Invacare Envoy User Manual

OWNER'S MANUAL

GUIDE DE LUTILISATEUR - FRENCH
CANADIAN

MANUAL DE INSTRUCCIONES - SPANISH



En voy

AEROSOL COMPRESSOR

COMPRESSEUR AÉROSOL

COMPRESOR PARA AEROSOL

DEALER: THIS MANUAL MUST BE GIVEN TO THE END USER.
USER: BEFORE USING THIS AEROSOL COMPRESSOR READ THIS

MANUAL AND SAVE FOR FUTURE REFERENCE.
FOURNISSEUR: CE MANUEL DOIT ÊTRE REMIS À LUTILISATEUR.

UTILISATEUR: AVANT DUTILISER LE COMPRESSEUR AÉROSOL, LIRE LE
MANUEL ET LE CONSERVER POUR Y RÉFÉRER ULTÉRIEUREMENT.

DISTRIBUIDOR: ENTREGUE ESTE MANUAL AL USUARIO FINAL.
USUARIO: ANTES DE USAR ESTE COMPRESOR DE AEROSOL, LEA ESTE

MANUAL Y CONSÉRVELO COMO REFERENCIA PARA EL FUTURO.

For more information regarding

Invacare products, parts, and services,

please visit: www.invacare.com

SPECIAL NOTES

SPECIAL NOTES

DANGER/WARNING/CAUTION notices as used in this
manual apply to hazards or unsafe practices which could
result in personal injury or property damage.

NOTICE

THE INFORMATION CONTAINED IN THIS DOCU­MENT IS SUBJECT TO CHANGE WITHOUT NOTICE.

THIS AEROSOL COMPRESSOR IS INTENDED FOR
HOUSEHOLD USE.

CHECK ALL PARTS FOR SHIPPING DAMAGE. IF
SHIPPING DAMAGE IS NOTED, DO NOT USE.
CONTACT DEALER/ CARRIER FOR FURTHER
INSTRUCTIONS.

WARNING

DO NOT INSTALL, MAINTAIN OR
OPERATE THIS EQUIPMENT WITHOUT
FIRST READING AND UNDERSTANDING
THIS MANUAL. IF YOU ARE UNABLE TO
UNDERSTAND THE DANGERS / WARNINGS
/ CAUTIONS AND INSTRUCTIONS,
CONTACT YOUR HOME HEALTHCARE
PROVIDER BEFORE ATTEMPTING TO USE
THIS EQUIPMENT - OTHERWISE INJURY OR
DAMAGE MAY RESULT.

SAVE THESE INSTRUCTIONS

2

TABLE OF CONTENTS

TABLE OF CONTENTS

SPECIAL NOTES ..................................................................... 2

IMPORTANT SAFEGUARDS ................................................. 4

SPECIFICATIONS AND SUPPLEMENTAL

INFORMATION........................................................................ 6

FEATURES ................................................................................ 8

HANDLING PROCEDURES ................................................... 9

Shipping and Transportation Instructions ...........................................9

Unpacking ...................................................................................................9

Inspection....................................................................................................9

Storage ........................................................................................................9

OPERATION............................................................................. 9

MAINTENANCE .................................................................... 12

Cleaning the Outer Case .....................................................................12

Cleaning the Nebulizer .........................................................................12

Cleaning or Replacing the Foam Intake Filter................................. 13

ACCESSORIES ....................................................................... 13

LIMITED WARRANTY .......................................................... 14

GUIDE DE LUTILISATEUR ................................................. 16

MANUAL DE INSTRUCCIONES ......................................... 30

3

IMPORTANT SAFEGUARDS

IMPORTANT SAFEGUARDS

READ ALL INSTRUCTIONS BEFORE USING

Caution: Federal law restricts this device to sale by or on
the order of a physician.

When using electrical products, especially when children
are present, basic safety precautions should always be
followed, including the following:

DANGER

TO REDUCE THE RISK OF ELECTROCUTION

ALWAYS unplug this product IMMEDIATELY after using.
DO NOT use while bathing.
DO NOT place or store product where it can fall or be

pulled into a tub or sink.
DO NOT reach for product that has fallen into water.

UNPLUG IMMEDIATELY.
DO NOT place or drop into water or other liquid.

WARNING

TO REDUCE THE RISK OF BURNS, ELECTROCUTION,

FIRE OR INJURY TO PERSONS

This product should NEVER be left unattended when
plugged in.

Close supervision is necessary when this product is used
by, on, or near CHILDREN AND PHYSICALLY
CHALLENGED INDIVIDUALS.

Use this product only for its intended use as described in
this manual. Use this product only under physicians
direction. DO NOT use attachments not recommended
by the manufacturer.

4

IMPORTANT SAFEGUARDS

WARNING

NEVER operate this product with a damaged cord or
plug, if it is not working properly, if it has been dropped
or damaged, or dropped into water; call Qualified Service
Personnel for examination and repair.

Keep the cord away from HEATED or HOT surfaces.
NEVER drop or insert any object into any opening.
NEVER use while sleeping or drowsy.
NEVER block the air openings of the product or place it

on a soft surface, such as a bed or couch, where the air
openings may be blocked. Keep the air openings free from
lint, hair and the like. Blocked openings may cause the
unit to shut down. Contact dealer immediately.

DO NOT use outdoors or operate where aerosol (spray)
products are being used or where oxygen is being adminis­tered in a closed environment such as an oxygen tent.

This unit is oil-less. DO NOT lubricate.

CAUTION

Risk of electric shock. Do not disassemble. Refer servicing
to qualified service personnel.

5

SPECIFICATIONS

SPECIFICATIONS AND

SUPPLEMENTAL INFORMATION

STANDARD SPECIFICATIONS

Electrical Requirements:

Running Current:

Sound Level:

Ambient Temperature Range:

Power Wattage:

Thermal Protector:

Foam Intake Filter:

Safety Systems:

Width:
Height:
Depth:

Weight:

Shipping Weight:

Regulatory Listing:

115 VAC, 60Hz, Single Phase

1.5 A @ 10 psig @ 115 volts (approx.)

55 dBA

50°F - 104°F (10°C - 40°C)

80 watts @ 10 psig

UL 547 Class B

Scot Industrial Foam, open cell 100 ppi,
polyurethane foam.

High temperature compressor shutdown.

11-inches

4.4-inches

8.5-inches

5Ibs.

6 lbs.

In compliance with UL 1431 Personal
Hygiene and Healthcare Appliances and
CSA 22.2 Electromedical Equipment.

6

SPECIFICATIONS

ELECTRICAL

This appliance has a polarized plug (one blade is wider than the other).
As a safety feature, this plug will fit in a polarized outlet only one way.
If the plug does not fit fully in the outlet, reverse the plug. If it still
does not fit, contact a qualified electrician. Do not attempt to defeat
this safety feature.

Compressor:
If the unit shuts down frequently, you may have a low voltage
situation.

Low voltage can also be suspected when:

1. The motor does not get up to full power or speed.

2. Home fuses or circuit breakers activate when starting compressor.

3. Lights dim or remain dim when compressor is started.

4. Other motor operated appliances fail to operate properly or
too many motor operated appliances are on same circuit.

The motor of this compressor has a thermal overload protector. If the
motor should overheat, the overload protector will shut off the motor.
If the unit shuts down and cannot be restarted, the motor must be
replaced. Call your dealer immediately.

Extension Cords:

Make certain extension cord is in good condition. Make certain extension
cord wire is NOT LESS than 18 gauge for 25 feet, 16 gauge for 50 feet and
14 gauge for 100 feet.

MAINTENANCE

Only authorized or factory-trained personnel should perform preventative
maintenance.

7

FEATURES

Thumb Latch

Storage

Compartment

Door

FEATURES

Reusable Foam Intake

Filter / Cover

Case

Separate Storage

Area for Cord

(Back of Unit)

Nebulizer

Mouthpiece

Storage

Compartment

Compressor Air Outlet

for Nebulizer Tubing

Power Switch

Nebulizer

Easy Grip Handle

with Nebulizer

Holder

Nebulizer Air Tubing

FIGURE 1 - FEATURES

8

HANDLING PROCEDURES/ OPERATION

HANDLING PROCEDURES

SHIPPING AND TRANSPORTATION INSTRUCTIONS

The shipping container has been designed to assure protection of
this device.

If this device is to be reshipped by common carrier, it should be packed
in the same carton. Extra cartons are available from Invacare.

UNPACKING

1. Check for any obvious damage to the carton or its contents. If
damage is evident, do NOT use. Notify Carrier/Invacare or your
local Invacare Dealer.

2. Remove all the loose packing from the carton.

3. Carefully remove all the components from the carton.

NOTE: Retain carton and packing materials for use in shipping or storing the
unit until use is required.

INSPECTION

1. Examine exterior for nicks, dents, scratches or other damage.
Inspect all components.

STORAGE

1. Store the repackaged device in a dry area.

2. DO NOT place other objects on top of the repackaged device.

OPERATION

Your nebulizer package includes a nebulizer mouthpiece, nebulizer, and
air tubing. These items are sold as a package only.

NOTE: Before initial operation, nebulizer should be cleaned. Follow the rec­ommended Cleaning Instructions in this Owners Manual.

9

OPERATION

WARNING

DO NOT run unit without filter.
Avoid operating this product in a dusty environment

which could cause premature compressor wear.

SETUP

1. Place the device on a table so that the controls can be reached
when seated.

2. Open the storage compartment door by lifting up the latch with
your thumb and pulling out with your fingers.

3. Remove nebulizer, nebulizer mouthpiece, and air tubing from the
storage compartment.

4. Secure one end of the tubing to the compressor air outlet
(FIGURE 1).

5. Connect the other end to the nebulizer.

Thumb Latch

Compressor Air Outlet for connecting

Nebulizer Air Tubing

Power Switch

FIGURE 1 - LOCATION OF COMPRESSOR AIR OUTLET

WARNING

In the case of high humidity, condensation may form
inside the internal tubing. Run the unit for two (2) minutes
before connecting the nebulizer to the tubing.

6. Add liquid medication to the nebulizer according to your
physicians prescription (FIGURE 2).

10

OPERATION

FIGURE 2 - ADDING
LIQUID MEDICATION

FIGURE 3 - LINE CORD

LOCATION

TO THE NEBULIZER

WARNING

Before plugging in the line cord, make sure that the power
switch is in the OFF (O) position.

7. Remove the line cord from the storage bin in the rear of the unit
(FIGURE 3).

8. Plug into a 115V/60Hz wall outlet.

9. Insert the nebulizer mouthpiece into the top of the nebulizer.

NOTE: Before attempting to start a cold unit, let the unit reach room
temperature in a heated area.

10. Press the power switch ON ( I ) to start the compressor.

11. Place mouthpiece between your teeth and close your mouth
(FIGURE 4).

FIGURE 4 - USING THE NEBULIZER

12. As aerosol begins to flow, inhale deeply, slowly, and hold breath
for 10 seconds. Then exhale slowly through the mouthpiece.

NOTE: If you need to rest during a treatment, place the nebulizer in the round
holder located within the handle opening. (Refer to Features Section in this manual.)

NOTE: Unit may be operated with the storage compartment door closed. Route
nebulizer air tubing through side opening in storage compartment door.

NOTE: Before storing supplies between treatments, clean and dry nebulizer.
(Refer to Maintenance Section in this manual.) Tighten caps on medication jars.

11

MAINTENANCE

MAINTENANCE

WARNING

Electrical shock hazard. DO NOT remove outer case of
this unit. All disassembly and maintenance of this unit
MUST BE done by a qualified Invacare Dealer.

CLEANING THE OUTER CASE

WARNING

UNPLUG unit before cleaning. DO NOT submerge in
water to clean. Clean outer case with damp cloth.

CLEANING THE NEBULIZER

NOTE - IRC1192 ONLY: With proper maintenance your nebulizer should last 30
days. Since the nebulizer is disposable, it is recommended that an extra nebulizer be
kept at all times.

NOTE - IRC1192D ONLY: With proper maintenance your Durable Sidestream
nebulizer should last for one (1) year.

NOTE: Clean the Nebulizer after every use and at least once a day.
NOTE - IRC 1192D ONLY: Durable Sidestream nebulizer is dishwasher safe.
NOTE: Your physician and/or a Invacare Dealer may specify certain cleaning

procedures. If so, follow their recommendations. If not, clean according to the
following instructions:

1. Remove the nebulizer and mouthpiece from the tubing.

2. Disassemble nebulizer chamber by turning counterclockwise and
separating.

3. Fill two (2) plastic containers or bowls:
A. Washing: Hot water/detergent solution.
B. Soaking: Hot water/vinegar solution (one [1] part vinegar to

three [3] parts water).

4. Thoroughly clean the nebulizer and mouthpiece in hot water/
detergent solution.

5. Remove from the water/detergent solution and rinse with clear hot
tap water.

6. Soak in hot water/vinegar solution for 30 minutes.

7. Rinse with hot tap water again and air dry thoroughly.

12

MAINTENANCE/ACCESSORIES

NOTE: If using medical disinfectant cleaners, follow manufacturers instructions
carefully.

8. Keep the outer surface of the tubing dust-free by wiping regularly.

NOTE: The nebulizer air tubing does not have to be washed internally because
only filtered air passes through the tubing.

CLEANING OR REPLACING THE
FOAM INTAKE FILTER

NOTE: Clean the filter once a month or sooner if filter discolors.

1. Unplug unit.

2. Open cover of storage compartment to gain access to filter.

3. Remove filter and clean with soap and water. Let dry thoroughly
before use.

4. Replace filter if it becomes clogged, torn or has a worn appearance.

NOTE: Regular filter cleaning/replacing is necessary to help ensure proper
compressor performance.

WARNING

DO NOT run unit without filter.

ACCESSORIES

Intake Filter
Filter Cover
Owner's Manual

TM

MS2100 Disposable Mobil-Mist
T-Piece, and 7 ft. tubing.

MS2200 Disposable Sidestream® Nebulizer (10 ml Capacity), w/Mouthpiece
and 7 ft. Tubing.

MS2400 Durable Sidestream® Nebulizer (10 ml Capacity), w/Mouth­piece and 7 ft. Tubing. One (1) Year Limited Warranty.

IRC1198 TruZone® PFM Peak Flow Meter.

NOTE: See Invacare Dealer for additional Nebulizers.

Nebulizer (5 ml Capacity), w/Mouthpiece,

13

WARRANTY

LIMITED WARRANTY

PLEASE NOTE: THE WARRANTY BELOW HAS BEEN
DRAFTED TO COMPLY WITH FEDERAL LAW APPLICABLE
TO PRODUCTS MANUFACTURED AFTER JULY 4,1975.

This warranty is extended only to the original purchaser of our
products.

This warranty gives you specific legal rights and you may also have
other legal rights which vary from state to state.

Invacare warrants the compressor of the Invacare EnvoyAerosol
Compressor to be free from defects in materials and workmanship
for a period of five (5) years from date of purchase. The nebulizer
chamber, nebulizer air tubing, and any other accessories are
excluded in this warranty. If within such warranty period any such
product shall be proven to Invacares satisfaction to be defective,
such product shall be repaired or replaced, at Invacares option.
This warranty does not include normal wear and tear or shipping
charges incurred in replacement part installation or repair of such
product. Invacares sole obligation and your exclusive remedy under
this warranty shall be limited to such repair or replacement.

For warranty service, please contact Invacares Service
Department during normal working hours at the Toll Free Number
listed.

Upon receiving notice of an alleged defect in a product, Invacare
will issue a serialized return authorization. It shall then be the
responsibility of the purchaser to return, at purchasers cost, to
either Invacares plant or service center as specified by Invacare in
advance. Defective component part(s) must be returned for war­ranty inspection using the serial number as identification within
thirty (30) days of return authorization date. DO NOT return
products to our factory without prior consent. C.O.D shipments will
be refused - please prepay shipping charges.

Limitations and Exclusions: The foregoing warranty shall not apply
to products subjected to negligence, accident, improper operation,
maintenance or storage, commercial or institutional use, products
modified without Invacares express written consent (including, but
not limited to, modification through the use of unauthorized parts
or attachments) or to products damaged by reason of repairs made
to any component without the specific consent of Invacare, or to a
product damaged by circumstances beyond Invacares control.

14
