Page 1
Parts Catalog
Pronto® M41™ with SureStep®
Issued: Jun 4, 2008
Powered Wheelchair
Yes, you can. ™
Page 2
Throughout this catalog you will notice letters to draw your attention to specific footnotes which are located at the
bottom of the page or below specified charts.
Parts Catalog Usage Guide
To order call toll free 1-800-333-6900, or www.invacare.com
The information contained in this document is subject to change without notice. This catalog contains
service parts for Form No. 06-108. If you have any questions regarding this catalog, please contact one
of our Customer Service Representatives.
For Customer Service Support Call:
1-800-333-6900
For Faxed In Orders Call:
1-800-678-4682 or
1-440-366-0709
For Technical Service Call:
1-800-832-4707
Literature Can Be Found at:
www.invacare.com or
1-800-828-6272
SYMBOL DEFINITION
Examples:
A,B,C etc.
NOTE:
NLA
= Special Comments
= General information pertaining to that specific page
= No Longer Available
HARDWARE MEASUREMENTS
The measurements for the hardware will be listed as follows:
Screws, Bolts
Washers
Spacers
For your convenience, we have supplied an area for you to list your Invacare Representatives.
©2008 Invacare Corporation. Elyria, Ohio. Invacare, Yes, you can., the Medallion Design, Pronto, and SureStep are registered trademarks and M41, MK5,
Diameter X Thread Count/Pitch X Length
Inside Diameter X Outside Diameter X Thickness
Inside Diameter X Outside Diameter X Length
Name Phone Numbers
NX, and SPJ are trademarks of Invacare Corporation.
Form No.
06-108
1
Page 3
Electronics - MK5 NX Controllers and Battery Chargers (For Ser. #'s Starting w/ 08C... &
Before)
Electronics - MK5 SPJ+ Joystick and Mounting Hardware (For Ser. #'s Starting w/ 08C... &
Before)
TABLE of CONTENTS
Page
Number
To order call toll free 1-800-333-6900, or www.invacare.com
Form No.
06-108
Description
Arms ......................................................................................................................................... 15
Battery Harnesses .................................................................................................................... 23
Casters and Forks .................................................................................................................... 20
Electronics - Joystick/Controller, A-Series Integrated (For Ser. #'s 08DSZ190001 & After) .... 47
45
43
Frame Finish, Touch Up Paint and Shroud Colors ................................................................... 4
Frame, Base and Seat Post Assembly ..................................................................................... 7
Front Rigging - Footboard Assembly - 90FB ............................................................................ 24
Front Rigging - Footrest Support (Hemi) - PHW93 .................................................................. 31
Front Rigging - Front Rigging Hangers (Hemi) ......................................................................... 26
Front Rigging - Legrest Support (Hemi) - PH904A ................................................................... 33
Front Rigging - Legrest Support Articulating (Hemi) - PHAL4A ............................................... 36
Front Rigging - Pivot/Slide Tube and Footplates - PH904A and PHAL4A ............................... 41
Front Rigging - Pivot/Slide Tube and Footplates - PHW93 ...................................................... 39
Front Rigging - Reference Chart .............................................................................................. 28
Motor, Drive Wheel, and Hardware .......................................................................................... 22
Oxygen Holder Assembly - Semi-Recline Van Seat ................................................................ 49
Packaging, Literature and Decals ............................................................................................ 5
Shrouds and Attaching Hardware ............................................................................................ 18
Swingarm Assembly and Hardware - SureStep ....................................................................... 8
2
Page 4
TABLE of CONTENTS
Page
Number
To order call toll free 1-800-333-6900, or www.invacare.com
Form No.
06-108
Description
Van Seat Assemblies & Mounting Hardware ........................................................................... 10
Van Seat Frame and Mounting Hardware ................................................................................ 13
3
Page 5
Frame Finish
Color Number Part Number Bottle Size Color
Flat Black.6 oz104632734P
Shroud Colors
Color Number Color
Deep BlueBL/DBLM
Candy RedRD/CRDM
Touch Up Paint and Shroud Colors
Form No.
06-108
To order call toll free 1-800-333-6900, or www.invacare.com
4
Page 6
Packaging, Literature and Decals
Form No.
06-108
5
To order call toll free 1-800-333-6900, or www.invacare.com
Page 7
Packaging, Literature and Decals
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1127296 Carton, Cover Base 1 11
1015592 Bag, Poly (72" L x 35" W x 19" D) 1 12
1127294 Insert, Carton 1 23
1134728 Carton, Corner Reinforcement 1 44
1127295 Tray, Carton 1 15
1143837 Kit, Literature (A-series Controller w/ Programming) 1 16 A
Warranty Card 1 1
Manual, Owner's M41 1 1
Manual, Instruction MK5 A-Series Programmer 1 1
Cable Tie (11-1/2" Long) 1 3
1143704 Carton, Corner Reinforcement 1 47
1143705 Carton, Shipper 1 18
1143701 Decal, Model M41 1 2B
1095489 Decal, Invacare 3-D Logo (2-1/2" L) 1 1B
1143237 Label, Battery Warning 1 1B
A - Includes Owner's Manual, MK5 Programmer Manual, and Warranty Card. Individual pieces of literature are available within
the kit only.
B - Not Shown
NOTE
: When adjusting or replacing parts, please refer to your owner's manual for assistance.
NOTE:
Form No.
06-108
6
To order call toll free 1-800-333-6900, or www.invacare.com
Page 8
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1143826 Frame Assembly 1 11 A
40117X006 Bearing (5/8") 1 42
1110717 Ring, Tolerance 1 43
1143697 Post, Seat Pivot 1 14
1124252 Screw, Socket Head Cap w/ Patch (3/8-16 x 2") 1 15
1127353 Grommet, Rubber 1 26
A - Includes Frame and items 2 and 3.
NOTE:
Base Frame Assembly and Seat Post
Form No.
06-108
7
To order call toll free 1-800-333-6900, or www.invacare.com
Page 9
Swingarm Assembly and Hardware - SureStep
Form No.
06-108
8
To order call toll free 1-800-333-6900, or www.invacare.com
Page 10
Swingarm Assembly and Hardware - SureStep
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1127400 Spring, Extension (1" I.D. x 4-1/2" Long) 1 11
1143829 Bracket, Stop Spring with Flanged Bearing and
Hook Fastener - Right
1 12 A
1143830 Bracket, Stop Spring with Flanged Bearing and
Hook Fastener - Left
1 12 A
1143678 Swingarm Assembly - Right 1 13 B
1143679 Swingarm Assembly - Left 1 13 B
1108437 Bumper, Rubber 1 24
000037 Nut, Keps (5/16-18) 1 25
40117X006 Bearing (5/8") 1 26
1110717 Ring, Tolerance 1 27
1140994 Bearing, Flange (5/8 x 23/32 x 1/2") 1 28
1110685 Spacer, Bushing 1 19
1028550 Locknut (5/8-18) 1 110
1121024 Screw, Hex Head Cap with Patch (1/4-20 x 5/8") 1 411
A - Stop Spring Bracket includes flanged bearing and hook fastener.
B - Includes Swingarm plus item 4-8.
NOTE:
Form No.
06-108
To order call toll free 1-800-333-6900, or www.invacare.com
9
Page 11
Van Seat Assemblies & Mounting Hardware
Form No.
06-108
10
To order call toll free 1-800-333-6900, or www.invacare.com
Page 12
Van Seat Assemblies & Mounting Hardware
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1141942 Van Seat, Fold Down 18" (Grey Vinyl Upholstery) 1 11 A
1141938 Arm Assembly - Right 1 12 G
1141939 Arm Assembly - Left 1 12 G
1145425 Cover, Back 1 13
1116413 Pivot, Seat 1 14
1125419 Washer (11/32 x 11/16 x 1/16") 1 45
1088117 Screw, Hex Head (5/16 x 18 x 1-1/4") 1 46
1127312 Package, Adjustment Knobs (5/16-18 x 3/4") 3 17
1141933 Positioning Strap, Seat/Chest w/ Auto Style Push
Button Buckle (eyelet to eyelet length 61")
1 18
1025195 Locknut (1/4-20) 1 39 F
1101524 Spacer (1/4 x 7/16 x 5/8") 1 310 F
1105049 Clamp Assembly, Captain/Van Seat 1 111 F
1057955 Screw, Hex Head (1/4-20 x 1-1/4") 1 312 F
1145426 Cover, Seat 1 113
1127716 Van Seat, Semi Recline Office Style w/ Backrest -
18" (Dark Grey/Charcoal Vinyl)
1 114 B,C,D
1127312 Package, Adjustment Knobs (5/16-18 x 3/4") 3 115 J
1127311 Package, Screws Socket Head Cap w/ Patch
(1/4-20 x 3/4")
4 116 E,J
1116413 Pivot, Seat 1 117 H,I,J
1092409 Washer, Steel (5/16 x 1-1/4 x 1/16") 1 418 H,I,J
1057955 Screw, Hex Head (1/4-20 x 1-1/4") 1 419 I,J
1127314 Backrest Extension, Semi Recline Office Style Van
Seat
1 120 J
1034625 Positioning Strap, Seat/Chest w/ Auto Style Push
Button Buckle
(Eyelet to Eyelet Length 61")
1 121 J
1144924 Bracket, Seat Frame 18" 1 122 J
1123426 Van Seat, Semi Recline w/ Backrest - 16" Grey
Vinyl
1 123 H,K
1109243 Van Seat, Semi Recline w/ Backrest - 20" Grey
Vinyl
1 123 I,K
1123012 Bracket, Seat Frame - 16" or 20" W Chair (RT- has
Release Handle)
1 124
1123013 Bracket, Seat Frame - 16" or 20" W Chair (LT) 1 125
1004310 Positioning Strap, Seat/Chest w/ Auto Style Push
Button Buckle
(Eyelet to Eyelet Length 48")
1 126 H
1034622 Positioning Strap, Seat/Chest w/ Auto Style Push
Button Buckle
(Eyelet to Eyelet Length 69")
1 126 I
1088897 Screw, Hex Head (1/4-20 x 1-1/4") 1 428 H,I
1026900 Washer (1/4 x 23/32 x 1/16") 1 429 H,I
1114911 Knob, Adjustment (5/16-18 x 1-1/2") 1 130 H,I
Form No.
06-108
11
To order call toll free 1-800-333-6900, or www.invacare.com
Page 13
Van Seat Assemblies & Mounting Hardware
A - Includes items 2-13.
B - Includes items 15-22. When replacing Semi Recline Van Seat, the front rigging hanger attachment kit may need to be
ordered as well since it is not included (see Front Rigging Hanger category).
C - Semi Recline Van Seat reclines approximately 90-114 degrees. Adjustable depths are 16, 17, and 18" deep. Recline
release levers are standard on the right side.
D - Arms are not included with the Semi Recline Van Seat. See Arm category for service part nos.
E - Package includes 4 screws, they are used to attach the Seat Positioning Strap (item 8)
F - Please see Electronics - SPJ+ Joystick category for Joystick Tube Mounting Hardware Kit.
G - Used on the Fold-Down Seat.
H - Used with the 16" wide Semi-Recline Office Style Van Seat.
I - Used with the 20" wide Semi-Recline Office Style Van Seat.
J - Used with the 18" wide Semi-Recline Office Style Van Seat.
K - Includes items 24 & 25
NOTE:
12
Form No.
06-108
To order call toll free 1-800-333-6900, or www.invacare.com
Page 14
Van Seat Frame and Mounting Hardware
If converting a chair from Office Style Van Seat to Semi-Recline Van Seat items 1, 13, and 15 must be
ordered in addition to the seat.
Form No.
06-108
13
To order call toll free 1-800-333-6900, or www.invacare.com
Page 15
Van Seat Frame and Mounting Hardware
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1119577 Kit, Van Seat Mounting Hardware 1 11 A,B
Screw, Hex Head Cap with Patch (1/4-20 x 1") 1 42
Washer (1/4 x 23/32 x 1/16") 1 63
Screw, Hex Head (1/4-20 x 1-1/4") 1 24
Spacer (1/4 x 5/8 x 1/4") 1 25
Spacer, Coved (1/4 x 11/16 x 1/2") 1 46
Screw, Hex Head w/Patch (1/4-20 x 2-1/2") 1 27
Plug Button, Black (1") 1 28
Locknut (5/16-18) 1 49
Washer, Steel (5/16 x 1-1/4 x 1/16") 1 410
Screw, Hex Head Cap w/ Patch (5/16-18 x 1") 1 411
Knob, Adjustment (5/16-18 x 1-1/2") 1 112
1092409 Washer, Steel (5/16 x 1-1/4 x 1/16") 1 410
1104258 Screw, Hex Head Cap w/ Patch (5/16-18 x 1") 1 411
1116919 Bracket, Seat Mounting 1 113 C
1116413 Pivot, Seat 1 114
1123391 Frame, Van Seat - 16" Wide 1 115
1116393 Frame, Van Seat - 20" Wide 1 115
1136494 Kit, Van Seat Mounting Hardware - Office Style 1 116 E
Washer, Steel (5/16 x 1-1/4 x 1/16") 1 417
Screw, Hex Head Cap with Patch (1/4-20 x 1-1/2") 1 418
A - Item 8, Plug Buttons, are only used in the absence of front riggings.
B - Includes items 2-12
C - Van Seats without Solid Seat Base
E - Includes items 17-18
NOTE:
If converting a chair from Office Style Van Seat to Semi-Recline Van Seat items 1, 13, and 15 must be
ordered in addition to the seat.
Form No.
06-108
14
To order call toll free 1-800-333-6900, or www.invacare.com
Page 16
Arms
Form No.
06-108
15
To order call toll free 1-800-333-6900, or www.invacare.com
Page 17
Arms
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1141938 Arm Assembly - Right 1 11 A
1141939 Arm Assembly - Left 1 11 A
1141937 Arm Pad - Full Length, Black Urethane 1 22 B
1142487 Upper Arm Assembly, Desk Length (Right/Left) 1 13 C
Arm Pad - Desk Length, Black Urethane (12-1/4" L
x 2-5/8" W)
1 14
Screw, Socket Head Cap with Patch (5/16-18 x
1-3/4")
1 15
Washer, Flat (5/16 x 5/8 x 1/16") 1 26
Locknut (5/16-18) 1 17
Screw, Hex Head (5/16-18 x 1-1/4") 1 18
Nut, Hex (5/16-18) 1 19
Arm Tube, Upper Adjustable Height 1 110
1139923 Arm Pad - Desk Length, Black Urethane (12-1/4" L
x 2-5/8" W)
1 14
1140426 Upper Arm Assembly, Full Length (Right/Left) 1 13 C
Arm Pad - Full Length, Black Urethane (15" L x
2-5/8" W)
1 14
Screw, Socket Head Cap with Patch (5/16-18 x
1-3/4")
1 15
Washer, Flat (5/16 x 5/8 x 1/16") 1 26
Locknut (5/16-18) 1 17
Screw, Hex Head (5/16-18 x 1-1/4") 1 18
Nut, Hex (5/16-18) 1 19
Arm Tube, Upper Adjustable Height 1 110
1139924 Arm Pad - Full Length, Black Urethane (15" L x
2-5/8" W)
1 14
1114910 Knob, Adjustment (5/16-18 x 3/4") 1 211
1113646 Arm Tube, Lower Adjustable Width - Right 1 112
1113647 Arm Tube, Lower Adjustable Width - Left 1 112
1142493 Arm Assembly, Desk Length Adj. Height - Right 1 113 D
1142492 Arm Assembly, Desk Length Adj. Height - Left 1 113 D
1142474 Arm Assembly, Full Length Adj. Height - Right 1 113 D
1142475 Arm Assembly, Full Length Adj. Height - Left 1 113 D
1142488 Arm Assembly, Desk Length Fixed Height - Right 1 114 E
Arm Pad - Desk Length, Black Urethane (12-1/4" L
x 2-5/8" W)
1 115
Screw, Socket Head Cap with Patch (5/16-18 x
1-3/4")
1 116
Washer, Flat (5/16 x 5/8 x 1/16") 1 217
Locknut (5/16-18) 1 118
Screw, Hex Head (5/16-18 x 1-1/4") 1 119
Nut, Hex (5/16-18) 1 120
Knob, Adjustment (5/16-18 x 3/4") 1 121
Arm Tube, Fixed Height - Right 1 122
Form No.
06-108
To order call toll free 1-800-333-6900, or www.invacare.com
16
Page 18
Arms
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1139923 Arm Pad - Desk Length, Black Urethane (12-1/4" L
x 2-5/8" W)
1 115
1142489 Arm Assembly, Desk Length Fixed Height - Left 1 114 E
Arm Pad - Desk Length, Black Urethane (12-1/4" L
x 2-5/8" W)
1 115
Screw, Socket Head Cap with Patch (5/16-18 x
1-3/4")
1 116
Washer, Flat (5/16 x 5/8 x 1/16") 1 217
Locknut (5/16-18) 1 118
Screw, Hex Head (5/16-18 x 1-1/4") 1 119
Nut, Hex (5/16-18) 1 120
Knob, Adjustment (5/16-18 x 3/4") 1 121
Arm Tube, Fixed Height - Left 1 122
1139923 Arm Pad - Desk Length, Black Urethane (12-1/4" L
x 2-5/8" W)
1 115
1142483 Arm Assembly, Full Length Fixed Height - Right 1 114 E
Arm Pad - Full Length, Black Urethane (15" L x
2-5/8" W)
1 115
Screw, Socket Head Cap with Patch (5/16-18 x
1-3/4")
1 116
Washer, Flat (5/16 x 5/8 x 1/16") 1 217
Locknut (5/16-18) 1 118
Screw, Hex Head (5/16-18 x 1-1/4") 1 119
Nut, Hex (5/16-18) 1 120
Knob, Adjustment (5/16-18 x 3/4") 1 121
Arm Tube, Fixed Height - Right 1 122
1139924 Arm Pad - Full Length, Black Urethane (15" L x
2-5/8" W)
1 115
1142486 Arm Assembly, Full Length Fixed Height - Left 1 114 E
Arm Pad - Full Length, Black Urethane (15" L x
2-5/8" W)
1 115
Screw, Socket Head Cap with Patch (5/16-18 x
1-3/4")
1 116
Washer, Flat (5/16 x 5/8 x 1/16") 1 217
Locknut (5/16-18) 1 118
Screw, Hex Head (5/16-18 x 1-1/4") 1 119
Nut, Hex (5/16-18) 1 120
Knob, Adjustment (5/16-18 x 3/4") 1 121
Arm Tube, Fixed Height - Left 1 122
1139924 Arm Pad - Full Length, Black Urethane (15" L x
2-5/8" W)
1 115
A - Includes Arm Tube, Arm Pad (item 2), and Attaching Hardware.
B - Arm Pad does not include attaching hardware. Item 1 must be ordered if hardware is needed.
C - Includes items 4-10.
D - Includes items 4-12.
E - Includes items 15-22.
NOTE:
Form No.
06-108
17
To order call toll free 1-800-333-6900, or www.invacare.com
Page 19
Shrouds and Attaching Hardware
Form No.
06-108
18
To order call toll free 1-800-333-6900, or www.invacare.com
Page 20
Shrouds and Attaching Hardware
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1026114 Screw, Phillips Pan Head (#10-32 x 1/2") 1 21
1145420 Shroud, Controller (Black) 1 12
1143701 Decal, Model M41 1 13
1028484 Screw, Phillips Pan Head Tap (#10-32 x 1/2") 1 44
1035900 Decal, Transportation 1 15
1119281 Name Plate, Patent Numbers 1 16
1147276 Screw, Phillips Pan Head (8/16 x 5/8") 1 67
1028516 Washer (3/16 x 7/16 x 1/16") 1 68
1145423 Top Shroud Assembly (Red) 1 19 A
1145424 Top Shroud Assembly (Blue) 1 19 A
1145419 Shroud, Front (Black) 1 110
1025735 Locknut (#10-32) 1 211
1095489 Decal, Invacare 3-D Logo (2-1/2" L) 1 112
A - Shroud includes decals, items 3, 5-6 & 12.
NOTE:
Form No.
06-108
To order call toll free 1-800-333-6900, or www.invacare.com
19
Page 21
Casters and Forks
Form No.
06-108
20
To order call toll free 1-800-333-6900, or www.invacare.com
Page 22
Casters and Forks
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1110709 Cap, Headtube 1 11
1106226 Kit, Fork Mounting Hardware 1 12 A
1028550 Locknut (5/8-18) 1 13
1041444 Washer (5/8 x 1-5/16 x 1/8") 1 14
1106068 Spacer, Stem (5/8 x 1-1/8 x 3/16") 1 15
1140984 Fork and Stem 1 16
1110708 Kit, Caster Mounting Hardware 1 17 B
1025726 Screw, Hex Head (7/16-20 x 3-1/4") 1 18
1025724 Washer (15/32 x 5/8 x 3/64") 1 29
1025734 Locknut (7/16-20) 1 110
1115179 Wheel with Bearings, 6 x 2" Urethane Deep Profile 1 111
A - Includes Items 3-5.
B - Includes Items 8-10.
NOTE:
Form No.
06-108
21
To order call toll free 1-800-333-6900, or www.invacare.com
Page 23
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1025737 Locknut (1/2-20) 1 11
1026174 Washer (1/2 x 7/8 x 3/64") 1 12
1105043 Wheel, Drive with Tire and Bearings - Flat Free (10"
x 3")
1 13
1102342 Tire w/ Flat-Free (10" x 3") 1 1
1121024 Screw, Hex Head Cap with Patch (1/4-20 x 5/8") 1 44
1023264 Key (6 MM x 6MM x 40 MM) 1 15
1134124 Motor and Gearbox Assembly - Right 1 16 A
1134125 Motor and Gearbox Assembly - Left 1 16 A
1143707 Package, Brake Lever Tips, Black 10 17
A - Brushes are not serviceable on these motors.
NOTE:
Motor, Drive Wheel, and Hardware
Form No.
06-108
To order call toll free 1-800-333-6900, or www.invacare.com
22
Page 24
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1122247 Harness, Battery with 75 Amp Fuse 1 11
1122244 Harness, Battery - Rear 1 12
1122245 Harness, Battery with 75 Amp Fuse 1 13
1122246 Harness, Battery - Front 1 14
1096799 Screw, Hex Flange Whiz Lock (1/4-20 x 7/8") 1 25
16721X000 Locknut (1/4-20) 1 46
1116381 Cable, Battery Extension (75 Amp) (Black
Connector)
1 17
Battery Harnesses
Form No.
06-108
23
To order call toll free 1-800-333-6900, or www.invacare.com
Page 25
Footboard Assembly - 90FB
Form No.
06-108
24
To order call toll free 1-800-333-6900, or www.invacare.com
Page 26
Footboard Assembly - 90FB
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1114312 Footboard Assembly 1 11 A
1105038 Cap, Tube (1" Square) 1 12
1106369 Bracket, Footboard Support (Black) 1 13
1049527 Washer, Nylon (3/8 x 3/4 x 1/16") 1 24
1028769 Locknut (5/16-18) 1 15
1108457 Screw, Socket Set Flat (5/16-18 x 1") 1 16
1065214 Washer, Flat (3/8 x 11/16 x 1/16") 1 17
1106223 Screw, Socket Head (3/8-16 x 2-1/2") 1 18
1105039 Bushing (3/8 x 5/8 x 1/2") 1 19
1028486 Locknut, Low Profile (3/8-16) 1 110
1114311 Footboard w/ Cover (11-1/4" Wide x 11-1/2" Long) 1 111
1109011 Pin, Quick Release 1 112
A - Includes items 2-12
NOTE:
Form No.
06-108
25
To order call toll free 1-800-333-6900, or www.invacare.com
Page 27
Front Riggings Hangers
Hemi
Front Rigging Hangers for Fold Down Seat are not available.
Form No.
06-108
26
To order call toll free 1-800-333-6900, or www.invacare.com
Page 28
Front Riggings Hangers
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1149192 Kit, Front Rigging Seat Support, 18" 1 11 A,B,C
Carton, Inner 1 12
Bracket, Front Rigging Hanger 1 23
Screw, Socket Button Head w/ Patch
(1/4-20 x 3/4")
1 44
Washer (1/4 x 23/32 x 1/16") 1 45
1148879 Kit, Front Rigging Seat Support, 20" 1 11 A
Bracket, Front Rigging Hanger 1 23
Screw, Socket Button Head w/ Patch
(1/4-20 x 3/4")
1 44
Washer (1/4 x 23/32 x 1/16") 1 45
1133009 Kit, Front Rigging Hanger Attachment 1 16 D
Carton, Inner 1 17
Front Rigging Hanger Assembly w/ Plug Button
(Hemi) - Left
1 18
Front Rigging Hanger Assembly w/ Plug Button
(Hemi) - Right
1 19
Bag, Zip Lip 1 110
Screw, Hex Head (1/4-20 x 1-1/2") 1 411
Spacer (1/4 x 3/8 x 3/16") 1 412
Locknut (1/4-20) 1 413
Instruction Sheet, Front Rigging Hanger 1 114
1113045 Kit, Front Rigging Hanger Hardware 1 115 E
Screw, Hex Head (1/4-20 x 1-1/2") 1 416
Spacer (1/4 x 3/8 x 3/16") 1 417
Locknut (1/4-20) 1 418
Bag, Zip Lip (4" x 4") 1 119
A - For Office Style Van Seat.
B - Items 11-13 can be ordered separately. Order item 15, part no. 1113045.
C - Includes items 2-5.
D - Includes items 7-14.
E - Includes items 16-19.
NOTE:
Hemi
Front Rigging Hangers for Fold Down Seat are not available.
Form No.
06-108
27
To order call toll free 1-800-333-6900, or www.invacare.com
Page 29
Support Assemblies
Legrest Calf Pad is not included with support assemblies. Please see specific front rigging category for
part numbers.
Front
Rigging
Color
Right
Color
Left
Chrome
Right
Chrome
Left
N/AN/A11147561114755PHW93
N/AN/A
8881114758
8881114757
PH904A
See Note(s) A See Note(s) A
11147621114761N/AN/APHAL4A
A - Specify 34P Flat Black Frame Finish When Ordering. NOTE:
PHW93
Pivot Slide Tubes with Footplates
Chair
Width
Aluminum
(1650)
Deluxe
Aluminum
(1450)
Extra Large
Aluminum
(1350)
Adjustable
Angle
(AT5543)
Composite
(1651)
10578691062756102639510741511074149
16" Wide
Right
10578701062757102639610741521074150
16" Wide
Left
10578791062756102639510741511074149
17-20" Wide
Right
10578801062757102639610741521074150
17-20" Wide
Left
NOTE: Pivot/ Slide Tube Mounting Hardware is not included.
PHAL4A
Pivot Slide Tubes with Footplates
Chair
Width
Aluminum
(1650)
Deluxe Aluminum
(1450)
Extra Large Aluminum
(1350)
103545610239241023907
16-20" Wide
Right
103545710239251023908
16-20" Wide
Left
NOTE: Pivot/ Slide Tube Mounting Hardware is not included.
Front Rigging Reference Chart
Form No.
06-108
To order call toll free 1-800-333-6900, or www.invacare.com
28
Page 30
Front Rigging Reference Chart
PH904A
Pivot Slide Tubes with Footplates
Chair
Width
Aluminum
(1650)
Deluxe Aluminum
(1450)
Extra Large Aluminum
(1350)
105883010287231058604
16-20" Wide
Right
105883110287241058605
16-20" Wide
Left
NOTE: Pivot/ Slide Tube Mounting Hardware is not included.
PHW93 (2" and 4" Longer) Aluminum, Extra Large, and Adj. Angle
Pivot Slide Tubes with Footplates
Footplate
Type
16-20" Wide
Right
16-20" Wide
Left
10864971086494
Aluminum (1650)
2" Longer
10864981086495
Aluminum (1650)
4" Longer
10865171086515
Extra Large Aluminum (1350)
2" Longer
10865181086516
Extra Large Aluminum (1350)
4" Longer
10627611062760
Adjustable Angle (AT5543)
2" Longer
NOTE: Pivot/ Slide Tube Mounting Hardware is not included.
PHW93 (2" and 4" Longer) - Composite (1651)
Pivot Slide Tubes with Footplates
Footplate
Type
16" Wide
Right
16" Wide
Left
17-20" Wide
Right
17-20" Wide
Left
1057882105788110578721057871
Composite (1651)
2" Longer
1058424105842310584221058421
Composite (1651)
4" Longer
NOTE: Pivot/ Slide Tube Mounting Hardware is not included.
Form No.
06-108
To order call toll free 1-800-333-6900, or www.invacare.com
29
Page 31
Front Rigging Reference Chart
PH904A (2" and 4" Longer)
Pivot Slide Tubes with Footplates
Footplate
Type
16-20" Wide
Right
16-20" Wide
Left
10865311086529
Aluminum (1650)
2" Longer
10865321086530
Aluminum (1650)
4" Longer
10865511086541
Extra Large Aluminum (1350)
2" Longer
10865521086542
Extra Large Aluminum (1350)
4" Longer
NOTE: Pivot/ Slide Tube Mounting Hardware is not included.
Form No.
06-108
To order call toll free 1-800-333-6900, or www.invacare.com
30
Page 32
Footrest Support - PHW93 (Hemi)
Black
For complete Footrest Support Assembly part nos., see Front Riggings Reference chart.
Form No.
06-108
31
To order call toll free 1-800-333-6900, or www.invacare.com
Page 33
Footrest Support - PHW93 (Hemi)
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1020719 Anti-Rattle, Black 1 11
1025716 Screw, Phillips Pan Head (#10-32 x 11/16") 1 12
47565X057 Bushing (7/32 x 3/8 x 11/32") 1 13
1025735 Locknut (#10-32) 1 14
1026114 Screw, Phillips Pan Head (#10-32 x 1/2") 1 15
1114749 Release Handle (Black) - Right 1 16 A
1114750 Release Handle (Black) - Left 1 16 A
1028846 Rivnut (#10-32) 1 17
1028707 Spring, Release - Right 1 18
1028708 Spring, Release - Left 1 18
1006490 Tip, Plastic, Black 1 19
15680X012 Collar, Anti-Rattle (7/8") 1 110
1070759 Screw, Hex Head (1/4-20 x 1-1/2") 1 111
1026099 Spacer, Coved (1/4 x 11/16 x 1/2") 1 212
1044214 Nut, Hex with Nylon Cap (1/4-20) 1 113
1020534 Insert, Threaded 1 114
1074143 Kit, Slide Tube Mounting Hardware 1 115
1114755 Footrest Support Assembly, Hemi, Black - Right 1 1B
1114756 Footrest Support Assembly, Hemi, Black - Left 1 1B
A - Includes items 2-4
B - Not Shown
NOTE:
Black
For complete Footrest Support Assembly part nos., see Front Riggings Reference chart.
Form No.
06-108
32
To order call toll free 1-800-333-6900, or www.invacare.com
Page 34
Legrest Support - PH904A (Hemi)
For complete Legrest Support Assembly part nos., see Front Riggings Reference chart.
Form No.
06-108
33
To order call toll free 1-800-333-6900, or www.invacare.com
Page 35
Legrest Support - PH904A (Hemi)
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1114749 Release Handle (Black) - Right 1 11 D
1114750 Release Handle (Black) - Left 1 11 D
1025716 Screw, Phillips Pan Head (#10-32 x 11/16") 1 12
47565X057 Bushing (7/32 x 3/8 x 11/32") 1 13
1025735 Locknut (#10-32) 1 14
1026114 Screw, Phillips Pan Head (#10-32 x 1/2") 1 15
1008935 Spring, Release - Right 1 16
1008936 Spring, Release - Left 1 16
67005X000 Rivnut (#10-32) 1 17
1030979 Screw, Phillips Pan Head Tap (#10-32 x 3/4") 1 18
1022874 Bumper 1 19
1114753 Support Bracket Assembly, Legrest (Black) - Right 1 110 E
1114754 Support Bracket Assembly, Legrest (Black) - Left 1 110 E
1006490 Tip, Plastic, Black 1 111
11919X000 Screw, Truss Head (3/8-16 x 1-1/2") 1 112
40363X000 Hex Nut (3/8"-16) 1 113
1037126 Handle, Release 1 114
1040060 Tip, Black Plastic 1 115
1058636 Washer, Nylon (25/64 x 7/8 x 1/32") 1 216
8881048851 Tube, Elevating Support (Color) - Right 1 117 A
8881048852 Tube, Elevating Support (Color) - Left 1 117 A
47328X003 Bushing, Pivot (5/16 x 7/16 x 7/8") 1 118
1037110 Screw, Hex Head (5/16-24 x 3-1/2") 1 119
1025730 Locknut (5/16-24) 1 220
1026030 Screw, Lug (5/16-24 x 1-3/8") 1 121
1110207 Bracket, Calf Pad, Black 1 122
1025133 Spacer, Legrest Pad 1 123
04526X019 Plate, Legrest Pad 1 124
48823X008 Spring, Leaf 1 125
1113030 Bar, Ratchet 1 126
47330X003 Spacer (5/16 x 1/2 x 3/8") 1 227
1013519 Washer, Nylon (5/16 x 11/16 x 1/16") 1 128
04528X002 Bracket, Release (Chrome) 1 129
10261X000 Acorn Nut (5/16"-24) 1 130
1040831 Snap Ring 1 131
1037125 Cam, Legrest 1 132
1037485 Spring, Release 1 133
8881091764 Pad, Legrest Vinyl - Right/Left 1 134 B
1068649 Screws, Phillips Head (#10-32 x 11/16") 2 135
8881114757 Legrest Support Assembly, Hemi, Color - Right 1 1A,C,F
8881114758 Legrest Support Assembly, Hemi, Color - Left 1 1A,C,F
For complete Legrest Support Assembly part nos., see Front Riggings Reference chart.
Form No.
06-108
34
To order call toll free 1-800-333-6900, or www.invacare.com
Page 36
Legrest Support - PH904A (Hemi)
A - Specify 34P flat black frame finish when ordering
B - Specify upholstery color U67 black when ordering
C - Not Shown
D - Includes items 2-4
E - Includes items 1-9
F - Includes items 1-33. Legrest Calf Pad is not included with support assemblies. Please see items 34 and 35.
NOTE:
For complete Legrest Support Assembly part nos., see Front Riggings Reference chart.
Form No.
06-108
35
To order call toll free 1-800-333-6900, or www.invacare.com
Page 37
Articulating Legrest Support - PHAL4A (Hemi)
Chrome
For complete Legrest Support Assembly part nos., see Front Riggings Reference chart.
Form No.
06-108
36
To order call toll free 1-800-333-6900, or www.invacare.com
Page 38
Articulating Legrest Support - PHAL4A (Hemi)
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1030979 Screw, Phillips Pan Head Tap (#10-32 x 3/4") 1 11
1022874 Bumper 1 12
1114751 Release Handle (Chrome) - Right 1 13 C
1114752 Release Handle (Chrome) - Left 1 13 C
47565X057 Bushing (7/32 x 3/8 x 11/32") 1 14
60279X003 Locknut (#10-32) 1 15
40163X008 Screw, Phillips Pan Head (#10-32 x 11/16") 1 16
1008935 Spring, Release - Right 1 17
1008936 Spring, Release - Left 1 17
67005X000 Rivnut (#10-32) 1 18
40163X002 Screw, Phillips Round Head (#10-32 x 1/2") 1 19
1114759 Tube, Legrest Support (Chrome) Hemi - Right 1 110 D
1114760 Tube, Legrest Support (Chrome) Hemi - Left 1 110 D
1027097 Plug Button, Black (3/4") 1 111
1006490 Tip, Plastic, Black 1 112
1040060 Tip, Black Plastic 1 113
1037126 Handle, Release 1 114
1049527 Washer, Nylon (3/8 x 3/4 x 1/16") 1 215
1022866 Screw, Socket Button Head (3/8-16 x 3/4") 1 216
40363X000 Hex Nut (3/8"-16) 1 317
1022846 Bar, Link, Chrome 1 118
1022877 Tube Support and Drive Link - Right 1 119
1022878 Tube Support and Drive Link - Left 1 119
1022854 Screw, Slotted Head Shoulder (1/2 x 1-1/8") 1 120
10261X000 Acorn Nut (5/16"-24) 1 121
04528X002 Bracket, Release (Chrome) 1 122
1040831 Snap Ring 1 123
47328X003 Bushing, Pivot (5/16 x 7/16 x 7/8") 1 224
42326X004 Bar, Ratchet - Right/Left 1 125
1037485 Spring, Release 1 126
1037125 Cam, Legrest 1 127
1013519 Washer, Nylon (5/16 x 11/16 x 1/16") 1 128
1024911 Decal, Smartleg 1 129
1014807 Screw, Hex Head (5/16-24 x 3-1/4") 1 130
48823X008 Spring, Leaf 1 131
47328X003 Bushing, Pivot (5/16 x 7/16 x 7/8") 1 132
1025133 Spacer, Legrest Pad 1 133
04526X019 Plate, Legrest Pad 1 134
60264X001 Locknut (5/16-24) 1 135
1025104 Bracket, Legrest (Chrome) 1 136
11232X009 Screw, Lug (5/16-24 x 1-3/8") 1 137
1022848 Slide Tube, Articulating (Chrome) - Right 1 138
Chrome
For complete Legrest Support Assembly part nos., see Front Riggings Reference chart.
Form No.
06-108
37
To order call toll free 1-800-333-6900, or www.invacare.com
Page 39
Articulating Legrest Support - PHAL4A (Hemi)
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1022849 Slide Tube, Articulating (Chrome) - Left 1 138
1027377 Washer (#20) 1 139
1107321 Nut, Low Cap (5/16"-24) 1 140
8881091764 Pad, Legrest Vinyl - Right/Left 1 141 A
1068649 Screws, Phillips Head (#10-32 x 11/16") 2 142
1114761 Legrest Support Assembly, Articulating, Hemi,
Chrome - Right
1 1B,E
1114762 Legrest Support Assembly, Articulating, Hemi,
Chrome - Left
1 1B,E
A - Specify upholstery color U67 black when ordering.
B - Not Shown
C - Includes items 4-6
D - Includes items 1-9
E - Includes items 1-40. Legrest Calf Pad is not included with support assemblies. Please see items 41 and 42.
NOTE:
Chrome
For complete Legrest Support Assembly part nos., see Front Riggings Reference chart.
Form No.
06-108
38
To order call toll free 1-800-333-6900, or www.invacare.com
Page 40
Pivot/Slide Tube and Footplate
PHW93
Heel loops are not included. See Footrest and Legrest Accessories.
For complete pivot/slide tube and footplate assemblies, see Front Riggings Reference chart.
Form No.
06-108
39
To order call toll free 1-800-333-6900, or www.invacare.com
Page 41
Pivot/Slide Tube and Footplate
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1027097 Plug Button, Black (3/4") 1 21
1048834 Pivot/Slide Tube with Plug Button 1 12 C,A
1098906 Pivot/Slide Tube with Plug Button - 2" Longer 1 12 C,A
1086482 Pivot/Slide Tube with Plug Button - 4" Longer 1 12 C,A
1070762 Pivot/Slide Tube with Plug Button, Deluxe Aluminum 1 12 B
44200X027 Footplate, Aluminum - Medium (7-3/4" W x 6" L) 1 13 A
1043659 Footplate, Aluminum - Deluxe (8" W x 5-3/4" L) -
Right
1 13 B
1043660 Footplate, Aluminum - Deluxe (8" W x 5-3/4" L) -
Left
1 13 B
44200X025 Footplate, Aluminum - Extra Large (8" W x 8-1/2" L)
- Right
1 13 C
44200X026 Footplate, Aluminum - Extra Large (8" W x 8-1/2" L)
- Left
1 13 C
1016346 Cap, Tube End (7/8") 1 14 A
1027095 Plug Button, Black (7/8") 1 14 C
1006981 Spring, Leaf 1 25 D,A
1036120 Spring 1 25 B,D
1036123 Spring, Leaf 1 15 C
40120X001 Screw, Phillips Pan Head (#8-32 x 3/8") 1 26 E
1070168 Push Plug, Footplate 1 17
A - Standard Aluminum (1650)
B - Deluxe Aluminum (1450)
C - Extra Large Aluminum (1350)
D - Two per side
E - Deluxe takes one
NOTE:
PHW93
Heel loops are not included. See Footrest and Legrest Accessories.
For complete pivot/slide tube and footplate assemblies, see Front Riggings Reference chart.
Form No.
06-108
40
To order call toll free 1-800-333-6900, or www.invacare.com
Page 42
Pivot/Slide Tube and Footplates
PH904A and PHAL4A
Heel loops are not included. See Footrest and Legrest Accessories.
For complete pivot/slide tube and footplate assemblies, see Front Riggings Reference chart.
Form No.
06-108
41
To order call toll free 1-800-333-6900, or www.invacare.com
Page 43
Pivot/Slide Tube and Footplates
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1027097 Plug Button, Black (3/4") 1 21
1100568 Pivot/Slide Tube with Plug Button (Black) 1 12 B,D,A
1100569 Pivot/Slide Tube with Plug Button
Extra Large and Standard Aluminium - 2" Longer
1 12 B,D,A
1100570 Pivot/Slide Tube with Plug Button - 4" Longer 1 12 B,D,A
1041526 Pivot/Slide Tube with Plug Button (Steel) 1 12 B,E,A
1100571 Pivot/Slide Tube with Plug Button - Deluxe 1 12 C,D
1023804 Pivot/Slide Tube w/ Plug Button 1 12 C,E
44200X027 Footplate, Aluminum - Medium (7-3/4" W x 6" L) 1 13 A
1043659 Footplate, Aluminum - Deluxe (8" W x 5-3/4" L) -
Right
1 13 C
1043660 Footplate, Aluminum - Deluxe (8" W x 5-3/4" L) -
Left
1 13 C
44200X025 Footplate, Aluminum - Extra Large (8" W x 8-1/2" L)
- Right
1 13 B
44200X026 Footplate, Aluminum - Extra Large (8" W x 8-1/2" L)
- Left
1 13 B
1016346 Cap, Tube End (7/8") 1 14 A
1027095 Plug Button, Black (7/8") 1 14 B
1006981 Spring, Leaf 1 15 A
1036120 Spring 1 15 C,F
1036123 Spring, Leaf 1 15 B
40120X001 Screw, Phillips Pan Head (#8-32 x 3/8") 1 26 G
1070168 Push Plug, Footplate 1 17
A - Standard Aluminum (1650)
B - Extra Large Aluminum (1350)
C - Deluxe Aluminum (1450)
D - PH904A
E - PHAL4A
F - Two per side
G - Deluxe takes one
NOTE:
PH904A and PHAL4A
Heel loops are not included. See Footrest and Legrest Accessories.
For complete pivot/slide tube and footplate assemblies, see Front Riggings Reference chart.
Form No.
42
06-108
To order call toll free 1-800-333-6900, or www.invacare.com
Page 44
MK5 SPJ+ Joystick and Mounting Hardware
(For Ser. #'s Starting w/ 08C... & Before)
Form No.
06-108
43
To order call toll free 1-800-333-6900, or www.invacare.com
Page 45
MK5 SPJ+ Joystick and Mounting Hardware
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1127291 Joystick, SPJ+ 1 11 A,D,E
1040217 Knob, Joystick 1 12
1040218 Skirt, Joystick 1 13
1117464 Kit, 2" Offset Joystick Tube with Hardware 1 14 B
Plug Button, Black (7/8") 1 15
Tube, Joystick 2" Offest 1 16
Cable Tie (11-1/2" Long) 1 17
Screw, Phillips Pan Head (#10-32 x 1-1/8") 1 28
Spacer, Joystick Tube 1 19
1130582 Package, Plug Buttons, Black (7/8") 10 15
1095502 Package, Cable Ties (11-1/2" Long) 10 17
1115000 Kit, Joystick Tube Mounting Hardware - Captain/
Van Seat
1 110 C
1037610 Screw, Hex Head (1/4-20 x 1-5/8") 1 311
1105049 Clamp Assembly, Captain/Van Seat 1 112
1087219 Spacer (1/4 x 3/8 x 1") 1 313
1025195 Locknut (1/4-20) 1 314
1116404 Cable, Joystick Extension 1 115 E
1127293 Cable, Joystick SPJ+ 1 116 E
1127291 Joystick, SPJ+ 1 117 E
A - Includes joystick and items 2-3.
B - Includes item 5-9.
C - Includes items 11-14.
D - Battery Charger is plugged into the front port on the joystick to charge batteries.
E - Used before 4/1/08, if unit was manufactured after 3/31/08, See Joystick/Controller, A-Series Integrated page
NOTE:
(For Ser. #'s Starting w/ 08C... & Before)
Form No.
44
06-108
To order call toll free 1-800-333-6900, or www.invacare.com
Page 46
Electronics - MK5 NX Controllers and Battery Chargers
(For Ser. #'s Starting w/ 08C... & Before)
Form No.
06-108
45
To order call toll free 1-800-333-6900, or www.invacare.com
Page 47
Electronics - MK5 NX Controllers and Battery Chargers
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1143839 Controller, MK5 NX 40 Amp. 1 11 B
1127352 Screw, Phillips Pan Head (#8-32 x 1") 1 22 B
1056098 Locknut (#8-32) 1 23 B
1121089 Battery Charger, 3 Amp. Off Board 1 14 A
1109091 Programmer, Remote 1 15
A - Battery Charger plugs into the front port on the joystick to charge batteries.
B - Used before 4/1/08, if unit was manufactured after 3/31/08, See Joystick/Controller, A-Series Integrated page
NOTE:
(For Ser. #'s Starting w/ 08C... & Before)
Form No.
06-108
46
To order call toll free 1-800-333-6900, or www.invacare.com
Page 48
Electronics - Joystick/Controller, A-Series Integrated
NOTE: Joystick and Controller are combined into one unit and has
programming capabilities
(For Ser. #'s 08DSZ190001 & After)
Form No.
06-108
47
To order call toll free 1-800-333-6900, or www.invacare.com
Page 49
Electronics - Joystick/Controller, A-Series Integrated
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1147600 Joystick/Controller, A-Series Integrated 1 11 A,B
1143837 Kit, Literature (A-series Controller w/ Programming) 1 12 A
Warranty Card 1 1
Manual, Owner's M41 1 1
Manual, Instruction MK5 A-Series Programmer 1 1
Cable Tie (11-1/2" Long) 1 3
A - Not shown
B - This item was introduced to this product 4/1/08 starting with serial number 08DSZ190001.
NOTE:
NOTE: Joystick and Controller are combined into one unit and has
programming capabilities
(For Ser. #'s 08DSZ190001 & After)
Form No.
06-108
To order call toll free 1-800-333-6900, or www.invacare.com
48
Page 50
Oxygen Holder Assembly
Semi-Recline Van Seat
Form No.
06-108
49
To order call toll free 1-800-333-6900, or www.invacare.com
Page 51
Oxygen Holder Assembly
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1116956 Assembly, Oxygen Holder (D or E Tanks) 1 11 A
1116950 Pad, Non-Skid 1 12
1080866 Decal, Oxygen Warning - English 1 13
1116945 Spring, Oxygen Holder 1 14
1072319 Screw, Socket Button Head (#10-32 x 1/2") 1 15
1025735 Locknut (#10-32) 1 16
1116957 Instruction Sheet, Oxygen Holder 1 17
1021866 Bag, Poly (15" Wide x 26" Long) 1 18
1063960 Carton 1 19
HFO2-ML6 Assembly, Oxygen Holder (Home Filled Tank) 1 110 A
A - Includes Oxygen Holder plus items 2-9. For seats with an EXTERNAL (visible) hinge assembly.
NOTE:
Semi-Recline Van Seat
Form No.
06-108
50
To order call toll free 1-800-333-6900, or www.invacare.com
Page 52
Invacare Corporation
06-108
©2008 Invacare Corporation. Elyria, Ohio.
All rights reserved. Trademarks are
identified by the symbols ™ and ®. All
trademarks are owned by or licensed to
Invacare Corporation unless otherwise
noted.
(Released 6/4/08)
www.invacare.com
Yes, you can. ™
One Invacare Way
Elyria, Oh USA
44036-2125
800-333-6900
Technical Support
800-832-4707
Florida Technical Support
407-321-5630
Customer Service
800-333-6900
Form No.
Loading...
