Digital
Terrestrial Receiver
IDL 1000 T
Manual
Detailed Table of Contents 2
1. Safety Precautions 3
2. Control elements and connections 4
3. Remote Control 5
4. Connecting and operating the receiver 6
5. Trouble-shooting 12
Technical data 13
Index (A-Z) 15
Table of Contents
1. Safety Precautions .........................................................................................................
2. Control elements and connections ..............................................................................
3. Remote Control ..............................................................................................................
4. Connecting and operating the receiver .......................................................................
4.1 Connections ..............................................................................................................................
4.2 On/Off switch ...........................................................................................................................
4.3 Programme selection ..............................................................................................................
4.4 Subtitling activation .....…………............................................................................................
4.5 Zapping ....................................................................................................................................
4.6 Teletext …..…............................................................................................................................
4.7 Calling up the Main Menu ......................................................................................................
4.8 Programme Search .................................................................................................................
4.9 Product Information …............................................................................................................
4.10 Software download ...............................................................................................................
4.11 Personal planner ....................................................................................................................
4.12 Default settings ..………………………...................................................................................
5. Trouble-shooting ............................................................................................................
Technical Data
Index (A-Z 40)
3
4
5
6
6
6
7
7
8
8
9
10
10
10
11
11
12
13
15
2
1. Safety Precautions
This set-top box has been manufactured in accordance with international safety standards.
For your own safety, youshould read the notes on safety precautions carefully, and take note
of them, before operating your new receiver.
For your own safety, please be sure to follow these safety precautions:
Mains power supply: Connect the unit only to a mains power supply that has the following characteristics:
90-260 V AC, 50-60 Hz
Connection to the TV set and video recorder: Here, too, the receiver must be disconnected from the
mains power supply before using a Scart cable to establish connections to the TV set and video recorder.
Optimum location: Set up your digital receiver indoors, in an area where it is protected from lightning,
rain water and direct sunshine. Ensure a minimum distance of 5 cm around the apparatus for sufficient
ventilation. Ensure that the ventilation is not impeded by covering the ventilation openings with items, such
as newspapers, table-cloths, curtains, etc… Do not place naked flame sources, such as lighted candles
on the apparatus. Do not expose the apparatus to dripping or splashing. Do not place objects filled with
liquids, such as vases on the apparatus.
Do not open the unit: Never open the casing, as you are in danger of electrocution!
Protect from humidity: Ensure that no humidity, dampness or liquid can get into the unit. You should
therefore also not position any liquids near the receiver. Do not use any liquid detergents, as these may
damage the unit, and may subject you to high-voltage shock.
Prevent intrusion of foreign matter: The receiver is fitted with small ventilation slits on the top and along
the sides to assist in circulating air. Small objects could fall into these slits, so please do not put any objects
on top of the receiver.
Ensure adequate ventilation: Never cover the ventilation slits on the unit casing. When in operation, the
digital receiver should be placed on a straight and solid base. It should not be placed in direct sunshine
nor too close to a heater or radiator. Ensure there is sufficient free space around the unit for free air
circulation. Use the apparatus only in moderate climates (not in tropical climates).
Protection from lightning: In case of thunderstorms, switch off the receiver, disconnect from the main
power supply, and disconnect the antenna cable from the unit. This will prevent your appliances being
damaged when there is a thunderstorm in your area.
Use only original parts and accessories: Use only original parts, or parts recommended by a specialist
retailer, as other parts may cause damage to the appliance, or bear the risk of personal injury. Nonobservance of this warning cancels the unit guarantee. Any repairs should only be carried out by qualified
specialist personnel. Take attention to the environmental aspects of battery disposal.
Disconnecting power during extended absence: If the appliance is to be unattended for an extended
period of time, e.g. when you go on holidays, you should disconnect it completely from the mains
power supply.
Retain original packaging material: Please retain the original packaging, should it be necessary at some
stage to return the unit.
The manufacturer undertakes no responsibility for damage or injury caused by non-observance
of these safety precautions, or by inappropriate handling of the appliance.
3
2. Control elements and connections
View of the front panel
1
2
Control elements on the front panel Connections on the rear panel
Infra-red sensor (Remote Control)
1.
Receives signals from the remote control unit
On/Off Led
2.
Indicates if the receiver is On or Off
View of the rear panel
VCR Scart
1.
Facility for connecting a video recorder
TV Scart
2.
For connection to TV set
ANTENNA IN
3.
Terrestrial antenna input
RF LOOP OUT
4.
Output of the terrestrial antenna signal -UHF
channel for connection to the TV
Mains power connection
5.
For connecting to domestic power supply
(cable supplied)
4
3. Remote Control
Function keys on the remote control unit
The keys on the remote control can be divided into groups:
- Function keys that directly control a specific function
(these keys have a double functionality according to the situation)
- Navigation keys
- Numeric keys 0-9
Mute
Muting the loudspeakers (on/off)
Guide
Activates the TV guide
Guide
FavSub
On/Off (Standby)
Switching the receiver on and off
Teletext
This calls up the built-in teletext
decoder when available (only
operational on TV programmes
Ch+ (Channel Up)
providing teletext or videotext)
Zapping to the next channel
Subtitles A/B
Red function key
Activates the subtitles
Special function in interactive TV
applications on-screen displays
Navigation (direction) keys
Used for navigating in the on-screen
displays (right, left, up, down)
OK / Menu
Confirming a selection, calling up
the Main Menu
Yellow function key
Special function in interactive TV
applications on-screen displays
Personal Planner
Activates the Personal Planner
Menu
i
Exit
Numeric keys 0-9
Ch- (Channel Down)
Zapping to the previous channel
Green function key
Special function in interactive TV
applications on-screen displays
Blue/Information function key
Details about the active channel or
special function in interactive TV
applications on-screen displays
Exit
Quick exit from a menu page
Batteries:
Batteries are required to operate the remote control unit (supplied with unit) To insert the batteries, open the
battery compartment cover on the rear of the remote control unit, insert the batteries (AA size, 2 x 1.5 Volt),
and replace the compartment cover.
Spent batteries should not be discarded in your domestic refuse. In most countries, you are legally obliged
to ensure spent batteries are properly recycled. They can be disposed of either in special bins provided in
your community, or may be returned to any retailer who sells batteries.
5
4. Connecting and operating the receiver
4.1 Connections
Your digital receiver provides a multitude of possible connections to other appliances. Here we list the
most important options available.
4.1.1 Connection to the terrestrial antenna
The digital receiver is connected directly to a terrestrial antenna on the ANTENNA IN connector (see page
4, connections on the rear panel item 3). , by means of a coaxial cable. This connection must be done
while the receiver is switched off.
4.1.2 Connection to the TV set
Digital receivers and TV sets are usually connected by means of a Scart cable. Simply connect the two
ends of the cable with the main socket on the TV set and with the TV socket on the receiver, respectively.
The Scart connection ensures that audio and video signals are transmitted to the TV set in optimum quality.
4.1.3 Connection to a video recorder
Just as the TV set, the video recorder is connected to the receiver via a Scart connection. Use the “VCR“
socket for this purpose.
4.2 On/Off switch
Press the On/Off key (Standby), on the remote control. The receiver is now ready for operation. Now switch
on your TV set, if it is not already switched on, and set it to an “AV“ programme slot (“EXT“,”AV“, “External
Source“, or similar).
When you have completed connecting the digital receiver to the terrestrial antenna and the TV set, as well
as to the video recorder where applicable, you can now proceed to switch it on for the first time. In order
to do this, press the On/Off (Standby) key on the remote control. The receiver will now be switched on.
The receiver is now ready for operation.
To switch the unit off, press the Standby key.
6
4.3 Programme selection
4.3.1 Using the directional Up/Down or Ch+/Ch- keys
You can move up or down the programme list one slot at a time by using the two
Ch+/Ch- or Up/Down keys on the remote control unit. When an interactive TV application is
active, only the Ch+/Ch- keys do allow zapping as the Up/Down keys can have another
functionality within the interactive-TV application.
A screen with the information about the current selected channel
is appearing then. This information screen can also be activated
by pressing the right key.
4.3.2 Using the numeric keys
If you want to select a programme directly, and you know its
programme number, then it is easiest to enter the programme
by means of the numeric keys. As the receiver is equipped to
store many programmes, the programme number might have
two digits. However, you can also enter a number consisting
of only one digit.
2
07:00-09:00 YLEQ:n piv
YLEQ
09:00-09:59 Lounas kuussa
08:16
Move i Info √ set Reminder
4.3.3 Using the programme list
Press the “Guide” key on the remote control or select the option
“TV Guide” in the Main Menu; a programme list will now be
displayed on-screen.
Use the Up/Down directional keys to navigate through this list
one programme slot at a time, backward or forward.
Press the “OK/Menu“ key to view the selected programme.
4.4 Subtitling activation
Some TV broadcasters provide subtitles, carrying commentary
in various European languages, to accompany the TV image.
To use this facility, press the “Sub“ key. It either activates or
deactivates the subtitling.
Warning: If this function is deactivated in the settings part of
the receiver, the “Sub” key is disabled.
Channel Time Program Wed May 22nd
1 BBC ONE No Program Information Available
No Synopsis Available
2 BBC TWO
3 ITV 1
4 Channel 4
5 fiva
6 ITV 2
7 BBC THREE
9 Teletext
10 BBC FOUR
11 Sye Travel
12 UKHistory
01:03 Wed May 22nd
Move Channel Fav On √ select Exit
TV GUIDE
No Program Information Available
No Program Information Available
No Program Information Available
No Program Information Available
No Program Information Available
No Program Information Available
No Program Information Available
No Program Information Available
No Program Information Available
No Program Information Available
Menu
7
4.5 Zapping
Various options exist to facilitate quick switching between programmes:
a) Fast zapping using the directional keys Ch+/Ch- and Up/Down:
Press the directional Ch+ or Up key to select the next higher programme in the
programme list and the directional key Ch- or Down to select the next lower
programme in the list.
b) Direct selection using the numeric keys:
As soon as a numeric key has been pressed, a small display field appears on
screen, which will display the selected channel number. A channel number may
consist of up to two digits. After a digit has been entered, the receiver will wait to
see whether any more digits are going to be entered. If no additional digits are
Menu
entered, the receiver will switch to the programme slot selected.
Example 1: You wish to select channel 1
Press “1“ on the remote control
The receiver will wait for 1 second to find out
whether any more digits are to be entered
The receiver will then switch to channel 1
Example 2: You wish to select channel 12
Enter “1“ on the remote control, followed by
“2“ within no more than 1 second of the first digit
The receiver will wait for 1 second to find out
whether any more digits are to be entered
The receiver will then switch to channel 12.
4.6 Teletext
The teletext or videotext feature
familiar from analogue TV
programmes is also broadcast on many digital
TV programmes. The digital receiver is
equipped to decode the teletext/video text
signal internally, and to display it on the
TV screen.
Press the ”Teletext“ key to display the videotext or teletext of the programme currently being viewed.
The teletext/video text will be displayed as an overlay on the screen over the current TV image.
In order to view a specific page of teletext/video text, use the numeric keys to enter the three-digit page
number. The receiver is capable of storing a large number of videotext pages in a temporary memory,
which reduces waiting times when calling up a new page. Enter “100“ at any time to return to the home
page of the teletext/video text pages of the TV programme being viewed.
You may use the directional keys Up/Down to page quickly through the complete teletext/video text section
of a particular TV programme. The benefit of the temporary page storage function is of particular benefit
when using this function for fast page scanning.
8
4.7 Calling up the Main Menu
The receiver can now be individually configured, using the
on-screen menu display.
Press the ”OK/Menu“ key on the remote control. The Main
Menu will be displayed.
Now use the directional keys to select the line “Settings“,
and confirm by pressing the “OK/Menu“ key.
In the sub-menu “Settings“ select the entry “Audio/Video
Settings“, and confirm by pressing the “OK/Menu“ key.
Navigation on this page is exclusively done by using the
Up/Down directional keys, and options are scrolled over
with the Left/Right navigation keys.
4.7.1 Screen Size
Main Menu
1 TV Guide
2 Personal Planner
3 Settings
4 Default Settings
5 Exit
Program Information...
01:03 Wed May 22nd
Move √ select Exit
Size 4:3 or 16:9 can be selected.
4.7.2 TV Scart
The format of the signal on the TV Scart can be chosen
here. The options are CVBS, RGB, S-Video.
Audio / Video Settings
1 Screen Size
2 TV SCART
3 Store & Exit
Swich Between 4:3 and 16:9 Ratios
07:50 Tue Feb 25th
Move √ select Exit
4:3
CVBS
9
4.8 Programme Search
Using the “OK/Menu“ key, call up the Main
Menu, select the sub-menu “Channel Search“ and an
automated channel search process starts.
4.9 Product information
In the last category of the Settings display you will find
detailed technical information relating to the product.
These might be relevant for the after sales services.
Especially, the SW built date can be seen in this information
window.
The sub-display “Product Information“ provides you with all
data relating to the hardware and software of the receiver.
Each unit has an own unique serial number (Product ID).
When making service calls it is important to specify the
hardware version applicable, as the technician then knows
exactly which components, circuit boards, etc. have been
used in the unit.
4.10 Software Download
The receiver software can be updated via the antenna and
can thus be kept up to date at all times.
How to start a Software Update:
to call up the Main Menu, then select “Settings“. Here you
should select the sub-display “Software Download“.
Now, either you choose the Auto mode, select option 6
“Start Scan” and press the OK/menu to start the update
process or you fill all the technical information about the
transponder in your country and press the OK/menu with
“Start Scan” selected to start the Software Update process.
Please contact your local retailer for obtaining the technical
details of the transponder in your country if the Auto Mode
is not working.
Press the OK/Menu key
Settings
1 User Preferences
2 Channel Search
3 Audio / Video Settings
4 Pi S
Searching for channels
Please Wait...
5 Se d
6 Pn en
7 Exit
Scan for Channels
01:16 Wed May 22nd
Move √ select Exit
10%
Product Information
1 Product Id
2 Serial Number
3 Software Version
4 Hardware Version
5 Software Build Date
6 Bootloader Version
7 Exit
08:03 Tue Feb 25th
Move √ select Exit
1319A2
1234567890
2.4
1
Jul/03
1.12
Software Download
1 Auto Mode
2 Channel Number
3 Frequency (Hz)
4 FFT Mode
5 Guard Interval
6 Start Scan
7 Exit
Set to on for automatic search for software updates
08:03 Tue Feb 25th
Move √ select Exit
10
4.11. Personal planner
This personal planner function allows defining events and
reminders. The receivers will zap then automatically to these
events or remind them to you.
To activate it, select “Personal Planner” from the Main Menu.
Select first a date, during which you want to set an event
and press the blue information key to add a reminder event
and then follow the instruction in the information bar at the
bottom of the screen.
Press the “OK/Menu” key on the current date (highlighted
in blue to define an event for today. The TV guide list appears
then; it is possible to toggle between the Main and favourite
list using the yellow function key. Details of a channel can
be seen with the red key. Press finally select to define an
event.
4.12. Default settings
A reset function is provided to return the receiver to all the
default settings programmed at the factory before delivery
to the customer. This deletes all subsequent programming
commands, and means that you have to start again with
the installation procedure.
A reset always makes sense when a large number of settings
have accidentally been made incorrectly or in error.
In order to proceed with a reset, press the “OK/Menu“ key
to call up the Main Menu. Select the entry “Default Settings“
and press the “OK/Menu“ key to confirm your selection.
In the next display, you will be given the option of pressing
the Select function key to confirm the selection, or the Exit
function key to abandon the reset and return to the Main
Menu.
Please note: if you press the select function key at this
stage in order to start the reset procedure, all individual
settings relating, e.g. to antenna configuration, channel
list, sorting of channels, etc., will be lost permanently!
Personal Planner
Wed May 22nd 2002
Sun Mon Tue Wed Thu Eri Sat
1 2 3 4
5 6 7 8 9 10 11
12 13 14 15 16 17 18
19 20 21 22 23 24 25
26 27 28 29 30 31
01:13 Wed May 22nd
Move Month- Month+ i Reorder √ select
Exit
Personal Planner
Wed May 22nd 2002
Sun Mon Tue Wed Thu Eri Sat
01:05
Use the numbered keys and LEFT and RIGHT for text input.
Use UP and DOWN to select annual or normal reminders.
Delet Insert Lower i Cancal
01:07 Wed May 22nd
Move Month- Month+ i Reorder √ select
Add a new reminder Daily
Press ‘Select’ to enter.
Exit
Main Menu
1 TV Guide
2 Personal Planner
3 Settings
Restore Factory Defaults ?
6 Default Settings
√ select Exit- Cancel
7 Exit
Revert to Factory Defaults
01:03 Wed May 22nd
Move √ select Exit
11
5. Trouble-shooting
Problem Possible cause Solution
No box reaction
No sound, no picture
Mains power cable not connected
to mains
antenna may not be correctly
connected.
Check mains cable and plug
Connect the antenna to the right
connector.
Sound OK, no picture
Remote control no longer
functioning
No sound or picture in case of
programmes that have worked
previously
Temporary picture and sound
problems
(square blocks in picture, or
picture frozen, gaps in sound)
Forgot PIN Incorrect code entered Contact your nearest retailer
If it becomes necessary to return the receiver for repairs, please use the original packaging if possible,
and return the receiver complete with all accessories.
Please include a copy of the original sales receipt, as well as a detailed description of the problem.
Scart cable defective, or not
connected properly at socket
Radio operation selected
Batteries spent
Batteries inserted incorrectly
Antenna has be disconnected
Programme has switched to
different transponder
Programme no longer broadcast
Antenna too small
Check Scart connection
Switch back to TV operation
Insert new batteries
Insert batteries in correct position
Adjust the antenna connection
Initiate new programme search
Delete programme from list
Set up larger antenna
12
Technical Data
OSD
OSD / Languages
Front Panel
Display
Control
Front end (RF Input)
Input Connector
Loop-through Output Connector
Input Frequency Range
Input Impedance
Input Signal Level
Bandwith
Modulation type
FFT mode
Constellation
Inner Coding Rate
MPEG and A/V Decoding
Video Decoding
Aspect Ratio
Video Resolution
Audio Decoding
Sampling Frequencies
A/V & Data In / Out
TV Scart Output
VCR Scart Output
VCR Scart Input
OSD with guiding menu for installation and information,Control – Delete
and Edit function.
Led On/Off
IR Sensor
1 x IEC 169-2 Female
1 x F-type
47-862 MHz
75 Ohms
-90 to –20 dBm
7 or 8 MHz
COFDM
2 k, 8 k
QPSK, 16 QAM, 64 QAM
1/4, 2/3, 3/4, 5/6, 7/8
According to MPEG-2 MP@ML - MPEG-1 ISO/IEC 1172-2
4:3, 16:9, automatic adjustment for 16:9 TV sets, Letter box filtering
720 x 576 (Pal)
MPEG _ Audio layer 1 and 2
16 kHz, 22.0516 kHz, 24 kHz, 32 kHz, 44.1 kHz, 44 kHz, 48 kHz,....88.2
kHz, 96 kHz
CVBS, RGB, L & R Audio
CVBS , L & R audio
Input CVBS, L & R audio
13
CPU & Memory Channels
Main Processor
Flash Memory
SDRAM
Channel Scan
Channel Memories
Remote Control
Operating Frequency / Distance
Code
Power Supply
Input Voltages
Physical Specifications
Size (WxDxH), Weight
Operating & Storage Temp
Special Features
Software update via Antenna
MHEG 5
Technical changes possible
Developed in Germany
32 Bits host CPU @ 81 MHz
2 Mbyte
16 Mbytes
Automated for all DVB programs, semi-automated or manual
999 channels, Last Station Memory
36 kHz, / 10 Meters max
RC 5
Internal: 95-250 Volt – AC – 50-60 Hz
315 x 152,5 x 60,8 mm. Weight: 2.2 Kg Net
5° to 40°C / -20°C to +65°C
Yes
Yes
14
Index (A-Z)
A
Antenna 6
Audio/Video Settings 9
B
Batteries 5
C
Channel Search 10
Connections 4
Control elements 4
D
Default Settings 11
F
Frequency 13
Function keys 5
M
Main Menu 9
Mute 5
O
On/Off switch 6
Operating the receiver 6
P
Programme Search 10
Programme selection 7
R
Remote Control 5
Reset 11
S
Safety Precautions 3
Software Download 10
Switch off 6
T
Technical Data 13
Trouble-shooting 12
TV set 3,6
V
Video recorder 4,6
Z
Zapping 8
15
Loading...
