Invacare BariatricBed User Manual
Invacare
®
IVC
™
Bariatric Bed
Invacare
®
IVC
™
Bariatric Bed
Invacare and the blue
medalion design are
registered trademarks
and Yes, you can., the
Bariatric Solutions design
and IVC are trademarks of
Invacare Corporation.
Specifications are subject
to change without notification.
© 2004
Invacare Corporation
Form No. 00-258
Rev. 10/04
T
he Invacare®IVC™Bariatric Bed is a heavy-duty full-electric bed frame designed for bariatric
individuals, capable of supporting up to 600 pounds. The bed frame extends to the edges of
the bed deck for better support. Using the hand pendant, the client or caregiver is able to
change the positioning of the head and foot sections,as well as the bed height. And,even though this
is a substantial bed, setup within the home is easy.
A B
FEATURES
• Heavy-duty frame design ensures added
strength for client support
• Heavy-duty bed sleep surface is 17% larger to
ensure comfortable positioning
• Split-spring design with removable bed ends for
ease in setup
• No special tools necessary for in-home setup
• Easy-release motor mounts allow quick
motor removal
• Robotically welded, steel frame construction
• Pendant allows for dynamic client positioning
• Quiet, smooth operation
• Emergency crank manually functions to lower
any raised section of bed
• UL73 approved
• Use with Invacare bariatric mattress
(BARMATT ) and bed rails (BAR6640IVC)
• 600-lb. client weight capacity
• Designed to meet K0456 criteria
Specifications
BAR600IVC Bariatric bed
Dimensions
Bed height* min. 14" - max. 22"
Sleep surface length 80"
Sleep surface width 42"
Overall length 88"
Overall width 42"
Universal bed end min. 27" - max. 34"
Carton size Shipping weight
BAR5000IVC Head spring 43.75" L x 10.5" w x 45.00" D 114 lb.
BAR5490IVC Foot spring 47.25" L x 10.5" w x 45.00" D 97 lb.
BAR5401IVC Bed ends 45.00" L x 7.5" w x 23.00" D 64 lb.
Limited warranty
All welds lifetime
Frame/structure 5 years
Mechanical/electrical 1 year
*Measurement from floor to bed deck.
‘‘Invacare says ‘Yes, you can™,’
and I couldn’t have said it
better myself.’’
Invacare Corporation
www.invacare.com
USA
One Invacare Way
Elyria, Ohio
44035-4190
(800) 333-6900
Canada
570 Matheson Blvd. E.
Unit 8
Mississauga, Ontario
L4Z 4G4 Canada
(800) 668-5324
A
Hand pendant
B
BAR600IVC with head raised
