Intuitive Aerial newton, NEWTON S2 User Manual
NEWTON
USER MANUAL 0.9.1
INTUITIVE AERIAL AB
2016-11-10
NEWTON i
USER MANUAL
CONTENTS
1 Introduction 1
1.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2 Warnings and reservations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.3 Physical layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 Operation 6
2.1 Unboxing and assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.2 Attaching camera and balancing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.3 Starting and connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.4 Tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.5 User Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.6 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3 Maintenance 13
3.1 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.2 Firmware update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.3 Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4 Troubleshooting 15
A Connectors and pin-outs 16
A.1 Pan-box connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
A.2 Cradle connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
B Technical specifications 18
C Revisions 20
DO NOT DISTRIBUTE
Copyright © 2016 Intuitive Aerial AB
NEWTON 1
USER MANUAL
1 Introduction
1.1 OVERVIEW
The Newton remote head is a fully electronically stabilized, three axis with free pan made for broadcast
and film production from cranes, wires, rails and vehicles.
The Newton is designed to be paired with the Dominion remote controller. Connection between
them can be either wireless or wired and the Dominion provides full control of all the functions of the
Newton.
1.2 WARNINGS AND RESERVATIONS
WARNING
Before connecting or turning on the Newton remote head read this manual
carefully.
WARNING
Do not power or charge the Newton controller with anything but external
power supplies delivered and approved by Intuitive Aerial for use with
Newton. Doing so can permanently damage or destroy your Newton.
Newton accepts external power between 12 volt and 26 volt. Powering it
with more than that can permanently damage it.
WARNING
Make sure that the camera and any other equipment is properly secured
before turning on the Newton.
WARNING
The Newton is rain protected but it is not water proof, so do not expose it
to direct spraying water or submersion into water.
WARNING
To get the best possible range, always extend the antennas vertically when
using and make sure they have a free line of sight to the controller.
DO NOT DISTRIBUTE
Copyright © 2016 Intuitive Aerial AB
NEWTON 2
USER MANUAL
WARNING
Performing any disassembly, modification or service not explicitly outlined
in this manual will void any warranties on the system.
DO NOT DISTRIBUTE
Copyright © 2016 Intuitive Aerial AB
NEWTON 3
USER MANUAL
1.3 PHYSICAL LAYOUT
6
5
4
3
2
1
8
7
Figure 1.1: Newton overview 1
Table 1.1: Overview Descriptions
Item Description
1,3 Battery
2 Attachment points
4 Battery clamp
5 Side-to-side lock clamp
6 Cradle connectors
7 Pan balance adjustment screw
8 Pan-box connectors
DO NOT DISTRIBUTE
Copyright © 2016 Intuitive Aerial AB
NEWTON 4
USER MANUAL
9
10
11
16
14
17
20
23
21
18
12
19
13
15
22
Figure 1.2: Newton overview 2
Table 1.2: Overview Descriptions
Item Description
9,13 Antennas
10 UI buttons
11 Display
12 Power switch
14 Vertical adjustment screw
15 Cradle connectors
16 Vertical lock clamp
17 Cradle release clamp
18 Cradle
19 Camera dovetail
20 Horizontal adjustment screw
21 Front-back lock clamp
22 Top-mount attachment
23 Pan balance lock clamp
DO NOT DISTRIBUTE
Copyright © 2016 Intuitive Aerial AB
