InVid PAR-ALLBSS23 Specsheet
PAR-ALLBSS 2 Megapixel All-in-One Outdoor Stainless Steel Mini
Bullet, Fixed Lens, 12VDC
Features
• 2 Megapixel 1080p (TVI/AHD/CVI) Resolution
• All-in-One Technology (TVI/AHD/CVI/Analog 960h)
• Fixed Lens
• True Day/Night
• Up The Cable (UTC) Function
• Stainless Steel Housing (Grade Steel | AISI 316)
• IP68 Waterproof
• OSD Remote on Detachable Cable
• 12VDC Only Operation
Model PAR-ALLBSS23
Image Sensor 1/2.9” Sony Exmor CMOS image sensor
Active Pixel 1920(H) x 1080(V)
Resolution 1080p@30fps/1080p@25fps
Min. Illumination
Scanning System Progressive
Video Output
S/N Ratio More than 50dB (AGC o)
AGC O/0 - 15
Shutter Speed AUTO/MANUAL(1/50(60) ~ 1/50,000 sec)
SENS-UP O/X2 – X30
Brightness 0 - 100
Backlight O/BLC/HSBLC
D-WDR O/0 ~ 8
Defog O/Auto
Day & Night Auto/Color/B&W/EXTERN
White Balance ATW/AWC/INDDOR/OUTDOOR/Manual/AWB
DNR O/Low/Middle/High
Mirror O/MIRROR/V-FLIP/ROTATE
Sharpness 0 -10 steps
Privacy Mask 4 Masks
Motion Detection O/On
Language
Housing IP68 Waterproof, Grade Steel | AISI 316
Power Source DC12V ±10%
Power Consumption Max 4.0 Watt at
Operating Temperature -4° ~ 140°F (-20° ~ 60℃)
Operating Humidity 10% to 85%
Lens 2.3mm Megapixel lens
Dimension Φ x L Φ1.92 x 4.29 inches (Φ49 x109mm)
Weight 1.19lb (540g) Approx
Color : 1.0 lux, BW : 0.5 lux
Color DSS : 0.002 lux, BW DSS : 0.0008 lux
Universal AHD, CVI, TVI : 1080P
Analog: NTSC/ PAL CVBS
English/Chinese/Germany/French/Italian
Spanish/Polish/Russian/Portuguese/Dutch/Turkish
Ordering Information
PAR-ALLBSS23: SS 2 Megapixel Mini Bullet, 2.3mm
InVid Tech, reserves the right to make changes to improve our products at any time without notice; we are not responsible for misprints.
Innovative Video Technology 355 Oser Avenue, Hauppauge, NY 11788 | 631-388-5700 | sales@invidtech.com | www.invidtech.com
