline battery)
Operating Temperature -15 to +55°C (Alkaline battery)
Storage Temperature -15 to +55°C (Alkaline battery)
Test results (ANSI S12.6-1997)
5
INVISIO S10 / Hearing Protection Headset with Hear-Thru
