Inventec DMP3000 Users Manual

Download

MediaBridge

Digital Media Player

User’s Guide

Model DMP3000

1662616C_01.indd 1 12/14/05 3:56:48 PM

Important Information

WARNING

To reduce the risk of ﬁre or electric shock, do not expose this product to rain or moisture. The apparatus shall not be exposed to dripping or splashing. No objects ﬁlled with liquids, such as vases, shall be placed on the apparatus.

This symbol indicates "dangerous voltage" inside the product that presents a risk of electric shock or personal injury.

This symbol indicates important instructions accompanying the product.

RISK OF ELECTRIC SHOCK.

DO NOT OPEN.

Caution: To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts inside. Refer servicing to qualiﬁed service personnel.

CAUTION

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliﬁers) that produce heat.

Caution: The power supply cord is used as the main disconnect device. Ensure that the socket-outlet is located/ installed near the equipment and is easily accessible.

CAUTION!

• Do not install or place this unit in a bookcase, built-in

cabinet or in another conﬁned space. Ensure the unit is well ventilated. To prevent risk of electric shock or ﬁre hazard due to overheating, ensure that curtains and any other materials do not obstruct the ventilation vents.

• Do not obstruct the unit’s ventilation openings with

newspapers, tablecloths, curtains, and similar items.

• Do not place sources of naked ﬂames, such as lighted

candles, on the unit.

• Dispose of batteries in an environmentally-friendly

manner.

CAUTION: To prevent electric shock, match the wide blade of the plug to the wide slot of the electrical outlet and fully insert.

FCC Regulations state that unauthorized changes or modiﬁcations to this equipment may void the user’s authority to operate it.

Operating Temperature: 40ºF to 120ºF (5ºC to 50ºC) Storage Temperature: -5ºF to 150ºF (-20ºC to 65ºC) Net Weight: 5.75 lbs (approx.)

1662616C_01.indd 2 12/14/05 3:56:49 PM

Important Information

Product Registration

Please ﬁll out the product registration card (packed separately) and return it immediately. Returning the card allows us to contact you if needed.

Product Information

Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the serial and model numbers in case you need them. These numbers are located on the product.

Model No.: ___________________________________________

Serial No.: ____________________________________________

Purchase Date: ________________________________________

Dealer/Address/Phone:_________________________________

Speciﬁcations and features are subject to change without notice. Product may vary from that shown.

Logos are registered trademarks of their respective companies.

NOTE: This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited consumer uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

9. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

10. Unplug this apparatus during lightning storms or when unused for long periods of time.

11. Refer all servicing to qualiﬁed service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

1662616C_01.indd 3 12/14/05 3:56:49 PM

FCC Declaration of Conformity

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Trade Name: Acoustic Research

Model(s): DMP3000

Equipment Classiﬁcation: TV/Computer Interface Device

Responsible Party: Thomson Inc. 10330 N. Meridian Street Indianapolis, IN 46290 Telephone: (317) 587-3569

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect this equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.

Important Information

1662616C_01.indd 4 12/14/05 3:56:49 PM

Graphics contained within this publication are for representation only.

Welcome to MediaBridge!

Your AR MediaBridge allows you to take digital music ﬁles, photos, and videos stored on your computer network and play them on a home entertainment system. Instead of crowding around a computer to look at pictures, watch them on your TV, even in HD. Listen to your music the way it was meant to be heard—on your home entertainment system.

You can even stream videos from your computer network to the TV by using the MediaBridge remote control. You can experience music, movies, or photos in the comfort of your living room, family room, or bedroom.

As the MediaBridge streams your digital ﬁles from your computer network, it leaves your computer free to perform other functions such as e-mail or surﬁng the web. Bridging the gap is seamless— wirelessly or wired—the choice is yours.

In This Guide ...

Welcome to MediaBridge! .......................5

Setting Up Your MediaBridge ..................8

Using Your MediaBridge ........................16

Using Your Remote Control ....................22

Troubleshooting ......................................29

Limited Warranty ....................................34

1662616C_01.indd 5 12/14/05 3:56:50 PM

Welcome to MediaBridge!

What’s in the Box

Before you start setting up, make sure your MediaBridge package includes the following parts:

• Acoustic Research Digital MediaBridge (DMP3000)

• Power supply and AC cable

• Remote control

• Two AA batteries for the remote

• Wireless networking antenna

• Composite video cable

• Analog audio cable

• Software installation CD

• Registration card

The ﬁrst step in setting up your MediaBridge is installing the batteries in the remote.

IMPORTANT: Do not turn on your MediaBridge yet! Wait until you’ve connected it to your home entertainment system and computer network—connection instructions start on page 8.

Installing the Batteries in the Remote Control

1. Remove the battery compartment cover from the back of the remote by pushing the tab and lifting off the cover.

2. Insert 2 “AA” fresh batteries. Make sure the polarities (+ and -) are aligned correctly.

3. Replace the cover.

Using the Remote to Operate Other Devices

The MediaBridge remote control is already programmed to operate the MediaBridge. You can program the remote to operate up to 5 other devices in your entertainment center. See pages 2228 for instructions on how to program and use the remote.

1662616C_01.indd 6 12/14/05 3:56:51 PM

Welcome to MediaBridge

Power switch

Network connection indicator

Power indicator

IR receiver (for remote)

Wi-Fi® antenna jack

USB port

Component video output jacks for HDTV or standard-deﬁnition televisions

Composite

video jack

Power cord

jack

Ethernet jack

Digital coaxial

audio jack

Digital optical

audio jack

Analog stereo

audio jacks

S-video jack

DVI video

jack

HD/SD switch

Front of the MediaBridge

Back of the MediaBridge

RESET

button

Wi-Fi is a registered trademark of the Wi-Fi Alliance.

1662616C_01.indd 7 12/14/05 3:56:52 PM

Graphics contained within this publication are for representation only.

Setting Up Your MediaBridge

There are four steps to setting up your MediaBridge:

1. Connect the MediaBridge to your Home Entertainment System.

2. Connect the MediaBridge to your Computer Network.

3. Install the Software on the PCs in your network.

4. Run the MediaBridge Setup Wizard.

Step 1: Connect the MediaBridge to your Home Entertainment System

You will need to make two connections between the MediaBridge and your entertainment system: one for video and one for audio.

Important: The MediaBridge uses on-screen menus for guiding your selections, so you need to connect it either directly to a TV or to a video input on an A/V receiver. It is recommended that you use Acoustic Research cables for best picture and sound performance.

Video Connection

The MediaBridge works with both High-Deﬁnition and Standard-Deﬁnition TVs. How you connect the MediaBridge to your TV depends upon the type of TV you have.

Note: You must have a High-Deﬁnition television or monitor in order to watch video in High-Deﬁnition.

1662616C_01.indd 8 12/14/05 3:56:52 PM

Setting Up Your MediaBridge

Connecting the MediaBridge to an HDTV or HDTV Monitor

1. Move the HD/SD switch on the back of the MediaBridge to the HD position.

Note: When the switch is in the HD position, there will be no video signal from the composite or S-video jacks.

2. Using either component video cables or a DVI video cable, connect the MediaBridge to the corresponding input on your HDTV or A/V receiver (HD video is available through both component video and DVI connections).

DMP3000 MediaBridge

DVI-HDTV?INPUT

COMPONENT?VIDEO?INPUT

HDTV or HDTV Monitor

Y PB PR

Connecting the MediaBridge to a Standard-Deﬁnition TV

1. Move the HD/SD switch on the back of the MediaBridge to the SD position.

Note: When the switch is in the SD position, there will be no video signal from the DVI connector.

2. Using one of the following connections to connect the MediaBridge to your TV:

• Component video (best quality)

• S-Video (better quality)

• Composite video (good quality)

Connect the cable from the back of the MediaBridge to the

corresponding input on your TV or A/V receiver.

DMP3000 MediaBridge

Y PB PR

COMPONENT VIDEO INPUT VIDEO INPUT S-VIDEO INPUT

Standard-Definition TV

OR OR

1662616C_01.indd 9 12/14/05 3:56:56 PM

Setting Up Your MediaBridge

Audio Connections

Your MediaBridge offers three audio output options: two digital outputs and one pair of analog stereo outputs. These outputs can be used to play audio through your TV, an A/V receiver, or a dedicated ampliﬁer. Any of these outputs can be used to connect the MediaBridge to your TV or A/V device. If your device has a digital input jack, use one of the digital connection options for the best sound quality.

Connection Options for Audio

The MediaBridge offers three types of audio connections:

• Digital Coaxial (excellent quality)

• Digital Optical (excellent quality)

• Analog Stereo (good quality)

DMP3000 MediaBridge

L R

AUDIO INPUT

COAXIAL DIGITAL

INPUT

Device with

Coaxial Digital

Input

OPTICAL DIGITAL

INPUT

Device with

Optical Digital

Input

Device with

Analog

Stereo Inputs

OROR

When connecting the audio cables, remember to connect the AUDIO OUT jacks on the back of the MediaBridge to the AUDIO IN jacks on your device.

1662616C_01.indd 10 12/14/05 3:56:58 PM

Setting Up Your MediaBridge

Step 2: Connecting the MediaBridge to your Computer Network

The MediaBridge must be connected to your computer or computer network in order to play your digital music, movies, and pictures.

You can connect the MediaBridge to your computer in one of two ways:

•

Using a wired network The MediaBridge can connect to a wired computer network using a standard Ethernet cable connected to the Ethernet port on the back of the unit.

•

Using a wireless network The MediaBridge has a built-in 802.11g wireless card and can work with an existing 802.11g or 802.11b wireless network.

Because wireless computer networks are subject to interference from devices likes cordless phones, microwave ovens, and neighboring wireless networks, the quality of the connection between your MediaBridge and your computer can vary throughout the day. For the best performance, use the wired Ethernet connection, particularly when playing high-deﬁnition video.

Note: If you’re using a wireless connection to the network, use the

802.11g-only option on your router, especially if you plan to use the MediaBridge for video streaming. See the users manual that came with your wireless router for more information.

Connecting the MediaBridge using the wired Ethernet connection

To attach your MediaBridge to a wired computer network, connect a standard Ethernet cable (Cat5 or better) between the MediaBridge and your Ethernet hub/switch/router.

The following diagram shows a typical wired home network with a MediaBridge connected using a wired Ethernet connection. Please note that your wired network might be different.

DMP3000 MediaBridge

Wired Ethernet Hub/Switch/Router

WAN 1 2 3 4

ETHERNET

Modem

Signal from Internet

Service Provider

Computer

A sample wired network with a MediaBridge connected. This diagram shows a typical conﬁguration—your network and devices might be different.

1662616C_01.indd 11 12/14/05 3:57:00 PM

Setting Up Your MediaBridge

Step 3: Install the Software

Once you’ve connected the MediaBridge to your computer network, you are ready to install the MediaBridge software.

You must install this software on your computer in order for the MediaBridge to work with your computer.

Turn on your computer and insert the software CD into the drive.

The setup program should start automatically after a few moments. (If it does not start automatically, browse to the top directory on the CD and double-click on the Setup icon.)

On-screen instructions will guide you through the setup process.

Important Notes

• The MediaBridge software is not compatible with Apple Macintosh® computers.

• When installing the MediaBridge, you must be logged in with administrator privileges on your computer. Otherwise, the software will not install correctly. You do not have to be an administrator to run the software once it’s installed, but to install, you must have administrative privileges.

• The MediaBridge is not designed to work with VPN (Virtual Private Network) software. If VPN software is installed on a computer in the network, the MediaBridge may not be able to see that computer.

Macintosh is a registered trademark of Apple Computer, Inc.

Connecting the MediaBridge using a wireless Ethernet connection

For the best reception, the MediaBridge includes an external antenna which must be attached to the unit before it can receive the wireless signal.

Connect the antenna to the ANTENNA jack on the back of the MediaBridge and place the antenna in an unobstructed location.

The following diagram shows a typical wireless home network with a MediaBridge. Please note that your network might be different.

DMP3000 MediaBridge

Wireless Hub/Switch/Router

WAN

ETHERNET

Modem

Signal from Internet

Service Provider

Computer with

wireless capability

Antenna for

wireless network

(included)

A sample wireless network with a MediaBridge. This diagram shows a typical conﬁguration—your network and devices might be different.

1662616C_01.indd 12 12/14/05 3:57:02 PM

Setting Up Your MediaBridge

Step 4: Run the MediaBridge Setup Wizard

The MediaBridge Setup Wizard takes you through the steps to get your MediaBridge up and running. The Setup Wizard lets you set the following options:

• Language • Screen resolution

• Display type • Network type

The last screen of the Setup Wizard conﬁrms your Network Status information.

How to Use the Remote Control in the Menu System

To move around in the Setup Wizard and other on-screen menus, use the arrow buttons on the MediaBridge remote. When an item is highlighted, you can select it by pressing the OK button. If an item has arrows, you can use the left and right arrow buttons on the MediaBridge remote to change that item’s setting.

Press the HOME button to display the Main Menu. Use the GO BACK button to retrace your steps in the menu system.

Using the MediaBridge with a Firewall

If you have ﬁrewall software installed on your network, you may need to reconﬁgure the ﬁrewall software to allow the MediaBridge to access your network computers.

The MediaBridge software setup installs a background program on your computer called “MediaStreamer.exe.” It is safe to allow this program to operate on the network. If the MediaStreamer program is blocked, the MediaBridge will not see any computers on the network, so the MediaBridge’s media libraries will be empty.

If you’re still having problems getting the MediaBridge to work with your ﬁrewall software, try making the following adjustments to your ﬁrewall settings:

• Port 6070 must be open for UDP-type network trafﬁc

• Port 40001 must be open for TCP-type network trafﬁc

• Port 40002 must be open for TCP-type network trafﬁc

Continues on the next page...

1662616C_01.indd 13 12/14/05 3:57:02 PM

Setting Up Your MediaBridge

To run the Setup Wizard:

1. Press the MEDIA button on the MediaBridge remote to turn the MediaBridge on.

2. Turn on your TV or A/V tuner. Select the correct input on your TV or tuner to display the signal from your MediaBridge.

The ﬁrst screen of the Setup Wizard should be displayed. Press

OK to continue. If you see a different menu screen, you can start the Setup Wizard through the Settings menu. See page 21 for more information.

3. In each Setup Wizard screen, press the up or down arrow on the remote to highlight any settings you’d like to change. Then, use the left and right arrows to scroll through the options for that setting.

When you’re done with a setting, press the up or down arrow

to highlight Continue. Press OK to go to the next screen.

You can change any of these settings or run the Setup Wizard again through the Settings menu. See page 21 for more information.

Special Note for Wireless Network Users

The Network Type screen in the Setup Wizard lets you set up a wireless network if you have one. If you’re using a wireless network, you must tell the MediaBridge the name of your wireless network. Also, if you’re using encryption on your wireless network, you must enter your security key.

Note on Network Conﬁguration: The MediaBridge is conﬁgured to work with DHCP (Dynamic Host Conﬁguration Protocol) servers incorporated in most routers. If you do not have a DHCP server in your router or elsewhere on your network, the MediaBridge will assign itself an IP address in the range of

169.254.xxx.xxx automatically.

Note: If you have turned on the encryption features of your wireless network, you need to have your WEP (Wired Equivalent Privacy) key before going any further. The MediaBridge only supports WEP. If you have turned off the broadcast of your SSID (Service Set Identiﬁer), you also need that information before continuing.

1662616C_01.indd 14 12/14/05 3:57:02 PM

Setting Up Your MediaBridge

To conﬁgure the MediaBridge for your wireless network:

1. In the Setup Wizard’s

Network Type screen, use the remote’s up

and down arrows to highlight the Network Type option.

2. If the

Network Type option is set to Wireless, you don’t need to

change it. Highlight Continue and press OK to continue.

If the

Network Type option is set to Wired, highlight the

Network Type option and use the left or right arrow buttons to

change the option to Wireless (it may take a few seconds for the item to change on the screen).

Then, highlight

Continue and press OK to continue.

3. The next screen in the Setup Wizard displays a list of wireless networks the MediaBridge can detect.

4. Select your network from the list.

Note: If you have disabled the SSID broadcast feature on your wireless access point, you need to select the Private option and type in the name of your network using the virtual keyboard. To use the virtual keyboard:

1. Press MENU on your remote to display the virtual keyboard.

2. Use the arrow buttons to highlight letters and numbers, and press OK to select them.

3. Press MENU again to remove the keyboard from the screen.

4. Highlight the on-screen Continue button and press OK to continue.

5. If you have enabled encryption on your wireless network,

highlight Encryption type. Use the left and right arrows to select the type of encryption your network uses. Then, highlight Continue and press OK to continue.

6. Select the

Encryption Key option and type in your WEP key or

passphrase using the virtual keyboard. When you’ve ﬁnished, press the MENU button on your remote to remove the virtual keyboard from the screen.

Conﬁrm that the “link” indicator on the front of the unit is lit.

If it is, highlight the on-screen Continue button and press OK to continue.

The next screen of the Setup Wizard shows your network status. Select Continue to see the ﬁnal screen of the Setup Wizard, or select Back to change your network settings.

1662616C_01.indd 15 12/14/05 3:57:03 PM

Graphics contained within this publication are for representation only.

Using Your MediaBridge

With the MediaBridge, you can play music from your hard drive, photos from your digital camera, or movies from your digital camcorder on your home entertainment system.

You can also access media ﬁles from USB devices via the USB port on the MediaBridge back panel.

The MediaBridge menu system displays all of the playable ﬁles available on your network. Files are listed by more than just their computer ﬁlenames—the MediaBridge menu system offers many ways of ﬁnding and sorting movies, music, and pictures.

At the bottom of the main menu, the MediaBridge offers Help and Off icons:

• Highlight and select the

Help icon if you need directions or

information on a speciﬁc screen.

• Highlight and select the

Off icon to turn the MediaBridge off.

The Main Menu

To access the MediaBridge main menu, press the MEDIA button on the MediaBridge remote to put the remote control in MediaBridge mode. Then, press the HOME button.

The MediaBridge main menu has four options:

•

Watch Movies

Browse through your library of movies.

•

Listen to Music

Browse through your library of music.

•

View Pictures

Browse through your library of pictures and picture albums.

•

Settings

Change network and video settings and choose preferences.

1662616C_01.indd 16 12/14/05 3:57:03 PM

Using Your MediaBridge

Watch Movies

The MediaBridge can play movies created by digital camcorders or created by PC-based tuner cards that record over-the-air digital broadcast television to your computer.

Note: If you have more than one computer on your network, the ﬁrst screen in the Video library will ask you to choose which computer you want to browse.

The MediaBridge offers two ways of browsing through your video library:

• By the date the movie was recorded

• By the directory of folders on your computer

Choosing Files

You can play individual movies, or you can play all of the movies in a given folder or recorded in a given year. You can also tell the MediaBridge to play all of the movies in the library for the selected hard disc.

Use the arrow buttons and the OK button to navigate through your library. Then, press OK or PLAY to start playing a single movie or a group of movies (depending on what’s highlighted).

Note: A red exclamation mark next to a video ﬁle in the library means that the MediaBridge cannot play that particular ﬁle. There are several possible reasons for this—the ﬁle may have a name that the MediaBridge has trouble

recognizing, or the ﬁle may be corrupt.

Playing Files

You can use these remote control buttons during movie playback:

INFO

Displays available information for the current ﬁle.

PAUSE

Pauses the movie.

PLAY

Continues the movie after a pause.

PREV or NEXT

Go to the previous or next movie in the list.

REVERSE and FORWARD

Provide transport control for standarddeﬁnition videos.

STOP

Stops the movie and returns to the Video library.

Note: If the movie you’re playing on the MediaBridge has multi-channel audio, audio will only be available from the digital audio outputs. There will be no audio signal from the MediaBridge’s other audio outputs.

To hear multichannel audio, use one of the MediaBridge’s digital audio outputs to connect it to multichannel-capable receiver.

More Options...

Press the GUIDE button to access more options for playback or browsing. Press GUIDE again to clear the option list from the screen.

Press the HOME button to go to the main menu from anywhere in the MediaBridge menu system.

Press the GO BACK button to retrace your steps in the menu system.

1662616C_01.indd 17 12/14/05 3:57:03 PM

Using Your MediaBridge

Listen to Music

The MediaBridge offers ﬁve ways of browsing through your music library:

• By artist • By album

• By genre • Alphabetically, by song or ﬁle title

• By your computer’s folder organization

The MediaBridge also lists any m3u or WPL playlists it ﬁnds in your network.

Note: If you have more than one computer in your network, the ﬁrst screen in the Music library will ask you to choose which computer you want to browse.

Choosing Files

You can play individual songs, or you can play all of the songs by a given artist, on a given album, or in a given genre. You can also choose playlists that the MediaBridge ﬁnds in your network or tell the MediaBridge to play all of the songs in the library for the selected hard disc.

Use the arrow buttons and the OK button to navigate through your library. Then, press OK or PLAY to start playing a single song or a group of songs (depending on what’s highlighted).

Playing Files

You can use these remote control buttons during music playback:

INFO

Displays available information for the current ﬁle.

PREV or NEXT

Go to the previous or next song in the list.

REVERSE, PLAY, FORWARD, STOP, and PAUSE

Provide transport control, just as they would with a CD player.

More Options...

Press the GUIDE button to access more options for playback or browsing. Press GUIDE again to clear the option list from the screen.

Press the HOME button to go to the main menu from anywhere in the MediaBridge menu system.

Press the GO BACK button to retrace your steps in the menu system.

1662616C_01.indd 18 12/14/05 3:57:03 PM

Using Your MediaBridge

View Pictures

The MediaBridge offers three ways of browsing through your photos:

• By the date the photo was taken

• By the directory of folders on your computer

• Within picture albums you’ve created

Note: If you have more than one hard disc in your network, the ﬁrst screen in the Picture library will ask you to choose which computer you want to browse.

The MediaBridge menu system displays thumbnails of your images to you help ﬁnd pictures.

You can also create and view picture albums on your MediaBridge.

Choosing Pictures

You can view individual pictures, or you can start a slideshow with all of the pictures in the list or category on the screen (by date or by folder).

Use the arrow buttons and the OK button to navigate through your library. Then, press OK or PLAY to view a single picture or a slideshow of a group of pictures (depending on what’s highlighted).

Note: A red exclamation mark next to a picture ﬁle’s name means that the MediaBridge cannot play that particular ﬁle.

Special note for plasma monitor owners: To avoid uneven phosphor aging (or “burn-in”), avoid displaying the same image on your plasma monitor for a prolonged period of time. Do not turn the MediaBridge’s screensaver off (by default the screensaver is on). See page 21 for more

information about the MediaBridge’s screensaver.

Viewing Pictures and Slideshows

You can use these remote control buttons while viewing individual pictures or during a slideshow:

CH+ or CH-

Zoom in on or out of the current picture.

CLEAR

Deletes the current picture from your network.

FORWARD or REVERSE

Rotate the current picture clockwise or counterclockwise.

INFO

Displays available information for the current ﬁle.

PAUSE

Pauses the slideshow.

PLAY

Continues the slideshow after a pause.

PREV or NEXT

Go to the previous or next picture.

STOP

Stops the slideshow and returns to the Picture library.

Note: The Rotate Picture function does not work with read-only content.

More Options...

Press the GUIDE button to access more options for playback or browsing. Press GUIDE again to clear the option list from the screen.

Press the HOME button to go to the main menu from anywhere in the MediaBridge menu system.

Press the GO BACK button to retrace your steps in the menu system.

1662616C_01.indd 19 12/14/05 3:57:04 PM

Using Your MediaBridge

Creating and Viewing Picture Albums

From the Pictures menu you can browse through the picture albums you’ve already created, organize existing albums, or create a new one.

• Choose

View Picture Albums to see the picture albums you’ve

already created and play one as a slideshow.

• Choose

Organize Albums to create a new picture album or

organize an existing album.

To create a new picture album:

1. Choose

View Pictures from the main menu. If you have more

than one source for media in your network, choose the source you want to browse for pictures.

2. Choose

Organize Albums from the Pictures menu.

3. Choose

Create new album from the Organize Album menu.

4. Browse through your picture library by year and month—the menu shows you thumbnails of the images for that year and month.

5. Use the arrow buttons to highlight a thumbnail, and press OK to include that image in the album (a checkmark appears above the images in the album).

Note: If you want to customize your album’s name, choose Rename this album from the Album browse screen. Then, press MENU and

use the on-screen keyboard to enter a name—you’ll need to delete the existing name ﬁrst. Press MENU again to clear the keyboard from the screen. Then, press GO BACK to return to the Album browse screen.

6. Press the GO BACK button when you’ve ﬁnished compiling the pictures in your album. The album appears in the list of albums available for organizing or viewing.

Playing Slideshows with Music

You can have the MediaBridge play music while you watch a slideshow.

To start the music during the slideshow:

While a slideshow is running, press the MUSIC button on the remote to bring up the music menu.

2. Browse and select the music or playlist you want to play. Press OK to start playback of the ﬁle(s).

3. Press the PICS button.

4. Select

Resume Slideshow and press OK.

You can also start the music playlist ﬁrst and add the slideshow later. Start the playlist (steps 1 and 2 here). Then, press the PICS button, ﬁnd the slideshow you want to see, and press OK or PLAY to select it.

1662616C_01.indd 20 12/14/05 3:57:04 PM

Using Your MediaBridge

Settings

The Settings menu lets you customize your MediaBridge to ﬁt your preferences and home entertainment/computer network conﬁguration. There are three kinds of options you can set: General Settings, Library Settings, and System Settings.

General Settings

Select General Settings in the Settings menu to set your preferences for the following options:

• screensaver delay • USB media auto-play

• closed captioning • menu system look and feel

• language

The General Settings menu also lets you repeat the Setup Wizard, restore the MediaBridge’s default settings, or update the MediaBridge’s software.

Note: The MediaBridge must have access to an internet connection in order to run the software update.

To repeat the Setup Wizard:

1. Choose

Settings from the main menu.

2. Choose

General Settings from the Settings menu.

3. Choose

Repeat setup wizard from the General Settings menu.

4. Follow the on-screen instructions to complete the Setup Wizard, or press the HOME button to exit.

Library Settings

Select Library Settings in the Settings menu if you want to scan a media library in your network.

System Settings

Select System Settings in the Settings menu to set your preferences for Display and Network Settings.

Accessing USB Devices

You can access the media from a USB storage device by connecting it to the USB port on the back of the MediaBridge.

The MediaBridge will recognize the device and scan it automatically—this will take a few moments.

A Removable Media menu item will appear in the movies, music, and pictures libraries until you disconnect the device. Choose this item to browse through the USB device’s media contents.

Notes:

• The MediaBridge recognizes only certain kinds of USB devices: USB thumb drives, USB memory card readers, and USB hard drives. Please note that not all USB devices are compatible with the MediaBridge.

• If you’re connecting an RCA Lyra to the MediaBridge using a USB connection, make sure the Lyra’s USB Protocol is set to Mass Storage Class.

• USB devices should be formatted as NTFS or FAT32 in order for the MediaBridge to play ﬁles from them. If your USB device is not recognized by the MediaBridge, check its formatting type.

1662616C_01.indd 21 12/14/05 3:57:04 PM

Graphics contained within this publication are for representation only.

Using Your Remote Control

The Remote Control

The MediaBridge includes a 6-device universal remote control. The remote already operates the MediaBridge and many RCA, GE, and Proscan devices. It must be programmed to work with other devices (see pages 24-25 for more information on programming).

The Buttons on the Remote

(0-9) Number buttons You can enter some settings directly with the number buttons.

ANTENNA In VCR mode (if programmed), this button works as a TV/VCR button for some

VCRs. In SAT•CAB mode (if programmed), this button works as a TV/SAT button for some satellite receivers.

Arrow buttons Used to navigate through on-screen menus and to highlight options.

CH + or CH - While viewing pictures from your MediaBridge, this button zooms in on or zooms

out of the current picture. Changes channels in TV, VCR, or SAT•CAB mode.

CLEAR While viewing pictures from your MediaBridge, this button deletes the current picture from the network (except for read-only pictures). For some other devices, this button removes menus or displays from the screen.

Device buttons Device buttons are used to set the remote to operate a certain device. For example, if you want to use the MediaBridge, press the MEDIA button. This tells the remote you are using the MediaBridge, and the remote communicates with the MediaBridge.

AUDIO Puts the remote in Audio mode so the remote (if programmed) operates the audio device. DVD Puts the remote in DVD mode so the remote (if programmed) operates the DVD player. MEDIA Puts the remote in MediaBridge mode so the remote operates the MediaBridge. SAT•CAB Puts the remote in satellite/cable box mode so the remote (if programmed) operates a satellite

receiver or cable box.

TV Puts the remote in TV mode so the remote (if programmed) operates the TV.

VCR Puts the remote in VCR mode so the remote (if programmed) operates the VCR.

Indicator

1662616C_01.indd 22 12/14/05 3:57:09 PM

Using Your Remote Control

picture in a playlist or slideshow. In DVD mode, goes to the next chapter.

NOW PLAYING This button has no functionality with the MediaBridge.

When in the menu system, selects highlighted items.

ON•OFF

Turns the MediaBridge on and off. If the remote is in another device mode (TV, DVD, etc.) and programmed to control that device, this button will turn the device on and off.

PICS Accesses the MediaBridge’s Pictures Media Library screen or Pictures Main Menu.

PLAY, STOP, and PAUSE Provide transport control for movie, music, and slideshow playback. Also provides transport control for many DVD players and VCRs.

PREV (Previous) In MediaBridge mode, goes to the previous song/movie/picture in a playlist or slideshow. In DVD mode, goes to the previous chapter.

RECORD

Starts recording for some VCRs, DVD recorders, or

hard disk recorders.

REVERSE and FORWARD Provide transport control for music and standard-deﬁnition movie playback. Rotate pictures counterclockwise and clockwise (except for read-only pictures). Also provides transport control for many DVD players and VCRs.

VOL – or VOL + Decreases or increases the volume.

GO BACK Returns you to the previous menu or screen.

GUIDE

When you’re controlling the MediaBridge, this button accesses the options available for viewing pictures or movies or listening to music (press again to clear the options from the screen).

HOME Brings up the main menu for the MediaBridge from any point in the MediaBridge media system.

Indicator Flashes when you press a remote control button. Also ﬂashes during the remote control programming procedure (see the following pages for more information).

INFO Displays available information for an image, song, or movie.

INPUT Press to toggle through the available input sources for TVs, satellite receivers, or VCRs.

MENU Brings up the MediaBridge’s on-screen keyboard (when available). For some devices, this button accesses a main menu.

MOVIES Accesses the MediaBridge’s Video Media Library screen or Videos Main Menu.

MUSIC Accesses the MediaBridge’s Music Media Library screen or Music Main Menu.

MUTE Reduces volume to its minimum level. Press again to restore the volume.

NEXT In MediaBridge mode, goes to the next song/movie/

1662616C_01.indd 23 12/14/05 3:57:09 PM

Using Your Remote Control

Using the Universal Remote with Other Devices

The universal remote can be programmed to operate many brands of remote controllable TVs, VCRs, audio devices, DVD players, cable boxes, satellite receivers, and other devices. This remote is already programmed to control many RCA, GE, and Proscan devices.

Find Out If You Need to Program the Remote

To determine whether the universal remote needs to be programmed to operate one of the devices in your home entertainment system:

1. Turn on the device (your TV, for example).

2. Point the remote at the device.

3. Press the corresponding device button (in this example, TV).

4. Press ON•OFF to see if the device responds. If the device

doesn’t respond, you need to program the remote to operate it.

Programming the Remote

There are two ways to program the remote control to operate other devices: Automatic Code Search and Direct Entry.

Using Automatic Code Search

The following instructions can be used to program the remote to operate each of your devices. If you want to stop the automatic code search without programming any of your devices, press and hold CLEAR until the indicator on the remote turns off.

1. Turn on the device you want to operate (VCR, DVD player, etc.).

2. Press and hold the device button you want to program (VCR, DVD, etc.). While holding the device button, press and hold ON•OFF until the indicator on the remote turns on, then release both buttons.

3. Point the remote at the device.

Important Note: The remote may not be compatible with all models of all brands of devices. It also may not operate all functions of your device.

4. Press and release PLAY, then wait 5 seconds or until the indicator stops ﬂashing.

At this point the remote is searching for the correct code to program. If, after 5 seconds, the device you want to operate does not turn off, press PLAY again to tell the remote to search the next set of codes.

1662616C_01.indd 24 12/14/05 3:57:09 PM

Using Your Remote Control

How to Use the Remote After You’ve Programmed It

Because this universal remote can control several different devices (TV, DVD, VCR, satellite receiver, etc.), the remote uses operational modes triggered by the device buttons.

1. Press the appropriate device button (DVD, TV, VCR, SAT•CABLE, AUDIO, AUX•HD) to set the remote to control the device.

2. Press ON•OFF to turn the device on or off.

3. Use the remote buttons that apply to that device.

Notes: The remote control may not be compatible with all brands and models of devices.

If you keep pressing buttons and nothing happens, the remote is probably in the wrong mode. You must press the device button that matches the device you want to operate (i.e., if you want to operate the VCR, press VCR on the remote control to put the remote in VCR mode).

Continue pressing and releasing PLAY until the device turns off or you have searched through all of the codes. The indicator ﬂashes when all codes have been searched; then, the indicator turns off, and the remote exits Automatic Code Search.

If the device you want to control does turn off:

1. Press and release REVERSE, then wait 2 seconds. Repeat this step until the device turns back on.

2. To ﬁnish, press and hold STOP until the indicator on the remote turns off.

Using Direct Entry

1. Turn on the device you want to operate (VCR, DVD player, etc.).

2. Look up the brand and code number(s) for the device on the code list on pages 26-28.

3. Press and hold the device button you want to program on the remote.

4. Enter the 4-digit code from the remote control code list on the following pages. If the indicator ﬂashes, you have either entered an invalid code or the button isn’t programmable.

5. Release the device button, point remote at device, and then press ON•OFF to see if the device responds to the command. If it doesn’t, try pressing the device button and then ON•OFF again.

• If you get no response, repeat these steps using the next code listed for your brand, until the device responds to the remote commands.

• If you try all the codes for your device brand and none work, try the automatic code search method. If automatic code search doesn’t ﬁnd the code, the remote is not compatible with your device.

1662616C_01.indd 25 12/14/05 3:57:09 PM

Remote Control Codes

Audio Codes

Audio (General)

GE........................................................................................4000

Proscan ................................................................................ 4000

RCA .....................................................................................4000

Amplier

GE........................................................................................4003

Proscan ................................................................................ 4003

RCA .....................................................................................4003

Audio Cassette

GE........................................................................................4006

Proscan ................................................................................ 4006

RCA .....................................................................................4006

ADC ................................................................. 4055, 4056, 4066

Aiwa .......................................................................... 4039, 4057

Akai ..................................................................................... 4058

Denon .................................................................................4060

Emerson .............................................................................. 4040

Fisher ............................................................... 4041, 4063, 4064

GE........................................................................................4065

GE........................................................................................4007

Hitachi ................................................................................. 4042

JVC ......................................................................................4043

Kenwood ........................................................4044, 4067, 4068

Luxman ............................................................................... 4069

Marantz ...............................................................................4046

MCS ..................................................................................... 4070

Mitsubishi .................................................................. 4071, 4072

NEC .....................................................................................4045

Onkyo ................................................................................. 4047

Panasonic ............................................................................4048

Pioneer ................................................................................4049

Proscan ................................................................................ 4007

RCA ...........................................................................4050, 4062

RCA .....................................................................................4007

Sears .................................................................................... 4059

Sony ..........................................................................4051, 4061

Technics .............................................................................. 4052

Toshiba ................................................................................4073

Yamaha ..................................................................... 4053, 4054

Phono

GE........................................................................................4005

Proscan ................................................................................ 4005

RCA .....................................................................................4005

Receiver/Tuner

Aiwa .................................. 4008, 4009, 4010, 4011, 4012, 4021

Denon .................................................................................4027

Harman Kardon .................................................................. 4020

JBL ....................................................................................... 4020

JVC ......................................................................................4013

Kenwood ............................................................................4014

Onkyo ................................................................................. 4022

Optimus .............................................................................. 4028

Panasonic .................................................................. 4023, 4024

Pioneer ................................................................................4074

RCA .................................................................4015, 4029, 4030

Sherwood ............................................................................ 4026

Sony ................................................................4016, 4017, 4025

Technics .................................................................... 4023, 4024

Yamaha ..................................................................... 4018, 4019

Cable Box Codes

ABC ............................................. 5002, 5003, 5004, 5006, 5045

Archer ........................................................................ 5009, 5010

Cableview ........................................................................... 5007

Contec ................................................................................. 5015

Eastern ................................................................................5016

GE.............................................................................. 5002, 5003

Gemini ......................................................................5017, 5018

General Instruments ........................................................... 5003

Hamlin......................................... 5019, 5020, 5021, 5026, 5033

Hitachi ................................................................................. 5003

Jerrold ............................... 5003, 5017, 5022, 5023, 5039, 5045

Magnavox............................................................................5024

Motorola .............................................................................. 5076

Movie Time .........................................................................5025

NEC .....................................................................................5005

NSC ...................................................................................... 5025

Oak ............................................................................ 5015, 5027

Panasonic .................................................................. 5041, 5044

Philips ..5011, 5012, 5013, 5014, 5018, 5024, 5028, 5029, 5030

Pioneer ...................................................................... 5031, 5032

Proscan ...................................................................... 5002, 5003

RCA .......................................................5007, 5040, 5042, 5044

Realistic ............................................................................... 5009

Samsung .............................................................................. 5032

Scientiﬁc Atlanta ..... 5006, 5034, 5035, 5036, 5073, 5074, 5075

Signature ............................................................................. 5003

Sprucer ................................................................................ 5044

Standard Component................................................ 5037, 5038

Starcom ..................................................................... 5017, 5045

Stargate ................................................................................ 5017

Tocom ....................................................................... 5004, 5022

United Cable ....................................................................... 5045

Universal ......................................................... 5008, 5009, 5010

View Star ......................................................... 5015, 5024, 5025

Zenith ..................................................................................5043

Combo Codes

DVD/VCR DVD VCR

Broksonic ...............................................3075 ..................... 2075

Emerson .................................................3076 ..................... 2076

Go Video ......................................3077, 3081 ..................... 2077

JVC .........................................................3078 .....................2078

RCA ........................................................3079 .....................2079

Samsung .................................................3080 ........... 2080, 2081

Sanyo ......................................................3082 .....................2082

Sony .......................................................3083 .....................2083

Zenith .....................................................3084 ..................... 2084

TV/DVD

Broksonic ............................................................................1143

Sansui .................................................................................. 1149

Toshiba ................................................................................1145

TV/DVD/VCR

Panasonic .................................................................. 1152, 1153

Sylvana ................................................................................ 1154

TV/VCR

Broksonic ............................................................................1151

DVD Codes

Aiwa ................................................................ 3010, 3021, 3022

Apex .......................................................................... 3023, 3024

Broksonic .................................................................. 3027, 3075

Daewoo ............................................................................... 3028

Denon ..................... 3029, 3030, 3031, 3042, 3062, 3063, 3064

Emerson .......................................................... 3032, 3033, 3076

Funai ................................................................................... 3033

GE.............................................................................. 3000, 3034

Go Video

................................................................... 3077, 3081

Hitachi ......................................... 3009, 3067, 3068, 3069, 3070

JVC ..................................................................3003, 3011, 3078

Kenwood ............................................................................3071

Konka ........................................................................ 3012, 3013

Lasonic ................................................................................ 3087

Magnavox.................................................................. 3004, 3036

Memorex ............................................................................. 3037

Mintek ................................................................................. 3038

Mitsubishi ............................................................................ 3005

NAD.....................................................................................3032

Norcent .....................................................................3039, 3040

Onkyo ................................................................................. 3041

Oritron.................................................................................3047

Panasonic ............................................................................3014

Philips .......................................................................3004, 3020

Pioneer .................................................. 3006, 3043, 3044, 3045

Proscan .................................................. 3000, 3035, 3046, 3048

1662616C_01.indd 26 12/14/05 3:57:10 PM

Remote Control Codes

DVD Codes (continued)

Qwestar ............................................................................... 3047

RCA .......................................................3000, 3002, 3079, 3086

Samsung ................................................ 3072, 3073, 3074, 3080

Sansui .................................................................................. 3049

Sanyo ......................................................................... 3015, 3082

Sharp ............................................................... 3050, 3052, 3053

Sony ........................ 3007, 3016, 3017, 3054, 3055, 3056, 3083

Sylvania ............................................................................... 3033

Teac ..................................................................................... 3057

Technics .............................................................................. 3058

Toshiba ........................................ 3008, 3018, 3059, 3060, 3061

Zenith .............................................................. 3019, 3065, 3084

Portable DVD

Audiovox................................................................... 3025, 3026

RCA .....................................................................................3066

Sharp ................................................................................... 3051

Home-Theater-In-A-Box (HTIB) Codes

Audio DVD

JBL ..........................................................4031 .....................3088

JVC .........................................................4032 .....................3089

Koss ........................................................4033 ........... 3085, 3090

Onkyo ....................................................4034 ..................... 3091

Panasonic ...............................................4035 ..................... 3092

Pioneer ...................................................4036 ..................... 3093

RCA ........................................................4037 .....................3094

Venturer ..................................................4038 .....................3095

PVR Codes

RePlay .................................................................................2086

Tivo ..................................................................................... 2085

Satellite Receiver Codes

Alphastar ............................................................................. 5064

Chaparral ................................................................... 5046, 5047

Dishnet ................................................................................ 5063

Drake......................................................................... 5048, 5049

Echostar...............................................................................5070

GE.................................................................... 5000, 5001, 5072

General Instruments ....................................... 5050, 5051, 5052

Hitachi ....................................................................... 5066, 5067

Hughes Network Systems ........................................ 5062, 5071

JVC ......................................................................................5065

Panasonic ............................................................................5060

Philips .................................................................................5068

Primestar ............................................................................. 5061

Proscan ............................................................ 5000, 5001, 5072

RCA .................................................................5000, 5001, 5072

Realistic ............................................................................... 5053

Sony ....................................................................................5058

STS1 ..................................................................................... 5054

STS3 ..................................................................................... 5055

STS4 ..................................................................................... 5056

Toshiba ......................................................................5057, 5059

Uniden ................................................................................5069

TV Codes

Admiral, ........................................................... 1002, 1097, 1118

Aiko ..................................................................................... 1015

Akai ..................................................................................... 1003

Amtron ................................................................................ 1026

Anam National ............................ 1004, 1026, 1110, 1111, 1112

AOC ................................... 1005, 1006, 1007, 1099, 1100, 1113

Apex ................................................................ 1140, 1148, 1150

Audiovox.............................................................................1026

Bell & Howell ................................................. 1002, 1029, 1045

Broksonic .................................................................. 1143, 1151

Celebrity .............................................................................. 1003

Centurion ............................................................................ 1009

Citizen ........................................ 1005, 1007, 1008, 1015, 1026,

1045, 1063, 1095, 1119

Colortyme .......................................................1005, 1007, 1010

Contec/Cony ......................................... 1011, 1012, 1013, 1026

Craig .................................................................................... 1026

Crown........................................................................ 1026, 1038

Curtis Mathes ............................. 1001, 1005, 1007, 1014, 1029,

1045, 1063, 1095, 1119, 1130, 1157

Daewoo ...................................... 1005, 1006, 1007, 1015, 1016,

1017, 1080, 1095, 1108

Daytron ........................................................... 1005, 1007, 1095

Dimensia ......................................................... 1001, 1130, 1157

Dumont ..................................................................... 1005, 1084

Electroband ......................................................................... 1003

Electrohome ............ 1003, 1004, 1005, 1007, 1018, 1019, 1020

Emerson ........................... 1005, 1007, 1011, 1021, 1022, 1023,

1024, 1025, 1026, 1027, 1029, 1045,

1078, 1095, 1101, 1102, 1109, 1127, 1131, 1138

Envision ....................................................................1005, 1007

Fisher ........................................... 1028, 1029, 1030, 1045, 1103

Fujitsu .................................................................................. 1027

Funai ......................................................................... 1026, 1027

GE........1000, 1001, 1004, 1005, 1007, 1020, 1031, 1032, 1054,

1104, 1120, 1130, 1132, 1157, 1158

Goldstar .........1005, 1006, 1007, 1011, 1018, 1033, 1034, 1035,

1087, 1088, 1095, 1096

Hallmark ...................................................................1005, 1007

Hisense ................................................................................ 1141

Hitachi .................... 1005, 1007, 1011, 1012, 1013, 1036, 1037,

1102, 1126, 1134, 1135, 1136, 1137, 1138

Inﬁnity ................................................................................. 1038

Janeil ................................................................................... 1098

JBL ....................................................................................... 1038

JC Penney .....1001, 1005, 1006, 1007, 1008, 1012, 1020, 1031,

1032, 1034, 1035, 1044, 1054, 1062, 1063, 1081,

1095, 1096, 1104, 1130, 1132, 1147, 1157

Jensen ........................................................................ 1005, 1007

JVC ................................... 1011, 1012, 1013, 1032, 1037, 1039,

1089, 1090, 1105, 1127, 1146

Kawasho .........................................................1003, 1005, 1007

Kenwood ........................................................1005, 1007, 1018

Kloss Novabeam ................................... 1026, 1040, 1041, 1098

KTV ....................................................... 1026, 1042, 1095, 1101

LG ........................................................................................ 1006

Loewe .................................................................................. 1038

Logik ...................................................................................1002

Luxman ..................................................................... 1005, 1007

LXI .......................... 1001, 1007, 1029, 1038, 1043, 1044, 1045,

1104, 1116, 1130, 1132, 1147, 1157

Magnavox......1005, 1007, 1008, 1018, 1038, 1040, 1041, 1046,

1047, 1048, 1055, 1082, 1083, 1124, 1125, 1129, 1139

Majestic ...............................................................................1002

Marantz .......................................1005, 1007, 1036, 1038, 1049

Megatron ................................................................... 1007, 1036

Memorex ..................................... 1002, 1006, 1007, 1029, 1045

MGA ...............1005, 1006, 1007, 1018, 1020, 1030, 1050, 1051

Mitsubishi ......................... 1005, 1006, 1007, 1018, 1020, 1030,

1050, 1051, 1052, 1079

Montgomery Ward ..............................................................1002

Motorola .................................................................... 1004, 1097

MTC ....................................................... 1005, 1006, 1007, 1063

Multitech .............................................................................1026

NAD................................... 1007, 1043, 1044, 1106, 1126, 1147

NEC ............................................. 1004, 1005, 1006, 1007, 1010

Nikko......................................................................... 1007, 1015

Onwa...................................................................................1026

Optimus .................................................................... 1106, 1126

Optonica ................................................................... 1061, 1097

Orion ......................................................................... 1025, 1109

Panasonic .......1004, 1032, 1038, 1094, 1121, 1128, 1152, 1153

Philco ............................... 1004, 1005, 1006, 1007, 1008, 1011,

1018, 1038, 1040, 1041, 1046, 1048

Philips .............................. 1004, 1005, 1008, 1011, 1018, 1038,

1040, 1041, 1046, 1053, 1054, 1055, 1056

Pioneer ............................. 1005, 1007, 1057, 1058, 1059, 1102,

1106, 1126, 1138

Portland ....................................... 1005, 1006, 1007, 1015, 1095

Price Club ...........................................................................1063

Prima ................................................................................... 1142

Prism ................................................................................... 1032

Proscan .................... 1000, 1001, 1104, 1130, 1132, 1157, 1158

Proton.............................................................. 1005, 1007, 1011

Quasar ......................................... 1004, 1032, 1042, 1060, 1121

Radio Shack .......................................... 1029, 1045, 1130, 1157

1662616C_01.indd 27 12/14/05 3:57:11 PM

Remote Control Codes

Radio Shack/Realistic ...... 1001, 1005, 1007, 1011, 1026, 1029,

1045, 1061, 1095, 1096

RCA .....1000, 1001, 1004, 1005, 1006, 1007, 1018, 1102, 1104,

1108, 1130, 1132, 1138, 1144, 1155, 1157, 1158

Realistic ................................................. 1029, 1045, 1130, 1157

Runco .................................................................................. 1084

Sampo ......................................... 1005, 1007, 1095, 1096, 1156

Samsung ........1005, 1006, 1007, 1011, 1014, 1018, 1062, 1063,

1064, 1095, 1096, 1114, 1133

Sansui ........................................................................ 1109, 1149

Sanyo ....1005, 1028, 1029, 1045, 1051, 1065, 1066, 1093, 1103

Scott ......................... 1005, 1007, 1011, 1021, 1025, 1026, 1027

Sears ....................... 1001, 1005, 1007, 1012, 1013, 1018, 1027,

1028, 1029, 1030, 1039, 1043, 1044, 1045,

1067, 1068, 1103, 1104, 1107, 1130, 1132, 1147, 1157

Sharp ................................ 1005, 1007, 1011, 1022, 1023, 1061,

1069, 1070, 1071, 1077, 1095, 1097

Signature ................................................................... 1002, 1072

Sony ......................................................1003, 1115, 1122, 1123

Soundesign .................................1005, 1007, 1008, 1026, 1027

Starlite .................................................................................1026

Supre-Macy ......................................................................... 1098

Sylvania .........1005, 1007, 1008, 1018, 1038, 1040, 1041, 1046,

1047, 1048, 1055, 1073, 1092, 1154

Symphonic ...................................................... 1024, 1026, 1107

Tandy .................................................................................. 1097

Tatung ................................................................................. 1004

Technics .............................................................................. 1032

Techwood ....................................................... 1005, 1007, 1032

Teknika .........1002, 1005, 1006, 1007, 1008, 1011, 1012, 1013,

1015, 1026, 1027, 1047, 1063, 1094, 1095, 1121, 1128

Telecaption ......................................................................... 1074

Toshiba ............................. 1029, 1043, 1044, 1045, 1063, 1067,

1074, 1075, 1091, 1092, 1145, 1147

Totevision............................................................................1095

Universal ................................................................... 1031, 1054

Wards ............................... 1001, 1002, 1005, 1006, 1007, 1018,

1021, 1024, 1027, 1031, 1038, 1040,

1041, 1046, 1047, 1054, 1055, 1061, 1076, 1130, 1157

Yamaha ................................................. 1005, 1006, 1007, 1018

Zenith ................................ 1002, 1005, 1084, 1085, 1086, 1117

VCR Codes

Admiral ................................................................................ 2068

Aiko ..................................................................................... 2023

Aiwa .................................................................................... 2022

Akai ................................... 2002, 2003, 2004, 2057, 2058, 2059

Audiovox.............................................................................2010

Bell & Howell ..................................................................... 2007

Broksonic ........................................................ 2008, 2021, 2075

Calix ....................................................................................2010

Canon ........................................................................ 2017, 2018

Capehart .................................................................... 2016, 2056

Carver .................................................................................. 2037

CCE ............................................................................ 2023, 2036

Citizen ............2009, 2010, 2011, 2012, 2013, 2014, 2015, 2023

Colortyme ...........................................................................2005

Craig ...................................................... 2009, 2010, 2019, 2036

Curtis Mathes .2005, 2009, 2012, 2014, 2017, 2018, 2020, 2060

Daewoo ................... 2011, 2013, 2015, 2021, 2022, 2023, 2056

Daytron ............................................................................... 2056

Electrohome .............................................................. 2010, 2024

Emerson ................. 2002, 2008, 2010, 2011, 2017, 2020, 2021,

2022, 2024, 2025, 2026, 2027, 2028, 2039,

2059, 2061, 2067, 2069,2076

Fisher ..................................................... 2007, 2019, 2029, 2030

Fuji................................................................... 2003, 2017, 2062

Funai ................................................................................... 2022

Garrard ................................................................................2022

GE.........2000, 2001, 2009, 2017, 2018, 2060, 2063, 2072, 2073

Go Video ................................................................... 2074, 2077

Goldstar ....................................... 2005, 2010, 2014, 2032, 2035

Gradiente ............................................................................2022

Harman Kardon .................................................................. 2005

Harwood ............................................................................. 2036

Hitachi ............................... 2033, 2034, 2035, 2053, 2057, 2063

JC Penney .....2005, 2006, 2007, 2008, 2009, 2010, 2017, 2018,

2030, 2033, 2034, 2036, 2037, 2053

Jensen .............................................................. 2033, 2034, 2057

JVC .......................... 2005, 2006, 2007, 2014, 2057, 2064, 2078

Kenwood ................ 2005, 2006, 2007, 2012, 2014, 2057, 2064

KLH .....................................................................................2036

Kodak ........................................................................ 2010, 2017

LG ........................................................................................ 2010

Logik ...................................................................................2036

LXI ....................................................................................... 2010

Magnavox................ 2017, 2018, 2037, 2038, 2052, 2054, 2065

Marantz ................... 2005, 2006, 2007, 2012, 2014, 2017, 2037

Matsushita ........................................................................... 2017

Memorex ........2007, 2009, 2010, 2017, 2019, 2022, 2052, 2068

MGA ................................................................ 2024, 2039, 2059

Minolta ............................................................ 2033, 2034, 2053

Mitsubishi .......2024, 2033, 2034, 2039, 2040, 2041, 2059, 2064

Montgomery Ward ..............................................................2068

Motorola .................................................................... 2017, 2068

MTC ..................................................................................... 2009

Multitech ..................................... 2009, 2012, 2022, 2031, 2036

NEC ......................... 2005, 2006, 2007, 2012, 2014, 2057, 2064

Nikko...................................................................................2010

Noblex ................................................................................. 2009

Olympus..............................................................................2017

Optimus .................................................................... 2010, 2068

Optonica .............................................................................2047

Panasonic .............................................. 2017, 2018, 2055, 2066

Pentax ......................................... 2012, 2033, 2034, 2053, 2063

Pentex Research ................................................................. 2014

Philco .................................................... 2017, 2018, 2037, 2038

Philips ...................................................2017, 2037, 2047, 2065

Pioneer .................................................. 2006, 2033, 2042, 2064

Portland ................................................. 2012, 2013, 2015, 2056

Proscan .................................................. 2000, 2001, 2072, 2073

Quasar ............................................................. 2017, 2018, 2066

Radio Shack .................................................... 2010, 2047, 2068

Radio Shack/Realistic ...... 2007, 2009, 2010, 2017, 2018, 2019,

2022, 2024, 2029, 2047

Radix ...................................................................................2010

RCA .....2000, 2001, 2002, 2009, 2017, 2033, 2034, 2043, 2044,

2045, 2053, 2060, 2063, 2066, 2070, 2072, 2073, 2079

Realistic .........2007, 2009, 2010, 2011, 2017, 2018, 2019, 2022,

2024, 2029, 2047, 2068

Ricoh ................................................................................... 2071

Runco .................................................................................. 2052

Samsung .........2004, 2009, 2011, 2027, 2031, 2058, 2080, 2081

Sansui .................................................... 2006, 2046, 2057, 2064

Sanyo ..................................................... 2007, 2009, 2019, 2082

Scott ......................... 2008, 2011, 2021, 2026, 2028, 2039, 2061

Sears .....2007, 2010, 2017, 2019, 2029, 2030, 2033, 2034, 2053

Sharp ........................................... 2013, 2024, 2047, 2048, 2068

Shintom ................................................. 2003, 2034, 2036, 2049

Signature ............................................................................. 2068

Singer .............................................................. 2017, 2036, 2071

Sony ............................................2003, 2049, 2050, 2062, 2083

STS ............................................................................. 2017, 2053

Sylvania ................... 2017, 2018, 2022, 2037, 2038, 2039, 2065

Symphonic .......................................................................... 2022

Tandy .................................................................................. 2007

Tashiko ................................................................................2010

Tatung ................................................................................. 2057

Teac ........................................................................... 2022, 2057

Technics .................................................................... 2017, 2055

Teknika ................................................. 2010, 2017, 2022, 2051

Toshiba .............................. 2011, 2029, 2030, 2033, 2039, 2059

Totevision..................................................................2009, 2010

Unitech ................................................................................ 2009

Vector Research .................................... 2005, 2006, 2011, 2012

Video Concepts .......................... 2005, 2006, 2011, 2012, 2059

Wards ..2009, 2010, 2011, 2017, 2019, 2022, 2024, 2033, 2034,

2036, 2047, 2053, 2061, 2068, 2070

XR-1000 ........................................................... 2017, 2022, 2036

Yamaha ....................................... 2005, 2006, 2007, 2014, 2057

Zenith ................................ 2003, 2049, 2052, 2062, 2071, 2084

1662616C_01.indd 28 12/14/05 3:57:12 PM

Graphics contained within this publication are for representation only.

Troubleshooting

Many problems you encounter with your MediaBridge can be resolved by consulting the following troubleshooting list.

Network problems

No connection to the wireless network.

Check to make sure the wireless antenna is properly attached to the back of the MediaBridge.

Also, check the “link” indicator on the front panel of the MediaBridge. If the “link” indicator is not lit, the MediaBridge has not obtained an IP address. Check your router and network settings.

The MediaBridge displays duplicate wireless network names.

Wireless access points come conﬁgured with a default wireless network name. For example, wireless routers and access points made by Linksys default to “linksys” as the network name. If the MediaBridge is displaying duplicate names, it is receiving a wireless signal from two different routers which happen to use identical names. Change the name of your wireless network, or try both networks.

Unsure which wireless network is yours.

Your wireless access point or wireless router determines the name of your wireless network. Refer to the manual of your access point or router to determine the network name (also called the SSID).

The MediaBridge can’t ﬁnd one of the computers in my network.

If VPN (Virtual Private Network) software is installed on a computer in your network, the MediaBridge may not be able to see that computer. The MediaBridge is not designed to work with VPN software.

Firewall problems

All of the MediaBridge media libraries are empty.

If you have ﬁrewall software installed on your network, you may need to reconﬁgure that ﬁrewall software to allow the MediaBridge to access your network computers.

The MediaBridge software setup installs a background program on your computer(s) called “MediaStreamer.exe.” It is safe to allow this program to operate on the network. If the MediaStreamer program is blocked, the MediaBridge will not see any computers on the network, so the MediaBridge’s media libraries will be empty.

If you’re still having problems getting the MediaBridge to work with your ﬁrewall software, try making the following adjustments to your ﬁrewall settings:

• Port 6070 must be open for UDP-type network trafﬁc.

• Port 40001 must be open for TCP-type network trafﬁc.

• Port 40002 must be open for TCP-type network trafﬁc.

1662616C_01.indd 29 12/14/05 3:57:12 PM

Troubleshooting

Remote control problems

Unit does not respond to remote.

Make sure the remote is in the right “mode” to control the MediaBridge: press the MEDIA button, then try using the remote with the MediaBridge.

If that doesn’t work, check the following items:

• Make sure the batteries in the remote are fresh.

• Point the remote directly at the remote sensor on the front panel of the MediaBridge.

• Make sure the path between the remote control and the MediaBridge is clear.

• Try moving closer to the MediaBridge.

If the MediaBridge still does not respond, press the power button on the MediaBridge front panel to turn the MediaBridge off. Wait a minute or two, then press the power button on the front panel of the MediaBridge again to turn the MediaBridge on.

If the MediaBridge does not turn off, unplug the AC power cord from the wall outlet and wait a minute or two. Then, plug the unit back in and turn it back on.

MediaBridge problems

The MediaBridge power button doesn’t turn the unit off.

Unplug the AC power cord from the wall outlet and wait a minute or two. Then, plug the unit back in and turn it back on.

USB device problems

The MediaBridge can’t ﬁnd my USB device.

It might take the MediaBridge a few moments to recognize and scan your USB device once you’ve connected it to the USB port.

If you’re connecting an RCA Lyra to the MediaBridge using a USB connection, make sure the Lyra’s USB Protocol is set to Mass

Storage Class.

Please note that USB devices should be formatted as NTFS or FAT32 in order for the MediaBridge to play ﬁles from them. If your USB device is not recognized by the MediaBridge, check its formatting type.

Not all USB devices are compatible with the MediaBridge. The MediaBridge recognizes only certain kinds of USB devices: USB thumb drives, USB memory card readers, and USB hard drives.

1662616C_01.indd 30 12/14/05 3:57:13 PM

Troubleshooting

DivX is a registered trademark of DivX Networks, Inc. iTunes is a registered trademark of Apple Computer, Inc. Windows Media is a registered trademark of the Microsoft Corporation in the

United States and/or other countries. Manufactured under license from Dolby Laboratories. “Dolby” and the

double-D symbol are trademarks of Dolby Laboratories. DTS is a registered trademark of Digital Theater Systems, Inc.

Media library problems

Files recently saved on networked media source don’t appear on MediaBridge.

You may need to refresh the MediaBridge’s browser.

First, press the HOME button on the MediaBridge’s remote. From the main menu, select the library you want to browse. Then, look for the recently saved ﬁles again.

If these ﬁles still don’t show up in the library, wait about 60 seconds and press the HOME button again. From the main menu, select the library you want to browse. Then, look for the recently saved ﬁles again.

If you still don’t see the recently saved ﬁles in the library, restart the MediaBridge and browse the media library again.

If you still have trouble viewing ﬁles, make sure your ﬁles match the supported formats (see “My images, music ﬁles, or video ﬁles won’t play or display”).

File problems

My images, music ﬁles, or video ﬁles won’t play or display

Make sure the MediaBridge supports the ﬁle format or encoding you’re trying to play. The MediaBridge may not support all music and movie ﬁles purchased from online music or movie sites.

The MediaBridge supports the following types of ﬁle formats and codecs (in the next column):

File Container Formats

• MPEG Program (ISO 11172-1 and ISO/IEC 13818-1)

• MPEG Transport (ISO/IEC 13818-1)

• AVI (DivX® 3, 4, 5; DivX HD, XviD, MJPEG, DV Type 2)

• ASF, WMV (Windows Media® Video)

• ASX, WMA (Windows Media® Audio), MP3, WAV, M4A

• IFO, VOB

Video Codecs

• MPEG1 (ISO 11172-2) • MPEG2 (ISO 13818-2)

• MPEG4 (ISO/IEC 14496-2) • DV (requires wired link)

• MJPEG (requires wired link) • WMV (V7, V8 Partial, V9) (non-drm)

Audio Codecs

• MPEG1/2 Layers 1,2 and 3 (MP3) (ISO 11172-3)

• SPDIF passthru for Dolby® Digital and DTS® audio

• WMA (Standard, Pro and Lossless) (non-drm)

• WAV (LPCM)

• AAC (except for protected ﬁles from the iTunes® music store)

Image Formats

• JPEG w/ JFIF (ISO DIS10918-1) • BMP

• PNG (ISO 15948:2003) • Uncompressed TIFF

If higher-deﬁnition video does not play back over a wireless connection, try a wired connection.

1662616C_01.indd 31 12/14/05 3:57:13 PM

Troubleshooting

I can’t hear the audio from my movie.

If the movie you’re playing on the MediaBridge has multichannel audio, audio will only be available from the digital audio outputs. There will be no audio signal from the MediaBridge’s other audio outputs.

To hear multichannel audio, use one of the MediaBridge’s digital audio outputs to connect it to multichannel-capable receiver.

There’s a red exclamation mark next to one of the video or picture ﬁles in my library.

The MediaBridge displays a red exclamation mark next to video or picture ﬁles it has tried unsuccessfully to play.

The red exclamation mark means that the MediaBridge cannot play that particular ﬁle. There are several possible reasons for this—the ﬁle may have a name that the MediaBridge has trouble recognizing, or the ﬁle may be corrupt.

Please note that Windows Media Center Edition PCs use a proprietary ﬁle format for recording, and the MediaBridge cannot play these ﬁles.

Display problems

Only the “AR” (Acoustic Research) screen appears when I turn on the MediaBridge. I don’t see the main menu.

Make sure the SD/HD switch on the back of the MediaBridge is set to the right position for the type of connection you’re using between the MediaBridge and your TV or monitor.

If you used the MediaBridge’s VIDEO or S-VIDEO output jacks, set the SD/HD switch to SD.

If you used the MediaBridge’s DVI output jack, set the SD/HD switch to HD.

If you used the MediaBridge’s COMPONENT VIDEO jacks, set the SD/HD switch to match the kind of TV or monitor you have: SD for a standard-deﬁnition monitor or HD for a high-deﬁnition monitor.

1662616C_01.indd 32 12/14/05 3:57:13 PM

Troubleshooting

Picture Appears, But Colors Are Wrong.

• If using an S-Video or a VGA connection, ensure that the cables are ﬁrmly connected to both the MediaBridge and the display.

• If using a component video connection, unplug each of the three (red, green, blue) connectors from the MediaBridge and verify that the color of the plug matches the color of the connector on the MediaBridge. Swapping the red and blue connectors accidentally will result in improper color display. If this does not solve the problem, do the same check on the display connectors.

• You may have a defective cable. Try another cable of the same type.

Problems going between media types

I am viewing images and would now like to listen to music. How do I go back to the Music Player?

Press the MUSIC button on the remote to access the Music Media Library. Use the arrow buttons and OK to browse through the library and choose the song(s) you want to hear.

To listen to music and view images at the same time, see the next troubleshooting item.

I am listening to music and would like to view images. How do I go back to the Picture Viewer?

With your music playing, press the PICS button on the remote to access the Pictures Media Library. Use the arrow buttons and OK to ﬁnd the picture(s) you want to view (even in slideshow mode).

If you would like to view images without listening to music, press PAUSE while you’re viewing the slideshow/pictures. Then, press MUSIC and press STOP while the Music Media Library is on the screen. Press PICS and then select Resume Slideshow to return to the pictures/slideshow.

1662616C_01.indd 33 12/14/05 3:57:13 PM

Limited Warranty

Media Bridge LIMITED WARRANTY

What your warranty covers:

• Any defect in materials or workmanship.

For how long after your purchase:

• 1 Year - Unit exchange, which includes parts and labor.

What we will do:

• Exchange the defective portion of your Media Bridge with a new or, at our option, refurbished unit.

How you get service:

• Call 1-800 464 7022 and have your unit’s date of purchase and model/serial number ready. The model/serial number information is on the back or bottom of your unit.

• A representative will troubleshoot your problem over the phone.

• If the representative determines that you should receive a replacement unit you will be provided with a Service Request (SR) number and instructions on how to obtain the exchange. No returns will be accepted without the SR number.

What your warranty does not cover:

• Acts of nature, such as but not limited to lightning damage.

• Damage from misuse or neglect.

• A unit that has been modiﬁed or incorporated into other products or is used for institutional or other commercial purposes.

• Batteries.

• Installation.

• Shipping damage if the unit was not packed and shipped in the manner prescribed by Thomson.

Product Registration:

• Please complete and mail the Product Registration Card packed with your unit. It will make it easier to contact you should it ever be necessary. The return of the card is not required for warranty coverage.

Limitation of Warranty:

• THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. ALL OTHER WARRANTIES, EXPRESS OR IMPLIED (INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE) ARE HEREBY DISCLAIMED. NO VERBAL OR WRITTEN INFORMATION GIVEN BY THOMSON INC., ITS AGENTS OR EMPLOYEES SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS WARRANTY.

1662616C_01.indd 34 12/14/05 3:57:13 PM

Limited Warranty

• REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER. THOMSON INC. SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT OR ARISING OUT OF ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. THIS DISCLAIMER OF WARRANTIES AND LIMITED WARRANTY ARE GOVERNED BY THE LAWS OF THE STATE OF INDIANA. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED TO THE APPLICABLE WARRANTY PERIOD SET FORTH ABOVE.

How state law relates to warranty:

• Some states do not allow the exclusion nor limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you.

• This warranty gives you speciﬁc legal rights, and you also may have other rights that vary from state to state.

If you purchased your product outside the United States:

• This warranty does not apply. See your dealer for warranty information.

1662616C_01.indd 35 12/14/05 3:57:14 PM

The MediaBridge PC application, user’s guide, and warranty are available for download at www.acoustic-research.com. All open-source GPL code that has been modiﬁed is also available at that website.

Thomson Inc. 10330 North Meridian Street Indianapolis, IN 46290

Printed in China

TOCOM 1662616C

1662616C_01.indd 36 12/14/05 3:57:14 PM

Inventec DMP3000 Users Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
